0-12 — CYLINDER BLOCK (#2934) — 196 parça

1 8 49 58 59 57 56 410 68 55 56 66 67 75 29 242 28 77 76 68 130 38 84 37 83 82 152 152 152 4 11 10 31 37 30 27 32 33 238 95 12 137 9 34 35 89 37 83 39 2 4 152 152 152 74 71 71 73 74 74 72 30

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date	A	B
1	BLOCK ASM; CYL	1-11210-421-0	01	1	9002-9201	●
1	BLOCK ASM; CYL	1-11210-588-0	01	1	9202-9306	●
1	BLOCK ASM; CYL	1-11210-568-1	01	1	9002-		●
2	LINER SET; ENG CYL	1-87810-425-0	06	1	9002-9306	●
2	LINER SET; ENG CYL CHINA TIBET EQUIPMENT(WD1)	1-87810-840-0	06	1	9002-9306		●
2	LINER SET; ENG CYL CHINA TIBET EQUIPMENT(WD1) NON GRADE	1-87811-397-0	06	1	9307-		●
2	LINER SET; ENG CYL EXC. CHINA TIBET EQUIPMENT(WD1)	1-87810-841-0	06	1	9002-9306		●
2	LINER SET; ENG CYL EXC. CHINA TIBET EQUIPMENT(WD1) NON GRADE	1-87811-467-0	06	1	9307-		●
4	LINER; C/BL ALSO INCLUDED IN LINER SET.	1-11261-105-1	06	1	9002-9306	●
4	LINER; C/BL ALSO INCLUDED IN LINER SET.	1-11261-160-0	06	1	9002-9306		●
4	LINER; C/BL ALSO INCLUDED IN LINER SET. OD GRADE=NON,ID GRADE=AX	1-11261-290-0	06	1	9307-		●
4	LINER; C/BL ALSO INCLUDED IN LINER SET. OD GRADE=NON,ID GRADE=CX	1-11261-291-0	06	1	9307-		●
8	BOLT; BRG CAP NO.1,7 M20X150	9-09804-217-0	04	1	9002-9306	●
8	BOLT; BRG CAP NO.2,4,5,6 M20X178	9-09804-218-0	08	1	9002-9306	●
8	BOLT; BRG CAP NO.3	1-09029-064-0	02	1	9202-9306	●
8	BOLT; BRG CAP M18X134	1-09009-103-0	10	1	9002-		●
8	BOLT; BRG CAP M18X123	9-09805-054-0	04	1	9002-		●
9	PIPE ASM; WATER DRAIN COCK	1-13711-036-3	01	1	9002-	●	●
10	CONNECTOR; WATER DRAIN	1-09660-011-1	01	1	9002-	●	●
11	GASKET; CONN TO C/BL ALSO INCLUDED IN GASKET SET(ENGINE). ID=18	9-09571-418-0	01	1	9002-	●	●
12	CONNECTOR; DRAIN COCK,WATER	1-09680-026-0	01	1	9002-9306	●	●
27	NIPPLE; OIL GALLERY ENGINE REAR PTO(SV1)	9-09902-198-0	01	1	9002-9003	●	●
27	NIPPLE; OIL GALLERY ENGINE REAR PTO(SV1)	1-09660-568-0	01	1	9004-9306	●	●
28	COVER; OIL PORT	9-11219-214-0	01	1	9002-	●	●
29	GASKET; COVER,OIL PORT ALSO INCLUDED IN GASKET SET(ENGINE). ID=27.7	1-09623-170-0	01	1	9002-9003	●	●
29	GASKET; COVER,OIL PORT ALSO INCLUDED IN GASKET SET(ENGINE). ID=27.7	1-09623-450-0	01	1	9004-	●	●
30	PIN; CYL HD GASKET SETTING (A) OD=8 L=16	9-08150-816-0	02	1	9002-	●	●
30	PIN; CYL HD GASKET SETTING (B) OD=20 L=15	9-11229-011-2	04	1	9002-	●	●
31	PLUG; OIL GALLERY CHEAPER CAB(SAX) PT1/4	1-09605-019-0	03	1	9010-9306		●
31	PLUG; OIL GALLERY PT1/4	1-09605-019-0	03	1	9307-		●
