3-58 — FIXING PARTS; OIL PIPING (#33627) — 151 parça

61 4

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date	A	B
4	BOLT; BRKT ANTI LOCK BRAKE(JE5) M6X14 W/LK&PL WASHER	8-97086-822-0	04	1	9505-9607	●	●
61	BOLT; BRK PIPE M6X16 W/LK WASHER	9-01900-616-0	02	1	9112-9204	●	●
61	BOLT; BRK PIPE M6X16 W/LK WASHER	0-50040-616-0	02	1	9205-	●	●

6 11 11 11 22 13 11 11 11 11 12

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date	A	B
6	CLIP; PIPE 4ZE1 ENG(RLJ),6VD1 SOHC ENG(RLU) EXC. EUROPE/CANARY EQUIPMENT(EK4),ANTI LOCK BRAKE(JE5)	8-94468-730-0	01	1	9209-9504	●	●
11	CLIP; OIL PIPE (C) ID=4.6X2	8-94241-454-0	01	1	9112-9607	●	●
11	CLIP; OIL PIPE EUROPE/CANARY EQUIPMENT(EK4) EXC. ANTI LOCK BRAKE(JE5) (C) ID=4.6X2	8-94241-454-0	01	1	9608-	●	●
11	CLIP; OIL PIPE (C) ID=4.6X2	8-94241-454-0	01	1	9608-	●	●
11	CLIP; OIL PIPE (B)	8-97035-570-3	01	1	9112-	●	●
11	CLIP; OIL PIPE (I)	8-97069-554-1	01	1	9112-	●	●
11	CLIP; OIL PIPE (G)	8-94435-553-0	01	1	9204-9409	●	●
11	CLIP; OIL PIPE 4JG2 ENG(RJC),4ZE1 ENG(RLJ) (G)	8-94435-553-0	01	1	9410-9504	●	●
11	CLIP; OIL PIPE 6VD1 SOHC ENG(RLU) EXC. ANTI LOCK BRAKE(JE5) (G)	8-94435-553-0	01	1	9410-9504	●	●
11	CLIP; OIL PIPE 6VD1 SOHC ENG(RLU) ANTI LOCK BRAKE(JE5) EXC. EUROPE/CANARY EQUIPMENT(EK4) (G)	8-94435-553-0	01	1	9410-9504	●	●
11	CLIP; OIL PIPE 4JG2 ENG(RJC),4ZE1 ENG(RLJ) (G)	8-94435-553-0	01	1	9505-9607	●	●
11	CLIP; OIL PIPE 6VD1 SOHC ENG(RLU) EXC. ANTI LOCK BRAKE(JE5) (G)	8-94435-553-0	01	1	9505-9607	●	●
11	CLIP; OIL PIPE 4JG2 ENG(RJC) EUROPE/CANARY EQUIPMENT(EK4) (G)	8-94435-553-0	01	1	9608-9706	●	●
11	CLIP; OIL PIPE 6VD1 SOHC ENG(RLU) EUROPE/CANARY EQUIPMENT(EK4) EXC. ANTI LOCK BRAKE(JE5) (G)	8-94435-553-0	01	1	9608-9706	●	●
11	CLIP; OIL PIPE EXC. EUROPE/CANARY EQUIPMENT(EK4) (G)	8-94435-553-0	01	1	9608-9706	●	●
11	CLIP; OIL PIPE 4JG2 ENG(RJC) (G)	8-94435-553-0	01	1	9707-	●	●
11	CLIP; OIL PIPE 4ZE1 ENG(RLJ),6VD1 SOHC ENG(RLU) EXC. EUROPE/CANARY EQUIPMENT(EK4),ANTI LOCK BRAKE(JE5) (G)	8-94435-553-0	01	1	9707-	●	●
11	CLIP; OIL PIPE 6VD1 SOHC ENG(RLU) EUROPE/CANARY EQUIPMENT(EK4) EXC. ANTI LOCK BRAKE(JE5) (G)	8-94435-553-0	01	1	9707-	●	●
