Isuzu WW
▶
TRUCKS
▶
EXZ
▶
10653 - EXZ
▶
0 - Engine, Emission, Engine Electrical
▶
0-28A - VENTILATION SYSTEM
▶
0-28A — VENTILATION SYSTEM
(#2294) — 27 parça
Tümü
A - 6RA1TC ENG
B - 6RB1 STD ENG
C - 6RB1TC ENG
11
10
8
7
6
9
5
4
3
2
1
11
10
1
9
8
7
6
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
A
B
C
1
BREATHER; AIR
1-11740-156-2
01
1
9002-9306
●
1
BREATHER; AIR
CHEAPER CAB(SAX)
9-11740-298-3
01
1
9002-9306
●
1
BREATHER; AIR
EXC. CHEAPER CAB(SAX)
1-11740-154-0
01
1
9002-9306
●
1
BREATHER; AIR
1-11740-182-1
01
1
9002-
●
2
CAP; AIR BREATHER BODY
EXC. CHEAPER CAB(SAX)
9-11746-025-0
01
1
9002-9306
●
3
GASKET; BODY TO CAP
EXC. CHEAPER CAB(SAX)
1-09630-100-0
01
1
9002-9306
●
4
RETAINER; ELEMENT
EXC. CHEAPER CAB(SAX)
9-11746-028-0
01
1
9002-9306
●
5
ELEMENT; BRASS WOOL
EXC. CHEAPER CAB(SAX)
9-11745-061-0
01
1
9002-9306
●
6
WASHER; BREATHER
ID=8.4
9-09160-508-0
02
1
9002-9306
●
●
6
WASHER; BREATHER
ID=8.4
9-09160-508-0
04
1
9002-
●
7
WASHER; LK,BREATHER
ID=8.2
9-09150-508-0
02
1
9002-9306
●
●
7
WASHER; LK,BREATHER
ID=8.2
9-09150-508-0
04
1
9002-
●
8
NUT; BREATHER
M8
9-09110-408-0
02
1
9002-9306
●
●
8
NUT; BREATHER
M8
9-09110-408-0
04
1
9002-
●
9
GASKET; AIR BREATHER
ALSO INCLUDED IN GASKET SET(ENGINE).
1-09623-299-0
01
1
9002-9306
●
9
GASKET; AIR BREATHER
ALSO INCLUDED IN GASKET SET(ENGINE). CHEAPER CAB(SAX) ID=38.7
1-09623-299-0
01
1
9002-9306
●
9
GASKET; AIR BREATHER
ALSO INCLUDED IN GASKET SET(ENGINE). EXC. CHEAPER CAB(SAX) ID=48
9-09920-647-0
01
1
9002-9003
●
9
GASKET; AIR BREATHER
ALSO INCLUDED IN GASKET SET(ENGINE). EXC. CHEAPER CAB(SAX) ID=47.7
1-09623-465-0
01
1
9004-9306
●
9
GASKET; AIR BREATHER
ALSO INCLUDED IN GASKET SET(ENGINE).
1-09623-426-0
01
1
9002-
●
10
CLIP; AIR BREATHER
ID=32
9-09915-005-1
01
1
9002-9306
●
●
10
CLIP; AIR BREATHER
CHEAPER CAB(SAX) ID=32
9-09915-005-1
01
1
9002-9306
●
10
CLIP; AIR BREATHER
EXC. CHEAPER CAB(SAX) D=50 BAND
1-09707-046-0
01
1
9002-9306
●
10
CLIP; AIR BREATHER
ID=32
9-09915-005-1
01
1
9307-
●
11
HOSE; RUBBER,AIR
ID=25 L=660
0-02825-660-0
01
1
9002-9306
●
●
11
HOSE; RUBBER,AIR
CHEAPER CAB(SAX) ID=25 L=660
0-02825-660-0
01
1
9002-9306
●
11
HOSE; RUBBER,AIR
EXC. CHEAPER CAB(SAX) L=520
1-09360-454-1
01
1
9002-9306
●
11
HOSE; RUBBER,AIR
ID=25 L=660
0-02825-660-0
01
1
9307-
●
Seçili parçaları sepete ekle
İpucu: çizimdeki balona veya tablodaki
Balon
sütununa tıkla; ilgili parçalar vurgulanır. Birden çok çizim varsa üstteki seçim kutusu/oklarla gezin.