32	PIN; INJ PUMP BRKT OD=8 L=16	9-08150-816-0	02	1	9002-	●	●
33	CONNECTOR; OIL GALLERY AIR COMPRESSOR HEAVY DUTY<E1Q>	1-09660-034-0	01	1	9103-9306	●
33	CONNECTOR; OIL GALLERY	1-09660-034-0	01	1	9002-9102	●	●
33	CONNECTOR; OIL GALLERY	1-09660-580-0	01	1	9103-		●
34	VALVE; OIL RELIEF	9-13160-060-2	01	1	9002-	●	●
35	GASKET; RELIEF VLV ALSO INCLUDED IN GASKET SET(ENGINE).	1-09623-059-0	01	1	9002-	●	●
37	PLUG; OIL GALLERY (A) PT3/8	1-09605-056-0	02	1	9002-9306	●
37	PLUG; OIL GALLERY (B) PT1/4	1-09605-019-0	04	1	9002-9009	●	●
37	PLUG; OIL GALLERY (B) PT1/4	1-09605-019-0	04	1	9010-9306	●
37	PLUG; OIL GALLERY EXC. CHEAPER CAB(SAX) (B) PT1/4	1-09605-019-0	04	1	9010-9306		●
37	PLUG; OIL GALLERY (C) PT3/4	1-09605-025-0	01	1	9002-	●	●
37	PLUG; OIL GALLERY (D) PT3/4,M8	1-09609-014-1	01	1	9002-	●	●
38	PIN; TIMING GEAR CASE	9-08151-222-0	02	1	9002-	●	●
39	DOWEL; IDLE GEAR SPINDLE	1-11229-013-0	01	1	9002-	●	●
49	WASHER; BRG CAP OD=23.8	9-09851-915-0	14	1	9002-9306	●
49	WASHER; BRG CAP ID=18	9-09851-862-0	14	1	9002-		●
55	PLUG; OIL GALLERY PT3/4	1-09605-025-0	01	1	9002-	●	●
56	JET; OIL,PISTON COOLING (A)	1-13342-082-0	03	1	9002-9306	●
56	JET; OIL,PISTON COOLING (B)	1-13342-083-0	03	1	9002-9306	●
56	JET; OIL,PISTON COOLING (A)	1-13342-068-0	03	1	9002-		●
56	JET; OIL,PISTON COOLING (B)	1-13342-069-0	03	1	9002-		●
57	BOLT; OIL JET M8X20	9-02050-820-0	06	1	9002-9005	●	●
57	BOLT; OIL JET M8X20	0-20800-820-0	06	1	9006-	●	●
58	STUD; OILING JET M8X20 L=32	9-04110-820-0	06	1	9002-	●	●
59	NUT; OILING JET M8	9-09110-408-0	06	1	9002-	●	●
66	CONNECTOR; PARTIAL FILTER	1-13341-077-2	01	1	9002-	●
66	CONNECTOR; PARTIAL FILTER EXC. OIL FILTER CENTRIFUGAL<E6S>	1-13341-077-2	01	1	9002-		●
67	BOLT; CONNECTOR M10X25 W/LK&PL WASHER	0-50151-025-0	03	1	9002-	●
67	BOLT; CONNECTOR EXC. OIL FILTER CENTRIFUGAL<E6S> M10X25 W/LK&PL WASHER	0-50151-025-0	03	1	9002-		●
68	GASKET; RETURN ALSO INCLUDED IN GASKET SET(ENGINE).	1-09623-171-0	01	1	9002-9003	●
68	GASKET; RETURN ALSO INCLUDED IN GASKET SET(ENGINE). EXC. OIL FILTER CENTRIFUGAL<E6S> (A) ID=49.7	1-09623-171-0	01	1	9002-9003		●
68	GASKET; RETURN ALSO INCLUDED IN GASKET SET(ENGINE).	1-09623-541-0	01	1	9004-	●
68	GASKET; RETURN ALSO INCLUDED IN GASKET SET(ENGINE). EXC. OIL FILTER CENTRIFUGAL<E6S> (A) ID=49.7	1-09623-541-0	01	1	9004-		●
68	GASKET; RETURN ALSO INCLUDED IN GASKET SET(ENGINE). EXC. OIL FILTER CENTRIFUGAL<E6S> (B) ID=27.7	1-09623-170-0	01	1	9002-9003		●
