Sayfa 0-66 - Isuzu EPC

0-66 — GENERATOR (#2177) — 292 parça

15 2 15 13 81 3 83 13 80 19 15 15 78 22 13 3 21 69 17 49 5 49 49 1 66 10 24 66 48 57 62 89 49 53 48 7 42 39 7 10

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date
1	COVER ASM; RR,GEN ASM PART: D = 9-82200-481-2	1-81214-141-0	01	1	-
1	COVER ASM; RR,GEN ASM PART: A = 1-81200-032-1	1-81214-154-0	01	1	-
1	COVER ASM; RR,GEN ASM PART: B = 1-81200-337-2	1-81214-274-0	01	1	-
1	COVER ASM; RR,GEN ASM PART: C = 5-81200-180-3	1-81214-312-0	01	1	-
2	ROTOR; GEN ASM PART: A = 1-81200-032-1	1-81221-015-0	01	1	-
2	ROTOR; GEN ASM PART: D = 9-82200-481-2	1-81221-043-0	01	1	-
2	ROTOR; GEN ASM PART: B = 1-81200-337-2	1-81221-080-0	01	1	-
2	ROTOR; GEN ASM PART: C = 5-81200-180-3	1-81221-084-0	01	1	-
3	BEARING; ROTOR,GEN (B) ASM PART: B = 1-81200-337-2	1-81229-224-0	01	1	-
3	BEARING; ROTOR,GEN (A) ASM PART: A = 1-81200-032-1, D = 9-82200-481-2	1-81229-303-0	01	1	-
3	BEARING; ROTOR,GEN (A) ASM PART: B = 1-81200-337-2	1-81229-393-0	01	1	-
3	BEARING; ROTOR,GEN (A) ASM PART: C = 5-81200-180-3	1-81229-576-0	01	1	-
3	BEARING; ROTOR,GEN (B) ASM PART: C = 5-81200-180-3	5-81229-104-0	01	1	-
3	BEARING; ROTOR,GEN (B) ASM PART: A = 1-81200-032-1, D = 9-82200-481-2	9-00090-264-0	01	1	-
5	HOLDER; BRUSH,GEN ASM PART: A = 1-81200-032-1	1-81215-025-0	01	1	-
5	HOLDER; BRUSH,GEN ASM PART: B = 1-81200-337-2	1-81217-015-0	01	1	-
5	HOLDER; BRUSH,GEN ASM PART: D = 9-82200-481-2	1-81217-026-0	01	1	-
5	HOLDER; BRUSH,GEN ASM PART: C = 5-81200-180-3	1-81217-070-0	01	1	-
7	WASHER; INSULATE,RECTIFIER,GEN ASM PART: B = 1-81200-337-2	1-81229-227-0	04	1	-
10	RECTIFIER; GEN (A) ASM PART: C = 5-81200-180-3	1-81219-101-0	01	1	-
10	RECTIFIER; GEN (B) ASM PART: C = 5-81200-180-3	1-81219-102-0	01	1	-
10	RECTIFIER; GEN (A) ASM PART: B = 1-81200-337-2	1-81219-103-0	01	1	-
10	RECTIFIER; GEN (B) ASM PART: B = 1-81200-337-2	1-81219-104-0	01	1	-
10	RECTIFIER; GEN (C) ASM PART: D = 9-82200-481-2	9-82211-897-0	01	1	-
13	GASKET; ROTOR,GEN (A) ASM PART: B = 1-81200-337-2	1-81229-162-0	01	1	-
13	GASKET; ROTOR,GEN (B) ASM PART: B = 1-81200-337-2	1-81229-165-0	01	1	-
13	GASKET; ROTOR,GEN (C) ASM PART: B = 1-81200-337-2	1-81229-231-0	01	1	-
13	GASKET; ROTOR,GEN (D) ASM PART: D = 9-82200-481-2	1-81229-304-0	02	1	-
15	RETAINER; ROTOR,GEN (C) ASM PART: D = 9-82200-481-2	1-81214-133-0	01	1	-
15	RETAINER; ROTOR,GEN (E) ASM PART: A = 1-81200-032-1	1-81229-050-0	01	1	-
15	RETAINER; ROTOR,GEN (A) ASM PART: B = 1-81200-337-2	1-81229-164-0	01	1	-
15	RETAINER; ROTOR,GEN (B) ASM PART: B = 1-81200-337-2	1-81229-170-0	01	1	-
15	RETAINER; ROTOR,GEN (C) ASM PART: B = 1-81200-337-2	1-81229-171-0	01	1	-
15	RETAINER; ROTOR,GEN (A) ASM PART: D = 9-82200-481-2	1-81229-305-0	01	1	-
