Isuzu WW
▶
TRUCKS
▶
CHR
▶
10648 - CHR/CJR/CQR
▶
6 - Exterior Body, Glass Mounting, Door Trim, Molding
▶
6-01 - FRONT BUMPER
▶
6-01 — FRONT BUMPER
(#2127) — 34 parça
Tümü
A - LVR5FB
B - LVR6FB
71
72
133
132
94
93
96
84
301
97
330
331
98
329
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
A
B
71
BOLT; BRKT TO FRAME
M8X40 W/LK WASHER
9-01900-840-0
02
1
9001-9204
●
●
71
BOLT; BRKT TO FRAME
M8X40 W/LK WASHER
0-50040-840-0
02
1
9205-9407
●
●
71
BOLT; BRKT TO FRAME
M8X40 W/LK WASHER
0-50040-840-0
02
1
9408-9606
●
71
BOLT; BRKT TO FRAME
EXC. HEAD LAMP RECTANGULAR ANGLE<TR4> M8X40 W/LK WASHER
0-50040-840-0
02
1
9408-9606
●
71
BOLT; BRKT TO FRAME
M8X45 FLANGE
0-28080-845-0
02
1
9607-
●
71
BOLT; BRKT TO FRAME
EXC. HEAD LAMP RECTANGULAR ANGLE<TR4> M8X45 FLANGE
0-28080-845-0
02
1
9607-
●
72
NUT; BRKT
M8
9-09110-408-0
02
1
9001-9407
●
●
72
NUT; BRKT
M8
9-09110-408-0
02
1
9408-9606
●
72
NUT; BRKT
EXC. HEAD LAMP RECTANGULAR ANGLE<TR4> M8
9-09110-408-0
02
1
9408-9606
●
72
NUT; BRKT
M8 FLANGE
0-91150-108-0
02
1
9607-
●
72
NUT; BRKT
EXC. HEAD LAMP RECTANGULAR ANGLE<TR4> M8 FLANGE
0-91150-108-0
02
1
9607-
●
84
HOOK
1-57181-027-1
01
1
9001-
●
●
93
WASHER; LK,HOOK
ID=16.2
9-09150-516-0
02
1
9001-
●
●
94
NUT; HOOK
M16
9-99110-416-0
02
1
9001-
●
●
96
PLATE; DIST,HOOK
1-57189-137-0
01
1
9001-
●
●
97
SPRING; FRT HOOK
9-53519-003-0
01
1
9001-
●
●
98
STOPPER; SPR,FRT HOOK
9-53519-006-0
01
1
9001-
●
●
132
PROTECTOR; FLEX HOSE
1-14181-174-0
01
1
9001-
●
●
133
BOLT; PROTECTOR FIX
M8X30 W/LK WASHER
9-01900-830-0
02
1
9001-9204
●
●
133
BOLT; PROTECTOR FIX
M8X30 W/LK WASHER
0-50040-830-0
02
1
9205-9606
●
●
133
BOLT; PROTECTOR FIX
M8X30 FLANGE
0-28680-830-0
02
1
9607-
●
●
301
BOLT; HOOK TO FRAME
M16X55
9-91051-655-0
01
1
9001-9001
●
●
301
BOLT; HOOK TO FRAME
M16X55
9-92051-655-0
01
1
9002-9008
●
●
301
BOLT; HOOK TO FRAME
M16X55
0-20801-655-0
01
1
9009-9606
●
●
301
BOLT; HOOK TO FRAME
M16X60
0-20801-660-0
01
1
9607-
●
●
301
BOLT; HOOK TO FRAME
M16X70
9-91051-670-0
01
1
9001-9005
●
●
301
BOLT; HOOK TO FRAME
M16X70
0-10811-670-0
01
1
9006-
●
●
329
BOLT; STOPPER,FRT
M16X75
9-91051-675-0
01
1
9001-9005
●
●
329
BOLT; STOPPER,FRT
M16X75
0-10811-675-0
01
1
9006-
●
●
329
BOLT; STOPPER,FRT
M16X85
9-91051-685-0
01
1
9001-9005
●
●
329
BOLT; STOPPER,FRT
M16X85
0-10811-685-0
01
1
9006-9606
●
●
329
BOLT; STOPPER,FRT
M16X90
0-10811-690-0
01
1
9607-
●
●
330
NUT; STOPPER,FRT
M16
9-99110-416-0
02
1
9001-
●
●
331
WASHER; LK,STOPPER FRT
ID=16.2
9-09150-516-0
02
1
9001-
●
●
