4-10 — FRONT AXLE (#2848) — 212 parça

21 21 60 2 1 30 32 33 34 25 30 9 305 34 33 32 8 25 6 6 8 8 11 105 105 109 104 103 109 103 103 104 103 106 107 108 106 107 108 61 81 74 275 58 80 66 59 68 66 304 67 58 51 52 8 6 17 18 61 40 6 8 8 305 9 5 2 11 3 37 36 37 50

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date	A	B
1	AXLE; FRT	1-43111-051-4	01	1	9002-9306	●	●
1	AXLE; FRT	1-43111-107-3	01	1	9307-	●	●
2	KNUCKLE; FRT AXLE	1-43132-046-3	01	1	9002-9404	●	●
2	KNUCKLE; FRT AXLE	1-43132-079-0	01	1	9405-	●	●
2	KNUCKLE; FRT AXLE	1-43131-046-4	01	1	9002-9404	●	●
2	KNUCKLE; FRT AXLE	1-43131-079-0	01	1	9405-	●	●
3	KING PIN SET	1-87830-039-5	02	1	9002-9306	●	●
3	KING PIN SET	1-87830-640-0	02	1	9307-9404	●	●
3	KING PIN SET	1-87830-738-0	02	1	9405-	●	●
5	PIN; KNUCKLE TO DRUM COVER	9-09878-625-0	02	1	9002-9404	●	●
5	PIN; KNUCKLE TO DRUM COVER	1-09740-072-0	02	1	9405-	●	●
6	SEAL; KING PIN	9-09926-024-0	04	1	9002-	●	●
8	BEARING; NEEDLE,KING PIN (A) NTN	9-00096-242-0	04	1	9002-	●	●
8	BEARING; NEEDLE,KING PIN (B) NTN	9-00096-243-0	02	1	9002-	●	●
9	PLUG; KNUCKLE	9-09201-363-0	02	1	9002-9404	●	●
11	RING; SNAP,KNUCKLE PLUG	9-09950-204-0	02	1	9002-	●	●
17	BOLT; STOPPER KNUCKLE M18X43	1-09009-065-0	02	1	9002-	●	●
18	NUT; STOPPER BOLT,KNUCKLE M18	9-99110-518-0	02	1	9002-	●	●
21	NIPPLE; GREASE,KING PIN (A) PT1/8 ELBOW 67.5?	9-09031-110-0	02	1	9002-	●	●
21	NIPPLE; GREASE,KING PIN (B) PT1/8 ELBOW	9-09031-210-0	02	1	9002-	●	●
25	BEARING; THRUST,KING PIN NTN	1-09829-027-1	02	1	9002-9203	●	●
25	BEARING; THRUST,KING PIN NSK	1-09829-043-2	02	1	9204-	●	●
30	WASHER; THRUST,KING PIN T=4.875 -4.900	1-43171-185-0	AR	1	9002-	●	●
30	WASHER; THRUST,KING PIN T=4.900 -4.925	1-43171-186-0	AR	1	9002-	●	●
30	WASHER; THRUST,KING PIN T=4.925 -4.950	1-43171-187-0	AR	1	9002-	●	●
30	WASHER; THRUST,KING PIN T=4.950 -4.975	1-43171-188-0	AR	1	9002-	●	●
30	WASHER; THRUST,KING PIN T=4.975 -5.000	1-43171-189-0	AR	1	9002-	●	●
30	WASHER; THRUST,KING PIN T=5.000 -5.025	1-43171-190-0	AR	1	9002-	●	●
30	WASHER; THRUST,KING PIN T=5.025 -5.050	1-43171-191-0	AR	1	9002-	●	●
30	WASHER; THRUST,KING PIN T=5.050 -5.075	1-43171-192-0	AR	1	9002-	●	●
30	WASHER; THRUST,KING PIN T=5.075 -5.100	1-43171-193-0	AR	1	9002-	●	●
30	WASHER; THRUST,KING PIN T=5.100 -5.125	1-43171-194-0	AR	1	9002-	●	●