15	RETAINER; ROTOR,GEN (F) ASM PART: C = 5-81200-180-3	1-81229-405-0	01	1	-
15	RETAINER; ROTOR,GEN (B) ASM PART: D = 9-82200-481-2	9-82216-055-0	01	1	-
15	RETAINER; ROTOR,GEN (D) ASM PART: B = 1-81200-337-2	9-82216-060-0	01	1	-
17	COVER ASM; FRT,GEN ASM PART: A = 1-81200-032-1	1-81213-012-0	01	1	-
17	COVER ASM; FRT,GEN ASM PART: B = 1-81200-337-2	1-81213-031-0	01	1	-
17	COVER ASM; FRT,GEN ASM PART: D = 9-82200-481-2	1-81213-046-0	01	1	-
17	COVER ASM; FRT,GEN ASM PART: C = 5-81200-180-3	1-81213-055-0	01	1	-
19	PULLEY; GEN ASM PART: D = 9-82200-481-2	1-81222-006-0	01	1	-
19	PULLEY; GEN ASM PART: A = 1-81200-032-1	1-81222-014-0	01	1	-
19	PULLEY; GEN ASM PART: B = 1-81200-337-2	1-81222-039-0	01	1	-
19	PULLEY; GEN ASM PART: C = 5-81200-180-3	5-81222-043-0	01	1	-
21	BOLT; THROUGH,GEN ASM PART: B = 1-81200-337-2	1-81229-008-0	04	1	-
21	BOLT; THROUGH,GEN ASM PART: A = 1-81200-032-1	1-81229-048-0	03	1	-
21	BOLT; THROUGH,GEN ASM PART: D = 9-82200-481-2	1-81229-613-0	03	1	-
21	BOLT; THROUGH,GEN ASM PART: C = 5-81200-180-3	5-81229-106-0	04	1	-
22	STATOR; GEN ASM PART: B = 1-81200-337-2	1-81211-033-0	01	1	-
22	STATOR; GEN ASM PART: D = 9-82200-481-2	1-81211-050-0	01	1	-
22	STATOR; GEN ASM PART: A = 1-81200-032-1	1-81211-055-0	01	1	-
22	STATOR; GEN ASM PART: C = 5-81200-180-3	1-81211-099-0	01	1	-
24	SCREW; RECTIFIER,GEN (A) ASM PART: D = 9-82200-481-2	1-81229-068-0	01	1	-
24	SCREW; RECTIFIER,GEN (C) ASM PART: B = 1-81200-337-2	1-81229-339-0	01	1	-
24	SCREW; RECTIFIER,GEN (B) ASM PART: D = 9-82200-481-2	9-82216-057-0	01	1	-
39	COVER; END,RR COVER,GEN ASM PART: B = 1-81200-337-2	1-81214-083-0	01	1	-
42	GASKET; RR COVER,GEN ASM PART: B = 1-81200-337-2	1-81229-233-0	01	1	-
48	DIODE; GEN (A) ASM PART: B = 1-81200-337-2	1-81218-002-0	03	1	-
48	DIODE; GEN (B) ASM PART: B = 1-81200-337-2	1-81219-027-0	03	1	-
48	DIODE; GEN (A) ASM PART: A = 1-81200-032-1	9-82211-699-0	03	1	-
48	DIODE; GEN (B) ASM PART: A = 1-81200-032-1	9-82212-101-0	03	1	-
48	DIODE; GEN (A) ASM PART: D = 9-82200-481-2	9-82212-102-0	03	1	-
48	DIODE; GEN (B) ASM PART: D = 9-82200-481-2	9-82212-103-0	03	1	-
49	BUSHING; RECTIFIER,GEN (A) ASM PART: B = 1-81200-337-2	1-81229-042-0	01	1	-
49	BUSHING; RECTIFIER,GEN (B) ASM PART: B = 1-81200-337-2	1-81229-248-0	02	1	-
49	BUSHING; RECTIFIER,GEN (C) ASM PART: B = 1-81200-337-2	9-82216-095-0	01	1	-
53	TUBE; RECTIFIER,GEN ASM PART: B = 1-81200-337-2	9-82215-515-0	02	1	-
57	COVER; BRUSH,GEN ASM PART: B = 1-81200-337-2	1-81214-050-0	01	1	-
57	COVER; BRUSH,GEN ASM PART: C = 5-81200-180-3	1-81217-071-0	01	1	-
57	COVER; BRUSH,GEN ASM PART: D = 9-82200-481-2	1-81229-067-0	01	1	-
62	CLIP; TERMINAL,BRUSH,GEN ASM PART: B = 1-81200-337-2	1-81118-011-0	01	1	-
