Isuzu WW
▶
TRUCKS
▶
GXZ
▶
10945 - GXZ(THAI)EURO2
▶
7 - Interior Trim, Emblems / Labels, Seats, Mirrors
▶
7-10 - CAUTION PLATE AND LABEL
▶
7-10 — CAUTION PLATE AND LABEL
(#26085) — 15 parça
◀
[710A] CAB SIDE (11 parça)
[710A] ENGINE AND FRAME SIDE (4 parça)
▶
49
225
51
51
1
112
160
60
39
225
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
1
PLATE; CAUTION,SHIFT PATTERN
THA
8-97918-792-0
01
1
0407-
39
PLATE; CAUTION,ENG STOP
6SD1 TCS ENG<83L> THA
8-97922-505-0
01
1
0407-
49
PLATE; CAUTION,FUSE BOX
ELECTRONIC GOV RED4<Q4F> THA
8-97922-160-2
01
1
0407-
49
PLATE; CAUTION,FUSE BOX
EXC. ELECTRONIC GOV RED4<Q4F> THA
8-97922-094-3
01
1
0407-
51
PLATE; CAUTION,WARNING
(A) THA
8-97910-543-0
01
1
0407-
51
PLATE; CAUTION,WARNING
(B) THA
8-97917-701-0
01
1
0407-
60
PLATE; CAUTION,CAB TILT
THA
8-97918-787-0
01
1
0407-
112
PLATE; CAUTION,T/M
THA
8-97918-790-0
01
1
0407-
160
PLATE; CAUTION,TOWING
THA
8-97918-791-1
01
1
0407-
225
PLATE; CAUTION,RELAY POSITION
(A) THA
8-97922-504-1
01
1
0407-
225
PLATE; CAUTION,RELAY POSITION
(B) THA
8-97922-506-0
01
1
0407-
4
6
228
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
4
LABEL; ENG MAINTENANCE
6SD1 TCN ENG<31L>
1-85886-841-0
01
1
0407-
4
LABEL; ENG MAINTENANCE
6SD1 TCS ENG<83L>
1-85889-082-0
01
1
0407-
6
PLATE; CAUTION,SPARE TIRE
SPARE WHEEL CARRIER FRAME SIDE<P13> THA
8-97918-788-0
01
1
0407-
228
PLATE; CAUTION,AIR DRYER
THA
8-97922-507-0
01
1
0407-0412
