1 |
CAP; HUB,FRT AXLE
OD=156
|
9-42313-123-2 |
02 |
1 |
0907- |
| |
3 |
BOLT; HUB CAP,FRT WHEEL
M8X12 FLANGE
|
0-28050-812-0 |
12 |
1 |
0907- |
| |
4 |
GASKET; HUB CAP,FRT WHEEL
|
1-42319-185-2 |
02 |
1 |
0907- |
| |
5 |
BOLT; LK WASHER
M6X16 HEX SOCKET
|
8-98084-271-0 |
04 |
1 |
0907-1201 |
| |
5 |
BOLT; LK WASHER
M6X16 HEX SOCKET
|
8-98200-943-0 |
04 |
1 |
1202- |
| |
6 |
WASHER; LK,FRT HUB
ID=48
|
8-98084-561-0 |
02 |
1 |
0907- |
| |
10 |
NUT; FRT HUB BRG
M48
|
1-09840-012-5 |
02 |
1 |
0907- |
| |
12 |
WASHER; LK,FRT HUB BRG
ID=48
|
1-09533-016-0 |
02 |
1 |
0907-0911 |
| |
12 |
WASHER; LK,FRT HUB BRG
ID=48
|
8-98156-755-0 |
02 |
1 |
0912- |
| |
13 |
BEARING; HUB OUTER,FRT AXLE
JTEKT
|
1-09812-234-0 |
02 |
1 |
0907- |
| |
15 |
PIN; WHEEL,FRT AXLE
DISC WHEEL 8STUD 19.5X6.75 147-12(FJR)
(B)
M22X82 RH THREAD
|
1-42337-093-1 |
16 |
1 |
1307- |
| |
15 |
PIN; WHEEL,FRT AXLE
(A)
M24X37.5,M22X49.5 RH THREAD
|
1-42331-148-1 |
08 |
1 |
0907-1306 |
| |
15 |
PIN; WHEEL,FRT AXLE
DISC WHEEL 8STUD 6.75X19.5 147-12(TEE)
(A)
M24X37.5,M22X49.5 RH THREAD
|
1-42331-148-1 |
08 |
1 |
1307- |
| |
15 |
PIN; WHEEL,FRT AXLE
(A)
M24X37.5 LH THREAD,M22X49.5 RH THREAD
|
1-42332-148-1 |
08 |
1 |
0907-1306 |
| |
15 |
PIN; WHEEL,FRT AXLE
DISC WHEEL 8STUD 6.75X19.5 147-12(TEE)
(A)
M24X37.5 LH THREAD,M22X49.5 RH THREAD
|
1-42332-148-1 |
08 |
1 |
1307- |
| |
17 |
HUB; FRT AXLE
DISC WHEEL 8STUD 19.5X6.75 147-12(FJR)
(B)
|
8-98141-529-1 |
02 |
1 |
1307- |
| |
17 |
HUB; FRT AXLE
(A)
|
1-42312-162-0 |
02 |
1 |
0907-1306 |
| |
17 |
HUB; FRT AXLE
DISC WHEEL 8STUD 6.75X19.5 147-12(TEE)
(A)
|
1-42312-162-0 |
02 |
1 |
1307- |
| |
19 |
BEARING; HUB INNER,FRT AXLE
|
1-09812-217-0 |
02 |
1 |
0907- |
| |
21 |
RING; SNAP,HUB
OD=132
|
9-09950-164-0 |
02 |
1 |
0907- |
| |
23 |
DRUM; BRK,FRT
DISC WHEEL 8STUD 19.5X6.75 147-12(FJR)
(B)
|
1-42315-415-0 |
02 |
1 |
1307- |
| |
23 |
DRUM; BRK,FRT
(A)
|
1-42315-414-0 |
02 |
1 |
0907-1306 |
| |
23 |
DRUM; BRK,FRT
DISC WHEEL 8STUD 6.75X19.5 147-12(TEE)
(A)
|
1-42315-414-0 |
02 |
1 |
1307- |
| |
27 |
NUT; WHEEL PIN,FRT AXLE
M22 FLANGE
|
1-09440-065-0 |
16 |
1 |
0907-1306 |
| |
27 |
NUT; WHEEL PIN,FRT AXLE
DISC WHEEL 8STUD 6.75X19.5 147-12(TEE)
M22 FLANGE
|
1-09440-065-0 |
16 |
1 |
1307- |
| |
28 |
SEAL; OIL,FRT HUB
OD=128
|
1-09625-129-0 |
02 |
1 |
0907- |
| |
30 |
RING; EXCITER,FRT HUB
|
1-42319-203-0 |
02 |
1 |
0907- |
| |
33 |
WASHER; LK,DRUM COVER
ID=14.2
|
0-91510-814-0 |
08 |
1 |
0907- |
| |
35 |
BOLT; DRUM COVER
M14X50
|
1-09040-066-0 |
08 |
1 |
0907- |
| |
53 |
NUT; DRUM COVER
M14
|
0-91110-514-0 |
08 |
1 |
0907- |
