8 |
KEY; SHAFT,OIL PUMP
ASM PART: A = 8-97258-461-3
|
9-19519-089-0 |
01 |
1 |
- |
| |
9 |
BODY ASM; FRT,OIL PUMP
ASM PART: A = 8-97258-461-3
|
8-97182-095-0 |
01 |
1 |
- |
| |
9 |
BODY ASM; FRT,OIL PUMP
ASM PART: B = 8-97388-651-0, C = 8-97388-652-1
|
8-97388-641-0 |
01 |
1 |
- |
| |
9 |
BODY ASM; FRT,OIL PUMP
ASM PART: D = 8-98138-133-2
|
8-98058-097-0 |
01 |
1 |
- |
| |
10 |
BODY ASM; RR,OIL PUMP
(A) ASM PART: B = 8-97388-651-0, C = 8-97388-652-1
|
8-97029-772-0 |
01 |
1 |
- |
| |
10 |
BODY ASM; RR,OIL PUMP
(B) ASM PART: A = 8-97258-461-3
|
8-97182-097-0 |
01 |
1 |
- |
| |
10 |
BODY ASM; RR,OIL PUMP
(A) ASM PART: A = 8-97258-461-3
|
8-97182-108-0 |
01 |
1 |
- |
| |
10 |
BODY ASM; RR,OIL PUMP
(A) ASM PART: D = 8-98138-133-2
|
8-98116-059-0 |
01 |
1 |
- |
| |
13 |
SHAFT KIT; RET
(A) ASM PART: A = 8-97258-461-3
|
8-97182-096-0 |
01 |
1 |
- |
| |
13 |
SHAFT KIT; RET
(B) ASM PART: A = 8-97258-461-3
|
8-97182-105-0 |
01 |
1 |
- |
| |
14 |
RING; RET,OIL PUMP
ASM PART: A = 8-97258-461-3
|
1-19519-257-0 |
01 |
1 |
- |
| |
15 |
BEARING; BALL,OIL PUMP
ASM PART: A = 8-97258-461-3
|
1-19519-264-0 |
01 |
1 |
- |
| |
16 |
RING; RET,OIL PUMP
ASM PART: A = 8-97258-461-3
|
1-19519-258-0 |
01 |
1 |
- |
| |
17 |
RING; RET
ASM PART: A = 8-97258-461-3
|
8-97182-106-0 |
01 |
1 |
- |
| |
22 |
CARTRIDGE ASM; OIL PUMP
(A) ASM PART: B = 8-97388-651-0, C = 8-97388-652-1
|
8-97148-690-0 |
01 |
1 |
- |
| |
22 |
CARTRIDGE ASM; OIL PUMP
(A) ASM PART: A = 8-97258-461-3
|
8-97182-092-0 |
01 |
1 |
- |
| |
22 |
CARTRIDGE ASM; OIL PUMP
(B) ASM PART: A = 8-97258-461-3
|
8-97182-102-0 |
01 |
1 |
- |
| |
22 |
CARTRIDGE ASM; OIL PUMP
(A) ASM PART: D = 8-98138-133-2
|
8-98058-088-0 |
01 |
1 |
-1311 |
| |
22 |
CARTRIDGE ASM; OIL PUMP
(A) ASM PART: D = 8-98138-133-2
|
8-98216-517-0 |
01 |
1 |
1312- |
| |
23 |
PLATE; SIDE,OIL PUMP
ASM PART: B = 8-97388-651-0, C = 8-97388-652-1
|
8-97147-453-0 |
01 |
1 |
- |
| |
23 |
PLATE; SIDE,OIL PUMP
ASM PART: A = 8-97258-461-3
|
8-97182-094-0 |
01 |
1 |
- |
| |
24 |
PLATE ASM; THRUST
(A) ASM PART: A = 8-97258-461-3
|
8-97182-093-0 |
01 |
1 |
- |
| |
24 |
PLATE ASM; THRUST
(B) ASM PART: A = 8-97258-461-3
|
8-97182-103-0 |
01 |
1 |
- |
| |
25 |
PIN; HSG,P/S
(A) ASM PART: A = 8-97258-461-3
|
1-19519-052-0 |
02 |
1 |
- |
| |
25 |
PIN; HSG,P/S
(B) ASM PART: A = 8-97258-461-3
|
8-97182-104-0 |
02 |
1 |
- |
| |
29 |
GASKET; PLUG TO VLV
(A) ASM PART: B = 8-97388-651-0, C = 8-97388-652-1,
D = 8-98138-133-2
|
8-94379-658-0 |
01 |
1 |
- |
| |
29 |
GASKET; PLUG TO VLV
(B) ASM PART: B = 8-97388-651-0, C = 8-97388-652-1,
D = 8-98138-133-2
|
8-94379-659-0 |
01 |
1 |
- |
| |
29 |
GASKET; PLUG TO VLV
(C) ASM PART: B = 8-97388-651-0, C = 8-97388-652-1,
D = 8-98138-133-2
|
8-94379-666-0 |
01 |
1 |
- |
| |
29 |
GASKET; PLUG TO VLV
(D) ASM PART: B = 8-97388-651-0, C = 8-97388-652-1,
