0-61 — BATTERY AND ENGINE ELECTRICAL PARTS (#22677) — 95 parça

62 49 3 1 61 75 23 75 112 30 31 48 3

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date	A	B	C
1	02.341 CABLE; BATTERY L=180	8-97230-530-2	01	1	0302-0506	●
1	02.341 CABLE; BATTERY L=180	8-97230-530-2	01	1	0507-0606		●
1	02.341 CABLE; BATTERY L=280	8-97230-719-2	01	1	0607-			●
3	02.525 HARNESS; CABLE,BATTERY TO STARTE FRT INDEPENDENT SUSPENSION(6PP)	8-97359-628-1	01	1	0302-0506	●
3	02.525 HARNESS; CABLE,BATTERY TO STARTE FRT INDEPENDENT SUSPENSION(6PP)	8-97359-628-1	01	1	0507-0606		●
3	02.525 HARNESS; CABLE,BATTERY TO STARTE SGL TIRE(NKB***) TRANSMISSION CONTROL-SMOOTHER(8GF)	8-98019-627-1	01	1	0607-			●
3	02.525 HARNESS; CABLE,BATTERY TO STARTE EXC. FRT INDEPENDENT SUSPENSION(6PP)	8-97363-573-0	01	1	0302-0506	●
3	02.525 HARNESS; CABLE,BATTERY TO STARTE EXC. FRT INDEPENDENT SUSPENSION(6PP)	8-97363-573-0	01	1	0507-0606		●
3	02.525 HARNESS; CABLE,BATTERY TO STARTE SGL TIRE(NKB***) EXC. TRANSMISSION CONTROL-SMOOTHER(8GF)	8-98019-624-1	01	1	0607-			●
3	02.525 HARNESS; CABLE,BATTERY TO STARTE DUAL RR TIRE(NKC***) TRANSMISSION CONTROL-SMOOTHER(8GF)	8-98019-628-0	01	1	0607-			●
3	02.525 HARNESS; CABLE,BATTERY TO STARTE DUAL RR TIRE(NKC***) EXC. TRANSMISSION CONTROL-SMOOTHER(8GF)	8-98019-625-0	01	1	0607-			●
23	02.343 BRACKET; CABLE CLIP TO FRAME SGL TIRE(NKB***)	8-98027-977-0	01	1	0607-			●
30	02.334 NUT; CABLE,STARTER TO BATTERY 02.559 M8	9-09110-408-0	01	1	0302-0506	●
30	02.334 NUT; CABLE,STARTER TO BATTERY 02.559 M8	9-09110-408-0	01	1	0507-0512		●
30	02.334 NUT; CABLE,STARTER TO BATTERY M8	0-91110-508-0	01	1	0601-0606		●
30	02.334 NUT; CABLE,STARTER TO BATTERY M8	0-91110-508-0	01	1	0607-			●
31	02.334 WASHER; LK,CABLE,STARTER TO BATT 00.002 ID=8.2	9-09150-508-0	01	1	0302-0506	●
31	02.334 WASHER; LK,CABLE,STARTER TO BATT 00.002 ID=8.2	9-09150-508-0	01	1	0507-0603		●
31	02.334 WASHER; LK,CABLE,STARTER TO BATT 04.439 ID=8.2	0-91510-508-0	01	1	0604-0606		●
31	02.334 WASHER; LK,CABLE,STARTER TO BATT 02.559 ID=8.2	0-91510-808-0	01	1	0607-			●
48	02.343 CLIP; CABLE EXC. FRT INDEPENDENT SUSPENSION(6PP) 02.559 L=250	5-09707-030-1	01	1	0302-0506	●
48	02.343 CLIP; CABLE DUAL RR TIRE(NKC***) 4 WHEEL ANTI LOCK BRAKE<JE5> 02.559 L=250	5-09707-030-1	01	1	0507-0606		●
48	02.343 CLIP; CABLE DUAL RR TIRE(NKC***) EXC. 4 WHEEL ANTI LOCK BRAKE<JE5> 03.162 L=140	5-09707-031-1	01	1	0507-0606		●
48	02.343 CLIP; CABLE TRANSMISSION CONTROL-SMOOTHER(8GF) 03.162 L=140	5-09707-031-1	01	1	0607-			●
48	02.343 CLIP; CABLE 03.162 L=140	5-09707-031-1	01	1	0607-			●
49	02.342 CABLE; BATTERY TO S/MBR,RH L=500	8-97035-845-3	01	1	0302-0506	●
49	02.342 CABLE; BATTERY TO S/MBR,RH L=500	8-97035-845-3	01	1	0507-0606		●
49	02.342 CABLE; BATTERY TO S/MBR,RH L=330	8-97373-778-0	01	1	0607-			●
61	02.333 BRACKET; BATTERY CABLE (A)	8-97353-709-0	01	1	0302-0506	●
61	02.333 BRACKET; BATTERY CABLE (A)	8-97353-709-0	01	1	0507-0606		●
61	02.333 BRACKET; BATTERY CABLE (C)	8-97369-198-1	01	1	0607-			●
61	02.333 BRACKET; BATTERY CABLE (B)	8-97362-323-0	01	1	0302-0506	●
61	02.333 BRACKET; BATTERY CABLE (B)	8-97362-323-0	01	1	0507-0606		●
62	02.343 BOLT; EARTH CABLE FIX M8X25 W/LK&PL WASHER	8-97087-203-0	01	1	0302-0506	●
62	02.343 BOLT; EARTH CABLE FIX M8X25 W/LK&PL WASHER	8-97087-203-0	01	1	0507-0606		●
62	02.343 BOLT; EARTH CABLE FIX M8X25 W/LK&PL WASHER	8-97087-203-0	01	1	0607-1004			●
62	02.343 BOLT; EARTH CABLE FIX M8X24 W/PL WASHER	8-98141-256-1	01	1	1005-			●
75	02.333 BOLT; BRKT 00.685 M6X25 FLANGE	0-28650-625-0	01	1	0607-			●
75	02.333 BOLT; BRKT SGL TIRE(NKB***) 06.216 M8X25 FLANGE	0-28650-825-0	01	1	0607-			●
112	02.343 TERMINAL; BATTERY (A) <+>	8-97356-925-1	01	1	0302-0506	●
112	02.343 TERMINAL; BATTERY (A) <+>	8-97356-925-1	01	1	0507-0606		●
112	02.343 TERMINAL; BATTERY (A) <+>	8-97356-925-1	01	1	0607-			●
112	02.343 TERMINAL; BATTERY (B) <->	8-97356-926-1	01	1	0302-0506	●
112	02.343 TERMINAL; BATTERY (B) <->	8-97356-926-1	01	1	0507-0606		●