62	CLIP; TERMINAL,BRUSH,GEN ASM PART: D = 9-82200-481-2	1-81229-306-0	01	1	-
66	GASKET; BRUSH HOLDER,GEN (A) ASM PART: B = 1-81200-337-2	1-81229-226-0	01	1	-
66	GASKET; BRUSH HOLDER,GEN (B) ASM PART: B = 1-81200-337-2	1-81229-232-0	01	1	-
69	CLIP; WIRE,GEN ASM PART: B = 1-81200-337-2	1-81229-122-0	02	1	-
69	CLIP; WIRE,GEN ASM PART: C = 5-81200-180-3	1-81229-534-0	01	1	-
78	CLIP; ROTOR,GEN ASM PART: B = 1-81200-337-2	1-81229-230-0	01	1	-
80	PLATE; ROTOR,GEN ASM PART: B = 1-81200-337-2	1-81229-123-0	01	1	-
81	SPACER; ROTOR,GEN ASM PART: B = 1-81200-337-2	1-81229-160-0	01	1	-
81	SPACER; ROTOR,GEN ASM PART: C = 5-81200-180-3	1-81229-403-0	01	1	-
81	SPACER; ROTOR,GEN ASM PART: D = 9-82200-481-2	9-82216-054-0	01	1	-
83	RING; SLIP,ROTOR,GEN ASM PART: B = 1-81200-337-2	1-81224-016-0	01	1	-
89	BOLT; RECTIFIER,GEN ASM PART: B = 1-81200-337-2	1-81229-238-0	01	1	-

17 3 9 79 81 2 15 20 85 27 27 27 19 25 18 25 25 25 57 5 3 25 30 29 27 21 10 69 37 25 1 10 22

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date
1	COVER ASM; RR,GEN ASM PART: D = 9-82200-481-2	1-81214-141-0	01	1	-
1	COVER ASM; RR,GEN ASM PART: A = 1-81200-032-1	1-81214-154-0	01	1	-
1	COVER ASM; RR,GEN ASM PART: B = 1-81200-337-2	1-81214-274-0	01	1	-
1	COVER ASM; RR,GEN ASM PART: C = 5-81200-180-3	1-81214-312-0	01	1	-
2	ROTOR; GEN ASM PART: A = 1-81200-032-1	1-81221-015-0	01	1	-
2	ROTOR; GEN ASM PART: D = 9-82200-481-2	1-81221-043-0	01	1	-
2	ROTOR; GEN ASM PART: B = 1-81200-337-2	1-81221-080-0	01	1	-
2	ROTOR; GEN ASM PART: C = 5-81200-180-3	1-81221-084-0	01	1	-
3	BEARING; ROTOR,GEN (B) ASM PART: B = 1-81200-337-2	1-81229-224-0	01	1	-
3	BEARING; ROTOR,GEN (A) ASM PART: A = 1-81200-032-1, D = 9-82200-481-2	1-81229-303-0	01	1	-
3	BEARING; ROTOR,GEN (A) ASM PART: B = 1-81200-337-2	1-81229-393-0	01	1	-
3	BEARING; ROTOR,GEN (A) ASM PART: C = 5-81200-180-3	1-81229-576-0	01	1	-
3	BEARING; ROTOR,GEN (B) ASM PART: C = 5-81200-180-3	5-81229-104-0	01	1	-
3	BEARING; ROTOR,GEN (B) ASM PART: A = 1-81200-032-1, D = 9-82200-481-2	9-00090-264-0	01	1	-
5	HOLDER; BRUSH,GEN ASM PART: A = 1-81200-032-1	1-81215-025-0	01	1	-
5	HOLDER; BRUSH,GEN ASM PART: B = 1-81200-337-2	1-81217-015-0	01	1	-
5	HOLDER; BRUSH,GEN ASM PART: D = 9-82200-481-2	1-81217-026-0	01	1	-
5	HOLDER; BRUSH,GEN ASM PART: C = 5-81200-180-3	1-81217-070-0	01	1	-
9	COVER; FELT WASHER,ROTOR,GEN ASM PART: C = 5-81200-180-3	1-81214-102-0	01	1	-
10	RECTIFIER; GEN (A) ASM PART: C = 5-81200-180-3	1-81219-101-0	01	1	-
10	RECTIFIER; GEN (B) ASM PART: C = 5-81200-180-3	1-81219-102-0	01	1	-
10	RECTIFIER; GEN (A) ASM PART: B = 1-81200-337-2	1-81219-103-0	01	1	-
10	RECTIFIER; GEN (B) ASM PART: B = 1-81200-337-2	1-81219-104-0	01	1	-
10	RECTIFIER; GEN (C) ASM PART: D = 9-82200-481-2	9-82211-897-0	01	1	-