11	CLIP; OIL PIPE EXC. ANTI LOCK BRAKE(JE5) (D)	8-94107-743-0	01	1	9112-9409	●	●
11	CLIP; OIL PIPE 6VD1 SOHC ENG(RLU) EUROPE/CANARY EQUIPMENT(EK4) (D)	8-94107-743-0	01	1	9410-9504	●	●
11	CLIP; OIL PIPE 6VD1 SOHC ENG(RLU) (D)	8-94107-743-0	01	1	9505-	●	●
11	CLIP; OIL PIPE EUROPE/CANARY EQUIPMENT(EK4) ANTI LOCK BRAKE(JE5) (E)	8-94338-104-0	01	1	9112-9407	●	●
11	CLIP; OIL PIPE EXC. EUROPE/CANARY EQUIPMENT(EK4) (E)	8-94338-104-0	01	1	9112-9407	●	●
11	CLIP; OIL PIPE 4JG2 ENG(RJC),4JG1 ENG(RLT) EXC. EUROPE/CANARY EQUIPMENT(EK4),ANTI LOCK BRAKE(JE5) (E)	8-94338-104-0	01	1	9408-9409	●	●
11	CLIP; OIL PIPE 4JG2 ENG(RJC) ANTI LOCK BRAKE(JE5) (E)	8-94338-104-0	01	1	9408-9409	●	●
11	CLIP; OIL PIPE 4JG2 ENG(RJC),4JG1 ENG(RLT) EXC. EUROPE/CANARY EQUIPMENT(EK4),ANTI LOCK BRAKE(JE5) (E)	8-94338-104-0	01	1	9410-9504	●	●
11	CLIP; OIL PIPE 4JG2 ENG(RJC) ANTI LOCK BRAKE(JE5) (E)	8-94338-104-0	01	1	9410-9504	●	●
11	CLIP; OIL PIPE 6VD1 SOHC ENG(RLU) EUROPE/CANARY EQUIPMENT(EK4) ANTI LOCK BRAKE(JE5) (E)	8-94338-104-0	01	1	9410-9504	●	●
11	CLIP; OIL PIPE 4JG2 ENG(RJC) EXC. EUROPE/CANARY EQUIPMENT(EK4) (E)	8-94338-104-0	01	1	9505-	●	●
11	CLIP; OIL PIPE EUROPE/CANARY EQUIPMENT(EK4) ANTI LOCK BRAKE(JE5) (J) ID=6.35 & 6.35	8-94474-113-0	02	1	9410-9504	●	●
11	CLIP; OIL PIPE EUROPE/CANARY EQUIPMENT(EK4) ANTI LOCK BRAKE(JE5) (J) ID=6.35 & 6.35	8-94474-113-0	03	1	9505-	●	●
11	CLIP; OIL PIPE 4JG2 ENG(RJC) ANTI LOCK BRAKE(JE5) (A)	8-97037-992-3	04	1	9112-	●	●
11	CLIP; OIL PIPE 4JG2 ENG(RJC),4JG1 ENG(RLT) EXC. ANTI LOCK BRAKE(JE5) (K) H=9.5	8-94375-291-0	04	1	9112-	●	●
11	CLIP; OIL PIPE 4ZE1 ENG(RLJ),6VD1 SOHC ENG(RLU) EXC. ANTI LOCK BRAKE(JE5) (K) H=9.5	8-94375-291-0	05	1	9112-	●	●
11	CLIP; OIL PIPE 6VD1 SOHC ENG(RLU) ANTI LOCK BRAKE(JE5) (D) ID=4.76X3	8-94122-333-0	03	1	9112-9402	●	●
11	CLIP; OIL PIPE 6VD1 SOHC ENG(RLU) ANTI LOCK BRAKE(JE5) (F) ID=4.8 & 10	8-94152-110-0	01	1	9112-9201	●	●
11	CLIP; OIL PIPE 6VD1 SOHC ENG(RLU) ANTI LOCK BRAKE(JE5) (A)	8-97037-992-3	05	1	9112-	●	●
11	CLIP; OIL PIPE 6VD1 SOHC ENG(RLU) ANTI LOCK BRAKE(JE5) (D) ID=4.76X3	8-94122-333-0	02	1	9309-	●	●
