1 |
DRUM; BRK,RR
4JB1 ENG<RLF>
FINAL GEAR RATIO 39/7<GV1>,FINAL GEAR RATIO
41/7<R41>,FINAL GEAR RATIO 43/7<R42>
THA
|
8-97940-560-0 |
04 |
1 |
0309- |
● |
|
|
| |
1 |
DRUM; BRK,RR
4HG1 ENG<RJH>
FINAL GEAR RATIO 41/8<RU1>,FINAL GEAR RATIO
43/8<R40>
THA
|
8-97940-561-0 |
04 |
1 |
0309- |
|
● |
|
| |
1 |
DRUM; BRK,RR
FINAL GEAR RATIO 39/7<GV1>,FINAL GEAR RATIO
41/7<R41>
THA
|
8-97940-559-0 |
02 |
1 |
0309- |
|
|
● |
| |
8 |
HUB; RR AXLE
FINAL GEAR RATIO 39/7<GV1>,FINAL GEAR RATIO
41/7<R41>
THA
|
8-97940-278-0 |
04 |
1 |
0309- |
|
|
● |
| |
8 |
HUB; RR AXLE
4JB1 ENG<RLF>
FINAL GEAR RATIO 39/7<GV1>,FINAL GEAR RATIO
41/7<R41>,FINAL GEAR RATIO 43/7<R42>
THA
|
8-97940-277-0 |
04 |
1 |
0309- |
● |
|
|
| |
8 |
HUB; RR AXLE
4HG1 ENG<RJH>
FINAL GEAR RATIO 41/8<RU1>,FINAL GEAR RATIO
43/8<R40>
THA
|
8-97940-279-0 |
04 |
1 |
0309- |
|
● |
|
| |
9 |
PIN; WHEEL,RR AXLE
FINAL GEAR RATIO 39/7<GV1>,FINAL GEAR RATIO
41/7<R41>
M14X50 RH THREAD
|
9-42331-605-4 |
12 |
1 |
0309- |
|
|
● |
| |
9 |
PIN; WHEEL,RR AXLE
FINAL GEAR RATIO 39/7<GV1>,FINAL GEAR RATIO
41/7<R41>
M14X50 LH THREAD
|
9-42332-605-4 |
12 |
1 |
0309- |
|
|
● |
| |
9 |
PIN; WHEEL,RR AXLE
4JB1 ENG<RLF>
FINAL GEAR RATIO 39/7<GV1>,FINAL GEAR RATIO
41/7<R41>,FINAL GEAR RATIO 43/7<R42>
M18X29,M20X43.5 RH THREAD
|
8-94383-436-1 |
10 |
1 |
0309- |
● |
|
|
| |
9 |
PIN; WHEEL,RR AXLE
4HG1 ENG<RJH>
FINAL GEAR RATIO 41/8<RU1>,FINAL GEAR RATIO
43/8<R40>
M18X29,M20X43.5 RH THREAD
|
8-94383-436-1 |
10 |
1 |
0309- |
|
● |
|
| |
9 |
PIN; WHEEL,RR AXLE
4JB1 ENG<RLF>
FINAL GEAR RATIO 39/7<GV1>,FINAL GEAR RATIO
41/7<R41>,FINAL GEAR RATIO 43/7<R42>
M18X29 LH THREAD,M20X43.5 RH THREAD
|
8-94383-437-1 |
10 |
1 |
0309- |
● |
|
|
| |
9 |
PIN; WHEEL,RR AXLE
4HG1 ENG<RJH>
FINAL GEAR RATIO 41/8<RU1>,FINAL GEAR RATIO
43/8<R40>
M18X29 LH THREAD,M20X43.5 RH THREAD
|
8-94383-437-1 |
10 |
1 |
0309- |
|
● |
|
| |
10 |
NUT; WHEEL PIN,RR AXLE
4JB1 ENG<RLF>
FINAL GEAR RATIO 39/7<GV1>,FINAL GEAR RATIO
41/7<R41>,FINAL GEAR RATIO 43/7<R42>
M20
|
9-99110-520-0 |
20 |
1 |
0309- |
● |
|
|
| |
10 |