15	RETAINER; ROTOR,GEN (C) ASM PART: D = 9-82200-481-2	1-81214-133-0	01	1	-
15	RETAINER; ROTOR,GEN (E) ASM PART: A = 1-81200-032-1	1-81229-050-0	01	1	-
15	RETAINER; ROTOR,GEN (A) ASM PART: B = 1-81200-337-2	1-81229-164-0	01	1	-
15	RETAINER; ROTOR,GEN (B) ASM PART: B = 1-81200-337-2	1-81229-170-0	01	1	-
15	RETAINER; ROTOR,GEN (C) ASM PART: B = 1-81200-337-2	1-81229-171-0	01	1	-
15	RETAINER; ROTOR,GEN (A) ASM PART: D = 9-82200-481-2	1-81229-305-0	01	1	-
15	RETAINER; ROTOR,GEN (F) ASM PART: C = 5-81200-180-3	1-81229-405-0	01	1	-
15	RETAINER; ROTOR,GEN (B) ASM PART: D = 9-82200-481-2	9-82216-055-0	01	1	-
15	RETAINER; ROTOR,GEN (D) ASM PART: B = 1-81200-337-2	9-82216-060-0	01	1	-
17	COVER ASM; FRT,GEN ASM PART: A = 1-81200-032-1	1-81213-012-0	01	1	-
17	COVER ASM; FRT,GEN ASM PART: B = 1-81200-337-2	1-81213-031-0	01	1	-
17	COVER ASM; FRT,GEN ASM PART: D = 9-82200-481-2	1-81213-046-0	01	1	-
17	COVER ASM; FRT,GEN ASM PART: C = 5-81200-180-3	1-81213-055-0	01	1	-
18	NUT; PULLEY,GEN ASM PART: C = 5-81200-180-3	8-94167-948-0	01	1	-
19	PULLEY; GEN ASM PART: D = 9-82200-481-2	1-81222-006-0	01	1	-
19	PULLEY; GEN ASM PART: A = 1-81200-032-1	1-81222-014-0	01	1	-
19	PULLEY; GEN ASM PART: B = 1-81200-337-2	1-81222-039-0	01	1	-
19	PULLEY; GEN ASM PART: C = 5-81200-180-3	5-81222-043-0	01	1	-
20	FAN; GEN ASM PART: C = 5-81200-180-3	5-81223-007-0	01	1	-
21	BOLT; THROUGH,GEN ASM PART: B = 1-81200-337-2	1-81229-008-0	04	1	-
21	BOLT; THROUGH,GEN ASM PART: A = 1-81200-032-1	1-81229-048-0	03	1	-
21	BOLT; THROUGH,GEN ASM PART: D = 9-82200-481-2	1-81229-613-0	03	1	-
21	BOLT; THROUGH,GEN ASM PART: C = 5-81200-180-3	5-81229-106-0	04	1	-
22	STATOR; GEN ASM PART: B = 1-81200-337-2	1-81211-033-0	01	1	-
22	STATOR; GEN ASM PART: D = 9-82200-481-2	1-81211-050-0	01	1	-
22	STATOR; GEN ASM PART: A = 1-81200-032-1	1-81211-055-0	01	1	-
22	STATOR; GEN ASM PART: C = 5-81200-180-3	1-81211-099-0	01	1	-
25	BUSHING; INSULATION TERMINAL (A) ASM PART: C = 5-81200-180-3	1-81229-410-0	02	1	-
25	BUSHING; INSULATION TERMINAL (B) ASM PART: C = 5-81200-180-3	1-81229-411-0	02	1	-
25	BUSHING; INSULATION TERMINAL (C) ASM PART: C = 5-81200-180-3	1-81229-413-0	01	1	-
25	BUSHING; INSULATION TERMINAL (D) ASM PART: C = 5-81200-180-3	1-81229-590-0	01	1	-
25	BUSHING; INSULATION TERMINAL (E) ASM PART: C = 5-81200-180-3	5-81229-105-0	04	1	-
27	NUT; RECTIFIER,GEN (A), M6 ASM PART: C = 5-81200-180-3	8-94206-186-0	01	1	-
27	NUT; RECTIFIER,GEN (B) ASM PART: C = 5-81200-180-3	8-94206-188-0	06	1	-
29	BRUSH; GEN ASM PART: C = 5-81200-180-3	5-81215-018-0	02	1	-
29	BRUSH; GEN ASM PART: D = 9-82200-481-2	9-82211-687-0	02	1	-
30	SPRING; BRUSH,GEN ASM PART: C = 5-81200-180-3	5-81216-002-0	02	1	-
