4-55 — FRONT LEAF SPRING (#32552) — 111 parça

17 17 16 1 32 2 17 19 3 19 4 19 5 6 17 29 17 16 32 1 15 32 2 19 3 17 19 4 19 5 6 20 32 15

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date
1	07.415 SPRING; LEAF,NO 1,FRT ASM PART: A = 8-97096-544-2, 97096544, F = 8-97202-804-0, 97202804	8-97133-074-0	01	1	-
1	07.415 SPRING; LEAF,NO 1,FRT ASM PART: B = 8-97122-381-2, 97122381	8-97133-117-0	01	1	-
1	07.415 SPRING; LEAF,NO 1,FRT ASM PART: C = 8-97147-110-1, 97147110	8-97174-322-0	01	1	-
1	07.415 SPRING; LEAF,NO 1,FRT ASM PART: D = 8-97174-304-0, 97174304	8-97178-577-0	01	1	-
1	07.415 SPRING; LEAF,NO 1,FRT ASM PART: E = 8-97174-305-0, 97174305	8-97178-583-0	01	1	-
1	07.415 SPRING; LEAF,NO 1,FRT ASM PART: G = 8-98043-019-0, 98043019	8-98030-713-0	01	1	-
1	07.415 SPRING; LEAF,NO 1,FRT ASM PART: H = 8-98043-020-0, 98043020	8-98030-719-0	01	1	-
2	07.415 SPRING; LEAF,NO 2,FRT ASM PART: A = 8-97096-544-2, 97096544, F = 8-97202-804-0, 97202804	8-97133-075-0	01	1	-
2	07.415 SPRING; LEAF,NO 2,FRT ASM PART: B = 8-97122-381-2, 97122381	8-97133-118-0	01	1	-
2	07.415 SPRING; LEAF,NO 2,FRT ASM PART: C = 8-97147-110-1, 97147110	8-97174-323-0	01	1	-
2	07.415 SPRING; LEAF,NO 2,FRT ASM PART: D = 8-97174-304-0, 97174304	8-97178-578-0	01	1	-
2	07.415 SPRING; LEAF,NO 2,FRT ASM PART: E = 8-97174-305-0, 97174305	8-97178-584-0	01	1	-
2	07.415 SPRING; LEAF,NO 2,FRT ASM PART: G = 8-98043-019-0, 98043019	8-98030-714-0	01	1	-
2	07.415 SPRING; LEAF,NO 2,FRT ASM PART: H = 8-98043-020-0, 98043020	8-98030-720-0	01	1	-
3	07.415 SPRING; LEAF,NO 3,FRT ASM PART: A = 8-97096-544-2, 97096544, F = 8-97202-804-0, 97202804	8-97133-076-0	01	1	-
3	07.415 SPRING; LEAF,NO 3,FRT ASM PART: B = 8-97122-381-2, 97122381	8-97133-119-0	01	1	-
3	07.415 SPRING; LEAF,NO 3,FRT ASM PART: C = 8-97147-110-1, 97147110	8-97174-324-0	01	1	-
3	07.415 SPRING; LEAF,NO 3,FRT ASM PART: D = 8-97174-304-0, 97174304	8-97178-579-0	01	1	-
3	07.415 SPRING; LEAF,NO 3,FRT ASM PART: E = 8-97174-305-0, 97174305	8-97178-585-0	01	1	-
3	07.415 SPRING; LEAF,NO 3,FRT ASM PART: G = 8-98043-019-0, 98043019	8-98030-715-0	01	1	-
3	07.415 SPRING; LEAF,NO 3,FRT ASM PART: H = 8-98043-020-0, 98043020	8-98030-721-0	01	1	-
4	07.415 SPRING; LEAF,NO 4,FRT ASM PART: A = 8-97096-544-2, 97096544, F = 8-97202-804-0, 97202804	8-97133-077-0	01	1	-
4	07.415 SPRING; LEAF,NO 4,FRT ASM PART: B = 8-97122-381-2, 97122381	8-97133-120-0	01	1	-
4	07.415 SPRING; LEAF,NO 4,FRT ASM PART: C = 8-97147-110-1, 97147110	8-97174-325-0	01	1	-
4	07.415 SPRING; LEAF,NO 4,FRT ASM PART: D = 8-97174-304-0, 97174304	8-97178-580-0	01	1	-
4	07.415 SPRING; LEAF,NO 4,FRT ASM PART: E = 8-97174-305-0, 97174305	8-97178-586-0	01	1	-