11	CLIP; OIL PIPE 6VD1 SOHC ENG(RLU) EUROPE/CANARY EQUIPMENT(EK4) ANTI LOCK BRAKE(JE5) (H) ID=6.4 & 4.8X2	8-94146-043-0	01	1	9410-	●	●
11	CLIP; OIL PIPE 6VD1 SOHC ENG(RLU) EUROPE/CANARY EQUIPMENT(EK4) ANTI LOCK BRAKE(JE5) (L) ID=4.8X3	8-94487-369-0	01	1	9411-	●	●
12	BRACKET; OIL PIPE	8-94382-253-0	01	1	9112-	●	●
13	BOLT; BRKT,OIL PIPE M6X12 W/LK WASHER	9-01900-612-0	01	1	9112-9204	●	●
13	BOLT; BRKT,OIL PIPE M6X12 W/LK WASHER	0-50040-612-0	01	1	9205-	●	●
22	CLIP; PIPE TO FRAME 4JG2 ENG(RJC),4JG1 ENG(RLT),6VD1 SOHC ENG(RLU)	8-94442-883-1	01	1	9112-	●	●
22	CLIP; PIPE TO FRAME 4ZE1 ENG(RLJ)	8-94442-883-1	02	1	9112-	●	●

11 18 11 22 13 11 11 11 11 12 11 11

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date	A	B
11	CLIP; OIL PIPE (C) ID=4.6X2	8-94241-454-0	01	1	9112-9607	●	●
11	CLIP; OIL PIPE EUROPE/CANARY EQUIPMENT(EK4) EXC. ANTI LOCK BRAKE(JE5) (C) ID=4.6X2	8-94241-454-0	01	1	9608-	●	●
11	CLIP; OIL PIPE (C) ID=4.6X2	8-94241-454-0	01	1	9608-	●	●
11	CLIP; OIL PIPE (B)	8-97035-570-3	01	1	9112-	●	●
11	CLIP; OIL PIPE (I)	8-97069-554-1	01	1	9112-	●	●
11	CLIP; OIL PIPE (G)	8-94435-553-0	01	1	9204-9409	●	●
11	CLIP; OIL PIPE 4JG2 ENG(RJC),4ZE1 ENG(RLJ) (G)	8-94435-553-0	01	1	9410-9504	●	●
11	CLIP; OIL PIPE 6VD1 SOHC ENG(RLU) EXC. ANTI LOCK BRAKE(JE5) (G)	8-94435-553-0	01	1	9410-9504	●	●
11	CLIP; OIL PIPE 6VD1 SOHC ENG(RLU) ANTI LOCK BRAKE(JE5) EXC. EUROPE/CANARY EQUIPMENT(EK4) (G)	8-94435-553-0	01	1	9410-9504	●	●
11	CLIP; OIL PIPE 4JG2 ENG(RJC),4ZE1 ENG(RLJ) (G)	8-94435-553-0	01	1	9505-9607	●	●
11	CLIP; OIL PIPE 6VD1 SOHC ENG(RLU) EXC. ANTI LOCK BRAKE(JE5) (G)	8-94435-553-0	01	1	9505-9607	●	●
11	CLIP; OIL PIPE 4JG2 ENG(RJC) EUROPE/CANARY EQUIPMENT(EK4) (G)	8-94435-553-0	01	1	9608-9706	●	●
11	CLIP; OIL PIPE 6VD1 SOHC ENG(RLU) EUROPE/CANARY EQUIPMENT(EK4) EXC. ANTI LOCK BRAKE(JE5) (G)	8-94435-553-0	01	1	9608-9706	●	●
11	CLIP; OIL PIPE EXC. EUROPE/CANARY EQUIPMENT(EK4) (G)	8-94435-553-0	01	1	9608-9706	●	●
11	CLIP; OIL PIPE 4JG2 ENG(RJC) (G)	8-94435-553-0	01	1	9707-	●	●
11	CLIP; OIL PIPE 4ZE1 ENG(RLJ),6VD1 SOHC ENG(RLU) EXC. EUROPE/CANARY EQUIPMENT(EK4),ANTI LOCK BRAKE(JE5) (G)	8-94435-553-0	01	1	9707-	●	●