30	WASHER; THRUST,KING PIN T=5.125 -5.150	1-43171-195-0	AR	1	9002-	●	●
30	WASHER; THRUST,KING PIN T=5.150 -5.175	1-43171-196-0	AR	1	9002-	●	●
30	WASHER; THRUST,KING PIN T=5.175 -5.200	1-43171-197-0	AR	1	9002-	●	●
30	WASHER; THRUST,KING PIN T=5.200 -5.225	1-43171-198-0	AR	1	9002-	●	●
30	WASHER; THRUST,KING PIN T=5.225 -5.250	1-43171-199-0	AR	1	9002-	●	●
32	BOLT; KEY,KING PIN	1-43116-002-1	02	1	9002-	●	●
33	NUT; KEY BOLT M10	9-09110-410-0	02	1	9002-	●	●
34	WASHER; LK,KEY BOLT ID=10.2	9-09150-510-0	02	1	9002-	●	●
36	ARM; KNUCKLE	1-43133-050-1	01	1	9002-9306	●	●
36	ARM; KNUCKLE	1-43133-057-1	01	1	9307-9404	●	●
36	ARM; KNUCKLE	1-43133-063-1	01	1	9405-	●	●
37	BOLT; KNUCKLE ARM (B) M22X167	1-09000-153-0	01	1	9002-9111	●	●
37	BOLT; KNUCKLE ARM (A) M22X179	1-09000-578-1	01	1	9112-	●	●
37	BOLT; KNUCKLE ARM (A) M22X179	9-09806-848-1	01	1	9002-9111	●	●
37	BOLT; KNUCKLE ARM (B) M22X167	9-09806-847-3	01	1	9112-	●	●
40	NUT; KNUCKLE ARM M22	9-09844-670-1	02	1	9002-	●	●
50	BRACKET; POWER CHAMBER	1-43145-010-2	01	1	9002-	●	●
50	BRACKET; POWER CHAMBER	1-43145-009-2	01	1	9002-	●	●
51	BOLT; POWER CHAMBER BRKT M12X60	9-91056-260-0	02	1	9002-9005	●	●
51	BOLT; POWER CHAMBER BRKT M12X60	0-10806-260-0	02	1	9006-	●	●
51	BOLT; POWER CHAMBER BRKT M12X28	9-92051-228-0	06	1	9002-9005	●	●
51	BOLT; POWER CHAMBER BRKT M12X28	0-20801-228-0	06	1	9006-	●	●
52	WASHER; LK,POWER CHAMBER BRKT ID=12.2	9-09150-512-0	08	1	9002-	●	●
58	ARM; TIE ROD WHEEL BASE 4500MM(45W)	1-43135-021-1	01	1	9002-9404	●	●
58	ARM; TIE ROD WHEEL BASE 4500MM(45W)	1-43135-044-0	01	1	9405-	●	●
58	ARM; TIE ROD WHEEL BASE 4500MM(45W)	1-43134-021-1	01	1	9002-9404	●	●
58	ARM; TIE ROD WHEEL BASE 4500MM(45W)	1-43134-044-0	01	1	9405-	●	●
58	ARM; TIE ROD WHEEL BASE 5000MM(50W),WHEEL BASE 5300MM(53W), WHEEL BASE 5500MM(55W),WHEEL BASE 5800MM(58W),WHEEL BASE 6400MM(64W)	1-43135-036-0	01	1	9002-9404	●	●
58	ARM; TIE ROD WHEEL BASE 5000MM(50W),WHEEL BASE 5300MM(53W), WHEEL BASE 5500MM(55W),WHEEL BASE 5800MM(58W),WHEEL BASE 6400MM(64W)	1-43135-043-0	01	1	9405-	●	●
58	ARM; TIE ROD WHEEL BASE 5000MM(50W),WHEEL BASE 5300MM(53W), WHEEL BASE 5500MM(55W),WHEEL BASE 5800MM(58W),WHEEL BASE 6400MM(64W)	1-43134-036-0	01	1	9002-9404	●	●
58	ARM; TIE ROD WHEEL BASE 5000MM(50W),WHEEL BASE 5300MM(53W), WHEEL BASE 5500MM(55W),WHEEL BASE 5800MM(58W),WHEEL BASE 6400MM(64W)	1-43134-043-0	01	1	9405-	●	●
