Sayfa 0-52 - Isuzu EPC

0-52 — OIL AND VACUUM PIPING; ENGINE (#24263) — 325 parça

47 2 40 63 47 3 100 44 476 48 47 157 3 2 44 3 47 40 2 147 40 149 150 40

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date	A	B
2	BOLT; EYE,OIL PIPE (A) M10X21 FLANGE	1-09675-077-0	02	1	9811-0201	●
2	BOLT; EYE,OIL PIPE EXC. EURO2 SPECIFICATION<THN> (A) M10X21 FLANGE	1-09675-077-0	02	1	0202-0203	●
2	BOLT; EYE,OIL PIPE (D) M12X33 FLANGE	1-09675-083-0	01	1	9811-0201	●
2	BOLT; EYE,OIL PIPE EXC. EURO2 SPECIFICATION<THN> (D) M12X33 FLANGE	1-09675-083-0	01	1	0202-0203	●
2	BOLT; EYE,OIL PIPE (B) M12X27 FLANGE	1-09675-085-0	01	1	9811-9902	●
2	BOLT; EYE,OIL PIPE (B) M12X27 FLANGE	1-09675-085-0	01	1	9903-	●	●
2	BOLT; EYE,OIL PIPE (C) M12X25	5-09675-006-1	01	1	9811-0201	●
2	BOLT; EYE,OIL PIPE EXC. EURO2 SPECIFICATION<THN> (C) M12X25	5-09675-006-1	01	1	0202-0203	●
2	BOLT; EYE,OIL PIPE (A) M10X21 FLANGE	1-09675-077-0	03	1	9903-0201		●
2	BOLT; EYE,OIL PIPE EURO2 SPECIFICATION<THN> (A) M10X21 FLANGE	1-09675-077-0	03	1	0202-0203	●
2	BOLT; EYE,OIL PIPE (A) M10X21 FLANGE	1-09675-077-0	03	1	0202-0203		●
2	BOLT; EYE,OIL PIPE (A) M10X21 FLANGE	1-09675-077-0	03	1	0204-0805	●	●
2	BOLT; EYE,OIL PIPE (A) M10X21 FLANGE	8-97372-238-0	03	1	0806-	●	●
2	BOLT; EYE,OIL PIPE (E) M14X27 FLANGE	1-09675-086-0	02	1	9903-0201		●
2	BOLT; EYE,OIL PIPE EURO2 SPECIFICATION<THN> (E) M14X27 FLANGE	1-09675-086-0	02	1	0202-0203	●
2	BOLT; EYE,OIL PIPE (E) M14X27 FLANGE	1-09675-086-0	02	1	0202-0203		●
2	BOLT; EYE,OIL PIPE (E) M14X27 FLANGE	1-09675-086-0	02	1	0204-	●	●
3	GASKET; EYE BOLT,OIL PIPE ALSO INCLUDED IN GASKET SET(ENGINE). (D) ID=12.2	1-09630-084-0	06	1	9811-0201	●
3	GASKET; EYE BOLT,OIL PIPE ALSO INCLUDED IN GASKET SET(ENGINE). EXC. EURO2 SPECIFICATION<THN> (D) ID=12.2	1-09630-084-0	06	1	0202-0203	●
3	GASKET; EYE BOLT,OIL PIPE ALSO INCLUDED IN GASKET SET(ENGINE). (B) ID=12.3	1-09623-481-0	01	1	9903-0201		●
3	GASKET; EYE BOLT,OIL PIPE ALSO INCLUDED IN GASKET SET(ENGINE). EURO2 SPECIFICATION<THN>. (B) ID=12.3	1-09623-481-0	01	1	0202-0203	●
3	GASKET; EYE BOLT,OIL PIPE ALSO INCLUDED IN GASKET SET(ENGINE). (B) ID=12.3	1-09623-481-0	01	1	0202-0203		●
3	GASKET; EYE BOLT,OIL PIPE ALSO INCLUDED IN GASKET SET(ENGINE). (B) ID=12.3	1-09623-481-0	01	1	0204-	●	●
3	GASKET; EYE BOLT,OIL PIPE ALSO INCLUDED IN GASKET SET(ENGINE). (A) ID=12.2	1-09630-084-0	02	1	9903-0201		●
3	GASKET; EYE BOLT,OIL PIPE ALSO INCLUDED IN GASKET SET(ENGINE). EURO2 SPECIFICATION<THN>. (A) ID=12.2	1-09630-084-0	02	1	0202-0203	●
3	GASKET; EYE BOLT,OIL PIPE ALSO INCLUDED IN GASKET SET(ENGINE). (A) ID=12.2	1-09630-084-0	02	1	0202-0203		●
3	GASKET; EYE BOLT,OIL PIPE ALSO INCLUDED IN GASKET SET(ENGINE). (A) ID=12.2	1-09630-084-0	02	1	0204-1312	●	●
3	GASKET; EYE BOLT,OIL PIPE ALSO INCLUDED IN GASKET SET(ENGINE). (A) ID=12.2	8-98251-344-0	02	1	1401-	●	●
3	GASKET; EYE BOLT,OIL PIPE ALSO INCLUDED IN GASKET SET(ENGINE). (C) ID=14.2 OD=19.2	1-09630-085-0	02	1	9903-0201		●
3	GASKET; EYE BOLT,OIL PIPE ALSO INCLUDED IN GASKET SET(ENGINE). EURO2 SPECIFICATION<THN>. (C) ID=14.2 OD=19.2	1-09630-085-0	02	1	0202-0203	●
3	GASKET; EYE BOLT,OIL PIPE ALSO INCLUDED IN GASKET SET(ENGINE). (C) ID=14.2 OD=19.2	1-09630-085-0	02	1	0202-0203		●
3	GASKET; EYE BOLT,OIL PIPE ALSO INCLUDED IN GASKET SET(ENGINE). (C) ID=14.2 OD=19.2	1-09630-085-0	02	1	0204-1312	●	●
3	GASKET; EYE BOLT,OIL PIPE ALSO INCLUDED IN GASKET SET(ENGINE). (C) ID=14.2 OD=19.2	8-98251-345-0	02	1	1401-	●	●
40	BOLT; OIL PIPE (A) M8X40 FLANGE	0-28080-840-0	02	1	9811-9902	●
