6-07 — FRONT WINDOW GLASS AND WEATHERSTRIP (#32941) — 15 parça

3 1 2 1 15 14 13 9 13 14 8 2 3 15

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date
1	GLASS; WINDSHIELD	8-97869-124-0	01	1	0609-0805
1	GLASS; WINDSHIELD	8-97997-944-1	01	1	0806-
2	WEATHERSTRIP; WINDSHIELD GLASS WINDSHIELD WEATHERSTRIP TYPE<7EL>	8-97856-351-4	01	1	0609-
3	MOLDING; WINDSHIELD EXC. WINDSHIELD WEATHERSTRIP TYPE<7EL>	8-97581-678-3	01	1	0609-
8	STOPPER; WINDSHIELD GLASS EXC. WINDSHIELD WEATHERSTRIP TYPE<7EL>	8-97853-733-1	02	1	0609-1304
8	STOPPER; WINDSHIELD GLASS KD PREPARATORY PACK VAR.4<7TV> EXC. WINDSHIELD WEATHERSTRIP TYPE<7EL>	8-97853-733-1	02	1	1305-
9	SCREW; STOPPER EXC. WINDSHIELD WEATHERSTRIP TYPE<7EL> M5X14	8-94279-325-0	02	1	0609-1304
9	SCREW; STOPPER KD PREPARATORY PACK VAR.4<7TV> EXC. WINDSHIELD WEATHERSTRIP TYPE<7EL> M5X14	8-94279-325-0	02	1	1305-
13	MOLDING; BRKT,OUTSIDE MIRROR EXC. WINDSHIELD WEATHERSTRIP TYPE<7EL>	8-97581-618-3	01	1	0609-
13	MOLDING; BRKT,OUTSIDE MIRROR EXC. WINDSHIELD WEATHERSTRIP TYPE<7EL>	8-97581-617-4	01	1	0609-
14	GROMMET; SCREW,STOPPER EXC. WINDSHIELD WEATHERSTRIP TYPE<7EL>,KD PREPARATORY PACK VAR.4<7TV> (B) D=7.9X7.9 L=11.4 M5	8-94367-528-0	02	1	1305-
14	GROMMET; SCREW,STOPPER WINDSHIELD WEATHERSTRIP TYPE<7EL> (B) 14.5X14.5 BLACK	8-94279-714-0	04	1	0609-
14	GROMMET; SCREW,STOPPER EXC. WINDSHIELD WEATHERSTRIP TYPE<7EL> (A) D=7.8X7.8 L=18 NATURAL	8-94279-043-0	02	1	0609-1304
14	GROMMET; SCREW,STOPPER KD PREPARATORY PACK VAR.4<7TV> EXC. WINDSHIELD WEATHERSTRIP TYPE<7EL> (A) D=7.8X7.8 L=18 NATURAL	8-94279-043-0	02	1	1305-
15	FINISHER; WINDSHIELD EXC. WINDSHIELD WEATHERSTRIP TYPE<7EL> GRAY	8-97582-226-7	01	1	0609-
