1 |
SHAFT; TOP GEAR,TRANS
Z=22
|
1-33211-897-0 |
01 |
1 |
0311- |
| |
2 |
RING; SNAP,TOP GEAR SHAFT
ID=66 T=2.53 WHITE
|
1-09588-131-0 |
AR |
1 |
0311- |
| |
2 |
RING; SNAP,TOP GEAR SHAFT
ID=66 T=2.56 YELLOW
|
1-09588-132-0 |
AR |
1 |
0311- |
| |
2 |
RING; SNAP,TOP GEAR SHAFT
ID=66 T=2.60 BLUE
|
1-09588-133-0 |
AR |
1 |
0311- |
| |
2 |
RING; SNAP,TOP GEAR SHAFT
ID=66 T=2.64 GREEN
|
1-09588-134-0 |
AR |
1 |
0311- |
| |
3 |
BEARING; TOP GEAR SHAFT
NTN
|
1-09810-164-0 |
01 |
1 |
0311- |
| |
3 |
BEARING; TOP GEAR SHAFT
NSK
|
1-09810-185-0 |
01 |
1 |
0311- |
| |
8 |
CLIP; DOG CLU
|
1-33219-008-0 |
01 |
1 |
0311- |
| |
9 |
CLUTCH; DOG,TOP GEAR
Z=54
|
1-33265-152-3 |
01 |
1 |
0311- |
| |
16 |
BEARING; PILOT,MAINSHAFT
NSK
|
1-09810-139-0 |
01 |
1 |
0311- |
| |
16 |
BEARING; PILOT,MAINSHAFT
NTN
|
1-09810-208-0 |
01 |
1 |
0311- |
| |
17 |
RING; SNAP,4TH GEAR
ID=55.8 T=2.53 WHITE
|
1-09588-160-1 |
01 |
1 |
0311- |
| |
19 |
RING; BLOCK,4TH & 5TH
(A)
Z=54
|
1-33265-290-8 |
01 |
1 |
0311- |
| |
19 |
RING; BLOCK,4TH & 5TH
(B)
Z=54
|
1-33265-544-1 |
01 |
1 |
0311- |
| |
20 |
SLEEVE
|
1-33262-097-1 |
01 |
1 |
0311- |
| |
21 |
HUB; CLU,4TH & 5TH
|
1-33261-186-2 |
01 |
1 |
0311- |
| |
22 |
SPRING; BLOCK,INSERT
|
1-09583-171-0 |
03 |
1 |
0311- |
| |
23 |
PLUNGER; DETENT,SYN
|
1-33263-020-0 |
03 |
1 |
0311- |
| |
25 |
INSERT; CLU HUB,4TH TO 5TH
|
1-33263-025-2 |
03 |
1 |
0311- |
| |
26 |
SPRING; BLOCK,INSERT
D=6.2
|
1-09580-091-1 |
03 |
1 |
0311- |
| |
27 |
BEARING; 4TH GEAR
NSK
|
1-09811-360-0 |
02 |
1 |
0311-1311 |
| |
27 |
BEARING; 4TH GEAR
NTN
|
1-09811-391-0 |
02 |
1 |
0311- |
| |
28 |
RING; SNAP,3RD GEAR
ID=74.5
|
1-09588-118-0 |
01 |
1 |
0311- |
| |
30 |
GEAR; 4TH,MAINSHAFT
Z=28
|
1-33253-606-0 |
01 |
1 |
0311- |
| |
32 |
COLLAR; 3RD GEAR
|
1-33234-075-0 |
01 |
1 |
0311- |
| |
33 |
BEARING; NEEDLE,3RD GEAR
NTN
|
1-09811-389-0 |
02 |
1 |
0311- |
| |
33 |
BEARING; NEEDLE,3RD GEAR
NSK
|
1-09811-411-0 |
02 |
1 |
0311- |
| |
36 |
GEAR; 3RD,MAINSHAFT
Z=37
|
1-33252-461-0 |
01 |
1 |
0311- |
| |
44 |
HUB; CLU,2ND & 3RD,MAIN
|
1-33261-260-0 |
01 |
1 |
0311- |
| |
45 |
SPRING; BLOCK INSERT
D=3.8
|