40	BOLT; OIL PIPE (A) M8X40 FLANGE	0-28080-840-0	02	1	9903-0512	●	●
40	BOLT; OIL PIPE (A) M8X40 FLANGE	0-28050-840-0	02	1	0601-	●	●
40	BOLT; OIL PIPE (C) M10X22 FLANGE	0-28181-022-0	02	1	9811-9902	●
40	BOLT; OIL PIPE (C) M10X22 FLANGE	0-28181-022-0	02	1	9903-	●	●
40	BOLT; OIL PIPE (B) M8X30 FLANGE	0-28080-830-0	02	1	9903-0201		●
40	BOLT; OIL PIPE EURO2 SPECIFICATION<THN> (B) M8X30 FLANGE	0-28080-830-0	02	1	0202-0203	●
40	BOLT; OIL PIPE (B) M8X30 FLANGE	0-28080-830-0	02	1	0202-0203		●
40	BOLT; OIL PIPE (B) M8X30 FLANGE	0-28080-830-0	02	1	0204-0512	●	●
40	BOLT; OIL PIPE (B) M8X30 FLANGE	0-28050-830-0	02	1	0601-	●	●
40	BOLT; OIL PIPE (D) M10X16 FLANGE	0-28181-016-0	02	1	9903-0201		●
40	BOLT; OIL PIPE EURO2 SPECIFICATION<THN> (D) M10X16 FLANGE	0-28181-016-0	02	1	0202-0203	●
40	BOLT; OIL PIPE (D) M10X16 FLANGE	0-28181-016-0	02	1	0202-0203		●
40	BOLT; OIL PIPE (D) M10X16 FLANGE	0-28181-016-0	02	1	0204-0512	●	●
40	BOLT; OIL PIPE (D) M10X16 FLANGE	0-28151-016-0	02	1	0601-	●	●
44	BOLT; CLIP,OIL PIPE (C) M6X22 FLANGE	0-28080-622-0	01	1	9811-0201	●
44	BOLT; CLIP,OIL PIPE EXC. EURO2 SPECIFICATION<THN> (C) M6X22 FLANGE	0-28080-622-0	01	1	0202-0203	●
44	BOLT; CLIP,OIL PIPE (B) M8X12 FLANGE	0-28080-812-0	01	1	9811-9812	●
44	BOLT; CLIP,OIL PIPE (A) M6X35 FLANGE	0-28680-635-0	02	1	9901-0201	●
44	BOLT; CLIP,OIL PIPE EXC. EURO2 SPECIFICATION<THN> (A) M6X35 FLANGE	0-28680-635-0	02	1	0202-0203	●
44	BOLT; CLIP,OIL PIPE (A) M8X16 FLANGE	0-28080-816-0	02	1	9811-9812	●
44	BOLT; CLIP,OIL PIPE (B) M8X16 FLANGE	0-28080-816-0	01	1	9901-9902	●
44	BOLT; CLIP,OIL PIPE (A) M8X12 FLANGE	0-28080-812-0	01	1	9903-0201		●
44	BOLT; CLIP,OIL PIPE EURO2 SPECIFICATION<THN> (A) M8X12 FLANGE	0-28080-812-0	01	1	0202-0203	●
44	BOLT; CLIP,OIL PIPE (A) M8X12 FLANGE	0-28080-812-0	01	1	0202-0203		●
44	BOLT; CLIP,OIL PIPE (A) M8X12 FLANGE	0-28080-812-0	01	1	0204-0512	●	●
44	BOLT; CLIP,OIL PIPE (A) M8X12 FLANGE	0-28050-812-0	01	1	0601-	●	●
44	BOLT; CLIP,OIL PIPE (B) M8X16 FLANGE	0-28080-816-0	01	1	9903-0512	●	●
44	BOLT; CLIP,OIL PIPE (B) M8X16 FLANGE	0-28050-816-0	01	1	0601-	●	●
47	GASKET; OIL PIPE ALSO INCLUDED IN GASKET SET(ENG. & HEAD) (A) ID=10.2 OD=15.2	1-09630-083-0	02	1	9903-0201		●
47	GASKET; OIL PIPE ALSO INCLUDED IN GASKET SET(ENG. & HEAD) EURO2 SPECIFICATION<THN> ALSO INCLUDED IN GASKET SET(ENG. & HEAD) (A) ID=10.2 OD=15.2	1-09630-083-0	02	1	0202-0203	●
47	GASKET; OIL PIPE ALSO INCLUDED IN GASKET SET(ENG. & HEAD) (A) ID=10.2 OD=15.2	1-09630-083-0	02	1	0202-0203		●
47	GASKET; OIL PIPE ALSO INCLUDED IN GASKET SET(ENG. & HEAD) (A) ID=10.2 OD=15.2	1-09630-083-0	02	1	0204-	●	●
47	GASKET; OIL PIPE ALSO INCLUDED IN GASKET SET(ENG. & HEAD) (B) ID=14.2 OD=19.2	1-09630-085-0	02	1	9903-0201		●
47	GASKET; OIL PIPE ALSO INCLUDED IN GASKET SET(ENG. & HEAD) EURO2 SPECIFICATION<THN> ALSO INCLUDED IN GASKET SET(ENG. & HEAD) (B) ID=14.2 OD=19.2	1-09630-085-0	02	1	0202-0203	●
47	GASKET; OIL PIPE ALSO INCLUDED IN GASKET SET(ENG. & HEAD) (B) ID=14.2 OD=19.2	1-09630-085-0	02	1	0202-0203		●
47	GASKET; OIL PIPE ALSO INCLUDED IN GASKET SET(ENG. & HEAD) (B) ID=14.2 OD=19.2	1-09630-085-0	02	1	0204-1312	●	●
47	GASKET; OIL PIPE ALSO INCLUDED IN GASKET SET(ENG. & HEAD) (B) ID=14.2 OD=19.2	8-98251-345-0	02	1	1401-	●	●
48	CLIP; OIL PIPE (A)	1-09701-265-0	01	1	9901-0201	●
48	CLIP; OIL PIPE EXC. EURO2 SPECIFICATION<THN> (A)	1-09701-265-0	01	1	0202-0203	●
48	CLIP; OIL PIPE (B)	8-94396-860-0	01	1	9901-0201	●
48	CLIP; OIL PIPE EXC. EURO2 SPECIFICATION<THN> (B)	8-94396-860-0	01	1	0202-0203	●
48	CLIP; OIL PIPE (A)	1-09701-091-0	01	1	9903-0201		●
