1 |
LINER KIT; CYL,AIR CMPR
|
1-19163-053-1 |
01 |
1 |
9601-9803 |
● |
|
|
|
| |
1 |
LINER KIT; CYL,AIR CMPR
|
1-19163-054-1 |
01 |
1 |
9601-0301 |
|
● |
|
|
| |
1 |
LINER KIT; CYL,AIR CMPR
|
1-19163-060-1 |
01 |
1 |
0302-0811 |
|
● |
|
|
| |
1 |
LINER KIT; CYL,AIR CMPR
|
1-19163-077-0 |
01 |
1 |
0812- |
|
● |
|
|
| |
1 |
LINER KIT; CYL,AIR CMPR
|
1-19163-052-1 |
01 |
1 |
9610-0106 |
|
|
● |
|
| |
1 |
LINER KIT; CYL,AIR CMPR
|
1-19163-052-1 |
01 |
1 |
0107-0812 |
|
|
|
● |
| |
1 |
LINER KIT; CYL,AIR CMPR
|
1-19163-075-0 |
01 |
1 |
0901- |
|
|
|
● |
| |
2 |
CRANKCASE; AIR CMPR
|
1-19151-266-1 |
01 |
1 |
9601-9803 |
● |
|
|
|
| |
2 |
CRANKCASE; AIR CMPR
|
1-19151-277-0 |
01 |
1 |
9601-9810 |
|
● |
|
|
| |
2 |
CRANKCASE; AIR CMPR
|
1-19151-288-0 |
01 |
1 |
9811- |
|
● |
|
|
| |
2 |
CRANKCASE; AIR CMPR
|
1-19151-274-0 |
01 |
1 |
9610-0106 |
|
|
● |
|
| |
2 |
CRANKCASE; AIR CMPR
|
1-19151-274-0 |
01 |
1 |
0107- |
|
|
|
● |
| |
3 |
BEARING; AIR CMPR
(B)
|
9-00006-206-0 |
01 |
1 |
9601-9609 |
● |
|
|
|
| |
3 |
BEARING; AIR CMPR
(B)
|
9-00006-206-0 |
01 |
1 |
9610-9803 |
● |
|
● |
|
| |
3 |
BEARING; AIR CMPR
(B)
|
9-00006-206-0 |
01 |
1 |
9804-0106 |
|
|
● |
|
| |
3 |
BEARING; AIR CMPR
(B)
|
9-00006-206-0 |
01 |
1 |
0107-1202 |
|
|
|
● |
| |
3 |
BEARING; AIR CMPR
(A)
|
9-00090-152-0 |
01 |
1 |
9601-9609 |
● |
|
|
|
| |
3 |
BEARING; AIR CMPR
(A)
|
9-00090-152-0 |
01 |
1 |
9610-9803 |
● |
|
● |
|
| |
3 |
BEARING; AIR CMPR
(A)
|
9-00090-152-0 |
01 |
1 |
9804-0106 |
|
|
● |
|
| |
3 |
BEARING; AIR CMPR
(A)
|
9-00090-152-0 |
01 |
1 |
0107- |
|
|
|
● |
| |
3 |
BEARING; AIR CMPR
(C)
|
1-09800-211-0 |
02 |
1 |
9601-9810 |
|
● |
|
|
| |
3 |
BEARING; AIR CMPR
(C)
|
1-09800-282-0 |
02 |
1 |
9811- |
|
● |
|
|
| |
3 |
BEARING; AIR CMPR
(D)
|
1-09800-232-0 |
01 |
1 |
9601- |
|
● |
|
|
| |
4 |
CRANKSHAFT; AIR CMPR
|
1-19171-048-1 |
01 |
1 |
9601-9803 |
● |
|
|
|
| |
4 |
CRANKSHAFT; AIR CMPR
|
1-19171-070-0 |
01 |
1 |
9601-9810 |
|
● |
|
|
| |
4 |
CRANKSHAFT; AIR CMPR
|
1-19171-081-1 |
01 |
1 |
9811- |
|
● |
|
|
| |
4 |
CRANKSHAFT; AIR CMPR
|
1-19171-028-0 |
01 |
1 |
9610-0106 |
|
|
● |
|
| |
4 |
CRANKSHAFT; AIR CMPR
|
1-19171-028-0 |
01 |
1 |
0107-1202 |
|
|
|
● |
| |
