0-61 — BATTERY AND ENGINE ELECTRICAL PARTS (#33792) — 60 parça

1 112 3 31 30 58 37 225 3 42 42

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date	A	B
1	02.341 CABLE; BATTERY L=280	8-98025-412-3	01	1	0803-	●	●
3	02.525 HARNESS; CABLE,BATTERY TO STARTE BATTERY 115E41L<8MA> (D) L=400	8-98056-339-1	01	1	0803-1203	●	●
3	02.525 HARNESS; CABLE,BATTERY TO STARTE BATTERY 115E41L<8MA> (D) L=400	8-98201-105-0	01	1	1204-	●	●
3	02.525 HARNESS; CABLE,BATTERY TO STARTE EXC. BATTERY 115E41L<8MA> (B) L=200	8-98056-337-1	01	1	0803-	●	●
3	02.525 HARNESS; CABLE,BATTERY TO STARTE M/T MYY6S(RST) TRANSMISSION CONTROL-SMOOTHER DELETE(8GJ) EXC. BATTERY 115E41L<8MA> (A)	8-98067-966-4	01	1	0803-1409	●	●
3	02.525 HARNESS; CABLE,BATTERY TO STARTE M/T MYY6S(RST) TRANSMISSION CONTROL-SMOOTHER DELETE(8GJ) EXC. BATTERY 115E41L<8MA> (A)	8-98294-718-0	01	1	1410-	●	●
3	02.525 HARNESS; CABLE,BATTERY TO STARTE M/T MYY6S(RST) TRANSMISSION CONTROL-SMOOTHER DELETE(8GJ) BATTERY 115E41L<8MA> (C)	8-98070-230-2	01	1	0803-1409	●	●
3	02.525 HARNESS; CABLE,BATTERY TO STARTE M/T MYY6S(RST) TRANSMISSION CONTROL-SMOOTHER DELETE(8GJ) BATTERY 115E41L<8MA> (C)	8-98294-721-0	01	1	1410-	●	●
3	02.525 HARNESS; CABLE,BATTERY TO STARTE M/T MYY6S(RST) TRANSMISSION CONTROL-SMOOTHER(8GF) BATTERY 115E41L<8MA> (C)	8-98077-141-2	01	1	0803-1409	●	●
3	02.525 HARNESS; CABLE,BATTERY TO STARTE M/T MYY6S(RST) TRANSMISSION CONTROL-SMOOTHER(8GF) BATTERY 115E41L<8MA> (C)	8-98294-726-0	01	1	1410-	●	●
3	02.525 HARNESS; CABLE,BATTERY TO STARTE M/T MYY6S(RST) TRANSMISSION CONTROL-SMOOTHER(8GF) EXC. BATTERY 115E41L<8MA> (A)	8-98077-138-4	01	1	0803-1409	●	●
3	02.525 HARNESS; CABLE,BATTERY TO STARTE M/T MYY6S(RST) TRANSMISSION CONTROL-SMOOTHER(8GF) EXC. BATTERY 115E41L<8MA> (A)	8-98294-724-0	01	1	1410-	●	●
3	02.525 HARNESS; CABLE,BATTERY TO STARTE M/T MZZ6F(RSR) TRANSMISSION CONTROL-SMOOTHER DELETE(8GJ) EXC. BATTERY 115E41L<8MA> (A)	8-98077-137-4	01	1	0803-1409	●	●
3	02.525 HARNESS; CABLE,BATTERY TO STARTE M/T MZZ6F(RSR) TRANSMISSION CONTROL-SMOOTHER DELETE(8GJ) EXC. BATTERY 115E41L<8MA> (A)	8-98294-723-0	01	1	1410-	●	●
3	02.525 HARNESS; CABLE,BATTERY TO STARTE M/T MZZ6F(RSR) TRANSMISSION CONTROL-SMOOTHER DELETE(8GJ) BATTERY 115E41L<8MA> (C)	8-98077-140-2	01	1	0803-1409	●	●
3	02.525 HARNESS; CABLE,BATTERY TO STARTE M/T MZZ6F(RSR) TRANSMISSION CONTROL-SMOOTHER DELETE(8GJ) BATTERY 115E41L<8MA> (C)	8-98294-725-0	01	1	1410-	●	●
3	02.525 HARNESS; CABLE,BATTERY TO STARTE M/T MZZ6F(RSR) TRANSMISSION CONTROL-SMOOTHER(8GF) BATTERY 115E41L<8MA> (C)	8-98099-102-1	01	1	0803-1409	●	●
3	02.525 HARNESS; CABLE,BATTERY TO STARTE M/T MZZ6F(RSR) TRANSMISSION CONTROL-SMOOTHER(8GF) BATTERY 115E41L<8MA> (C)	8-98294-731-0	01	1	1410-	●	●
3	02.525 HARNESS; CABLE,BATTERY TO STARTE M/T MZZ6F(RSR) TRANSMISSION CONTROL-SMOOTHER(8GF) EXC. BATTERY 115E41L<8MA> (A)	8-98099-101-2	01	1	0803-1409	●	●
3	02.525 HARNESS; CABLE,BATTERY TO STARTE M/T MZZ6F(RSR) TRANSMISSION CONTROL-SMOOTHER(8GF) EXC. BATTERY 115E41L<8MA> (A)	8-98294-730-0	01	1	1410-	●	●
30	02.334 NUT; CABLE,STARTER TO BATTERY M8	0-91110-508-0	01	1	0803-	●	●
31	02.334 WASHER; LK,CABLE,STARTER TO BATT 02.559 ID=8.2	0-91510-808-0	01	1	0803-	●	●
37	02.343 CAP; TERMINAL,BATTERY CABLE M/T MZZ6F(RSR),M/T MYY6S(RST) TRANSMISSION CONTROL-SMOOTHER(8GF), TRANSMISSION CONTROL-SMOOTHER DELETE(8GJ)	8-98042-507-0	01	1	0803-	●	●
42	02.343 BOLT; BRKT,BATTERY CABLE 02.500 (B) M6X16 FLANGE	8-97329-599-0	01	1	0803-	●	●
42	02.343 BOLT; BRKT,BATTERY CABLE BATTERY 115E41L<8MA> 06.216 (A) M8X25 FLANGE	0-28650-825-0	01	1	0803-	●	●
58	02.343 BOLT; CABLE,BATTERY M8X25 W/LK&PL WASHER	8-97087-203-0	01	1	0803-1004	●	●
58	02.343 BOLT; CABLE,BATTERY M8X24 W/PL WASHER	8-98141-256-1	01	1	1005-	●	●
112	02.343 TERMINAL; BATTERY <+>	8-97365-771-0	01	1	0803-	●	●
225	02.343 BLOCK; TERMINAL M/T MZZ6F(RSR),M/T MYY6S(RST) TRANSMISSION CONTROL-SMOOTHER(8GF), TRANSMISSION CONTROL-SMOOTHER DELETE(8GJ)	8-98029-689-0	01	1	0803-1409	●	●
225	02.343 BLOCK; TERMINAL M/T MZZ6F(RSR),M/T MYY6S(RST) TRANSMISSION CONTROL-SMOOTHER(8GF), TRANSMISSION CONTROL-SMOOTHER DELETE(8GJ)	8-98294-524-0	01	1	1410-	●	●