11	CLIP; OIL PIPE 6VD1 SOHC ENG(RLU) EUROPE/CANARY EQUIPMENT(EK4) EXC. ANTI LOCK BRAKE(JE5) (G)	8-94435-553-0	01	1	9707-	●	●
11	CLIP; OIL PIPE EXC. ANTI LOCK BRAKE(JE5) (D)	8-94107-743-0	01	1	9112-9409	●	●
11	CLIP; OIL PIPE 6VD1 SOHC ENG(RLU) EUROPE/CANARY EQUIPMENT(EK4) (D)	8-94107-743-0	01	1	9410-9504	●	●
11	CLIP; OIL PIPE 6VD1 SOHC ENG(RLU) (D)	8-94107-743-0	01	1	9505-	●	●
11	CLIP; OIL PIPE EUROPE/CANARY EQUIPMENT(EK4) ANTI LOCK BRAKE(JE5) (E)	8-94338-104-0	01	1	9112-9407	●	●
11	CLIP; OIL PIPE EXC. EUROPE/CANARY EQUIPMENT(EK4) (E)	8-94338-104-0	01	1	9112-9407	●	●
11	CLIP; OIL PIPE 4JG2 ENG(RJC),4JG1 ENG(RLT) EXC. EUROPE/CANARY EQUIPMENT(EK4),ANTI LOCK BRAKE(JE5) (E)	8-94338-104-0	01	1	9408-9409	●	●
11	CLIP; OIL PIPE 4JG2 ENG(RJC) ANTI LOCK BRAKE(JE5) (E)	8-94338-104-0	01	1	9408-9409	●	●
11	CLIP; OIL PIPE 4JG2 ENG(RJC),4JG1 ENG(RLT) EXC. EUROPE/CANARY EQUIPMENT(EK4),ANTI LOCK BRAKE(JE5) (E)	8-94338-104-0	01	1	9410-9504	●	●
11	CLIP; OIL PIPE 4JG2 ENG(RJC) ANTI LOCK BRAKE(JE5) (E)	8-94338-104-0	01	1	9410-9504	●	●
11	CLIP; OIL PIPE 6VD1 SOHC ENG(RLU) EUROPE/CANARY EQUIPMENT(EK4) ANTI LOCK BRAKE(JE5) (E)	8-94338-104-0	01	1	9410-9504	●	●
11	CLIP; OIL PIPE 4JG2 ENG(RJC) EXC. EUROPE/CANARY EQUIPMENT(EK4) (E)	8-94338-104-0	01	1	9505-	●	●
11	CLIP; OIL PIPE EUROPE/CANARY EQUIPMENT(EK4) ANTI LOCK BRAKE(JE5) (J) ID=6.35 & 6.35	8-94474-113-0	02	1	9410-9504	●	●
11	CLIP; OIL PIPE EUROPE/CANARY EQUIPMENT(EK4) ANTI LOCK BRAKE(JE5) (J) ID=6.35 & 6.35	8-94474-113-0	03	1	9505-	●	●
11	CLIP; OIL PIPE 4JG2 ENG(RJC) ANTI LOCK BRAKE(JE5) (A)	8-97037-992-3	04	1	9112-	●	●
11	CLIP; OIL PIPE 4JG2 ENG(RJC),4JG1 ENG(RLT) EXC. ANTI LOCK BRAKE(JE5) (K) H=9.5	8-94375-291-0	04	1	9112-	●	●
11	CLIP; OIL PIPE 4ZE1 ENG(RLJ),6VD1 SOHC ENG(RLU) EXC. ANTI LOCK BRAKE(JE5) (K) H=9.5	8-94375-291-0	05	1	9112-	●	●
11	CLIP; OIL PIPE 6VD1 SOHC ENG(RLU) ANTI LOCK BRAKE(JE5) (D) ID=4.76X3	8-94122-333-0	03	1	9112-9402	●	●
11	CLIP; OIL PIPE 6VD1 SOHC ENG(RLU) ANTI LOCK BRAKE(JE5) (F) ID=4.8 & 10	8-94152-110-0	01	1	9112-9201	●	●
11	CLIP; OIL PIPE 6VD1 SOHC ENG(RLU) ANTI LOCK BRAKE(JE5) (A)	8-97037-992-3	05	1	9112-	●	●
11	CLIP; OIL PIPE 6VD1 SOHC ENG(RLU) ANTI LOCK BRAKE(JE5) (D) ID=4.76X3	8-94122-333-0	02	1	9309-	●	●