59	NUT; TIE ROD ARM M22	9-09844-670-1	04	1	9002-	●	●
60	BOLT; TIE ROD ARM M22X193	1-09000-154-2	04	1	9002-	●	●
61	ROD END; TIE ROD	1-43150-631-2	01	1	9307-	●	●
61	ROD END; TIE ROD	1-43150-630-2	01	1	9307-	●	●
61	ROD END; TIE ROD L TYPE ENG<90L>	1-43150-436-1	01	1	9002-9306	●	●
61	ROD END; TIE ROD L TYPE ENG<90L>	1-43150-435-1	01	1	9002-9306	●	●
61	ROD END; TIE ROD V TYPE ENG<91L>	1-43150-440-1	01	1	9002-9306	●	●
61	ROD END; TIE ROD V TYPE ENG<91L>	1-43150-439-1	01	1	9002-9306	●	●
66	NUT; TIE ROD END M24	9-09844-669-2	02	1	9002-9306	●	●
66	NUT; TIE ROD END M24 SLOTTED	1-09442-020-0	02	1	9307-	●	●
67	WASHER; LK,TIE ROD END ID=12.2	9-09150-512-0	04	1	9002-9207	●	●
67	WASHER; LK,TIE ROD END ID=12.2	9-09150-812-0	04	1	9208-9410	●	●
68	BOLT; TIE ROD END M12X55	9-91061-255-0	04	1	9002-	●	●
74	NUT; TIE ROD END M12	9-99110-412-0	04	1	9002-9207	●	●
74	NUT; TIE ROD END M12	9-99110-512-0	04	1	9208-	●	●
80	PIN; SPLIT,ROD END OD=4.6 L=35	9-08115-035-0	02	1	9307-	●	●
81	ROD; TIE L TYPE ENG<90L> WHEEL BASE 4500MM(45W) L=1600	9-43151-118-1	01	1	9002-9306	●
81	ROD; TIE V TYPE ENG<91L> WHEEL BASE 4500MM(45W) L=1605	1-43151-027-0	01	1	9002-9306	●
81	ROD; TIE WHEEL BASE 4500MM(45W) L=1605	1-43151-027-0	01	1	9307-9407	●
81	ROD; TIE WHEEL BASE 4500MM(45W) L=1600	1-43151-012-0	01	1	9408-	●	●
81	ROD; TIE L TYPE ENG<90L> WHEEL BASE 5000MM(50W),WHEEL BASE 5500MM(55W), WHEEL BASE 5800MM(58W),WHEEL BASE 6400MM(64W) L=1648	9-43151-121-1	01	1	9002-9306	●	●
81	ROD; TIE V TYPE ENG<91L> WHEEL BASE 5000MM(50W),WHEEL BASE 5800MM(58W) L=1650	1-43151-026-0	01	1	9002-9306	●	●
81	ROD; TIE WHEEL BASE 5000MM(50W),WHEEL BASE 5300MM(53W), WHEEL BASE 5500MM(55W),WHEEL BASE 5800MM(58W),WHEEL BASE 6400MM(64W) L=1650	1-43151-066-0	01	1	9307-	●	●
103	NUT; BRKT FIX EXC. CAB SUSPENSION RIGID(W71) M14	9-99110-514-0	02	1	9002-	●	●
103	NUT; BRKT FIX EXC. CAB UP 110MM(W60),CAB SUSPENSION RIGID(W71) M10	9-09110-510-0	02	1	9002-	●	●
104	WASHER; LK,BRKT EXC. CAB SUSPENSION RIGID(W71) ID=14.2	9-09150-614-0	02	1	9002-	●	●
105	BOLT; BRKT FIX EXC. CAB UP 110MM(W60),CAB SUSPENSION RIGID(W71) M10X25	9-01911-025-0	02	1	9002-9002	●	●
105	BOLT; BRKT FIX EXC. CAB UP 110MM(W60),CAB SUSPENSION RIGID(W71) M10X25 W/LK WASHER	0-50041-025-0	02	1	9003-	●	●
106	BOLT; CAP FIX EXC. CAB SUSPENSION RIGID(W71) M8X25 W/LK WASHER	9-01910-825-0	02	1	9002-9005	●	●