3 1 112 112 2 62 49 48 30 104 61 3 42 31 6 61

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date	A	B	C
1	02.341 CABLE; BATTERY L=180	8-97230-530-2	01	1	0302-0506	●
1	02.341 CABLE; BATTERY L=180	8-97230-530-2	01	1	0507-0606		●
1	02.341 CABLE; BATTERY L=280	8-97230-719-2	01	1	0607-			●
2	02.341 CABLE; BATTERY L=180	8-97230-538-1	01	1	0302-0506	●
2	02.341 CABLE; BATTERY L=180	8-97230-538-1	01	1	0507-0606		●
3	02.525 HARNESS; CABLE,BATTERY TO STARTE FRT INDEPENDENT SUSPENSION(6PP)	8-97359-628-1	01	1	0302-0506	●
3	02.525 HARNESS; CABLE,BATTERY TO STARTE FRT INDEPENDENT SUSPENSION(6PP)	8-97359-628-1	01	1	0507-0606		●
3	02.525 HARNESS; CABLE,BATTERY TO STARTE SGL TIRE(NKB***) TRANSMISSION CONTROL-SMOOTHER(8GF)	8-98019-627-1	01	1	0607-			●
3	02.525 HARNESS; CABLE,BATTERY TO STARTE EXC. FRT INDEPENDENT SUSPENSION(6PP)	8-97363-573-0	01	1	0302-0506	●
3	02.525 HARNESS; CABLE,BATTERY TO STARTE EXC. FRT INDEPENDENT SUSPENSION(6PP)	8-97363-573-0	01	1	0507-0606		●
3	02.525 HARNESS; CABLE,BATTERY TO STARTE SGL TIRE(NKB***) EXC. TRANSMISSION CONTROL-SMOOTHER(8GF)	8-98019-624-1	01	1	0607-			●
3	02.525 HARNESS; CABLE,BATTERY TO STARTE DUAL RR TIRE(NKC***) TRANSMISSION CONTROL-SMOOTHER(8GF)	8-98019-628-0	01	1	0607-			●
3	02.525 HARNESS; CABLE,BATTERY TO STARTE DUAL RR TIRE(NKC***) EXC. TRANSMISSION CONTROL-SMOOTHER(8GF)	8-98019-625-0	01	1	0607-			●
6	02.343 GROMMET; BATTERY CABLE ID=17	8-94128-319-2	01	1	0302-0506	●
6	02.343 GROMMET; BATTERY CABLE ID=17	8-94128-319-2	01	1	0507-0606		●
30	02.334 NUT; CABLE,STARTER TO BATTERY 02.559 M8	9-09110-408-0	01	1	0302-0506	●
30	02.334 NUT; CABLE,STARTER TO BATTERY 02.559 M8	9-09110-408-0	01	1	0507-0512		●
30	02.334 NUT; CABLE,STARTER TO BATTERY M8	0-91110-508-0	01	1	0601-0606		●
30	02.334 NUT; CABLE,STARTER TO BATTERY M8	0-91110-508-0	01	1	0607-			●
31	02.334 WASHER; LK,CABLE,STARTER TO BATT 00.002 ID=8.2	9-09150-508-0	01	1	0302-0506	●
31	02.334 WASHER; LK,CABLE,STARTER TO BATT 00.002 ID=8.2	9-09150-508-0	01	1	0507-0603		●
31	02.334 WASHER; LK,CABLE,STARTER TO BATT 04.439 ID=8.2	0-91510-508-0	01	1	0604-0606		●
31	02.334 WASHER; LK,CABLE,STARTER TO BATT 02.559 ID=8.2	0-91510-808-0	01	1	0607-			●
42	02.343 BOLT; BRKT,BATTERY CABLE 02.559 M10X16 FLANGE	0-28081-016-0	01	1	0302-0506	●
