37 |
CLIP; FUEL HOSE
ID=12
|
8-94238-610-0 |
02 |
1 |
0504-0609 |
● |
|
| |
37 |
CLIP; FUEL HOSE
ID=12
|
8-94238-610-0 |
02 |
1 |
0610- |
|
● |
| |
87 |
BOLT; STAY,FUEL PIPE
M8X12 FLANGE
|
0-28080-812-0 |
01 |
1 |
0504-0512 |
● |
|
| |
87 |
BOLT; STAY,FUEL PIPE
M8X12 FLANGE
|
0-28050-812-0 |
01 |
1 |
0601-0609 |
● |
|
| |
87 |
BOLT; STAY,FUEL PIPE
M8X12 FLANGE
|
0-28050-812-0 |
01 |
1 |
0610- |
|
● |
| |
92 |
BRACKET; FUEL PIPE
(A)
|
8-97166-995-1 |
01 |
1 |
0504-0609 |
● |
|
| |
92 |
BRACKET; FUEL PIPE
(A)
|
8-97166-995-1 |
01 |
1 |
0610- |
|
● |
| |
92 |
BRACKET; FUEL PIPE
(B)
|
8-97173-465-2 |
01 |
1 |
0504-0609 |
● |
|
| |
92 |
BRACKET; FUEL PIPE
(B)
|
8-97173-465-2 |
01 |
1 |
0610- |
|
● |
| |
100 |
CLIP; "B",FUEL PIPE
|
8-97108-315-0 |
01 |
1 |
0504-0609 |
● |
|
| |
100 |
CLIP; "B",FUEL PIPE
|
8-97108-315-0 |
01 |
1 |
0610- |
|
● |
| |
107 |
PIPE; FUEL,FEED PUMP TO FUEL FILTER
|
8-97148-967-3 |
01 |
1 |
0504-0609 |
● |
|
| |
107 |
PIPE; FUEL,FEED PUMP TO FUEL FILTER
|
8-97148-967-3 |
01 |
1 |
0610- |
|
● |
| |
108 |
BOLT; JOINT,FUEL FILTER
M14X27 FLANGE
|
1-09675-086-0 |
02 |
1 |
0504-0609 |
● |
|
| |
108 |
BOLT; JOINT,FUEL FILTER
M14X27 FLANGE
|
1-09675-086-0 |
02 |
1 |
0610- |
|
● |
| |
115 |
GASKET; JOINT BOLT,FUEL PIPE
ALSO INCLUDED IN GASKET SET(ENG. & HEAD)
ID=14.2 OD=23.0
|
9-09572-014-0 |
04 |
1 |
0504-0609 |
● |
|
| |
115 |
GASKET; JOINT BOLT,FUEL PIPE
ALSO INCLUDED IN GASKET SET(ENG. & HEAD)
ID=14.2 OD=23.0
|
9-09572-014-0 |
04 |
1 |
0610- |
|
● |
| |
119 |
PIPE; FUEL,FUEL FILTER TO INJ PUMP
|
8-97357-237-0 |
01 |
1 |
0504-0609 |
● |
|
| |
119 |
PIPE; FUEL,FUEL FILTER TO INJ PUMP
|
8-97357-237-0 |
01 |
1 |
0610- |
|
● |
| |
123 |
PIPE; FUEL,FUEL FILTER LEAK OFF
|
8-97148-970-2 |
01 |
1 |
0504-0609 |
● |
|
| |
123 |
PIPE; FUEL,FUEL FILTER LEAK OFF
|
8-97148-970-2 |
01 |
1 |
0610- |
|
● |
| |
145 |
CLIP; FUEL PIPE
ID=6.1 & 9.6
|
8-97016-323-0 |
02 |
1 |
0504-0609 |
● |
|
| |
145 |
CLIP; FUEL PIPE
ID=6.1 & 9.6
|
8-97016-323-1 |
02 |
1 |
0610- |
|
● |
| |
148 |
BOLT; BRKT
(A)
M8X16 FLANGE
|
0-28090-816-0 |
02 |
1 |
0504-0512 |
● |
|
| |
148 |
BOLT; BRKT
(A)
M8X16 FLANGE
|
0-28060-816-0 |
02 |
1 |
0601-0609 |
● |
|
| |
148 |
BOLT; BRKT
(A)
M8X16 FLANGE
|
0-28060-816-0 |
02 |
1 |
0610- |
|
● |
| |
148 |
BOLT; BRKT
(B)
M6X25 FLANGE
|
0-28680-625-0 |
02 |
1 |
0504-0512 |
● |
|
| |
148 |
BOLT; BRKT
(B)
M6X25 FLANGE
|
0-28650-625-0 |
02 |
1 |
0601-0609 |
● |
|
| |
148 |
BOLT; BRKT
(B)
M6X25 FLANGE
|
0-28650-625-0 |
02 |
1 |
0610- |
|
● |
| |
150 |
GASKET; FUEL PIPE
ALSO INCLUDED IN GASKET SET(ENG. & HEAD)
ID=14.2 OD=23.0
|
9-09572-014-0 |
02 |
1 |
0504-0609 |
● |
|
| |
150 |
GASKET; FUEL PIPE
ALSO INCLUDED IN GASKET SET(ENG. & HEAD)
ID=14.2 OD=23.0
|
9-09572-014-0 |
02 |
1 |
0610- |
|
● |
| |
159 |
BOLT; CLIP
M6X12 FLANGE
|
0-28080-612-0 |
01 |
1 |
0504-0512 |
● |
|
| |
159 |
BOLT; CLIP
M6X12 FLANGE
|
0-28050-612-0 |
01 |
1 |
0601-0609 |
● |
|
| |
159 |
BOLT; CLIP
M6X12 FLANGE
|
0-28050-612-0 |
01 |
1 |
0610- |
|
● |
| |
220 |
HOSE; FUEL
L=180
SERVICED BY L=3000
|
0-01256-300-0 |
01 |
1 |
0504-0609 |
● |
|
| |
220 |
HOSE; FUEL
L=180
SERVICED BY L=3000
|
0-01256-300-0 |
01 |
1 |
0610- |
|
● |
| |
221 |
BOLT; FUEL PIPE
M6X40 FLANGE
|
0-28680-640-0 |
01 |
1 |
0504-0512 |
● |
|
| |
221 |
BOLT; FUEL PIPE
M6X40 FLANGE
|
0-28650-640-0 |
01 |
1 |
0601-0609 |
● |
|
| |
221 |
BOLT; FUEL PIPE
M6X40 FLANGE
|
0-28650-640-0 |
01 |
1 |
0610- |
|
● |
