Sayfa 4-35 - Isuzu EPC

4-35 — POWER STEERING CONTROL; CHASSIS SIDE (#22856) — 306 parça

2 5 280 3 15 1 19 46 12 15 15 15 31 48 19 58 61 58 59 61 68 65 37 65 37 58 61 68 58 61 239 31 79 81 61 277 31 59 278 68 66 46 205 1 192 207 25 41 155 207 41 37 26 280 125 282 42 31 157 195 280 59 48

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date	A	B
1	TANK ASM; OIL,P/S 6HH1 STD ENG(65L) (A)	1-21210-205-0	01	1	9601-0308	●	●
1	TANK ASM; OIL,P/S (A)	1-21210-205-0	01	1	0309-0508		●
1	TANK ASM; OIL,P/S (A)	1-21210-238-1	01	1	0509-1006		●
1	TANK ASM; OIL,P/S (A)	8-98166-928-0	01	1	1007-		●
1	TANK ASM; OIL,P/S 6SD1 STD ENG(37L) (B)	1-21210-152-6	01	1	9601-0308	●	●
2	CAP; OIL TANK,P/S	1-21241-004-3	01	1	9601-0308	●	●
2	CAP; OIL TANK,P/S	1-21241-004-4	01	1	0309-1006		●
2	CAP; OIL TANK,P/S	8-98166-876-0	01	1	1007-		●
3	GASKET; OIL TANK,P/S	1-21249-003-1	01	1	9601-0308	●	●
3	GASKET; OIL TANK,P/S	1-21249-003-1	01	1	0309-		●
5	STRAINER; OIL TANK,P/S	1-21235-007-1	01	1	9601-0308	●	●
5	STRAINER; OIL TANK,P/S	1-21235-007-1	01	1	0309-		●
12	FILTER; MICROBON,OIL TANK,P/S 6HH1 STD ENG(65L) (A)	1-21235-011-0	01	1	9601-0308	●	●
12	FILTER; MICROBON,OIL TANK,P/S (A)	1-21235-011-0	01	1	0309-		●
12	FILTER; MICROBON,OIL TANK,P/S 6SD1 STD ENG(37L) (B)	1-21235-004-1	01	1	9601-0308	●	●
15	PLATE; FILTER,OIL TANK 6HH1 STD ENG(65L)	1-21249-007-1	02	1	9601-0308	●	●
15	PLATE; FILTER,OIL TANK 6SD1 STD ENG(37L)	1-21249-007-1	04	1	9601-0308	●	●
15	PLATE; FILTER,OIL TANK	1-21249-007-1	02	1	0309-0508		●
15	PLATE; FILTER,OIL TANK	1-21249-016-0	02	1	0509-		●
19	SEAT; OIL TANK	1-21249-004-0	02	1	9601-0308	●	●
19	SEAT; OIL TANK	1-21249-004-0	02	1	0309-		●
25	BOLT; OIL TANK BRKT 6HH1 STD ENG(65L) M8X20 FLANGE	0-28080-820-0	02	1	9601-9606	●	●
25	BOLT; OIL TANK BRKT 6HH1 STD ENG(65L) M8X25 FLANGE	0-28680-825-0	02	1	9607-0308	●	●
25	BOLT; OIL TANK BRKT 6SD1 STD ENG(37L) M8X20 FLANGE	0-28080-820-0	04	1	9601-9606	●	●
25	BOLT; OIL TANK BRKT 6SD1 STD ENG(37L) M8X25 FLANGE	0-28680-825-0	04	1	9607-0308	●	●
25	BOLT; OIL TANK BRKT M8X25 FLANGE	0-28680-825-0	02	1	0309-0512		●
25	BOLT; OIL TANK BRKT M8X25 FLANGE	0-28650-825-0	02	1	0601-		●
26	NUT; OIL TANK TO BRKT 6HH1 STD ENG(65L) M8	9-09110-408-0	02	1	9601-9606	●	●
26	NUT; OIL TANK TO BRKT 6HH1 STD ENG(65L) M8 FLANGE	0-91150-108-0	02	1	9607-0308	●	●
26	NUT; OIL TANK TO BRKT 6SD1 STD ENG(37L) M8	9-09110-408-0	04	1	9601-9606	●	●
26	NUT; OIL TANK TO BRKT 6SD1 STD ENG(37L) M8 FLANGE	0-91150-108-0	04	1	9607-0308	●	●
26	NUT; OIL TANK TO BRKT M8 FLANGE	0-91150-108-0	02	1	0309-0602		●
26	NUT; OIL TANK TO BRKT M8 FLANGE	0-91180-108-0	02	1	0603-		●
31	HOSE; P/S OIL TANK,INL 6HH1 STD ENG(65L) (A)	1-21113-590-0	01	1	9601-0308	●	●
31	HOSE; P/S OIL TANK,INL (A)	1-21113-590-0	01	1	0309-		●
31	HOSE; P/S OIL TANK,INL 6SD1 STD ENG(37L) (B)	1-21115-465-1	01	1	9601-0004	●	●
31	HOSE; P/S OIL TANK,INL 6SD1 STD ENG(37L) (B)	1-21115-465-2	01	1	0005-0308	●	●
37	CLIP; HOSE,P/S (A) ID=26	1-09704-082-0	02	1	9601-0308	●	●