4 |
CRANKSHAFT; AIR CMPR
|
8-98209-089-0 |
01 |
1 |
1203- |
|
|
|
● |
| |
5 |
GASKET; AIR CMPR
|
1-09623-361-0 |
01 |
1 |
9601-9609 |
● |
|
|
|
| |
5 |
GASKET; AIR CMPR
|
1-09623-361-0 |
01 |
1 |
9610-9803 |
● |
|
● |
|
| |
5 |
GASKET; AIR CMPR
|
1-09623-361-0 |
01 |
1 |
9804-0106 |
|
|
● |
|
| |
5 |
GASKET; AIR CMPR
|
1-09623-361-0 |
01 |
1 |
0107-1107 |
|
|
|
● |
| |
5 |
GASKET; AIR CMPR
|
8-98192-460-0 |
01 |
1 |
1108- |
|
|
|
● |
| |
6 |
COVER ASM; BRG,AIR CMPR
|
1-19156-058-1 |
01 |
1 |
9601-9803 |
● |
|
|
|
| |
6 |
COVER ASM; BRG,AIR CMPR
|
1-19156-045-0 |
01 |
1 |
9601-9810 |
|
● |
|
|
| |
6 |
COVER ASM; BRG,AIR CMPR
|
1-19156-080-0 |
01 |
1 |
9811- |
|
● |
|
|
| |
6 |
COVER ASM; BRG,AIR CMPR
|
1-19156-039-0 |
01 |
1 |
9610-0106 |
|
|
● |
|
| |
6 |
COVER ASM; BRG,AIR CMPR
|
1-19156-039-0 |
01 |
1 |
0107-1202 |
|
|
|
● |
| |
6 |
COVER ASM; BRG,AIR CMPR
|
8-98209-092-0 |
01 |
1 |
1203- |
|
|
|
● |
| |
7 |
SEAL; OIL,BRG COVER,AIR CMPR
|
1-19158-026-0 |
01 |
1 |
9601-9803 |
● |
|
|
|
| |
7 |
SEAL; OIL,BRG COVER,AIR CMPR
|
1-09625-187-0 |
01 |
1 |
9601-9810 |
|
● |
|
|
| |
7 |
SEAL; OIL,BRG COVER,AIR CMPR
|
1-09625-534-0 |
01 |
1 |
9811- |
|
● |
|
|
| |
8 |
HEAD ASM; CYL,AIR CMPR
|
1-19110-052-1 |
01 |
1 |
9601-9803 |
● |
|
|
|
| |
8 |
HEAD ASM; CYL,AIR CMPR
|
1-19110-016-0 |
01 |
1 |
9601- |
|
● |
|
|
| |
8 |
HEAD ASM; CYL,AIR CMPR
|
1-19110-056-1 |
01 |
1 |
9610-0106 |
|
|
● |
|
| |
8 |
HEAD ASM; CYL,AIR CMPR
|
1-19110-056-1 |
01 |
1 |
0107- |
|
|
|
● |
| |
9 |
VALVE ASM; UNLOADER,AIR CMPR
|
1-19120-017-1 |
01 |
1 |
9601-9609 |
● |
|
|
|
| |
9 |
VALVE ASM; UNLOADER,AIR CMPR
|
1-19120-017-1 |
01 |
1 |
9610-9803 |
● |
|
● |
|
| |
9 |
VALVE ASM; UNLOADER,AIR CMPR
|
1-19120-017-1 |
01 |
1 |
9804-0106 |
|
|
● |
|
| |
9 |
VALVE ASM; UNLOADER,AIR CMPR
|
1-19120-017-1 |
01 |
1 |
0107- |
|
|
|
● |
| |
9 |
VALVE ASM; UNLOADER,AIR CMPR
|
1-19120-021-1 |
01 |
1 |
9601- |
|
● |
|
|
| |
12 |
GASKET; AIR CMPR
|
8-98185-684-0 |
01 |
1 |
1108- |
|
|
|
● |
| |
12 |
GASKET; AIR CMPR
|
1-09623-539-0 |
01 |
1 |
9601-9601 |
● |
|
|
|
| |
12 |
GASKET; AIR CMPR
|
1-09623-539-0 |
01 |
1 |
9602-9609 |
● |
● |
|
|
| |
12 |
GASKET; AIR CMPR
|
1-09623-539-0 |
01 |
1 |
