2 |
COVER; INL
|
8-94394-301-5 |
01 |
1 |
9811-0201 |
● |
|
| |
2 |
COVER; INL
EXC. EURO2 SPECIFICATION<THN>
|
8-94394-301-5 |
01 |
1 |
0202-0203 |
● |
|
| |
2 |
COVER; INL
EURO2 SPECIFICATION<THN>
|
8-97602-255-0 |
01 |
1 |
0202-0203 |
● |
|
| |
2 |
COVER; INL
|
8-97602-255-0 |
01 |
1 |
0204- |
● |
|
| |
2 |
COVER; INL
|
8-94391-107-2 |
01 |
1 |
9903- |
|
● |
| |
7 |
GASKET; INL MANIF TO HD
ALSO INCLUDED IN GASKET SET(ENG. & HEAD)
|
8-94397-039-1 |
01 |
1 |
9811-9902 |
● |
|
| |
7 |
GASKET; INL MANIF TO HD
ALSO INCLUDED IN GASKET SET(ENG. & HEAD)
|
8-94397-039-1 |
01 |
1 |
9903- |
● |
● |
| |
32 |
STUD; INL PIPE
(A)
M6X25 L=34
|
9-04110-625-0 |
04 |
1 |
9811-0201 |
● |
|
| |
32 |
STUD; INL PIPE
EXC. EURO2 SPECIFICATION<THN>
(A)
M6X25 L=34
|
9-04110-625-0 |
04 |
1 |
0202-0203 |
● |
|
| |
32 |
STUD; INL PIPE
(A)
M10X20 L=35
|
9-04411-020-0 |
04 |
1 |
0204- |
● |
● |
| |
32 |
STUD; INL PIPE
(B)
M10X20 L=35
|
9-04411-020-0 |
04 |
1 |
9811-9902 |
● |
|
| |
32 |
STUD; INL PIPE
(B)
M10X20 L=35
|
9-04411-020-0 |
04 |
1 |
9903-0203 |
● |
● |
| |
32 |
STUD; INL PIPE
(A)
M6X30 L=38
|
9-04110-630-0 |
03 |
1 |
9903-0201 |
|
● |
| |
32 |
STUD; INL PIPE
EURO2 SPECIFICATION<THN>
(A)
M6X30 L=38
|
9-04110-630-0 |
03 |
1 |
0202-0203 |
● |
|
| |
32 |
STUD; INL PIPE
(A)
M6X30 L=38
|
9-04110-630-0 |
03 |
1 |
0202-0203 |
|
● |
| |
32 |
STUD; INL PIPE
(A)
M6X30 L=38
|
9-04110-630-0 |
03 |
1 |
0204-0604 |
● |
● |
| |
32 |
STUD; INL PIPE
(A)
M6X30 L=38
|
0-41010-630-0 |
03 |
1 |
0605- |
● |
● |
| |
44 |
NUT; PIPE BRKT
M8 FLANGE
|
0-91150-108-0 |
02 |
1 |
9811-0201 |
● |
|
| |
44 |
NUT; PIPE BRKT
EXC. EURO2 SPECIFICATION<THN>
M8 FLANGE
|
0-91150-108-0 |
02 |
1 |
0202-0203 |
● |
|
| |
44 |
NUT; PIPE BRKT
M8 FLANGE
|
0-91150-108-0 |
03 |
1 |
9903-0201 |
|
● |
| |
44 |
NUT; PIPE BRKT
EURO2 SPECIFICATION<THN>
M8 FLANGE
|
0-91150-108-0 |
03 |
1 |
0202-0203 |
● |
|
| |
44 |
NUT; PIPE BRKT
M8 FLANGE
|
0-91150-108-0 |
03 |
1 |
0202-0203 |
|
● |
| |
44 |
NUT; PIPE BRKT
M8 FLANGE
|
0-91150-108-0 |
03 |
1 |
0204-0602 |
● |
● |
| |
44 |
NUT; PIPE BRKT
M8 FLANGE
|
0-91180-108-0 |
03 |
1 |
0603- |
● |
● |
| |
50 |
PIPE; INL
|
8-94394-400-1 |
01 |
1 |
9811-0201 |
● |
|
| |
50 |
PIPE; INL
EXC. EURO2 SPECIFICATION<THN>
|
8-94394-400-1 |
01 |
1 |
0202-0203 |
● |
|
| |
50 |
