1 |
HOSE; ATF
MAL6 M/T<X9G>
EXC. MIXER TRUCK<RA2>
L=500
|
1-09365-150-0 |
01 |
1 |
0604- |
| |
1 |
HOSE; ATF
MJT7 M/T<Y9E>
L=430
|
1-09364-872-0 |
01 |
1 |
0604- |
| |
8 |
UNION
M16 L=42
|
9-09233-010-1 |
01 |
1 |
0604-0607 |
| |
8 |
UNION
M16 STRAIGHT L=42
|
0-92123-010-0 |
01 |
1 |
0608- |
| |
11 |
CLIP; PIPE
(C)
ID=11 & 11 L=21.5 & 21.5
|
1-09700-660-0 |
01 |
1 |
0604- |
| |
11 |
CLIP; PIPE
(B)
ID=11 H=20 L=20
|
5-09700-351-0 |
01 |
1 |
0604-0707 |
| |
11 |
CLIP; PIPE
(B)
ID=11 H=20 L=20
|
8-98033-780-0 |
01 |
1 |
0708- |
| |
11 |
CLIP; PIPE
(A)
ID=11X2 L=20
|
9-09535-036-0 |
01 |
1 |
0604- |
| |
11 |
CLIP; PIPE
(A)
ID=11X2 L=20
|
9-09535-036-0 |
03 |
1 |
0604- |
| |
12 |
NUT; BRKT
M8 FLANGE
|
0-91180-108-0 |
01 |
1 |
0604- |
| |
12 |
NUT; BRKT
M8 FLANGE
|
0-91180-108-0 |
04 |
1 |
0604- |
| |
19 |
BRACKET; FLEX HOSE
|
1-47479-559-0 |
01 |
1 |
0604- |
| |
20 |
BOLT; COOLER TO BRKT
M10X20 FLANGE
|
0-28051-020-0 |
02 |
1 |
0604- |
| |
24 |
CLIP; OIL PIPE
ID=11 H=20 L=20
|
5-09700-351-0 |
02 |
1 |
0604-0707 |
| |
24 |
CLIP; OIL PIPE
ID=11 H=20 L=20
|
8-98033-780-0 |
02 |
1 |
0708- |
| |
26 |
BOLT; PIPE CLIP
M8X20 FLANGE
|
0-28650-820-0 |
02 |
1 |
0604- |
| |
29 |
BOLT; FILTER TO BRKT
(B)
M8X30 FLANGE
|
0-28650-830-0 |
04 |
1 |
0604- |
| |
29 |
BOLT; FILTER TO BRKT
(A)
M10X30 FLANGE
|
0-28651-030-0 |
02 |
1 |
0604- |
| |
31 |
BRACKET; OIL FILTER
|
1-33119-222-0 |
01 |
1 |
0604- |
| |
35 |
PIPE; OIL,OIL COOLER TO FILTER
|
1-49167-851-0 |
01 |
1 |
0604- |
| |
48 |
NUT; BRKT
M8 FLANGE
|
0-91180-108-0 |
03 |
1 |
0604- |
| |
50 |
BOLT; CLIP
M8X16 FLANGE
|
0-28050-816-0 |
01 |
1 |
0604- |
| |
50 |
BOLT; CLIP
M8X20 FLANGE
|
0-28050-820-0 |
01 |
1 |
0604- |
| |
50 |
BOLT; CLIP
M8X25 FLANGE
|
0-28650-825-0 |
04 |
1 |
0604- |
| |
63 |
COOLER; OIL
|
1-21700-290-0 |
01 |
1 |
0604-0609 |
| |
63 |
COOLER; OIL
|
1-21700-394-0 |
01 |
1 |
0610-1405 |
| |
63 |
COOLER; OIL
|
8-98269-766-0 |
01 |
1 |
1406- |
| |
73 |
HOSE; FLEX,TRANS
MAL6 M/T<X9G>
EXC. MIXER TRUCK<RA2>
L=430
|
1-09364-872-0 |
01 |
1 |
0604- |
| |
73 |
HOSE; FLEX,TRANS
MJT7 M/T<Y9E>
L=430
|
1-09364-872-0 |
01 |
1 |
0604- |
| |
76 |
NUT; FLEX HOSE
M16
|
0-91111-516-0 |
01 |
1 |
0604- |
| |
77 |
WASHER; LK
ID=16.2
|
9-09150-516-0 |
01 |
1 |
0604-0604 |
| |
77 |
WASHER; LK
ID=16.2
|
0-91510-516-0 |
01 |
1 |
0604- |
| |
91 |
PIPE; OIL,FLEX HOSE TO UNION
L=876
|
1-49166-710-0 |
01 |
1 |
0604- |
| |
92 |
NUT; CLIP
M8 FLANGE
|
0-91180-108-0 |
01 |
1 |
0604- |
| |
95 |
BRACKET; CLIP
(A)
L=50
|
1-47475-299-2 |
01 |
1 |
0604- |
| |
95 |
BRACKET; CLIP
(B)
|
1-47479-482-0 |
01 |
1 |
0604- |
| |
95 |
BRACKET; CLIP
(B)
|
1-47479-482-0 |
04 |
1 |
0604- |
| |
106 |
PIPE ASM; OIL,COOLER TO UNION
L=2341
SERVICED BY L=2500
|
1-47428-883-0 |
01 |
1 |
0604- |
| |
109 |
UNION
M16 L=42
|
9-09233-010-1 |
01 |
1 |
0604-0607 |
| |
109 |
UNION
M16 STRAIGHT L=42
|
0-92123-010-0 |
01 |
1 |
0608- |
| |
114 |
PIPE; OIL,UNION TO FLEX HOSE
L=831
SERVICED BY L=900
|
1-47428-788-0 |
01 |
1 |
0604- |
| |
116 |
NUT; BRKT,FLEX HOSE
M16
|
0-91111-516-0 |
01 |
1 |
0604- |
| |
117 |
WASHER; LK,FLEX HOSE
ID=16.2
|
9-09150-516-0 |
01 |
1 |
0604-0604 |
| |
117 |
WASHER; LK,FLEX HOSE
ID=16.2
|
0-91510-516-0 |
01 |
1 |
0604- |
| |
125 |
CONNECTOR; OIL FILTER
M16 & PT1/4 ELBOW
|
1-09650-434-0 |
02 |
1 |
0604-0607 |
| |
125 |
CONNECTOR; OIL FILTER
M16 & PT1/4 ELBOW
|
0-92134-310-0 |
02 |
1 |
0608- |
| |
136 |
CLIP; FLEX HOSE
L=350
|
1-09707-183-0 |
01 |
1 |
0604- |
| |
147 |
PIPE; OIL,UNION TO FILTER
L=1715
SERVICED BY L=1783
|
1-47428-881-0 |
01 |
1 |
0604- |
| |
178 |
BOLT; BRKT,CLIP
M8X35 FLANGE
|
0-28650-835-0 |
01 |
1 |
0604- |
| |
179 |
BOLT; BRKT
M8X35 FLANGE
|
0-28650-835-0 |
02 |
1 |
0604- |
| |
183 |
CARTRIDGE; OIL FILTER
|
8-94459-700-1 |
01 |
1 |
0604- |
| |
210 |
BAND; FLEX HOSE
L=175
|
1-09707-178-0 |
01 |
1 |
0604- |