58 1 3 3 37 225 31 30 112 42

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date	A	B
1	02.341 CABLE; BATTERY L=280	8-98025-412-3	01	1	0803-	●	●
3	02.525 HARNESS; CABLE,BATTERY TO STARTE BATTERY 115E41L<8MA> (D) L=400	8-98056-339-1	01	1	0803-1203	●	●
3	02.525 HARNESS; CABLE,BATTERY TO STARTE BATTERY 115E41L<8MA> (D) L=400	8-98201-105-0	01	1	1204-	●	●
3	02.525 HARNESS; CABLE,BATTERY TO STARTE EXC. BATTERY 115E41L<8MA> (B) L=200	8-98056-337-1	01	1	0803-	●	●
3	02.525 HARNESS; CABLE,BATTERY TO STARTE M/T MYY6S(RST) TRANSMISSION CONTROL-SMOOTHER DELETE(8GJ) EXC. BATTERY 115E41L<8MA> (A)	8-98067-966-4	01	1	0803-1409	●	●
3	02.525 HARNESS; CABLE,BATTERY TO STARTE M/T MYY6S(RST) TRANSMISSION CONTROL-SMOOTHER DELETE(8GJ) EXC. BATTERY 115E41L<8MA> (A)	8-98294-718-0	01	1	1410-	●	●
3	02.525 HARNESS; CABLE,BATTERY TO STARTE M/T MYY6S(RST) TRANSMISSION CONTROL-SMOOTHER DELETE(8GJ) BATTERY 115E41L<8MA> (C)	8-98070-230-2	01	1	0803-1409	●	●
3	02.525 HARNESS; CABLE,BATTERY TO STARTE M/T MYY6S(RST) TRANSMISSION CONTROL-SMOOTHER DELETE(8GJ) BATTERY 115E41L<8MA> (C)	8-98294-721-0	01	1	1410-	●	●
3	02.525 HARNESS; CABLE,BATTERY TO STARTE M/T MYY6S(RST) TRANSMISSION CONTROL-SMOOTHER(8GF) BATTERY 115E41L<8MA> (C)	8-98077-141-2	01	1	0803-1409	●	●
3	02.525 HARNESS; CABLE,BATTERY TO STARTE M/T MYY6S(RST) TRANSMISSION CONTROL-SMOOTHER(8GF) BATTERY 115E41L<8MA> (C)	8-98294-726-0	01	1	1410-	●	●
3	02.525 HARNESS; CABLE,BATTERY TO STARTE M/T MYY6S(RST) TRANSMISSION CONTROL-SMOOTHER(8GF) EXC. BATTERY 115E41L<8MA> (A)	8-98077-138-4	01	1	0803-1409	●	●
3	02.525 HARNESS; CABLE,BATTERY TO STARTE M/T MYY6S(RST) TRANSMISSION CONTROL-SMOOTHER(8GF) EXC. BATTERY 115E41L<8MA> (A)	8-98294-724-0	01	1	1410-	●	●
3	02.525 HARNESS; CABLE,BATTERY TO STARTE M/T MZZ6F(RSR) TRANSMISSION CONTROL-SMOOTHER DELETE(8GJ) EXC. BATTERY 115E41L<8MA> (A)	8-98077-137-4	01	1	0803-1409	●	●
3	02.525 HARNESS; CABLE,BATTERY TO STARTE M/T MZZ6F(RSR) TRANSMISSION CONTROL-SMOOTHER DELETE(8GJ) EXC. BATTERY 115E41L<8MA> (A)	8-98294-723-0	01	1	1410-	●	●
