Sayfa 4-10 - Isuzu EPC

4-10 — FRONT AXLE (#213) — 294 parça

17 18 59 80 2 66 21 2 36 59 21 48 80 32 44 66 46 47 34 33 1 58 8 8 61 62 30 81 7 63 62 25 8 8 9 305 61 21 8 11 32 65 64 304 8 7 3 25 33 8 8 9 34 305 11

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date
1	AXLE; FRT FRONT AXLE F049<FS4>	1-43111-070-0	01	1	9212-9412
1	AXLE; FRT FRONT AXLE F049<FS4>	1-43111-133-0	01	1	9501-
1	AXLE; FRT EXC. FRONT AXLE F049<FS4>	1-43111-101-2	01	1	9212-
2	KNUCKLE; FRT AXLE FRONT AXLE F049<FS4>	1-43132-044-6	01	1	9212-9412
2	KNUCKLE; FRT AXLE FRONT AXLE F049<FS4>	1-43132-089-0	01	1	9501-
2	KNUCKLE; FRT AXLE FRONT AXLE F049<FS4>	1-43131-044-6	01	1	9212-9412
2	KNUCKLE; FRT AXLE FRONT AXLE F049<FS4>	1-43131-089-0	01	1	9501-
2	KNUCKLE; FRT AXLE EXC. FRONT AXLE F049<FS4>	1-43132-075-2	01	1	9212-9310
2	KNUCKLE; FRT AXLE EXC. FRONT AXLE F049<FS4>	1-43132-080-1	01	1	9311-
2	KNUCKLE; FRT AXLE EXC. FRONT AXLE F049<FS4>	1-43131-075-2	01	1	9212-9310
2	KNUCKLE; FRT AXLE EXC. FRONT AXLE F049<FS4>	1-43131-080-1	01	1	9311-
3	KING PIN SET FRONT AXLE F049<FS4>	1-87830-363-0	02	1	9212-9412
3	KING PIN SET FRONT AXLE F049<FS4>	1-87830-804-0	02	1	9501-
3	KING PIN SET EXC. FRONT AXLE F049<FS4>	1-87830-615-0	01	1	9212-9310
3	KING PIN SET EXC. FRONT AXLE F049<FS4>	1-87830-717-0	01	1	9311-
3	KING PIN SET EXC. FRONT AXLE F049<FS4>	1-87830-614-0	01	1	9212-9310
3	KING PIN SET EXC. FRONT AXLE F049<FS4>	1-87830-716-0	01	1	9311-
7	SEAL; OIL,KING PIN FRONT AXLE F049<FS4> NSK	1-09625-087-0	02	1	9212-
7	SEAL; OIL,KING PIN FRONT AXLE F049<FS4> NTN	1-09625-089-0	02	1	9212-
7	SEAL; OIL,KING PIN EXC. FRONT AXLE F049<FS4> OD=42	1-09625-005-1	02	1	9212-
8	BEARING; NEEDLE,KING PIN FRONT AXLE F049<FS4> NTN	1-09811-071-0	08	1	9212-
8	BEARING; NEEDLE,KING PIN FRONT AXLE F049<FS4> NSK	1-09811-072-0	08	1	9212-
8	BEARING; NEEDLE,KING PIN EXC. FRONT AXLE F049<FS4> NTN	1-09811-001-0	08	1	9212-
8	BEARING; NEEDLE,KING PIN EXC. FRONT AXLE F049<FS4> NSK	1-09811-339-0	08	1	9212-
9	PLUG; KNUCKLE FRONT AXLE F049<FS4>	9-09201-363-0	02	1	9212-9412
9	PLUG; KNUCKLE EXC. FRONT AXLE F049<FS4>	9-09201-048-0	02	1	9212-9310
11	RING; SNAP,KNUCKLE PLUG FRONT AXLE F049<FS4>	9-09950-204-0	02	1	9501-
11	RING; SNAP,KNUCKLE PLUG EXC. FRONT AXLE F049<FS4>	1-09589-017-1	02	1	9311-
17	BOLT; STOPPER KNUCKLE FRONT AXLE F049<FS4> M14X47.0	1-09009-058-0	02	1	9212-
17	BOLT; STOPPER KNUCKLE BRAKE SYSTEM HEAVY DUTY VAR2(WG3) EXC. HEAVY DUTY PACKAGE TRUCK<RD2> M14X47.0	1-09009-058-0	02	1	9212-
17	BOLT; STOPPER KNUCKLE EXC. BRAKE SYSTEM HEAVY DUTY VAR2(WG3) M14X42.5	1-09009-008-0	02	1	9212-
18	NUT; STOPPER BOLT,KNUCKLE FRONT AXLE F049<FS4> M14	9-99112-814-0	02	1	9212-
18	NUT; STOPPER BOLT,KNUCKLE EXC. FRONT AXLE F049<FS4> M14	5-09400-034-0	02	1	9212-
21	NIPPLE; GREASE,KING PIN PT1/8 STRAIGHT	9-09031-010-0	04	1	9212-
25	BEARING; THRUST,KING PIN FRONT AXLE F049<FS4> NTN	1-09829-026-0	02	1	9212-
25	BEARING; THRUST,KING PIN FRONT AXLE F049<FS4> NSK	1-09829-028-0	02	1	9212-
25	BEARING; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> NSK	1-09829-033-1	01	1	9212-
25	BEARING; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> NSK	1-09829-031-0	01	1	9212-
30	WASHER; THRUST,KING PIN FRONT AXLE F049<FS4> T=2.8000	1-43171-229-0	AR	1	9212-
30	WASHER; THRUST,KING PIN FRONT AXLE F049<FS4> T=2.8500	1-43171-230-0	AR	1	9212-
30	WASHER; THRUST,KING PIN FRONT AXLE F049<FS4> T=2.9000	1-43171-231-0	AR	1	9212-
30	WASHER; THRUST,KING PIN FRONT AXLE F049<FS4> T=2.9500	1-43171-232-0	AR	1	9212-