NUT; WHEEL PIN,RR AXLE
4HG1 ENG<RJH>
FINAL GEAR RATIO 41/8<RU1>,FINAL GEAR RATIO
43/8<R40>
M20
|
9-99110-520-0 |
20 |
1 |
0309- |
|
● |
|
| |
15 |
BEARING; HUB OUTER,RR AXLE
FINAL GEAR RATIO 39/7<GV1>,FINAL GEAR RATIO
41/7<R41>
NSK
THA
|
9-00093-082-0 |
02 |
1 |
0309- |
|
|
● |
| |
15 |
BEARING; HUB OUTER,RR AXLE
4JB1 ENG<RLF>
FINAL GEAR RATIO 39/7<GV1>,FINAL GEAR RATIO
41/7<R41>,FINAL GEAR RATIO 43/7<R42>
NSK
THA
|
9-00093-082-0 |
02 |
1 |
0309- |
● |
|
|
| |
15 |
BEARING; HUB OUTER,RR AXLE
4HG1 ENG<RJH>
FINAL GEAR RATIO 41/8<RU1>,FINAL GEAR RATIO
43/8<R40>
NSK
THA
|
9-00093-607-0 |
02 |
1 |
0309- |
|
● |
|
| |
16 |
SEAL; OIL,RR HUB,OUTER
FINAL GEAR RATIO 39/7<GV1>
TKK
|
8-94336-315-2 |
02 |
1 |
0309- |
|
|
● |
| |
16 |
SEAL; OIL,RR HUB,OUTER
4JB1 ENG<RLF>
FINAL GEAR RATIO 41/7<R41>
TKK
|
8-94336-315-2 |
02 |
1 |
0309- |
● |
|
|
| |
16 |
SEAL; OIL,RR HUB,OUTER
FINAL GEAR RATIO 39/7<GV1>
NOK
|
8-94367-961-1 |
02 |
1 |
0309- |
|
|
● |
| |
16 |
SEAL; OIL,RR HUB,OUTER
4JB1 ENG<RLF>
FINAL GEAR RATIO 41/7<R41>
NOK
|
8-94367-961-1 |
02 |
1 |
0309- |
● |
|
|
| |
16 |
SEAL; OIL,RR HUB,OUTER
4HG1 ENG<RJH>
FINAL GEAR RATIO 41/8<RU1>
TKK
|
8-94336-317-2 |
02 |
1 |
0309- |
|
● |
|
| |
16 |
SEAL; OIL,RR HUB,OUTER
4HG1 ENG<RJH>
FINAL GEAR RATIO 41/8<RU1>
NOK
|
8-94367-960-1 |
02 |
1 |
0309- |
|
● |
|
| |
20 |
NUT; BRG,RR HUB
FINAL GEAR RATIO 39/7<GV1>
M52
|
8-97137-092-0 |
02 |
1 |
0309- |
|
|
● |
| |
20 |
NUT; BRG,RR HUB
4JB1 ENG<RLF>
FINAL GEAR RATIO 41/7<R41>
M52
|
8-97137-092-0 |
02 |
1 |
0309- |
● |
|
|
| |
20 |
NUT; BRG,RR HUB
4HG1 ENG<RJH>
FINAL GEAR RATIO 41/8<RU1>
M55
|
8-97137-094-0 |
02 |
1 |
0309- |
|
● |
|
| |
21 |
WASHER; LK,BRG NUT
FINAL GEAR RATIO 39/7<GV1>
ID=52
|
9-09853-214-0 |
02 |
1 |
0309- |
|
|
● |
| |
21 |
WASHER; LK,BRG NUT
4JB1 ENG<RLF>
FINAL GEAR RATIO 41/7<R41>
ID=52
|
9-09853-214-0 |
02 |
1 |
0309- |
● |
|
|
| |
21 |
WASHER; LK,BRG NUT
4HG1 ENG<RJH>
FINAL GEAR RATIO 41/8<RU1>
ID=55
|
9-09653-002-0 |
02 |
1 |
0309- |
|
● |
|
| |
24 |
BOLT; LK WASHER
FINAL GEAR RATIO 39/7<GV1>
