16 |
CLIP; FLEX HOSE
ID=10 & 12
|
1-09709-278-1 |
01 |
1 |
1001- |
| |
22 |
UNION; CLU PIPE
ASSISTOR SHIFT CONTROL<WX8>
M12 3WAY
|
0-92138-706-0 |
01 |
1 |
1001- |
| |
23 |
GROMMET; CLU PIPE
ID=28 OD=35 T=17
|
9-09956-256-2 |
01 |
1 |
1001- |
| |
28 |
CLIP; OIL PIPE
(A)
ID=6.35
|
1-09701-247-1 |
04 |
1 |
1001- |
| |
28 |
CLIP; OIL PIPE
(B)
ID=6.35 & 6.35
|
1-09709-273-1 |
01 |
1 |
1001- |
| |
47 |
HOSE; FLEX,CLU CONT
BRAKE REGULATION ECE<TDV>
ASSISTOR SHIFT CONTROL<WX8>
MANUAL TRANSMISSION<X9C>
(D)
L=350
|
1-09363-877-0 |
01 |
1 |
1502- |
| |
47 |
HOSE; FLEX,CLU CONT
BRAKE REGULATION ECE<TDV>
MANUAL TRANSMISSION<X9C>
(E)
L=415
|
8-98206-619-0 |
01 |
1 |
1502- |
| |
47 |
HOSE; FLEX,CLU CONT
(B)
L=530
|
8-98072-348-0 |
01 |
1 |
1001-1501 |
| |
47 |
HOSE; FLEX,CLU CONT
MANUAL TRANSMISSION<X9C>
EXC. BRAKE REGULATION ECE<TDV>
(B)
L=530
|
8-98072-348-0 |
01 |
1 |
1502- |
| |
47 |
HOSE; FLEX,CLU CONT
ASSISTOR SHIFT CONTROL<WX8>
(A)
L=340
|
1-09363-617-0 |
01 |
1 |
1001-1501 |
| |
47 |
HOSE; FLEX,CLU CONT
ASSISTOR SHIFT CONTROL<WX8>
MANUAL TRANSMISSION<X9C>
EXC. BRAKE REGULATION ECE<TDV>
(A)
L=340
|
1-09363-617-0 |
01 |
1 |
1502- |
| |
47 |
HOSE; FLEX,CLU CONT
EXC. ASSISTOR SHIFT CONTROL<WX8>
(C)
L=420
|
1-09363-633-0 |
01 |
1 |
1001- |
| |
48 |
GASKET; FLEX HOSE,CLU CONT
ID=10.2 OD=16.0
|
9-09571-410-0 |
02 |
1 |
1001- |
| |
49 |
PIPE; AIR,FLEX HOSE TO CLU BOOSTER
L=239
|
1-49117-401-0 |
01 |
1 |
1001- |
| |
50 |
NUT; UNION
(A)
M12
|
0-91111-512-0 |
01 |
1 |
1001- |
| |
50 |
NUT; UNION
(A)
M12
|
0-91111-512-0 |
01 |
1 |
1001- |
| |
50 |
NUT; UNION
(B)
M12
|
9-09840-280-0 |
01 |
1 |
1001-1501 |
| |
50 |
NUT; UNION
(B)
M12
|
9-09840-280-0 |
01 |
1 |
1502- |
| |
50 |
NUT; UNION
(B)
M12
|
9-09840-280-0 |
01 |
1 |
1502- |
| |
50 |
NUT; UNION
BRAKE REGULATION ECE<TDV>
(B)
M12
|
9-09840-280-0 |
01 |
1 |
1502- |
| |
51 |
WASHER; LK
ID=12.2
SOU
|
0-91510-512-0 |
01 |
1 |
1001- |
| |
52 |
BOLT; EYE,AIR PIPE
M14X27 FLANGE
|
1-09675-086-0 |
01 |
1 |
1001- |
| |
53 |
GASKET; JOINT BOLT
ID=14.2 OD=19.2
SOU
|
1-09630-085-0 |
02 |
1 |
1001-1312 |
| |
53 |
GASKET; JOINT BOLT
ID=14.2 OD=19.2
|
8-98251-345-0 |
02 |
1 |
1401- |
| |
101 |
HOSE; FLEX,OIL PIPE TO OIL PIPE
L=440
|
8-98072-346-0 |
01 |
1 |
1001- |
| |
102 |
NUT; FLEX HOSE,CLU CONT
BRAKE REGULATION ECE<TDV>
MANUAL TRANSMISSION<X9C>
M8 FLANGE
SOU
|
0-91180-108-0 |
02 |
1 |
1502- |
| |
104 |
PIPE; OIL,FLEX HOSE TO CONNECTOR
BRAKE REGULATION ECE<TDV>
MANUAL TRANSMISSION<X9C>
(A)
L=2803
SERVICED BY L=2900
|
1-47428-744-0 |
01 |
1 |
1502- |
| |
104 |
PIPE; OIL,FLEX HOSE TO CONNECTOR
(B)
L=541
SERVICED BY L=550
|
1-47428-724-0 |
01 |
1 |
1001- |
| |
104 |
PIPE; OIL,FLEX HOSE TO CONNECTOR
(A)
L=2824
SERVICED BY L=2900
|
1-47428-744-0 |
01 |
1 |
1001-1501 |
| |
104 |
PIPE; OIL,FLEX HOSE TO CONNECTOR
MANUAL TRANSMISSION<X9C>
EXC. BRAKE REGULATION ECE<TDV>
(A)
L=2824
SERVICED BY L=2900
|
1-47428-744-0 |
01 |
1 |
1502- |
| |
106 |
UNION; OIL PIPE
BRAKE REGULATION ECE<TDV>
MANUAL TRANSMISSION<X9C>
(B)
M12 L=56.5
|
0-92113-106-0 |
01 |
1 |
1502- |
| |
106 |
UNION; OIL PIPE
(A)
M12 2WAY
SOU
|
1-09654-059-2 |
01 |
1 |
1001-1501 |
| |
106 |
UNION; OIL PIPE
MANUAL TRANSMISSION<X9C>
EXC. BRAKE REGULATION ECE<TDV>
(A)
M12 2WAY
SOU
|
1-09654-059-2 |
01 |
1 |
1502- |
| |
139 |
BOLT; BRKT
BRAKE REGULATION ECE<TDV>
MANUAL TRANSMISSION<X9C>
M8X30 FLANGE
|
0-28650-830-0 |
01 |
1 |
1502- |
| |
167 |
BRACKET; UNION
BRAKE REGULATION ECE<TDV>
MANUAL TRANSMISSION<X9C>
|
8-98244-257-0 |
01 |
1 |
1502- |
| |
184 |
UNION; FLEX HOSE
|
8-98150-865-0 |
01 |
1 |
1001- |
| |
239 |
UNION; CLU HOSE
M12 2WAY
SOU
|
1-09654-059-2 |
01 |
1 |
1001- |