30	WASHER; THRUST,KING PIN FRONT AXLE F049<FS4> T=3.0000	1-43171-233-0	AR	1	9212-
30	WASHER; THRUST,KING PIN FRONT AXLE F049<FS4> T=3.0500	1-43171-234-0	AR	1	9212-
30	WASHER; THRUST,KING PIN FRONT AXLE F049<FS4> T=3.1000	1-43171-235-0	AR	1	9212-
30	WASHER; THRUST,KING PIN FRONT AXLE F049<FS4> T=3.1500	1-43171-236-0	AR	1	9212-
30	WASHER; THRUST,KING PIN FRONT AXLE F049<FS4> T=3.2000	1-43171-237-0	AR	1	9212-
30	WASHER; THRUST,KING PIN FRONT AXLE F049<FS4> T=3.2500	1-43171-238-0	AR	1	9212-
30	WASHER; THRUST,KING PIN FRONT AXLE F049<FS4> T=3.3000	1-43171-239-0	AR	1	9212-
30	WASHER; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> T=3.9000	1-43171-261-1	AR	1	9212-
30	WASHER; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> T=3.9125	1-43171-262-1	AR	1	9212-
30	WASHER; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> T=3.9250	1-43171-263-1	AR	1	9212-
30	WASHER; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> T=3.9375	1-43171-264-1	AR	1	9212-
30	WASHER; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> T=3.9500	1-43171-265-1	AR	1	9212-
30	WASHER; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> T=3.9625	1-43171-266-1	AR	1	9212-
30	WASHER; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> T=3.9750	1-43171-267-1	AR	1	9212-
30	WASHER; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> T=3.9875	1-43171-268-1	AR	1	9212-
30	WASHER; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> T=4.0000	1-43171-269-1	AR	1	9212-
30	WASHER; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> T=4.0125	1-43171-270-1	AR	1	9212-
30	WASHER; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> T=4.0250	1-43171-271-1	AR	1	9212-
30	WASHER; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> T=4.0375	1-43171-272-1	AR	1	9212-
30	WASHER; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> T=4.0500	1-43171-273-1	AR	1	9212-
30	WASHER; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> T=4.0625	1-43171-274-1	AR	1	9212-
30	WASHER; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> T=4.0750	1-43171-275-1	AR	1	9212-
30	WASHER; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> T=4.0875	1-43171-276-1	AR	1	9212-
30	WASHER; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> T=4.1000	1-43171-277-1	AR	1	9212-
30	WASHER; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> T=4.1125	1-43171-278-1	AR	1	9212-
30	WASHER; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> T=4.1250	1-43171-279-1	AR	1	9212-
30	WASHER; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> T=4.1375	1-43171-280-1	AR	1	9212-
30	WASHER; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> T=4.1500	1-43171-281-1	AR	1	9212-
30	WASHER; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> T=4.162	1-43171-311-0	AR	1	9406-
30	WASHER; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> T=4.175	1-43171-312-0	AR	1	9406-
30	WASHER; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> T=4.187	1-43171-313-0	AR	1	9406-
30	WASHER; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> T=4.200	1-43171-314-0	AR	1	9406-
30	WASHER; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> T=4.212	1-43171-315-0	AR	1	9406-
30	WASHER; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> T=4.225	1-43171-316-0	AR	1	9406-
30	WASHER; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> T=4.237	1-43171-317-0	AR	1	9406-
30	WASHER; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> T=4.250	1-43171-318-0	AR	1	9406-
