Sayfa 0-45 - Isuzu EPC

122 124 123

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date	A	B
122	03.164 HOSE; EVAPO,TANK TO 2 WAY VLV 4X2 SINGLE CAB LONG(TFB5SF) 4X4 SPACE CAB(TFS5CF) 4X4 SINGLE CAB LONG(TFS5SF) 03.163 L=60 SERVICED BY L=3000	8-94128-826-0	01	1	0212-	●	●
122	03.164 HOSE; EVAPO,TANK TO 2 WAY VLV CREW CAB(TF*W) 03.163 L=150 SERVICED BY L=3000	8-94128-826-0	01	1	0212-	●	●
123	03.164 HOSE; EVAPO,2 WAY VLV TO FRAME 4X2 SINGLE CAB LONG(TFB5SF) 4X4 SPACE CAB(TFS5CF) 4X4 SINGLE CAB LONG(TFS5SF) 03.163 L=400 SERVICED BY L=3000	8-94128-826-0	01	1	0212-	●	●
123	03.164 HOSE; EVAPO,2 WAY VLV TO FRAME CREW CAB(TF*W) 03.163 L=360 SERVICED BY L=3000	8-94128-826-0	01	1	0212-	●	●
124	03.164 VALVE; 2 WAY,EVAP 03.162	8-97178-373-0	01	1	0212-	●	●

45 45 62 62 62 55 55 62 62 55 62

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date	A	B
45	03.417 CLIP; HOSE,PURGE SIGNAL 03.163 ID=11	8-97173-219-0	02	1	0108-0211	●	●
55	03.120 HOSE; EVAP,CONT VLV TO PIPE SPACE CAB(TF*C) 08.962 L=290 SERVICED BY L=3000	0-04750-300-0	01	1	0108-0211	●
55	03.120 HOSE; EVAP,CONT VLV TO PIPE SINGLE CAB(TF*S) 08.962 L=320 SERVICED BY L=3000	0-04750-300-0	01	1	0108-0211	●	●
55	03.120 HOSE; EVAP,CONT VLV TO PIPE CREW CAB(TF*W) 08.962 L=250 SERVICED BY L=3000	0-04750-300-0	01	1	0108-0211	●	●
62	03.120 HOSE; EVAP,CONT VLV SPACE CAB(TF*C) 08.962 (B) L=370 SERVICED BY L=3000	0-04750-300-0	01	1	0108-0211	●
62	03.120 HOSE; EVAP,CONT VLV 08.962 (A) L=350 SERVICED BY L=3000	0-04750-300-0	01	1	0108-0211	●	●
62	03.120 HOSE; EVAP,CONT VLV SINGLE CAB(TF*S) 08.962 (B) L=250 SERVICED BY L=3000	0-04750-300-0	01	1	0108-0211	●	●
62	03.120 HOSE; EVAP,CONT VLV CREW CAB(TF*W) 08.962 (B) L=240 SERVICED BY L=3000	0-04750-300-0	01	1	0108-0211	●	●
