Sayfa 3-78 - Isuzu EPC

3-78 — FIXING PARTS; AIR PIPING (#24819) — 552 parça

16 11 16 27 128 29 379 322 376 297 16 22 29

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date	A	B
11	BOLT; CLIP BRKT 6SD1 TCN ENG(31L) M8X30 FLANGE	0-28680-830-0	01	1	0202-0512	●
11	BOLT; CLIP BRKT 6SD1 TCN ENG(31L) M8X30 FLANGE	0-28650-830-0	01	1	0601-	●
16	BRACKET; PIPE CLIP (C) L=55	1-47476-177-0	01	1	9601-9803	●	●
16	BRACKET; PIPE CLIP (C) L=55	1-47476-177-0	01	1	9804-0502	●
16	BRACKET; PIPE CLIP (C) L=55 B=25	1-47478-439-0	01	1	0503-	●
16	BRACKET; PIPE CLIP (A)	1-47476-699-2	01	1	9601-9803	●	●
16	BRACKET; PIPE CLIP (A)	1-47476-699-2	01	1	9804-	●
16	BRACKET; PIPE CLIP (B) L=100 H=30	1-47477-645-2	02	1	9601-9803	●	●
16	BRACKET; PIPE CLIP (B) L=100 H=30	1-47477-645-1	01	1	9601-9609		●
16	BRACKET; PIPE CLIP 6HE1 TC ENG(57L) (B) L=100 H=30	1-47477-645-2	01	1	9610-9803	●
16	BRACKET; PIPE CLIP (B) L=100 H=30	1-47477-645-2	01	1	9610-9803		●
16	BRACKET; PIPE CLIP WHEEL BASE 5000MM(50W) (B) L=150 H=30	1-47477-629-2	02	1	9706-9803		●
22	BRACKET; CLIP 6SD1 TCN ENG(31L)	1-47477-571-3	01	1	0202-	●
27	CLIP; FLEX HOSE (A) ID=25 H=30 L=35	1-09700-875-0	02	1	9601-9605	●
27	CLIP; FLEX HOSE (A) ID=25 H=30 L=35	1-09700-875-0	01	1	9606-9609	●
27	CLIP; FLEX HOSE (A) ID=25 H=30 L=35	1-09700-875-0	01	1	9606-9609	●
27	CLIP; FLEX HOSE ZF 9S109 OD M/T(Y2L) (A) ID=25 H=30 L=35	1-09700-875-0	01	1	9610-9903	●
27	CLIP; FLEX HOSE 6SD1 TCN ENG(31L) (A) ID=25 H=30 L=35	1-09700-875-0	01	1	9610-9903	●
27	CLIP; FLEX HOSE 6SD1 TCN ENG(31L) (A) ID=25 H=30 L=35	1-09700-875-0	01	1	9904-0004	●
27	CLIP; FLEX HOSE ZF 9S109 OD M/T(Y2L),ZF 9S109 OD M/T(Y3Y) (A) ID=25 H=30 L=35	1-09700-875-0	01	1	9904-0004	●
27	CLIP; FLEX HOSE 6SD1 TCN ENG(31L) (A) ID=25 H=30 L=35	1-09700-875-0	01	1	0005-0106	●
27	CLIP; FLEX HOSE ZF 9S109 OD M/T(Y2L) (A) ID=25 H=30 L=35	1-09700-875-0	01	1	0005-0106	●
27	CLIP; FLEX HOSE 6SD1 TCN ENG(31L) ZF 9S109 OD M/T(Y2L) (A) ID=25 H=30 L=35	1-09700-875-0	02	1	0107-0207	●
27	CLIP; FLEX HOSE 6SD1 TCN ENG(31L) ZF 9S109 OD M/T(Y2L) (A) ID=25 H=30 L=35	1-09700-875-0	03	1	0208-	●
27	CLIP; FLEX HOSE (A) ID=28 H=45 L=30	1-09700-948-0	01	1	9601-9609	●
27	CLIP; FLEX HOSE ZF 9S109 OD M/T(Y2L) (A) ID=28 H=45 L=30	1-09700-948-0	01	1	9610-9903	●
27	CLIP; FLEX HOSE ZF 9S109 OD M/T(Y2L),ZF 9S109 OD M/T(Y3Y) (A) ID=28 H=45 L=30	1-09700-948-0	01	1	9904-0004	●
27	CLIP; FLEX HOSE ZF 9S109 OD M/T(Y2L) (A) ID=28 H=45 L=30	1-09700-948-0	01	1	0005-0106	●
27	CLIP; FLEX HOSE 6SD1 TCN ENG(31L) ZF 9S109 OD M/T(Y2L) (A) ID=28 H=45 L=30	1-09700-948-0	01	1	0107-0207	●
27	CLIP; FLEX HOSE (B) ID=25 H=60 L=35	1-09701-103-0	01	1	9601-9609	●
27	CLIP; FLEX HOSE ZF 9S109 OD M/T(Y2L) (B) ID=25 H=60 L=35	1-09701-103-0	01	1	9610-9903	●
27	CLIP; FLEX HOSE ZF 9S109 OD M/T(Y2L),ZF 9S109 OD M/T(Y3Y) (B) ID=25 H=60 L=35	1-09701-103-0	01	1	9904-0004	●
27	CLIP; FLEX HOSE ZF 9S109 OD M/T(Y2L) (B) ID=25 H=60 L=35	1-09701-103-0	01	1	0005-0106	●
27	CLIP; FLEX HOSE 6SD1 TCN ENG(31L) ZF 9S109 OD M/T(Y2L) (B) ID=25 H=60 L=35	1-09701-103-0	01	1	0107-	●
27	CLIP; FLEX HOSE MAL6S M/T(Y1V) (A) ID=25 H=30 L=35	1-09700-875-0	03	1	0012-0106	●
27	CLIP; FLEX HOSE 6SD1 TCN ENG(31L) MAL6S M/T(Y1V) (A) ID=25 H=30 L=35	1-09700-875-0	04	1	0107-	●
29	BRACKET; CLIP,AIR PIPE (B) L=105 B=25	1-47476-161-0	01	1	9601-9609	●
29	BRACKET; CLIP,AIR PIPE 6SD1 TCN ENG(31L) (B) L=105 B=25	1-47476-161-0	01	1	9610-	●
29	BRACKET; CLIP,AIR PIPE MAL6S M/T(Y1V) (A)	1-82699-639-1	03	1	0012-0106	●
29	BRACKET; CLIP,AIR PIPE 6SD1 TCN ENG(31L) MAL6S M/T(Y1V) (A)	1-82699-639-1	03	1	0107-	●
128	CLIP; NYLON TUBE WHEEL BASE 5500MM(55W) (A) L=250	1-09707-126-0	07	1	9601-9602	●
128	CLIP; NYLON TUBE WHEEL BASE 6000MM(60W) (A) L=250	1-09707-126-0	15	1	9603-9609	●
128	CLIP; NYLON TUBE WHEEL BASE 4600MM(46W) (A) L=250	1-09707-126-0	15	1	9603-9609		●
128	CLIP; NYLON TUBE 6SD1 TCN ENG(31L) WHEEL BASE 4600MM(46W),WHEEL BASE 5500MM(55W) (A) L=250	1-09707-126-0	13	1	9610-0006	●
128	CLIP; NYLON TUBE 6SD1 TCN ENG(31L) WHEEL BASE 4600MM(46W),WHEEL BASE 5500MM(55W) (A) L=250	1-09707-126-0	14	1	0007-0106	●
128	CLIP; NYLON TUBE 6SD1 TCN ENG(31L) WHEEL BASE 5600MM(56W) (A) L=250	1-09707-126-0	14	1	0107-	●
128	CLIP; NYLON TUBE WHEEL BASE 6000MM(60W) (A) L=250	1-09707-126-0	08	1	9601-9602	●
128	CLIP; NYLON TUBE 6HE1 TC ENG(57L) WHEEL BASE 4600MM(46W) (A) L=250	1-09707-126-0	15	1	0007-0106	●
128	CLIP; NYLON TUBE 6HK1 TCS ENG(80L) WHEEL BASE 4700MM(47W) (A) L=250	1-09707-126-0	15	1	0107-	●
128	CLIP; NYLON TUBE 6HE1 TC ENG(57L) WHEEL BASE 6000MM(60W) (A) L=250	1-09707-126-0	18	1	9610-9705	●
128	CLIP; NYLON TUBE WHEEL BASE 6000MM(60W) (A) L=250	1-09707-126-0	18	1	9610-9705		●
128	CLIP; NYLON TUBE 6HE1 TC ENG(57L) WHEEL BASE 6000MM(60W) (A) L=250	1-09707-126-0	18	1	9706-9803	●
128	CLIP; NYLON TUBE 6HE1 TC ENG(57L),6HH1 STD ENG(65L) WHEEL BASE 6000MM(60W) (A) L=250	1-09707-126-0	18	1	9706-9803		●
128	CLIP; NYLON TUBE 6HE1 TC ENG(57L) WHEEL BASE 6000MM(60W) (A) L=250	1-09707-126-0	18	1	9804-0106	●
128	CLIP; NYLON TUBE 6SD1 TCN ENG(31L) (A) L=250	1-09707-126-0	01	1	0202-	●
128	CLIP; NYLON TUBE (A) L=250	1-09707-126-0	02	1	9601-9602	●	●
128	CLIP; NYLON TUBE (B) ID=21 L=30 H=40	1-09700-991-1	01	1	9601-9609		●
128	CLIP; NYLON TUBE 6HE1 TC ENG(57L) (B) ID=21 L=30 H=40	1-09700-991-1	01	1	9610-9803	●
128	CLIP; NYLON TUBE (B) ID=21 L=30 H=40	1-09700-991-1	01	1	9610-9803		●
128	CLIP; NYLON TUBE 6HE1 TC ENG(57L) (B) ID=21 L=30 H=40	1-09700-991-1	01	1	9804-9903	●
128	CLIP; NYLON TUBE WHEEL BASE 4600MM(46W) (A) L=250	1-09707-126-0	11	1	9601-9602		●
128	CLIP; NYLON TUBE WHEEL BASE 5500MM(55W) (A) L=250	1-09707-126-0	12	1	9601-9602		●