1-09580-395-0 |
03 |
1 |
0311- |
| |
46 |
PLUNGER; DETENT,SYN
|
1-33269-037-1 |
03 |
1 |
0311- |
| |
47 |
BLOCK; INDEX,SYN
|
1-33269-035-1 |
03 |
1 |
0311- |
| |
48 |
SYNCHRONIZER ASM; 2ND & 3RD
|
1-33265-542-0 |
02 |
1 |
0311-0407 |
| |
48 |
SYNCHRONIZER ASM; 2ND & 3RD
|
1-33265-611-1 |
02 |
1 |
0408- |
| |
49 |
BEARING; NEEDLE,2ND GEAR
NTN
|
1-09811-389-0 |
02 |
1 |
0311- |
| |
49 |
BEARING; NEEDLE,2ND GEAR
NSK
|
1-09811-411-0 |
02 |
1 |
0311- |
| |
50 |
GEAR; 2ND,MAINSHAFT
Z=52
|
1-33251-327-3 |
01 |
1 |
0311- |
| |
56 |
BEARING; NEEDLE,1ST,REV
NTN
|
1-09811-389-0 |
04 |
1 |
0311- |
| |
56 |
BEARING; NEEDLE,1ST,REV
NSK
|
1-09811-411-0 |
04 |
1 |
0311- |
| |
59 |
GEAR; REV MAINSHAFT
Z=38
|
1-33257-066-1 |
01 |
1 |
0311- |
| |
67 |
HUB; CLU,1ST TO REV
|
1-33261-223-0 |
01 |
1 |
0311- |
| |
68 |
SLEEVE; 1ST TO REV
|
1-33262-160-0 |
01 |
1 |
0311- |
| |
70 |
GEAR; 1ST,MAINSHAFT
Z=44
|
1-33255-064-0 |
01 |
1 |
0311- |
| |
76 |
WASHER; THRUST,MAIN LOW
|
1-33239-146-0 |
01 |
1 |
0311- |
| |
77 |
GEAR; 6TH,MAINSHAFT
Z=19
|
1-33253-474-0 |
01 |
1 |
0311- |
| |
78 |
COLLAR; DIST,MAINSHAFT BRG
|
1-33235-074-0 |
01 |
1 |
0311- |
| |
80 |
GEAR; SPD DRIVE
Z=5
|
1-33371-014-2 |
01 |
1 |
0311- |
| |
82 |
SHAFT; MAIN,TRANS
Z=28-28-37-18
|
1-33231-306-0 |
01 |
1 |
0311- |
| |
84 |
BEARING; COUNTER SHAFT,FRT
NSK
|
1-09810-221-0 |
01 |
1 |
0311-1405 |
| |
84 |
BEARING; COUNTER SHAFT,FRT
NSK
|
1-09810-287-1 |
01 |
1 |
1406- |
| |
84 |
BEARING; COUNTER SHAFT,FRT
NTN
|
1-09810-222-0 |
01 |
1 |
0311-1405 |
| |
93 |
RING; SNAP,COUNTER FRT BRG
ID=74.5
|
1-09588-118-0 |
01 |
1 |
0311- |
| |
94 |
KEY; FEATHER,COUNTER SHAFT
L=50.0
|
1-09735-010-0 |
01 |
1 |
0311- |
| |
96 |
GEAR; COUNTER DRIVE
Z=41
|
1-33331-193-0 |
01 |
1 |
0311- |
| |
101 |
KEY; PTO DRIVE GEAR
L=40
|
1-09735-008-0 |
01 |
1 |
0311- |
| |
102 |
GEAR; PTO DRIVE,COUNTER
Z=33
|
1-33337-014-1 |
01 |
1 |
0311- |
| |
103 |
KEY; COUNTER GEAR
L=50.0
|
1-09735-010-0 |
01 |
1 |
0311- |
| |
103 |
KEY; COUNTER GEAR
L=46
|
1-09735-038-1 |
01 |
1 |
0311- |
| |
104 |
GEAR; 4TH,COUNTER
Z=36
|
1-33338-291-0 |
01 |
1 |
0311- |
| |
105 |
GEAR; 3RD,COUNTER
Z=28