37	CLIP; HOSE,P/S (A) ID=26	1-09704-082-0	02	1	0309-		●
37	CLIP; HOSE,P/S 6SD1 STD ENG(37L) (B) ID=24.5 H=35 L=25	1-09700-990-0	01	1	9601-0108	●	●
37	CLIP; HOSE,P/S 6SD1 STD ENG(37L) (B) ID=24.5 H=23 L=25	1-09700-862-0	01	1	0109-0308	●	●
41	CLIP; HOSE,P/S ID=32	1-09704-085-0	02	1	9601-0308	●	●
41	CLIP; HOSE,P/S ID=32	1-09704-085-0	02	1	0309-		●
42	CLIP; HOSE,P/S 6SD1 STD ENG(37L) L=250	1-09707-126-0	01	1	9601-0308	●	●
46	PIPE; OIL,P/S UNIT TO OIL TANK 6HH1 STD ENG(65L) (A)	1-21115-360-0	01	1	9601-9712	●	●
46	PIPE; OIL,P/S UNIT TO OIL TANK 6HH1 STD ENG(65L) (A)	1-21116-024-1	01	1	9801-9803	●	●
46	PIPE; OIL,P/S UNIT TO OIL TANK 6HH1 STD ENG(65L) (A)	1-21116-028-1	01	1	9804-0308	●	●
46	PIPE; OIL,P/S UNIT TO OIL TANK (A)	1-21116-028-1	01	1	0309-		●
46	PIPE; OIL,P/S UNIT TO OIL TANK 6SD1 STD ENG(37L) (B)	1-21115-565-0	01	1	9601-0004	●	●
46	PIPE; OIL,P/S UNIT TO OIL TANK 6SD1 STD ENG(37L) (B)	1-21115-565-0	01	1	0005-0308	●	●
48	PIPE; OIL,FLEX HOSE TO STRG UNIT 6SD1 STD ENG(37L)	1-21115-564-0	01	1	9601-9809	●	●
48	PIPE; OIL,FLEX HOSE TO STRG UNIT 6SD1 STD ENG(37L)	1-21116-221-0	01	1	9810-0004	●	●
48	PIPE; OIL,FLEX HOSE TO STRG UNIT 6SD1 STD ENG(37L)	1-21116-221-0	01	1	0005-0308	●	●
58	BOLT; CLIP 6HH1 STD ENG(65L) (A) M8X20 FLANGE	0-28080-820-0	01	1	9601-9606	●	●
58	BOLT; CLIP 6HH1 STD ENG(65L) (A) M8X25 FLANGE	0-28680-825-0	01	1	9607-9803	●	●
58	BOLT; CLIP 6HH1 STD ENG(65L) (A) M8X20 FLANGE	0-28680-820-0	01	1	9804-0308	●	●
58	BOLT; CLIP 6HH1 STD ENG(65L) (A) M8X20 FLANGE	0-28680-820-0	01	1	0309-0512		●
58	BOLT; CLIP (A) M8X20 FLANGE	0-28650-820-0	01	1	0601-		●
58	BOLT; CLIP 6HH1 STD ENG(65L) (B) M8X25 FLANGE	0-28080-825-0	02	1	9601-9606	●	●
58	BOLT; CLIP 6HH1 STD ENG(65L) (B) M8X30 FLANGE	0-28680-830-0	02	1	9607-0308	●	●
58	BOLT; CLIP 6HH1 STD ENG(65L) (B) M8X30 FLANGE	0-28680-830-0	02	1	0309-0512		●
58	BOLT; CLIP (B) M8X30 FLANGE	0-28650-830-0	02	1	0601-		●
58	BOLT; CLIP 6SD1 STD ENG(37L) (D) M8X16 FLANGE	0-28080-816-0	01	1	9601-0308	●	●
58	BOLT; CLIP 6SD1 STD ENG(37L) (E) M8X25 FLANGE	0-28080-825-0	01	1	9601-9606	●	●
58	BOLT; CLIP 6SD1 STD ENG(37L) (E) M8X45 FLANGE	0-28080-845-0	02	1	9607-0004	●	●
58	BOLT; CLIP 6SD1 STD ENG(37L) (E) M8X45 FLANGE	0-28080-845-0	02	1	0005-0308	●	●
58	BOLT; CLIP 6SD1 STD ENG(37L) (C) M8X40 FLANGE	0-28080-840-0	02	1	9601-9606	●	●
58	BOLT; CLIP 6SD1 STD ENG(37L) (C) M8X30 FLANGE	0-28680-830-0	01	1	9607-0308	●	●
59	BRACKET; CLIP,OIL PIPE 6HH1 STD ENG(65L) (C) L=60	1-47475-455-0	01	1	9601-0308	●	●
59	BRACKET; CLIP,OIL PIPE (C) L=60	1-47475-455-0	01	1	0309-		●
59	BRACKET; CLIP,OIL PIPE 6SD1 STD ENG(37L) (A) L=60	1-47465-745-0	01	1	9601-0308	●	●
59	BRACKET; CLIP,OIL PIPE 6SD1 STD ENG(37L) (B)	1-47475-427-1	02	1	9601-0004	●	●
59	BRACKET; CLIP,OIL PIPE 6SD1 STD ENG(37L) (B)	1-47475-427-1	02	1	0005-0308	●	●
61	CLIP; OIL PIPE (C) ID=12 & 15	1-09709-281-1	01	1	9601-0308	●	●
61	CLIP; OIL PIPE (C) ID=12 & 15	1-09709-281-1	01	1	0309-		●
61	CLIP; OIL PIPE 6HH1 STD ENG(65L) (A) ID=15 H=24 L=20	1-09700-606-0	02	1	9601-0308	●	●