37	BUSHING; RR COVER,GEN ASM PART: C = 5-81200-180-3	9-82215-879-0	01	1	-
57	COVER; BRUSH,GEN ASM PART: B = 1-81200-337-2	1-81214-050-0	01	1	-
57	COVER; BRUSH,GEN ASM PART: C = 5-81200-180-3	1-81217-071-0	01	1	-
57	COVER; BRUSH,GEN ASM PART: D = 9-82200-481-2	1-81229-067-0	01	1	-
69	CLIP; WIRE,GEN ASM PART: B = 1-81200-337-2	1-81229-122-0	02	1	-
69	CLIP; WIRE,GEN ASM PART: C = 5-81200-180-3	1-81229-534-0	01	1	-
79	WASHER; FELT,ROTOR,GEN ASM PART: C = 5-81200-180-3	9-82215-707-0	01	1	-
81	SPACER; ROTOR,GEN ASM PART: B = 1-81200-337-2	1-81229-160-0	01	1	-
81	SPACER; ROTOR,GEN ASM PART: C = 5-81200-180-3	1-81229-403-0	01	1	-
81	SPACER; ROTOR,GEN ASM PART: D = 9-82200-481-2	9-82216-054-0	01	1	-
85	SPACER; PULLEY,GEN ASM PART: C = 5-81200-180-3	1-81229-415-0	01	1	-
85	SPACER; PULLEY,GEN ASM PART: D = 9-82200-481-2	9-82225-072-0	01	1	-

22 12 3 17 15 3 2 19 21 21 86 1 5 21 54 47 48 48 46

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date
1	COVER ASM; RR,GEN ASM PART: D = 9-82200-481-2	1-81214-141-0	01	1	-
1	COVER ASM; RR,GEN ASM PART: A = 1-81200-032-1	1-81214-154-0	01	1	-
1	COVER ASM; RR,GEN ASM PART: B = 1-81200-337-2	1-81214-274-0	01	1	-
1	COVER ASM; RR,GEN ASM PART: C = 5-81200-180-3	1-81214-312-0	01	1	-
2	ROTOR; GEN ASM PART: A = 1-81200-032-1	1-81221-015-0	01	1	-
2	ROTOR; GEN ASM PART: D = 9-82200-481-2	1-81221-043-0	01	1	-
2	ROTOR; GEN ASM PART: B = 1-81200-337-2	1-81221-080-0	01	1	-
2	ROTOR; GEN ASM PART: C = 5-81200-180-3	1-81221-084-0	01	1	-
3	BEARING; ROTOR,GEN (B) ASM PART: B = 1-81200-337-2	1-81229-224-0	01	1	-
3	BEARING; ROTOR,GEN (A) ASM PART: A = 1-81200-032-1, D = 9-82200-481-2	1-81229-303-0	01	1	-
3	BEARING; ROTOR,GEN (A) ASM PART: B = 1-81200-337-2	1-81229-393-0	01	1	-
3	BEARING; ROTOR,GEN (A) ASM PART: C = 5-81200-180-3	1-81229-576-0	01	1	-
3	BEARING; ROTOR,GEN (B) ASM PART: C = 5-81200-180-3	5-81229-104-0	01	1	-
3	BEARING; ROTOR,GEN (B) ASM PART: A = 1-81200-032-1, D = 9-82200-481-2	9-00090-264-0	01	1	-
5	HOLDER; BRUSH,GEN ASM PART: A = 1-81200-032-1	1-81215-025-0	01	1	-
5	HOLDER; BRUSH,GEN ASM PART: B = 1-81200-337-2	1-81217-015-0	01	1	-
5	HOLDER; BRUSH,GEN ASM PART: D = 9-82200-481-2	1-81217-026-0	01	1	-
5	HOLDER; BRUSH,GEN ASM PART: C = 5-81200-180-3	1-81217-070-0	01	1	-
12	KEY; ROTOR,GEN ASM PART: D = 9-82200-481-2	9-82215-146-0	01	1	-
12	KEY; ROTOR,GEN ASM PART: A = 1-81200-032-1	9-82215-159-0	01	1	-
15	RETAINER; ROTOR,GEN (C) ASM PART: D = 9-82200-481-2	1-81214-133-0	01	1	-
15	RETAINER; ROTOR,GEN (E) ASM PART: A = 1-81200-032-1	1-81229-050-0	01	1	-
15	RETAINER; ROTOR,GEN (A) ASM PART: B = 1-81200-337-2	1-81229-164-0	01	1	-
15	RETAINER; ROTOR,GEN (B) ASM PART: B = 1-81200-337-2	1-81229-170-0	01	1	-