9610-9803 |
● |
● |
● |
|
| |
12 |
GASKET; AIR CMPR
|
1-09623-539-0 |
01 |
1 |
9804-0106 |
|
● |
● |
|
| |
12 |
GASKET; AIR CMPR
|
1-09623-539-0 |
01 |
1 |
0107-1107 |
|
● |
|
● |
| |
12 |
GASKET; AIR CMPR
|
1-09623-539-0 |
01 |
1 |
1108- |
|
● |
|
|
| |
12 |
GASKET; AIR CMPR
|
1-19623-539-0 |
01 |
1 |
9601-9601 |
|
● |
|
|
| |
13 |
GASKET; AIR CMPR
(D)
|
1-19139-016-0 |
01 |
1 |
0107- |
|
|
|
● |
| |
13 |
GASKET; AIR CMPR
(B)
T=0.8
|
1-19139-004-0 |
01 |
1 |
9601-9609 |
● |
|
|
|
| |
13 |
GASKET; AIR CMPR
(A)
|
1-19139-002-0 |
01 |
1 |
9610-0106 |
|
|
● |
|
| |
13 |
GASKET; AIR CMPR
(B)
T=0.8
|
1-19139-004-0 |
01 |
1 |
9610-9803 |
● |
|
● |
|
| |
13 |
GASKET; AIR CMPR
(B)
T=0.8
|
1-19139-004-0 |
01 |
1 |
9804-0106 |
|
|
● |
|
| |
13 |
GASKET; AIR CMPR
(C)
|
1-19139-001-0 |
01 |
1 |
9601-0301 |
|
● |
|
|
| |
13 |
GASKET; AIR CMPR
(C)
|
1-19139-017-1 |
01 |
1 |
0302-0811 |
|
● |
|
|
| |
13 |
GASKET; AIR CMPR
(C)
|
8-98113-037-0 |
01 |
1 |
0812- |
|
● |
|
|
| |
15 |
CYLINDER; AIR CMPR
|
1-19151-219-0 |
01 |
1 |
9601-9803 |
● |
|
|
|
| |
15 |
CYLINDER; AIR CMPR
|
1-19151-251-0 |
01 |
1 |
9601- |
|
● |
|
|
| |
15 |
CYLINDER; AIR CMPR
|
1-19151-218-0 |
01 |
1 |
9610-0106 |
|
|
● |
|
| |
15 |
CYLINDER; AIR CMPR
|
1-19151-218-0 |
01 |
1 |
0107- |
|
|
|
● |
| |
20 |
RING KIT; PISTON,AIR CMPR
|
1-19163-058-0 |
01 |
1 |
0812-0812 |
|
● |
|
|
| |
20 |
RING KIT; PISTON,AIR CMPR
|
1-19163-058-0 |
01 |
1 |
0901- |
|
● |
|
● |
| |
20 |
RING KIT; PISTON,AIR CMPR
|
1-19163-051-0 |
01 |
1 |
9601-9609 |
● |
● |
|
|
| |
20 |
RING KIT; PISTON,AIR CMPR
|
1-19163-051-1 |
01 |
1 |
9610-9803 |
● |
● |
● |
|
| |
20 |
RING KIT; PISTON,AIR CMPR
|
1-19163-051-1 |
01 |
1 |
9804-0106 |
|
● |
● |
|
| |
20 |
RING KIT; PISTON,AIR CMPR
|
1-19163-051-1 |
01 |
1 |
0107-0811 |
|
● |
|
● |
| |
20 |
RING KIT; PISTON,AIR CMPR
|
1-19163-051-1 |
01 |
1 |
0812-0812 |
|
|
|
● |
| |
21 |
PISTON; AIR CMPR
|
1-19161-027-0 |
01 |
1 |
0812-0812 |
|
● |
|
|
| |
21 |
PISTON; AIR CMPR
|
1-19161-027-0 |
01 |
1 |
0901- |
|
● |
|
● |
| |
21 |
PISTON; AIR CMPR
|
1-19161-016-0 |
01 |
1 |
9601-9609 |
● |
● |
|
|
| |
21 |
PISTON; AIR CMPR
|
1-19161-016-0 |
01 |
1 |
9610-9803 |
● |
● |
● |
|
| |
21 |
