◀ 🏠 ▶ Isuzu WW ▶ TRUCKS ▶ FRR ▶ 11415 - FRR AUSTRALIA EURO4 EXC.SPACECAB ▶ 0 - Engine, Emission, Engine Electrical ▶ 0-01 - PARTIAL ENGINE ▶
0-01 — PARTIAL ENGINE (#21706) — 12 parça
çizim 108948
1
BalonParca AdiParca NoAdetTipApplied Date A B C
1 ENGINE ASM; PARTIAL 5-87311-091-5 01 1 0712-1312 ●
1 ENGINE ASM; PARTIAL 5-87311-234-1 01 1 1401- ●
1 ENGINE ASM; PARTIAL 1-87310-617-3 01 1 0710-1012 ● ●
1 ENGINE ASM; PARTIAL 1-87310-722-0 01 1 1101-1208 ● ●
1 ENGINE ASM; PARTIAL 1-87310-798-0 01 1 1209-1312 ● ●
1 ENGINE ASM; PARTIAL 1-87310-965-0 01 1 1401- ● ●
çizim 109270
1
BalonParca AdiParca NoAdetTipApplied Date A B C
1 ENGINE ASM; PARTIAL 5-87311-091-5 01 1 0712-1312 ●
1 ENGINE ASM; PARTIAL 5-87311-234-1 01 1 1401- ●
1 ENGINE ASM; PARTIAL 1-87310-617-3 01 1 0710-1012 ● ●
1 ENGINE ASM; PARTIAL 1-87310-722-0 01 1 1101-1208 ● ●
1 ENGINE ASM; PARTIAL 1-87310-798-0 01 1 1209-1312 ● ●
1 ENGINE ASM; PARTIAL 1-87310-965-0 01 1 1401- ● ●
İpucu: çizimdeki balona veya tablodaki Balon sütununa tıkla; ilgili parçalar vurgulanır. Birden çok çizim varsa üstteki seçim kutusu/oklarla gezin.