48	CLIP; OIL PIPE (A)	1-09701-091-0	01	1	0202-	●	●
48	CLIP; OIL PIPE (B)	8-94395-170-0	01	1	9903-0201		●
48	CLIP; OIL PIPE EURO2 SPECIFICATION<THN> (B)	8-94395-170-0	01	1	0202-0203	●
48	CLIP; OIL PIPE (B)	8-94395-170-0	01	1	0202-0203		●
48	CLIP; OIL PIPE (B)	8-94395-170-0	01	1	0204-	●	●
63	PIPE; OIL,TURBOCHARGER FEED (B)	8-94301-581-0	01	1	9811-9812	●
63	PIPE; OIL,TURBOCHARGER FEED (B)	8-97600-198-0	01	1	9901-0201	●
63	PIPE; OIL,TURBOCHARGER FEED EXC. EURO2 SPECIFICATION<THN> (B)	8-97600-198-0	01	1	0202-0203	●
63	PIPE; OIL,TURBOCHARGER FEED (A)	8-94395-102-0	01	1	9811-0201	●
63	PIPE; OIL,TURBOCHARGER FEED EXC. EURO2 SPECIFICATION<THN> (A)	8-94395-102-0	01	1	0202-0203	●
63	PIPE; OIL,TURBOCHARGER FEED (C)	8-94392-976-0	01	1	9903-0201		●
63	PIPE; OIL,TURBOCHARGER FEED (C)	8-94392-976-0	01	1	0202-	●	●
100	BOLT; CLIP (B) M6X16 FLANGE	0-28080-616-0	01	1	9903-0201		●
100	BOLT; CLIP EURO2 SPECIFICATION<THN> (B) M6X16 FLANGE	0-28080-616-0	01	1	0202-0203	●
100	BOLT; CLIP (B) M6X16 FLANGE	0-28080-616-0	01	1	0202-0203		●
100	BOLT; CLIP (B) M6X16 FLANGE	0-28080-616-0	01	1	0204-0512	●	●
100	BOLT; CLIP (B) M6X16 FLANGE	0-28050-616-0	01	1	0601-	●	●
100	BOLT; CLIP (A) M6X22 FLANGE	0-28080-622-0	01	1	9903-0201		●
100	BOLT; CLIP (A) M6X22 FLANGE	0-28080-622-0	01	1	0202-	●	●
147	GASKET; OIL PIPE TO TURBOCHARGER ALSO INCLUDED IN GASKET SET(ENGINE).	1-09637-058-1	01	1	9811-9902	●
147	GASKET; OIL PIPE TO TURBOCHARGER ALSO INCLUDED IN GASKET SET(ENGINE).	1-09637-058-2	01	1	9903-	●	●
149	PIPE; OIL RETURN,TURBOCHARGER	8-94395-380-0	01	1	9811-0201	●
149	PIPE; OIL RETURN,TURBOCHARGER EXC. EURO2 SPECIFICATION<THN>	8-94395-380-0	01	1	0202-0203	●
149	PIPE; OIL RETURN,TURBOCHARGER	8-94392-977-0	01	1	9903-0201		●
149	PIPE; OIL RETURN,TURBOCHARGER	8-94392-977-0	01	1	0202-	●	●
150	GASKET; OIL PIPE TO C/BL ALSO INCLUDED IN GASKET SET(ENGINE). ID=30	8-94394-671-0	01	1	9811-9902	●
150	GASKET; OIL PIPE TO C/BL ALSO INCLUDED IN GASKET SET(ENGINE). ID=30	8-94394-671-0	01	1	9903-	●	●
157	BRACKET; OIL PIPE	8-94395-168-0	01	1	9903-0201		●
157	BRACKET; OIL PIPE EURO2 SPECIFICATION<THN>	8-94395-168-0	01	1	0202-0203	●
157	BRACKET; OIL PIPE	8-94395-168-0	01	1	0202-0203		●
157	BRACKET; OIL PIPE	8-94395-168-0	01	1	0204-	●	●
476	PIPE; OIL,C/BL TO AIR CMPR	8-94394-940-1	01	1	9903-0201		●
476	PIPE; OIL,C/BL TO AIR CMPR EURO2 SPECIFICATION<THN>	8-94394-940-1	01	1	0202-0203	●
476	PIPE; OIL,C/BL TO AIR CMPR	8-94394-940-1	01	1	0202-0203		●
476	PIPE; OIL,C/BL TO AIR CMPR	8-94394-940-1	01	1	0204-	●	●

117 117 44 117 2 117 115 1 2 3 452 3 261 2

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date	A	B
1	PIPE; OIL,INJ PUMP TO C/BL	8-94394-276-0	01	1	9811-0201	●
1	PIPE; OIL,INJ PUMP TO C/BL EXC. EURO2 SPECIFICATION<THN>	8-94394-276-0	01	1	0202-0203	●
1	PIPE; OIL,INJ PUMP TO C/BL	8-94395-795-0	01	1	9903-0201		●
1	PIPE; OIL,INJ PUMP TO C/BL EURO2 SPECIFICATION<THN>	8-94395-795-0	01	1	0202-0203	●
1	PIPE; OIL,INJ PUMP TO C/BL	8-94395-795-0	01	1	0202-0203		●
1	PIPE; OIL,INJ PUMP TO C/BL	8-94395-795-0	01	1	0204-	●	●
2	BOLT; EYE,OIL PIPE (A) M10X21 FLANGE	1-09675-077-0	02	1	9811-0201	●
2	BOLT; EYE,OIL PIPE EXC. EURO2 SPECIFICATION<THN> (A) M10X21 FLANGE	1-09675-077-0	02	1	0202-0203	●
2	BOLT; EYE,OIL PIPE (D) M12X33 FLANGE	1-09675-083-0	01	1	9811-0201	●
2	BOLT; EYE,OIL PIPE EXC. EURO2 SPECIFICATION<THN> (D) M12X33 FLANGE	1-09675-083-0	01	1	0202-0203	●
2	BOLT; EYE,OIL PIPE (B) M12X27 FLANGE	1-09675-085-0	01	1	9811-9902	●
2	BOLT; EYE,OIL PIPE (B) M12X27 FLANGE	1-09675-085-0	01	1	9903-	●	●