128	CLIP; NYLON TUBE WHEEL BASE 5500MM(55W) (A) L=250	1-09707-126-0	17	1	9603-9609		●
128	CLIP; NYLON TUBE 6SD1 TCN ENG(31L) WHEEL BASE 6000MM(60W) (A) L=250	1-09707-126-0	15	1	9610-9705	●
128	CLIP; NYLON TUBE 6HE1 TC ENG(57L) WHEEL BASE 4600MM(46W) (A) L=250	1-09707-126-0	15	1	9610-9705	●
128	CLIP; NYLON TUBE WHEEL BASE 4600MM(46W) (A) L=250	1-09707-126-0	15	1	9610-9705		●
128	CLIP; NYLON TUBE 6SD1 TCN ENG(31L) WHEEL BASE 6000MM(60W) (A) L=250	1-09707-126-0	15	1	9706-9803	●
128	CLIP; NYLON TUBE 6HE1 TC ENG(57L) WHEEL BASE 4600MM(46W) (A) L=250	1-09707-126-0	15	1	9706-9803	●
128	CLIP; NYLON TUBE 6HE1 TC ENG(57L),6HH1 STD ENG(65L) WHEEL BASE 4600MM(46W) (A) L=250	1-09707-126-0	15	1	9706-9803		●
128	CLIP; NYLON TUBE 6HE1 TC ENG(57L) WHEEL BASE 4600MM(46W) (A) L=250	1-09707-126-0	15	1	9804-0006	●
128	CLIP; NYLON TUBE 6SD1 TCN ENG(31L) WHEEL BASE 6000MM(60W) (A) L=250	1-09707-126-0	15	1	9804-0006	●
128	CLIP; NYLON TUBE 6SD1 TCN ENG(31L) WHEEL BASE 6000MM(60W) (A) L=250	1-09707-126-0	16	1	0007-0106	●
128	CLIP; NYLON TUBE 6SD1 TCN ENG(31L) WHEEL BASE 6100MM(61W) (A) L=250	1-09707-126-0	16	1	0107-	●
128	CLIP; NYLON TUBE WHEEL BASE 6000MM(60W) (A) L=250	1-09707-126-0	14	1	9601-9602		●
128	CLIP; NYLON TUBE WHEEL BASE 6000MM(60W) (A) L=250	1-09707-126-0	18	1	9603-9609		●
128	CLIP; NYLON TUBE 6HE1 TC ENG(57L) WHEEL BASE 5500MM(55W) (A) L=250	1-09707-126-0	17	1	9610-9705	●
128	CLIP; NYLON TUBE WHEEL BASE 5500MM(55W) (A) L=250	1-09707-126-0	17	1	9610-9705		●
128	CLIP; NYLON TUBE 6HE1 TC ENG(57L) WHEEL BASE 5500MM(55W) (A) L=250	1-09707-126-0	17	1	9706-9803	●
128	CLIP; NYLON TUBE 6HE1 TC ENG(57L),6HH1 STD ENG(65L) WHEEL BASE 5000MM(50W),WHEEL BASE 5500MM(55W) (A) L=250	1-09707-126-0	17	1	9706-9803		●
128	CLIP; NYLON TUBE 6HE1 TC ENG(57L) WHEEL BASE 5500MM(55W) (A) L=250	1-09707-126-0	17	1	9804-0106	●
128	CLIP; NYLON TUBE 6HK1 TCS ENG(80L) WHEEL BASE 5600MM(56W) (A) L=250	1-09707-126-0	17	1	0107-	●
297	NUT; BRKT 6HE1 TC ENG(57L) M8 FLANGE	0-91150-108-0	01	1	0009-0106	●
297	NUT; BRKT 6SD1 TCN ENG(31L) M8 FLANGE	0-91150-108-0	01	1	0107-0602	●
297	NUT; BRKT 6SD1 TCN ENG(31L) M8 FLANGE	0-91180-108-0	01	1	0603-	●
297	NUT; BRKT 6HK1 TCS ENG(80L) M8 FLANGE	0-91150-108-0	02	1	0107-0602	●
297	NUT; BRKT 6HK1 TCS ENG(80L) M8 FLANGE	0-91180-108-0	02	1	0603-	●
322	BRACKET; CLIP 6HE1 TC ENG(57L) L=90	1-47477-755-1	01	1	0009-0106	●
322	BRACKET; CLIP 6HK1 TCS ENG(80L) L=59 B=20	1-47479-048-0	01	1	0107-	●
322	BRACKET; CLIP 6SD1 TCN ENG(31L) MAL6S M/T(Y1V) L=95	1-82699-085-0	01	1	0105-0106	●
322	BRACKET; CLIP MAL6S M/T(Y1V) L=95	1-82699-085-0	01	1	0107-	●
322	BRACKET; CLIP L=95	1-82699-085-0	01	1	0107-	●
376	BOLT; BRKT 6HE1 TC ENG(57L) M8X25 FLANGE	0-28680-825-0	01	1	0009-0106	●
376	BOLT; BRKT 6HK1 TCS ENG(80L) M8X25 FLANGE	0-28680-825-0	01	1	0107-0512	●
376	BOLT; BRKT 6HK1 TCS ENG(80L) M8X25 FLANGE	0-28650-825-0	01	1	0601-	●
376	BOLT; BRKT 6SD1 TCN ENG(31L) MAL6S M/T(Y1V) M8X30 FLANGE	0-28680-830-0	01	1	0105-0106	●
376	BOLT; BRKT MAL6S M/T(Y1V) M8X30 FLANGE	0-28680-830-0	01	1	0107-0512	●
376	BOLT; BRKT M8X30 FLANGE	0-28680-830-0	01	1	0107-0512	●
376	BOLT; BRKT MAL6S M/T(Y1V) M8X30 FLANGE	0-28650-830-0	01	1	0601-	●
376	BOLT; BRKT M8X30 FLANGE	0-28650-830-0	01	1	0601-	●
379	BRACKET; NYLON TUBE	1-47477-514-3	02	1	9601-9609	●
379	BRACKET; NYLON TUBE 6SD1 TCN ENG(31L)	1-47477-514-3	02	1	9610-	●

28 30 254 288 300 13 107 286 31 290 55 79 78 39 333 103 80 108 98 20 14 126 133 267 371 4 13 27 91 97 107 265 375 6 21 92 99 109 127 268 295 309 13 39 78 292 318 32 74 76 128 107 265 266 286 331 332 375 356

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date	A	B
4	CLIP; AIR PIPE ID=11 H=20 L=20	5-09700-351-0	01	1	9601-9609	●
4	CLIP; AIR PIPE 6SD1 TCN ENG(31L) ID=11 H=20 L=20	5-09700-351-0	01	1	9610-0707	●
4	CLIP; AIR PIPE 6SD1 TCN ENG(31L) ID=11 H=20 L=20	8-98033-780-0	01	1	0708-	●
6	NUT; PIPE CLIP M8	9-09110-408-0	01	1	9601-9606	●
6	NUT; PIPE CLIP M8 FLANGE	0-91150-108-0	01	1	9607-9609	●
6	NUT; PIPE CLIP 6SD1 TCN ENG(31L) M8 FLANGE	0-91150-108-0	01	1	9610-0602	●
6	NUT; PIPE CLIP 6SD1 TCN ENG(31L) M8 FLANGE	0-91180-108-0	01	1	0603-	●
13	CLIP; AIR PIPE 6HK1 TCS ENG(80L) (B) ID=7 L=20	9-09524-635-0	01	1	0107-0606	●
13	CLIP; AIR PIPE 6HK1 TCS ENG(80L) (B) ID=7 L=20	0-95234-635-0	01	1	0607-	●
13	CLIP; AIR PIPE (C)	8-94435-553-0	03	1	9601-9803	●	●
13	CLIP; AIR PIPE (C)	8-94435-553-0	03	1	9804-	●
13	CLIP; AIR PIPE (A) ID=7 L=38 H=21	1-09700-916-0	01	1	9601-9609		●
13	CLIP; AIR PIPE 6HE1 TC ENG(57L) (A) ID=7 L=38 H=21	1-09700-916-0	01	1	9610-9803	●
13	CLIP; AIR PIPE (A) ID=7 L=38 H=21	1-09700-916-0	01	1	9610-9803		●
13	CLIP; AIR PIPE 6HE1 TC ENG(57L) (A) ID=7 L=38 H=21	1-09700-916-0	01	1	9804-0106	●
13	CLIP; AIR PIPE 6HK1 TCS ENG(80L) (A) ID=7 L=38 H=21	1-09700-916-0	01	1	0107-	●
13	CLIP; AIR PIPE (B) ID=7 L=40	9-09524-675-0	01	1	9601-9609		●
13	CLIP; AIR PIPE 6HE1 TC ENG(57L) (B) ID=7 L=40	9-09524-675-0	01	1	9610-9803	●
13	CLIP; AIR PIPE (B) ID=7 L=40	9-09524-675-0	01	1	9610-9803		●
13	CLIP; AIR PIPE 6HE1 TC ENG(57L) (B) ID=7 L=40	9-09524-675-0	01	1	9804-0106	●
13	CLIP; AIR PIPE 6HK1 TCS ENG(80L) (B) ID=7 L=40	9-09524-675-0	01	1	0107-0606	●
13	CLIP; AIR PIPE 6HK1 TCS ENG(80L) (B) ID=7 L=40	0-95234-675-0	01	1	0607-	●
13	CLIP; AIR PIPE 6HE1 TC ENG(57L) (B) ID=7 L=20	9-09524-635-0	01	1	9706-9803		●
14	BOLT; PIPE CLIP M8X25 FLANGE	0-28080-825-0	01	1	9601-9606	●
14	BOLT; PIPE CLIP M8X30 FLANGE	0-28680-830-0	01	1	9607-9609	●
14	BOLT; PIPE CLIP 6SD1 TCN ENG(31L) M8X30 FLANGE	0-28680-830-0	01	1	9610-0512	●
14	BOLT; PIPE CLIP 6SD1 TCN ENG(31L) M8X30 FLANGE	0-28650-830-0	01	1	0601-	●