4	07.415 SPRING; LEAF,NO 4,FRT ASM PART: G = 8-98043-019-0, 98043019	8-98030-716-0	01	1	-
4	07.415 SPRING; LEAF,NO 4,FRT ASM PART: H = 8-98043-020-0, 98043020	8-98030-722-0	01	1	-
5	07.415 SPRING; LEAF,NO 5,FRT ASM PART: A = 8-97096-544-2, 97096544, F = 8-97202-804-0, 97202804	8-97133-078-0	01	1	-
5	07.415 SPRING; LEAF,NO 5,FRT ASM PART: B = 8-97122-381-2, 97122381	8-97133-127-0	01	1	-
5	07.415 SPRING; LEAF,NO 5,FRT ASM PART: C = 8-97147-110-1, 97147110	8-97174-326-0	01	1	-
5	07.415 SPRING; LEAF,NO 5,FRT ASM PART: D = 8-97174-304-0, 97174304	8-97178-581-0	01	1	-
5	07.415 SPRING; LEAF,NO 5,FRT ASM PART: E = 8-97174-305-0, 97174305	8-97178-587-0	01	1	-
5	07.415 SPRING; LEAF,NO 5,FRT ASM PART: G = 8-98043-019-0, 98043019	8-98030-717-0	01	1	-
5	07.415 SPRING; LEAF,NO 5,FRT ASM PART: H = 8-98043-020-0, 98043020	8-98030-723-0	01	1	-
6	07.415 SPRING; LEAF,NO 6,FRT ASM PART: A = 8-97096-544-2, 97096544, F = 8-97202-804-0, 97202804	8-97133-079-0	01	1	-
6	07.415 SPRING; LEAF,NO 6,FRT ASM PART: B = 8-97122-381-2, 97122381	8-97133-128-0	01	1	-
6	07.415 SPRING; LEAF,NO 6,FRT ASM PART: C = 8-97147-110-1, 97147110	8-97174-327-0	01	1	-
6	07.415 SPRING; LEAF,NO 6,FRT ASM PART: D = 8-97174-304-0, 97174304	8-97178-582-0	01	1	-
6	07.415 SPRING; LEAF,NO 6,FRT ASM PART: E = 8-97174-305-0, 97174305	8-97178-588-0	01	1	-
6	07.415 SPRING; LEAF,NO 6,FRT ASM PART: G = 8-98043-019-0, 98043019	8-98030-718-0	01	1	-
6	07.415 SPRING; LEAF,NO 6,FRT ASM PART: H = 8-98043-020-0, 98043020	8-98030-724-0	01	1	-
15	07.428 BOLT; CENTER,LEAF SPR,FRT L=95 ASM PART: A = 8-97096-544-2, 97096544, B = 8-97122-381-2, 97122381, C = 8-97147-110-1, 97147110, D = 8-97174-304-0, 97174304, E = 8-97174-305-0, 97174305, F = 8-97202-804-0, 97202804	8-97108-550-0	01	1	-
15	07.428 BOLT; CENTER,LEAF SPR,FRT ASM PART: G = 8-98043-019-0, 98043019, H = 8-98043-020-0, 98043020	8-98045-600-0	01	1	-
16	07.506 NUT; CENTER BOLT,LEAF SPR,FRT M10 ASM PART: A = 8-97096-544-2, 97096544, B = 8-97122-381-2, 97122381, C = 8-97147-110-1, 97147110, D = 8-97174-304-0, 97174304, E = 8-97174-305-0, 97174305, F = 8-97202-804-0, 97202804, G = 8-98043-019-0, 98043019, H = 8-98043-020-0, 98043020	1-09400-055-0	01	1	-
17	07.413 BUSHING; LEAF SPR,FRT 07.524, (A) ASM PART: A = 8-97096-544-2, 97096544, B = 8-97122-381-2, 97122381, C = 8-97147-110-1, 97147110, D = 8-97174-304-0, 97174304, E = 8-97174-305-0, 97174305, F = 8-97202-804-0, 97202804, G = 8-98043-019-0, 98043019, H = 8-98043-020-0, 98043020	8-94118-588-1	02	1	-
17	07.413 BUSHING; LEAF SPR,FRT 07.105, (B) ASM PART: A = 8-97096-544-2, 97096544, B = 8-97122-381-2, 97122381, C = 8-97147-110-1, 97147110, D = 8-97174-304-0, 97174304, E = 8-97174-305-0, 97174305, F = 8-97202-804-0, 97202804	8-94130-354-0	01	1	-