2	BOLT; EYE,OIL PIPE (C) M12X25	5-09675-006-1	01	1	9811-0201	●
2	BOLT; EYE,OIL PIPE EXC. EURO2 SPECIFICATION<THN> (C) M12X25	5-09675-006-1	01	1	0202-0203	●
2	BOLT; EYE,OIL PIPE (A) M10X21 FLANGE	1-09675-077-0	03	1	9903-0201		●
2	BOLT; EYE,OIL PIPE EURO2 SPECIFICATION<THN> (A) M10X21 FLANGE	1-09675-077-0	03	1	0202-0203	●
2	BOLT; EYE,OIL PIPE (A) M10X21 FLANGE	1-09675-077-0	03	1	0202-0203		●
2	BOLT; EYE,OIL PIPE (A) M10X21 FLANGE	1-09675-077-0	03	1	0204-0805	●	●
2	BOLT; EYE,OIL PIPE (A) M10X21 FLANGE	8-97372-238-0	03	1	0806-	●	●
2	BOLT; EYE,OIL PIPE (E) M14X27 FLANGE	1-09675-086-0	02	1	9903-0201		●
2	BOLT; EYE,OIL PIPE EURO2 SPECIFICATION<THN> (E) M14X27 FLANGE	1-09675-086-0	02	1	0202-0203	●
2	BOLT; EYE,OIL PIPE (E) M14X27 FLANGE	1-09675-086-0	02	1	0202-0203		●
2	BOLT; EYE,OIL PIPE (E) M14X27 FLANGE	1-09675-086-0	02	1	0204-	●	●
3	GASKET; EYE BOLT,OIL PIPE ALSO INCLUDED IN GASKET SET(ENGINE). (D) ID=12.2	1-09630-084-0	06	1	9811-0201	●
3	GASKET; EYE BOLT,OIL PIPE ALSO INCLUDED IN GASKET SET(ENGINE). EXC. EURO2 SPECIFICATION<THN> (D) ID=12.2	1-09630-084-0	06	1	0202-0203	●
3	GASKET; EYE BOLT,OIL PIPE ALSO INCLUDED IN GASKET SET(ENGINE). (B) ID=12.3	1-09623-481-0	01	1	9903-0201		●
3	GASKET; EYE BOLT,OIL PIPE ALSO INCLUDED IN GASKET SET(ENGINE). EURO2 SPECIFICATION<THN>. (B) ID=12.3	1-09623-481-0	01	1	0202-0203	●
3	GASKET; EYE BOLT,OIL PIPE ALSO INCLUDED IN GASKET SET(ENGINE). (B) ID=12.3	1-09623-481-0	01	1	0202-0203		●
3	GASKET; EYE BOLT,OIL PIPE ALSO INCLUDED IN GASKET SET(ENGINE). (B) ID=12.3	1-09623-481-0	01	1	0204-	●	●
3	GASKET; EYE BOLT,OIL PIPE ALSO INCLUDED IN GASKET SET(ENGINE). (A) ID=12.2	1-09630-084-0	02	1	9903-0201		●
3	GASKET; EYE BOLT,OIL PIPE ALSO INCLUDED IN GASKET SET(ENGINE). EURO2 SPECIFICATION<THN>. (A) ID=12.2	1-09630-084-0	02	1	0202-0203	●
3	GASKET; EYE BOLT,OIL PIPE ALSO INCLUDED IN GASKET SET(ENGINE). (A) ID=12.2	1-09630-084-0	02	1	0202-0203		●
3	GASKET; EYE BOLT,OIL PIPE ALSO INCLUDED IN GASKET SET(ENGINE). (A) ID=12.2	1-09630-084-0	02	1	0204-1312	●	●
3	GASKET; EYE BOLT,OIL PIPE ALSO INCLUDED IN GASKET SET(ENGINE). (A) ID=12.2	8-98251-344-0	02	1	1401-	●	●
3	GASKET; EYE BOLT,OIL PIPE ALSO INCLUDED IN GASKET SET(ENGINE). (C) ID=14.2 OD=19.2	1-09630-085-0	02	1	9903-0201		●
3	GASKET; EYE BOLT,OIL PIPE ALSO INCLUDED IN GASKET SET(ENGINE). EURO2 SPECIFICATION<THN>. (C) ID=14.2 OD=19.2	1-09630-085-0	02	1	0202-0203	●
3	GASKET; EYE BOLT,OIL PIPE ALSO INCLUDED IN GASKET SET(ENGINE). (C) ID=14.2 OD=19.2	1-09630-085-0	02	1	0202-0203		●
3	GASKET; EYE BOLT,OIL PIPE ALSO INCLUDED IN GASKET SET(ENGINE). (C) ID=14.2 OD=19.2	1-09630-085-0	02	1	0204-1312	●	●
3	GASKET; EYE BOLT,OIL PIPE ALSO INCLUDED IN GASKET SET(ENGINE). (C) ID=14.2 OD=19.2	8-98251-345-0	02	1	1401-	●	●
44	BOLT; CLIP,OIL PIPE (C) M6X22 FLANGE	0-28080-622-0	01	1	9811-0201	●
44	BOLT; CLIP,OIL PIPE EXC. EURO2 SPECIFICATION<THN> (C) M6X22 FLANGE	0-28080-622-0	01	1	0202-0203	●
44	BOLT; CLIP,OIL PIPE (B) M8X12 FLANGE	0-28080-812-0	01	1	9811-9812	●
44	BOLT; CLIP,OIL PIPE (A) M6X35 FLANGE	0-28680-635-0	02	1	9901-0201	●
44	BOLT; CLIP,OIL PIPE EXC. EURO2 SPECIFICATION<THN> (A) M6X35 FLANGE	0-28680-635-0	02	1	0202-0203	●
44	BOLT; CLIP,OIL PIPE (A) M8X16 FLANGE	0-28080-816-0	02	1	9811-9812	●
44	BOLT; CLIP,OIL PIPE (B) M8X16 FLANGE	0-28080-816-0	01	1	9901-9902	●
44	BOLT; CLIP,OIL PIPE (A) M8X12 FLANGE	0-28080-812-0	01	1	9903-0201		●
44	BOLT; CLIP,OIL PIPE EURO2 SPECIFICATION<THN> (A) M8X12 FLANGE	0-28080-812-0	01	1	0202-0203	●
44	BOLT; CLIP,OIL PIPE (A) M8X12 FLANGE	0-28080-812-0	01	1	0202-0203		●