20	BOLT; CLIP 6SD1 TCN ENG(31L) M8X16 FLANGE	0-28080-816-0	01	1	0107-0512	●
20	BOLT; CLIP 6SD1 TCN ENG(31L) M8X16 FLANGE	0-28050-816-0	01	1	0601-	●
20	BOLT; CLIP M8X20 FLANGE	0-28080-820-0	01	1	9601-9608		●
20	BOLT; CLIP M8X25 FLANGE	0-28680-825-0	01	1	9607-9705		●
20	BOLT; CLIP 6HE1 TC ENG(57L) M8X25 FLANGE	0-28680-825-0	01	1	9706-9803	●
20	BOLT; CLIP M8X25 FLANGE	0-28680-825-0	01	1	9706-9803		●
20	BOLT; CLIP 6HE1 TC ENG(57L) M8X25 FLANGE	0-28680-825-0	01	1	9804-0106	●
20	BOLT; CLIP 6HK1 TCS ENG(80L) M8X25 FLANGE	0-28680-825-0	01	1	0107-0512	●
20	BOLT; CLIP 6HK1 TCS ENG(80L) M8X25 FLANGE	0-28650-825-0	01	1	0601-	●
21	NUT; CLIP M8	9-09110-408-0	03	1	9601-9606	●
21	NUT; CLIP M8 FLANGE	0-91150-108-0	03	1	9607-9609	●
21	NUT; CLIP ZF 9S109 OD M/T(Y2L) M8 FLANGE	0-91150-108-0	03	1	9610-9903	●
21	NUT; CLIP ZF 9S109 OD M/T(Y2L),ZF 9S109 OD M/T(Y3Y) M8 FLANGE	0-91150-108-0	03	1	9904-0004	●
21	NUT; CLIP ZF 9S109 OD M/T(Y2L) M8 FLANGE	0-91150-108-0	03	1	0005-0106	●
21	NUT; CLIP 6SD1 TCN ENG(31L) ZF 9S109 OD M/T(Y2L) M8 FLANGE	0-91150-108-0	03	1	0107-0602	●
21	NUT; CLIP 6SD1 TCN ENG(31L) ZF 9S109 OD M/T(Y2L) M8 FLANGE	0-91180-108-0	03	1	0603-	●
21	NUT; CLIP M8	9-09110-408-0	01	1	9601-9608		●
21	NUT; CLIP M8 FLANGE	0-91150-108-0	01	1	9607-9705		●
21	NUT; CLIP 6HE1 TC ENG(57L) M8 FLANGE	0-91150-108-0	01	1	9706-9803	●
21	NUT; CLIP M8 FLANGE	0-91150-108-0	01	1	9706-9803		●
21	NUT; CLIP 6HE1 TC ENG(57L) M8 FLANGE	0-91150-108-0	01	1	9804-0011	●
21	NUT; CLIP MAL6S M/T(Y1V) M8 FLANGE	0-91150-108-0	01	1	0012-0106	●
21	NUT; CLIP 6HE1 TC ENG(57L) M8 FLANGE	0-91150-108-0	01	1	0012-0106	●
21	NUT; CLIP 6SD1 TCN ENG(31L) MAL6S M/T(Y1V) M8 FLANGE	0-91150-108-0	01	1	0107-0602	●
21	NUT; CLIP 6SD1 TCN ENG(31L),6HK1 TCS ENG(80L) M8 FLANGE	0-91150-108-0	01	1	0107-0602	●
21	NUT; CLIP 6SD1 TCN ENG(31L) MAL6S M/T(Y1V) M8 FLANGE	0-91180-108-0	01	1	0603-	●
21	NUT; CLIP 6SD1 TCN ENG(31L),6HK1 TCS ENG(80L) M8 FLANGE	0-91180-108-0	01	1	0603-	●
27	CLIP; FLEX HOSE (A) ID=25 H=30 L=35	1-09700-875-0	02	1	9601-9605	●
27	CLIP; FLEX HOSE (A) ID=25 H=30 L=35	1-09700-875-0	01	1	9606-9609	●
27	CLIP; FLEX HOSE (A) ID=25 H=30 L=35	1-09700-875-0	01	1	9606-9609	●
27	CLIP; FLEX HOSE ZF 9S109 OD M/T(Y2L) (A) ID=25 H=30 L=35	1-09700-875-0	01	1	9610-9903	●
27	CLIP; FLEX HOSE 6SD1 TCN ENG(31L) (A) ID=25 H=30 L=35	1-09700-875-0	01	1	9610-9903	●
27	CLIP; FLEX HOSE 6SD1 TCN ENG(31L) (A) ID=25 H=30 L=35	1-09700-875-0	01	1	9904-0004	●
27	CLIP; FLEX HOSE ZF 9S109 OD M/T(Y2L),ZF 9S109 OD M/T(Y3Y) (A) ID=25 H=30 L=35	1-09700-875-0	01	1	9904-0004	●
27	CLIP; FLEX HOSE 6SD1 TCN ENG(31L) (A) ID=25 H=30 L=35	1-09700-875-0	01	1	0005-0106	●
27	CLIP; FLEX HOSE ZF 9S109 OD M/T(Y2L) (A) ID=25 H=30 L=35	1-09700-875-0	01	1	0005-0106	●
27	CLIP; FLEX HOSE 6SD1 TCN ENG(31L) ZF 9S109 OD M/T(Y2L) (A) ID=25 H=30 L=35	1-09700-875-0	02	1	0107-0207	●
27	CLIP; FLEX HOSE 6SD1 TCN ENG(31L) ZF 9S109 OD M/T(Y2L) (A) ID=25 H=30 L=35	1-09700-875-0	03	1	0208-	●
27	CLIP; FLEX HOSE (A) ID=28 H=45 L=30	1-09700-948-0	01	1	9601-9609	●
27	CLIP; FLEX HOSE ZF 9S109 OD M/T(Y2L) (A) ID=28 H=45 L=30	1-09700-948-0	01	1	9610-9903	●
27	CLIP; FLEX HOSE ZF 9S109 OD M/T(Y2L),ZF 9S109 OD M/T(Y3Y) (A) ID=28 H=45 L=30	1-09700-948-0	01	1	9904-0004	●
27	CLIP; FLEX HOSE ZF 9S109 OD M/T(Y2L) (A) ID=28 H=45 L=30	1-09700-948-0	01	1	0005-0106	●
27	CLIP; FLEX HOSE 6SD1 TCN ENG(31L) ZF 9S109 OD M/T(Y2L) (A) ID=28 H=45 L=30	1-09700-948-0	01	1	0107-0207	●
27	CLIP; FLEX HOSE (B) ID=25 H=60 L=35	1-09701-103-0	01	1	9601-9609	●
27	CLIP; FLEX HOSE ZF 9S109 OD M/T(Y2L) (B) ID=25 H=60 L=35	1-09701-103-0	01	1	9610-9903	●
27	CLIP; FLEX HOSE ZF 9S109 OD M/T(Y2L),ZF 9S109 OD M/T(Y3Y) (B) ID=25 H=60 L=35	1-09701-103-0	01	1	9904-0004	●
27	CLIP; FLEX HOSE ZF 9S109 OD M/T(Y2L) (B) ID=25 H=60 L=35	1-09701-103-0	01	1	0005-0106	●
27	CLIP; FLEX HOSE 6SD1 TCN ENG(31L) ZF 9S109 OD M/T(Y2L) (B) ID=25 H=60 L=35	1-09701-103-0	01	1	0107-	●
27	CLIP; FLEX HOSE MAL6S M/T(Y1V) (A) ID=25 H=30 L=35	1-09700-875-0	03	1	0012-0106	●
27	CLIP; FLEX HOSE 6SD1 TCN ENG(31L) MAL6S M/T(Y1V) (A) ID=25 H=30 L=35	1-09700-875-0	04	1	0107-	●
28	BOLT; CLIP,FLEX HOSE M8X20 FLANGE	0-28080-820-0	04	1	9601-9606	●
28	BOLT; CLIP,FLEX HOSE M8X25 FLANGE	0-28680-825-0	04	1	9607-9609	●
28	BOLT; CLIP,FLEX HOSE 6SD1 TCN ENG(31L) M8X25 FLANGE	0-28680-825-0	04	1	9610-0209	●
28	BOLT; CLIP,FLEX HOSE 6SD1 TCN ENG(31L) M8X20 FLANGE	0-28680-820-0	04	1	0210-0512	●
28	BOLT; CLIP,FLEX HOSE 6SD1 TCN ENG(31L) M8X20 FLANGE	0-28650-820-0	04	1	0601-	●
30	BOLT; CLIP BRKT M8X30 FLANGE	0-28080-830-0	01	1	9601-9606	●
30	BOLT; CLIP BRKT M8X35 FLANGE	0-28680-835-0	01	1	9607-9609	●
30	BOLT; CLIP BRKT 6SD1 TCN ENG(31L) M8X35 FLANGE	0-28680-835-0	01	1	9610-0512	●
30	BOLT; CLIP BRKT 6SD1 TCN ENG(31L) M8X35 FLANGE	0-28650-835-0	01	1	0601-	●
31	NUT; CLIP BRKT M8	9-09110-408-0	01	1	9601-9606	●
31	NUT; CLIP BRKT M8 FLANGE	0-91150-108-0	01	1	9607-9609	●
31	NUT; CLIP BRKT 6SD1 TCN ENG(31L) M8 FLANGE	0-91150-108-0	01	1	9610-0602	●
31	NUT; CLIP BRKT 6SD1 TCN ENG(31L) M8 FLANGE	0-91180-108-0	01	1	0603-	●
31	NUT; CLIP BRKT MAL6S M/T(Y1V) M10 FLANGE	5-09440-006-0	03	1	0012-0106	●
31	NUT; CLIP BRKT 6SD1 TCN ENG(31L) MAL6S M/T(Y1V) M10 FLANGE	5-09440-006-0	03	1	0107-	●
32	CLIP; BAND,RUBBER SLEEVE L=250	1-09707-126-0	01	1	9604-9609	●
32	CLIP; BAND,RUBBER SLEEVE ZF 9S109 OD M/T(Y2L) L=250	1-09707-126-0	01	1	9610-9903	●
32	CLIP; BAND,RUBBER SLEEVE ZF 9S109 OD M/T(Y2L),ZF 9S109 OD M/T(Y3Y) L=250	1-09707-126-0	01	1	9904-0004	●
32	CLIP; BAND,RUBBER SLEEVE ZF 9S109 OD M/T(Y2L) L=250	1-09707-126-0	01	1	0005-0106	●