15	RETAINER; ROTOR,GEN (C) ASM PART: B = 1-81200-337-2	1-81229-171-0	01	1	-
15	RETAINER; ROTOR,GEN (A) ASM PART: D = 9-82200-481-2	1-81229-305-0	01	1	-
15	RETAINER; ROTOR,GEN (F) ASM PART: C = 5-81200-180-3	1-81229-405-0	01	1	-
15	RETAINER; ROTOR,GEN (B) ASM PART: D = 9-82200-481-2	9-82216-055-0	01	1	-
15	RETAINER; ROTOR,GEN (D) ASM PART: B = 1-81200-337-2	9-82216-060-0	01	1	-
17	COVER ASM; FRT,GEN ASM PART: A = 1-81200-032-1	1-81213-012-0	01	1	-
17	COVER ASM; FRT,GEN ASM PART: B = 1-81200-337-2	1-81213-031-0	01	1	-
17	COVER ASM; FRT,GEN ASM PART: D = 9-82200-481-2	1-81213-046-0	01	1	-
17	COVER ASM; FRT,GEN ASM PART: C = 5-81200-180-3	1-81213-055-0	01	1	-
19	PULLEY; GEN ASM PART: D = 9-82200-481-2	1-81222-006-0	01	1	-
19	PULLEY; GEN ASM PART: A = 1-81200-032-1	1-81222-014-0	01	1	-
19	PULLEY; GEN ASM PART: B = 1-81200-337-2	1-81222-039-0	01	1	-
19	PULLEY; GEN ASM PART: C = 5-81200-180-3	5-81222-043-0	01	1	-
21	BOLT; THROUGH,GEN ASM PART: B = 1-81200-337-2	1-81229-008-0	04	1	-
21	BOLT; THROUGH,GEN ASM PART: A = 1-81200-032-1	1-81229-048-0	03	1	-
21	BOLT; THROUGH,GEN ASM PART: D = 9-82200-481-2	1-81229-613-0	03	1	-
21	BOLT; THROUGH,GEN ASM PART: C = 5-81200-180-3	5-81229-106-0	04	1	-
22	STATOR; GEN ASM PART: B = 1-81200-337-2	1-81211-033-0	01	1	-
22	STATOR; GEN ASM PART: D = 9-82200-481-2	1-81211-050-0	01	1	-
22	STATOR; GEN ASM PART: A = 1-81200-032-1	1-81211-055-0	01	1	-
22	STATOR; GEN ASM PART: C = 5-81200-180-3	1-81211-099-0	01	1	-
46	RECTIFIER; (+),GEN ASM PART: A = 1-81200-032-1	1-81229-051-0	01	1	-
47	RECTIFIER; (-),GEN ASM PART: A = 1-81200-032-1	1-81229-052-0	01	1	-
48	DIODE; GEN (A) ASM PART: B = 1-81200-337-2	1-81218-002-0	03	1	-
48	DIODE; GEN (B) ASM PART: B = 1-81200-337-2	1-81219-027-0	03	1	-
48	DIODE; GEN (A) ASM PART: A = 1-81200-032-1	9-82211-699-0	03	1	-
48	DIODE; GEN (B) ASM PART: A = 1-81200-032-1	9-82212-101-0	03	1	-
48	DIODE; GEN (A) ASM PART: D = 9-82200-481-2	9-82212-102-0	03	1	-
48	DIODE; GEN (B) ASM PART: D = 9-82200-481-2	9-82212-103-0	03	1	-
54	BOLT; RECTIFIER,GEN ASM PART: A = 1-81200-032-1	9-82215-963-0	02	1	-
86	NUT SET; PULLEY,GEN ASM PART: A = 1-81200-032-1	1-81229-049-0	01	1	-
86	NUT SET; PULLEY,GEN ASM PART: D = 9-82200-481-2	9-82215-464-0	01	1	-

3 15 2 81 12 15 13 15 3 17 22 85 21 1 62 16 57 19 86 29 29 24 48 32 24 48 10 24 5

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date
1	COVER ASM; RR,GEN ASM PART: D = 9-82200-481-2	1-81214-141-0	01	1	-
1	COVER ASM; RR,GEN ASM PART: A = 1-81200-032-1	1-81214-154-0	01	1	-
1	COVER ASM; RR,GEN ASM PART: B = 1-81200-337-2	1-81214-274-0	01	1	-
1	COVER ASM; RR,GEN ASM PART: C = 5-81200-180-3	1-81214-312-0	01	1	-
2	ROTOR; GEN ASM PART: A = 1-81200-032-1	1-81221-015-0	01	1	-