61	CLIP; OIL PIPE (A) ID=15 H=24 L=20	1-09700-606-0	02	1	0309-		●
61	CLIP; OIL PIPE 6HH1 STD ENG(65L) (B) ID=16 & 13 L=18 & 17	1-09700-658-0	01	1	9601-0001	●	●
61	CLIP; OIL PIPE 6HH1 STD ENG(65L) (B) ID=16 & 13 L=21.5 & 21.5	1-09700-668-0	01	1	0002-0308	●	●
61	CLIP; OIL PIPE (B) ID=16 & 13 L=21.5 & 21.5	1-09700-668-0	01	1	0309-		●
61	CLIP; OIL PIPE 6SD1 STD ENG(37L) (B) ID=16 & 13 L=21.5 & 21.5	1-09700-668-0	03	1	9601-0004	●	●
61	CLIP; OIL PIPE 6SD1 STD ENG(37L) (B) ID=16 & 13 L=21.5 & 21.5	1-09700-668-0	03	1	0005-0308	●	●
61	CLIP; OIL PIPE 6SD1 STD ENG(37L) (D) ID=16 L=40	9-09525-576-0	01	1	9601-0308	●	●
65	NUT; BRKT 6HH1 STD ENG(65L) M8	9-09110-408-0	03	1	9601-9606	●	●
65	NUT; BRKT 6HH1 STD ENG(65L) M8 FLANGE	0-91150-108-0	03	1	9607-0308	●	●
65	NUT; BRKT 6HH1 STD ENG(65L) M8 FLANGE	0-91150-108-0	03	1	0309-0602		●
65	NUT; BRKT M8 FLANGE	0-91180-108-0	03	1	0603-		●
65	NUT; BRKT 6SD1 STD ENG(37L) M8	9-09110-408-0	01	1	9601-9606	●	●
65	NUT; BRKT 6SD1 STD ENG(37L) M8	9-09110-408-0	01	1	9601-9606	●	●
65	NUT; BRKT 6SD1 STD ENG(37L) M8 FLANGE	0-91150-108-0	01	1	9607-0308	●	●
65	NUT; BRKT 6SD1 STD ENG(37L) M8 FLANGE	0-91150-108-0	01	1	9607-0308	●	●
65	NUT; BRKT 6SD1 STD ENG(37L) M8	9-09110-408-0	02	1	9601-9606	●	●
65	NUT; BRKT 6SD1 STD ENG(37L) M8 FLANGE	0-91150-108-0	02	1	9607-0308	●	●
66	BOLT; BRKT,OIL PIPE 6SD1 STD ENG(37L) M8X20 FLANGE	0-28080-820-0	01	1	9601-9606	●	●
66	BOLT; BRKT,OIL PIPE 6SD1 STD ENG(37L) M8X25 FLANGE	0-28680-825-0	01	1	9607-0308	●	●
68	NUT; CLIP,OIL PIPE 6SD1 STD ENG(37L) M8	9-09110-408-0	03	1	9601-9606	●	●
68	NUT; CLIP,OIL PIPE 6SD1 STD ENG(37L) M8 FLANGE	0-91150-108-0	03	1	9607-0004	●	●
68	NUT; CLIP,OIL PIPE 6SD1 STD ENG(37L) M8 FLANGE	0-91150-108-0	03	1	0005-0308	●	●
79	BOLT; BRKT 6HH1 STD ENG(65L) (A) M8X12 FLANGE	0-28080-812-0	02	1	9601-0308	●	●
79	BOLT; BRKT (A) M8X12 FLANGE	0-28080-812-0	02	1	0309-0512		●
79	BOLT; BRKT (A) M8X12 FLANGE	0-28050-812-0	02	1	0601-		●
79	BOLT; BRKT 6HH1 STD ENG(65L) (B) M8X20 FLANGE	0-28080-820-0	01	1	9601-9606	●	●
79	BOLT; BRKT 6HH1 STD ENG(65L) (B) M8X25 FLANGE	0-28680-825-0	01	1	9607-9801	●	●
79	BOLT; BRKT 6HH1 STD ENG(65L) (B) M8X20 FLANGE	0-28680-820-0	01	1	9802-0308	●	●
79	BOLT; BRKT 6HH1 STD ENG(65L) (B) M8X20 FLANGE	0-28680-820-0	01	1	0309-0512		●
79	BOLT; BRKT (B) M8X20 FLANGE	0-28650-820-0	01	1	0601-		●
79	BOLT; BRKT 6SD1 STD ENG(37L) (C) M8X25 FLANGE	0-28080-825-0	02	1	9601-9606	●	●
79	BOLT; BRKT 6SD1 STD ENG(37L) (C) M8X30 FLANGE	0-28680-830-0	02	1	9607-9610	●	●
79	BOLT; BRKT 6SD1 STD ENG(37L) (C) M8X25 FLANGE	0-28080-825-0	02	1	9611-9803	●	●
79	BOLT; BRKT 6SD1 STD ENG(37L) (C) M8X30 FLANGE	0-28680-830-0	02	1	9804-0308	●	●
81	WASHER; LK,FLEX HOSE 6SD1 STD ENG(37L) ID=20.2	9-09150-520-0	01	1	9601-0308	●	●
125	CONNECTOR; P/S PUMP 6HH1 STD ENG(65L) (A)	8-94394-319-0	01	1	9601-9605	●	●
125	CONNECTOR; P/S PUMP 6HH1 STD ENG(65L) (A)	8-94390-310-0	01	1	9606-9803	●	●
125	CONNECTOR; P/S PUMP 6HH1 STD ENG(65L) (B)	8-94390-584-1	01	1	9804-0212	●	●