M6X12 W/LK WASHER
|
0-50040-612-0 |
04 |
1 |
0309- |
|
|
● |
| |
24 |
BOLT; LK WASHER
4JB1 ENG<RLF>
FINAL GEAR RATIO 41/7<R41>
M6X12 W/LK WASHER
|
0-50040-612-0 |
04 |
1 |
0309- |
● |
|
|
| |
24 |
BOLT; LK WASHER
4HG1 ENG<RJH>
FINAL GEAR RATIO 41/8<RU1>
M6X12 W/LK WASHER
|
0-50040-612-0 |
04 |
1 |
0309- |
|
● |
|
| |
25 |
SHAFT; AXLE,RR
FINAL GEAR RATIO 39/7<GV1>,FINAL GEAR RATIO
41/7<R41>
THA
|
8-94366-192-0 |
02 |
1 |
0309- |
|
|
● |
| |
25 |
SHAFT; AXLE,RR
4JB1 ENG<RLF>
FINAL GEAR RATIO 39/7<GV1>,FINAL GEAR RATIO
41/7<R41>,FINAL GEAR RATIO 43/7<R42>
THA
|
8-97032-496-0 |
02 |
1 |
0309- |
● |
|
|
| |
25 |
SHAFT; AXLE,RR
4HG1 ENG<RJH>
FINAL GEAR RATIO 41/8<RU1>,FINAL GEAR RATIO
43/8<R40>
L=780
|
8-94366-190-1 |
02 |
1 |
0309- |
|
● |
|
| |
31 |
STUD; AXLE SHAFT TO HUB
FINAL GEAR RATIO 39/7<GV1>,FINAL GEAR RATIO
41/7<R41>
M10X30 L=49
|
5-09300-066-1 |
12 |
1 |
0309- |
|
|
● |
| |
31 |
STUD; AXLE SHAFT TO HUB
4JB1 ENG<RLF>
FINAL GEAR RATIO 39/7<GV1>,FINAL GEAR RATIO
41/7<R41>,FINAL GEAR RATIO 43/7<R42>
M10X30 L=49
|
5-09300-066-1 |
16 |
1 |
0309- |
● |
|
|
| |
31 |
STUD; AXLE SHAFT TO HUB
4HG1 ENG<RJH>
FINAL GEAR RATIO 41/8<RU1>,FINAL GEAR RATIO
43/8<R40>
M10X30 L=49
|
5-09300-066-1 |
16 |
1 |
0309- |
|
● |
|
| |
34 |
NUT; AXLE SHAFT
FINAL GEAR RATIO 39/7<GV1>,FINAL GEAR RATIO
41/7<R41>
M10 FLANGE
|
0-91150-210-0 |
12 |
1 |
0309- |
|
|
● |
| |
34 |
NUT; AXLE SHAFT
4JB1 ENG<RLF>
FINAL GEAR RATIO 39/7<GV1>,FINAL GEAR RATIO
41/7<R41>,FINAL GEAR RATIO 43/7<R42>
M10 FLANGE
|
0-91150-210-0 |
16 |
1 |
0309- |
● |
|
|
| |
34 |
NUT; AXLE SHAFT
4HG1 ENG<RJH>
FINAL GEAR RATIO 41/8<RU1>,FINAL GEAR RATIO
43/8<R40>
M10 FLANGE
|
0-91150-210-0 |
16 |
1 |
0309- |
|
● |
|
| |
36 |
WASHER; SPECIAL,AXLE SHAFT
FINAL GEAR RATIO 39/7<GV1>,FINAL GEAR RATIO
41/7<R41>
ID=10.5
|
9-09855-207-0 |
12 |
1 |
0309- |
|
|
● |
| |
36 |
WASHER; SPECIAL,AXLE SHAFT
4JB1 ENG<RLF>
FINAL GEAR RATIO 39/7<GV1>,FINAL GEAR RATIO
41/7<R41>,FINAL GEAR RATIO 43/7<R42>
ID=10.5
|
9-09855-207-0 |
16 |
1 |
0309- |
● |
|
|
| |
36 |
WASHER; SPECIAL,AXLE SHAFT