PIPE; INL
|
8-94391-478-1 |
01 |
1 |
9903-0001 |
|
● |
| |
50 |
PIPE; INL
|
8-97601-301-0 |
01 |
1 |
0002-0201 |
|
● |
| |
50 |
PIPE; INL
|
8-97601-301-0 |
01 |
1 |
0202- |
● |
● |
| |
53 |
BOLT; INL PIPE
M8X16 FLANGE
|
0-28080-816-0 |
01 |
1 |
9811-0201 |
● |
|
| |
53 |
BOLT; INL PIPE
EXC. EURO2 SPECIFICATION<THN>
M8X16 FLANGE
|
0-28080-816-0 |
01 |
1 |
0202-0203 |
● |
|
| |
55 |
NUT; INL PIPE
(A)
M10 FLANGE
|
0-91150-110-0 |
04 |
1 |
9811-9902 |
● |
|
| |
55 |
NUT; INL PIPE
(A)
M10 FLANGE
|
0-91150-110-0 |
04 |
1 |
9903-0602 |
● |
● |
| |
55 |
NUT; INL PIPE
(A)
M10 FLANGE
|
0-91180-110-0 |
04 |
1 |
0603- |
● |
● |
| |
55 |
NUT; INL PIPE
(B)
M8
|
9-09110-408-0 |
03 |
1 |
9811-9902 |
● |
|
| |
55 |
NUT; INL PIPE
(B)
M8
|
9-09110-408-0 |
03 |
1 |
9903-0512 |
● |
● |
| |
55 |
NUT; INL PIPE
(B)
M8
|
0-91110-508-0 |
03 |
1 |
0601- |
● |
● |
| |
70 |
STUD; WATER PIPE
M10X30 L=45
|
9-04411-030-0 |
02 |
1 |
9811-0201 |
● |
|
| |
70 |
STUD; WATER PIPE
EXC. EURO2 SPECIFICATION<THN>
M10X30 L=45
|
9-04411-030-0 |
02 |
1 |
0202-0203 |
● |
|
| |
75 |
STUD; BRKT,AIR PIPE
M10X25 L=40
|
9-04411-025-0 |
02 |
1 |
9903-0201 |
|
● |
| |
75 |
STUD; BRKT,AIR PIPE
EURO2 SPECIFICATION<THN>
M10X25 L=40
|
9-04411-025-0 |
02 |
1 |
0202-0203 |
● |
|
| |
75 |
STUD; BRKT,AIR PIPE
M10X25 L=40
|
9-04411-025-0 |
02 |
1 |
0202-0203 |
|
● |
| |
75 |
STUD; BRKT,AIR PIPE
M10X25 L=40
|
9-04411-025-0 |
02 |
1 |
0204-0604 |
● |
● |
| |
75 |
STUD; BRKT,AIR PIPE
M10X25 L=40
|
0-44011-025-0 |
02 |
1 |
0605- |
● |
● |
| |
167 |
PLUG; INL MANIF
|
1-09604-078-0 |
06 |
1 |
9811-0201 |
● |
|
| |
167 |
PLUG; INL MANIF
EXC. EURO2 SPECIFICATION<THN>
|
1-09604-078-0 |
06 |
1 |
0202-0203 |
● |
|
| |
170 |
BOLT; BRKT
M8X16 FLANGE
|
0-28080-816-0 |
01 |
1 |
9811-9902 |
● |
|
| |
170 |
BOLT; BRKT
M8X16 FLANGE
|
0-28080-816-0 |
01 |
1 |
9903-0512 |
● |
● |
| |
170 |
BOLT; BRKT
M8X16 FLANGE
|
0-28050-816-0 |
01 |
1 |
0601- |
● |
● |
| |
170 |
BOLT; BRKT
M8X25 FLANGE
|
0-28080-825-0 |
01 |
1 |
9811-9902 |
● |
|
| |
170 |
BOLT; BRKT
M8X25 FLANGE
|
0-28080-825-0 |
01 |
1 |
9903-0512 |
● |
● |
| |
170 |
BOLT; BRKT
M8X25 FLANGE
|
0-28050-825-0 |
01 |
1 |
0601- |
● |
● |
| |
170 |
BOLT; BRKT
M10X25 FLANGE
|
0-28081-025-0 |
01 |
1 |
9903-0201 |
|
● |
| |
170 |
BOLT; BRKT
M10X25 FLANGE
|
