1 |
STEERING UNIT
SEE FIG-NO 4-40 FOR COMPONENT.
POWER STEERING(N40)
|
1-44000-773-3 |
01 |
1 |
9212- |
| |
1 |
STEERING UNIT
SEE FIG-NO 4-40 FOR COMPONENT.
EXC. POWER STEERING(N40)
|
1-44000-721-3 |
01 |
1 |
9212- |
| |
2 |
SHAFT ASM; STRG
DRIVING POSITION WIDE LEG SPACE(PR2)
|
1-44130-524-0 |
01 |
1 |
9212-9504 |
| |
2 |
SHAFT ASM; STRG
DRIVING POSITION WIDE LEG SPACE(PR2)
|
1-44130-607-0 |
01 |
1 |
9505- |
| |
2 |
SHAFT ASM; STRG
EXC. DRIVING POSITION WIDE LEG SPACE(PR2)
|
1-44130-510-0 |
01 |
1 |
9212-9504 |
| |
2 |
SHAFT ASM; STRG
EXC. DRIVING POSITION WIDE LEG SPACE(PR2)
|
1-44130-606-0 |
01 |
1 |
9505- |
| |
6 |
SHAFT; STRG LWR
|
1-44135-257-0 |
01 |
1 |
9212- |
| |
11 |
SEAL; JOURNAL,STRG
|
1-44229-049-0 |
01 |
1 |
9212- |
| |
16 |
BRACKET; COMB SW
DRIVING POSITION WIDE LEG SPACE(PR2)
|
1-44227-124-0 |
01 |
1 |
9212- |
| |
16 |
BRACKET; COMB SW
EXC. DRIVING POSITION WIDE LEG SPACE(PR2)
|
1-44227-123-0 |
01 |
1 |
9212- |
| |
17 |
SCREW; BRKT
M5X10 W/LK WASHER
|
9-03910-510-0 |
03 |
1 |
9212- |
| |
29 |
SPRING; COLUMN
|
1-09583-274-0 |
02 |
1 |
9212- |
| |
31 |
SCREW; HOOK
|
9-01045-620-0 |
02 |
1 |
9212-9504 |
| |
31 |
SCREW; HOOK
M6X20
|
0-20800-620-0 |
02 |
1 |
9505- |
| |
33 |
BOLT; STRG SHAFT TO UNIT
M10X35
|
1-09009-126-1 |
03 |
1 |
9212- |
| |
35 |
WASHER; LK,STRG SHAFT
ID=10.2
|
9-09150-810-0 |
02 |
1 |
9212- |
| |
38 |
JOURNAL; STRG SHAFT
|
1-44135-209-0 |
01 |
1 |
9212- |
| |
41 |
YOKE; SLEEVE,STRG
|
1-44135-261-0 |
01 |
1 |
9212- |
| |
42 |
NIPPLE; GREASE,SLEEVE YOKE
M6 STRAIGHT
|
9-09031-006-0 |
01 |
1 |
9212- |
| |
44 |
SHAFT; SPLINE,STRG
|
1-44135-228-0 |
01 |
1 |
9212- |
| |
45 |
BOOT; STRG SHAFT
|
1-44139-064-0 |
01 |
1 |
9212- |
| |
46 |
CLIP; BOOT
(A)
|
1-09704-086-1 |
01 |
1 |
9212- |
| |
46 |
CLIP; BOOT
(B)
|
1-09704-087-2 |
01 |
1 |
9212- |
| |
47 |
WASHER; CORK,STRG SHAFT
|
1-44139-050-0 |
01 |
1 |
9212- |
| |
48 |
RETAINER; FELT RING SLEEVE
|
1-44139-075-0 |
01 |
1 |
9212- |
| |
52 |
WASHER; PL,ADJ LEVER
|
1-09503-229-0 |
01 |
1 |
9212- |
| |
55 |
PLATE; GUIDE
|
1-44227-109-0 |
01 |
1 |
9212- |
| |
57 |
NUT; ADJ BOLT
|
1-44227-106-1 |
01 |
1 |
9212- |
| |
