2-37 — MANUAL TRANSMISSION CONT; MISSION SIDE (#25506) — 67 parça

45 49 30 35 47 32 5 49 45 30 8 47 44 36 6 38 38 44 36 32 35

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date	A	B
5	ROD; LINK,3RD SHIFT L=1120	1-33652-603-0	01	1	0308-	●	●
6	ROD; LINK,3RD SELECT L=1652	1-33652-935-1	01	1	0308-	●	●
8	ROD; LINK,4TH SHIFT L=370	1-33652-654-1	01	1	0308-	●	●
30	JOINT; BALL,RIGHT SCREW,LINK ROD	1-09760-124-0	02	1	0308-	●	●
32	NUT; 3RD LINK ROD M10 FLANGE	1-09440-061-0	02	1	0308-	●	●
35	NUT; LK,RIGHT SCREW,LINK ROD M10	9-09111-410-0	02	1	0308-0512	●	●
35	NUT; LK,RIGHT SCREW,LINK ROD M10	0-91111-510-0	02	1	0601-	●	●
36	JOINT; BALL,RIGHT SCREW,LINK ROD	1-09760-124-0	02	1	0308-	●	●
38	NUT; 3RD LINK ROD M10 FLANGE	1-09440-061-0	02	1	0308-	●	●
44	NUT; LK,RIGHT SCREW,LINK ROD M10	9-09111-410-0	02	1	0308-0512	●	●
44	NUT; LK,RIGHT SCREW,LINK ROD M10	0-91111-510-0	02	1	0601-	●	●
45	JOINT; BALL,RIGHT SCREW,LINK ROD	1-09760-125-0	02	1	0308-	●	●
47	NUT; 4TH LINK ROD M10 FLANGE	1-09440-061-0	02	1	0308-	●	●
49	NUT; LK,RIGHT SCREW,LINK ROD M12	9-99111-412-0	02	1	0308-0512	●	●
49	NUT; LK,RIGHT SCREW,LINK ROD M12	0-91111-512-0	02	1	0601-	●	●

112 112 24 24 15 15 25 25 22 25 25 22 24 24 22 25 15 25 28 22 28

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date	A	B
15	ROD; LINK 1ST SHIFT (B) L=88	1-33652-740-0	01	1	0308-	●	●
15	ROD; LINK 1ST SHIFT CAB UP +110MM<TGG> (D) L=474	1-33652-803-1	01	1	0308-	●	●
15	ROD; LINK 1ST SHIFT CAB UP +110MM<TGG> (E) L=446	1-33652-998-1	01	1	0308-	●	●
15	ROD; LINK 1ST SHIFT CAB UP +110MM<TGG> (A) L=355	1-33652-999-0	01	1	0308-	●	●
15	ROD; LINK 1ST SHIFT CAB UP +50MM<W60> (C) L=485	1-33652-713-1	01	1	0308-	●	●
15	ROD; LINK 1ST SHIFT CAB UP +50MM<W60> (A) L=345	1-33652-736-0	01	1	0308-	●	●
15	ROD; LINK 1ST SHIFT CAB UP +50MM<W60> (E) L=464	1-33652-885-2	01	1	0308-	●	●
22	JOINT; BALL,SCREW,LINK ROD (B)	1-09760-109-0	02	1	0308-	●	●
22	JOINT; BALL,SCREW,LINK ROD (A)	1-09760-125-0	01	1	0308-	●	●
24	NUT; 2ND LINK ROD,SHIFT M10 FLANGE	1-09440-061-0	01	1	0308-0312	●	●
24	NUT; 2ND LINK ROD,SHIFT M10 FLANGE	1-09440-061-0	01	1	0308-0312	●	●
24	NUT; 2ND LINK ROD,SHIFT M10 FLANGE	1-09440-061-0	02	1	0401-	●	●
25	NUT; LK,RIGHT SCREW,LINK ROD (B) M10 LH THREAD	9-09840-167-0	01	1	0308-	●	●
25	NUT; LK,RIGHT SCREW,LINK ROD (B) M10 LH THREAD	9-09840-167-0	01	1	0308-	●	●
25	NUT; LK,RIGHT SCREW,LINK ROD (A) M12	9-99111-412-0	02	1	0308-0512	●	●
25	NUT; LK,RIGHT SCREW,LINK ROD (A) M12	0-91111-512-0	02	1	0601-	●	●
25	NUT; LK,RIGHT SCREW,LINK ROD CAB UP +110MM<TGG> (C) M10	9-09111-410-0	02	1	0308-0512	●	●
25	NUT; LK,RIGHT SCREW,LINK ROD (C) M10	0-91111-510-0	02	1	0601-	●	●
25	NUT; LK,RIGHT SCREW,LINK ROD CAB UP +50MM<W60> (C) M10	9-09111-510-0	02	1	0308-0512	●	●
28	NUT; 2ND LINK ROD M8 FLANGE	1-09440-062-1	01	1	0308-0312	●	●
28	NUT; 2ND LINK ROD M8 FLANGE	1-09440-062-1	01	1	0308-0312	●	●
28	NUT; 2ND LINK ROD M8 FLANGE	1-09440-062-1	02	1	0401-	●	●
112	JOINT; RUBBER	1-33670-413-1	01	1	0308-	●	●
112	JOINT; RUBBER CAB UP +110MM<TGG>,CAB UP +50MM<W60>	1-33670-413-1	01	1	0308-	●	●