30	WASHER; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> T=4.262	1-43171-319-0	AR	1	9406-
30	WASHER; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> T=4.275	1-43171-320-0	AR	1	9406-
30	WASHER; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> T=4.287	1-43171-321-0	AR	1	9406-
30	WASHER; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> T=4.300	1-43171-322-0	AR	1	9406-
30	WASHER; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> T=4.312	1-43171-323-0	AR	1	9406-
30	WASHER; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> T=4.325	1-43171-324-0	AR	1	9406-
30	WASHER; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> T=4.337	1-43171-325-0	AR	1	9406-
30	WASHER; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> T=4.350	1-43171-326-0	AR	1	9406-
32	BOLT; KEY,KING PIN FRONT AXLE F049<FS4>	1-43116-005-1	02	1	9212-
32	BOLT; KEY,KING PIN EXC. FRONT AXLE F049<FS4>	1-43116-003-1	02	1	9212-
33	NUT; KEY BOLT M10	9-09110-410-0	02	1	9212-
34	WASHER; LK,KEY BOLT ID=10.2	9-09150-510-0	02	1	9212-
36	ARM; KNUCKLE FRONT AXLE F049<FS4>	1-43133-031-1	01	1	9212-9503
36	ARM; KNUCKLE FRONT AXLE F049<FS4>	1-43133-069-0	01	1	9504-
36	ARM; KNUCKLE EXC. FRONT AXLE F049<FS4>	1-43133-055-6	01	1	9212-
44	COVER; KING PIN FRONT AXLE F049<FS4>	1-43175-016-0	02	1	9212-
44	COVER; KING PIN EXC. FRONT AXLE F049<FS4>	1-43175-015-0	02	1	9212-
46	WASHER; LK,COVER ID=12.2	9-09150-512-0	02	1	9212-
47	WASHER; PL,COVER,KING PIN ID=12.5 OD=32	9-09164-712-0	02	1	9212-
48	BOLT; COVER M12X25	1-09009-081-0	02	1	9212-
58	ARM; TIE ROD FRONT AXLE F049<FS4>	1-43135-015-1	01	1	9212-
58	ARM; TIE ROD FRONT AXLE F049<FS4>	1-43134-015-1	01	1	9212-
58	ARM; TIE ROD EXC. FRONT AXLE F049<FS4>	1-43134-034-2	01	1	9212-
59	NUT; TIE ROD ARM M27	1-09449-016-0	02	1	9212-
61	ROD END; TIE ROD FRONT AXLE F049<FS4> EXC. FRT AXLE GREASE NON MAINTENANCE<B3L>	1-43150-658-1	01	1	9212-9302
61	ROD END; TIE ROD FRONT AXLE F049<FS4> EXC. FRT AXLE GREASE NON MAINTENANCE<B3L>	1-43150-657-1	01	1	9212-9302
61	ROD END; TIE ROD FRT AXLE GREASE NON MAINTENANCE<B3L> FRONT AXLE F049<FS4>	1-43150-671-1	01	1	9212-9302
61	ROD END; TIE ROD FRONT AXLE F049<FS4>	1-43150-671-1	01	1	9303-
61	ROD END; TIE ROD FRT AXLE GREASE NON MAINTENANCE<B3L> FRONT AXLE F049<FS4>	1-43150-670-1	01	1	9212-9302
61	ROD END; TIE ROD FRONT AXLE F049<FS4>	1-43150-670-1	01	1	9303-
61	ROD END; TIE ROD FRT AXLE GREASE NON MAINTENANCE<B3L> BRAKE SYSTEM HEAVY DUTY VAR2(WG3) EXC. HEAVY DUTY PACKAGE TRUCK<RD2>	1-43150-680-1	01	1	9212-9302
61	ROD END; TIE ROD FRT AXLE GREASE NON MAINTENANCE<B3L> EXC. IVORY COAST EQUIPMENT(SW3),BRAKE SYSTEM HEAVY DUTY VAR2(WG3)	1-43150-680-1	01	1	9212-9302
61	ROD END; TIE ROD BRAKE SYSTEM HEAVY DUTY VAR2(WG3) EXC. HEAVY DUTY PACKAGE TRUCK<RD2>	1-43150-680-1	01	1	9303-
61	ROD END; TIE ROD EXC. IVORY COAST EQUIPMENT(SW3),BRAKE SYSTEM HEAVY DUTY VAR2(WG3)	1-43150-680-1	01	1	9303-
61	ROD END; TIE ROD FRT AXLE GREASE NON MAINTENANCE<B3L> BRAKE SYSTEM HEAVY DUTY VAR2(WG3) EXC. HEAVY DUTY PACKAGE TRUCK<RD2>	1-43150-679-1	01	1	9212-9302
61	ROD END; TIE ROD FRT AXLE GREASE NON MAINTENANCE<B3L> EXC. IVORY COAST EQUIPMENT(SW3),BRAKE SYSTEM HEAVY DUTY VAR2(WG3)	1-43150-679-1	01	1	9212-9302
61	ROD END; TIE ROD BRAKE SYSTEM HEAVY DUTY VAR2(WG3) EXC. HEAVY DUTY PACKAGE TRUCK<RD2>	1-43150-679-1	01	1	9303-
61	ROD END; TIE ROD EXC. IVORY COAST EQUIPMENT(SW3),BRAKE SYSTEM HEAVY DUTY VAR2(WG3)	1-43150-679-1	01	1	9303-