0-28081-025-0 |
01 |
1 |
0202-0512 |
● |
● |
| |
170 |
BOLT; BRKT
M10X25 FLANGE
|
0-28051-025-0 |
01 |
1 |
0601- |
● |
● |
| |
192 |
WASHER; PL,INL PIPE
ID=8.4 OD=26
|
9-09164-808-0 |
03 |
1 |
9811-9902 |
● |
|
| |
192 |
WASHER; PL,INL PIPE
ID=8.4 OD=26
|
9-09164-808-0 |
03 |
1 |
9903-0605 |
● |
● |
| |
192 |
WASHER; PL,INL PIPE
ID=8.4 OD=26
|
0-91614-808-0 |
03 |
1 |
0606- |
● |
● |
| |
200 |
BRACKET; AIR DUCT
(B)
|
8-94390-088-0 |
01 |
1 |
9811-9812 |
● |
|
| |
200 |
BRACKET; AIR DUCT
(B)
|
8-97600-201-0 |
01 |
1 |
9901-0201 |
● |
|
| |
200 |
BRACKET; AIR DUCT
EXC. EURO2 SPECIFICATION<THN>
(B)
|
8-97600-201-0 |
01 |
1 |
0202-0203 |
● |
|
| |
200 |
BRACKET; AIR DUCT
(B)
|
8-94394-312-1 |
01 |
1 |
0204- |
● |
● |
| |
200 |
BRACKET; AIR DUCT
(A)
|
8-94394-312-1 |
01 |
1 |
9811-9902 |
● |
|
| |
200 |
BRACKET; AIR DUCT
(A)
|
8-94394-312-1 |
01 |
1 |
9903-0203 |
● |
● |
| |
200 |
BRACKET; AIR DUCT
(B)
|
8-94390-088-0 |
01 |
1 |
9903-0201 |
|
● |
| |
200 |
BRACKET; AIR DUCT
(B)
|
8-94390-088-0 |
01 |
1 |
0202- |
● |
● |
| |
201 |
BOLT; BRKT,AIR DUCT
M8X16 FLANGE
|
0-28080-816-0 |
05 |
1 |
9811-9902 |
● |
|
| |
201 |
BOLT; BRKT,AIR DUCT
M8X16 FLANGE
|
0-28080-816-0 |
05 |
1 |
9903-0512 |
● |
● |
| |
201 |
BOLT; BRKT,AIR DUCT
M8X16 FLANGE
|
0-28050-816-0 |
05 |
1 |
0601- |
● |
● |
| |
228 |
STUD; INL COVER
(C)
M8X16 L=28
|
9-04110-816-0 |
06 |
1 |
9811-9902 |
● |
|
| |
228 |
STUD; INL COVER
(C)
M8X16 L=28
|
9-04110-816-0 |
06 |
1 |
9903-0604 |
● |
● |
| |
228 |
STUD; INL COVER
(C)
M8X16 L=28
|
0-41010-816-0 |
06 |
1 |
0605- |
● |
● |
| |
228 |
STUD; INL COVER
(A)
M8X25 L=37
|
9-04110-825-0 |
01 |
1 |
9903-0201 |
|
● |
| |
228 |
STUD; INL COVER
EURO2 SPECIFICATION<THN>
(A)
M8X25 L=37
|
9-04110-825-0 |
01 |
1 |
0202-0203 |
● |
|
| |
228 |
STUD; INL COVER
(A)
M8X25 L=37
|
9-04110-825-0 |
01 |
1 |
0202-0203 |
|
● |
| |
228 |
STUD; INL COVER
(A)
M8X25 L=37
|
9-04110-825-0 |
01 |
1 |
0204-0604 |
● |
● |
| |
228 |
STUD; INL COVER
(A)
M8X25 L=37
|
0-41010-825-0 |
01 |
1 |
0605- |
● |
● |
| |
228 |
STUD; INL COVER
(B)
M8X40 L=52
|
9-04110-840-0 |
01 |
1 |
9903-0201 |
|
● |
| |
228 |
STUD; INL COVER
EURO2 SPECIFICATION<THN>
(B)
M8X40 L=52
|
9-04110-840-0 |
01 |
1 |
0202-0203 |
● |
|
| |
228 |
STUD; INL COVER
(B)
M8X40 L=52
|
9-04110-840-0 |
01 |
