Isuzu WW
▶
TRUCKS
▶
NLR
▶
51264 - NLR CNG-RHD
▶
1 - Fuel Tank, Cooling, Air Intake, Exhaust System
▶
1-41 - FUEL PIPING; CHASSIS
▶
1-41 — FUEL PIPING; CHASSIS
(#32381) — 24 parça
132
132
156
633
24
24
46
436
48
413
436
51
97
429
132
15
29
429
231
102
61
309
216
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
15
03.162 CLIP; FUEL PIPE
ID=12 & 6.35
8-97215-437-0
02
1
0909-
24
03.162 CLIP; FUEL HOSE
02.559 (A) ID=24 L=24
1-09701-001-1
01
1
0909-
24
03.162 CLIP; FUEL HOSE
06.672 (B) ID=20.2X2
8-94480-371-0
01
1
0909-
29
03.163 HOSE; FUEL
8-98148-494-0
01
1
0909-
46
03.163 PIPE; FUEL,TANK SIDE
8-98050-950-1
01
1
0909-
48
03.162 BOLT; BRKT
06.216 M8X25 FLANGE
0-28650-825-0
02
1
0909-
51
03.162 NUT; CLIP,PIPE
00.787 M10
0-91111-510-0
02
1
0909-
61
03.162 GROMMET; PIPE TO FRAME
02.343 ID=17
8-94128-319-2
01
1
0909-
97
03.162 BRACKET; CLIP
8-98067-396-1
02
1
0909-
102
03.162 NUT; CLIP,FUEL PIPE
01.062 M8 FLANGE
0-91180-108-0
01
1
0909-
132
03.162 BOLT; FUEL HOSE
03.314 (C) M6X60 FLANGE
0-28050-660-0
01
1
0909-
132
03.162 BOLT; FUEL HOSE
03.680 (B) M6X30 FLANGE
0-28650-630-0
01
1
0909-1007
132
03.162 BOLT; FUEL HOSE
01.428 (B) M6X25 FLANGE
0-28050-625-0
01
1
1008-
132
03.162 BOLT; FUEL HOSE
06.216 (A) M8X25 FLANGE
0-28650-825-0
01
1
0909-
156
03.162 BRACKET; FUEL HOSE
8-98054-311-2
01
1
0909-
216
03.163 INSULATION; FUEL PIPE
03.162 OD=16 L=20
8-97254-836-0
01
1
0909-
231
03.162 RUBBER; SUPPORT,FUEL PIPE
OD=15 L=50
8-97066-274-0
01
1
0909-
309
03.162 CLIP; PIPE
01.540 ID=13 L=28
0-95235-255-0
01
1
0909-
413
03.163 PIPE; FUEL,CENTER
8-98148-495-0
01
1
0909-
429
03.162 GASKET; JOINT
(A)
8-98005-350-0
01
1
0909-
429
03.162 GASKET; JOINT
(B)
8-98140-336-0
01
1
0909-
436
03.163 PIPE; FUEL,REGULATOR
(B)
8-98050-952-0
01
1
0909-
436
03.163 PIPE; FUEL,REGULATOR
(A)
8-98055-710-0
01
1
0909-
633
03.162 NUT; FUEL HOSE
01.062 M8 FLANGE
0-91180-108-0
02
1
0909-
Seçili parçaları sepete ekle
İpucu: çizimdeki balona veya tablodaki
Balon
sütununa tıkla; ilgili parçalar vurgulanır. Birden çok çizim varsa üstteki seçim kutusu/oklarla gezin.
