2-26 — MANUAL TRANSMISSION GEAR (#30891) — 192 parça

38 322 39 28 172 70 37 298 286 56 57 58 59 56 60 74 75 77 80 46 47 345 342 121 11 45 13 14 15 22 24 23 124 43 18 17 27 27 37 30 34 42 34 36 82 50 1 84 93 96 2 16 97 104 8 3 105 94 94 94 94 108 109 110 118 7 7 9 10 11 12 128 135 130 132 128 129 129 131

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date	A	B
1	SHAFT; TOP GEAR,TRANS Z=25	1-33211-785-0	01	1	0107-	●
1	SHAFT; TOP GEAR,TRANS Z=24	1-33211-788-0	01	1	0107-		●
2	RING; SNAP,TOP GEAR SHAFT ID=55.8 T=2.53 WHITE	1-09588-160-1	AR	1	0107-	●	●
2	RING; SNAP,TOP GEAR SHAFT ID=55.8 T=2.56 YELLOW	1-09588-161-1	AR	1	0107-	●	●
2	RING; SNAP,TOP GEAR SHAFT ID=55.8 T=2.60 BLUE	1-09588-162-1	AR	1	0107-	●	●
2	RING; SNAP,TOP GEAR SHAFT ID=55.8 T=2.64 GREEN	1-09588-163-1	AR	1	0107-	●	●
3	BEARING; TOP GEAR SHAFT NSK	1-09810-050-2	01	1	0107-	●	●
7	WASHER; THRUST,MAINSHAFT	1-33239-080-1	02	1	0107-	●	●
8	CLIP; DOG CLU	1-33219-020-0	01	1	0107-	●	●
9	CLUTCH; DOG,TOP GEAR Z=48	1-33265-227-2	01	1	0107-	●	●
10	RING; SNAP,PILOT BRG	1-09587-072-0	01	1	0107-	●	●
11	RING; BLOCK,5TH & 6TH Z=36	1-33265-281-1	02	1	0107-	●	●
12	SLEEVE; 5TH & 6TH Z=42	1-33262-136-0	01	1	0107-	●	●
13	GEAR; 5TH,MAINSHAFT Z=28	1-33253-711-0	01	1	0107-		●
14	BEARING; NEEDLE,5TH NSK	1-09811-298-0	01	1	0107-	●	●
15	COLLAR; 4TH GEAR	1-33234-048-1	01	1	0107-	●	●
16	BEARING; PILOT,MAINSHAFT KOYO	1-09844-015-0	13	1	0107-	●	●
17	RING; SNAP,4TH GEAR	1-09588-151-1	01	1	0107-	●	●
18	RING; SNAP,CLU HUB T=2.00	1-09588-150-1	01	1	0107-	●	●
22	SPRING; BLOCK,INSERT	1-09583-228-1	03	1	0107-	●	●
23	PLUNGER; DETENT,SYN	1-33269-037-1	03	1	0107-	●	●
24	BLOCK; INDEX,SYN	1-33269-035-1	03	1	0107-	●	●
27	BEARING; 4TH GEAR NSK	1-09811-300-0	02	1	0107-	●	●
28	RING; SNAP,3RD GEAR	1-09588-124-1	01	1	0107-	●	●
30	GEAR; 4TH,MAINSHAFT Z=33	1-33253-501-0	01	1	0107-	●
30	GEAR; 4TH,MAINSHAFT Z=36	1-33253-502-0	01	1	0107-		●
34	SYNCHRONIZER; 4TH & 3RD	1-33265-372-1	02	1	0107-0312	●	●
34	SYNCHRONIZER; 4TH & 3RD	1-33265-619-0	02	1	0401-	●	●
36	GEAR; 3RD,MAINSHAFT Z=43	1-33252-373-1	01	1	0107-	●
36	GEAR; 3RD,MAINSHAFT Z=44	1-33252-374-1	01	1	0107-		●
37	BEARING; NEEDLE,2ND & 3RD KOYO	1-09811-277-0	02	1	0107-	●	●
37	BEARING; NEEDLE,2ND & 3RD NSK	1-09811-279-0	02	1	0107-	●	●
38	SYNCHRONIZER; LOW & 2ND	1-33265-372-1	01	1	0107-0312	●	●
38	SYNCHRONIZER; LOW & 2ND	1-33265-619-0	01	1	0401-	●	●
39	HUB; CLU,LOW & 2ND Z=54	1-33261-217-0	01	1	0107-	●	●
42	SLEEVE Z=54	1-33262-154-0	01	1	0107-	●	●