17	07.413 BUSHING; LEAF SPR,FRT (C), OD=42 L=81 ASM PART: G = 8-98043-019-0, 98043019, H = 8-98043-020-0, 98043020	8-97081-586-0	01	1	-
19	07.425 SPACER; LEAF SPRING,FRT T=1 ASM PART: G = 8-98043-019-0, 98043019, H = 8-98043-020-0, 98043020	8-97084-845-0	01	1	-
19	07.425 SPACER; LEAF SPRING,FRT T=1 ASM PART: A = 8-97096-544-2, 97096544, B = 8-97122-381-2, 97122381, C = 8-97147-110-1, 97147110, F = 8-97202-804-0, 97202804	8-97084-845-0	03	1	-
20	07.425 SEAT; LEAF SPR,FRT (A), T=8 ASM PART: G = 8-98043-019-0, 98043019, H = 8-98043-020-0, 98043020	8-97084-891-0	03	1	-
20	07.425 SEAT; LEAF SPR,FRT (A), T=8 ASM PART: A = 8-97096-544-2, 97096544, B = 8-97122-381-2, 97122381	8-97084-891-0	01	1	-
20	07.425 SEAT; LEAF SPR,FRT (A), T=8 ASM PART: D = 8-97174-304-0, 97174304, E = 8-97174-305-0, 97174305	8-97084-891-0	02	1	-
20	07.425 SEAT; LEAF SPR,FRT (B), T=6 ASM PART: G = 8-98043-019-0, 98043019, H = 8-98043-020-0, 98043020	8-98030-726-0	01	1	-
29	07.425 SUPPORTER; LEAF SPR,FRT ASM PART: C = 8-97147-110-1, 97147110, F = 8-97202-804-0, 97202804	8-94342-292-1	01	1	-
32	07.425 PLATE; CASTER ASM PART: A = 8-97096-544-2, 97096544, B = 8-97122-381-2, 97122381, C = 8-97147-110-1, 97147110, D = 8-97174-304-0, 97174304, E = 8-97174-305-0, 97174305, F = 8-97202-804-0, 97202804	8-97164-386-2	02	1	-

17 17 16 1 32 2 17 3 4 5 6 20 20 32 16 17 15 17 20 20 20 19 1 2 17 3 4 5 6 20 15

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date
1	07.415 SPRING; LEAF,NO 1,FRT ASM PART: A = 8-97096-544-2, 97096544, F = 8-97202-804-0, 97202804	8-97133-074-0	01	1	-
1	07.415 SPRING; LEAF,NO 1,FRT ASM PART: B = 8-97122-381-2, 97122381	8-97133-117-0	01	1	-
1	07.415 SPRING; LEAF,NO 1,FRT ASM PART: C = 8-97147-110-1, 97147110	8-97174-322-0	01	1	-
1	07.415 SPRING; LEAF,NO 1,FRT ASM PART: D = 8-97174-304-0, 97174304	8-97178-577-0	01	1	-
1	07.415 SPRING; LEAF,NO 1,FRT ASM PART: E = 8-97174-305-0, 97174305	8-97178-583-0	01	1	-
1	07.415 SPRING; LEAF,NO 1,FRT ASM PART: G = 8-98043-019-0, 98043019	8-98030-713-0	01	1	-
1	07.415 SPRING; LEAF,NO 1,FRT ASM PART: H = 8-98043-020-0, 98043020	8-98030-719-0	01	1	-
2	07.415 SPRING; LEAF,NO 2,FRT ASM PART: A = 8-97096-544-2, 97096544, F = 8-97202-804-0, 97202804	8-97133-075-0	01	1	-
2	07.415 SPRING; LEAF,NO 2,FRT ASM PART: B = 8-97122-381-2, 97122381	8-97133-118-0	01	1	-
2	07.415 SPRING; LEAF,NO 2,FRT ASM PART: C = 8-97147-110-1, 97147110	8-97174-323-0	01	1	-
2	07.415 SPRING; LEAF,NO 2,FRT ASM PART: D = 8-97174-304-0, 97174304	8-97178-578-0	01	1	-
2	07.415 SPRING; LEAF,NO 2,FRT ASM PART: E = 8-97174-305-0, 97174305	8-97178-584-0	01	1	-