61	ROD END; TIE ROD BRAKE SYSTEM HEAVY DUTY VAR2(WG3) EXC. FRT AXLE GREASE NON MAINTENANCE<B3L>,HEAVY DUTY PACKAGE TRUCK<RD2>	1-43150-654-2	01	1	9212-9302
61	ROD END; TIE ROD EXC. FRT AXLE GREASE NON MAINTENANCE<B3L>,IVORY COAST EQUIPMENT(SW3),BRAKE SYSTEM HEAVY DUTY VAR2(WG3)	1-43150-654-2	01	1	9212-9302
61	ROD END; TIE ROD BRAKE SYSTEM HEAVY DUTY VAR2(WG3) EXC. FRT AXLE GREASE NON MAINTENANCE<B3L>,HEAVY DUTY PACKAGE TRUCK<RD2>	1-43150-653-2	01	1	9212-9302
61	ROD END; TIE ROD EXC. FRT AXLE GREASE NON MAINTENANCE<B3L>,IVORY COAST EQUIPMENT(SW3),BRAKE SYSTEM HEAVY DUTY VAR2(WG3)	1-43150-653-2	01	1	9212-9302
61	ROD END; TIE ROD IVORY COAST EQUIPMENT(SW3) EXC. REAR WHEEL PARKING BRAKE AIR CONTROL(B3A),FRT AXLE GREASE NON MAINTENANCE<B3L>,BRAKE SYSTEM HEAVYDUTY VAR2(WG3)	1-43150-656-0	01	1	9212-9302
61	ROD END; TIE ROD IVORY COAST EQUIPMENT(SW3) EXC. REAR WHEEL PARKING BRAKE AIR CONTROL(B3A), BRAKE SYSTEM HEAVY DUTY VAR2(WG3)	1-43150-602-2	01	1	9303-
61	ROD END; TIE ROD IVORY COAST EQUIPMENT(SW3) EXC. REAR WHEEL PARKING BRAKE AIR CONTROL(B3A),FRT AXLE GREASE NON MAINTENANCE<B3L>,BRAKE SYSTEM HEAVYDUTY VAR2(WG3)	1-43150-655-0	01	1	9212-9302
61	ROD END; TIE ROD IVORY COAST EQUIPMENT(SW3) EXC. REAR WHEEL PARKING BRAKE AIR CONTROL(B3A), BRAKE SYSTEM HEAVY DUTY VAR2(WG3)	1-43150-601-2	01	1	9303-
62	CLAMP; TIE ROD BRAKE SYSTEM HEAVY DUTY VAR2(WG3) EXC. HEAVY DUTY PACKAGE TRUCK<RD2>	1-43159-002-2	02	1	9212-
62	CLAMP; TIE ROD EXC. IVORY COAST EQUIPMENT(SW3),BRAKE SYSTEM HEAVY DUTY VAR2(WG3)	1-43159-002-2	02	1	9212-
63	BOLT; CLAMP TIE ROD BRAKE SYSTEM HEAVY DUTY VAR2(WG3) EXC. HEAVY DUTY PACKAGE TRUCK<RD2> M12X47	9-09801-294-0	02	1	9212-
63	BOLT; CLAMP TIE ROD EXC. IVORY COAST EQUIPMENT(SW3),BRAKE SYSTEM HEAVY DUTY VAR2(WG3) M12X47	9-09801-294-0	02	1	9212-
64	NUT; CLAMP BRAKE SYSTEM HEAVY DUTY VAR2(WG3) EXC. HEAVY DUTY PACKAGE TRUCK<RD2> M12	9-99110-512-0	02	1	9212-
64	NUT; CLAMP EXC. IVORY COAST EQUIPMENT(SW3),BRAKE SYSTEM HEAVY DUTY VAR2(WG3) M12	9-99110-512-0	02	1	9212-
65	WASHER; LK,CLAMP BRAKE SYSTEM HEAVY DUTY VAR2(WG3) EXC. HEAVY DUTY PACKAGE TRUCK<RD2> ID=12.2	9-09150-812-0	02	1	9212-9410
65	WASHER; LK,CLAMP EXC. IVORY COAST EQUIPMENT(SW3),BRAKE SYSTEM HEAVY DUTY VAR2(WG3) ID=12.2	9-09150-812-0	02	1	9212-9410
66	NUT; TIE ROD END FRONT AXLE F049<FS4> M24 SLOTTED	1-09442-020-0	02	1	9212-
66	NUT; TIE ROD END EXC. FRONT AXLE F049<FS4> M16 SLOTTED	1-09442-021-1	02	1	9212-
80	PIN; SPLIT,ROD END FRONT AXLE F049<FS4> OD=4.6 L=35	9-08115-035-0	02	1	9212-
80	PIN; SPLIT,ROD END EXC. FRONT AXLE F049<FS4> OD=3.7 L=22	9-08114-022-0	02	1	9212-
81	ROD; TIE FRONT AXLE F049<FS4>	1-43151-077-0	01	1	9212-
81	ROD; TIE BRAKE SYSTEM HEAVY DUTY VAR2(WG3) EXC. HEAVY DUTY PACKAGE TRUCK<RD2>	1-43151-109-0	01	1	9212-
81	ROD; TIE EXC. IVORY COAST EQUIPMENT(SW3),BRAKE SYSTEM HEAVY DUTY VAR2(WG3)	1-43151-109-0	01	1	9212-
81	ROD; TIE IVORY COAST EQUIPMENT(SW3) EXC. REAR WHEEL PARKING BRAKE AIR CONTROL(B3A), BRAKE SYSTEM HEAVY DUTY VAR2(WG3)	1-43151-116-0	01	1	9212-
304	WASHER; PL FRONT AXLE F049<FS4> ID=12.5	9-09164-512-0	04	1	9411-
304	WASHER; PL EXC. FRONT AXLE F049<FS4> ID=12.5	9-09164-512-0	02	1	9411-
305	COVER; KNUCKLE FRONT AXLE F049<FS4>	1-43175-021-0	02	1	9501-
305	COVER; KNUCKLE EXC. FRONT AXLE F049<FS4>	1-43175-022-0	02	1	9311-

40 21 36 17 18 59 59 42 21 2 48 2 32 43 33 255 80 66 44 37 37 46 47 34 1 8 8 58 61 80 30 74 7 67 304 66 25 68 58 61 8 8 9 305 11 81 8 32 8 7 3 25 33 8 8 9 34 305 11

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date