1 |
0202-0203 |
|
● |
| |
228 |
STUD; INL COVER
(B)
M8X40 L=52
|
9-04110-840-0 |
01 |
1 |
0204-0604 |
● |
● |
| |
228 |
STUD; INL COVER
(B)
M8X40 L=52
|
0-41010-840-0 |
01 |
1 |
0605- |
● |
● |
| |
232 |
BRACKET; INJ PIPE
|
8-94395-027-0 |
01 |
1 |
9903-0108 |
|
● |
| |
232 |
BRACKET; INJ PIPE
|
8-94391-452-0 |
01 |
1 |
0109-0201 |
|
● |
| |
232 |
BRACKET; INJ PIPE
EURO2 SPECIFICATION<THN>
|
8-94391-452-0 |
01 |
1 |
0202-0203 |
● |
|
| |
232 |
BRACKET; INJ PIPE
|
8-94391-452-0 |
01 |
1 |
0202-0203 |
|
● |
| |
232 |
BRACKET; INJ PIPE
|
8-94391-452-0 |
01 |
1 |
0204- |
● |
● |
| |
284 |
RUBBER; INL PIPE MTG
|
8-94394-268-1 |
02 |
1 |
9811-9902 |
● |
|
| |
284 |
RUBBER; INL PIPE MTG
|
8-94394-268-1 |
02 |
1 |
9903-0910 |
● |
● |
| |
284 |
RUBBER; INL PIPE MTG
|
8-98148-109-0 |
02 |
1 |
0911- |
● |
● |
| |
324 |
GASKET; INL PIPE TO INL CVR
ALSO INCLUDED IN GASKET SET(ENG. & HEAD)
ID=62.6
|
1-09623-505-0 |
02 |
1 |
9811-9902 |
● |
|
| |
324 |
GASKET; INL PIPE TO INL CVR
ALSO INCLUDED IN GASKET SET(ENG. & HEAD)
ID=62.6
|
1-09623-505-0 |
02 |
1 |
9903- |
● |
● |
| |
327 |
VALVE; SAFETY,TURBOCHARGER
|
8-94393-227-0 |
01 |
1 |
9811- |
● |
|
| |
341 |
BOLT; BRKT,INL COVER
M10X20 FLANGE
|
0-28181-020-0 |
01 |
1 |
9811-0201 |
● |
|
| |
341 |
BOLT; BRKT,INL COVER
EXC. EURO2 SPECIFICATION<THN>
M10X20 FLANGE
|
0-28181-020-0 |
01 |
1 |
0202-0203 |
● |
|
| |
344 |
BRACKET; INL PIPE
|
8-94393-865-0 |
01 |
1 |
9811-9902 |
● |
|
| |
344 |
BRACKET; INL PIPE
|
8-94393-865-0 |
01 |
1 |
9903- |
● |
● |
| |
353 |
PIPE; AIR,BOOST
(A)
|
8-94394-439-0 |
01 |
1 |
9811-0201 |
● |
|
| |
353 |
PIPE; AIR,BOOST
EXC. EURO2 SPECIFICATION<THN>
(A)
|
8-94394-439-0 |
01 |
1 |
0202-0203 |
● |
|
| |
353 |
PIPE; AIR,BOOST
(B)
PT1/4 ELBOW
|
8-94221-562-0 |
01 |
1 |
9903-0201 |
|
● |
| |
353 |
PIPE; AIR,BOOST
EURO2 SPECIFICATION<THN>
(B)
PT1/4 ELBOW
|
8-94221-562-0 |
01 |
1 |
0202-0203 |
● |
|
| |
353 |
PIPE; AIR,BOOST
(B)
PT1/4 ELBOW
|
8-94221-562-0 |
01 |
1 |
0202-0203 |
|
● |
| |
353 |
PIPE; AIR,BOOST
(B)
PT1/4 ELBOW
|
8-94221-562-0 |
01 |
1 |
0204- |
● |
● |
| |
363 |
BOLT; EYE
|
1-09675-184-0 |
01 |
1 |
9811-0201 |
● |
|
| |
363 |
BOLT; EYE
EXC. EURO2 SPECIFICATION<THN>
|
1-09675-184-0 |
01 |
1 |
0202-0203 |
● |
|
| |
364 |
GASKET
ALSO INCLUDED IN GASKET SET(ENGINE).
