5 |
ROD; LINK,3RD SHIFT
L=1120
|
1-33652-603-0 |
01 |
1 |
0302- |
| |
6 |
ROD; LINK,3RD SELECT
L=1638
|
1-33652-997-1 |
01 |
1 |
0302- |
| |
8 |
ROD; LINK,4TH SHIFT
L=480
|
1-33652-730-0 |
01 |
1 |
0302- |
| |
15 |
ROD; LINK 1ST SHIFT
(B)
L=485
|
1-33652-713-1 |
01 |
1 |
0302- |
| |
15 |
ROD; LINK 1ST SHIFT
(A)
L=345
|
1-33652-736-0 |
01 |
1 |
0302- |
| |
15 |
ROD; LINK 1ST SHIFT
(D)
L=88
|
1-33652-740-0 |
01 |
1 |
0302- |
| |
15 |
ROD; LINK 1ST SHIFT
(C)
L=464
|
1-33652-885-2 |
01 |
1 |
0302- |
| |
22 |
JOINT; BALL,SCREW,LINK ROD
(B)
|
1-09760-109-0 |
02 |
1 |
0302- |
| |
22 |
JOINT; BALL,SCREW,LINK ROD
(A)
|
1-09760-125-0 |
01 |
1 |
0302- |
| |
24 |
NUT; 2ND LINK ROD,SHIFT
M10 FLANGE
|
1-09440-061-0 |
02 |
1 |
0302- |
| |
25 |
NUT; LK,RIGHT SCREW,LINK ROD
(B)
M10
|
9-09111-510-0 |
02 |
1 |
0302- |
| |
25 |
NUT; LK,RIGHT SCREW,LINK ROD
(C)
M10 LH THREAD
|
9-09840-167-0 |
01 |
1 |
0302- |
| |
25 |
NUT; LK,RIGHT SCREW,LINK ROD
(A)
M12
|
9-99111-412-0 |
02 |
1 |
0302- |
| |
28 |
NUT; 2ND LINK ROD
M8 FLANGE
|
1-09440-062-1 |
02 |
1 |
0302- |
| |
30 |
JOINT; BALL,RIGHT SCREW,LINK ROD
|
1-09760-124-0 |
02 |
1 |
0302- |
| |
32 |
NUT; 3RD LINK ROD
M10 FLANGE
|
1-09440-061-0 |
02 |
1 |
0302- |
| |
35 |
NUT; LK,RIGHT SCREW,LINK ROD
M10
|
9-09111-410-0 |
02 |
1 |
0302- |
| |
36 |
JOINT; BALL,RIGHT SCREW,LINK ROD
|
1-09760-124-0 |
02 |
1 |
0302- |
| |
38 |
NUT; 3RD LINK ROD
M10 FLANGE
|
1-09440-061-0 |
02 |
1 |
0302- |
| |
44 |
NUT; LK,RIGHT SCREW,LINK ROD
M10
|
9-09111-410-0 |
02 |
1 |
0302- |
| |
45 |
JOINT; BALL,RIGHT SCREW,LINK ROD
|
1-09760-125-0 |
02 |
1 |
0302- |
| |
47 |
NUT; 4TH LINK ROD
M10 FLANGE
|
1-09440-061-0 |
02 |
1 |
0302- |
| |
49 |
NUT; LK,RIGHT SCREW,LINK ROD
M12
|
9-99111-412-0 |
02 |
1 |
0302- |
| |
112 |
JOINT; RUBBER
|
1-33670-413-1 |
02 |
1 |
0302- |
