2 |
WHEEL; DISC
DISC WHEEL 10STUD 8.25X22.5 165-13(QM8)
(B) FRONT,REAR
|
1-42350-730-0 |
06 |
1 |
0610-1205 |
| |
2 |
WHEEL; DISC
DISC WHEEL 10STUD 8.25X22.5 165-13(QM8)
(B) FRONT,REAR
|
8-98217-247-0 |
06 |
1 |
1206-1407 |
| |
2 |
WHEEL; DISC
DISC WHEEL 10STUD 8.25X22.5 165-13(QM8)
(B) FRONT,REAR
|
8-98281-497-0 |
06 |
1 |
1408- |
| |
2 |
WHEEL; DISC
DISC WHEEL 10STUD 8.25X22.5 165-13(QM8)
SPARE TIRE & DISC WHEEL FRONT TIRE ONE<WH2>
(B) SPARE
|
1-42350-730-0 |
01 |
1 |
0610-1205 |
| |
2 |
WHEEL; DISC
DISC WHEEL 10STUD 8.25X22.5 165-13(QM8)
SPARE TIRE & DISC WHEEL FRONT TIRE ONE<WH2>
(B) SPARE
|
8-98217-247-0 |
01 |
1 |
1206-1407 |
| |
2 |
WHEEL; DISC
DISC WHEEL 10STUD 8.25X22.5 165-13(QM8)
SPARE TIRE & DISC WHEEL FRONT TIRE ONE<WH2>
(B) SPARE
|
8-98281-497-0 |
01 |
1 |
1408- |
| |
2 |
WHEEL; DISC
WHEEL 8STUD 8.25X22.5 165-13TC(SKV)
(A) FRONT,REAR
|
1-42350-667-0 |
06 |
1 |
0610- |
| |
2 |
WHEEL; DISC
WHEEL 8STUD 8.25X22.5 165-13TC(SKV)
SPARE TIRE & DISC WHEEL FRONT TIRE ONE<WH2>
(A) SPARE
|
1-42350-667-0 |
01 |
1 |
0610- |
| |
3 |
NUT; WHEEL,FRT AXLE
INTERNATIONAL STANDARD ISO 10STUD<B3V>
M22X1.5
|
1-42333-050-1 |
20 |
1 |
0610-0907 |
| |
3 |
NUT; WHEEL,FRT AXLE
INTERNATIONAL STANDARD ISO 10STUD<B3V>
M22X1.5
|
1-42333-055-0 |
20 |
1 |
0908- |
| |
3 |
NUT; WHEEL,FRT AXLE
DISC WHEEL STEEL<SDN>
EXC. INTERNATIONAL STANDARD ISO 10STUD<B3V>
M24
|
1-42333-022-3 |
08 |
1 |
0610- |
| |
3 |
NUT; WHEEL,FRT AXLE
DISC WHEEL STEEL<SDN>
EXC. INTERNATIONAL STANDARD ISO 10STUD<B3V>
M24 LH THREAD
|
1-42334-022-3 |
08 |
1 |
0610- |
| |
4 |
NUT; WHEEL,RR AXLE
INTERNATIONAL STANDARD ISO 10STUD<B3V>
M22X1.5
|
1-42333-050-1 |
20 |
1 |
0610-0907 |
| |
4 |
NUT; WHEEL,RR AXLE
INTERNATIONAL STANDARD ISO 10STUD<B3V>
M22X1.5
|
1-42333-055-0 |
20 |
1 |
0908- |
| |
4 |
NUT; WHEEL,RR AXLE
EXC. INTERNATIONAL STANDARD ISO 10STUD<B3V>
M30
|
1-42333-023-0 |
08 |
1 |
0610-0610 |
| |
4 |
NUT; WHEEL,RR AXLE
EXC. INTERNATIONAL STANDARD ISO 10STUD<B3V>
M30 RH THREAD
|
8-97359-809-0 |
08 |
1 |
0611- |
| |
4 |
NUT; WHEEL,RR AXLE
EXC. INTERNATIONAL STANDARD ISO 10STUD<B3V>
M30 LH THREAD
|
1-42334-023-0 |
08 |
1 |
0610-0610 |
| |
4 |
NUT; WHEEL,RR AXLE
EXC. INTERNATIONAL STANDARD ISO 10STUD<B3V>
M30 LH THREAD
|
8-97359-810-0 |
08 |
1 |
0611- |
| |
5 |