11	CLIP; OIL PIPE 6VD1 SOHC ENG(RLU) EUROPE/CANARY EQUIPMENT(EK4) ANTI LOCK BRAKE(JE5) (H) ID=6.4 & 4.8X2	8-94146-043-0	01	1	9410-	●	●
11	CLIP; OIL PIPE 6VD1 SOHC ENG(RLU) EUROPE/CANARY EQUIPMENT(EK4) ANTI LOCK BRAKE(JE5) (L) ID=4.8X3	8-94487-369-0	01	1	9411-	●	●
12	BRACKET; OIL PIPE	8-94382-253-0	01	1	9112-	●	●
13	BOLT; BRKT,OIL PIPE M6X12 W/LK WASHER	9-01900-612-0	01	1	9112-9204	●	●
13	BOLT; BRKT,OIL PIPE M6X12 W/LK WASHER	0-50040-612-0	01	1	9205-	●	●
18	CLIP; BRK PIPE ANTI LOCK BRAKE(JE5)	8-97062-177-1	03	1	9112-	●	●
22	CLIP; PIPE TO FRAME 4JG2 ENG(RJC),4JG1 ENG(RLT),6VD1 SOHC ENG(RLU)	8-94442-883-1	01	1	9112-	●	●
22	CLIP; PIPE TO FRAME 4ZE1 ENG(RLJ)	8-94442-883-1	02	1	9112-	●	●

3 3 3 3 3 3 11 11 11

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date	A	B
3	CLIP; BRK PIPE 4JG1 ENG(RLT) (A)	8-94326-752-0	07	1	9112-9504	●
3	CLIP; BRK PIPE (A)	8-94326-752-0	01	1	9505-	●	●
3	CLIP; BRK PIPE EUROPE/CANARY EQUIPMENT(EK4) EXC. ANTI LOCK BRAKE(JE5) (D) ID=4.76X3	8-94122-333-0	02	1	9112-9412	●	●
3	CLIP; BRK PIPE EUROPE/CANARY EQUIPMENT(EK4) (D) ID=4.76X3	8-94122-333-0	02	1	9501-9504	●	●
3	CLIP; BRK PIPE EUROPE/CANARY EQUIPMENT(EK4) (F) ID=4.8X3	8-94487-369-0	02	1	9505-9607	●	●
3	CLIP; BRK PIPE EUROPE/CANARY EQUIPMENT(EK4) (F) ID=4.8X3	8-94487-369-0	01	1	9608-	●	●
3	CLIP; BRK PIPE EUROPE/CANARY EQUIPMENT(EK4) EXC. ANTI LOCK BRAKE(JE5) (C) ID=4.6X2	8-94241-454-0	01	1	9112-9607	●	●
3	CLIP; BRK PIPE 4JG2 ENG(RJC) EUROPE/CANARY EQUIPMENT(EK4) (D) ID=4.76X3	8-94122-333-0	01	1	9112-9504	●	●
3	CLIP; BRK PIPE 4JG2 ENG(RJC) EUROPE/CANARY EQUIPMENT(EK4) (E) ID=6.35 & 6.35	8-94474-113-0	01	1	9112-9503	●	●
3	CLIP; BRK PIPE 4JG2 ENG(RJC) RR COIL & LINK SUSPENSION<6SV> (B)	8-97043-724-0	05	1	9112-9504	●	●
3	CLIP; BRK PIPE 4ZE1 ENG(RLJ),6VD1 SOHC ENG(RLU) (A)	8-94326-752-0	01	1	9112-9308	●	●
3	CLIP; BRK PIPE 4JG2 ENG(RJC) RR COIL & LINK SUSPENSION<6SV> (A)	8-94326-752-0	01	1	9112-9308	●
3	CLIP; BRK PIPE 4JG1 ENG(RLT) (A)	8-94326-752-0	09	1	9112-9504		●
3	CLIP; BRK PIPE 4JG2 ENG(RJC) RR COIL & LINK SUSPENSION<6SV> (A)	8-94326-752-0	02	1	9112-9308		●