PISTON; AIR CMPR
|
1-19161-016-0 |
01 |
1 |
9804-0106 |
|
● |
● |
|
| |
21 |
PISTON; AIR CMPR
|
1-19161-016-0 |
01 |
1 |
0107-0811 |
|
● |
|
● |
| |
21 |
PISTON; AIR CMPR
|
1-19161-016-0 |
01 |
1 |
0812-0812 |
|
|
|
● |
| |
23 |
RING; SNAP,PISTON,AIR CMPR
|
9-19168-003-0 |
02 |
1 |
9601-9803 |
● |
● |
|
|
| |
23 |
RING; SNAP,PISTON,AIR CMPR
|
9-19168-003-0 |
02 |
1 |
9804-0811 |
|
● |
|
|
| |
23 |
RING; SNAP,PISTON,AIR CMPR
|
1-19169-004-0 |
02 |
1 |
0812-0812 |
|
● |
|
|
| |
23 |
RING; SNAP,PISTON,AIR CMPR
|
1-19169-004-0 |
02 |
1 |
0901- |
|
● |
|
● |
| |
23 |
RING; SNAP,PISTON,AIR CMPR
|
9-19168-008-0 |
02 |
1 |
9610-0106 |
|
|
● |
|
| |
23 |
RING; SNAP,PISTON,AIR CMPR
|
9-19168-008-0 |
02 |
1 |
0107-0812 |
|
|
|
● |
| |
24 |
ROD ASM; CONN,AIR CMPR
|
1-19173-010-0 |
01 |
1 |
9601-9609 |
● |
|
|
|
| |
24 |
ROD ASM; CONN,AIR CMPR
|
1-19173-010-0 |
01 |
1 |
9610-9803 |
● |
|
● |
|
| |
24 |
ROD ASM; CONN,AIR CMPR
|
1-19173-010-0 |
01 |
1 |
9804-0106 |
|
|
● |
|
| |
24 |
ROD ASM; CONN,AIR CMPR
|
1-19173-010-0 |
01 |
1 |
0107-1202 |
|
|
|
● |
| |
24 |
ROD ASM; CONN,AIR CMPR
|
8-98209-093-0 |
01 |
1 |
1203- |
|
|
|
● |
| |
24 |
ROD ASM; CONN,AIR CMPR
|
1-19173-007-0 |
01 |
1 |
9601- |
|
● |
|
|
| |
25 |
PIN; PISTON,AIR CMPR
|
1-19167-003-0 |
01 |
1 |
0812-0812 |
|
● |
|
|
| |
25 |
PIN; PISTON,AIR CMPR
|
1-19167-003-0 |
01 |
1 |
0901- |
|
● |
|
● |
| |
25 |
PIN; PISTON,AIR CMPR
|
9-19167-003-0 |
01 |
1 |
9601-9609 |
● |
● |
|
|
| |
25 |
PIN; PISTON,AIR CMPR
|
9-19167-003-0 |
01 |
1 |
9610-9803 |
● |
● |
● |
|
| |
25 |
PIN; PISTON,AIR CMPR
|
9-19167-003-0 |
01 |
1 |
9804-0106 |
|
● |
● |
|
| |
25 |
PIN; PISTON,AIR CMPR
|
9-19167-003-0 |
01 |
1 |
0107-0811 |
|
● |
|
● |
| |
25 |
PIN; PISTON,AIR CMPR
|
9-19167-003-0 |
01 |
1 |
0812-0812 |
|
|
|
● |
| |
27 |
BOLT; HD
(B)
M10X45
|
9-01066-045-0 |
02 |
1 |
9601-9609 |
● |
|
|
|
| |
27 |
BOLT; HD
(B)
M10X45
|
9-01066-045-0 |
02 |
1 |
9610-9803 |
● |
|
● |
|
| |
27 |
BOLT; HD
(B)
M10X45
|
9-01066-045-0 |
02 |
1 |
9804-0106 |
|
|
● |
|
| |
27 |
BOLT; HD
(B)
M10X45
|
9-01066-045-0 |
02 |
1 |
0107- |
|
|
|
● |
| |
27 |
BOLT; HD
(A)
M10X60
|
9-01066-060-0 |
02 |
1 |
9601-9609 |
● |
|
|
|
| |
27 |
BOLT; HD
(A)
M10X60