68	GASKET; RETURN ALSO INCLUDED IN GASKET SET(ENGINE). EXC. OIL FILTER CENTRIFUGAL<E6S> (B) ID=27.7	1-09623-450-0	01	1	9004-		●
71	GASKET; COVER TO C/BL ALSO INCLUDED IN GASKET SET(ENGINE).	1-11292-028-0	02	1	9002-9306	●
71	GASKET; COVER TO C/BL ALSO INCLUDED IN GASKET SET(ENGINE).	1-11292-030-0	02	1	9002-		●
72	COVER; TAPPET CHAMBER	1-11291-048-3	01	1	9002-9306	●
72	COVER; TAPPET CHAMBER	1-11291-064-1	01	1	9002-		●
73	COVER ASM; TAPPET CHAMBER	1-11291-035-1	01	1	9002-9306	●
73	COVER ASM; TAPPET CHAMBER	1-11291-068-0	01	1	9002-		●
74	BOLT; COVER TO C/BL M8X22	9-01910-822-0	29	1	9002-9005	●
74	BOLT; COVER TO C/BL M8X22 W/LK WASHER	0-50040-822-0	29	1	9006-9306	●
74	BOLT; COVER TO C/BL M8X25 W/LK WASHER	9-01910-825-0	03	1	9002-9005	●
74	BOLT; COVER TO C/BL M8X25 W/LK WASHER	0-50040-825-0	03	1	9006-9306	●
74	BOLT; COVER TO C/BL M8X22	9-01910-822-0	26	1	9002-9005		●
74	BOLT; COVER TO C/BL M8X22 W/LK WASHER	0-50040-822-0	26	1	9006-		●
74	BOLT; COVER TO C/BL M8X25 W/LK WASHER	9-01910-825-0	02	1	9002-9005		●
74	BOLT; COVER TO C/BL M8X25 W/LK WASHER	0-50040-825-0	02	1	9006-		●
75	COVER; C/BL,OIL PUMP	1-11219-122-0	01	1	9002-	●	●
76	GASKET; COVER TO C/BL ALSO INCLUDED IN GASKET SET(ENGINE).	1-13114-008-0	01	1	9002-	●	●
77	BOLT; COVER TO C/BL M10X35 W/LK WASHER	0-50051-035-0	03	1	9002-	●	●
77	BOLT; COVER TO C/BL M10X40 W/LK WASHER	0-50051-040-0	02	1	9002-	●	●
82	STUD; FLYWHEEL HSG M14X42 L=63	9-04411-442-0	01	1	9002-	●	●
83	PIN; FLYWHEEL HSG	9-08151-428-0	02	1	9002-	●	●
84	PLUG; CAM BRG	9-09201-371-0	01	1	9002-	●	●
89	CUP; SEALING,OIL GALLERY OD=45	1-09600-005-1	02	1	9002-		●
95	PRESSURE UNIT; OIL	1-83151-035-0	01	1	9002-9306	●	●
95	PRESSURE UNIT; OIL	1-83151-040-0	01	1	9307-		●
130	DOWEL; BRG CAP ID=13-18 L=14.5	9-11229-040-2	07	1	9002-		●
130	DOWEL; BRG CAP OD=24 L=31	9-11229-046-2	07	1	9002-		●
137	COCK; DRAIN,WATER	1-09680-026-0	01	1	9307-		●
152	GASKET; LINER TO BLOCK ALSO INCLUDED IN LINER SET. (A)	1-09623-471-0	12	1	9002-		●
152	GASKET; LINER TO BLOCK ALSO INCLUDED IN LINER SET. (B)	1-09623-485-0	06	1	9002-		●
238	PLUG; WATER GALLERY	9-09860-031-0	06	1	9002-		●
242	BOLT; COVER,OIL PORT M8X20 W/LK WASHER	9-01910-820-0	02	1	9002-9005	●	●
242	BOLT; COVER,OIL PORT M8X20 W/LK WASHER	0-50040-820-0	02	1	9006-	●	●
410	JET; OIL,TIMING GEAR	9-13342-002-0	01	1	9002-	●	●