NUT; WHEEL,INNER,RR AXLE
DISC WHEEL STEEL<SDN>
EXC. INTERNATIONAL STANDARD ISO 10STUD<B3V>
OUTER M30,INNER M20 RH THREAD
|
1-42335-005-1 |
08 |
1 |
0610-0610 |
| |
5 |
NUT; WHEEL,INNER,RR AXLE
DISC WHEEL STEEL<SDN>
EXC. INTERNATIONAL STANDARD ISO 10STUD<B3V>
OUTER M30,INNER M20 RH THREAD
|
8-97359-805-0 |
08 |
1 |
0611- |
| |
5 |
NUT; WHEEL,INNER,RR AXLE
DISC WHEEL STEEL<SDN>
EXC. INTERNATIONAL STANDARD ISO 10STUD<B3V>
OUTER M30,INNER M20 LH THREAD
|
1-42336-005-1 |
08 |
1 |
0610-0610 |
| |
5 |
NUT; WHEEL,INNER,RR AXLE
DISC WHEEL STEEL<SDN>
EXC. INTERNATIONAL STANDARD ISO 10STUD<B3V>
OUTER M30,INNER M20 LH THREAD
|
8-97359-806-0 |
08 |
1 |
0611- |
| |
8 |
VALVE; TIRE
DISC WHEEL 10STUD 8.25X22.5 165-13(QM8)
|
1-42370-048-0 |
06 |
1 |
1206-1407 |
| |
8 |
VALVE; TIRE
DISC WHEEL 10STUD 8.25X22.5 165-13(QM8)
|
1-42370-019-3 |
06 |
1 |
1408- |
| |
8 |
VALVE; TIRE
DISC WHEEL 10STUD 8.25X22.5 165-13(QM8)
SPARE TIRE & DISC WHEEL FRONT TIRE ONE<WH2>
|
1-42370-048-0 |
01 |
1 |
1206-1407 |
| |
8 |
VALVE; TIRE
DISC WHEEL 10STUD 8.25X22.5 165-13(QM8)
SPARE TIRE & DISC WHEEL FRONT TIRE ONE<WH2>
|
1-42370-019-3 |
01 |
1 |
1408- |
| |
8 |
VALVE; TIRE
|
1-42370-020-3 |
06 |
1 |
0610-1205 |
| |
8 |
VALVE; TIRE
WHEEL 8STUD 8.25X22.5 165-13TC(SKV)
|
1-42370-020-3 |
06 |
1 |
1206- |
| |
8 |
VALVE; TIRE
SPARE TIRE & DISC WHEEL FRONT TIRE ONE<WH2>
|
1-42370-020-3 |
01 |
1 |
0610-1205 |
| |
8 |
VALVE; TIRE
WHEEL 8STUD 8.25X22.5 165-13TC(SKV)
SPARE TIRE & DISC WHEEL FRONT TIRE ONE<WH2>
|
1-42370-020-3 |
01 |
1 |
1206- |
| |
16 |
HOLDER; TIRE VALVE,DISC WHEEL
DISC WHEEL 10STUD 8.25X22.5 165-13(QM8)
L=170
|
1-42370-024-0 |
02 |
1 |
0610-1003 |
| |
16 |
HOLDER; TIRE VALVE,DISC WHEEL
DISC WHEEL 10STUD 8.25X22.5 165-13(QM8)
L=170
|
8-98167-052-0 |
02 |
1 |
1004- |
| |
32 |
CAP; VALVE
DISC WHEEL 10STUD 8.25X22.5 165-13(QM8)
|
1-42374-001-0 |
06 |
1 |
0610- |
| |
32 |
CAP; VALVE
WHEEL 8STUD 8.25X22.5 165-13TC(SKV)
EXC. SPARE TIRE & DISC WHEEL FRONT TIRE ONE<WH2>
|
1-42374-001-0 |
06 |
1 |
0610- |
| |
32 |
CAP; VALVE
DISC WHEEL 10STUD 8.25X22.5 165-13(QM8)
SPARE TIRE & DISC WHEEL FRONT TIRE ONE<WH2>
|
1-42374-001-0 |
01 |
1 |
0610- |
| |
32 |
CAP; VALVE
WHEEL 8STUD 8.25X22.5 165-13TC(SKV)
SPARE TIRE & DISC WHEEL FRONT TIRE ONE<WH2>
|
1-42374-001-0 |
07 |
1 |
0610- |