10 16 14 21 25 25 1 15 14 112 21 12 18 16 1 15 12 18

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date	A	B
1	ROD; LINK,1ST SHIFT (A) L=421	1-33652-738-0	01	1	0308-	●	●
1	ROD; LINK,1ST SHIFT (B) L=88	1-33652-740-0	01	1	0308-	●	●
10	JOINT ASM; BALL,SELECT ROD	1-09760-124-0	01	1	0308-	●	●
12	NUT; 1ST LINK ROD,SHIFT M10 FLANGE	1-09440-061-0	02	1	0308-	●	●
14	NUT; LK,RIGHT SCREW,LINK ROD (A) M10	9-09111-410-0	01	1	0308-0512	●	●
14	NUT; LK,RIGHT SCREW,LINK ROD (A) M10	0-91111-510-0	01	1	0601-	●	●
14	NUT; LK,RIGHT SCREW,LINK ROD (B) M12	9-99111-412-0	01	1	0308-0512	●	●
14	NUT; LK,RIGHT SCREW,LINK ROD (B) M12	0-91111-512-0	01	1	0601-	●	●
15	ROD; LINK 1ST SHIFT (B) L=88	1-33652-740-0	01	1	0308-	●	●
15	ROD; LINK 1ST SHIFT CAB UP +110MM<TGG> (D) L=474	1-33652-803-1	01	1	0308-	●	●
15	ROD; LINK 1ST SHIFT CAB UP +110MM<TGG> (E) L=446	1-33652-998-1	01	1	0308-	●	●
15	ROD; LINK 1ST SHIFT CAB UP +110MM<TGG> (A) L=355	1-33652-999-0	01	1	0308-	●	●
15	ROD; LINK 1ST SHIFT CAB UP +50MM<W60> (C) L=485	1-33652-713-1	01	1	0308-	●	●
15	ROD; LINK 1ST SHIFT CAB UP +50MM<W60> (A) L=345	1-33652-736-0	01	1	0308-	●	●
15	ROD; LINK 1ST SHIFT CAB UP +50MM<W60> (E) L=464	1-33652-885-2	01	1	0308-	●	●
16	JOINT ASM; BALL,CONT ROD	1-09760-109-0	02	1	0308-	●	●
18	NUT; 1ST LINK ROD M8 FLANGE	1-09440-062-1	02	1	0308-	●	●
21	NUT; LK,RIGHT SCREW,LINK ROD M10	9-09111-410-0	02	1	0308-0512	●	●
21	NUT; LK,RIGHT SCREW,LINK ROD M10	0-91111-510-0	02	1	0601-	●	●
25	NUT; LK,RIGHT SCREW,LINK ROD (B) M10 LH THREAD	9-09840-167-0	01	1	0308-	●	●
25	NUT; LK,RIGHT SCREW,LINK ROD (B) M10 LH THREAD	9-09840-167-0	01	1	0308-	●	●
25	NUT; LK,RIGHT SCREW,LINK ROD (A) M12	9-99111-412-0	02	1	0308-0512	●	●
25	NUT; LK,RIGHT SCREW,LINK ROD (A) M12	0-91111-512-0	02	1	0601-	●	●
25	NUT; LK,RIGHT SCREW,LINK ROD CAB UP +110MM<TGG> (C) M10	9-09111-410-0	02	1	0308-0512	●	●
25	NUT; LK,RIGHT SCREW,LINK ROD (C) M10	0-91111-510-0	02	1	0601-	●	●
25	NUT; LK,RIGHT SCREW,LINK ROD CAB UP +50MM<W60> (C) M10	9-09111-510-0	02	1	0308-0512	●	●
112	JOINT; RUBBER	1-33670-413-1	01	1	0308-	●	●
112	JOINT; RUBBER CAB UP +110MM<TGG>,CAB UP +50MM<W60>	1-33670-413-1	01	1	0308-	●	●