4HG1 ENG<RJH>
FINAL GEAR RATIO 41/8<RU1>,FINAL GEAR RATIO
43/8<R40>
ID=10.5
|
9-09855-207-0 |
16 |
1 |
0309- |
|
● |
|
| |
37 |
BEARING; HUB INNER,RR AXLE
FINAL GEAR RATIO 39/7<GV1>,FINAL GEAR RATIO
41/7<R41>
NSK
THA
|
9-00093-081-0 |
02 |
1 |
0309- |
|
|
● |
| |
37 |
BEARING; HUB INNER,RR AXLE
4JB1 ENG<RLF>
FINAL GEAR RATIO 39/7<GV1>,FINAL GEAR RATIO
41/7<R41>,FINAL GEAR RATIO 43/7<R42>
NSK
THA
|
9-00093-081-0 |
02 |
1 |
0309- |
● |
|
|
| |
37 |
BEARING; HUB INNER,RR AXLE
4HG1 ENG<RJH>
FINAL GEAR RATIO 41/8<RU1>,FINAL GEAR RATIO
43/8<R40>
NSK
THA
|
9-00093-624-0 |
02 |
1 |
0309- |
|
● |
|
| |
38 |
SEAL; OIL,RR HUB,INNER
FINAL GEAR RATIO 39/7<GV1>
TKK
|
8-94336-314-1 |
02 |
1 |
0309- |
|
|
● |
| |
38 |
SEAL; OIL,RR HUB,INNER
4JB1 ENG<RLF>
FINAL GEAR RATIO 41/7<R41>
TKK
|
8-94336-314-1 |
02 |
1 |
0309- |
● |
|
|
| |
38 |
SEAL; OIL,RR HUB,INNER
FINAL GEAR RATIO 39/7<GV1>
NOK
|
8-94367-959-0 |
02 |
1 |
0309- |
|
|
● |
| |
38 |
SEAL; OIL,RR HUB,INNER
4JB1 ENG<RLF>
FINAL GEAR RATIO 41/7<R41>
NOK
|
8-94367-959-0 |
02 |
1 |
0309- |
● |
|
|
| |
38 |
SEAL; OIL,RR HUB,INNER
4HG1 ENG<RJH>
FINAL GEAR RATIO 41/8<RU1>
TKK
|
8-94336-316-1 |
02 |
1 |
0309- |
|
● |
|
| |
38 |
SEAL; OIL,RR HUB,INNER
4HG1 ENG<RJH>
FINAL GEAR RATIO 41/8<RU1>
NOK
|
8-94367-958-0 |
02 |
1 |
0309- |
|
● |
|
| |
49 |
CASE; RR AXLE
FINAL GEAR RATIO 39/7<GV1>
|
8-97032-768-3 |
01 |
1 |
0309- |
|
|
● |
| |
49 |
CASE; RR AXLE
4JB1 ENG<RLF>
FINAL GEAR RATIO 41/7<R41>
|
8-97032-861-4 |
01 |
1 |
0309- |
● |
|
|
| |
49 |
CASE; RR AXLE
4HG1 ENG<RJH>
FINAL GEAR RATIO 41/8<RU1>
|
8-97070-484-5 |
01 |
1 |
0309- |
|
● |
|
| |
58 |
PLUG; DRAIN,AXLE CASE
FINAL GEAR RATIO 39/7<GV1>
M16X12.5
|
8-97109-869-0 |
01 |
1 |
0309- |
|
|
● |
| |
58 |
PLUG; DRAIN,AXLE CASE
4JB1 ENG<RLF>
FINAL GEAR RATIO 41/7<R41>
M16X12.5
|
8-97109-869-0 |
01 |
1 |
0309- |
● |
|
|
| |
58 |
PLUG; DRAIN,AXLE CASE
4HG1 ENG<RJH>
FINAL GEAR RATIO 41/8<RU1>
M16X12.5
|
8-97109-869-0 |
01 |
1 |
0309- |
|
● |
|
| |
59 |
GASKET; DRAIN PLUG
FINAL GEAR RATIO 39/7<GV1>
ID=16.2 OD=24
|