D = 8-98138-133-2
|
8-97075-581-0 |
01 |
1 |
- |
| |
29 |
GASKET; PLUG TO VLV
(G), ID=11.0
ASM PART: A = 8-97258-461-3
|
9-09561-111-0 |
02 |
1 |
- |
| |
29 |
GASKET; PLUG TO VLV
(H), ID=13.0
ASM PART: A = 8-97258-461-3
|
9-09561-113-0 |
02 |
1 |
- |
| |
29 |
GASKET; PLUG TO VLV
(E) ASM PART: A = 8-97258-461-3
|
9-48429-028-0 |
01 |
1 |
- |
| |
29 |
GASKET; PLUG TO VLV
(F) ASM PART: A = 8-97258-461-3
|
9-88510-248-0 |
01 |
1 |
- |
| |
32 |
SPRING; OIL PUMP
(A) ASM PART: B = 8-97388-651-0, C = 8-97388-652-1
|
8-94379-654-0 |
01 |
1 |
- |
| |
32 |
SPRING; OIL PUMP
(A) ASM PART: A = 8-97258-461-3
|
8-94475-376-0 |
01 |
1 |
- |
| |
32 |
SPRING; OIL PUMP
(B) ASM PART: A = 8-97258-461-3
|
9-19529-013-0 |
01 |
1 |
- |
| |
33 |
BOLT; COVER
(E) ASM PART: A = 8-97258-461-3
|
1-44519-119-0 |
04 |
1 |
- |
| |
33 |
BOLT; COVER
(G) ASM PART: A = 8-97258-461-3
|
1-48119-054-0 |
02 |
1 |
- |
| |
33 |
BOLT; COVER
(B) ASM PART: B = 8-97388-651-0, C = 8-97388-652-1
|
8-97029-773-0 |
03 |
1 |
- |
| |
33 |
BOLT; COVER
(A) ASM PART: B = 8-97388-651-0, C = 8-97388-652-1
|
8-97075-585-0 |
01 |
1 |
- |
| |
33 |
BOLT; COVER
(F) ASM PART: A = 8-97258-461-3
|
8-97182-100-0 |
01 |
1 |
- |
| |
33 |
BOLT; COVER
(H) ASM PART: A = 8-97258-461-3
|
8-97182-110-0 |
02 |
1 |
- |
| |
33 |
BOLT; COVER
(C) ASM PART: D = 8-98138-133-2
|
8-97184-761-0 |
01 |
1 |
- |
| |
33 |
BOLT; COVER
(D) ASM PART: D = 8-98138-133-2
|
8-98139-286-0 |
03 |
1 |
- |
| |
35 |
PIPE; HOSE CONN,OIL PUMP
(A) ASM PART: A = 8-97258-461-3
|
8-97182-101-0 |
01 |
1 |
- |
| |
35 |
PIPE; HOSE CONN,OIL PUMP
(B) ASM PART: A = 8-97258-461-3
|
8-97258-420-1 |
01 |
1 |
- |
| |
35 |
PIPE; HOSE CONN,OIL PUMP
(A) ASM PART: B = 8-97388-651-0, C = 8-97388-652-1
|
8-97388-640-0 |
01 |
1 |
- |
| |
35 |
PIPE; HOSE CONN,OIL PUMP
(A) ASM PART: D = 8-98138-133-2
|
8-98139-290-0 |
01 |
1 |
- |
| |
36 |
BOLT; CONN,PIPE
ASM PART: B = 8-97388-651-0, C = 8-97388-652-1
|
8-94379-664-0 |
02 |
1 |
- |
| |
36 |
BOLT; CONN,PIPE
ASM PART: A = 8-97258-461-3
|
8-94461-139-1 |
04 |
1 |
- |
| |
36 |
BOLT; CONN,PIPE
ASM PART: D = 8-98138-133-2
|
8-97184-763-0 |
01 |
1 |
- |
| |
37 |
GASKET; PIPE CONN,OIL PUMP
ASM PART: A = 8-97258-461-3
|
1-19519-292-0 |
02 |
1 |
- |
| |
37 |
GASKET; PIPE CONN,OIL PUMP
ASM PART: B = 8-97388-651-0, D = 8-98138-133-2
|
8-97184-767-0 |
01 |
1 |
- |
| |
37 |
GASKET; PIPE CONN,OIL PUMP
ASM PART: C = 8-97388-652-1
|
8-97357-781-0 |
01 |
1 |
- |
| |
38 |
CONNECTOR; OIL PUMP
(A) ASM PART: B = 8-97388-651-0, C = 8-97388-652-1
|
8-97093-504-0 |
01 |
1 |
- |
| |
38 |
CONNECTOR; OIL PUMP
(A) ASM PART: A = 8-97258-461-3
|
8-97182-098-0 |
01 |
1 |
- |
| |
38 |
CONNECTOR; OIL PUMP
(B) ASM PART: A = 8-97258-461-3
|
8-97182-109-0 |
01 |
1 |
- |
| |
38 |
CONNECTOR; OIL PUMP
(A) ASM PART: D = 8-98138-133-2
|
8-98139-291-0 |
01 |
1 |
- |