32	CLIP; BAND,RUBBER SLEEVE 6SD1 TCN ENG(31L) ZF 9S109 OD M/T(Y2L) L=250	1-09707-126-0	01	1	0107-	●
39	CLIP; AIR PIPE 6HE1 TC ENG(57L) EXC. AIR DRYER<PS7> (B) ID=6.35 & 15	1-09709-276-1	01	1	9804-0106	●
39	CLIP; AIR PIPE EXC. AIR DRYER<PS7> (A) ID=16 & 7 L=21 & 17	1-09700-675-0	01	1	9601-9803	●	●
39	CLIP; AIR PIPE EXC. AIR DRYER<PS7> (A) ID=16 & 7 L=21 & 17	1-09700-675-0	01	1	9804-0106	●
39	CLIP; AIR PIPE AIR DRYER<PS7> (B) ID=15 & 15	1-09709-282-1	01	1	9601-9609		●
39	CLIP; AIR PIPE 6HE1 TC ENG(57L) AIR DRYER<PS7> (B) ID=15 & 15	1-09709-282-1	01	1	9610-9803	●
39	CLIP; AIR PIPE AIR DRYER<PS7> (B) ID=15 & 15	1-09709-282-1	01	1	9610-9803		●
39	CLIP; AIR PIPE 6HE1 TC ENG(57L) AIR DRYER<PS7> (B) ID=15 & 15	1-09709-282-1	01	1	9804-0106	●
39	CLIP; AIR PIPE 6HK1 TCS ENG(80L) (B) ID=15 & 15	1-09709-282-1	01	1	0107-	●
55	BOLT; PIPE CLIP M8X25 FLANGE	0-28080-825-0	02	1	9601-9606	●
55	BOLT; PIPE CLIP M8X30 FLANGE	0-28680-830-0	02	1	9607-9609	●
55	BOLT; PIPE CLIP 6SD1 TCN ENG(31L) M8X30 FLANGE	0-28680-830-0	02	1	9610-0106	●
55	BOLT; PIPE CLIP 6SD1 TCN ENG(31L) M8X30 FLANGE	0-28680-830-0	02	1	0107-0512	●
55	BOLT; PIPE CLIP 6SD1 TCN ENG(31L) M8X30 FLANGE	0-28650-830-0	02	1	0601-	●
55	BOLT; PIPE CLIP M8X25 FLANGE	0-28080-825-0	04	1	9601-9606		●
55	BOLT; PIPE CLIP M8X30 FLANGE	0-28680-830-0	04	1	9607-9610		●
55	BOLT; PIPE CLIP 6HE1 TC ENG(57L) M8X30 FLANGE	0-28680-830-0	04	1	9611-9803	●
55	BOLT; PIPE CLIP M8X30 FLANGE	0-28680-830-0	04	1	9611-9803		●
55	BOLT; PIPE CLIP 6HE1 TC ENG(57L) M8X30 FLANGE	0-28680-830-0	04	1	9804-0106	●
55	BOLT; PIPE CLIP 6HK1 TCS ENG(80L) M8X30 FLANGE	0-28680-830-0	04	1	0107-0512	●
55	BOLT; PIPE CLIP 6HK1 TCS ENG(80L) M8X30 FLANGE	0-28650-830-0	04	1	0601-	●
74	CLIP; NYLON TUBE L=250	1-09707-126-0	01	1	9601-9602	●
76	CLIP; NYLON TUBE L=250	1-09707-126-0	01	1	9601-9602	●
76	CLIP; NYLON TUBE L=250	1-09707-126-0	07	1	9601-9602	●
76	CLIP; NYLON TUBE L=250	1-09707-126-0	06	1	9601-9602		●
78	CLIP; AIR PIPE AIR DRYER<PS7> (B) ID=16 & 7 L=21 & 17	1-09700-675-0	01	1	9601-9601	●
78	CLIP; AIR PIPE AIR DRYER<PS7> (A) ID=6.35 & 15	1-09709-276-1	04	1	9602-9609	●
78	CLIP; AIR PIPE 6SD1 TCN ENG(31L) AIR DRYER<PS7> (A) ID=6.35 & 15	1-09709-276-1	04	1	9610-9803	●
78	CLIP; AIR PIPE 6SD1 TCN ENG(31L) WHEEL BASE 4600MM(46W),WHEEL BASE 5500MM(55W), WHEEL BASE 6000MM(60W) AIR DRYER<PS7> (A) ID=6.35 & 15	1-09709-276-1	05	1	9804-0104	●
78	CLIP; AIR PIPE 6SD1 TCN ENG(31L) WHEEL BASE 4600MM(46W),WHEEL BASE 5500MM(55W), WHEEL BASE 6000MM(60W) AIR DRYER<PS7> (A) ID=6.35 & 15	1-09709-276-1	06	1	0105-0106	●
78	CLIP; AIR PIPE 6SD1 TCN ENG(31L) (A) ID=6.35 & 15	1-09709-276-1	06	1	0107-	●
78	CLIP; AIR PIPE WHEEL BASE 5500MM(55W),WHEEL BASE 6000MM(60W) AIR DRYER<PS7> (A) ID=6.35 & 15	1-09709-276-1	03	1	9601-9601	●
78	CLIP; AIR PIPE EXC. AIR DRYER<PS7> (A) ID=6.35 & 15	1-09709-276-1	02	1	9602-9609	●
78	CLIP; AIR PIPE 6SD1 TCN ENG(31L) EXC. AIR DRYER<PS7> (A) ID=6.35 & 15	1-09709-276-1	02	1	9610-0106	●
78	CLIP; AIR PIPE 6HK1 TCS ENG(80L) (A) ID=6.35 & 15	1-09709-276-1	01	1	0107-	●
78	CLIP; AIR PIPE WHEEL BASE 5500MM(55W),WHEEL BASE 6000MM(60W) EXC. AIR DRYER<PS7> (A) ID=6.35 & 15	1-09709-276-1	02	1	9601-9601	●
78	CLIP; AIR PIPE WHEEL BASE 5500MM(55W),WHEEL BASE 6000MM(60W) (B) ID=16 & 7 L=21 & 17	1-09700-675-0	01	1	9602-9609	●
78	CLIP; AIR PIPE 6SD1 TCN ENG(31L) WHEEL BASE 4600MM(46W),WHEEL BASE 5500MM(55W), WHEEL BASE 6000MM(60W) (B) ID=16 & 7 L=21 & 17	1-09700-675-0	01	1	9610-9803	●
78	CLIP; AIR PIPE 6SD1 TCN ENG(31L) (B) ID=16 & 7 L=21 & 17	1-09700-675-0	01	1	9804-9806	●
78	CLIP; AIR PIPE 6HE1 TC ENG(57L) AIR DRYER<PS7> (A) ID=6.35 & 15	1-09709-276-1	01	1	9804-0106	●
79	BOLT; PIPE CLIP AIR DRYER<PS7> M8X50 FLANGE	0-28080-850-0	01	1	9601-9601	●
79	BOLT; PIPE CLIP WHEEL BASE 5500MM(55W),WHEEL BASE 6000MM(60W) M8X50 FLANGE	0-28080-850-0	01	1	9602-9609	●
79	BOLT; PIPE CLIP 6SD1 TCN ENG(31L) WHEEL BASE 4600MM(46W),WHEEL BASE 5500MM(55W), WHEEL BASE 6000MM(60W) M8X50 FLANGE	0-28080-850-0	01	1	9610-9803	●
79	BOLT; PIPE CLIP 6SD1 TCN ENG(31L) M8X50 FLANGE	0-28080-850-0	01	1	9804-9806	●
80	NUT; CLIP,AIR PIPE AIR DRYER<PS7> M8	9-09110-408-0	01	1	9601-9601	●
80	NUT; CLIP,AIR PIPE WHEEL BASE 5500MM(55W),WHEEL BASE 6000MM(60W) M8	9-09110-408-0	01	1	9602-9606	●
80	NUT; CLIP,AIR PIPE WHEEL BASE 5500MM(55W),WHEEL BASE 6000MM(60W) M8 FLANGE	0-91150-108-0	01	1	9607-9609	●
80	NUT; CLIP,AIR PIPE 6SD1 TCN ENG(31L) WHEEL BASE 4600MM(46W),WHEEL BASE 5500MM(55W), WHEEL BASE 6000MM(60W) M8 FLANGE	0-91150-108-0	01	1	9610-9803	●
80	NUT; CLIP,AIR PIPE 6SD1 TCN ENG(31L) M8 FLANGE	0-91150-108-0	01	1	9804-9806	●
91	CLIP; AIR PIPE ID=11 H=20 L=20	5-09700-351-0	02	1	9601-9609	●
91	CLIP; AIR PIPE 6SD1 TCN ENG(31L) ID=11 H=20 L=20	5-09700-351-0	02	1	9610-0707	●
91	CLIP; AIR PIPE 6SD1 TCN ENG(31L) ID=11 H=20 L=20	8-98033-780-0	02	1	0708-	●
91	CLIP; AIR PIPE ID=11 H=20 L=20	5-09700-351-0	04	1	9601-9610		●
91	CLIP; AIR PIPE 6HE1 TC ENG(57L) ID=11 H=20 L=20	5-09700-351-0	04	1	9611-9803	●
91	CLIP; AIR PIPE ID=11 H=20 L=20	5-09700-351-0	04	1	9611-9803		●
91	CLIP; AIR PIPE 6HE1 TC ENG(57L) ID=11 H=20 L=20	5-09700-351-0	04	1	9804-0106	●
91	CLIP; AIR PIPE 6HK1 TCS ENG(80L) ID=11 H=20 L=20	5-09700-351-0	04	1	0107-0707	●
91	CLIP; AIR PIPE 6HK1 TCS ENG(80L) ID=11 H=20 L=20	8-98033-780-0	04	1	0708-	●
92	NUT; PIPE CLIP M8	9-09110-408-0	01	1	9601-9606	●
92	NUT; PIPE CLIP M8 FLANGE	0-91150-108-0	01	1	9607-9609	●
92	NUT; PIPE CLIP 6SD1 TCN ENG(31L) M8 FLANGE	0-91150-108-0	01	1	9610-0602	●
92	NUT; PIPE CLIP 6SD1 TCN ENG(31L) M8 FLANGE	0-91180-108-0	01	1	0603-	●
92	NUT; PIPE CLIP M8	9-09110-408-0	02	1	9601-9606		●