1	AXLE; FRT FRONT AXLE F049<FS4>	1-43111-070-0	01	1	9212-9412
1	AXLE; FRT FRONT AXLE F049<FS4>	1-43111-133-0	01	1	9501-
1	AXLE; FRT EXC. FRONT AXLE F049<FS4>	1-43111-101-2	01	1	9212-
2	KNUCKLE; FRT AXLE FRONT AXLE F049<FS4>	1-43132-044-6	01	1	9212-9412
2	KNUCKLE; FRT AXLE FRONT AXLE F049<FS4>	1-43132-089-0	01	1	9501-
2	KNUCKLE; FRT AXLE FRONT AXLE F049<FS4>	1-43131-044-6	01	1	9212-9412
2	KNUCKLE; FRT AXLE FRONT AXLE F049<FS4>	1-43131-089-0	01	1	9501-
2	KNUCKLE; FRT AXLE EXC. FRONT AXLE F049<FS4>	1-43132-075-2	01	1	9212-9310
2	KNUCKLE; FRT AXLE EXC. FRONT AXLE F049<FS4>	1-43132-080-1	01	1	9311-
2	KNUCKLE; FRT AXLE EXC. FRONT AXLE F049<FS4>	1-43131-075-2	01	1	9212-9310
2	KNUCKLE; FRT AXLE EXC. FRONT AXLE F049<FS4>	1-43131-080-1	01	1	9311-
3	KING PIN SET FRONT AXLE F049<FS4>	1-87830-363-0	02	1	9212-9412
3	KING PIN SET FRONT AXLE F049<FS4>	1-87830-804-0	02	1	9501-
3	KING PIN SET EXC. FRONT AXLE F049<FS4>	1-87830-615-0	01	1	9212-9310
3	KING PIN SET EXC. FRONT AXLE F049<FS4>	1-87830-717-0	01	1	9311-
3	KING PIN SET EXC. FRONT AXLE F049<FS4>	1-87830-614-0	01	1	9212-9310
3	KING PIN SET EXC. FRONT AXLE F049<FS4>	1-87830-716-0	01	1	9311-
7	SEAL; OIL,KING PIN FRONT AXLE F049<FS4> NSK	1-09625-087-0	02	1	9212-
7	SEAL; OIL,KING PIN FRONT AXLE F049<FS4> NTN	1-09625-089-0	02	1	9212-
7	SEAL; OIL,KING PIN EXC. FRONT AXLE F049<FS4> OD=42	1-09625-005-1	02	1	9212-
8	BEARING; NEEDLE,KING PIN FRONT AXLE F049<FS4> NTN	1-09811-071-0	08	1	9212-
8	BEARING; NEEDLE,KING PIN FRONT AXLE F049<FS4> NSK	1-09811-072-0	08	1	9212-
8	BEARING; NEEDLE,KING PIN EXC. FRONT AXLE F049<FS4> NTN	1-09811-001-0	08	1	9212-
8	BEARING; NEEDLE,KING PIN EXC. FRONT AXLE F049<FS4> NSK	1-09811-339-0	08	1	9212-
9	PLUG; KNUCKLE FRONT AXLE F049<FS4>	9-09201-363-0	02	1	9212-9412
9	PLUG; KNUCKLE EXC. FRONT AXLE F049<FS4>	9-09201-048-0	02	1	9212-9310
11	RING; SNAP,KNUCKLE PLUG FRONT AXLE F049<FS4>	9-09950-204-0	02	1	9501-
11	RING; SNAP,KNUCKLE PLUG EXC. FRONT AXLE F049<FS4>	1-09589-017-1	02	1	9311-
17	BOLT; STOPPER KNUCKLE FRONT AXLE F049<FS4> M14X47.0	1-09009-058-0	02	1	9212-
17	BOLT; STOPPER KNUCKLE BRAKE SYSTEM HEAVY DUTY VAR2(WG3) EXC. HEAVY DUTY PACKAGE TRUCK<RD2> M14X47.0	1-09009-058-0	02	1	9212-
17	BOLT; STOPPER KNUCKLE EXC. BRAKE SYSTEM HEAVY DUTY VAR2(WG3) M14X42.5	1-09009-008-0	02	1	9212-
18	NUT; STOPPER BOLT,KNUCKLE FRONT AXLE F049<FS4> M14	9-99112-814-0	02	1	9212-
18	NUT; STOPPER BOLT,KNUCKLE EXC. FRONT AXLE F049<FS4> M14	5-09400-034-0	02	1	9212-
21	NIPPLE; GREASE,KING PIN PT1/8 STRAIGHT	9-09031-010-0	04	1	9212-
25	BEARING; THRUST,KING PIN FRONT AXLE F049<FS4> NTN	1-09829-026-0	02	1	9212-
25	BEARING; THRUST,KING PIN FRONT AXLE F049<FS4> NSK	1-09829-028-0	02	1	9212-
25	BEARING; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> NSK	1-09829-033-1	01	1	9212-
25	BEARING; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> NSK	1-09829-031-0	01	1	9212-
30	WASHER; THRUST,KING PIN FRONT AXLE F049<FS4> T=2.8000	1-43171-229-0	AR	1	9212-
30	WASHER; THRUST,KING PIN FRONT AXLE F049<FS4> T=2.8500	1-43171-230-0	AR	1	9212-
30	WASHER; THRUST,KING PIN FRONT AXLE F049<FS4> T=2.9000	1-43171-231-0	AR	1	9212-
30	WASHER; THRUST,KING PIN FRONT AXLE F049<FS4> T=2.9500	1-43171-232-0	AR	1	9212-
30	WASHER; THRUST,KING PIN FRONT AXLE F049<FS4> T=3.0000	1-43171-233-0	AR	1	9212-
30	WASHER; THRUST,KING PIN FRONT AXLE F049<FS4> T=3.0500	1-43171-234-0	AR	1	9212-
30	WASHER; THRUST,KING PIN FRONT AXLE F049<FS4> T=3.1000	1-43171-235-0	AR	1	9212-
30	WASHER; THRUST,KING PIN FRONT AXLE F049<FS4> T=3.1500	1-43171-236-0	AR	1	9212-