9-09571-416-0 |
01 |
1 |
0309- |
|
|
● |
| |
59 |
GASKET; DRAIN PLUG
4JB1 ENG<RLF>
FINAL GEAR RATIO 41/7<R41>
ID=16.2 OD=24
|
9-09571-416-0 |
01 |
1 |
0309- |
● |
|
|
| |
59 |
GASKET; DRAIN PLUG
4HG1 ENG<RJH>
FINAL GEAR RATIO 41/8<RU1>
ID=16.2 OD=24
|
9-09571-416-0 |
01 |
1 |
0309- |
|
● |
|
| |
60 |
BREATHER; RR AXLE CASE
L=30
|
8-94416-611-1 |
01 |
1 |
0309-0409 |
● |
● |
● |
| |
60 |
BREATHER; RR AXLE CASE
L=29
|
8-97383-656-0 |
01 |
1 |
0410- |
● |
● |
● |
| |
63 |
PLUG; OIL FILLER,AXLE CASE
FINAL GEAR RATIO 39/7<GV1>
M20X10.5
|
9-09662-005-0 |
01 |
1 |
0309- |
|
|
● |
| |
63 |
PLUG; OIL FILLER,AXLE CASE
4JB1 ENG<RLF>
FINAL GEAR RATIO 41/7<R41>
M20X10.5
|
9-09662-005-0 |
01 |
1 |
0309- |
● |
|
|
| |
63 |
PLUG; OIL FILLER,AXLE CASE
4HG1 ENG<RJH>
FINAL GEAR RATIO 41/8<RU1>
M20X10.5
|
9-09662-005-0 |
01 |
1 |
0309- |
|
● |
|
| |
64 |
GASKET; OIL FILLER,AXLE CASE
FINAL GEAR RATIO 39/7<GV1>
ID=20 OD=30
THA
|
8-94462-734-0 |
01 |
1 |
0309- |
|
|
● |
| |
64 |
GASKET; OIL FILLER,AXLE CASE
4JB1 ENG<RLF>
FINAL GEAR RATIO 41/7<R41>
ID=20 OD=30
THA
|
8-94462-734-0 |
01 |
1 |
0309- |
● |
|
|
| |
64 |
GASKET; OIL FILLER,AXLE CASE
4HG1 ENG<RJH>
FINAL GEAR RATIO 41/8<RU1>
ID=20 OD=30
THA
|
8-94462-734-0 |
01 |
1 |
0309- |
|
● |
|
| |
67 |
BOLT; FINAL DRIVE SETTING
FINAL GEAR RATIO 39/7<GV1>
M10X40 W/LK WASHER
|
0-50061-040-0 |
08 |
1 |
0309- |
|
|
● |
| |
67 |
BOLT; FINAL DRIVE SETTING
4JB1 ENG<RLF>
FINAL GEAR RATIO 41/7<R41>
M10X40 W/LK WASHER
|
0-50061-040-0 |
11 |
1 |
0309- |
● |
|
|
| |
67 |
BOLT; FINAL DRIVE SETTING
4HG1 ENG<RJH>
FINAL GEAR RATIO 41/8<RU1>
M10X40 W/LK WASHER
|
0-50061-040-0 |
11 |
1 |
0309- |
|
● |
|
| |
69 |
STUD; AXLE CASE
FINAL GEAR RATIO 39/7<GV1>
M10X40.5 L=52.5
|
8-97026-282-0 |
02 |
1 |
0309- |
|
|
● |
| |
69 |
STUD; AXLE CASE
4JB1 ENG<RLF>
FINAL GEAR RATIO 41/7<R41>
M10X40.5 L=52.5
|
8-97026-282-0 |
02 |
1 |
0309- |
● |
|
|
| |
69 |
STUD; AXLE CASE
4HG1 ENG<RJH>
FINAL GEAR RATIO 41/8<RU1>
M10X40.5 L=52.5
|
8-97026-282-0 |
02 |
1 |
0309- |
|
● |
|
| |
70 |
NUT; CARRIER
FINAL GEAR RATIO 39/7<GV1>