92	NUT; PIPE CLIP M8 FLANGE	0-91150-108-0	02	1	9607-9610		●
92	NUT; PIPE CLIP 6HE1 TC ENG(57L) M8 FLANGE	0-91150-108-0	02	1	9611-9803	●
92	NUT; PIPE CLIP M8 FLANGE	0-91150-108-0	02	1	9611-9803		●
92	NUT; PIPE CLIP 6HE1 TC ENG(57L) M8 FLANGE	0-91150-108-0	02	1	9804-0106	●
92	NUT; PIPE CLIP 6HK1 TCS ENG(80L) M8 FLANGE	0-91150-108-0	02	1	0107-0602	●
92	NUT; PIPE CLIP 6HK1 TCS ENG(80L) M8 FLANGE	0-91180-108-0	02	1	0603-	●
97	CLIP; AIR PIPE ID=11 H=20 L=20	5-09700-351-0	01	1	9601-9609	●
97	CLIP; AIR PIPE 6SD1 TCN ENG(31L) ID=11 H=20 L=20	5-09700-351-0	01	1	9610-0707	●
97	CLIP; AIR PIPE 6SD1 TCN ENG(31L) ID=11 H=20 L=20	8-98033-780-0	01	1	0708-	●
98	BOLT; PIPE CLIP M8X25 FLANGE	0-28080-825-0	01	1	9601-9606	●
98	BOLT; PIPE CLIP M8X30 FLANGE	0-28680-830-0	01	1	9607-9609	●
98	BOLT; PIPE CLIP 6SD1 TCN ENG(31L) M8X30 FLANGE	0-28680-830-0	01	1	9610-0512	●
98	BOLT; PIPE CLIP 6SD1 TCN ENG(31L) M8X30 FLANGE	0-28650-830-0	01	1	0601-	●
99	NUT; PIPE CLIP M8	9-09110-408-0	01	1	9601-9606	●
99	NUT; PIPE CLIP M8 FLANGE	0-91150-108-0	01	1	9607-9609	●
99	NUT; PIPE CLIP 6SD1 TCN ENG(31L) M8 FLANGE	0-91150-108-0	01	1	9610-0602	●
99	NUT; PIPE CLIP 6SD1 TCN ENG(31L) M8 FLANGE	0-91180-108-0	01	1	0603-	●
103	NUT; PIPE CLIP M8	9-09110-408-0	01	1	9601-9606	●
103	NUT; PIPE CLIP M8 FLANGE	0-91150-108-0	01	1	9607-9609	●
103	NUT; PIPE CLIP 6SD1 TCN ENG(31L) M8 FLANGE	0-91150-108-0	01	1	9610-0602	●
103	NUT; PIPE CLIP 6SD1 TCN ENG(31L) M8 FLANGE	0-91180-108-0	01	1	0603-	●
103	NUT; PIPE CLIP M8	9-09110-408-0	02	1	9601-9606		●
103	NUT; PIPE CLIP M8 FLANGE	0-91150-108-0	02	1	9607-9610		●
103	NUT; PIPE CLIP 6HE1 TC ENG(57L) M8 FLANGE	0-91150-108-0	02	1	9611-9803	●
103	NUT; PIPE CLIP M8 FLANGE	0-91150-108-0	02	1	9611-9803		●
103	NUT; PIPE CLIP 6HE1 TC ENG(57L) M8 FLANGE	0-91150-108-0	02	1	9804-0106	●
103	NUT; PIPE CLIP 6HK1 TCS ENG(80L) M8 FLANGE	0-91150-108-0	02	1	0107-0602	●
103	NUT; PIPE CLIP 6HK1 TCS ENG(80L) M8 FLANGE	0-91180-108-0	02	1	0603-	●
107	CLIP; NYLON TUBE WHEEL BASE 5500MM(55W) (B) L=250	1-09707-126-0	15	1	9601-9602	●
107	CLIP; NYLON TUBE WHEEL BASE 5500MM(55W),WHEEL BASE 6000MM(60W) (B) L=250	1-09707-126-0	14	1	9603-9609	●
107	CLIP; NYLON TUBE 6SD1 TCN ENG(31L) WHEEL BASE 4600MM(46W),WHEEL BASE 5500MM(55W), WHEEL BASE 6000MM(60W) (B) L=250	1-09707-126-0	14	1	9610-0106	●
107	CLIP; NYLON TUBE 6SD1 TCN ENG(31L) (B) L=250	1-09707-126-0	15	1	0107-0201	●
107	CLIP; NYLON TUBE 6SD1 TCN ENG(31L) (B) L=250	1-09707-126-0	16	1	0202-	●
107	CLIP; NYLON TUBE WHEEL BASE 6000MM(60W) (B) L=250	1-09707-126-0	16	1	9601-9602	●
107	CLIP; NYLON TUBE 6HE1 TC ENG(57L) (C) ID=18 L=28	1-09701-067-0	01	1	0003-0004	●
107	CLIP; NYLON TUBE (C) ID=18 L=28	1-09701-067-0	01	1	0005-0006	●
107	CLIP; NYLON TUBE 6SD1 TCN ENG(31L) (C) ID=18 L=28	1-09701-067-0	01	1	0007-0011	●
107	CLIP; NYLON TUBE (C) ID=18 L=28	1-09701-067-0	01	1	0012-0106	●
107	CLIP; NYLON TUBE 6HK1 TCS ENG(80L) (B) L=250	1-09707-126-0	12	1	0107-	●
107	CLIP; NYLON TUBE 6HE1 TC ENG(57L) (C) ID=15 L=28	1-09701-216-0	01	1	0003-0004	●
107	CLIP; NYLON TUBE (C) ID=15 L=28	1-09701-216-0	01	1	0005-0106	●
107	CLIP; NYLON TUBE (C) ID=15 L=28	1-09701-216-0	01	1	0107-0206	●
107	CLIP; NYLON TUBE 6HE1 TC ENG(57L) (C) ID=18 L=54	1-09701-068-0	01	1	0007-0011	●
107	CLIP; NYLON TUBE (A) ID=27.5 H=23 L=24	1-09700-863-0	02	1	9601-9803	●	●
107	CLIP; NYLON TUBE (A) ID=27.5 H=23 L=24	1-09700-863-0	01	1	9804-	●
107	CLIP; NYLON TUBE (A) ID=35 H=45 L=33	1-09700-947-0	02	1	9601-9609		●
107	CLIP; NYLON TUBE 6HE1 TC ENG(57L) (A) ID=35 H=45 L=33	1-09700-947-0	02	1	9610-9803	●
107	CLIP; NYLON TUBE (A) ID=35 H=45 L=33	1-09700-947-0	02	1	9610-9803		●
107	CLIP; NYLON TUBE 6SD1 TCN ENG(31L),6HE1 TC ENG(57L) (A) ID=35 H=45 L=33	1-09700-947-0	02	1	9804-0106	●
107	CLIP; NYLON TUBE 6SD1 TCN ENG(31L) (A) ID=35 H=45 L=33	1-09700-947-0	02	1	0107-	●
107	CLIP; NYLON TUBE (B) L=250	1-09707-126-0	01	1	9601-9609		●
107	CLIP; NYLON TUBE 6HE1 TC ENG(57L) (B) L=250	1-09707-126-0	01	1	9610-9803	●
107	CLIP; NYLON TUBE (B) L=250	1-09707-126-0	01	1	9610-9803		●
107	CLIP; NYLON TUBE 6HE1 TC ENG(57L) (B) L=250	1-09707-126-0	01	1	9804-0106	●
107	CLIP; NYLON TUBE (B) L=250	1-09707-126-0	01	1	9804-0106	●
107	CLIP; NYLON TUBE (B) L=250	1-09707-126-0	09	1	9601-9609		●
107	CLIP; NYLON TUBE 6HE1 TC ENG(57L) (B) L=250	1-09707-126-0	09	1	9610-9803	●
107	CLIP; NYLON TUBE (B) L=250	1-09707-126-0	09	1	9610-9803		●
107	CLIP; NYLON TUBE 6HE1 TC ENG(57L) (B) L=250	1-09707-126-0	09	1	9804-0002	●
107	CLIP; NYLON TUBE 6HE1 TC ENG(57L) (B) L=250	1-09707-126-0	08	1	0003-0106	●
107	CLIP; NYLON TUBE (C) ID=18 L=28	1-09701-067-0	01	1	0107-0206	●
107	CLIP; NYLON TUBE (C) ID=18 L=28	1-09701-067-0	02	1	0207-	●
108	BOLT; TUBE CLIP M8X25 FLANGE	0-28080-825-0	01	1	9601-9606	●
108	BOLT; TUBE CLIP M8X30 FLANGE	0-28680-830-0	01	1	9607-9609	●
108	BOLT; TUBE CLIP 6SD1 TCN ENG(31L) M8X30 FLANGE	0-28680-830-0	01	1	9610-9803	●
108	BOLT; TUBE CLIP 6SD1 TCN ENG(31L),6HE1 TC ENG(57L) M8X30 FLANGE	0-28680-830-0	02	1	9804-0106	●
108	BOLT; TUBE CLIP M8X30 FLANGE	0-28680-830-0	02	1	0107-0512	●
108	BOLT; TUBE CLIP M8X30 FLANGE	0-28650-830-0	02	1	0601-	●
108	BOLT; TUBE CLIP M8X25 FLANGE	0-28680-825-0	01	1	0005-0106	●
108	BOLT; TUBE CLIP M8X25 FLANGE	0-28680-825-0	01	1	0005-0106	●
108	BOLT; TUBE CLIP 6SD1 TCN ENG(31L) M8X16 FLANGE	0-28080-816-0	02	1	0107-0512	●
108	BOLT; TUBE CLIP 6SD1 TCN ENG(31L) M8X16 FLANGE	0-28050-816-0	02	1	0601-	●
108	BOLT; TUBE CLIP M8X16 FLANGE	0-28080-816-0	01	1	9601-9803	●	●
108	BOLT; TUBE CLIP M8X16 FLANGE	0-28080-816-0	01	1	9804-0512	●
108	BOLT; TUBE CLIP M8X16 FLANGE	0-28050-816-0	01	1	0601-	●