106	BOLT; CAP FIX EXC. CAB SUSPENSION RIGID(W71) M8X25 W/LK WASHER	0-50040-825-0	02	1	9006-9302	●	●
106	BOLT; CAP FIX EXC. CAB SUSPENSION RIGID(W71) M8X25 FLANGE	0-28080-825-0	02	1	9303-	●	●
107	BUSHING; STABILIZER BAR EXC. CAB SUSPENSION RIGID(W71)	1-53459-860-0	02	1	9002-	●	●
108	CAP EXC. CAB SUSPENSION RIGID(W71)	1-53459-392-1	02	1	9002-	●	●
109	BUFFER; STAB BAR CAB UP 110MM(W60)	1-53459-535-1	01	1	9002-	●	●
109	BUFFER; STAB BAR CAB UP 110MM(W60)	1-53459-536-1	01	1	9002-	●	●
109	BUFFER; STAB BAR EXC. CAB UP 110MM(W60),CAB SUSPENSION RIGID(W71)	1-53459-532-0	01	1	9002-	●	●
109	BUFFER; STAB BAR EXC. CAB UP 110MM(W60),CAB SUSPENSION RIGID(W71)	1-53459-533-0	01	1	9002-	●	●
275	BOOT; ROD END,TIE	1-43159-078-0	02	1	9307-	●	●
304	WASHER; PL ID=12.5	9-09164-512-0	04	1	9411-	●	●
305	COVER; KNUCKLE	1-43175-021-0	02	1	9405-	●	●

21 21 60 2 1 30 32 33 34 30 25 33 34 32 11 9 8 25 6 8 6 8 3 11 9 5 2 43 37 37 50 255 42 36 51 52 8 6 6 8 8 18 17 40 58 66 81 61 66 58 59 61 68 67 71 73 74 72 72 75 78 77 79 105 105 109 104 103 107 108 106 108 106 107 103 109 103 104 103

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date	A	B
1	AXLE; FRT	1-43111-051-4	01	1	9002-9306	●	●
1	AXLE; FRT	1-43111-107-3	01	1	9307-	●	●
2	KNUCKLE; FRT AXLE	1-43132-046-3	01	1	9002-9404	●	●
2	KNUCKLE; FRT AXLE	1-43132-079-0	01	1	9405-	●	●
2	KNUCKLE; FRT AXLE	1-43131-046-4	01	1	9002-9404	●	●
2	KNUCKLE; FRT AXLE	1-43131-079-0	01	1	9405-	●	●
3	KING PIN SET	1-87830-039-5	02	1	9002-9306	●	●
3	KING PIN SET	1-87830-640-0	02	1	9307-9404	●	●
3	KING PIN SET	1-87830-738-0	02	1	9405-	●	●
5	PIN; KNUCKLE TO DRUM COVER	9-09878-625-0	02	1	9002-9404	●	●
5	PIN; KNUCKLE TO DRUM COVER	1-09740-072-0	02	1	9405-	●	●
6	SEAL; KING PIN	9-09926-024-0	04	1	9002-	●	●
8	BEARING; NEEDLE,KING PIN (A) NTN	9-00096-242-0	04	1	9002-	●	●
8	BEARING; NEEDLE,KING PIN (B) NTN	9-00096-243-0	02	1	9002-	●	●
9	PLUG; KNUCKLE	9-09201-363-0	02	1	9002-9404	●	●
11	RING; SNAP,KNUCKLE PLUG	9-09950-204-0	02	1	9002-	●	●
17	BOLT; STOPPER KNUCKLE M18X43	1-09009-065-0	02	1	9002-	●	●
18	NUT; STOPPER BOLT,KNUCKLE M18	9-99110-518-0	02	1	9002-	●	●
21	NIPPLE; GREASE,KING PIN (A) PT1/8 ELBOW 67.5?	9-09031-110-0	02	1	9002-	●	●
21	NIPPLE; GREASE,KING PIN (B) PT1/8 ELBOW	9-09031-210-0	02	1	9002-	●	●