125	CONNECTOR; P/S PUMP 6HH1 STD ENG(65L) EXC. ANTI NOISE EQUIPMENT ECE<SLK> (B)	8-94390-584-1	01	1	0301-0308	●	●
125	CONNECTOR; P/S PUMP 6HH1 STD ENG(65L) ANTI NOISE EQUIPMENT ECE<SLK> (B)	8-94391-745-0	01	1	0301-0308	●	●
125	CONNECTOR; P/S PUMP (B)	8-94391-745-0	01	1	0309-		●
125	CONNECTOR; P/S PUMP 6SD1 STD ENG(37L) (C)	1-21122-019-2	01	1	9601-0308	●	●
155	BOLT; CONNECTOR 6HH1 STD ENG(65L) M8X16 FLANGE	0-28080-816-0	02	1	9804-0308	●	●
155	BOLT; CONNECTOR M8X16 FLANGE	0-28080-816-0	02	1	0309-0512		●
155	BOLT; CONNECTOR M8X16 FLANGE	0-28050-816-0	02	1	0601-		●
155	BOLT; CONNECTOR 6SD1 STD ENG(37L) M8X18 W/LK&PL WASHER	0-50140-818-0	02	1	9601-0308	●	●
157	GASKET; P/S PUMP ALSO INCLUDED IN GASKET SET(ENGINE). 6HH1 STD ENG(65L) (A) ID=96.4	1-09623-178-0	01	1	9601-0308	●	●
157	GASKET; P/S PUMP ALSO INCLUDED IN GASKET SET(ENGINE). (A) ID=96.4	1-09623-178-0	01	1	0309-		●
157	GASKET; P/S PUMP ALSO INCLUDED IN GASKET SET(ENGINE). 6SD1 STD ENG(37L) (B) ID=77	1-09623-143-0	01	1	0210-0308	●	●
192	BRACKET; P/S OIL TANK 6HH1 STD ENG(65L) (A)	1-21119-142-1	01	1	9601-0308	●	●
192	BRACKET; P/S OIL TANK (A)	1-21119-142-1	01	1	0309-		●
192	BRACKET; P/S OIL TANK 6SD1 STD ENG(37L) (B)	1-21219-093-2	01	1	9601-0308	●	●
195	BOLT; BRKT 6HH1 STD ENG(65L) M10X25 FLANGE	0-28081-025-0	02	1	9601-9606	●	●
195	BOLT; BRKT 6HH1 STD ENG(65L) M10X30 FLANGE	0-28681-030-0	02	1	9607-0308	●	●
195	BOLT; BRKT M10X30 FLANGE	0-28681-030-0	02	1	0309-0512		●
195	BOLT; BRKT M10X30 FLANGE	0-28651-030-0	02	1	0601-		●
195	BOLT; BRKT 6SD1 STD ENG(37L) M10X20 FLANGE	0-28081-020-0	03	1	9601-9606	●	●
195	BOLT; BRKT 6SD1 STD ENG(37L) M10X25 FLANGE	0-28681-025-0	03	1	9607-0308	●	●
205	BOLT; EYE,FLEX HOSE,P/S 6SD1 STD ENG(37L) M18X36	1-09675-205-0	01	1	9601-0308	●	●
207	GASKET; FLEX HOSE,P/S PUMP 6SD1 STD ENG(37L) ID=18.2 OD=26.0	9-09571-418-0	02	1	9601-0308	●	●
239	BRACKET; FLEX HOSE 6SD1 STD ENG(37L)	1-47477-639-0	01	1	9601-0308	●	●
277	BOLT; HOSE CLIP 6HH1 STD ENG(65L) M8X16 FLANGE	0-28080-816-0	01	1	9601-0308	●	●
277	BOLT; HOSE CLIP M8X16 FLANGE	0-28080-816-0	01	1	0309-0512		●
277	BOLT; HOSE CLIP M8X16 FLANGE	0-28050-816-0	01	1	0601-		●
277	BOLT; HOSE CLIP 6SD1 STD ENG(37L) M8X20 FLANGE	0-28080-820-0	01	1	9601-9606	●	●
277	BOLT; HOSE CLIP 6SD1 STD ENG(37L) M8X25 FLANGE	0-28680-825-0	01	1	9607-0308	●	●
278	NUT; HOSE CLIP 6SD1 STD ENG(37L) M8	9-09110-408-0	01	1	9601-9606	●	●
278	NUT; HOSE CLIP 6SD1 STD ENG(37L) M8 FLANGE	0-91150-108-0	01	1	9607-0308	●	●
280	HOSE; P/S OIL PUMP,INL 6HH1 STD ENG(65L) (A)	1-21115-491-0	01	1	9601-0206	●	●
280	HOSE; P/S OIL PUMP,INL 6HH1 STD ENG(65L) (A)	1-21116-721-0	01	1	0207-0308	●	●
280	HOSE; P/S OIL PUMP,INL (A)	1-21116-721-0	01	1	0309-		●
280	HOSE; P/S OIL PUMP,INL 6SD1 STD ENG(37L) (B)	1-21115-048-1	01	1	9601-0308	●	●
282	SLEEVE; RUBBER,PIPE 6SD1 STD ENG(37L) ID=32 OD=36 L=50	1-09337-023-0	01	1	9601-0308	●	●

288 39 125 277 157 161 155 1 2 130 5 131 3 192 19 26 12 15 19 195 25 31 37 41 58 125 37 61 65 41 280 58 157 131 61 79 263 232 65 46 58 61 61 65 59 79 67 44

