107 |
PIPE; FUEL,FEED PUMP TO FUEL FILTER
|
8-97610-907-1 |
01 |
1 |
1006- |
● |
● |
|
| |
107 |
PIPE; FUEL,FEED PUMP TO FUEL FILTER
|
8-97608-899-1 |
01 |
1 |
0904- |
|
|
● |
| |
108 |
BOLT; JOINT,FUEL FILTER
M14X27 FLANGE
|
1-09675-086-0 |
01 |
1 |
0904-1005 |
|
|
● |
| |
108 |
BOLT; JOINT,FUEL FILTER
M14X27 FLANGE
|
1-09675-086-0 |
01 |
1 |
1006- |
● |
● |
● |
| |
110 |
GASKET; JOINT BOLT,FUEL PIPE
ALSO INCLUDED IN GASKET SET(ENG. & HEAD)
ID=14.2 OD=25
|
1-09630-141-0 |
02 |
1 |
0904-1005 |
|
|
● |
| |
110 |
GASKET; JOINT BOLT,FUEL PIPE
ALSO INCLUDED IN GASKET SET(ENG. & HEAD)
ID=14.2 OD=25
|
1-09630-141-0 |
02 |
1 |
1006- |
● |
● |
● |
| |
112 |
BOLT; JOINT,FUEL FILTER
M14X27 FLANGE
|
1-09675-086-0 |
01 |
1 |
0904-1005 |
|
|
● |
| |
112 |
BOLT; JOINT,FUEL FILTER
M14X27 FLANGE
|
1-09675-086-0 |
01 |
1 |
1006- |
● |
● |
● |
| |
115 |
GASKET; JOINT BOLT,FUEL PIPE
ALSO INCLUDED IN GASKET SET(ENG. & HEAD)
ID=14.2 OD=25
|
1-09630-141-0 |
02 |
1 |
0904-1005 |
|
|
● |
| |
115 |
GASKET; JOINT BOLT,FUEL PIPE
ALSO INCLUDED IN GASKET SET(ENG. & HEAD)
ID=14.2 OD=25
|
1-09630-141-0 |
02 |
1 |
1006- |
● |
● |
● |
| |
119 |
PIPE; FUEL,FUEL FILTER TO INJ PUMP
|
8-97610-906-1 |
01 |
1 |
1006- |
● |
● |
|
| |
119 |
PIPE; FUEL,FUEL FILTER TO INJ PUMP
|
8-97608-900-1 |
01 |
1 |
0904- |
|
|
● |
| |
123 |
PIPE; FUEL,FUEL FILTER LEAK OFF
(B)
|
8-97608-901-1 |
01 |
1 |
1006- |
● |
● |
● |
| |
123 |
PIPE; FUEL,FUEL FILTER LEAK OFF
(A)
|
8-97607-213-0 |
01 |
1 |
0904- |
|
|
● |
| |
123 |
PIPE; FUEL,FUEL FILTER LEAK OFF
(B)
|
8-97608-901-1 |
01 |
1 |
0904-1005 |
|
|
● |
| |
123 |
PIPE; FUEL,FUEL FILTER LEAK OFF
(A)
|
8-97610-909-1 |
01 |
1 |
1006- |
● |
● |
|
| |
125 |
CLIP; FUEL PIPE
(C)
ID=9 & 9 L=25
|
1-09701-180-0 |
02 |
1 |
0904-1005 |
|
|
● |
| |
125 |
CLIP; FUEL PIPE
(C)
ID=9 & 9 L=25
|
1-09701-180-0 |
02 |
1 |
1006- |
● |
● |
● |
| |
125 |
CLIP; FUEL PIPE
(D)
ID=9 & 11 L=28
|
1-09701-193-1 |
03 |
1 |
0904-1005 |
|
|
● |
| |
125 |
CLIP; FUEL PIPE
(D)
ID=9 & 11 L=28
|
1-09701-193-1 |
03 |
1 |
1006- |
● |
● |
● |
| |
125 |
CLIP; FUEL PIPE
(A)
ID=9 & 11 L=28
|
1-09701-194-1 |
02 |
1 |
0904-1005 |
|
|
● |
| |
125 |
CLIP; FUEL PIPE
(A)
ID=9 & 11 L=28
|
1-09701-194-1 |
02 |
1 |
1006- |
● |
● |
● |
| |
125 |
CLIP; FUEL PIPE
(B)
ID=9 & 9 L=25
|
8-94393-280-3 |
02 |
1 |
0904-1005 |
|
|
● |
| |
125 |
CLIP; FUEL PIPE
(B)
ID=9 & 9 L=25
|
8-94393-280-3 |
02 |
1 |
1006- |
● |
● |
● |
| |
126 |
BOLT; CLIP,FUEL PIPE
(A)
M6X30 FLANGE
|
0-28050-630-0 |
01 |
1 |
0904-1005 |
|
|
● |
| |
126 |
BOLT; CLIP,FUEL PIPE
(A)
M6X30 FLANGE
|
0-28050-630-0 |
01 |
1 |
1006- |
● |
● |
● |
| |
126 |
BOLT; CLIP,FUEL PIPE
(B)
M6X40 FLANGE
|
0-28050-640-0 |
04 |
1 |
0904-1005 |
|
|
● |
| |
126 |
BOLT; CLIP,FUEL PIPE
(B)
M6X40 FLANGE
|
0-28050-640-0 |
04 |
1 |
1006- |
● |
● |
● |
| |
131 |
BRACKET; FUEL PIPE CLIP
|
8-97606-142-0 |
01 |
1 |
0904-1005 |
|
|
● |
| |
131 |
BRACKET; FUEL PIPE CLIP
|
8-97606-142-0 |
01 |
1 |
1006- |
● |
● |
● |
| |
148 |
BOLT; BRKT
M10X20 FLANGE
|
0-28151-020-0 |
01 |
1 |
0904-1005 |
|
|
● |
| |
148 |
BOLT; BRKT
M10X20 FLANGE
|
0-28151-020-0 |
01 |
1 |
1006- |
● |
● |
● |
| |
190 |
SENSOR; FUEL TEMP
|
8-97224-993-0 |
01 |
1 |
0904-1005 |
|
|
● |
| |
190 |
SENSOR; FUEL TEMP
|
8-97224-993-0 |
01 |
1 |
1006- |
● |
● |
● |
| |
207 |
GASKET; EYE BOLT
ID=14.2 OD=25
|
1-09630-141-0 |
03 |
1 |
0904-1005 |
|
|
● |
| |
207 |
GASKET; EYE BOLT
ID=14.2 OD=25
|
1-09630-141-0 |
03 |
1 |
1006- |
● |
● |
● |
| |
256 |
BOLT; EYE,FUEL PIPE
M14X43 EYE-BOLT
|
8-98037-829-0 |
01 |
1 |
0904-1005 |
|
|
● |
| |
256 |
BOLT; EYE,FUEL PIPE
M14X43 EYE-BOLT
|
8-98037-829-0 |
01 |
1 |
1006- |
● |
● |
● |
| |
280 |
ADAPTER; FUEL TEMP SEN
M12 & M14 STRAIGHT
|
1-15419-716-1 |
01 |
1 |
0904-1005 |
|
|
● |
| |
280 |
ADAPTER; FUEL TEMP SEN
M12 & M14 STRAIGHT
|
1-15419-716-1 |
01 |
1 |
1006- |
● |
● |
● |