43	HUB; CLU,3RD & 4TH,MAIN Z=54	1-33261-218-0	01	1	0107-	●	●
45	SPRING; BLOCK INSERT	1-09580-395-0	06	1	0107-	●	●
46	PLUNGER; DETENT,SYN	1-33269-037-1	06	1	0107-	●	●
47	BLOCK; INDEX,SYN	1-33269-035-1	06	1	0107-	●	●
50	GEAR; 2ND,MAINSHAFT Z=48	1-33251-294-1	01	1	0107-	●	●
56	BEARING; NEEDLE,1ST,REV KOYO	1-09811-320-0	02	1	0107-	●	●
57	SLEEVE; REV Z=40	1-33262-110-0	01	1	0107-	●	●
58	HUB; CLU,REV Z=26	1-33261-132-2	01	1	0107-	●	●
59	GEAR; REV MAINSHAFT Z=44	1-33257-060-1	01	1	0107-	●	●
60	COLLAR; REV MAIN	1-33234-095-0	01	1	0107-	●	●
70	GEAR; 1ST,MAINSHAFT Z=52	1-33255-055-1	01	1	0107-	●	●
74	WASHER; THRUST,REV GEAR	1-33239-035-2	01	1	0107-	●	●
75	BEARING; MAINSHAFT NSK	1-09810-047-1	01	1	0107-	●	●
75	BEARING; MAINSHAFT NTN	1-09810-154-0	01	1	0107-	●	●
77	GEAR; 6TH,MAINSHAFT Z=25	1-33253-517-0	01	1	0107-	●
80	GEAR; SPD DRIVE Z=5	1-33371-041-2	01	1	0107-	●	●
82	SHAFT; MAIN,TRANS Z=19-34-37-26-20	1-33231-249-0	01	1	0107-	●
82	SHAFT; MAIN,TRANS Z=19-34-37-26-20	1-33231-271-0	01	1	0107-		●
84	BEARING; COUNTER SHAFT,FRT NSK	1-09810-140-0	01	1	0107-	●	●
93	RING; SNAP,COUNTER FRT BRG ID=55.8	1-09588-125-0	01	1	0107-	●	●
94	KEY; FEATHER,COUNTER SHAFT (A) L=47	1-09735-022-1	02	1	0107-	●	●
94	KEY; FEATHER,COUNTER SHAFT (B) L=55	1-09735-025-0	02	1	0107-	●	●
96	GEAR; COUNTER DRIVE Z=42	1-33331-212-1	01	1	0107-	●
96	GEAR; COUNTER DRIVE Z=43	1-33331-215-1	01	1	0107-		●
97	GEAR; 5TH,COUNTER Z=40	1-33332-113-0	01	1	0107-		●
104	GEAR; 4TH,COUNTER Z=36	1-33332-121-0	01	1	0107-	●
104	GEAR; 4TH,COUNTER Z=33	1-33332-122-0	01	1	0107-		●
105	GEAR; 3RD,COUNTER Z=28	1-33333-161-0	01	1	0107-	●
105	GEAR; 3RD,COUNTER Z=27	1-33333-160-0	01	1	0107-		●
108	SHAFT; COUNTER Z=19-13	1-33311-235-1	01	1	0107-	●
108	SHAFT; COUNTER Z=19-13	1-33311-274-1	01	1	0107-		●
109	BEARING; COUNTER SHAFT,RR KOYO	1-09810-039-1	01	1	0107-	●	●
109	BEARING; COUNTER SHAFT,RR NSK	1-09810-041-1	01	1	0107-	●	●
110	RING; SNAP,COUNTER BRG ID=46.3	1-09588-047-0	01	1	0107-	●	●
118	GEAR; 6TH,COUNTER Z=55	1-33332-103-1	01	1	0107-	●
121	HUB; CLU,6TH	1-33261-156-2	01	1	0107-0212	●	●
121	HUB; CLU,6TH	1-33261-270-0	01	1	0301-	●	●
124	SPRING; PLUNGER,CLU HUB	1-09580-395-0	03	1	0107-	●	●
128	WASHER; THRUST,REV SHAFT (A) ID=38.5 T=42	1-33239-079-1	01	1	0107-	●	●
128	WASHER; THRUST,REV SHAFT (B) ID=38.5 T=2	1-33363-024-1	01	1	0107-	●	●
129	BEARING; NEEDLE,IDLER KOYO	1-09811-102-0	02	1	0107-	●	●
129	BEARING; NEEDLE,IDLER NTN	1-09811-103-0	02	1	0107-	●	●
130	COLLAR; DIST,NEEDLE BRG	1-33363-023-0	01	1	0107-	●	●