3	CLIP; BRK PIPE 4ZE1 ENG(RLJ),6VD1 SOHC ENG(RLU) (A)	8-94326-752-0	01	1	9309-9504	●	●
3	CLIP; BRK PIPE 4JG2 ENG(RJC) RR COIL & LINK SUSPENSION<6SV> (A)	8-94326-752-0	01	1	9309-9504	●
3	CLIP; BRK PIPE 4JG2 ENG(RJC) (A)	8-94326-752-0	05	1	9505-	●	●
3	CLIP; BRK PIPE 4JG2 ENG(RJC) RR COIL & LINK SUSPENSION<6SV> (A)	8-94326-752-0	02	1	9309-9504		●
3	CLIP; BRK PIPE 4JG2 ENG(RJC) (A)	8-94326-752-0	02	1	9505-		●
11	CLIP; OIL PIPE (C) ID=4.6X2	8-94241-454-0	01	1	9112-9607	●	●
11	CLIP; OIL PIPE EUROPE/CANARY EQUIPMENT(EK4) EXC. ANTI LOCK BRAKE(JE5) (C) ID=4.6X2	8-94241-454-0	01	1	9608-	●	●
11	CLIP; OIL PIPE (C) ID=4.6X2	8-94241-454-0	01	1	9608-	●	●
11	CLIP; OIL PIPE (B)	8-97035-570-3	01	1	9112-	●	●
11	CLIP; OIL PIPE (I)	8-97069-554-1	01	1	9112-	●	●
11	CLIP; OIL PIPE (G)	8-94435-553-0	01	1	9204-9409	●	●
11	CLIP; OIL PIPE 4JG2 ENG(RJC),4ZE1 ENG(RLJ) (G)	8-94435-553-0	01	1	9410-9504	●	●
11	CLIP; OIL PIPE 6VD1 SOHC ENG(RLU) EXC. ANTI LOCK BRAKE(JE5) (G)	8-94435-553-0	01	1	9410-9504	●	●
11	CLIP; OIL PIPE 6VD1 SOHC ENG(RLU) ANTI LOCK BRAKE(JE5) EXC. EUROPE/CANARY EQUIPMENT(EK4) (G)	8-94435-553-0	01	1	9410-9504	●	●
11	CLIP; OIL PIPE 4JG2 ENG(RJC),4ZE1 ENG(RLJ) (G)	8-94435-553-0	01	1	9505-9607	●	●
11	CLIP; OIL PIPE 6VD1 SOHC ENG(RLU) EXC. ANTI LOCK BRAKE(JE5) (G)	8-94435-553-0	01	1	9505-9607	●	●
11	CLIP; OIL PIPE 4JG2 ENG(RJC) EUROPE/CANARY EQUIPMENT(EK4) (G)	8-94435-553-0	01	1	9608-9706	●	●
11	CLIP; OIL PIPE 6VD1 SOHC ENG(RLU) EUROPE/CANARY EQUIPMENT(EK4) EXC. ANTI LOCK BRAKE(JE5) (G)	8-94435-553-0	01	1	9608-9706	●	●
11	CLIP; OIL PIPE EXC. EUROPE/CANARY EQUIPMENT(EK4) (G)	8-94435-553-0	01	1	9608-9706	●	●
11	CLIP; OIL PIPE 4JG2 ENG(RJC) (G)	8-94435-553-0	01	1	9707-	●	●
11	CLIP; OIL PIPE 4ZE1 ENG(RLJ),6VD1 SOHC ENG(RLU) EXC. EUROPE/CANARY EQUIPMENT(EK4),ANTI LOCK BRAKE(JE5) (G)	8-94435-553-0	01	1	9707-	●	●
11	CLIP; OIL PIPE 6VD1 SOHC ENG(RLU) EUROPE/CANARY EQUIPMENT(EK4) EXC. ANTI LOCK BRAKE(JE5) (G)	8-94435-553-0	01	1	9707-	●	●
11	CLIP; OIL PIPE EXC. ANTI LOCK BRAKE(JE5) (D)	8-94107-743-0	01	1	9112-9409	●	●
11	CLIP; OIL PIPE 6VD1 SOHC ENG(RLU) EUROPE/CANARY EQUIPMENT(EK4) (D)	8-94107-743-0	01	1	9410-9504	●	●