2	ROTOR; GEN ASM PART: D = 9-82200-481-2	1-81221-043-0	01	1	-
2	ROTOR; GEN ASM PART: B = 1-81200-337-2	1-81221-080-0	01	1	-
2	ROTOR; GEN ASM PART: C = 5-81200-180-3	1-81221-084-0	01	1	-
3	BEARING; ROTOR,GEN (B) ASM PART: B = 1-81200-337-2	1-81229-224-0	01	1	-
3	BEARING; ROTOR,GEN (A) ASM PART: A = 1-81200-032-1, D = 9-82200-481-2	1-81229-303-0	01	1	-
3	BEARING; ROTOR,GEN (A) ASM PART: B = 1-81200-337-2	1-81229-393-0	01	1	-
3	BEARING; ROTOR,GEN (A) ASM PART: C = 5-81200-180-3	1-81229-576-0	01	1	-
3	BEARING; ROTOR,GEN (B) ASM PART: C = 5-81200-180-3	5-81229-104-0	01	1	-
3	BEARING; ROTOR,GEN (B) ASM PART: A = 1-81200-032-1, D = 9-82200-481-2	9-00090-264-0	01	1	-
5	HOLDER; BRUSH,GEN ASM PART: A = 1-81200-032-1	1-81215-025-0	01	1	-
5	HOLDER; BRUSH,GEN ASM PART: B = 1-81200-337-2	1-81217-015-0	01	1	-
5	HOLDER; BRUSH,GEN ASM PART: D = 9-82200-481-2	1-81217-026-0	01	1	-
5	HOLDER; BRUSH,GEN ASM PART: C = 5-81200-180-3	1-81217-070-0	01	1	-
10	RECTIFIER; GEN (A) ASM PART: C = 5-81200-180-3	1-81219-101-0	01	1	-
10	RECTIFIER; GEN (B) ASM PART: C = 5-81200-180-3	1-81219-102-0	01	1	-
10	RECTIFIER; GEN (A) ASM PART: B = 1-81200-337-2	1-81219-103-0	01	1	-
10	RECTIFIER; GEN (B) ASM PART: B = 1-81200-337-2	1-81219-104-0	01	1	-
10	RECTIFIER; GEN (C) ASM PART: D = 9-82200-481-2	9-82211-897-0	01	1	-
12	KEY; ROTOR,GEN ASM PART: D = 9-82200-481-2	9-82215-146-0	01	1	-
12	KEY; ROTOR,GEN ASM PART: A = 1-81200-032-1	9-82215-159-0	01	1	-
13	GASKET; ROTOR,GEN (A) ASM PART: B = 1-81200-337-2	1-81229-162-0	01	1	-
13	GASKET; ROTOR,GEN (B) ASM PART: B = 1-81200-337-2	1-81229-165-0	01	1	-
13	GASKET; ROTOR,GEN (C) ASM PART: B = 1-81200-337-2	1-81229-231-0	01	1	-
13	GASKET; ROTOR,GEN (D) ASM PART: D = 9-82200-481-2	1-81229-304-0	02	1	-
15	RETAINER; ROTOR,GEN (C) ASM PART: D = 9-82200-481-2	1-81214-133-0	01	1	-
15	RETAINER; ROTOR,GEN (E) ASM PART: A = 1-81200-032-1	1-81229-050-0	01	1	-
15	RETAINER; ROTOR,GEN (A) ASM PART: B = 1-81200-337-2	1-81229-164-0	01	1	-
15	RETAINER; ROTOR,GEN (B) ASM PART: B = 1-81200-337-2	1-81229-170-0	01	1	-
15	RETAINER; ROTOR,GEN (C) ASM PART: B = 1-81200-337-2	1-81229-171-0	01	1	-
15	RETAINER; ROTOR,GEN (A) ASM PART: D = 9-82200-481-2	1-81229-305-0	01	1	-
15	RETAINER; ROTOR,GEN (F) ASM PART: C = 5-81200-180-3	1-81229-405-0	01	1	-
15	RETAINER; ROTOR,GEN (B) ASM PART: D = 9-82200-481-2	9-82216-055-0	01	1	-
15	RETAINER; ROTOR,GEN (D) ASM PART: B = 1-81200-337-2	9-82216-060-0	01	1	-
16	TERMINAL ASM; RECTIFIER,GEN ASM PART: D = 9-82200-481-2	9-82216-058-0	01	1	-
17	COVER ASM; FRT,GEN ASM PART: A = 1-81200-032-1	1-81213-012-0	01	1	-
17	COVER ASM; FRT,GEN ASM PART: B = 1-81200-337-2	1-81213-031-0	01	1	-
17	COVER ASM; FRT,GEN ASM PART: D = 9-82200-481-2	1-81213-046-0	01	1	-