108	BOLT; TUBE CLIP M8X25 FLANGE	0-28080-825-0	03	1	9601-9606		●
108	BOLT; TUBE CLIP M8X30 FLANGE	0-28680-830-0	03	1	9607-9609		●
108	BOLT; TUBE CLIP 6HE1 TC ENG(57L) M8X30 FLANGE	0-28680-830-0	03	1	9610-9803	●
108	BOLT; TUBE CLIP M8X30 FLANGE	0-28680-830-0	03	1	9610-9803		●
109	NUT; TUBE CLIP M8 FLANGE	0-91150-108-0	04	1	0005-0106	●
109	NUT; TUBE CLIP M8 FLANGE	0-91150-108-0	03	1	0107-0602	●
109	NUT; TUBE CLIP M8 FLANGE	0-91180-108-0	03	1	0603-	●
109	NUT; TUBE CLIP 6SD1 TCN ENG(31L) M8 FLANGE	0-91150-108-0	02	1	0107-0602	●
109	NUT; TUBE CLIP 6SD1 TCN ENG(31L) M8 FLANGE	0-91180-108-0	02	1	0603-	●
109	NUT; TUBE CLIP M8	9-09110-408-0	02	1	9601-9606	●	●
109	NUT; TUBE CLIP M8 FLANGE	0-91150-108-0	02	1	9607-9803	●	●
109	NUT; TUBE CLIP M8 FLANGE	0-91150-108-0	03	1	9804-0004	●
109	NUT; TUBE CLIP M8 FLANGE	0-91150-108-0	01	1	0005-0104	●
109	NUT; TUBE CLIP 6SD1 TCN ENG(31L) MAL6S M/T(Y1V) M8 FLANGE	0-91150-108-0	01	1	0105-0106	●
109	NUT; TUBE CLIP M8 FLANGE	0-91150-108-0	01	1	0105-0106	●
109	NUT; TUBE CLIP 6HK1 TCS ENG(80L) ZF 9S109 OD M/T(Y2L) M8 FLANGE	0-91150-108-0	01	1	0107-0602	●
109	NUT; TUBE CLIP MAL6S M/T(Y1V) M8 FLANGE	0-91150-108-0	01	1	0107-0602	●
109	NUT; TUBE CLIP 6HK1 TCS ENG(80L) ZF 9S109 OD M/T(Y2L) M8 FLANGE	0-91180-108-0	01	1	0603-	●
109	NUT; TUBE CLIP MAL6S M/T(Y1V) M8 FLANGE	0-91180-108-0	01	1	0603-	●
109	NUT; TUBE CLIP M8	9-09110-408-0	04	1	9601-9606		●
109	NUT; TUBE CLIP M8 FLANGE	0-91150-108-0	04	1	9607-9609		●
109	NUT; TUBE CLIP 6HE1 TC ENG(57L) M8 FLANGE	0-91150-108-0	04	1	9610-9803	●
109	NUT; TUBE CLIP M8 FLANGE	0-91150-108-0	04	1	9610-9803		●
126	BOLT; CLIP BRKT M8X20 FLANGE	0-28080-820-0	03	1	9601-9606	●	●
126	BOLT; CLIP BRKT M8X25 FLANGE	0-28680-825-0	03	1	9607-9803	●	●
126	BOLT; CLIP BRKT M8X25 FLANGE	0-28680-825-0	03	1	9804-0512	●
126	BOLT; CLIP BRKT M8X25 FLANGE	0-28650-825-0	03	1	0601-	●
126	BOLT; CLIP BRKT M8X30 FLANGE	0-28080-830-0	02	1	9601-9606	●	●
126	BOLT; CLIP BRKT M8X35 FLANGE	0-28680-835-0	02	1	9607-9803	●	●
126	BOLT; CLIP BRKT M8X30 FLANGE	0-28080-830-0	01	1	9601-9606		●
126	BOLT; CLIP BRKT M8X35 FLANGE	0-28680-835-0	01	1	9607-9609		●
126	BOLT; CLIP BRKT 6HE1 TC ENG(57L) M8X35 FLANGE	0-28680-835-0	01	1	9610-9803	●
126	BOLT; CLIP BRKT M8X35 FLANGE	0-28680-835-0	01	1	9610-9803		●
126	BOLT; CLIP BRKT WHEEL BASE 5000MM(50W) M8X30 FLANGE	0-28680-830-0	02	1	9706-9803		●
127	NUT; CLIP BRKT M8	9-09110-408-0	05	1	9601-9606	●	●
127	NUT; CLIP BRKT M8 FLANGE	0-91150-108-0	05	1	9607-9803	●	●
127	NUT; CLIP BRKT M8 FLANGE	0-91150-108-0	02	1	9804-9807	●
127	NUT; CLIP BRKT M8 FLANGE	0-91150-108-0	03	1	9808-0602	●
127	NUT; CLIP BRKT M8 FLANGE	0-91180-108-0	03	1	0603-	●
127	NUT; CLIP BRKT M8	9-09110-408-0	01	1	9601-9606		●
127	NUT; CLIP BRKT M8 FLANGE	0-91150-108-0	01	1	9607-9609		●
127	NUT; CLIP BRKT 6HE1 TC ENG(57L) M8 FLANGE	0-91150-108-0	01	1	9610-9803	●
127	NUT; CLIP BRKT M8 FLANGE	0-91150-108-0	01	1	9610-9803		●
127	NUT; CLIP BRKT WHEEL BASE 5000MM(50W) M8 FLANGE	0-91150-108-0	02	1	9706-9803		●
128	CLIP; NYLON TUBE WHEEL BASE 5500MM(55W) (A) L=250	1-09707-126-0	07	1	9601-9602	●
128	CLIP; NYLON TUBE WHEEL BASE 6000MM(60W) (A) L=250	1-09707-126-0	15	1	9603-9609	●
128	CLIP; NYLON TUBE WHEEL BASE 4600MM(46W) (A) L=250	1-09707-126-0	15	1	9603-9609		●
128	CLIP; NYLON TUBE 6SD1 TCN ENG(31L) WHEEL BASE 4600MM(46W),WHEEL BASE 5500MM(55W) (A) L=250	1-09707-126-0	13	1	9610-0006	●
128	CLIP; NYLON TUBE 6SD1 TCN ENG(31L) WHEEL BASE 4600MM(46W),WHEEL BASE 5500MM(55W) (A) L=250	1-09707-126-0	14	1	0007-0106	●
128	CLIP; NYLON TUBE 6SD1 TCN ENG(31L) WHEEL BASE 5600MM(56W) (A) L=250	1-09707-126-0	14	1	0107-	●
128	CLIP; NYLON TUBE WHEEL BASE 6000MM(60W) (A) L=250	1-09707-126-0	08	1	9601-9602	●
128	CLIP; NYLON TUBE 6HE1 TC ENG(57L) WHEEL BASE 4600MM(46W) (A) L=250	1-09707-126-0	15	1	0007-0106	●
128	CLIP; NYLON TUBE 6HK1 TCS ENG(80L) WHEEL BASE 4700MM(47W) (A) L=250	1-09707-126-0	15	1	0107-	●
128	CLIP; NYLON TUBE 6HE1 TC ENG(57L) WHEEL BASE 6000MM(60W) (A) L=250	1-09707-126-0	18	1	9610-9705	●
128	CLIP; NYLON TUBE WHEEL BASE 6000MM(60W) (A) L=250	1-09707-126-0	18	1	9610-9705		●
128	CLIP; NYLON TUBE 6HE1 TC ENG(57L) WHEEL BASE 6000MM(60W) (A) L=250	1-09707-126-0	18	1	9706-9803	●
128	CLIP; NYLON TUBE 6HE1 TC ENG(57L),6HH1 STD ENG(65L) WHEEL BASE 6000MM(60W) (A) L=250	1-09707-126-0	18	1	9706-9803		●
128	CLIP; NYLON TUBE 6HE1 TC ENG(57L) WHEEL BASE 6000MM(60W) (A) L=250	1-09707-126-0	18	1	9804-0106	●
128	CLIP; NYLON TUBE 6SD1 TCN ENG(31L) (A) L=250	1-09707-126-0	01	1	0202-	●
128	CLIP; NYLON TUBE (A) L=250	1-09707-126-0	02	1	9601-9602	●	●
128	CLIP; NYLON TUBE (B) ID=21 L=30 H=40	1-09700-991-1	01	1	9601-9609		●
128	CLIP; NYLON TUBE 6HE1 TC ENG(57L) (B) ID=21 L=30 H=40	1-09700-991-1	01	1	9610-9803	●
128	CLIP; NYLON TUBE (B) ID=21 L=30 H=40	1-09700-991-1	01	1	9610-9803		●
128	CLIP; NYLON TUBE 6HE1 TC ENG(57L) (B) ID=21 L=30 H=40	1-09700-991-1	01	1	9804-9903	●
128	CLIP; NYLON TUBE WHEEL BASE 4600MM(46W) (A) L=250	1-09707-126-0	11	1	9601-9602		●
128	CLIP; NYLON TUBE WHEEL BASE 5500MM(55W) (A) L=250	1-09707-126-0	12	1	9601-9602		●
128	CLIP; NYLON TUBE WHEEL BASE 5500MM(55W) (A) L=250	1-09707-126-0	17	1	9603-9609		●
128	CLIP; NYLON TUBE 6SD1 TCN ENG(31L) WHEEL BASE 6000MM(60W) (A) L=250	1-09707-126-0	15	1	9610-9705	●
128	CLIP; NYLON TUBE 6HE1 TC ENG(57L) WHEEL BASE 4600MM(46W) (A) L=250	1-09707-126-0	15	1	9610-9705	●
128	CLIP; NYLON TUBE WHEEL BASE 4600MM(46W) (A) L=250	1-09707-126-0	15	1	9610-9705		●
128	CLIP; NYLON TUBE 6SD1 TCN ENG(31L) WHEEL BASE 6000MM(60W) (A) L=250	1-09707-126-0	15	1	9706-9803	●
128	CLIP; NYLON TUBE 6HE1 TC ENG(57L) WHEEL BASE 4600MM(46W) (A) L=250	1-09707-126-0	15	1	9706-9803	●