44	BOLT; CLIP,OIL PIPE (A) M8X12 FLANGE	0-28080-812-0	01	1	0204-0512	●	●
44	BOLT; CLIP,OIL PIPE (A) M8X12 FLANGE	0-28050-812-0	01	1	0601-	●	●
44	BOLT; CLIP,OIL PIPE (B) M8X16 FLANGE	0-28080-816-0	01	1	9903-0512	●	●
44	BOLT; CLIP,OIL PIPE (B) M8X16 FLANGE	0-28050-816-0	01	1	0601-	●	●
115	CLIP; PIPE,INJ PUMP	1-09701-091-0	01	1	9811-0201	●
115	CLIP; PIPE,INJ PUMP EXC. EURO2 SPECIFICATION<THN>	1-09701-091-0	01	1	0202-0203	●
117	GASKET; JOINT,OIL PIPE ALSO INCLUDED IN GASKET SET(ENG. & HEAD) ID=10.2 OD=15.2	1-09630-083-0	04	1	9811-9902	●
117	GASKET; JOINT,OIL PIPE ALSO INCLUDED IN GASKET SET(ENG. & HEAD) ID=10.2 OD=15.2	1-09630-083-0	04	1	9903-	●	●
261	BRACKET; CLIP,OIL PIPE	8-94394-410-3	01	1	9811-0201	●
261	BRACKET; CLIP,OIL PIPE EXC. EURO2 SPECIFICATION<THN>	8-94394-410-3	01	1	0202-0203	●
452	PIPE; OIL,OIL FILTER TO AIR CMPR	8-94390-073-0	01	1	9811-9906	●
452	PIPE; OIL,OIL FILTER TO AIR CMPR	8-97600-569-0	01	1	9907-0201	●
452	PIPE; OIL,OIL FILTER TO AIR CMPR EXC. EURO2 SPECIFICATION<THN>	8-97600-569-0	01	1	0202-0203	●

63 44 2 3 3 44 63 3 3 2 147 44 48 149 44 40 40 48 384 150 404

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date	A	B
2	BOLT; EYE,OIL PIPE (A) M10X21 FLANGE	1-09675-077-0	02	1	9811-0201	●
2	BOLT; EYE,OIL PIPE EXC. EURO2 SPECIFICATION<THN> (A) M10X21 FLANGE	1-09675-077-0	02	1	0202-0203	●
2	BOLT; EYE,OIL PIPE (D) M12X33 FLANGE	1-09675-083-0	01	1	9811-0201	●
2	BOLT; EYE,OIL PIPE EXC. EURO2 SPECIFICATION<THN> (D) M12X33 FLANGE	1-09675-083-0	01	1	0202-0203	●
2	BOLT; EYE,OIL PIPE (B) M12X27 FLANGE	1-09675-085-0	01	1	9811-9902	●
2	BOLT; EYE,OIL PIPE (B) M12X27 FLANGE	1-09675-085-0	01	1	9903-	●	●
2	BOLT; EYE,OIL PIPE (C) M12X25	5-09675-006-1	01	1	9811-0201	●
2	BOLT; EYE,OIL PIPE EXC. EURO2 SPECIFICATION<THN> (C) M12X25	5-09675-006-1	01	1	0202-0203	●
2	BOLT; EYE,OIL PIPE (A) M10X21 FLANGE	1-09675-077-0	03	1	9903-0201		●
2	BOLT; EYE,OIL PIPE EURO2 SPECIFICATION<THN> (A) M10X21 FLANGE	1-09675-077-0	03	1	0202-0203	●
2	BOLT; EYE,OIL PIPE (A) M10X21 FLANGE	1-09675-077-0	03	1	0202-0203		●
2	BOLT; EYE,OIL PIPE (A) M10X21 FLANGE	1-09675-077-0	03	1	0204-0805	●	●
2	BOLT; EYE,OIL PIPE (A) M10X21 FLANGE	8-97372-238-0	03	1	0806-	●	●
2	BOLT; EYE,OIL PIPE (E) M14X27 FLANGE	1-09675-086-0	02	1	9903-0201		●
2	BOLT; EYE,OIL PIPE EURO2 SPECIFICATION<THN> (E) M14X27 FLANGE	1-09675-086-0	02	1	0202-0203	●
2	BOLT; EYE,OIL PIPE (E) M14X27 FLANGE	1-09675-086-0	02	1	0202-0203		●
2	BOLT; EYE,OIL PIPE (E) M14X27 FLANGE	1-09675-086-0	02	1	0204-	●	●
3	GASKET; EYE BOLT,OIL PIPE ALSO INCLUDED IN GASKET SET(ENGINE). (D) ID=12.2	1-09630-084-0	06	1	9811-0201	●
3	GASKET; EYE BOLT,OIL PIPE ALSO INCLUDED IN GASKET SET(ENGINE). EXC. EURO2 SPECIFICATION<THN> (D) ID=12.2	1-09630-084-0	06	1	0202-0203	●
3	GASKET; EYE BOLT,OIL PIPE ALSO INCLUDED IN GASKET SET(ENGINE). (B) ID=12.3	1-09623-481-0	01	1	9903-0201		●
3	GASKET; EYE BOLT,OIL PIPE ALSO INCLUDED IN GASKET SET(ENGINE). EURO2 SPECIFICATION<THN>. (B) ID=12.3	1-09623-481-0	01	1	0202-0203	●
3	GASKET; EYE BOLT,OIL PIPE ALSO INCLUDED IN GASKET SET(ENGINE). (B) ID=12.3	1-09623-481-0	01	1	0202-0203		●
3	GASKET; EYE BOLT,OIL PIPE ALSO INCLUDED IN GASKET SET(ENGINE). (B) ID=12.3	1-09623-481-0	01	1	0204-	●	●
3	GASKET; EYE BOLT,OIL PIPE ALSO INCLUDED IN GASKET SET(ENGINE). (A) ID=12.2	1-09630-084-0	02	1	9903-0201		●
3	GASKET; EYE BOLT,OIL PIPE ALSO INCLUDED IN GASKET SET(ENGINE). EURO2 SPECIFICATION<THN>. (A) ID=12.2	1-09630-084-0	02	1	0202-0203	●
3	GASKET; EYE BOLT,OIL PIPE ALSO INCLUDED IN GASKET SET(ENGINE). (A) ID=12.2	1-09630-084-0	02	1	0202-0203		●