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date	A	B
1	TANK ASM; OIL,P/S 6HH1 STD ENG(65L) (A)	1-21210-205-0	01	1	9601-0308	●	●
1	TANK ASM; OIL,P/S (A)	1-21210-205-0	01	1	0309-0508		●
1	TANK ASM; OIL,P/S (A)	1-21210-238-1	01	1	0509-1006		●
1	TANK ASM; OIL,P/S (A)	8-98166-928-0	01	1	1007-		●
1	TANK ASM; OIL,P/S 6SD1 STD ENG(37L) (B)	1-21210-152-6	01	1	9601-0308	●	●
2	CAP; OIL TANK,P/S	1-21241-004-3	01	1	9601-0308	●	●
2	CAP; OIL TANK,P/S	1-21241-004-4	01	1	0309-1006		●
2	CAP; OIL TANK,P/S	8-98166-876-0	01	1	1007-		●
3	GASKET; OIL TANK,P/S	1-21249-003-1	01	1	9601-0308	●	●
3	GASKET; OIL TANK,P/S	1-21249-003-1	01	1	0309-		●
5	STRAINER; OIL TANK,P/S	1-21235-007-1	01	1	9601-0308	●	●
5	STRAINER; OIL TANK,P/S	1-21235-007-1	01	1	0309-		●
12	FILTER; MICROBON,OIL TANK,P/S 6HH1 STD ENG(65L) (A)	1-21235-011-0	01	1	9601-0308	●	●
12	FILTER; MICROBON,OIL TANK,P/S (A)	1-21235-011-0	01	1	0309-		●
12	FILTER; MICROBON,OIL TANK,P/S 6SD1 STD ENG(37L) (B)	1-21235-004-1	01	1	9601-0308	●	●
15	PLATE; FILTER,OIL TANK 6HH1 STD ENG(65L)	1-21249-007-1	02	1	9601-0308	●	●
15	PLATE; FILTER,OIL TANK 6SD1 STD ENG(37L)	1-21249-007-1	04	1	9601-0308	●	●
15	PLATE; FILTER,OIL TANK	1-21249-007-1	02	1	0309-0508		●
15	PLATE; FILTER,OIL TANK	1-21249-016-0	02	1	0509-		●
19	SEAT; OIL TANK	1-21249-004-0	02	1	9601-0308	●	●
19	SEAT; OIL TANK	1-21249-004-0	02	1	0309-		●
25	BOLT; OIL TANK BRKT 6HH1 STD ENG(65L) M8X20 FLANGE	0-28080-820-0	02	1	9601-9606	●	●
25	BOLT; OIL TANK BRKT 6HH1 STD ENG(65L) M8X25 FLANGE	0-28680-825-0	02	1	9607-0308	●	●
25	BOLT; OIL TANK BRKT 6SD1 STD ENG(37L) M8X20 FLANGE	0-28080-820-0	04	1	9601-9606	●	●
25	BOLT; OIL TANK BRKT 6SD1 STD ENG(37L) M8X25 FLANGE	0-28680-825-0	04	1	9607-0308	●	●
25	BOLT; OIL TANK BRKT M8X25 FLANGE	0-28680-825-0	02	1	0309-0512		●
25	BOLT; OIL TANK BRKT M8X25 FLANGE	0-28650-825-0	02	1	0601-		●
26	NUT; OIL TANK TO BRKT 6HH1 STD ENG(65L) M8	9-09110-408-0	02	1	9601-9606	●	●
26	NUT; OIL TANK TO BRKT 6HH1 STD ENG(65L) M8 FLANGE	0-91150-108-0	02	1	9607-0308	●	●
26	NUT; OIL TANK TO BRKT 6SD1 STD ENG(37L) M8	9-09110-408-0	04	1	9601-9606	●	●
26	NUT; OIL TANK TO BRKT 6SD1 STD ENG(37L) M8 FLANGE	0-91150-108-0	04	1	9607-0308	●	●
26	NUT; OIL TANK TO BRKT M8 FLANGE	0-91150-108-0	02	1	0309-0602		●
26	NUT; OIL TANK TO BRKT M8 FLANGE	0-91180-108-0	02	1	0603-		●
31	HOSE; P/S OIL TANK,INL 6HH1 STD ENG(65L) (A)	1-21113-590-0	01	1	9601-0308	●	●
31	HOSE; P/S OIL TANK,INL (A)	1-21113-590-0	01	1	0309-		●
31	HOSE; P/S OIL TANK,INL 6SD1 STD ENG(37L) (B)	1-21115-465-1	01	1	9601-0004	●	●
31	HOSE; P/S OIL TANK,INL 6SD1 STD ENG(37L) (B)	1-21115-465-2	01	1	0005-0308	●	●
37	CLIP; HOSE,P/S (A) ID=26	1-09704-082-0	02	1	9601-0308	●	●
37	CLIP; HOSE,P/S (A) ID=26	1-09704-082-0	02	1	0309-		●
37	CLIP; HOSE,P/S 6SD1 STD ENG(37L) (B) ID=24.5 H=35 L=25	1-09700-990-0	01	1	9601-0108	●	●
37	CLIP; HOSE,P/S 6SD1 STD ENG(37L) (B) ID=24.5 H=23 L=25	1-09700-862-0	01	1	0109-0308	●	●