2 4 1 49 8 58 59 57 71 56 410 56 67 71 73 74 95 72 77 75 65 68 66 55 76 77 81 27 80 84 37 83 82 37 4 30 30 37 32 28 242 20 29 33 19 18 11 10 12 9 35 34 37 38 39 36 47

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date	A	B
1	BLOCK ASM; CYL	1-11210-421-0	01	1	9002-9201	●
1	BLOCK ASM; CYL	1-11210-588-0	01	1	9202-9306	●
1	BLOCK ASM; CYL	1-11210-568-1	01	1	9002-		●
2	LINER SET; ENG CYL	1-87810-425-0	06	1	9002-9306	●
2	LINER SET; ENG CYL CHINA TIBET EQUIPMENT(WD1)	1-87810-840-0	06	1	9002-9306		●
2	LINER SET; ENG CYL CHINA TIBET EQUIPMENT(WD1) NON GRADE	1-87811-397-0	06	1	9307-		●
2	LINER SET; ENG CYL EXC. CHINA TIBET EQUIPMENT(WD1)	1-87810-841-0	06	1	9002-9306		●
2	LINER SET; ENG CYL EXC. CHINA TIBET EQUIPMENT(WD1) NON GRADE	1-87811-467-0	06	1	9307-		●
4	LINER; C/BL ALSO INCLUDED IN LINER SET.	1-11261-105-1	06	1	9002-9306	●
4	LINER; C/BL ALSO INCLUDED IN LINER SET.	1-11261-160-0	06	1	9002-9306		●
4	LINER; C/BL ALSO INCLUDED IN LINER SET. OD GRADE=NON,ID GRADE=AX	1-11261-290-0	06	1	9307-		●
4	LINER; C/BL ALSO INCLUDED IN LINER SET. OD GRADE=NON,ID GRADE=CX	1-11261-291-0	06	1	9307-		●
8	BOLT; BRG CAP NO.1,7 M20X150	9-09804-217-0	04	1	9002-9306	●
8	BOLT; BRG CAP NO.2,4,5,6 M20X178	9-09804-218-0	08	1	9002-9306	●
8	BOLT; BRG CAP NO.3	1-09029-064-0	02	1	9202-9306	●
8	BOLT; BRG CAP M18X134	1-09009-103-0	10	1	9002-		●
8	BOLT; BRG CAP M18X123	9-09805-054-0	04	1	9002-		●
9	PIPE ASM; WATER DRAIN COCK	1-13711-036-3	01	1	9002-	●	●
10	CONNECTOR; WATER DRAIN	1-09660-011-1	01	1	9002-	●	●
11	GASKET; CONN TO C/BL ALSO INCLUDED IN GASKET SET(ENGINE). ID=18	9-09571-418-0	01	1	9002-	●	●
12	CONNECTOR; DRAIN COCK,WATER	1-09680-026-0	01	1	9002-9306	●	●
18	BOLT; BRKT TO C/BL AIR COMPRESSOR HEAVY DUTY<E1Q> M10X22	9-02361-022-0	02	1	9002-9306	●
19	WASHER; BRKT AIR COMPRESSOR HEAVY DUTY<E1Q> ID=10.5 OD=22 T=4	1-09503-045-0	02	1	9002-9306	●
20	BRACKET; AIR CMPR AIR COMPRESSOR HEAVY DUTY<E1Q>	1-19187-014-1	01	1	9002-9306	●
27	NIPPLE; OIL GALLERY ENGINE REAR PTO(SV1)	9-09902-198-0	01	1	9002-9003	●	●
27	NIPPLE; OIL GALLERY ENGINE REAR PTO(SV1)	1-09660-568-0	01	1	9004-9306	●	●
28	COVER; OIL PORT	9-11219-214-0	01	1	9002-	●	●
29	GASKET; COVER,OIL PORT ALSO INCLUDED IN GASKET SET(ENGINE). ID=27.7	1-09623-170-0	01	1	9002-9003	●	●
29	GASKET; COVER,OIL PORT ALSO INCLUDED IN GASKET SET(ENGINE). ID=27.7	1-09623-450-0	01	1	9004-	●	●
30	PIN; CYL HD GASKET SETTING (A) OD=8 L=16	9-08150-816-0	02	1	9002-	●	●
30	PIN; CYL HD GASKET SETTING (B) OD=20 L=15	9-11229-011-2	04	1	9002-	●	●