3	GASKET; EYE BOLT,OIL PIPE ALSO INCLUDED IN GASKET SET(ENGINE). (A) ID=12.2	1-09630-084-0	02	1	0204-1312	●	●
3	GASKET; EYE BOLT,OIL PIPE ALSO INCLUDED IN GASKET SET(ENGINE). (A) ID=12.2	8-98251-344-0	02	1	1401-	●	●
3	GASKET; EYE BOLT,OIL PIPE ALSO INCLUDED IN GASKET SET(ENGINE). (C) ID=14.2 OD=19.2	1-09630-085-0	02	1	9903-0201		●
3	GASKET; EYE BOLT,OIL PIPE ALSO INCLUDED IN GASKET SET(ENGINE). EURO2 SPECIFICATION<THN>. (C) ID=14.2 OD=19.2	1-09630-085-0	02	1	0202-0203	●
3	GASKET; EYE BOLT,OIL PIPE ALSO INCLUDED IN GASKET SET(ENGINE). (C) ID=14.2 OD=19.2	1-09630-085-0	02	1	0202-0203		●
3	GASKET; EYE BOLT,OIL PIPE ALSO INCLUDED IN GASKET SET(ENGINE). (C) ID=14.2 OD=19.2	1-09630-085-0	02	1	0204-1312	●	●
3	GASKET; EYE BOLT,OIL PIPE ALSO INCLUDED IN GASKET SET(ENGINE). (C) ID=14.2 OD=19.2	8-98251-345-0	02	1	1401-	●	●
40	BOLT; OIL PIPE (A) M8X40 FLANGE	0-28080-840-0	02	1	9811-9902	●
40	BOLT; OIL PIPE (A) M8X40 FLANGE	0-28080-840-0	02	1	9903-0512	●	●
40	BOLT; OIL PIPE (A) M8X40 FLANGE	0-28050-840-0	02	1	0601-	●	●
40	BOLT; OIL PIPE (C) M10X22 FLANGE	0-28181-022-0	02	1	9811-9902	●
40	BOLT; OIL PIPE (C) M10X22 FLANGE	0-28181-022-0	02	1	9903-	●	●
40	BOLT; OIL PIPE (B) M8X30 FLANGE	0-28080-830-0	02	1	9903-0201		●
40	BOLT; OIL PIPE EURO2 SPECIFICATION<THN> (B) M8X30 FLANGE	0-28080-830-0	02	1	0202-0203	●
40	BOLT; OIL PIPE (B) M8X30 FLANGE	0-28080-830-0	02	1	0202-0203		●
40	BOLT; OIL PIPE (B) M8X30 FLANGE	0-28080-830-0	02	1	0204-0512	●	●
40	BOLT; OIL PIPE (B) M8X30 FLANGE	0-28050-830-0	02	1	0601-	●	●
40	BOLT; OIL PIPE (D) M10X16 FLANGE	0-28181-016-0	02	1	9903-0201		●
40	BOLT; OIL PIPE EURO2 SPECIFICATION<THN> (D) M10X16 FLANGE	0-28181-016-0	02	1	0202-0203	●
40	BOLT; OIL PIPE (D) M10X16 FLANGE	0-28181-016-0	02	1	0202-0203		●
40	BOLT; OIL PIPE (D) M10X16 FLANGE	0-28181-016-0	02	1	0204-0512	●	●
40	BOLT; OIL PIPE (D) M10X16 FLANGE	0-28151-016-0	02	1	0601-	●	●
44	BOLT; CLIP,OIL PIPE (C) M6X22 FLANGE	0-28080-622-0	01	1	9811-0201	●
44	BOLT; CLIP,OIL PIPE EXC. EURO2 SPECIFICATION<THN> (C) M6X22 FLANGE	0-28080-622-0	01	1	0202-0203	●
44	BOLT; CLIP,OIL PIPE (B) M8X12 FLANGE	0-28080-812-0	01	1	9811-9812	●
44	BOLT; CLIP,OIL PIPE (A) M6X35 FLANGE	0-28680-635-0	02	1	9901-0201	●
44	BOLT; CLIP,OIL PIPE EXC. EURO2 SPECIFICATION<THN> (A) M6X35 FLANGE	0-28680-635-0	02	1	0202-0203	●
44	BOLT; CLIP,OIL PIPE (A) M8X16 FLANGE	0-28080-816-0	02	1	9811-9812	●
44	BOLT; CLIP,OIL PIPE (B) M8X16 FLANGE	0-28080-816-0	01	1	9901-9902	●
44	BOLT; CLIP,OIL PIPE (A) M8X12 FLANGE	0-28080-812-0	01	1	9903-0201		●
44	BOLT; CLIP,OIL PIPE EURO2 SPECIFICATION<THN> (A) M8X12 FLANGE	0-28080-812-0	01	1	0202-0203	●
44	BOLT; CLIP,OIL PIPE (A) M8X12 FLANGE	0-28080-812-0	01	1	0202-0203		●
44	BOLT; CLIP,OIL PIPE (A) M8X12 FLANGE	0-28080-812-0	01	1	0204-0512	●	●
44	BOLT; CLIP,OIL PIPE (A) M8X12 FLANGE	0-28050-812-0	01	1	0601-	●	●
44	BOLT; CLIP,OIL PIPE (B) M8X16 FLANGE	0-28080-816-0	01	1	9903-0512	●	●
44	BOLT; CLIP,OIL PIPE (B) M8X16 FLANGE	0-28050-816-0	01	1	0601-	●	●
48	CLIP; OIL PIPE (A)	1-09701-265-0	01	1	9901-0201	●
48	CLIP; OIL PIPE EXC. EURO2 SPECIFICATION<THN> (A)	1-09701-265-0	01	1	0202-0203	●
48	CLIP; OIL PIPE (B)	8-94396-860-0	01	1	9901-0201	●
48	CLIP; OIL PIPE EXC. EURO2 SPECIFICATION<THN> (B)	8-94396-860-0	01	1	0202-0203	●
48	CLIP; OIL PIPE (A)	1-09701-091-0	01	1	9903-0201		●
48	CLIP; OIL PIPE (A)	1-09701-091-0	01	1	0202-	●	●
48	CLIP; OIL PIPE (B)	8-94395-170-0	01	1	9903-0201		●
48	CLIP; OIL PIPE EURO2 SPECIFICATION<THN> (B)	8-94395-170-0	01	1	0202-0203	●