25	BEARING; THRUST,KING PIN NTN	1-09829-027-1	02	1	9002-9203	●	●
25	BEARING; THRUST,KING PIN NSK	1-09829-043-2	02	1	9204-	●	●
30	WASHER; THRUST,KING PIN T=4.875 -4.900	1-43171-185-0	AR	1	9002-	●	●
30	WASHER; THRUST,KING PIN T=4.900 -4.925	1-43171-186-0	AR	1	9002-	●	●
30	WASHER; THRUST,KING PIN T=4.925 -4.950	1-43171-187-0	AR	1	9002-	●	●
30	WASHER; THRUST,KING PIN T=4.950 -4.975	1-43171-188-0	AR	1	9002-	●	●
30	WASHER; THRUST,KING PIN T=4.975 -5.000	1-43171-189-0	AR	1	9002-	●	●
30	WASHER; THRUST,KING PIN T=5.000 -5.025	1-43171-190-0	AR	1	9002-	●	●
30	WASHER; THRUST,KING PIN T=5.025 -5.050	1-43171-191-0	AR	1	9002-	●	●
30	WASHER; THRUST,KING PIN T=5.050 -5.075	1-43171-192-0	AR	1	9002-	●	●
30	WASHER; THRUST,KING PIN T=5.075 -5.100	1-43171-193-0	AR	1	9002-	●	●
30	WASHER; THRUST,KING PIN T=5.100 -5.125	1-43171-194-0	AR	1	9002-	●	●
30	WASHER; THRUST,KING PIN T=5.125 -5.150	1-43171-195-0	AR	1	9002-	●	●
30	WASHER; THRUST,KING PIN T=5.150 -5.175	1-43171-196-0	AR	1	9002-	●	●
30	WASHER; THRUST,KING PIN T=5.175 -5.200	1-43171-197-0	AR	1	9002-	●	●
30	WASHER; THRUST,KING PIN T=5.200 -5.225	1-43171-198-0	AR	1	9002-	●	●
30	WASHER; THRUST,KING PIN T=5.225 -5.250	1-43171-199-0	AR	1	9002-	●	●
32	BOLT; KEY,KING PIN	1-43116-002-1	02	1	9002-	●	●
33	NUT; KEY BOLT M10	9-09110-410-0	02	1	9002-	●	●
34	WASHER; LK,KEY BOLT ID=10.2	9-09150-510-0	02	1	9002-	●	●
36	ARM; KNUCKLE	1-43133-050-1	01	1	9002-9306	●	●
36	ARM; KNUCKLE	1-43133-057-1	01	1	9307-9404	●	●
36	ARM; KNUCKLE	1-43133-063-1	01	1	9405-	●	●
37	BOLT; KNUCKLE ARM (B) M22X167	1-09000-153-0	01	1	9002-9111	●	●
37	BOLT; KNUCKLE ARM (A) M22X179	1-09000-578-1	01	1	9112-	●	●
37	BOLT; KNUCKLE ARM (A) M22X179	9-09806-848-1	01	1	9002-9111	●	●
37	BOLT; KNUCKLE ARM (B) M22X167	9-09806-847-3	01	1	9112-	●	●
40	NUT; KNUCKLE ARM M22	9-09844-670-1	02	1	9002-	●	●
42	JOINT; BALL,KNUCKLE ARM	1-44361-100-0	01	1	9002-9306	●	●
43	NUT; JOINT BALL,KNUCKLE ARM M24 SLOTTED	1-09442-020-0	01	1	9002-9306	●	●
50	BRACKET; POWER CHAMBER	1-43145-010-2	01	1	9002-	●	●
50	BRACKET; POWER CHAMBER	1-43145-009-2	01	1	9002-	●	●
51	BOLT; POWER CHAMBER BRKT M12X60	9-91056-260-0	02	1	9002-9005	●	●
51	BOLT; POWER CHAMBER BRKT M12X60	0-10806-260-0	02	1	9006-	●	●
51	BOLT; POWER CHAMBER BRKT M12X28	9-92051-228-0	06	1	9002-9005	●	●
51	BOLT; POWER CHAMBER BRKT M12X28	0-20801-228-0	06	1	9006-	●	●