32	PIN; INJ PUMP BRKT OD=8 L=16	9-08150-816-0	02	1	9002-	●	●
33	CONNECTOR; OIL GALLERY AIR COMPRESSOR HEAVY DUTY<E1Q>	1-09660-034-0	01	1	9103-9306	●
33	CONNECTOR; OIL GALLERY	1-09660-034-0	01	1	9002-9102	●	●
33	CONNECTOR; OIL GALLERY	1-09660-580-0	01	1	9103-		●
34	VALVE; OIL RELIEF	9-13160-060-2	01	1	9002-	●	●
35	GASKET; RELIEF VLV ALSO INCLUDED IN GASKET SET(ENGINE).	1-09623-059-0	01	1	9002-	●	●
36	CUP; SEALING,WATER JACKET OD=45	1-09600-005-1	04	1	9002-9306	●
37	PLUG; OIL GALLERY (A) PT3/8	1-09605-056-0	02	1	9002-9306	●
37	PLUG; OIL GALLERY (B) PT1/4	1-09605-019-0	04	1	9002-9009	●	●
37	PLUG; OIL GALLERY (B) PT1/4	1-09605-019-0	04	1	9010-9306	●
37	PLUG; OIL GALLERY EXC. CHEAPER CAB(SAX) (B) PT1/4	1-09605-019-0	04	1	9010-9306		●
37	PLUG; OIL GALLERY (C) PT3/4	1-09605-025-0	01	1	9002-	●	●
37	PLUG; OIL GALLERY (D) PT3/4,M8	1-09609-014-1	01	1	9002-	●	●
38	PIN; TIMING GEAR CASE	9-08151-222-0	02	1	9002-	●	●
39	DOWEL; IDLE GEAR SPINDLE	1-11229-013-0	01	1	9002-	●	●
47	PIN; BRG CAP OD=8 L=16	9-08150-816-0	14	1	9002-9306	●
49	WASHER; BRG CAP OD=23.8	9-09851-915-0	14	1	9002-9306	●
49	WASHER; BRG CAP ID=18	9-09851-862-0	14	1	9002-		●
55	PLUG; OIL GALLERY PT3/4	1-09605-025-0	01	1	9002-	●	●
56	JET; OIL,PISTON COOLING (A)	1-13342-082-0	03	1	9002-9306	●
56	JET; OIL,PISTON COOLING (B)	1-13342-083-0	03	1	9002-9306	●
56	JET; OIL,PISTON COOLING (A)	1-13342-068-0	03	1	9002-		●
56	JET; OIL,PISTON COOLING (B)	1-13342-069-0	03	1	9002-		●
57	BOLT; OIL JET M8X20	9-02050-820-0	06	1	9002-9005	●	●
57	BOLT; OIL JET M8X20	0-20800-820-0	06	1	9006-	●	●
58	STUD; OILING JET M8X20 L=32	9-04110-820-0	06	1	9002-	●	●
59	NUT; OILING JET M8	9-09110-408-0	06	1	9002-	●	●
65	GASKET; SUCTION ID=27.7	1-09623-170-0	01	1	9002-9003	●
65	GASKET; SUCTION ID=27.7	1-09623-450-0	01	1	9004-9306	●
66	CONNECTOR; PARTIAL FILTER	1-13341-077-2	01	1	9002-	●
66	CONNECTOR; PARTIAL FILTER EXC. OIL FILTER CENTRIFUGAL<E6S>	1-13341-077-2	01	1	9002-		●
67	BOLT; CONNECTOR M10X25 W/LK&PL WASHER	0-50151-025-0	03	1	9002-	●
67	BOLT; CONNECTOR EXC. OIL FILTER CENTRIFUGAL<E6S> M10X25 W/LK&PL WASHER	0-50151-025-0	03	1	9002-		●
68	GASKET; RETURN ALSO INCLUDED IN GASKET SET(ENGINE).	1-09623-171-0	01	1	9002-9003	●
68	GASKET; RETURN ALSO INCLUDED IN GASKET SET(ENGINE). EXC. OIL FILTER CENTRIFUGAL<E6S> (A) ID=49.7	1-09623-171-0	01	1	9002-9003		●
68	GASKET; RETURN ALSO INCLUDED IN GASKET SET(ENGINE).	1-09623-541-0	01	1	9004-	●
