Isuzu WW
▶
TRUCKS
▶
FRR
▶
11310 - FRR(MIDDLE EAST)
▶
0 - Engine, Emission, Engine Electrical
▶
0-52 - OIL AND VACUUM PIPING; ENGINE
▶
0-52 — OIL AND VACUUM PIPING; ENGINE
(#22348) — 24 parça
Tümü
A - 6HH1 N ENG
B - 6HH1-STD ENG
117
117
117
44
2
117
115
1
2
452
3
3
261
396
2
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
A
B
1
PIPE; OIL,INJ PUMP TO C/BL
8-94394-276-0
01
1
9510-0102
●
1
PIPE; OIL,INJ PUMP TO C/BL
8-94394-276-0
01
1
0103-0210
●
●
2
BOLT; EYE,OIL PIPE
(A) M10X21 FLANGE
1-09675-077-0
02
1
9510-0102
●
2
BOLT; EYE,OIL PIPE
(A) M10X21 FLANGE
1-09675-077-0
02
1
0103-0210
●
●
2
BOLT; EYE,OIL PIPE
(B) M12X27 FLANGE
1-09675-085-0
01
1
9510-0102
●
2
BOLT; EYE,OIL PIPE
(B) M12X27 FLANGE
1-09675-085-0
01
1
0103-0210
●
●
3
GASKET; EYE BOLT,OIL PIPE
ALSO INCLUDED IN GASKET SET(ENGINE). ID=12.2
1-09630-084-0
02
1
9510-0102
●
3
GASKET; EYE BOLT,OIL PIPE
ALSO INCLUDED IN GASKET SET(ENGINE). ID=12.2
1-09630-084-0
02
1
0103-0210
●
●
44
BOLT; CLIP,OIL PIPE
M6X22 FLANGE
0-28080-622-0
01
1
9510-0102
●
44
BOLT; CLIP,OIL PIPE
M6X22 FLANGE
0-28080-622-0
01
1
0103-0210
●
●
115
CLIP; PIPE,INJ PUMP
1-09701-091-0
01
1
9510-0102
●
115
CLIP; PIPE,INJ PUMP
1-09701-091-0
01
1
0103-0210
●
●
117
GASKET; JOINT,OIL PIPE
ALSO INCLUDED IN GASKET SET(ENG. & HEAD) ID=10.2 OD=15.2
1-09630-083-0
04
1
9510-0102
●
117
GASKET; JOINT,OIL PIPE
ALSO INCLUDED IN GASKET SET(ENG. & HEAD) ID=10.2 OD=15.2
1-09630-083-0
04
1
0103-0210
●
●
261
BRACKET; CLIP,OIL PIPE
8-94394-410-3
01
1
9510-0102
●
261
BRACKET; CLIP,OIL PIPE
8-94394-410-3
01
1
0103-0210
●
●
396
SLEEVE; RUBBER,OIL PIPE
ID=10 OD=14 L=30
9-09956-682-0
01
1
0002-0102
●
396
SLEEVE; RUBBER,OIL PIPE
ID=10 OD=14 L=30
9-09956-682-0
01
1
0103-0210
●
●
452
PIPE; OIL,OIL FILTER TO AIR CMPR
8-94390-073-0
01
1
9510-9510
●
452
PIPE; OIL,OIL FILTER TO AIR CMPR
PARTIAL OIL FILTER CARTRIDGE TYPE<KC2>
8-94390-073-0
01
1
9511-9906
●
452
PIPE; OIL,OIL FILTER TO AIR CMPR
PARTIAL OIL FILTER CARTRIDGE TYPE<KC2>
8-97600-569-0
01
1
9907-0102
●
452
PIPE; OIL,OIL FILTER TO AIR CMPR
EXC. PARTIAL OIL FILTER ELEMENT TYPE<KC1>
8-97600-569-0
01
1
0103-0210
●
●
452
PIPE; OIL,OIL FILTER TO AIR CMPR
PARTIAL OIL FILTER ELEMENT TYPE<KC1>
8-94395-595-1
01
1
9511-9906
●
452
PIPE; OIL,OIL FILTER TO AIR CMPR
PARTIAL OIL FILTER ELEMENT TYPE<KC1>
8-97600-573-0
01
1
9907-0210
●