11	CLIP; OIL PIPE 6VD1 SOHC ENG(RLU) (D)	8-94107-743-0	01	1	9505-	●	●
11	CLIP; OIL PIPE EUROPE/CANARY EQUIPMENT(EK4) ANTI LOCK BRAKE(JE5) (E)	8-94338-104-0	01	1	9112-9407	●	●
11	CLIP; OIL PIPE EXC. EUROPE/CANARY EQUIPMENT(EK4) (E)	8-94338-104-0	01	1	9112-9407	●	●
11	CLIP; OIL PIPE 4JG2 ENG(RJC),4JG1 ENG(RLT) EXC. EUROPE/CANARY EQUIPMENT(EK4),ANTI LOCK BRAKE(JE5) (E)	8-94338-104-0	01	1	9408-9409	●	●
11	CLIP; OIL PIPE 4JG2 ENG(RJC) ANTI LOCK BRAKE(JE5) (E)	8-94338-104-0	01	1	9408-9409	●	●
11	CLIP; OIL PIPE 4JG2 ENG(RJC),4JG1 ENG(RLT) EXC. EUROPE/CANARY EQUIPMENT(EK4),ANTI LOCK BRAKE(JE5) (E)	8-94338-104-0	01	1	9410-9504	●	●
11	CLIP; OIL PIPE 4JG2 ENG(RJC) ANTI LOCK BRAKE(JE5) (E)	8-94338-104-0	01	1	9410-9504	●	●
11	CLIP; OIL PIPE 6VD1 SOHC ENG(RLU) EUROPE/CANARY EQUIPMENT(EK4) ANTI LOCK BRAKE(JE5) (E)	8-94338-104-0	01	1	9410-9504	●	●
11	CLIP; OIL PIPE 4JG2 ENG(RJC) EXC. EUROPE/CANARY EQUIPMENT(EK4) (E)	8-94338-104-0	01	1	9505-	●	●
11	CLIP; OIL PIPE EUROPE/CANARY EQUIPMENT(EK4) ANTI LOCK BRAKE(JE5) (J) ID=6.35 & 6.35	8-94474-113-0	02	1	9410-9504	●	●
11	CLIP; OIL PIPE EUROPE/CANARY EQUIPMENT(EK4) ANTI LOCK BRAKE(JE5) (J) ID=6.35 & 6.35	8-94474-113-0	03	1	9505-	●	●
11	CLIP; OIL PIPE 4JG2 ENG(RJC) ANTI LOCK BRAKE(JE5) (A)	8-97037-992-3	04	1	9112-	●	●
11	CLIP; OIL PIPE 4JG2 ENG(RJC),4JG1 ENG(RLT) EXC. ANTI LOCK BRAKE(JE5) (K) H=9.5	8-94375-291-0	04	1	9112-	●	●
11	CLIP; OIL PIPE 4ZE1 ENG(RLJ),6VD1 SOHC ENG(RLU) EXC. ANTI LOCK BRAKE(JE5) (K) H=9.5	8-94375-291-0	05	1	9112-	●	●
11	CLIP; OIL PIPE 6VD1 SOHC ENG(RLU) ANTI LOCK BRAKE(JE5) (D) ID=4.76X3	8-94122-333-0	03	1	9112-9402	●	●
11	CLIP; OIL PIPE 6VD1 SOHC ENG(RLU) ANTI LOCK BRAKE(JE5) (F) ID=4.8 & 10	8-94152-110-0	01	1	9112-9201	●	●
11	CLIP; OIL PIPE 6VD1 SOHC ENG(RLU) ANTI LOCK BRAKE(JE5) (A)	8-97037-992-3	05	1	9112-	●	●
11	CLIP; OIL PIPE 6VD1 SOHC ENG(RLU) ANTI LOCK BRAKE(JE5) (D) ID=4.76X3	8-94122-333-0	02	1	9309-	●	●
11	CLIP; OIL PIPE 6VD1 SOHC ENG(RLU) EUROPE/CANARY EQUIPMENT(EK4) ANTI LOCK BRAKE(JE5) (H) ID=6.4 & 4.8X2	8-94146-043-0	01	1	9410-	●	●
11	CLIP; OIL PIPE 6VD1 SOHC ENG(RLU) EUROPE/CANARY EQUIPMENT(EK4) ANTI LOCK BRAKE(JE5) (L) ID=4.8X3	8-94487-369-0	01	1	9411-	●	●
