Isuzu WW
▶
TRUCKS
▶
CYH
▶
11035 - CYH RHD EURO4
▶
7 - Interior Trim, Emblems / Labels, Seats, Mirrors
▶
7-10 - CAUTION PLATE AND LABEL
▶
7-10 — CAUTION PLATE AND LABEL
(#26991) — 56 parça
◀
[710A] NO.5 (4 parça)
[710A] NO.3 (9 parça)
[710A] NO.1 (19 parça)
[710A] NO.4 (7 parça)
[710A] NO.2 (17 parça)
▶
181
175
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
175
LABEL; STRG,AIR BAG
CAUTIONS ENGLISH<RR8> AIR BAG(TFQ)
1-85878-116-0
02
1
0705-
175
LABEL; STRG,AIR BAG
AIR BAG(TFQ)
1-85878-107-0
02
1
0610-0704
175
LABEL; STRG,AIR BAG
CAUTIONS CHINESE<SL7> AIR BAG(TFQ)
1-85878-107-0
02
1
0705-
181
PLATE; CAUTION,AIR CLEANER
1-85886-796-1
01
1
0610-
60
156
6
6
263
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
6
PLATE; CAUTION,SPARE TIRE
SPARE WHEEL CARRIER FRAME REAR<P10> CAUTIONS ENGLISH<RR8> (A)
1-53639-004-0
01
1
0610-0703
6
PLATE; CAUTION,SPARE TIRE
SPARE WHEEL CARRIER FRAME REAR<P10>,SPARE WHEEL CARRIER FRAME SIDE<P13> CAUTIONS ENGLISH<RR8> (A)
1-53639-004-0
01
1
0704-0708
6
PLATE; CAUTION,SPARE TIRE
SPARE WHEEL CARRIER FRAME REAR<P10>,SPARE WHEEL CARRIER FRAME SIDE<P13> CAUTIONS ENGLISH<RR8> (B)
8-98082-437-0
01
1
0709-
6
PLATE; CAUTION,SPARE TIRE
SPARE WHEEL CARRIER FRAME REAR<P10>,SPARE WHEEL CARRIER FRAME SIDE<P13> CAUTIONS CHINESE<SL7> (A)
1-85883-113-0
01
1
0610-0708
6
PLATE; CAUTION,SPARE TIRE
SPARE WHEEL CARRIER FRAME REAR<P10>,SPARE WHEEL CARRIER FRAME SIDE<P13> CAUTIONS CHINESE<SL7> (B)
8-98082-438-0
01
1
0709-
60
PLATE; CAUTION,CAB TILT
CAUTIONS ENGLISH<RR8>
1-85883-234-0
01
1
0610-
60
PLATE; CAUTION,CAB TILT
CAUTIONS CHINESE<SL7>
1-85883-242-0
01
1
0610-
156
PLATE; CAUTION,A/C
AIR CONDITIONER MANUAL CONTROL(C60) CAUTIONS CHINESE<SL7>
8-98055-383-0
01
1
0610-
263
PLATE; CAUTION,JACK
TOOL B KIT<SL1> CAUTIONS CHINESE<SL7>
1-85881-878-0
01
1
0610-
1
1
252
51
74
70
5
5
289
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
1
PLATE; CAUTION,SHIFT PATTERN
SMOOTHER-G(C1W) (B)
1-85881-842-0
01
1
0610-
1
PLATE; CAUTION,SHIFT PATTERN
SMOOTHER-G(C1W) (A)
1-85881-879-1
01
1
0610-
5
LABEL; TIRE AIR PRESSURE
TIRE 11.00R-22.5-16 RIB(55N) PROVISIONAL PACKAGE SPEC<BCC> CAUTIONS CHINESE<SL7> (A)
1-85881-976-0
01
1
0706-
5
LABEL; TIRE AIR PRESSURE
TIRE 12R22.5-152/148K RIB LUG(5A7),TIRE 12R22.5-16 RIB(75N) CAUTIONS CHINESE<SL7> (A)
1-85881-947-0
01
1
0610-
5
LABEL; TIRE AIR PRESSURE
TIRE 295/80R22.5-152/148K RIB LUG CHINA(5D9),TIRE 295/80R22.5-152/148J RIB CHINA(5E0) CAUTIONS CHINESE<SL7> (A)
1-85881-887-0
01
1
0610-
5
LABEL; TIRE AIR PRESSURE
EXC. CAUTIONS CHINESE<SL7> (B)
1-85880-778-0
01
1
0610-
51
PLATE; CAUTION,WARNING
1 CREWS SEAT ASM PASSENGER DELETE(AP5) CAUTIONS CHINESE<SL7> (C)
8-97623-390-0
01
1
0706-
51
PLATE; CAUTION,WARNING
CAUTIONS ENGLISH<RR8> (B)
1-85878-544-0
01
1
0610-
51
PLATE; CAUTION,WARNING
CAUTIONS CHINESE<SL7> (C)
8-97616-500-0
01
1
0610-0705
51
PLATE; CAUTION,WARNING
CAUTIONS CHINESE<SL7> EXC. 1 CREWS SEAT ASM PASSENGER DELETE(AP5) (C)
8-97616-500-0
01
1
0706-
51
PLATE; CAUTION,WARNING