42	02.343 BOLT; BRKT,BATTERY CABLE 02.559 M10X16 FLANGE	0-28081-016-0	01	1	0507-0512		●
42	02.343 BOLT; BRKT,BATTERY CABLE 02.483 M10X16 FLANGE	0-28051-016-0	01	1	0601-0606		●
48	02.343 CLIP; CABLE EXC. FRT INDEPENDENT SUSPENSION(6PP) 02.559 L=250	5-09707-030-1	01	1	0302-0506	●
48	02.343 CLIP; CABLE DUAL RR TIRE(NKC***) 4 WHEEL ANTI LOCK BRAKE<JE5> 02.559 L=250	5-09707-030-1	01	1	0507-0606		●
48	02.343 CLIP; CABLE DUAL RR TIRE(NKC***) EXC. 4 WHEEL ANTI LOCK BRAKE<JE5> 03.162 L=140	5-09707-031-1	01	1	0507-0606		●
48	02.343 CLIP; CABLE TRANSMISSION CONTROL-SMOOTHER(8GF) 03.162 L=140	5-09707-031-1	01	1	0607-			●
48	02.343 CLIP; CABLE 03.162 L=140	5-09707-031-1	01	1	0607-			●
49	02.342 CABLE; BATTERY TO S/MBR,RH L=500	8-97035-845-3	01	1	0302-0506	●
49	02.342 CABLE; BATTERY TO S/MBR,RH L=500	8-97035-845-3	01	1	0507-0606		●
49	02.342 CABLE; BATTERY TO S/MBR,RH L=330	8-97373-778-0	01	1	0607-			●
61	02.333 BRACKET; BATTERY CABLE (A)	8-97353-709-0	01	1	0302-0506	●
61	02.333 BRACKET; BATTERY CABLE (A)	8-97353-709-0	01	1	0507-0606		●
61	02.333 BRACKET; BATTERY CABLE (C)	8-97369-198-1	01	1	0607-			●
61	02.333 BRACKET; BATTERY CABLE (B)	8-97362-323-0	01	1	0302-0506	●
61	02.333 BRACKET; BATTERY CABLE (B)	8-97362-323-0	01	1	0507-0606		●
62	02.343 BOLT; EARTH CABLE FIX M8X25 W/LK&PL WASHER	8-97087-203-0	01	1	0302-0506	●
62	02.343 BOLT; EARTH CABLE FIX M8X25 W/LK&PL WASHER	8-97087-203-0	01	1	0507-0606		●
62	02.343 BOLT; EARTH CABLE FIX M8X25 W/LK&PL WASHER	8-97087-203-0	01	1	0607-1004			●
62	02.343 BOLT; EARTH CABLE FIX M8X24 W/PL WASHER	8-98141-256-1	01	1	1005-			●
104	02.343 NUT; BATTERY CABLE 04.594 M6 FLANGE	0-91150-106-0	01	1	0302-0506	●
104	02.343 NUT; BATTERY CABLE 04.594 M6 FLANGE	0-91150-106-0	01	1	0507-0602		●
104	02.343 NUT; BATTERY CABLE 01.062 M6 FLANGE	0-91180-106-0	01	1	0603-0606		●
112	02.343 TERMINAL; BATTERY (A) <+>	8-97356-925-1	01	1	0302-0506	●
112	02.343 TERMINAL; BATTERY (A) <+>	8-97356-925-1	01	1	0507-0606		●
112	02.343 TERMINAL; BATTERY (A) <+>	8-97356-925-1	01	1	0607-			●
112	02.343 TERMINAL; BATTERY (B) <->	8-97356-926-1	01	1	0302-0506	●
112	02.343 TERMINAL; BATTERY (B) <->	8-97356-926-1	01	1	0507-0606		●

İpucu: çizimdeki balona veya tablodaki Balon sütununa tıkla; ilgili parçalar vurgulanır. Birden çok çizim varsa üstteki seçim kutusu/oklarla gezin.