48	CLIP; OIL PIPE (B)	8-94395-170-0	01	1	0202-0203		●
48	CLIP; OIL PIPE (B)	8-94395-170-0	01	1	0204-	●	●
63	PIPE; OIL,TURBOCHARGER FEED (B)	8-94301-581-0	01	1	9811-9812	●
63	PIPE; OIL,TURBOCHARGER FEED (B)	8-97600-198-0	01	1	9901-0201	●
63	PIPE; OIL,TURBOCHARGER FEED EXC. EURO2 SPECIFICATION<THN> (B)	8-97600-198-0	01	1	0202-0203	●
63	PIPE; OIL,TURBOCHARGER FEED (A)	8-94395-102-0	01	1	9811-0201	●
63	PIPE; OIL,TURBOCHARGER FEED EXC. EURO2 SPECIFICATION<THN> (A)	8-94395-102-0	01	1	0202-0203	●
63	PIPE; OIL,TURBOCHARGER FEED (C)	8-94392-976-0	01	1	9903-0201		●
63	PIPE; OIL,TURBOCHARGER FEED (C)	8-94392-976-0	01	1	0202-	●	●
147	GASKET; OIL PIPE TO TURBOCHARGER ALSO INCLUDED IN GASKET SET(ENGINE).	1-09637-058-1	01	1	9811-9902	●
147	GASKET; OIL PIPE TO TURBOCHARGER ALSO INCLUDED IN GASKET SET(ENGINE).	1-09637-058-2	01	1	9903-	●	●
149	PIPE; OIL RETURN,TURBOCHARGER	8-94395-380-0	01	1	9811-0201	●
149	PIPE; OIL RETURN,TURBOCHARGER EXC. EURO2 SPECIFICATION<THN>	8-94395-380-0	01	1	0202-0203	●
149	PIPE; OIL RETURN,TURBOCHARGER	8-94392-977-0	01	1	9903-0201		●
149	PIPE; OIL RETURN,TURBOCHARGER	8-94392-977-0	01	1	0202-	●	●
150	GASKET; OIL PIPE TO C/BL ALSO INCLUDED IN GASKET SET(ENGINE). ID=30	8-94394-671-0	01	1	9811-9902	●
150	GASKET; OIL PIPE TO C/BL ALSO INCLUDED IN GASKET SET(ENGINE). ID=30	8-94394-671-0	01	1	9903-	●	●
384	BRACKET; CLIP,OIL PIPE,TURBOCHARGER	8-97600-199-0	01	1	9901-0201	●
384	BRACKET; CLIP,OIL PIPE,TURBOCHARGER EXC. EURO2 SPECIFICATION<THN>	8-97600-199-0	01	1	0202-0203	●
404	BOLT; BRKT M8X12 FLANGE	0-28080-812-0	02	1	9901-0201	●
404	BOLT; BRKT EXC. EURO2 SPECIFICATION<THN> M8X12 FLANGE	0-28080-812-0	02	1	0202-0203	●

3 117 117 117 3 117 2 1 2 475 100 48 2

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date	A	B
1	PIPE; OIL,INJ PUMP TO C/BL	8-94394-276-0	01	1	9811-0201	●
1	PIPE; OIL,INJ PUMP TO C/BL EXC. EURO2 SPECIFICATION<THN>	8-94394-276-0	01	1	0202-0203	●
1	PIPE; OIL,INJ PUMP TO C/BL	8-94395-795-0	01	1	9903-0201		●
1	PIPE; OIL,INJ PUMP TO C/BL EURO2 SPECIFICATION<THN>	8-94395-795-0	01	1	0202-0203	●
1	PIPE; OIL,INJ PUMP TO C/BL	8-94395-795-0	01	1	0202-0203		●
1	PIPE; OIL,INJ PUMP TO C/BL	8-94395-795-0	01	1	0204-	●	●
2	BOLT; EYE,OIL PIPE (A) M10X21 FLANGE	1-09675-077-0	02	1	9811-0201	●
2	BOLT; EYE,OIL PIPE EXC. EURO2 SPECIFICATION<THN> (A) M10X21 FLANGE	1-09675-077-0	02	1	0202-0203	●
2	BOLT; EYE,OIL PIPE (D) M12X33 FLANGE	1-09675-083-0	01	1	9811-0201	●
2	BOLT; EYE,OIL PIPE EXC. EURO2 SPECIFICATION<THN> (D) M12X33 FLANGE	1-09675-083-0	01	1	0202-0203	●
2	BOLT; EYE,OIL PIPE (B) M12X27 FLANGE	1-09675-085-0	01	1	9811-9902	●
2	BOLT; EYE,OIL PIPE (B) M12X27 FLANGE	1-09675-085-0	01	1	9903-	●	●
2	BOLT; EYE,OIL PIPE (C) M12X25	5-09675-006-1	01	1	9811-0201	●
2	BOLT; EYE,OIL PIPE EXC. EURO2 SPECIFICATION<THN> (C) M12X25	5-09675-006-1	01	1	0202-0203	●
2	BOLT; EYE,OIL PIPE (A) M10X21 FLANGE	1-09675-077-0	03	1	9903-0201		●
2	BOLT; EYE,OIL PIPE EURO2 SPECIFICATION<THN> (A) M10X21 FLANGE	1-09675-077-0	03	1	0202-0203	●
2	BOLT; EYE,OIL PIPE (A) M10X21 FLANGE	1-09675-077-0	03	1	0202-0203		●
2	BOLT; EYE,OIL PIPE (A) M10X21 FLANGE	1-09675-077-0	03	1	0204-0805	●	●
2	BOLT; EYE,OIL PIPE (A) M10X21 FLANGE	8-97372-238-0	03	1	0806-	●	●
2	BOLT; EYE,OIL PIPE (E) M14X27 FLANGE	1-09675-086-0	02	1	9903-0201		●
2	BOLT; EYE,OIL PIPE EURO2 SPECIFICATION<THN> (E) M14X27 FLANGE	1-09675-086-0	02	1	0202-0203	●
2	BOLT; EYE,OIL PIPE (E) M14X27 FLANGE	1-09675-086-0	02	1	0202-0203		●
2	BOLT; EYE,OIL PIPE (E) M14X27 FLANGE	1-09675-086-0	02	1	0204-	●	●