2	07.415 SPRING; LEAF,NO 2,FRT ASM PART: G = 8-98043-019-0, 98043019	8-98030-714-0	01	1	-
2	07.415 SPRING; LEAF,NO 2,FRT ASM PART: H = 8-98043-020-0, 98043020	8-98030-720-0	01	1	-
3	07.415 SPRING; LEAF,NO 3,FRT ASM PART: A = 8-97096-544-2, 97096544, F = 8-97202-804-0, 97202804	8-97133-076-0	01	1	-
3	07.415 SPRING; LEAF,NO 3,FRT ASM PART: B = 8-97122-381-2, 97122381	8-97133-119-0	01	1	-
3	07.415 SPRING; LEAF,NO 3,FRT ASM PART: C = 8-97147-110-1, 97147110	8-97174-324-0	01	1	-
3	07.415 SPRING; LEAF,NO 3,FRT ASM PART: D = 8-97174-304-0, 97174304	8-97178-579-0	01	1	-
3	07.415 SPRING; LEAF,NO 3,FRT ASM PART: E = 8-97174-305-0, 97174305	8-97178-585-0	01	1	-
3	07.415 SPRING; LEAF,NO 3,FRT ASM PART: G = 8-98043-019-0, 98043019	8-98030-715-0	01	1	-
3	07.415 SPRING; LEAF,NO 3,FRT ASM PART: H = 8-98043-020-0, 98043020	8-98030-721-0	01	1	-
4	07.415 SPRING; LEAF,NO 4,FRT ASM PART: A = 8-97096-544-2, 97096544, F = 8-97202-804-0, 97202804	8-97133-077-0	01	1	-
4	07.415 SPRING; LEAF,NO 4,FRT ASM PART: B = 8-97122-381-2, 97122381	8-97133-120-0	01	1	-
4	07.415 SPRING; LEAF,NO 4,FRT ASM PART: C = 8-97147-110-1, 97147110	8-97174-325-0	01	1	-
4	07.415 SPRING; LEAF,NO 4,FRT ASM PART: D = 8-97174-304-0, 97174304	8-97178-580-0	01	1	-
4	07.415 SPRING; LEAF,NO 4,FRT ASM PART: E = 8-97174-305-0, 97174305	8-97178-586-0	01	1	-
4	07.415 SPRING; LEAF,NO 4,FRT ASM PART: G = 8-98043-019-0, 98043019	8-98030-716-0	01	1	-
4	07.415 SPRING; LEAF,NO 4,FRT ASM PART: H = 8-98043-020-0, 98043020	8-98030-722-0	01	1	-
5	07.415 SPRING; LEAF,NO 5,FRT ASM PART: A = 8-97096-544-2, 97096544, F = 8-97202-804-0, 97202804	8-97133-078-0	01	1	-
5	07.415 SPRING; LEAF,NO 5,FRT ASM PART: B = 8-97122-381-2, 97122381	8-97133-127-0	01	1	-
5	07.415 SPRING; LEAF,NO 5,FRT ASM PART: C = 8-97147-110-1, 97147110	8-97174-326-0	01	1	-
5	07.415 SPRING; LEAF,NO 5,FRT ASM PART: D = 8-97174-304-0, 97174304	8-97178-581-0	01	1	-
5	07.415 SPRING; LEAF,NO 5,FRT ASM PART: E = 8-97174-305-0, 97174305	8-97178-587-0	01	1	-
5	07.415 SPRING; LEAF,NO 5,FRT ASM PART: G = 8-98043-019-0, 98043019	8-98030-717-0	01	1	-
5	07.415 SPRING; LEAF,NO 5,FRT ASM PART: H = 8-98043-020-0, 98043020	8-98030-723-0	01	1	-
6	07.415 SPRING; LEAF,NO 6,FRT ASM PART: A = 8-97096-544-2, 97096544, F = 8-97202-804-0, 97202804	8-97133-079-0	01	1	-
6	07.415 SPRING; LEAF,NO 6,FRT ASM PART: B = 8-97122-381-2, 97122381	8-97133-128-0	01	1	-
6	07.415 SPRING; LEAF,NO 6,FRT ASM PART: C = 8-97147-110-1, 97147110	8-97174-327-0	01	1	-
6	07.415 SPRING; LEAF,NO 6,FRT ASM PART: D = 8-97174-304-0, 97174304	8-97178-582-0	01	1	-
6	07.415 SPRING; LEAF,NO 6,FRT ASM PART: E = 8-97174-305-0, 97174305	8-97178-588-0	01	1	-
6	07.415 SPRING; LEAF,NO 6,FRT ASM PART: G = 8-98043-019-0, 98043019	8-98030-718-0	01	1	-