|
9-01066-060-0 |
02 |
1 |
9610-9803 |
● |
|
● |
|
| |
27 |
BOLT; HD
(A)
M10X60
|
9-01066-060-0 |
02 |
1 |
9804-0106 |
|
|
● |
|
| |
27 |
BOLT; HD
(A)
M10X60
|
9-01066-060-0 |
02 |
1 |
0107- |
|
|
|
● |
| |
27 |
BOLT; HD
(A)
M10X60
|
9-01066-060-0 |
04 |
1 |
9601- |
|
● |
|
|
| |
30 |
BOLT; CYL TO CRANKCASE
M10X25
|
9-02051-025-0 |
04 |
1 |
9601-9609 |
● |
● |
|
|
| |
30 |
BOLT; CYL TO CRANKCASE
M10X25
|
9-02051-025-0 |
04 |
1 |
9610-9803 |
● |
● |
● |
|
| |
30 |
BOLT; CYL TO CRANKCASE
M10X25
|
9-02051-025-0 |
04 |
1 |
9804-0106 |
|
● |
● |
|
| |
30 |
BOLT; CYL TO CRANKCASE
M10X25
|
9-02051-025-0 |
04 |
1 |
0107- |
|
● |
|
● |
| |
38 |
BOLT; COVER FIX
|
9-81385-023-0 |
04 |
1 |
9601-9803 |
● |
|
|
|
| |
38 |
BOLT; COVER FIX
M6X16
|
9-02050-616-0 |
06 |
1 |
9601- |
|
● |
|
|
| |
38 |
BOLT; COVER FIX
|
1-19179-011-0 |
04 |
1 |
9610-0106 |
|
|
● |
|
| |
38 |
BOLT; COVER FIX
|
1-19179-011-0 |
04 |
1 |
0107- |
|
|
|
● |
| |
39 |
WASHER; LK,COVER FIX
ID=8.2
|
9-09150-608-0 |
04 |
1 |
9601-9609 |
● |
|
|
|
| |
39 |
WASHER; LK,COVER FIX
ID=8.2
|
9-09150-608-0 |
04 |
1 |
9610-9803 |
● |
|
● |
|
| |
39 |
WASHER; LK,COVER FIX
ID=8.2
|
9-09150-608-0 |
04 |
1 |
9804-0106 |
|
|
● |
|
| |
39 |
WASHER; LK,COVER FIX
ID=8.2
|
9-09150-608-0 |
04 |
1 |
0107- |
|
|
|
● |
| |
39 |
WASHER; LK,COVER FIX
ID=6.1
|
9-09150-506-0 |
06 |
1 |
9601-9810 |
|
● |
|
|
| |
39 |
WASHER; LK,COVER FIX
ID=10.2
|
9-09150-510-0 |
06 |
1 |
9811- |
|
● |
|
|
| |
43 |
WASHER; LK,CYL TO CRANKCASE,AIR CMPR
ID=10.2
|
9-09150-610-0 |
04 |
1 |
9601-9609 |
● |
● |
|
|
| |
43 |
WASHER; LK,CYL TO CRANKCASE,AIR CMPR
ID=10.2
|
9-09150-610-0 |
04 |
1 |
9610-9803 |
● |
● |
● |
|
| |
43 |
WASHER; LK,CYL TO CRANKCASE,AIR CMPR
ID=10.2
|
9-09150-610-0 |
04 |
1 |
9804-0106 |
|
● |
● |
|
| |
43 |
WASHER; LK,CYL TO CRANKCASE,AIR CMPR
ID=10.2
|
9-09150-610-0 |
04 |
1 |
0107- |
|
● |
|
● |
| |
45 |
WASHER; PL,COVER FIX,AIR CMPR
ID=8.4
|
9-09160-508-0 |
04 |
1 |
9601-9803 |
● |
|
|
|
| |
45 |
WASHER; PL,COVER FIX,AIR CMPR
|
1-19159-005-0 |
06 |
1 |
9601- |
|
● |
|
|
| |
48 |
SLEEVE; CR/SHF
|
1-19179-014-0 |
01 |
1 |
9601-9803 |
● |
|
|
|
| |
48 |
SLEEVE; CR/SHF
|
1-19179-018-0 |
01 |
1 |
9811- |
|
● |
|
|
