2 |
GASKET; EXH MANIF TO HD
ALSO INCLUDED IN GASKET SET(ENG. & HEAD)
|
8-94393-672-1 |
06 |
1 |
9510-0210 |
● |
|
| |
2 |
GASKET; EXH MANIF TO HD
ALSO INCLUDED IN GASKET SET(ENG. & HEAD)
|
8-94393-672-4 |
06 |
1 |
0211- |
|
● |
| |
5 |
MANIFOLD; EXH,FRT
|
8-94394-753-1 |
01 |
1 |
9510-0210 |
● |
|
| |
5 |
MANIFOLD; EXH,FRT
|
8-94394-753-1 |
01 |
1 |
0211- |
|
● |
| |
6 |
MANIFOLD; EXH,RR
|
8-94394-755-4 |
01 |
1 |
9510-0210 |
● |
|
| |
6 |
MANIFOLD; EXH,RR
|
8-94394-755-4 |
01 |
1 |
0211- |
|
● |
| |
12 |
PROTECTOR; HEAT,TURBOCHARGER,EXH MANIF
(A)
|
8-94395-204-0 |
01 |
1 |
9510-0210 |
● |
|
| |
12 |
PROTECTOR; HEAT,TURBOCHARGER,EXH MANIF
(A)
|
8-94395-204-0 |
01 |
1 |
0211- |
|
● |
| |
12 |
PROTECTOR; HEAT,TURBOCHARGER,EXH MANIF
(B)
|
8-94395-413-1 |
01 |
1 |
9510-9609 |
● |
|
| |
12 |
PROTECTOR; HEAT,TURBOCHARGER,EXH MANIF
(B)
|
8-94391-040-0 |
01 |
1 |
9610-9809 |
● |
|
| |
12 |
PROTECTOR; HEAT,TURBOCHARGER,EXH MANIF
(B)
|
8-94392-947-0 |
01 |
1 |
9810-0210 |
● |
|
| |
12 |
PROTECTOR; HEAT,TURBOCHARGER,EXH MANIF
(B)
|
8-94392-947-0 |
01 |
1 |
0211- |
|
● |
| |
16 |
STUD; EXH PIPE TO MANIF
M12X103 L=123
|
8-94394-656-0 |
03 |
1 |
9510-0210 |
● |
|
| |
16 |
STUD; EXH PIPE TO MANIF
M12X103 L=123
|
8-94394-656-0 |
03 |
1 |
0211- |
|
● |
| |
18 |
NUT; EXH MANIF
M10 FLANGE
|
0-91150-210-0 |
12 |
1 |
9510-0210 |
● |
|
| |
18 |
NUT; EXH MANIF
M10 FLANGE
|
0-91150-210-0 |
12 |
1 |
0211-0602 |
|
● |
| |
18 |
NUT; EXH MANIF
M10 FLANGE
|
0-91180-210-0 |
12 |
1 |
0603- |
|
● |
| |
20 |
WASHER; PL,HEAT PROTECTOR
ID=8.4 OD=18
|
9-09160-608-0 |
01 |
1 |
9510-9803 |
● |
|
| |
33 |
WASHER; EXH MANIF
T=2.2
|
1-09556-015-0 |
12 |
1 |
9510-0210 |
● |
|
| |
33 |
WASHER; EXH MANIF
T=2.2
|
1-09556-015-0 |
12 |
1 |
0211- |
|
● |
| |
34 |
COLLAR; DIST,EXH MANIF
L=28
|
8-94395-679-0 |
12 |
1 |
9510-0209 |
● |
|
| |
34 |
COLLAR; DIST,EXH MANIF
L=28
|
8-97250-073-1 |
12 |
1 |
0210-0210 |
● |
|
| |
34 |
COLLAR; DIST,EXH MANIF
L=28
|
8-97250-073-1 |
12 |
1 |
0211- |
|
● |
| |
57 |
BOLT; HEAT PROTECTOR,EXH MANIF
(A)
M8X12 FLANGE
|
0-28080-812-0 |
02 |
1 |
9510-0210 |
● |
|
| |
57 |
BOLT; HEAT PROTECTOR,EXH MANIF
(A)
M8X12 FLANGE
|
0-28080-812-0 |
02 |
1 |
0211-0512 |
|
● |
| |
57 |
BOLT; HEAT PROTECTOR,EXH MANIF
(A)
M8X12 FLANGE
|
0-28050-812-0 |
02 |
1 |
0601- |
|
● |
| |
57 |
BOLT; HEAT PROTECTOR,EXH MANIF
(B)
M8X14 FLANGE
|
8-94312-699-1 |
04 |
1 |
9510-9803 |
● |
|
| |
57 |
BOLT; HEAT PROTECTOR,EXH MANIF
(B)
M8X14 FLANGE
|
8-94312-699-1 |
05 |
1 |
9804-0210 |
● |
|
| |
57 |
BOLT; HEAT PROTECTOR,EXH MANIF
(B)
M8X14 FLANGE
|
8-94312-699-1 |
05 |
1 |
0211-0408 |
|
● |
| |
57 |
BOLT; HEAT PROTECTOR,EXH MANIF
(B)
M8X14 FLANGE
|
8-97378-075-0 |
05 |
1 |
0409- |
|
● |
| |
58 |
STUD; HEAT PROTECTOR
|
8-94396-828-2 |
01 |
1 |
9510-9803 |
● |
|
| |
155 |
RING; SEAL,EXH MANIF
(A)
STAMP RH
|
1-14149-151-0 |
01 |
1 |
9510-0210 |
● |
|
| |
155 |
RING; SEAL,EXH MANIF
(A)
STAMP RH
|
1-14149-151-0 |
01 |
1 |
0211- |
|
● |
| |
155 |
RING; SEAL,EXH MANIF
(B)
|
1-14149-184-0 |
02 |
1 |
9510-0210 |
● |
|
| |
155 |
RING; SEAL,EXH MANIF
(B)
|
1-14149-184-0 |
02 |
1 |
0211- |
|
● |