39	CLIP; FLEX HOSE 6HH1 STD ENG(65L) ID=40	8-94226-553-0	01	1	9601-0308	●	●
39	CLIP; FLEX HOSE ID=40	8-94226-553-0	01	1	0309-		●
41	CLIP; HOSE,P/S ID=32	1-09704-085-0	02	1	9601-0308	●	●
41	CLIP; HOSE,P/S ID=32	1-09704-085-0	02	1	0309-		●
44	PIPE; OIL,P/S UNIT TO NIPPLE 6HH1 STD ENG(65L)	1-21115-359-0	01	1	9601-0308	●	●
44	PIPE; OIL,P/S UNIT TO NIPPLE	1-21115-359-0	01	1	0309-		●
46	PIPE; OIL,P/S UNIT TO OIL TANK 6HH1 STD ENG(65L) (A)	1-21115-360-0	01	1	9601-9712	●	●
46	PIPE; OIL,P/S UNIT TO OIL TANK 6HH1 STD ENG(65L) (A)	1-21116-024-1	01	1	9801-9803	●	●
46	PIPE; OIL,P/S UNIT TO OIL TANK 6HH1 STD ENG(65L) (A)	1-21116-028-1	01	1	9804-0308	●	●
46	PIPE; OIL,P/S UNIT TO OIL TANK (A)	1-21116-028-1	01	1	0309-		●
46	PIPE; OIL,P/S UNIT TO OIL TANK 6SD1 STD ENG(37L) (B)	1-21115-565-0	01	1	9601-0004	●	●
46	PIPE; OIL,P/S UNIT TO OIL TANK 6SD1 STD ENG(37L) (B)	1-21115-565-0	01	1	0005-0308	●	●
58	BOLT; CLIP 6HH1 STD ENG(65L) (A) M8X20 FLANGE	0-28080-820-0	01	1	9601-9606	●	●
58	BOLT; CLIP 6HH1 STD ENG(65L) (A) M8X25 FLANGE	0-28680-825-0	01	1	9607-9803	●	●
58	BOLT; CLIP 6HH1 STD ENG(65L) (A) M8X20 FLANGE	0-28680-820-0	01	1	9804-0308	●	●
58	BOLT; CLIP 6HH1 STD ENG(65L) (A) M8X20 FLANGE	0-28680-820-0	01	1	0309-0512		●
58	BOLT; CLIP (A) M8X20 FLANGE	0-28650-820-0	01	1	0601-		●
58	BOLT; CLIP 6HH1 STD ENG(65L) (B) M8X25 FLANGE	0-28080-825-0	02	1	9601-9606	●	●
58	BOLT; CLIP 6HH1 STD ENG(65L) (B) M8X30 FLANGE	0-28680-830-0	02	1	9607-0308	●	●
58	BOLT; CLIP 6HH1 STD ENG(65L) (B) M8X30 FLANGE	0-28680-830-0	02	1	0309-0512		●
58	BOLT; CLIP (B) M8X30 FLANGE	0-28650-830-0	02	1	0601-		●
58	BOLT; CLIP 6SD1 STD ENG(37L) (D) M8X16 FLANGE	0-28080-816-0	01	1	9601-0308	●	●
58	BOLT; CLIP 6SD1 STD ENG(37L) (E) M8X25 FLANGE	0-28080-825-0	01	1	9601-9606	●	●
58	BOLT; CLIP 6SD1 STD ENG(37L) (E) M8X45 FLANGE	0-28080-845-0	02	1	9607-0004	●	●
58	BOLT; CLIP 6SD1 STD ENG(37L) (E) M8X45 FLANGE	0-28080-845-0	02	1	0005-0308	●	●
58	BOLT; CLIP 6SD1 STD ENG(37L) (C) M8X40 FLANGE	0-28080-840-0	02	1	9601-9606	●	●
58	BOLT; CLIP 6SD1 STD ENG(37L) (C) M8X30 FLANGE	0-28680-830-0	01	1	9607-0308	●	●
59	BRACKET; CLIP,OIL PIPE 6HH1 STD ENG(65L) (C) L=60	1-47475-455-0	01	1	9601-0308	●	●
59	BRACKET; CLIP,OIL PIPE (C) L=60	1-47475-455-0	01	1	0309-		●
59	BRACKET; CLIP,OIL PIPE 6SD1 STD ENG(37L) (A) L=60	1-47465-745-0	01	1	9601-0308	●	●
59	BRACKET; CLIP,OIL PIPE 6SD1 STD ENG(37L) (B)	1-47475-427-1	02	1	9601-0004	●	●
59	BRACKET; CLIP,OIL PIPE 6SD1 STD ENG(37L) (B)	1-47475-427-1	02	1	0005-0308	●	●
61	CLIP; OIL PIPE (C) ID=12 & 15	1-09709-281-1	01	1	9601-0308	●	●
61	CLIP; OIL PIPE (C) ID=12 & 15	1-09709-281-1	01	1	0309-		●
61	CLIP; OIL PIPE 6HH1 STD ENG(65L) (A) ID=15 H=24 L=20	1-09700-606-0	02	1	9601-0308	●	●
61	CLIP; OIL PIPE (A) ID=15 H=24 L=20	1-09700-606-0	02	1	0309-		●
61	CLIP; OIL PIPE 6HH1 STD ENG(65L) (B) ID=16 & 13 L=18 & 17	1-09700-658-0	01	1	9601-0001	●	●
61	CLIP; OIL PIPE 6HH1 STD ENG(65L) (B) ID=16 & 13 L=21.5 & 21.5	1-09700-668-0	01	1	0002-0308	●	●
61	CLIP; OIL PIPE (B) ID=16 & 13 L=21.5 & 21.5	1-09700-668-0	01	1	0309-		●