17	COVER ASM; FRT,GEN ASM PART: C = 5-81200-180-3	1-81213-055-0	01	1	-
19	PULLEY; GEN ASM PART: D = 9-82200-481-2	1-81222-006-0	01	1	-
19	PULLEY; GEN ASM PART: A = 1-81200-032-1	1-81222-014-0	01	1	-
19	PULLEY; GEN ASM PART: B = 1-81200-337-2	1-81222-039-0	01	1	-
19	PULLEY; GEN ASM PART: C = 5-81200-180-3	5-81222-043-0	01	1	-
21	BOLT; THROUGH,GEN ASM PART: B = 1-81200-337-2	1-81229-008-0	04	1	-
21	BOLT; THROUGH,GEN ASM PART: A = 1-81200-032-1	1-81229-048-0	03	1	-
21	BOLT; THROUGH,GEN ASM PART: D = 9-82200-481-2	1-81229-613-0	03	1	-
21	BOLT; THROUGH,GEN ASM PART: C = 5-81200-180-3	5-81229-106-0	04	1	-
22	STATOR; GEN ASM PART: B = 1-81200-337-2	1-81211-033-0	01	1	-
22	STATOR; GEN ASM PART: D = 9-82200-481-2	1-81211-050-0	01	1	-
22	STATOR; GEN ASM PART: A = 1-81200-032-1	1-81211-055-0	01	1	-
22	STATOR; GEN ASM PART: C = 5-81200-180-3	1-81211-099-0	01	1	-
24	SCREW; RECTIFIER,GEN (A) ASM PART: D = 9-82200-481-2	1-81229-068-0	01	1	-
24	SCREW; RECTIFIER,GEN (C) ASM PART: B = 1-81200-337-2	1-81229-339-0	01	1	-
24	SCREW; RECTIFIER,GEN (B) ASM PART: D = 9-82200-481-2	9-82216-057-0	01	1	-
29	BRUSH; GEN ASM PART: C = 5-81200-180-3	5-81215-018-0	02	1	-
29	BRUSH; GEN ASM PART: D = 9-82200-481-2	9-82211-687-0	02	1	-
32	TERMINAL; RECTIFIER,GEN ASM PART: D = 9-82200-481-2	9-82216-056-0	01	1	-
48	DIODE; GEN (A) ASM PART: B = 1-81200-337-2	1-81218-002-0	03	1	-
48	DIODE; GEN (B) ASM PART: B = 1-81200-337-2	1-81219-027-0	03	1	-
48	DIODE; GEN (A) ASM PART: A = 1-81200-032-1	9-82211-699-0	03	1	-
48	DIODE; GEN (B) ASM PART: A = 1-81200-032-1	9-82212-101-0	03	1	-
48	DIODE; GEN (A) ASM PART: D = 9-82200-481-2	9-82212-102-0	03	1	-
48	DIODE; GEN (B) ASM PART: D = 9-82200-481-2	9-82212-103-0	03	1	-
57	COVER; BRUSH,GEN ASM PART: B = 1-81200-337-2	1-81214-050-0	01	1	-
57	COVER; BRUSH,GEN ASM PART: C = 5-81200-180-3	1-81217-071-0	01	1	-
57	COVER; BRUSH,GEN ASM PART: D = 9-82200-481-2	1-81229-067-0	01	1	-
62	CLIP; TERMINAL,BRUSH,GEN ASM PART: B = 1-81200-337-2	1-81118-011-0	01	1	-
62	CLIP; TERMINAL,BRUSH,GEN ASM PART: D = 9-82200-481-2	1-81229-306-0	01	1	-
81	SPACER; ROTOR,GEN ASM PART: B = 1-81200-337-2	1-81229-160-0	01	1	-
81	SPACER; ROTOR,GEN ASM PART: C = 5-81200-180-3	1-81229-403-0	01	1	-
81	SPACER; ROTOR,GEN ASM PART: D = 9-82200-481-2	9-82216-054-0	01	1	-
85	SPACER; PULLEY,GEN ASM PART: C = 5-81200-180-3	1-81229-415-0	01	1	-
85	SPACER; PULLEY,GEN ASM PART: D = 9-82200-481-2	9-82225-072-0	01	1	-
86	NUT SET; PULLEY,GEN ASM PART: A = 1-81200-032-1	1-81229-049-0	01	1	-
86	NUT SET; PULLEY,GEN ASM PART: D = 9-82200-481-2	9-82215-464-0	01	1	-

İpucu: çizimdeki balona veya tablodaki Balon sütununa tıkla; ilgili parçalar vurgulanır. Birden çok çizim varsa üstteki seçim kutusu/oklarla gezin.