59 |
COLLAR; DIST,ADJ BOLT
|
1-44227-107-0 |
01 |
1 |
9212- |
| |
60 |
LEVER; ADJ,STRG COLUMN
|
1-44227-121-0 |
01 |
1 |
9212- |
| |
62 |
SPRING; LK,LEVER
|
1-09580-455-1 |
01 |
1 |
9212- |
| |
63 |
BOLT; ADJ LEVER,TILT STRG
|
1-44227-108-0 |
01 |
1 |
9212- |
| |
64 |
BOLT; ADJ,PROTECTOR
|
1-44227-104-0 |
01 |
1 |
9212- |
| |
68 |
PIN; TILT CENTER
|
1-44227-102-2 |
01 |
1 |
9212- |
| |
71 |
WASHER; LK,SHAFT TO UNIT
ID=10.2
|
9-09150-810-0 |
01 |
1 |
9212- |
| |
74 |
BRACKET; SUPPORT,STRG
|
1-44220-026-1 |
01 |
1 |
9212- |
| |
75 |
BOLT; STRG COLUMN
M8X25 W/LK&PL WASHER
|
0-50140-825-0 |
04 |
1 |
9212- |
| |
95 |
BOLT; STRG UNIT
BRAKE SYSTEM HEAVY DUTY VAR2(WG3)
EXC. POWER STEERING(N40),HEAVY DUTY PACKAGE
TRUCK<RD2>
M14X45
|
9-92061-445-0 |
02 |
1 |
9212- |
| |
95 |
BOLT; STRG UNIT
EXC. POWER STEERING(N40),BRAKE SYSTEM HEAVY DUTY
VAR2(WG3)
M14X45
|
9-92061-445-0 |
02 |
1 |
9212- |
| |
95 |
BOLT; STRG UNIT
HEAVY DUTY PACKAGE TRUCK<RD2>
BRAKE SYSTEM HEAVY DUTY VAR2(WG3)
EXC. POWER STEERING(N40)
M14X55
|
9-92061-455-0 |
02 |
1 |
9212- |
| |
95 |
BOLT; STRG UNIT
POWER STEERING(N40)
HEAVY DUTY PACKAGE TRUCK<RD2>
BRAKE SYSTEM HEAVY DUTY VAR2(WG3)
M14X55
|
9-92061-455-0 |
04 |
1 |
9212- |
| |
95 |
BOLT; STRG UNIT
POWER STEERING(N40)
EXC. HEAVY DUTY PACKAGE TRUCK<RD2>
M14X45
|
9-92061-445-0 |
04 |
1 |
9212- |
| |
95 |
BOLT; STRG UNIT
POWER STEERING(N40)
HEAVY DUTY PACKAGE TRUCK<RD2>
EXC. BRAKE SYSTEM HEAVY DUTY VAR2(WG3)
M14X45
|
9-92061-445-0 |
04 |
1 |
9212- |
| |
96 |
NUT; STRG UNIT
M14
|
9-99110-514-0 |
04 |
1 |
9212- |
| |
97 |
WASHER; PL,STRG UNIT
POWER STEERING(N40)
ID=15
|
9-09651-069-0 |
08 |
1 |
9212- |
| |
97 |
WASHER; PL,STRG UNIT
EXC. POWER STEERING(N40)
ID=15
|
9-09651-069-0 |
06 |
1 |
9212- |
| |
115 |
PIN; SPLIT,TILT CENTER BOLT
OD=1.8 L=15
|
9-08112-015-0 |
01 |
1 |
9212- |
| |
145 |
PLUG; AIR BREATHER
EXC. POWER STEERING(N40)
|
1-09893-002-0 |
01 |
1 |
9212- |
| |
147 |
STUD; STRG UNIT
EXC. POWER STEERING(N40)
M14X37 L=66
|
1-09300-095-1 |
02 |
1 |
9212- |
| |
252 |
NUT; TILT CENTER BOLT
M10
|
9-09116-510-0 |
01 |
1 |
9212- |
| |
253 |
NUT; CAP
|
1-71736-199-0 |
01 |
1 |
9212- |