61	CLIP; OIL PIPE 6SD1 STD ENG(37L) (B) ID=16 & 13 L=21.5 & 21.5	1-09700-668-0	03	1	9601-0004	●	●
61	CLIP; OIL PIPE 6SD1 STD ENG(37L) (B) ID=16 & 13 L=21.5 & 21.5	1-09700-668-0	03	1	0005-0308	●	●
61	CLIP; OIL PIPE 6SD1 STD ENG(37L) (D) ID=16 L=40	9-09525-576-0	01	1	9601-0308	●	●
65	NUT; BRKT 6HH1 STD ENG(65L) M8	9-09110-408-0	03	1	9601-9606	●	●
65	NUT; BRKT 6HH1 STD ENG(65L) M8 FLANGE	0-91150-108-0	03	1	9607-0308	●	●
65	NUT; BRKT 6HH1 STD ENG(65L) M8 FLANGE	0-91150-108-0	03	1	0309-0602		●
65	NUT; BRKT M8 FLANGE	0-91180-108-0	03	1	0603-		●
65	NUT; BRKT 6SD1 STD ENG(37L) M8	9-09110-408-0	01	1	9601-9606	●	●
65	NUT; BRKT 6SD1 STD ENG(37L) M8	9-09110-408-0	01	1	9601-9606	●	●
65	NUT; BRKT 6SD1 STD ENG(37L) M8 FLANGE	0-91150-108-0	01	1	9607-0308	●	●
65	NUT; BRKT 6SD1 STD ENG(37L) M8 FLANGE	0-91150-108-0	01	1	9607-0308	●	●
65	NUT; BRKT 6SD1 STD ENG(37L) M8	9-09110-408-0	02	1	9601-9606	●	●
65	NUT; BRKT 6SD1 STD ENG(37L) M8 FLANGE	0-91150-108-0	02	1	9607-0308	●	●
67	NUT; BRKT 6HH1 STD ENG(65L) M8	9-09110-408-0	01	1	9601-9606	●	●
67	NUT; BRKT 6HH1 STD ENG(65L) M8 FLANGE	0-91150-108-0	01	1	9607-0308	●	●
67	NUT; BRKT 6HH1 STD ENG(65L) M8 FLANGE	0-91150-108-0	01	1	0309-0602		●
67	NUT; BRKT M8 FLANGE	0-91180-108-0	01	1	0603-		●
79	BOLT; BRKT 6HH1 STD ENG(65L) (A) M8X12 FLANGE	0-28080-812-0	02	1	9601-0308	●	●
79	BOLT; BRKT (A) M8X12 FLANGE	0-28080-812-0	02	1	0309-0512		●
79	BOLT; BRKT (A) M8X12 FLANGE	0-28050-812-0	02	1	0601-		●
79	BOLT; BRKT 6HH1 STD ENG(65L) (B) M8X20 FLANGE	0-28080-820-0	01	1	9601-9606	●	●
79	BOLT; BRKT 6HH1 STD ENG(65L) (B) M8X25 FLANGE	0-28680-825-0	01	1	9607-9801	●	●
79	BOLT; BRKT 6HH1 STD ENG(65L) (B) M8X20 FLANGE	0-28680-820-0	01	1	9802-0308	●	●
79	BOLT; BRKT 6HH1 STD ENG(65L) (B) M8X20 FLANGE	0-28680-820-0	01	1	0309-0512		●
79	BOLT; BRKT (B) M8X20 FLANGE	0-28650-820-0	01	1	0601-		●
79	BOLT; BRKT 6SD1 STD ENG(37L) (C) M8X25 FLANGE	0-28080-825-0	02	1	9601-9606	●	●
79	BOLT; BRKT 6SD1 STD ENG(37L) (C) M8X30 FLANGE	0-28680-830-0	02	1	9607-9610	●	●
79	BOLT; BRKT 6SD1 STD ENG(37L) (C) M8X25 FLANGE	0-28080-825-0	02	1	9611-9803	●	●
79	BOLT; BRKT 6SD1 STD ENG(37L) (C) M8X30 FLANGE	0-28680-830-0	02	1	9804-0308	●	●
125	CONNECTOR; P/S PUMP 6HH1 STD ENG(65L) (A)	8-94394-319-0	01	1	9601-9605	●	●
125	CONNECTOR; P/S PUMP 6HH1 STD ENG(65L) (A)	8-94390-310-0	01	1	9606-9803	●	●
125	CONNECTOR; P/S PUMP 6HH1 STD ENG(65L) (B)	8-94390-584-1	01	1	9804-0212	●	●
125	CONNECTOR; P/S PUMP 6HH1 STD ENG(65L) EXC. ANTI NOISE EQUIPMENT ECE<SLK> (B)	8-94390-584-1	01	1	0301-0308	●	●
125	CONNECTOR; P/S PUMP 6HH1 STD ENG(65L) ANTI NOISE EQUIPMENT ECE<SLK> (B)	8-94391-745-0	01	1	0301-0308	●	●
125	CONNECTOR; P/S PUMP (B)	8-94391-745-0	01	1	0309-		●
125	CONNECTOR; P/S PUMP 6SD1 STD ENG(37L) (C)	1-21122-019-2	01	1	9601-0308	●	●
130	ADAPTER; P/S PUMP 6HH1 STD ENG(65L)	8-94390-583-0	01	1	9804-0308	●	●
130	ADAPTER; P/S PUMP	8-94390-583-0	01	1	0309-		●
131	HOSE; RUBBER,P/S 6HH1 STD ENG(65L)	8-94396-331-1	01	1	9601-0308	●	●