3	GASKET; EYE BOLT,OIL PIPE ALSO INCLUDED IN GASKET SET(ENGINE). (D) ID=12.2	1-09630-084-0	06	1	9811-0201	●
3	GASKET; EYE BOLT,OIL PIPE ALSO INCLUDED IN GASKET SET(ENGINE). EXC. EURO2 SPECIFICATION<THN> (D) ID=12.2	1-09630-084-0	06	1	0202-0203	●
3	GASKET; EYE BOLT,OIL PIPE ALSO INCLUDED IN GASKET SET(ENGINE). (B) ID=12.3	1-09623-481-0	01	1	9903-0201		●
3	GASKET; EYE BOLT,OIL PIPE ALSO INCLUDED IN GASKET SET(ENGINE). EURO2 SPECIFICATION<THN>. (B) ID=12.3	1-09623-481-0	01	1	0202-0203	●
3	GASKET; EYE BOLT,OIL PIPE ALSO INCLUDED IN GASKET SET(ENGINE). (B) ID=12.3	1-09623-481-0	01	1	0202-0203		●
3	GASKET; EYE BOLT,OIL PIPE ALSO INCLUDED IN GASKET SET(ENGINE). (B) ID=12.3	1-09623-481-0	01	1	0204-	●	●
3	GASKET; EYE BOLT,OIL PIPE ALSO INCLUDED IN GASKET SET(ENGINE). (A) ID=12.2	1-09630-084-0	02	1	9903-0201		●
3	GASKET; EYE BOLT,OIL PIPE ALSO INCLUDED IN GASKET SET(ENGINE). EURO2 SPECIFICATION<THN>. (A) ID=12.2	1-09630-084-0	02	1	0202-0203	●
3	GASKET; EYE BOLT,OIL PIPE ALSO INCLUDED IN GASKET SET(ENGINE). (A) ID=12.2	1-09630-084-0	02	1	0202-0203		●
3	GASKET; EYE BOLT,OIL PIPE ALSO INCLUDED IN GASKET SET(ENGINE). (A) ID=12.2	1-09630-084-0	02	1	0204-1312	●	●
3	GASKET; EYE BOLT,OIL PIPE ALSO INCLUDED IN GASKET SET(ENGINE). (A) ID=12.2	8-98251-344-0	02	1	1401-	●	●
3	GASKET; EYE BOLT,OIL PIPE ALSO INCLUDED IN GASKET SET(ENGINE). (C) ID=14.2 OD=19.2	1-09630-085-0	02	1	9903-0201		●
3	GASKET; EYE BOLT,OIL PIPE ALSO INCLUDED IN GASKET SET(ENGINE). EURO2 SPECIFICATION<THN>. (C) ID=14.2 OD=19.2	1-09630-085-0	02	1	0202-0203	●
3	GASKET; EYE BOLT,OIL PIPE ALSO INCLUDED IN GASKET SET(ENGINE). (C) ID=14.2 OD=19.2	1-09630-085-0	02	1	0202-0203		●
3	GASKET; EYE BOLT,OIL PIPE ALSO INCLUDED IN GASKET SET(ENGINE). (C) ID=14.2 OD=19.2	1-09630-085-0	02	1	0204-1312	●	●
3	GASKET; EYE BOLT,OIL PIPE ALSO INCLUDED IN GASKET SET(ENGINE). (C) ID=14.2 OD=19.2	8-98251-345-0	02	1	1401-	●	●
48	CLIP; OIL PIPE (A)	1-09701-265-0	01	1	9901-0201	●
48	CLIP; OIL PIPE EXC. EURO2 SPECIFICATION<THN> (A)	1-09701-265-0	01	1	0202-0203	●
48	CLIP; OIL PIPE (B)	8-94396-860-0	01	1	9901-0201	●
48	CLIP; OIL PIPE EXC. EURO2 SPECIFICATION<THN> (B)	8-94396-860-0	01	1	0202-0203	●
48	CLIP; OIL PIPE (A)	1-09701-091-0	01	1	9903-0201		●
48	CLIP; OIL PIPE (A)	1-09701-091-0	01	1	0202-	●	●
48	CLIP; OIL PIPE (B)	8-94395-170-0	01	1	9903-0201		●
48	CLIP; OIL PIPE EURO2 SPECIFICATION<THN> (B)	8-94395-170-0	01	1	0202-0203	●
48	CLIP; OIL PIPE (B)	8-94395-170-0	01	1	0202-0203		●
48	CLIP; OIL PIPE (B)	8-94395-170-0	01	1	0204-	●	●
100	BOLT; CLIP (B) M6X16 FLANGE	0-28080-616-0	01	1	9903-0201		●
100	BOLT; CLIP EURO2 SPECIFICATION<THN> (B) M6X16 FLANGE	0-28080-616-0	01	1	0202-0203	●
100	BOLT; CLIP (B) M6X16 FLANGE	0-28080-616-0	01	1	0202-0203		●
100	BOLT; CLIP (B) M6X16 FLANGE	0-28080-616-0	01	1	0204-0512	●	●
100	BOLT; CLIP (B) M6X16 FLANGE	0-28050-616-0	01	1	0601-	●	●
100	BOLT; CLIP (A) M6X22 FLANGE	0-28080-622-0	01	1	9903-0201		●
100	BOLT; CLIP (A) M6X22 FLANGE	0-28080-622-0	01	1	0202-	●	●
117	GASKET; JOINT,OIL PIPE ALSO INCLUDED IN GASKET SET(ENG. & HEAD) ID=10.2 OD=15.2	1-09630-083-0	04	1	9811-9902	●
117	GASKET; JOINT,OIL PIPE ALSO INCLUDED IN GASKET SET(ENG. & HEAD) ID=10.2 OD=15.2	1-09630-083-0	04	1	9903-	●	●
475	PIPE; OIL,OIL FILTER TO INJ PUMP	8-94390-488-0	01	1	9903-9906		●
475	PIPE; OIL,OIL FILTER TO INJ PUMP	8-97600-567-1	01	1	9907-0201		●
475	PIPE; OIL,OIL FILTER TO INJ PUMP	8-97600-567-1	01	1	0202-	●	●

İpucu: çizimdeki balona veya tablodaki Balon sütununa tıkla; ilgili parçalar vurgulanır. Birden çok çizim varsa üstteki seçim kutusu/oklarla gezin.