128	CLIP; NYLON TUBE 6HE1 TC ENG(57L),6HH1 STD ENG(65L) WHEEL BASE 4600MM(46W) (A) L=250	1-09707-126-0	15	1	9706-9803		●
128	CLIP; NYLON TUBE 6HE1 TC ENG(57L) WHEEL BASE 4600MM(46W) (A) L=250	1-09707-126-0	15	1	9804-0006	●
128	CLIP; NYLON TUBE 6SD1 TCN ENG(31L) WHEEL BASE 6000MM(60W) (A) L=250	1-09707-126-0	15	1	9804-0006	●
128	CLIP; NYLON TUBE 6SD1 TCN ENG(31L) WHEEL BASE 6000MM(60W) (A) L=250	1-09707-126-0	16	1	0007-0106	●
128	CLIP; NYLON TUBE 6SD1 TCN ENG(31L) WHEEL BASE 6100MM(61W) (A) L=250	1-09707-126-0	16	1	0107-	●
128	CLIP; NYLON TUBE WHEEL BASE 6000MM(60W) (A) L=250	1-09707-126-0	14	1	9601-9602		●
128	CLIP; NYLON TUBE WHEEL BASE 6000MM(60W) (A) L=250	1-09707-126-0	18	1	9603-9609		●
128	CLIP; NYLON TUBE 6HE1 TC ENG(57L) WHEEL BASE 5500MM(55W) (A) L=250	1-09707-126-0	17	1	9610-9705	●
128	CLIP; NYLON TUBE WHEEL BASE 5500MM(55W) (A) L=250	1-09707-126-0	17	1	9610-9705		●
128	CLIP; NYLON TUBE 6HE1 TC ENG(57L) WHEEL BASE 5500MM(55W) (A) L=250	1-09707-126-0	17	1	9706-9803	●
128	CLIP; NYLON TUBE 6HE1 TC ENG(57L),6HH1 STD ENG(65L) WHEEL BASE 5000MM(50W),WHEEL BASE 5500MM(55W) (A) L=250	1-09707-126-0	17	1	9706-9803		●
128	CLIP; NYLON TUBE 6HE1 TC ENG(57L) WHEEL BASE 5500MM(55W) (A) L=250	1-09707-126-0	17	1	9804-0106	●
128	CLIP; NYLON TUBE 6HK1 TCS ENG(80L) WHEEL BASE 5600MM(56W) (A) L=250	1-09707-126-0	17	1	0107-	●
133	BOLT; BRKT M8X25 FLANGE	0-28080-825-0	02	1	9601-9606	●
133	BOLT; BRKT M8X30 FLANGE	0-28680-830-0	02	1	9607-9609	●
133	BOLT; BRKT 6SD1 TCN ENG(31L) M8X30 FLANGE	0-28680-830-0	02	1	9610-0512	●
133	BOLT; BRKT 6SD1 TCN ENG(31L) M8X30 FLANGE	0-28650-830-0	02	1	0601-	●
254	BOLT; PIPE CLIP M8X24.5 W/LK&PL WASHER	8-94279-208-0	02	1	9601-9803	●	●
254	BOLT; PIPE CLIP M8X24.5 W/LK&PL WASHER	8-94279-208-0	02	1	9804-0204	●
254	BOLT; PIPE CLIP M8X20.5 W/LK&PL WASHER	8-94279-207-0	02	1	0205-0205	●
265	CLIP; NYLON TUBE (A) ID=6 H=20 L=20	1-09700-603-0	01	1	9601-9803	●	●
265	CLIP; NYLON TUBE (A) ID=6 H=20 L=20	1-09700-603-0	01	1	9804-9808	●
265	CLIP; NYLON TUBE (B) L=250	1-09707-126-0	01	1	9601-9803	●	●
265	CLIP; NYLON TUBE (B) L=250	1-09707-126-0	01	1	9804-9808	●
266	CLIP; NYLON TUBE L=250	1-09707-126-0	01	1	9804-0006	●
266	CLIP; NYLON TUBE L=250	1-09707-126-0	02	1	0007-0106	●
266	CLIP; NYLON TUBE L=250	1-09707-126-0	01	1	0107-	●
267	BOLT; CLIP BRKT M8X20 FLANGE	0-28080-820-0	01	1	9601-9606	●	●
267	BOLT; CLIP BRKT M8X25 FLANGE	0-28680-825-0	01	1	9607-9803	●	●
267	BOLT; CLIP BRKT M8X25 FLANGE	0-28680-825-0	01	1	9804-9808	●
268	NUT; CLIP BRKT M8	9-09110-408-0	01	1	9601-9606	●	●
268	NUT; CLIP BRKT M8 FLANGE	0-91150-108-0	01	1	9607-9803	●	●
268	NUT; CLIP BRKT M8 FLANGE	0-91150-108-0	01	1	9804-9808	●
286	CLIP; NYLON TUBE (A) L=250	1-09707-126-0	07	1	9603-9609	●
286	CLIP; NYLON TUBE 6SD1 TCN ENG(31L) (A) L=250	1-09707-126-0	07	1	9610-9610	●
286	CLIP; NYLON TUBE 6SD1 TCN ENG(31L) (A) L=250	1-09707-126-0	10	1	9611-0008	●
286	CLIP; NYLON TUBE 6SD1 TCN ENG(31L),6HE1 TC ENG(57L) (A) L=250	1-09707-126-0	11	1	0009-0106	●
286	CLIP; NYLON TUBE 6SD1 TCN ENG(31L) (A) L=250	1-09707-126-0	10	1	0107-	●
286	CLIP; NYLON TUBE 6HK1 TCS ENG(80L) (A) L=250	1-09707-126-0	09	1	0107-	●
286	CLIP; NYLON TUBE 6HK1 TCS ENG(80L) ZF 9S109 OD M/T(Y2L) (B) ID=13 H=40 L=25	1-09700-620-0	01	1	0107-	●
286	CLIP; NYLON TUBE 6SD1 TCN ENG(31L) MAL6S M/T(Y1V) (B) ID=15 L=28	1-09701-216-0	01	1	0105-0106	●
286	CLIP; NYLON TUBE MAL6S M/T(Y1V) (B) ID=15 L=28	1-09701-216-0	01	1	0107-0208	●
286	CLIP; NYLON TUBE MAL6S M/T(Y1V) (B) ID=18 L=28	1-09701-067-0	01	1	0209-	●
286	CLIP; NYLON TUBE (A) L=250	1-09707-126-0	06	1	9603-9609		●
286	CLIP; NYLON TUBE 6HE1 TC ENG(57L) (A) L=250	1-09707-126-0	06	1	9610-9610	●
286	CLIP; NYLON TUBE (A) L=250	1-09707-126-0	06	1	9610-9610		●
286	CLIP; NYLON TUBE 6HE1 TC ENG(57L) (A) L=250	1-09707-126-0	09	1	9611-9803	●
286	CLIP; NYLON TUBE (A) L=250	1-09707-126-0	09	1	9611-9803		●
286	CLIP; NYLON TUBE 6HE1 TC ENG(57L) (A) L=250	1-09707-126-0	09	1	9804-0006	●
286	CLIP; NYLON TUBE 6HE1 TC ENG(57L) (A) L=250	1-09707-126-0	11	1	0007-0008	●
288	BOLT; CLIP,AIR PIPE 6HE1 TC ENG(57L) M8X20 FLANGE	0-28680-820-0	03	1	9807-0106	●
288	BOLT; CLIP,AIR PIPE 6HK1 TCS ENG(80L) M8X20 FLANGE	0-28680-820-0	03	1	0107-0512	●
288	BOLT; CLIP,AIR PIPE 6HK1 TCS ENG(80L) M8X20 FLANGE	0-28650-820-0	03	1	0601-	●
288	BOLT; CLIP,AIR PIPE M8X20 FLANGE	0-28080-820-0	02	1	9601-9606		●
288	BOLT; CLIP,AIR PIPE M8X25 FLANGE	0-28680-825-0	02	1	9607-9705		●
288	BOLT; CLIP,AIR PIPE 6HH1 STD ENG(65L) M8X25 FLANGE	0-28680-825-0	02	1	9706-9712		●
288	BOLT; CLIP,AIR PIPE 6HH1 STD ENG(65L) M8X20 FLANGE	0-28680-820-0	02	1	9801-9803		●
288	BOLT; CLIP,AIR PIPE 6HE1 TC ENG(57L) M8X25 FLANGE	0-28680-825-0	03	1	9706-9712		●
288	BOLT; CLIP,AIR PIPE 6HE1 TC ENG(57L) M8X20 FLANGE	0-28680-820-0	03	1	9801-9803		●
290	NUT; CLIP,AIR PIPE 6HE1 TC ENG(57L) M8 FLANGE	0-91150-108-0	03	1	9807-0106	●
290	NUT; CLIP,AIR PIPE 6HK1 TCS ENG(80L) M8 FLANGE	0-91150-108-0	03	1	0107-0602	●
290	NUT; CLIP,AIR PIPE 6HK1 TCS ENG(80L) M8 FLANGE	0-91180-108-0	03	1	0603-	●
290	NUT; CLIP,AIR PIPE M8	9-09110-408-0	02	1	9601-9606		●
290	NUT; CLIP,AIR PIPE M8 FLANGE	0-91150-108-0	02	1	9607-9705		●
290	NUT; CLIP,AIR PIPE 6HH1 STD ENG(65L) M8 FLANGE	0-91150-108-0	02	1	9706-9803		●
290	NUT; CLIP,AIR PIPE 6HE1 TC ENG(57L) M8 FLANGE	0-91150-108-0	03	1	9706-9803		●
292	CLIP; AIR PIPE AIR DRYER<PS7> ID=6.35 & 15	1-09709-276-1	02	1	9601-9609		●
292	CLIP; AIR PIPE 6HE1 TC ENG(57L) AIR DRYER<PS7> ID=6.35 & 15	1-09709-276-1	02	1	9610-9803	●
292	CLIP; AIR PIPE AIR DRYER<PS7> ID=6.35 & 15	1-09709-276-1	02	1	9610-9803		●