30	WASHER; THRUST,KING PIN FRONT AXLE F049<FS4> T=3.2000	1-43171-237-0	AR	1	9212-
30	WASHER; THRUST,KING PIN FRONT AXLE F049<FS4> T=3.2500	1-43171-238-0	AR	1	9212-
30	WASHER; THRUST,KING PIN FRONT AXLE F049<FS4> T=3.3000	1-43171-239-0	AR	1	9212-
30	WASHER; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> T=3.9000	1-43171-261-1	AR	1	9212-
30	WASHER; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> T=3.9125	1-43171-262-1	AR	1	9212-
30	WASHER; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> T=3.9250	1-43171-263-1	AR	1	9212-
30	WASHER; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> T=3.9375	1-43171-264-1	AR	1	9212-
30	WASHER; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> T=3.9500	1-43171-265-1	AR	1	9212-
30	WASHER; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> T=3.9625	1-43171-266-1	AR	1	9212-
30	WASHER; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> T=3.9750	1-43171-267-1	AR	1	9212-
30	WASHER; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> T=3.9875	1-43171-268-1	AR	1	9212-
30	WASHER; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> T=4.0000	1-43171-269-1	AR	1	9212-
30	WASHER; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> T=4.0125	1-43171-270-1	AR	1	9212-
30	WASHER; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> T=4.0250	1-43171-271-1	AR	1	9212-
30	WASHER; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> T=4.0375	1-43171-272-1	AR	1	9212-
30	WASHER; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> T=4.0500	1-43171-273-1	AR	1	9212-
30	WASHER; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> T=4.0625	1-43171-274-1	AR	1	9212-
30	WASHER; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> T=4.0750	1-43171-275-1	AR	1	9212-
30	WASHER; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> T=4.0875	1-43171-276-1	AR	1	9212-
30	WASHER; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> T=4.1000	1-43171-277-1	AR	1	9212-
30	WASHER; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> T=4.1125	1-43171-278-1	AR	1	9212-
30	WASHER; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> T=4.1250	1-43171-279-1	AR	1	9212-
30	WASHER; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> T=4.1375	1-43171-280-1	AR	1	9212-
30	WASHER; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> T=4.1500	1-43171-281-1	AR	1	9212-
30	WASHER; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> T=4.162	1-43171-311-0	AR	1	9406-
30	WASHER; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> T=4.175	1-43171-312-0	AR	1	9406-
30	WASHER; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> T=4.187	1-43171-313-0	AR	1	9406-
30	WASHER; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> T=4.200	1-43171-314-0	AR	1	9406-
30	WASHER; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> T=4.212	1-43171-315-0	AR	1	9406-
30	WASHER; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> T=4.225	1-43171-316-0	AR	1	9406-
30	WASHER; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> T=4.237	1-43171-317-0	AR	1	9406-
30	WASHER; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> T=4.250	1-43171-318-0	AR	1	9406-
30	WASHER; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> T=4.262	1-43171-319-0	AR	1	9406-
30	WASHER; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> T=4.275	1-43171-320-0	AR	1	9406-
30	WASHER; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> T=4.287	1-43171-321-0	AR	1	9406-
