Isuzu WW
▶
TRUCKS
▶
EXR
▶
11037 - EXR RHD EURO4
▶
2 - Clutch, Transmission, Trans Axle
▶
2-25 - SPEEDOMETER DRIVEN GEAR
▶
2-25 — SPEEDOMETER DRIVEN GEAR
(#26725) — 10 parça
10
2
3
1
13
32
18
34
32
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
1
GEAR; DRIVEN,SPD
Z=15
1-33372-147-4
01
1
0610-
2
BUSHING; DRIVEN GEAR,SPEEDOMETER
1-33373-077-0
01
1
0610-
3
GASKET; BUSHING
ALSO INCLUDED IN GASKET SET(M/T).
1-09623-246-0
01
1
0610-
10
SEAL; OIL,DRIVE GEAR
ALSO INCLUDED IN GASKET SET(M/T). NOK
1-09625-510-0
01
1
0610-
13
SCREW; BUSHING,DRIVEN GEAR
M6X12.5 FLANGE
1-09044-063-0
01
1
0610-0805
13
SCREW; BUSHING,DRIVEN GEAR
M6X12.5 FLANGE
8-98014-141-0
01
1
0806-
18
BOLT; CLU HSG TO TRANS
M12X50 FLANGE
0-28151-250-0
17
1
0610-
32
BOLT; CLU HSG TO FLYWHEEL HSG
M12X60 FLANGE
0-28151-260-0
12
1
0610-1103
32
BOLT; CLU HSG TO FLYWHEEL HSG
M12X70 FLANGE
0-28151-270-0
12
1
1104-
34
STUD; CLU HSG
M10X28,M12X50 L=89.7
1-09049-037-0
02
1
0610-
