◀ 🏠 ▶ Isuzu WW ▶ TRUCKS ▶ FVZ ▶ 11393 - FVZ(INDONESIA) ▶ 6 - Exterior Body, Glass Mounting, Door Trim, Molding ▶ 6-70 - FLOOR PANEL ▶
6-70 — FLOOR PANEL (#20168) — 62 parça
çizim 108418
542 24 542 540 539 538 22 144 170 462 220 548 57 373 548 544 373 546 23 376 448 380 311 18 375 15 380 563 15 537 537 563 220 554 545 220 3 549 174 144 549 546 545 15 539 448 18 376 375 380 311 23 536 544 373 547 15 563 563 57 4 550 380 541 81 276 398 541
BalonParca AdiParca NoAdetTipApplied Date
3 HOOD ASM; ENG
FULLER ES11109 DD M/T(Y5N) 		8-98053-677-9 01 1 1310-
3 HOOD ASM; ENG
ZF9S1110 DD M/T(Y5P) 		8-98167-036-0 01 1 1104-
4 FRAME; FLOOR,FRT 8-98073-693-1 01 1 1104-
15 FRAME; UNDER
(A) 		8-97584-387-9 01 1 1104-
15 FRAME; UNDER
(B) 		8-97584-388-9 01 1 1104-
15 FRAME; UNDER
(A) 		8-97584-411-9 01 1 1104-
15 FRAME; UNDER
(B) 		8-97584-412-7 01 1 1104-
18 FRAME; FLOOR,CENTER SIDE 8-97584-398-4 01 1 1104-
18 FRAME; FLOOR,CENTER SIDE 8-97584-421-4 01 1 1104-
22 FRAME; FLOOR REAR 8-97584-431-5 01 1 1104-
23 PANEL; FLOOR,SIDE 8-97584-372-7 01 1 1104-
23 PANEL; FLOOR,SIDE 8-98073-691-1 01 1 1104-
24 PANEL; BED PAN 8-97584-378-6 01 1 1104-
57 BRACKET; SPARE TIRE 8-98038-970-1 02 1 1104-
81 BRACKET; HARNESS SUPPORT 8-98041-333-3 01 1 1104-
144 BRACKET; MTG,RR 8-97584-432-6 01 1 1104-
144 BRACKET; MTG,RR 8-97589-666-6 01 1 1104-
170 EXTENSION; RR FLOOR 8-97589-207-4 01 1 1104-
174 GROMMET; AIR PIPE
OD=35 IDN 		8-94122-971-0 01 1 1104-
220 PATCH
(A) 		8-97588-840-4 01 1 1104-
220 PATCH
(B) 		8-97589-603-3 01 1 1104-
220 PATCH
(C) 		8-97589-627-2 01 1 1104-
276 BRACKET; RAD GRILLE 8-97589-596-3 01 1 1104-
311 BOLT; BRKT
M6X16 FLANGE 		0-28650-616-0 04 1 1104-
373 REINFORCEMENT; SEAT BELT
(B) 		8-97584-345-9 01 1 1104-
373 REINFORCEMENT; SEAT BELT
(A) 		8-97584-367-2 01 1 1104-
373 REINFORCEMENT; SEAT BELT
(A) 		8-97584-375-2 01 1 1104-
375 CLOSING; PILLAR 8-98044-897-3 01 1 1104-
375 CLOSING; PILLAR 8-98044-898-3 01 1 1104-
376 CLOSING; PILLAR,LWR 8-97589-554-4 01 1 1104-1403
376 CLOSING; PILLAR,LWR 8-98199-228-0 01 1 1404-
376 CLOSING; PILLAR,LWR 8-97589-556-5 01 1 1104-
380 BRACKET; HEAD LAMP
(A) 		8-97584-460-2 01 1 1104-
380 BRACKET; HEAD LAMP
(A) 		8-97589-506-2 01 1 1104-
380 BRACKET; HEAD LAMP
(B) 		8-98032-615-1 01 1 1104-
380 BRACKET; HEAD LAMP
(B) 		8-98032-614-1 01 1 1104-
398 BRACKET; PIPE SUPPORT 8-97589-681-3 01 1 1104-
448 CLOSING; ROCKER 8-97589-551-2 01 1 1104-
448 CLOSING; ROCKER 8-97589-552-2 01 1 1104-
462 BRACKET; EXTINGUISHER 8-97585-688-1 01 1 1104-
536 PLUG; CABLE,PTO 8-97612-074-1 01 1 1104-
537 SUPPORT ASM; MTG RR 8-97584-391-4 01 1 1104-
537 SUPPORT ASM; MTG RR 8-97584-417-4 01 1 1104-
538 REINFORCEMENT ASM; AIR INT DUCT 8-97610-207-2 01 1 1104-
539 PATCH ASM; SAFTY HOOK
(A) 		8-97584-440-2 01 1 1104-
539 PATCH ASM; SAFTY HOOK
(B) IDN 		8-98131-661-0 01 1 1104-
540 BRACKET ASM; CAB LOCK LEVER 8-97584-438-1 01 1 1104-
541 REINFORCEMENT; MTG,FRT 8-98067-903-0 02 1 1104-
542 BOLSTER; BED PAN 8-97589-685-1 02 1 1104-
544 BRACKET; DUMP CONT 8-97584-363-1 01 1 1104-
544 BRACKET; DUMP CONT 8-98049-529-0 01 1 1104-
545 BRACKET; SEAT FRT 8-97584-361-1 01 1 1104-
545 BRACKET; SEAT FRT 8-97584-373-1 01 1 1104-
546 REINFORCEMENT; FLOOR SIDE 8-97584-427-0 02 1 1104-
547 BRACKET; JACK HANDLE 8-97588-843-1 01 1 1104-
548 BRACKET; MUD GUARD 8-97588-961-1 01 1 1104-
548 BRACKET; MUD GUARD 8-97588-962-1 01 1 1104-
549 BRACKET; SEAT RR 8-97588-958-4 01 1 1104-
549 BRACKET; SEAT RR 8-97589-557-4 01 1 1104-
550 CLOSING ASM; MTG,FRT 8-97584-615-4 01 1 1104-
554 REINFORCEMENT; FLOOR CENTER 8-97584-351-2 01 1 1104-
563 REINFORCEMENT; MTG FRT,RR 8-97589-579-2 04 1 1104-