30	WASHER; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> T=4.300	1-43171-322-0	AR	1	9406-
30	WASHER; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> T=4.312	1-43171-323-0	AR	1	9406-
30	WASHER; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> T=4.325	1-43171-324-0	AR	1	9406-
30	WASHER; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> T=4.337	1-43171-325-0	AR	1	9406-
30	WASHER; THRUST,KING PIN EXC. FRONT AXLE F049<FS4> T=4.350	1-43171-326-0	AR	1	9406-
32	BOLT; KEY,KING PIN FRONT AXLE F049<FS4>	1-43116-005-1	02	1	9212-
32	BOLT; KEY,KING PIN EXC. FRONT AXLE F049<FS4>	1-43116-003-1	02	1	9212-
33	NUT; KEY BOLT M10	9-09110-410-0	02	1	9212-
34	WASHER; LK,KEY BOLT ID=10.2	9-09150-510-0	02	1	9212-
36	ARM; KNUCKLE FRONT AXLE F049<FS4>	1-43133-031-1	01	1	9212-9503
36	ARM; KNUCKLE FRONT AXLE F049<FS4>	1-43133-069-0	01	1	9504-
36	ARM; KNUCKLE EXC. FRONT AXLE F049<FS4>	1-43133-055-6	01	1	9212-
37	BOLT; KNUCKLE ARM FRONT AXLE F049<FS4> M22X162	1-09000-107-0	01	1	9212-
37	BOLT; KNUCKLE ARM FRONT AXLE F049<FS4> M22X147	1-09000-108-0	01	1	9212-
40	NUT; KNUCKLE ARM FRONT AXLE F049<FS4> M22	9-09844-670-0	02	1	9212-
42	JOINT; BALL,KNUCKLE ARM FRONT AXLE F049<FS4>	1-44361-060-0	01	1	9212-9503
42	JOINT; BALL,KNUCKLE ARM FRONT AXLE F049<FS4>	1-44361-110-1	01	1	9504-
43	NUT; JOINT BALL,KNUCKLE ARM FRONT AXLE F049<FS4> M24	9-09844-669-2	01	1	9212-9503
43	NUT; JOINT BALL,KNUCKLE ARM FRONT AXLE F049<FS4> M24 SLOTTED	1-09442-020-0	01	1	9504-
44	COVER; KING PIN FRONT AXLE F049<FS4>	1-43175-016-0	02	1	9212-
44	COVER; KING PIN EXC. FRONT AXLE F049<FS4>	1-43175-015-0	02	1	9212-
46	WASHER; LK,COVER ID=12.2	9-09150-512-0	02	1	9212-
47	WASHER; PL,COVER,KING PIN ID=12.5 OD=32	9-09164-712-0	02	1	9212-
48	BOLT; COVER M12X25	1-09009-081-0	02	1	9212-
58	ARM; TIE ROD FRONT AXLE F049<FS4>	1-43135-015-1	01	1	9212-
58	ARM; TIE ROD FRONT AXLE F049<FS4>	1-43134-015-1	01	1	9212-
58	ARM; TIE ROD EXC. FRONT AXLE F049<FS4>	1-43134-034-2	01	1	9212-
59	NUT; TIE ROD ARM M27	1-09449-016-0	02	1	9212-
61	ROD END; TIE ROD FRONT AXLE F049<FS4> EXC. FRT AXLE GREASE NON MAINTENANCE<B3L>	1-43150-658-1	01	1	9212-9302
61	ROD END; TIE ROD FRONT AXLE F049<FS4> EXC. FRT AXLE GREASE NON MAINTENANCE<B3L>	1-43150-657-1	01	1	9212-9302
61	ROD END; TIE ROD FRT AXLE GREASE NON MAINTENANCE<B3L> FRONT AXLE F049<FS4>	1-43150-671-1	01	1	9212-9302
61	ROD END; TIE ROD FRONT AXLE F049<FS4>	1-43150-671-1	01	1	9303-
61	ROD END; TIE ROD FRT AXLE GREASE NON MAINTENANCE<B3L> FRONT AXLE F049<FS4>	1-43150-670-1	01	1	9212-9302
61	ROD END; TIE ROD FRONT AXLE F049<FS4>	1-43150-670-1	01	1	9303-
61	ROD END; TIE ROD FRT AXLE GREASE NON MAINTENANCE<B3L> BRAKE SYSTEM HEAVY DUTY VAR2(WG3) EXC. HEAVY DUTY PACKAGE TRUCK<RD2>	1-43150-680-1	01	1	9212-9302
61	ROD END; TIE ROD FRT AXLE GREASE NON MAINTENANCE<B3L> EXC. IVORY COAST EQUIPMENT(SW3),BRAKE SYSTEM HEAVY DUTY VAR2(WG3)	1-43150-680-1	01	1	9212-9302
61	ROD END; TIE ROD BRAKE SYSTEM HEAVY DUTY VAR2(WG3) EXC. HEAVY DUTY PACKAGE TRUCK<RD2>	1-43150-680-1	01	1	9303-
61	ROD END; TIE ROD EXC. IVORY COAST EQUIPMENT(SW3),BRAKE SYSTEM HEAVY DUTY VAR2(WG3)	1-43150-680-1	01	1	9303-
61	ROD END; TIE ROD FRT AXLE GREASE NON MAINTENANCE<B3L> BRAKE SYSTEM HEAVY DUTY VAR2(WG3) EXC. HEAVY DUTY PACKAGE TRUCK<RD2>	1-43150-679-1	01	1	9212-9302
61	ROD END; TIE ROD FRT AXLE GREASE NON MAINTENANCE<B3L> EXC. IVORY COAST EQUIPMENT(SW3),BRAKE SYSTEM HEAVY DUTY VAR2(WG3)	1-43150-679-1	01	1	9212-9302