CATALYSIS CONTROL<6MZ> (D)
1-85878-571-0
01
1
0610-
51
PLATE; CAUTION,WARNING
(A)
1-85880-777-0
01
1
0610-
70
PLATE; CAUTION,ACT
MJX12P M/T SMOOTHER-G(Y4S) SMOOTHER-G(C1W) CAUTIONS ENGLISH<RR8>
1-85878-484-0
01
1
0610-
70
PLATE; CAUTION,ACT
MJX12P M/T SMOOTHER-G(Y4S) SMOOTHER-G(C1W) CAUTIONS CHINESE<SL7>
1-85878-547-0
01
1
0610-
74
PLATE; CAUTION,CHANGE LEV
MJX12P M/T SMOOTHER-G(Y4S) SMOOTHER-G(C1W) CAUTIONS ENGLISH<RR8>
1-85881-869-0
01
1
0610-
74
PLATE; CAUTION,CHANGE LEV
MJX12P M/T SMOOTHER-G(Y4S) SMOOTHER-G(C1W) CAUTIONS CHINESE<SL7>
1-85881-928-0
01
1
0610-
252
PLATE; CAUTION,HARNESS
CAUTIONS ENGLISH<RR8>
1-85878-488-1
01
1
0610-
252
PLATE; CAUTION,HARNESS
CAUTIONS CHINESE<SL7>
1-85878-515-0
01
1
0610-
289
PLATE; CAUTION,DRIVING
HONG KONG EQUIPMENT(PQ1) CAUTIONS CHINESE<SL7>
1-85883-223-1
01
1
0610-
4
4
180
180
180
180
180
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
4
LABEL; ENG MAINTENANCE
(A)
1-85875-350-2
01
1
0610-
4
LABEL; ENG MAINTENANCE
(B)
8-94391-524-0
01
1
0610-
180
PLATE; CAUTION,SWITCH
MJX12P M/T SMOOTHER-G(Y4S) (A) SPL N
1-85881-871-0
01
1
0610-
180
PLATE; CAUTION,SWITCH
MJX12P M/T SMOOTHER-G(Y4S) (B) SPL H
1-85881-872-0
01
1
0610-
180
PLATE; CAUTION,SWITCH
MJX12P M/T SMOOTHER-G(Y4S) (C) SPL L
1-85881-873-0
01
1
0610-
180
PLATE; CAUTION,SWITCH
MJX12P M/T SMOOTHER-G(Y4S) (D) RANGE H
1-85881-880-0
01
1
0610-
180
PLATE; CAUTION,SWITCH
MJX12P M/T SMOOTHER-G(Y4S) (E) RANGE L
1-85881-881-0
01
1
0610-
176
163
51
51
51
119
49
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
49
PLATE; CAUTION,FUSE BOX
CAUTIONS ENGLISH<RR8>
1-85878-549-0
01
1
0610-0610
49
PLATE; CAUTION,FUSE BOX
CAUTIONS ENGLISH<RR8>
8-97619-856-0
01
1
0611-
49
PLATE; CAUTION,FUSE BOX
CAUTIONS CHINESE<SL7>
1-85878-566-0
01
1
0610-0610
49
PLATE; CAUTION,FUSE BOX
CAUTIONS CHINESE<SL7>
8-97619-854-0
01
1
0611-
51
PLATE; CAUTION,WARNING
1 CREWS SEAT ASM PASSENGER DELETE(AP5) CAUTIONS CHINESE<SL7> (C)
8-97623-390-0
01
1
0706-
51
PLATE; CAUTION,WARNING
CAUTIONS ENGLISH<RR8> (B)
1-85878-544-0
01
1
0610-
51
PLATE; CAUTION,WARNING
CAUTIONS CHINESE<SL7> (C)
8-97616-500-0
01
1
0610-0705
51
PLATE; CAUTION,WARNING
CAUTIONS CHINESE<SL7> EXC. 1 CREWS SEAT ASM PASSENGER DELETE(AP5) (C)
8-97616-500-0
01
1
0706-
51
PLATE; CAUTION,WARNING
CATALYSIS CONTROL<6MZ> (D)
1-85878-571-0
01
1
0610-
51
PLATE; CAUTION,WARNING
(A)
1-85880-777-0
01
1
0610-
119
PLATE; CAUTION,HAND BRK LEVER
1-85881-759-0
01
1
0610-
163
PLATE; NAME,AIR BAG
CAUTIONS ENGLISH<RR8> AIR BAG(TFQ)
1-85878-485-0
01
1
0705-
163
PLATE; NAME,AIR BAG
AIR BAG(TFQ)
1-85878-109-0
01
1
0610-0704
163
PLATE; NAME,AIR BAG
CAUTIONS CHINESE<SL7> AIR BAG(TFQ)
1-85878-109-0
01
1
0705-
176
LABEL; SEAT BELT
CAUTIONS ENGLISH<RR8> SEAT BELT PRE TENSIONER 3POINT W/AIR BAG(7MC)
1-85878-486-0
01
1
0705-
176
LABEL; SEAT BELT
SEAT BELT PRE TENSIONER 3POINT W/AIR BAG(7MC)
1-85878-108-0
01
1
0610-0704
176
LABEL; SEAT BELT
CAUTIONS CHINESE<SL7> SEAT BELT PRE TENSIONER 3POINT W/AIR BAG(7MC)
1-85878-108-0
01
1
0705-