ID=10.2 OD=15.2
|
1-09630-083-0 |
02 |
1 |
9811-0201 |
● |
|
| |
364 |
GASKET
ALSO INCLUDED IN GASKET SET(ENGINE).
EXC. EURO2 SPECIFICATION<THN>
ID=10.2 OD=15.2
|
1-09630-083-0 |
02 |
1 |
0202-0203 |
● |
|
| |
452 |
CYLINDER ASM; AIR
EURO2 SPECIFICATION<THN>
|
1-14370-007-0 |
06 |
1 |
0202-0203 |
● |
|
| |
452 |
CYLINDER ASM; AIR
|
1-14370-007-0 |
06 |
1 |
0204- |
● |
|
| |
454 |
PIPE; AIR,IVES
EURO2 SPECIFICATION<THN>
(B)
6-JOINT
|
8-94394-415-1 |
01 |
1 |
0202-0203 |
● |
|
| |
454 |
PIPE; AIR,IVES
(B)
6-JOINT
|
8-94394-415-1 |
01 |
1 |
0204- |
● |
|
| |
454 |
PIPE; AIR,IVES
EURO2 SPECIFICATION<THN>
(A)
JOINT & NUT W/BRKT
|
8-94395-743-0 |
01 |
1 |
0202-0203 |
● |
|
| |
454 |
PIPE; AIR,IVES
(A)
JOINT & NUT W/BRKT
|
8-94395-743-0 |
01 |
1 |
0204- |
● |
|
| |
457 |
BOLT; EYE,AIR PIPE,IVES
EURO2 SPECIFICATION<THN>
(A)
M8X18 EYE-BOLT
|
1-09675-037-1 |
06 |
1 |
0202-0203 |
● |
|
| |
457 |
BOLT; EYE,AIR PIPE,IVES
(A)
M8X18 EYE-BOLT
|
1-09675-037-1 |
06 |
1 |
0204- |
● |
|
| |
457 |
BOLT; EYE,AIR PIPE,IVES
EURO2 SPECIFICATION<THN>
(B)
M8X19
|
1-09675-220-0 |
01 |
1 |
0202-0203 |
● |
|
| |
457 |
BOLT; EYE,AIR PIPE,IVES
(B)
M8X19
|
1-09675-220-0 |
01 |
1 |
0204- |
● |
|
| |
458 |
GASKET; AIR PIPE,VSS
EURO2 SPECIFICATION<THN>
(A)
ID=8.2 OD=13.2
|
1-09630-082-0 |
02 |
1 |
0202-0203 |
● |
|
| |
458 |
GASKET; AIR PIPE,VSS
(A)
ID=8.2 OD=13.2
|
1-09630-082-0 |
02 |
1 |
0204- |
● |
|
| |
458 |
GASKET; AIR PIPE,VSS
EURO2 SPECIFICATION<THN>
(B)
ID=8.3
|
8-97600-925-0 |
06 |
1 |
0202-0203 |
● |
|
| |
458 |
GASKET; AIR PIPE,VSS
(B)
ID=8.3
|
8-97600-925-0 |
06 |
1 |
0204-1301 |
● |
|
| |
458 |
GASKET; AIR PIPE,VSS
(B)
|
8-98231-394-0 |
06 |
1 |
1302- |
● |
|
| |
459 |
BOLT; CLIP FIX
EURO2 SPECIFICATION<THN>
M8X12 FLANGE
|
0-28080-812-0 |
01 |
1 |
0202-0203 |
● |
|
| |
459 |
BOLT; CLIP FIX
M8X12 FLANGE
|
0-28080-812-0 |
01 |
1 |
0204-0512 |
● |
|
| |
459 |
BOLT; CLIP FIX
M8X12 FLANGE
|
0-28050-812-0 |
01 |
1 |
0601- |
● |
|
| |
587 |
MOUNTING; INTAKE DUCT
|
8-94395-966-0 |
13 |
1 |
9811-9902 |
● |
|
| |
587 |
MOUNTING; INTAKE DUCT
|
8-94395-966-0 |
13 |
1 |
9903- |
● |
● |