3	02.525 HARNESS; CABLE,BATTERY TO STARTE M/T MZZ6F(RSR) TRANSMISSION CONTROL-SMOOTHER DELETE(8GJ) BATTERY 115E41L<8MA> (C)	8-98077-140-2	01	1	0803-1409	●	●
3	02.525 HARNESS; CABLE,BATTERY TO STARTE M/T MZZ6F(RSR) TRANSMISSION CONTROL-SMOOTHER DELETE(8GJ) BATTERY 115E41L<8MA> (C)	8-98294-725-0	01	1	1410-	●	●
3	02.525 HARNESS; CABLE,BATTERY TO STARTE M/T MZZ6F(RSR) TRANSMISSION CONTROL-SMOOTHER(8GF) BATTERY 115E41L<8MA> (C)	8-98099-102-1	01	1	0803-1409	●	●
3	02.525 HARNESS; CABLE,BATTERY TO STARTE M/T MZZ6F(RSR) TRANSMISSION CONTROL-SMOOTHER(8GF) BATTERY 115E41L<8MA> (C)	8-98294-731-0	01	1	1410-	●	●
3	02.525 HARNESS; CABLE,BATTERY TO STARTE M/T MZZ6F(RSR) TRANSMISSION CONTROL-SMOOTHER(8GF) EXC. BATTERY 115E41L<8MA> (A)	8-98099-101-2	01	1	0803-1409	●	●
3	02.525 HARNESS; CABLE,BATTERY TO STARTE M/T MZZ6F(RSR) TRANSMISSION CONTROL-SMOOTHER(8GF) EXC. BATTERY 115E41L<8MA> (A)	8-98294-730-0	01	1	1410-	●	●
30	02.334 NUT; CABLE,STARTER TO BATTERY M8	0-91110-508-0	01	1	0803-	●	●
31	02.334 WASHER; LK,CABLE,STARTER TO BATT 02.559 ID=8.2	0-91510-808-0	01	1	0803-	●	●
37	02.343 CAP; TERMINAL,BATTERY CABLE M/T MZZ6F(RSR),M/T MYY6S(RST) TRANSMISSION CONTROL-SMOOTHER(8GF), TRANSMISSION CONTROL-SMOOTHER DELETE(8GJ)	8-98042-507-0	01	1	0803-	●	●
42	02.343 BOLT; BRKT,BATTERY CABLE 02.500 (B) M6X16 FLANGE	8-97329-599-0	01	1	0803-	●	●
42	02.343 BOLT; BRKT,BATTERY CABLE BATTERY 115E41L<8MA> 06.216 (A) M8X25 FLANGE	0-28650-825-0	01	1	0803-	●	●
58	02.343 BOLT; CABLE,BATTERY M8X25 W/LK&PL WASHER	8-97087-203-0	01	1	0803-1004	●	●
58	02.343 BOLT; CABLE,BATTERY M8X24 W/PL WASHER	8-98141-256-1	01	1	1005-	●	●
112	02.343 TERMINAL; BATTERY <+>	8-97365-771-0	01	1	0803-	●	●
225	02.343 BLOCK; TERMINAL M/T MZZ6F(RSR),M/T MYY6S(RST) TRANSMISSION CONTROL-SMOOTHER(8GF), TRANSMISSION CONTROL-SMOOTHER DELETE(8GJ)	8-98029-689-0	01	1	0803-1409	●	●
225	02.343 BLOCK; TERMINAL M/T MZZ6F(RSR),M/T MYY6S(RST) TRANSMISSION CONTROL-SMOOTHER(8GF), TRANSMISSION CONTROL-SMOOTHER DELETE(8GJ)	8-98294-524-0	01	1	1410-	●	●

İpucu: çizimdeki balona veya tablodaki Balon sütununa tıkla; ilgili parçalar vurgulanır. Birden çok çizim varsa üstteki seçim kutusu/oklarla gezin.