6	07.415 SPRING; LEAF,NO 6,FRT ASM PART: H = 8-98043-020-0, 98043020	8-98030-724-0	01	1	-
15	07.428 BOLT; CENTER,LEAF SPR,FRT L=95 ASM PART: A = 8-97096-544-2, 97096544, B = 8-97122-381-2, 97122381, C = 8-97147-110-1, 97147110, D = 8-97174-304-0, 97174304, E = 8-97174-305-0, 97174305, F = 8-97202-804-0, 97202804	8-97108-550-0	01	1	-
15	07.428 BOLT; CENTER,LEAF SPR,FRT ASM PART: G = 8-98043-019-0, 98043019, H = 8-98043-020-0, 98043020	8-98045-600-0	01	1	-
16	07.506 NUT; CENTER BOLT,LEAF SPR,FRT M10 ASM PART: A = 8-97096-544-2, 97096544, B = 8-97122-381-2, 97122381, C = 8-97147-110-1, 97147110, D = 8-97174-304-0, 97174304, E = 8-97174-305-0, 97174305, F = 8-97202-804-0, 97202804, G = 8-98043-019-0, 98043019, H = 8-98043-020-0, 98043020	1-09400-055-0	01	1	-
17	07.413 BUSHING; LEAF SPR,FRT 07.524, (A) ASM PART: A = 8-97096-544-2, 97096544, B = 8-97122-381-2, 97122381, C = 8-97147-110-1, 97147110, D = 8-97174-304-0, 97174304, E = 8-97174-305-0, 97174305, F = 8-97202-804-0, 97202804, G = 8-98043-019-0, 98043019, H = 8-98043-020-0, 98043020	8-94118-588-1	02	1	-
17	07.413 BUSHING; LEAF SPR,FRT 07.105, (B) ASM PART: A = 8-97096-544-2, 97096544, B = 8-97122-381-2, 97122381, C = 8-97147-110-1, 97147110, D = 8-97174-304-0, 97174304, E = 8-97174-305-0, 97174305, F = 8-97202-804-0, 97202804	8-94130-354-0	01	1	-
17	07.413 BUSHING; LEAF SPR,FRT (C), OD=42 L=81 ASM PART: G = 8-98043-019-0, 98043019, H = 8-98043-020-0, 98043020	8-97081-586-0	01	1	-
19	07.425 SPACER; LEAF SPRING,FRT T=1 ASM PART: G = 8-98043-019-0, 98043019, H = 8-98043-020-0, 98043020	8-97084-845-0	01	1	-
19	07.425 SPACER; LEAF SPRING,FRT T=1 ASM PART: A = 8-97096-544-2, 97096544, B = 8-97122-381-2, 97122381, C = 8-97147-110-1, 97147110, F = 8-97202-804-0, 97202804	8-97084-845-0	03	1	-
20	07.425 SEAT; LEAF SPR,FRT (A), T=8 ASM PART: G = 8-98043-019-0, 98043019, H = 8-98043-020-0, 98043020	8-97084-891-0	03	1	-
20	07.425 SEAT; LEAF SPR,FRT (A), T=8 ASM PART: A = 8-97096-544-2, 97096544, B = 8-97122-381-2, 97122381	8-97084-891-0	01	1	-
20	07.425 SEAT; LEAF SPR,FRT (A), T=8 ASM PART: D = 8-97174-304-0, 97174304, E = 8-97174-305-0, 97174305	8-97084-891-0	02	1	-
20	07.425 SEAT; LEAF SPR,FRT (B), T=6 ASM PART: G = 8-98043-019-0, 98043019, H = 8-98043-020-0, 98043020	8-98030-726-0	01	1	-
32	07.425 PLATE; CASTER ASM PART: A = 8-97096-544-2, 97096544, B = 8-97122-381-2, 97122381, C = 8-97147-110-1, 97147110, D = 8-97174-304-0, 97174304, E = 8-97174-305-0, 97174305, F = 8-97202-804-0, 97202804	8-97164-386-2	02	1	-

İpucu: çizimdeki balona veya tablodaki Balon sütununa tıkla; ilgili parçalar vurgulanır. Birden çok çizim varsa üstteki seçim kutusu/oklarla gezin.