61	ROD END; TIE ROD BRAKE SYSTEM HEAVY DUTY VAR2(WG3) EXC. HEAVY DUTY PACKAGE TRUCK<RD2>	1-43150-679-1	01	1	9303-
61	ROD END; TIE ROD EXC. IVORY COAST EQUIPMENT(SW3),BRAKE SYSTEM HEAVY DUTY VAR2(WG3)	1-43150-679-1	01	1	9303-
61	ROD END; TIE ROD BRAKE SYSTEM HEAVY DUTY VAR2(WG3) EXC. FRT AXLE GREASE NON MAINTENANCE<B3L>,HEAVY DUTY PACKAGE TRUCK<RD2>	1-43150-654-2	01	1	9212-9302
61	ROD END; TIE ROD EXC. FRT AXLE GREASE NON MAINTENANCE<B3L>,IVORY COAST EQUIPMENT(SW3),BRAKE SYSTEM HEAVY DUTY VAR2(WG3)	1-43150-654-2	01	1	9212-9302
61	ROD END; TIE ROD BRAKE SYSTEM HEAVY DUTY VAR2(WG3) EXC. FRT AXLE GREASE NON MAINTENANCE<B3L>,HEAVY DUTY PACKAGE TRUCK<RD2>	1-43150-653-2	01	1	9212-9302
61	ROD END; TIE ROD EXC. FRT AXLE GREASE NON MAINTENANCE<B3L>,IVORY COAST EQUIPMENT(SW3),BRAKE SYSTEM HEAVY DUTY VAR2(WG3)	1-43150-653-2	01	1	9212-9302
61	ROD END; TIE ROD IVORY COAST EQUIPMENT(SW3) EXC. REAR WHEEL PARKING BRAKE AIR CONTROL(B3A),FRT AXLE GREASE NON MAINTENANCE<B3L>,BRAKE SYSTEM HEAVYDUTY VAR2(WG3)	1-43150-656-0	01	1	9212-9302
61	ROD END; TIE ROD IVORY COAST EQUIPMENT(SW3) EXC. REAR WHEEL PARKING BRAKE AIR CONTROL(B3A), BRAKE SYSTEM HEAVY DUTY VAR2(WG3)	1-43150-602-2	01	1	9303-
61	ROD END; TIE ROD IVORY COAST EQUIPMENT(SW3) EXC. REAR WHEEL PARKING BRAKE AIR CONTROL(B3A),FRT AXLE GREASE NON MAINTENANCE<B3L>,BRAKE SYSTEM HEAVYDUTY VAR2(WG3)	1-43150-655-0	01	1	9212-9302
61	ROD END; TIE ROD IVORY COAST EQUIPMENT(SW3) EXC. REAR WHEEL PARKING BRAKE AIR CONTROL(B3A), BRAKE SYSTEM HEAVY DUTY VAR2(WG3)	1-43150-601-2	01	1	9303-
66	NUT; TIE ROD END FRONT AXLE F049<FS4> M24 SLOTTED	1-09442-020-0	02	1	9212-
66	NUT; TIE ROD END EXC. FRONT AXLE F049<FS4> M16 SLOTTED	1-09442-021-1	02	1	9212-
67	WASHER; LK,TIE ROD END FRONT AXLE F049<FS4> ID=12.2	9-09150-812-0	04	1	9212-9410
67	WASHER; LK,TIE ROD END IVORY COAST EQUIPMENT(SW3) EXC. REAR WHEEL PARKING BRAKE AIR CONTROL(B3A), BRAKE SYSTEM HEAVY DUTY VAR2(WG3) ID=12.2	9-09150-812-0	02	1	9212-9410
68	BOLT; TIE ROD END FRONT AXLE F049<FS4> M12X55	9-91061-255-0	04	1	9212-
68	BOLT; TIE ROD END IVORY COAST EQUIPMENT(SW3) EXC. REAR WHEEL PARKING BRAKE AIR CONTROL(B3A), BRAKE SYSTEM HEAVY DUTY VAR2(WG3) M12X50	9-91066-250-0	02	1	9212-
74	NUT; TIE ROD END FRONT AXLE F049<FS4> M12	9-99110-512-0	04	1	9212-
74	NUT; TIE ROD END IVORY COAST EQUIPMENT(SW3) EXC. REAR WHEEL PARKING BRAKE AIR CONTROL(B3A), BRAKE SYSTEM HEAVY DUTY VAR2(WG3) M12	9-99110-512-0	02	1	9212-
80	PIN; SPLIT,ROD END FRONT AXLE F049<FS4> OD=4.6 L=35	9-08115-035-0	02	1	9212-
80	PIN; SPLIT,ROD END EXC. FRONT AXLE F049<FS4> OD=3.7 L=22	9-08114-022-0	02	1	9212-
81	ROD; TIE FRONT AXLE F049<FS4>	1-43151-077-0	01	1	9212-
81	ROD; TIE BRAKE SYSTEM HEAVY DUTY VAR2(WG3) EXC. HEAVY DUTY PACKAGE TRUCK<RD2>	1-43151-109-0	01	1	9212-
81	ROD; TIE EXC. IVORY COAST EQUIPMENT(SW3),BRAKE SYSTEM HEAVY DUTY VAR2(WG3)	1-43151-109-0	01	1	9212-
81	ROD; TIE IVORY COAST EQUIPMENT(SW3) EXC. REAR WHEEL PARKING BRAKE AIR CONTROL(B3A), BRAKE SYSTEM HEAVY DUTY VAR2(WG3)	1-43151-116-0	01	1	9212-
255	PIN; SPLIT,JOINT BALL FRONT AXLE F049<FS4> OD=4.6 L=35	9-08115-035-0	01	1	9504-
304	WASHER; PL FRONT AXLE F049<FS4> ID=12.5	9-09164-512-0	04	1	9411-
304	WASHER; PL EXC. FRONT AXLE F049<FS4> ID=12.5	9-09164-512-0	02	1	9411-
305	COVER; KNUCKLE FRONT AXLE F049<FS4>	1-43175-021-0	02	1	9501-
305	COVER; KNUCKLE EXC. FRONT AXLE F049<FS4>	1-43175-022-0	02	1	9311-

İpucu: çizimdeki balona veya tablodaki Balon sütununa tıkla; ilgili parçalar vurgulanır. Birden çok çizim varsa üstteki seçim kutusu/oklarla gezin.