131	GASKET; REV SHAFT ALSO INCLUDED IN GASKET SET(M/T).	1-09623-384-0	01	1	0107-	●	●
132	SHAFT; REV	1-33351-017-0	01	1	0107-	●	●
135	GEAR; REV IDLER Z=30-25	1-33361-063-0	01	1	0107-	●	●
172	RING; SNAP,CLU HUB ID=130 T=2.5	1-09588-040-0	01	1	0107-	●	●
286	NUT; LK,MAINSHAFT M36 FLANGE	1-09449-063-0	01	1	0107-0805	●	●
286	NUT; LK,MAINSHAFT M36 FLANGE	8-98014-140-0	01	1	0806-	●	●
298	GASKET; MAINSHAFT ALSO INCLUDED IN GASKET SET(M/T). ID=47 T=5	1-09623-380-0	01	1	0107-	●	●
322	SLEEVE; SYN,LOW & 2ND	1-33262-153-1	01	1	0107-	●	●
342	FLANGE; OUTPUT EXC. BRAKE SYSTEM RETARDER<RE2>	1-37243-307-1	01	1	0107-	●	●
345	BOLT; FLANGE TO YOKE EXC. BRAKE SYSTEM RETARDER<RE2> M14X43 KNURL	1-09046-003-0	04	1	0107-0707	●	●
345	BOLT; FLANGE TO YOKE EXC. BRAKE SYSTEM RETARDER<RE2> M14X43	8-98014-003-0	04	1	0708-	●	●

38 322 39 70 37 56 57 47 345 342 59 56 298 60 286 74 75 78 79 80 58 46 28 172 13 14 17 45 24 23 26 18 121 11 22 43 34 36 15 27 27 30 34 42 81 37 82 84 93 96 97 50 16 2 9 3 94 1 94 7 94 94 7 8 10 11 104 105 129 108 12 126 111 123 122 124 129 109 135 110 117 117 112 113 114 130 131 132 126 128 128

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date	A	B
1	SHAFT; TOP GEAR,TRANS Z=25	1-33211-785-0	01	1	0107-	●
1	SHAFT; TOP GEAR,TRANS Z=24	1-33211-788-0	01	1	0107-		●
2	RING; SNAP,TOP GEAR SHAFT ID=55.8 T=2.53 WHITE	1-09588-160-1	AR	1	0107-	●	●
2	RING; SNAP,TOP GEAR SHAFT ID=55.8 T=2.56 YELLOW	1-09588-161-1	AR	1	0107-	●	●
2	RING; SNAP,TOP GEAR SHAFT ID=55.8 T=2.60 BLUE	1-09588-162-1	AR	1	0107-	●	●
2	RING; SNAP,TOP GEAR SHAFT ID=55.8 T=2.64 GREEN	1-09588-163-1	AR	1	0107-	●	●
3	BEARING; TOP GEAR SHAFT NSK	1-09810-050-2	01	1	0107-	●	●
7	WASHER; THRUST,MAINSHAFT	1-33239-080-1	02	1	0107-	●	●
8	CLIP; DOG CLU	1-33219-020-0	01	1	0107-	●	●
9	CLUTCH; DOG,TOP GEAR Z=48	1-33265-227-2	01	1	0107-	●	●
10	RING; SNAP,PILOT BRG	1-09587-072-0	01	1	0107-	●	●
11	RING; BLOCK,5TH & 6TH Z=36	1-33265-281-1	02	1	0107-	●	●
12	SLEEVE; 5TH & 6TH Z=42	1-33262-136-0	01	1	0107-	●	●
13	GEAR; 5TH,MAINSHAFT Z=28	1-33253-711-0	01	1	0107-		●
14	BEARING; NEEDLE,5TH NSK	1-09811-298-0	01	1	0107-	●	●
15	COLLAR; 4TH GEAR	1-33234-048-1	01	1	0107-	●	●
16	BEARING; PILOT,MAINSHAFT KOYO	1-09844-015-0	13	1	0107-	●	●
17	RING; SNAP,4TH GEAR	1-09588-151-1	01	1	0107-	●	●
18	RING; SNAP,CLU HUB T=2.00	1-09588-150-1	01	1	0107-	●	●
22	SPRING; BLOCK,INSERT	1-09583-228-1	03	1	0107-	●	●
23	PLUNGER; DETENT,SYN	1-33269-037-1	03	1	0107-	●	●
24	BLOCK; INDEX,SYN	1-33269-035-1	03	1	0107-	●	●