52	WASHER; LK,POWER CHAMBER BRKT ID=12.2	9-09150-512-0	08	1	9002-	●	●
58	ARM; TIE ROD WHEEL BASE 4500MM(45W)	1-43135-021-1	01	1	9002-9404	●	●
58	ARM; TIE ROD WHEEL BASE 4500MM(45W)	1-43135-044-0	01	1	9405-	●	●
58	ARM; TIE ROD WHEEL BASE 4500MM(45W)	1-43134-021-1	01	1	9002-9404	●	●
58	ARM; TIE ROD WHEEL BASE 4500MM(45W)	1-43134-044-0	01	1	9405-	●	●
58	ARM; TIE ROD WHEEL BASE 5000MM(50W),WHEEL BASE 5300MM(53W), WHEEL BASE 5500MM(55W),WHEEL BASE 5800MM(58W),WHEEL BASE 6400MM(64W)	1-43135-036-0	01	1	9002-9404	●	●
58	ARM; TIE ROD WHEEL BASE 5000MM(50W),WHEEL BASE 5300MM(53W), WHEEL BASE 5500MM(55W),WHEEL BASE 5800MM(58W),WHEEL BASE 6400MM(64W)	1-43135-043-0	01	1	9405-	●	●
58	ARM; TIE ROD WHEEL BASE 5000MM(50W),WHEEL BASE 5300MM(53W), WHEEL BASE 5500MM(55W),WHEEL BASE 5800MM(58W),WHEEL BASE 6400MM(64W)	1-43134-036-0	01	1	9002-9404	●	●
58	ARM; TIE ROD WHEEL BASE 5000MM(50W),WHEEL BASE 5300MM(53W), WHEEL BASE 5500MM(55W),WHEEL BASE 5800MM(58W),WHEEL BASE 6400MM(64W)	1-43134-043-0	01	1	9405-	●	●
59	NUT; TIE ROD ARM M22	9-09844-670-1	04	1	9002-	●	●
60	BOLT; TIE ROD ARM M22X193	1-09000-154-2	04	1	9002-	●	●
61	ROD END; TIE ROD	1-43150-631-2	01	1	9307-	●	●
61	ROD END; TIE ROD	1-43150-630-2	01	1	9307-	●	●
61	ROD END; TIE ROD L TYPE ENG<90L>	1-43150-436-1	01	1	9002-9306	●	●
61	ROD END; TIE ROD L TYPE ENG<90L>	1-43150-435-1	01	1	9002-9306	●	●
61	ROD END; TIE ROD V TYPE ENG<91L>	1-43150-440-1	01	1	9002-9306	●	●
61	ROD END; TIE ROD V TYPE ENG<91L>	1-43150-439-1	01	1	9002-9306	●	●
66	NUT; TIE ROD END M24	9-09844-669-2	02	1	9002-9306	●	●
66	NUT; TIE ROD END M24 SLOTTED	1-09442-020-0	02	1	9307-	●	●
67	WASHER; LK,TIE ROD END ID=12.2	9-09150-512-0	04	1	9002-9207	●	●
67	WASHER; LK,TIE ROD END ID=12.2	9-09150-812-0	04	1	9208-9410	●	●
68	BOLT; TIE ROD END M12X55	9-91061-255-0	04	1	9002-	●	●
71	BOOT; TIE ROD END ID=31 & 49	1-43159-038-0	02	1	9002-9306	●	●
72	SEAT; BALL,TIE ROD JOINT	1-44371-012-1	04	1	9002-9306	●	●
73	NIPPLE; GREASE,TIE ROD END PT1/8 STRAIGHT	9-09031-010-0	02	1	9002-9306	●	●
74	NUT; TIE ROD END M12	9-99110-412-0	04	1	9002-9207	●	●
74	NUT; TIE ROD END M12	9-99110-512-0	04	1	9208-	●	●
75	JOINT; BALL,DRAG LINK	9-44361-169-3	02	1	9002-9306	●	●
77	SPRING; TIE ROD END	9-09941-272-0	02	1	9002-9306	●	●
78	PLUG; ADJ,ROD END	1-44375-014-0	02	1	9002-9306	●	●