292	CLIP; AIR PIPE 6HE1 TC ENG(57L) AIR DRYER<PS7> ID=6.35 & 15	1-09709-276-1	02	1	9804-0006	●
292	CLIP; AIR PIPE 6HE1 TC ENG(57L) AIR DRYER<PS7> ID=6.35 & 15	1-09709-276-1	03	1	0007-0106	●
292	CLIP; AIR PIPE 6HK1 TCS ENG(80L) ID=6.35 & 15	1-09709-276-1	02	1	0107-	●
295	NUT; CLIP,AIR PIPE WHEEL BASE 5500MM(55W),WHEEL BASE 6000MM(60W) EXC. AIR DRYER<PS7> M8	9-09110-408-0	01	1	9601-9601	●
300	BOLT; TUBE CLIP M8X24.5 W/LK&PL WASHER	8-94279-208-0	02	1	0206-0904	●
300	BOLT; TUBE CLIP M8X24.5 W/LK&PL WASHER	8-98059-720-0	02	1	0905-	●
309	NUT; BRKT FIX M8	9-09110-408-0	02	1	9601-9606	●
309	NUT; BRKT FIX M8 FLANGE	0-91150-108-0	02	1	9607-9609	●
309	NUT; BRKT FIX 6SD1 TCN ENG(31L) M8 FLANGE	0-91150-108-0	02	1	9610-0602	●
309	NUT; BRKT FIX 6SD1 TCN ENG(31L) M8 FLANGE	0-91180-108-0	02	1	0603-	●
309	NUT; BRKT FIX M8 FLANGE	8-94279-517-0	02	1	9601-9611	●	●
309	NUT; BRKT FIX M8 CUTTING NUT W/FLANGE	1-09985-340-0	02	1	9612-9803	●	●
309	NUT; BRKT FIX M8 CUTTING NUT W/FLANGE	1-09985-340-0	02	1	9804-	●
318	CLIP; AIR PIPE AIR DRYER<PS7> ID=6.35 & 6.35	1-09709-273-1	01	1	9601-9609	●
318	CLIP; AIR PIPE 6SD1 TCN ENG(31L) AIR DRYER<PS7> ID=6.35 & 6.35	1-09709-273-1	01	1	9610-0106	●
318	CLIP; AIR PIPE 6SD1 TCN ENG(31L) ID=6.35 & 6.35	1-09709-273-1	01	1	0107-	●
318	CLIP; AIR PIPE ID=6.35 & 15	1-09709-276-1	01	1	9601-9609		●
318	CLIP; AIR PIPE 6HE1 TC ENG(57L) ID=6.35 & 15	1-09709-276-1	01	1	9610-9803	●
318	CLIP; AIR PIPE ID=6.35 & 15	1-09709-276-1	01	1	9610-9803		●
318	CLIP; AIR PIPE 6HE1 TC ENG(57L) ID=6.35 & 15	1-09709-276-1	01	1	9804-0106	●
318	CLIP; AIR PIPE 6HK1 TCS ENG(80L) ID=6.35 & 15	1-09709-276-1	01	1	0107-	●
331	CLIP; NYLON TUBE L=250	1-09707-126-0	02	1	9601-9602	●
331	CLIP; NYLON TUBE L=250	1-09707-126-0	05	1	9603-9603	●
331	CLIP; NYLON TUBE L=250	1-09707-126-0	06	1	9603-9609	●
331	CLIP; NYLON TUBE 6SD1 TCN ENG(31L) L=250	1-09707-126-0	06	1	9610-	●
332	CLIP; BAND L=250	1-09707-126-0	02	1	9604-9803	●	●
332	CLIP; BAND L=250	1-09707-126-0	02	1	9804-	●
333	BRACKET; BRK AIR PIPE (B)	1-79738-815-1	01	1	9601-9803	●	●
333	BRACKET; BRK AIR PIPE (B)	1-79738-815-2	01	1	9804-	●
333	BRACKET; BRK AIR PIPE EXC. AIR DRYER<PS7> (A)	1-47475-427-1	01	1	9601-9803	●	●
333	BRACKET; BRK AIR PIPE EXC. AIR DRYER<PS7> (A)	1-47475-427-1	01	1	9804-0106	●
356	CLIP; AIR PIPE ID=4.8	8-94128-483-0	01	1	9601-9705	●	●
356	CLIP; AIR PIPE ID=4.8	8-94128-483-0	01	1	9706-9803	●
356	CLIP; AIR PIPE AIR SUSP DRIVER SEAT<A56> ID=4.8	8-94128-483-0	01	1	9706-9803		●
356	CLIP; AIR PIPE ID=4.8	8-94128-483-0	01	1	9804-	●
371	BOLT; CLIP,AIR PIPE EXC. AIR DRYER<PS7> M8X50 FLANGE	0-28080-850-0	01	1	9601-9803	●	●
371	BOLT; CLIP,AIR PIPE EXC. AIR DRYER<PS7> M8X50 FLANGE	0-28080-850-0	01	1	9804-0106	●
375	CLIP; AIR PIPE (B) L=250	1-09707-126-0	01	1	9601-9609	●	●
375	CLIP; AIR PIPE 6SD1 TCN ENG(31L) (B) L=250	1-09707-126-0	01	1	9610-9705	●
375	CLIP; AIR PIPE (B) L=250	1-09707-126-0	01	1	9610-9705		●
375	CLIP; AIR PIPE 6SD1 TCN ENG(31L) (B) L=250	1-09707-126-0	01	1	9706-9708	●
375	CLIP; AIR PIPE 6HH1 STD ENG(65L) (B) L=250	1-09707-126-0	01	1	9706-9708		●
375	CLIP; AIR PIPE (B) L=250	1-09707-126-0	01	1	9709-9803	●	●
375	CLIP; AIR PIPE 6SD1 TCN ENG(31L) (B) L=250	1-09707-126-0	01	1	9804-0008	●
375	CLIP; AIR PIPE 6SD1 TCN ENG(31L),6HE1 TC ENG(57L) (B) L=250	1-09707-126-0	01	1	0009-0106	●
375	CLIP; AIR PIPE (B) L=250	1-09707-126-0	01	1	0107-	●
375	CLIP; AIR PIPE (A) ID=14 H=50 L=20	1-09700-843-0	01	1	9601-9705		●
375	CLIP; AIR PIPE 6HE1 TC ENG(57L) (A) ID=14 H=50 L=20	1-09700-843-0	01	1	9706-9803	●
375	CLIP; AIR PIPE (A) ID=14 H=50 L=20	1-09700-843-0	01	1	9706-9803		●
375	CLIP; AIR PIPE 6HE1 TC ENG(57L) (A) ID=9 H=60	1-09700-956-0	01	1	9804-0106	●
375	CLIP; AIR PIPE 6HK1 TCS ENG(80L) (A) ID=9 H=60	1-09700-956-0	01	1	0107-	●

389 388 309 389 388 34 34 333

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date	A	B
34	NUT; BRKT 6SD1 TCN ENG(31L) MAL6S M/T(Y1V) M8 FLANGE	0-91150-108-0	01	1	0105-0106	●
34	NUT; BRKT MAL6S M/T(Y1V) M8 FLANGE	0-91150-108-0	01	1	0107-0602	●
34	NUT; BRKT MAL6S M/T(Y1V) M8 FLANGE	0-91180-108-0	01	1	0603-	●
34	NUT; BRKT M8 FLANGE	8-94279-517-0	03	1	9601-9611	●	●
34	NUT; BRKT M8 CUTTING NUT W/FLANGE	1-09985-340-0	03	1	9612-9803	●	●
34	NUT; BRKT M8 CUTTING NUT W/FLANGE	1-09985-340-0	03	1	9804-	●
309	NUT; BRKT FIX M8	9-09110-408-0	02	1	9601-9606	●
309	NUT; BRKT FIX M8 FLANGE	0-91150-108-0	02	1	9607-9609	●
309	NUT; BRKT FIX 6SD1 TCN ENG(31L) M8 FLANGE	0-91150-108-0	02	1	9610-0602	●
309	NUT; BRKT FIX 6SD1 TCN ENG(31L) M8 FLANGE	0-91180-108-0	02	1	0603-	●
309	NUT; BRKT FIX M8 FLANGE	8-94279-517-0	02	1	9601-9611	●	●
309	NUT; BRKT FIX M8 CUTTING NUT W/FLANGE	1-09985-340-0	02	1	9612-9803	●	●
309	NUT; BRKT FIX M8 CUTTING NUT W/FLANGE	1-09985-340-0	02	1	9804-	●
333	BRACKET; BRK AIR PIPE (B)	1-79738-815-1	01	1	9601-9803	●	●
333	BRACKET; BRK AIR PIPE (B)	1-79738-815-2	01	1	9804-	●
333	BRACKET; BRK AIR PIPE EXC. AIR DRYER<PS7> (A)	1-47475-427-1	01	1	9601-9803	●	●
333	BRACKET; BRK AIR PIPE EXC. AIR DRYER<PS7> (A)	1-47475-427-1	01	1	9804-0106	●
388	SEAL (A) L=280	1-79738-793-1	01	1	9601-9803	●	●
388	SEAL (A) L=280	1-79738-793-1	01	1	9804-	●
388	SEAL (B)	1-79738-826-0	01	1	9601-9803	●	●
388	SEAL (B)	1-79738-826-0	01	1	9804-	●
389	BRACKET; UNION (B)	1-79738-791-2	01	1	9601-9803	●	●
389	BRACKET; UNION (B)	1-79738-814-2	01	1	9804-	●
389	BRACKET; UNION (A)	1-79738-827-1	01	1	9601-9803	●	●
389	BRACKET; UNION (A)	1-79738-827-1	01	1	9804-	●

İpucu: çizimdeki balona veya tablodaki Balon sütununa tıkla; ilgili parçalar vurgulanır. Birden çok çizim varsa üstteki seçim kutusu/oklarla gezin.