26	SPRING; BLOCK,INSERT	1-09580-395-0	03	1	0107-		●
27	BEARING; 4TH GEAR NSK	1-09811-300-0	02	1	0107-	●	●
28	RING; SNAP,3RD GEAR	1-09588-124-1	01	1	0107-	●	●
30	GEAR; 4TH,MAINSHAFT Z=33	1-33253-501-0	01	1	0107-	●
30	GEAR; 4TH,MAINSHAFT Z=36	1-33253-502-0	01	1	0107-		●
34	SYNCHRONIZER; 4TH & 3RD	1-33265-372-1	02	1	0107-0312	●	●
34	SYNCHRONIZER; 4TH & 3RD	1-33265-619-0	02	1	0401-	●	●
36	GEAR; 3RD,MAINSHAFT Z=43	1-33252-373-1	01	1	0107-	●
36	GEAR; 3RD,MAINSHAFT Z=44	1-33252-374-1	01	1	0107-		●
37	BEARING; NEEDLE,2ND & 3RD KOYO	1-09811-277-0	02	1	0107-	●	●
37	BEARING; NEEDLE,2ND & 3RD NSK	1-09811-279-0	02	1	0107-	●	●
38	SYNCHRONIZER; LOW & 2ND	1-33265-372-1	01	1	0107-0312	●	●
38	SYNCHRONIZER; LOW & 2ND	1-33265-619-0	01	1	0401-	●	●
39	HUB; CLU,LOW & 2ND Z=54	1-33261-217-0	01	1	0107-	●	●
42	SLEEVE Z=54	1-33262-154-0	01	1	0107-	●	●
43	HUB; CLU,3RD & 4TH,MAIN Z=54	1-33261-218-0	01	1	0107-	●	●
45	SPRING; BLOCK INSERT	1-09580-395-0	06	1	0107-	●	●
46	PLUNGER; DETENT,SYN	1-33269-037-1	06	1	0107-	●	●
47	BLOCK; INDEX,SYN	1-33269-035-1	06	1	0107-	●	●
50	GEAR; 2ND,MAINSHAFT Z=48	1-33251-294-1	01	1	0107-	●	●
56	BEARING; NEEDLE,1ST,REV KOYO	1-09811-320-0	02	1	0107-	●	●
57	SLEEVE; REV Z=40	1-33262-110-0	01	1	0107-	●	●
58	HUB; CLU,REV Z=26	1-33261-132-2	01	1	0107-	●	●
59	GEAR; REV MAINSHAFT Z=44	1-33257-060-1	01	1	0107-	●	●
60	COLLAR; REV MAIN	1-33234-095-0	01	1	0107-	●	●
70	GEAR; 1ST,MAINSHAFT Z=52	1-33255-055-1	01	1	0107-	●	●
74	WASHER; THRUST,REV GEAR	1-33239-035-2	01	1	0107-	●	●
75	BEARING; MAINSHAFT NSK	1-09810-047-1	01	1	0107-	●	●
75	BEARING; MAINSHAFT NTN	1-09810-154-0	01	1	0107-	●	●
78	COLLAR; DIST,MAINSHAFT BRG	1-33235-085-0	01	1	0107-		●
79	BEARING; BALL,MAINSHAFT KOYO	1-09800-150-0	01	1	0107-		●
79	BEARING; BALL,MAINSHAFT NTN	1-09800-151-0	01	1	0107-		●
80	GEAR; SPD DRIVE Z=5	1-33371-041-2	01	1	0107-	●	●
81	GEAR; 7TH,MAIN Z=19	1-33254-013-0	01	1	0107-		●
82	SHAFT; MAIN,TRANS Z=19-34-37-26-20	1-33231-249-0	01	1	0107-	●
82	SHAFT; MAIN,TRANS Z=19-34-37-26-20	1-33231-271-0	01	1	0107-		●
84	BEARING; COUNTER SHAFT,FRT NSK	1-09810-140-0	01	1	0107-	●	●
93	RING; SNAP,COUNTER FRT BRG ID=55.8	1-09588-125-0	01	1	0107-	●	●
94	KEY; FEATHER,COUNTER SHAFT (A) L=47	1-09735-022-1	02	1	0107-	●	●
94	KEY; FEATHER,COUNTER SHAFT (B) L=55	1-09735-025-0	02	1	0107-	●	●
96	GEAR; COUNTER DRIVE Z=42	1-33331-212-1	01	1	0107-	●
96	GEAR; COUNTER DRIVE Z=43	1-33331-215-1	01	1	0107-		●
97	GEAR; 5TH,COUNTER Z=40	1-33332-113-0	01	1	0107-		●
104	GEAR; 4TH,COUNTER Z=36	1-33332-121-0	01	1	0107-	●