68	GASKET; RETURN ALSO INCLUDED IN GASKET SET(ENGINE). EXC. OIL FILTER CENTRIFUGAL<E6S> (A) ID=49.7	1-09623-541-0	01	1	9004-		●
68	GASKET; RETURN ALSO INCLUDED IN GASKET SET(ENGINE). EXC. OIL FILTER CENTRIFUGAL<E6S> (B) ID=27.7	1-09623-170-0	01	1	9002-9003		●
68	GASKET; RETURN ALSO INCLUDED IN GASKET SET(ENGINE). EXC. OIL FILTER CENTRIFUGAL<E6S> (B) ID=27.7	1-09623-450-0	01	1	9004-		●
71	GASKET; COVER TO C/BL ALSO INCLUDED IN GASKET SET(ENGINE).	1-11292-028-0	02	1	9002-9306	●
71	GASKET; COVER TO C/BL ALSO INCLUDED IN GASKET SET(ENGINE).	1-11292-030-0	02	1	9002-		●
72	COVER; TAPPET CHAMBER	1-11291-048-3	01	1	9002-9306	●
72	COVER; TAPPET CHAMBER	1-11291-064-1	01	1	9002-		●
73	COVER ASM; TAPPET CHAMBER	1-11291-035-1	01	1	9002-9306	●
73	COVER ASM; TAPPET CHAMBER	1-11291-068-0	01	1	9002-		●
74	BOLT; COVER TO C/BL M8X22	9-01910-822-0	29	1	9002-9005	●
74	BOLT; COVER TO C/BL M8X22 W/LK WASHER	0-50040-822-0	29	1	9006-9306	●
74	BOLT; COVER TO C/BL M8X25 W/LK WASHER	9-01910-825-0	03	1	9002-9005	●
74	BOLT; COVER TO C/BL M8X25 W/LK WASHER	0-50040-825-0	03	1	9006-9306	●
74	BOLT; COVER TO C/BL M8X22	9-01910-822-0	26	1	9002-9005		●
74	BOLT; COVER TO C/BL M8X22 W/LK WASHER	0-50040-822-0	26	1	9006-		●
74	BOLT; COVER TO C/BL M8X25 W/LK WASHER	9-01910-825-0	02	1	9002-9005		●
74	BOLT; COVER TO C/BL M8X25 W/LK WASHER	0-50040-825-0	02	1	9006-		●
75	COVER; C/BL,OIL PUMP	1-11219-122-0	01	1	9002-	●	●
76	GASKET; COVER TO C/BL ALSO INCLUDED IN GASKET SET(ENGINE).	1-13114-008-0	01	1	9002-	●	●
77	BOLT; COVER TO C/BL M10X35 W/LK WASHER	0-50051-035-0	03	1	9002-	●	●
77	BOLT; COVER TO C/BL M10X40 W/LK WASHER	0-50051-040-0	02	1	9002-	●	●
80	CUP; SEALING,TAPPET CHAMBER PT1/8	1-09605-050-0	15	1	9002-9306	●
81	PLUG; WATER JACKET	9-09864-050-1	06	1	9002-9306	●
82	STUD; FLYWHEEL HSG M14X42 L=63	9-04411-442-0	01	1	9002-	●	●
83	PIN; FLYWHEEL HSG	9-08151-428-0	02	1	9002-	●	●
84	PLUG; CAM BRG	9-09201-371-0	01	1	9002-	●	●
95	PRESSURE UNIT; OIL	1-83151-035-0	01	1	9002-9306	●	●
95	PRESSURE UNIT; OIL	1-83151-040-0	01	1	9307-		●
242	BOLT; COVER,OIL PORT M8X20 W/LK WASHER	9-01910-820-0	02	1	9002-9005	●	●
242	BOLT; COVER,OIL PORT M8X20 W/LK WASHER	0-50040-820-0	02	1	9006-	●	●
410	JET; OIL,TIMING GEAR	9-13342-002-0	01	1	9002-	●	●

İpucu: çizimdeki balona veya tablodaki Balon sütununa tıkla; ilgili parçalar vurgulanır. Birden çok çizim varsa üstteki seçim kutusu/oklarla gezin.

Isuzu EPC — test · veri: yerel (eski sürüm)