M10 FLANGE
|
0-91150-210-0 |
02 |
1 |
0309- |
|
|
● |
| |
70 |
NUT; CARRIER
4JB1 ENG<RLF>
FINAL GEAR RATIO 41/7<R41>
M10 FLANGE
|
0-91150-210-0 |
02 |
1 |
0309- |
● |
|
|
| |
70 |
NUT; CARRIER
4HG1 ENG<RJH>
FINAL GEAR RATIO 41/8<RU1>
M10 FLANGE
|
0-91150-210-0 |
02 |
1 |
0309- |
|
● |
|
| |
74 |
BOLT; RR BRK ASM SETTING
FINAL GEAR RATIO 39/7<GV1>,FINAL GEAR RATIO
41/7<R41>
|
8-97259-178-0 |
12 |
1 |
0309- |
|
|
● |
| |
74 |
BOLT; RR BRK ASM SETTING
4JB1 ENG<RLF>
FINAL GEAR RATIO 39/7<GV1>,FINAL GEAR RATIO
41/7<R41>,FINAL GEAR RATIO 43/7<R42>
M12X32
|
5-09000-078-0 |
12 |
1 |
0309- |
● |
|
|
| |
74 |
BOLT; RR BRK ASM SETTING
4HG1 ENG<RJH>
FINAL GEAR RATIO 41/8<RU1>,FINAL GEAR RATIO
43/8<R40>
M12X32
|
5-09000-078-0 |
12 |
1 |
0309- |
|
● |
|
| |
75 |
WASHER; LK,RR BRK ASM SETTING
FINAL GEAR RATIO 39/7<GV1>,FINAL GEAR RATIO
41/7<R41>
ID=10.2
|
9-09150-610-0 |
12 |
1 |
0309- |
|
|
● |
| |
75 |
WASHER; LK,RR BRK ASM SETTING
4JB1 ENG<RLF>
FINAL GEAR RATIO 39/7<GV1>,FINAL GEAR RATIO
41/7<R41>,FINAL GEAR RATIO 43/7<R42>
ID=12.2
|
9-09150-612-0 |
12 |
1 |
0309- |
● |
|
|
| |
75 |
WASHER; LK,RR BRK ASM SETTING
4HG1 ENG<RJH>
FINAL GEAR RATIO 41/8<RU1>,FINAL GEAR RATIO
43/8<R40>
ID=12.2
|
9-09150-612-0 |
12 |
1 |
0309- |
|
● |
|
| |
76 |
NUT; RR BRK ASM SETTING
FINAL GEAR RATIO 39/7<GV1>,FINAL GEAR RATIO
41/7<R41>
M10
|
9-09110-510-0 |
12 |
1 |
0309- |
|
|
● |
| |
76 |
NUT; RR BRK ASM SETTING
4JB1 ENG<RLF>
FINAL GEAR RATIO 39/7<GV1>,FINAL GEAR RATIO
41/7<R41>,FINAL GEAR RATIO 43/7<R42>
M12
|
9-99110-512-0 |
12 |
1 |
0309-0512 |
● |
|
|
| |
76 |
NUT; RR BRK ASM SETTING
4HG1 ENG<RJH>
FINAL GEAR RATIO 41/8<RU1>,FINAL GEAR RATIO
43/8<R40>
M12
|
9-99110-512-0 |
12 |
1 |
0309-0512 |
|
● |
|
| |
76 |
NUT; RR BRK ASM SETTING
4JB1 ENG<RLF>
FINAL GEAR RATIO 39/7<GV1>,FINAL GEAR RATIO
41/7<R41>,FINAL GEAR RATIO 43/7<R42>
M12
|
0-91110-512-0 |
12 |
1 |
0601- |
● |
|
|
| |
76 |
NUT; RR BRK ASM SETTING
4HG1 ENG<RJH>
FINAL GEAR RATIO 41/8<RU1>,FINAL GEAR RATIO
43/8<R40>
M12
|
0-91110-512-0 |
12 |
1 |
0601- |
|
● |
|