104	GEAR; 4TH,COUNTER Z=33	1-33332-122-0	01	1	0107-		●
105	GEAR; 3RD,COUNTER Z=28	1-33333-161-0	01	1	0107-	●
105	GEAR; 3RD,COUNTER Z=27	1-33333-160-0	01	1	0107-		●
108	SHAFT; COUNTER Z=19-13	1-33311-235-1	01	1	0107-	●
108	SHAFT; COUNTER Z=19-13	1-33311-274-1	01	1	0107-		●
109	BEARING; COUNTER SHAFT,RR KOYO	1-09810-039-1	01	1	0107-	●	●
109	BEARING; COUNTER SHAFT,RR NSK	1-09810-041-1	01	1	0107-	●	●
110	RING; SNAP,COUNTER BRG ID=46.3	1-09588-047-0	01	1	0107-	●	●
111	GEAR; 7TH COUNTER SHAFT Z=45	1-33338-311-1	01	1	0107-		●
112	RING; BLOCK,7TH SYN Z=36	1-33265-281-1	01	1	0107-		●
113	SLEEVE; 7TH COUNTER SHAFT	1-33262-111-3	01	1	0107-		●
114	HUB; CLU,7TH	1-33261-159-1	01	1	0107-		●
117	BEARING; NEEDLE,7TH,COUNTER SHAFT NSK	1-09811-105-0	02	1	0107-		●
121	HUB; CLU,6TH	1-33261-156-2	01	1	0107-0212	●	●
121	HUB; CLU,6TH	1-33261-270-0	01	1	0301-	●	●
122	PLUNGER; DETENT,SYN	1-33269-037-1	03	1	0107-		●
123	BLOCK; INDEX,SYN	1-33269-035-1	03	1	0107-		●
124	SPRING; PLUNGER,CLU HUB	1-09580-395-0	03	1	0107-	●	●
126	RING; SNAP,CLU HUB (A) OD=121.2	1-09587-031-0	01	1	0107-		●
126	RING; SNAP,CLU HUB (B) OD=55.8	1-09588-043-0	01	1	0107-		●
128	WASHER; THRUST,REV SHAFT (A) ID=38.5 T=42	1-33239-079-1	01	1	0107-	●	●
128	WASHER; THRUST,REV SHAFT (B) ID=38.5 T=2	1-33363-024-1	01	1	0107-	●	●
129	BEARING; NEEDLE,IDLER KOYO	1-09811-102-0	02	1	0107-	●	●
129	BEARING; NEEDLE,IDLER NTN	1-09811-103-0	02	1	0107-	●	●
130	COLLAR; DIST,NEEDLE BRG	1-33363-023-0	01	1	0107-	●	●
131	GASKET; REV SHAFT ALSO INCLUDED IN GASKET SET(M/T).	1-09623-384-0	01	1	0107-	●	●
132	SHAFT; REV	1-33351-017-0	01	1	0107-	●	●
135	GEAR; REV IDLER Z=30-25	1-33361-063-0	01	1	0107-	●	●
172	RING; SNAP,CLU HUB ID=130 T=2.5	1-09588-040-0	01	1	0107-	●	●
286	NUT; LK,MAINSHAFT M36 FLANGE	1-09449-063-0	01	1	0107-0805	●	●
286	NUT; LK,MAINSHAFT M36 FLANGE	8-98014-140-0	01	1	0806-	●	●
298	GASKET; MAINSHAFT ALSO INCLUDED IN GASKET SET(M/T). ID=47 T=5	1-09623-380-0	01	1	0107-	●	●
322	SLEEVE; SYN,LOW & 2ND	1-33262-153-1	01	1	0107-	●	●
342	FLANGE; OUTPUT EXC. BRAKE SYSTEM RETARDER<RE2>	1-37243-307-1	01	1	0107-	●	●
345	BOLT; FLANGE TO YOKE EXC. BRAKE SYSTEM RETARDER<RE2> M14X43 KNURL	1-09046-003-0	04	1	0107-0707	●	●
345	BOLT; FLANGE TO YOKE EXC. BRAKE SYSTEM RETARDER<RE2> M14X43	8-98014-003-0	04	1	0708-	●	●

İpucu: çizimdeki balona veya tablodaki Balon sütununa tıkla; ilgili parçalar vurgulanır. Birden çok çizim varsa üstteki seçim kutusu/oklarla gezin.

Isuzu EPC — test · veri: yerel (eski sürüm)
