Isuzu WW
▶
TRUCKS
▶
NHR
▶
51101 - NHR EURO4
▶
6 - Exterior Body, Glass Mounting, Door Trim, Molding
▶
6-07 - FRONT WINDOW GLASS AND WEATHERSTRIP
▶
6-07 — FRONT WINDOW GLASS AND WEATHERSTRIP
(#23070) — 13 parça
3
15
1
42
13
8
9
14
13
3
15
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
1
16.005 GLASS; WINDSHIELD
CAB-LOW ROOF<6XQ>
8-97869-121-1
01
1
0609-
1
16.005 GLASS; WINDSHIELD
EXC. CAB-LOW ROOF<6XQ>
8-97869-124-0
01
1
0609-0805
1
16.005 GLASS; WINDSHIELD
EXC. CAB-LOW ROOF<6XQ>
8-97997-944-1
01
1
0806-
3
16.470 MOLDING; WINDSHIELD
CAB-LOW ROOF<6XQ>
8-97581-623-3
01
1
0609-
3
16.470 MOLDING; WINDSHIELD
EXC. CAB-LOW ROOF<6XQ>
8-97581-678-3
01
1
0609-
8
16.041 STOPPER; WINDSHIELD GLASS
8-97853-733-1
02
1
0609-1108
9
16.041 SCREW; STOPPER
16.067 M5X14
8-94279-325-0
02
1
0609-1108
13
16.041 MOLDING; BRKT,OUTSIDE MIRROR
8-97581-618-3
01
1
0609-
13
16.041 MOLDING; BRKT,OUTSIDE MIRROR
8-97581-617-4
01
1
0609-
14
16.041 GROMMET; SCREW,STOPPER
16.802 D=7.8X7.8 L=18 NATURAL
8-94279-043-0
02
1
0609-1108
15
16.041 FINISHER; WINDSHIELD
CAB-LOW ROOF<6XQ> GRAY
8-97582-227-7
01
1
0609-
15
16.041 FINISHER; WINDSHIELD
EXC. CAB-LOW ROOF<6XQ> GRAY
8-97582-226-7
01
1
0609-
42
16.041 SEAL; HOLE
16.165 OD=20 T=0.05 BLACK
5-76777-036-0
02
1
1109-