|
1-33333-147-1 |
01 |
1 |
0311- |
| |
108 |
SHAFT; COUNTER
Z=23-13
|
1-33311-276-0 |
01 |
1 |
0311- |
| |
109 |
BEARING; COUNTER SHAFT,RR
NSK
|
1-09810-021-1 |
01 |
1 |
0311- |
| |
109 |
BEARING; COUNTER SHAFT,RR
NTN
|
1-09810-163-0 |
01 |
1 |
0311- |
| |
110 |
RING; SNAP,COUNTER BRG
|
1-09588-042-1 |
01 |
1 |
0311- |
| |
115 |
BEARING; NEEDLE,6TH,COUNTER
NSK
|
1-09811-355-0 |
02 |
1 |
0311-1311 |
| |
115 |
BEARING; NEEDLE,6TH,COUNTER
NTN
|
1-09811-402-0 |
02 |
1 |
0311- |
| |
118 |
GEAR; 6TH,COUNTER
Z=44
|
1-33338-307-0 |
01 |
1 |
0311- |
| |
119 |
RING; BLOCK,6TH SYN
Z=54
|
1-33265-356-0 |
01 |
1 |
0311- |
| |
120 |
SLEEVE
|
1-33262-098-2 |
01 |
1 |
0311- |
| |
121 |
HUB; CLU,6TH
|
1-33261-189-2 |
01 |
1 |
0311- |
| |
122 |
PLUNGER; DETENT,SYN
|
1-33263-020-0 |
03 |
1 |
0311- |
| |
124 |
SPRING; PLUNGER,CLU HUB
D=6.2
|
1-09580-091-1 |
03 |
1 |
0311- |
| |
125 |
INSERT; 6TH SYN
|
1-33263-025-2 |
03 |
1 |
0311- |
| |
126 |
RING; SNAP,CLU HUB
(A)
ID=130 T=2.5
|
1-09588-040-0 |
01 |
1 |
0311- |
| |
126 |
RING; SNAP,CLU HUB
(B)
ID=55.8 T=2.53 WHITE
|
1-09588-160-1 |
01 |
1 |
0311- |
| |
128 |
WASHER; THRUST,REV SHAFT
T=4.0
|
9-33363-015-0 |
02 |
1 |
0311- |
| |
129 |
BEARING; NEEDLE,IDLER
NSK
|
1-09811-388-0 |
02 |
1 |
0311- |
| |
129 |
BEARING; NEEDLE,IDLER
NTN
|
9-00096-215-0 |
02 |
1 |
0311- |
| |
130 |
COLLAR; DIST,NEEDLE BRG
|
1-33359-001-0 |
01 |
1 |
0311- |
| |
132 |
SHAFT; REV
|
1-33351-012-2 |
01 |
1 |
0311- |
| |
133 |
SCREW; SET,REV SHAFT
|
1-09122-023-0 |
01 |
1 |
0311- |
| |
134 |
WASHER; LK,REV SHAFT
ID=8.2
|
9-09150-508-0 |
01 |
1 |
0311-0603 |
| |
134 |
WASHER; LK,REV SHAFT
ID=8.2
|
0-91510-508-0 |
01 |
1 |
0604- |
| |
135 |
GEAR; REV IDLER
Z=27
|
1-33361-070-1 |
01 |
1 |
0311- |
| |
149 |
BEARING; NEEDLE,MAINSHAFT,RR
(A)
NSK
|
1-09810-021-1 |
01 |
1 |
0311- |
| |
149 |
BEARING; NEEDLE,MAINSHAFT,RR
(A)
NTN
|
1-09810-163-0 |
01 |
1 |
0311- |
| |
149 |
BEARING; NEEDLE,MAINSHAFT,RR
(B)
NSK
|
1-09810-172-0 |
01 |
1 |
0311- |
| |
149 |
BEARING; NEEDLE,MAINSHAFT,RR
(B)
NTN
|
1-09810-173-0 |
01 |
1 |
0311- |
| |
429 |
SLEEVE; 2ND & 3RD
|
1-33262-220-0 |
01 |
1 |
0311- |