79	RING; SNAP,ADJ PLUG	1-09589-006-0	02	1	9002-9306	●	●
81	ROD; TIE L TYPE ENG<90L> WHEEL BASE 4500MM(45W) L=1600	9-43151-118-1	01	1	9002-9306	●
81	ROD; TIE V TYPE ENG<91L> WHEEL BASE 4500MM(45W) L=1605	1-43151-027-0	01	1	9002-9306	●
81	ROD; TIE WHEEL BASE 4500MM(45W) L=1605	1-43151-027-0	01	1	9307-9407	●
81	ROD; TIE WHEEL BASE 4500MM(45W) L=1600	1-43151-012-0	01	1	9408-	●	●
81	ROD; TIE L TYPE ENG<90L> WHEEL BASE 5000MM(50W),WHEEL BASE 5500MM(55W), WHEEL BASE 5800MM(58W),WHEEL BASE 6400MM(64W) L=1648	9-43151-121-1	01	1	9002-9306	●	●
81	ROD; TIE V TYPE ENG<91L> WHEEL BASE 5000MM(50W),WHEEL BASE 5800MM(58W) L=1650	1-43151-026-0	01	1	9002-9306	●	●
81	ROD; TIE WHEEL BASE 5000MM(50W),WHEEL BASE 5300MM(53W), WHEEL BASE 5500MM(55W),WHEEL BASE 5800MM(58W),WHEEL BASE 6400MM(64W) L=1650	1-43151-066-0	01	1	9307-	●	●
103	NUT; BRKT FIX EXC. CAB SUSPENSION RIGID(W71) M14	9-99110-514-0	02	1	9002-	●	●
103	NUT; BRKT FIX EXC. CAB UP 110MM(W60),CAB SUSPENSION RIGID(W71) M10	9-09110-510-0	02	1	9002-	●	●
104	WASHER; LK,BRKT EXC. CAB SUSPENSION RIGID(W71) ID=14.2	9-09150-614-0	02	1	9002-	●	●
105	BOLT; BRKT FIX EXC. CAB UP 110MM(W60),CAB SUSPENSION RIGID(W71) M10X25	9-01911-025-0	02	1	9002-9002	●	●
105	BOLT; BRKT FIX EXC. CAB UP 110MM(W60),CAB SUSPENSION RIGID(W71) M10X25 W/LK WASHER	0-50041-025-0	02	1	9003-	●	●
106	BOLT; CAP FIX EXC. CAB SUSPENSION RIGID(W71) M8X25 W/LK WASHER	9-01910-825-0	02	1	9002-9005	●	●
106	BOLT; CAP FIX EXC. CAB SUSPENSION RIGID(W71) M8X25 W/LK WASHER	0-50040-825-0	02	1	9006-9302	●	●
106	BOLT; CAP FIX EXC. CAB SUSPENSION RIGID(W71) M8X25 FLANGE	0-28080-825-0	02	1	9303-	●	●
107	BUSHING; STABILIZER BAR EXC. CAB SUSPENSION RIGID(W71)	1-53459-860-0	02	1	9002-	●	●
108	CAP EXC. CAB SUSPENSION RIGID(W71)	1-53459-392-1	02	1	9002-	●	●
109	BUFFER; STAB BAR CAB UP 110MM(W60)	1-53459-535-1	01	1	9002-	●	●
109	BUFFER; STAB BAR CAB UP 110MM(W60)	1-53459-536-1	01	1	9002-	●	●
109	BUFFER; STAB BAR EXC. CAB UP 110MM(W60),CAB SUSPENSION RIGID(W71)	1-53459-532-0	01	1	9002-	●	●
109	BUFFER; STAB BAR EXC. CAB UP 110MM(W60),CAB SUSPENSION RIGID(W71)	1-53459-533-0	01	1	9002-	●	●
255	PIN; SPLIT,JOINT BALL OD=4.6 L=35	9-08115-035-0	01	1	9002-9306	●	●

İpucu: çizimdeki balona veya tablodaki Balon sütununa tıkla; ilgili parçalar vurgulanır. Birden çok çizim varsa üstteki seçim kutusu/oklarla gezin.