131	HOSE; RUBBER,P/S	8-94396-331-1	01	1	0309-		●
155	BOLT; CONNECTOR 6HH1 STD ENG(65L) M8X16 FLANGE	0-28080-816-0	02	1	9804-0308	●	●
155	BOLT; CONNECTOR M8X16 FLANGE	0-28080-816-0	02	1	0309-0512		●
155	BOLT; CONNECTOR M8X16 FLANGE	0-28050-816-0	02	1	0601-		●
155	BOLT; CONNECTOR 6SD1 STD ENG(37L) M8X18 W/LK&PL WASHER	0-50140-818-0	02	1	9601-0308	●	●
157	GASKET; P/S PUMP ALSO INCLUDED IN GASKET SET(ENGINE). 6HH1 STD ENG(65L) (A) ID=96.4	1-09623-178-0	01	1	9601-0308	●	●
157	GASKET; P/S PUMP ALSO INCLUDED IN GASKET SET(ENGINE). (A) ID=96.4	1-09623-178-0	01	1	0309-		●
157	GASKET; P/S PUMP ALSO INCLUDED IN GASKET SET(ENGINE). 6SD1 STD ENG(37L) (B) ID=77	1-09623-143-0	01	1	0210-0308	●	●
161	NUT; P/S PIPE 6HH1 STD ENG(65L) M10 FLANGE	0-91150-110-0	01	1	9804-0308	●	●
161	NUT; P/S PIPE M10 FLANGE	0-91150-110-0	01	1	0309-0602		●
161	NUT; P/S PIPE M10 FLANGE	0-91180-110-0	01	1	0603-		●
192	BRACKET; P/S OIL TANK 6HH1 STD ENG(65L) (A)	1-21119-142-1	01	1	9601-0308	●	●
192	BRACKET; P/S OIL TANK (A)	1-21119-142-1	01	1	0309-		●
192	BRACKET; P/S OIL TANK 6SD1 STD ENG(37L) (B)	1-21219-093-2	01	1	9601-0308	●	●
195	BOLT; BRKT 6HH1 STD ENG(65L) M10X25 FLANGE	0-28081-025-0	02	1	9601-9606	●	●
195	BOLT; BRKT 6HH1 STD ENG(65L) M10X30 FLANGE	0-28681-030-0	02	1	9607-0308	●	●
195	BOLT; BRKT M10X30 FLANGE	0-28681-030-0	02	1	0309-0512		●
195	BOLT; BRKT M10X30 FLANGE	0-28651-030-0	02	1	0601-		●
195	BOLT; BRKT 6SD1 STD ENG(37L) M10X20 FLANGE	0-28081-020-0	03	1	9601-9606	●	●
195	BOLT; BRKT 6SD1 STD ENG(37L) M10X25 FLANGE	0-28681-025-0	03	1	9607-0308	●	●
232	NUT; BRKT 6HH1 STD ENG(65L) M8	9-09110-408-0	02	1	9601-9606	●	●
232	NUT; BRKT 6HH1 STD ENG(65L) M8 FLANGE	0-91150-108-0	02	1	9607-0308	●	●
232	NUT; BRKT M8 FLANGE	0-91150-108-0	02	1	0309-0602		●
232	NUT; BRKT 6HH1 STD ENG(65L) M8 FLANGE	0-91180-108-0	02	1	0603-		●
263	BRACKET; P/S PIPE 6HH1 STD ENG(65L)	8-94393-981-0	01	1	9601-9901	●	●
263	BRACKET; P/S PIPE 6HH1 STD ENG(65L)	8-97600-117-0	01	1	9902-0308	●	●
263	BRACKET; P/S PIPE	8-97600-117-0	01	1	0309-		●
277	BOLT; HOSE CLIP 6HH1 STD ENG(65L) M8X16 FLANGE	0-28080-816-0	01	1	9601-0308	●	●
277	BOLT; HOSE CLIP M8X16 FLANGE	0-28080-816-0	01	1	0309-0512		●
277	BOLT; HOSE CLIP M8X16 FLANGE	0-28050-816-0	01	1	0601-		●
277	BOLT; HOSE CLIP 6SD1 STD ENG(37L) M8X20 FLANGE	0-28080-820-0	01	1	9601-9606	●	●
277	BOLT; HOSE CLIP 6SD1 STD ENG(37L) M8X25 FLANGE	0-28680-825-0	01	1	9607-0308	●	●
280	HOSE; P/S OIL PUMP,INL 6HH1 STD ENG(65L) (A)	1-21115-491-0	01	1	9601-0206	●	●
280	HOSE; P/S OIL PUMP,INL 6HH1 STD ENG(65L) (A)	1-21116-721-0	01	1	0207-0308	●	●
280	HOSE; P/S OIL PUMP,INL (A)	1-21116-721-0	01	1	0309-		●
280	HOSE; P/S OIL PUMP,INL 6SD1 STD ENG(37L) (B)	1-21115-048-1	01	1	9601-0308	●	●
288	BRACKET; CLIP,P/S 6HH1 STD ENG(65L)	1-82659-149-0	01	1	9601-0308	●	●
288	BRACKET; CLIP,P/S	1-82659-149-0	01	1	0309-		●

İpucu: çizimdeki balona veya tablodaki Balon sütununa tıkla; ilgili parçalar vurgulanır. Birden çok çizim varsa üstteki seçim kutusu/oklarla gezin.
