Sayfa 6-90 - Isuzu EPC

6-90 — REAR BUMPER (#18326) — 330 parça

113 127 127 129 129 134 135 133 158 136 128 128 114 113

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date	A	B	C	D	E	F
113	07.800 BRACKET; LICENSE PLATE FRAME STRAIGHT TYPE<7KJ> 02.662 (A)	8-97122-800-0	01	1	0211-0501	●	●	●
113	07.800 BRACKET; LICENSE PLATE FRAME STRAIGHT TYPE<7KJ> EXC. RR BODY FLAT BED(RS6) 02.662 (A)	8-97122-800-0	01	1	0211-0501				●	●
113	07.800 BRACKET; LICENSE PLATE FRAME STRAIGHT TYPE<7KJ> EXC. RR BODY FLAT BED(RS6) 02.662 (A)	8-97122-800-1	01	1	0502-0506				●	●
113	07.800 BRACKET; LICENSE PLATE FRAME STRAIGHT TYPE<7KJ> 02.662 (A)	8-97122-800-1	01	1	0502-0506		●
113	07.800 BRACKET; LICENSE PLATE FRAME STRAIGHT TYPE<7KJ> 02.662 (A)	8-97122-800-2	01	1	0507-	●	●
113	07.800 BRACKET; LICENSE PLATE FRAME STRAIGHT TYPE<7KJ> EXC. RR BODY FLAT BED(RS6) 02.662 (A)	8-97122-800-2	01	1	0507-				●	●
113	07.800 BRACKET; LICENSE PLATE 02.662 (A)	8-97122-800-2	01	1	0507-			●
113	07.800 BRACKET; LICENSE PLATE EXC. FRAME STRAIGHT TYPE<7KJ> 02.662 (A)	8-97096-644-2	01	1	0211-0501	●	●	●
113	07.800 BRACKET; LICENSE PLATE EXC. RR BODY FLAT BED(RS6),FRAME STRAIGHT TYPE<7KJ> 02.662 (A)	8-97096-644-2	01	1	0211-0501				●	●
113	07.800 BRACKET; LICENSE PLATE 02.662 (A)	8-97096-644-2	01	1	0211-0501						●
113	07.800 BRACKET; LICENSE PLATE 02.662 (A)	8-97096-644-3	01	1	0502-0506	●					●
113	07.800 BRACKET; LICENSE PLATE EXC. RR BODY FLAT BED(RS6),FRAME STRAIGHT TYPE<7KJ> 02.662 (A)	8-97096-644-3	01	1	0502-0506				●	●
113	07.800 BRACKET; LICENSE PLATE EXC. FRAME STRAIGHT TYPE<7KJ> 02.662 (A)	8-97096-644-3	01	1	0502-0506		●
113	07.800 BRACKET; LICENSE PLATE EXC. FRAME STRAIGHT TYPE<7KJ> 02.662 (A)	8-97096-644-3	01	1	0507-0806	●	●
113	07.800 BRACKET; LICENSE PLATE EXC. RR BODY FLAT BED(RS6),FRAME STRAIGHT TYPE<7KJ> 02.662 (A)	8-97096-644-3	01	1	0507-0806				●	●
113	07.800 BRACKET; LICENSE PLATE 02.662 (A)	8-97096-644-3	01	1	0507-0806						●
113	07.800 BRACKET; LICENSE PLATE EXC. FRAME STRAIGHT TYPE<7KJ> (A)	8-98029-390-3	01	1	0807-	●	●
113	07.800 BRACKET; LICENSE PLATE EXC. RR BODY FLAT BED(RS6),FRAME STRAIGHT TYPE<7KJ> (A)	8-98029-390-3	01	1	0807-				●	●
113	07.800 BRACKET; LICENSE PLATE (A)	8-98029-390-3	01	1	0807-						●
113	07.800 BRACKET; LICENSE PLATE RR BODY FLAT BED(RS6) (B)	8-97077-573-2	01	1	0211-				●	●
114	07.800 BOLT; BRKT,LICENSE PLATE RR BODY FLAT BED(RS6) 02.334 M6X25 FLANGE	0-28680-625-0	02	1	0211-0512				●	●
114	07.800 BOLT; BRKT,LICENSE PLATE RR BODY FLAT BED(RS6) 00.685 M6X25 FLANGE	0-28650-625-0	02	1	0601-				●	●
127	02.662 BOLT; CROSS PLATE 03.483 M8X40 W/LK&PL WASHER	0-50140-840-0	02	1	0211-0403	●	●	●			●
127	02.662 BOLT; CROSS PLATE EXC. RR BODY FLAT BED(RS6) 03.483 M8X40 W/LK&PL WASHER	0-50140-840-0	02	1	0211-0403				●	●
127	02.662 BOLT; CROSS PLATE 03.704 M8X40 FLANGE	0-28680-840-0	02	1	0404-0408	●	●	●			●
127	02.662 BOLT; CROSS PLATE EXC. RR BODY FLAT BED(RS6) 03.704 M8X40 FLANGE	0-28680-840-0	02	1	0404-0408				●	●
127	02.662 BOLT; CROSS PLATE EXC. IDENTIFICATION LABEL FOR KD<6UT> 03.704 M8X40 FLANGE	0-28680-840-0	02	1	0409-0409	●	●	●			●
127	02.662 BOLT; CROSS PLATE EXC. RR BODY FLAT BED(RS6), IDENTIFICATION LABEL FOR KD<6UT> 03.704 M8X40 FLANGE	0-28680-840-0	02	1	0409-0409				●	●
127	02.662 BOLT; CROSS PLATE 03.704 M8X40 FLANGE	0-28680-840-0	02	1	0409-0501	●	●	●			●
127	02.662 BOLT; CROSS PLATE EXC. RR BODY FLAT BED(RS6) 03.704 M8X40 FLANGE	0-28680-840-0	02	1	0409-0501				●	●
127	02.662 BOLT; CROSS PLATE 03.704 M8X40 FLANGE	0-28680-840-0	02	1	0502-0506	●	●				●
127	02.662 BOLT; CROSS PLATE EXC. RR BODY FLAT BED(RS6) 03.704 M8X40 FLANGE	0-28680-840-0	02	1	0502-0506				●	●
127	02.662 BOLT; CROSS PLATE 03.704 M8X40 FLANGE	0-28680-840-0	02	1	0507-0512	●	●	●			●
127	02.662 BOLT; CROSS PLATE EXC. RR BODY FLAT BED(RS6) 03.704 M8X40 FLANGE	0-28680-840-0	02	1	0507-0512				●	●
127	02.662 BOLT; CROSS PLATE 00.685 M8X40 FLANGE	0-28650-840-0	02	1	0601-	●	●	●			●
127	02.662 BOLT; CROSS PLATE EXC. RR BODY FLAT BED(RS6) 00.685 M8X40 FLANGE	0-28650-840-0	02	1	0601-				●	●
128	02.662 NUT; CROSS PLATE 02.559 M8	9-09110-408-0	02	1	0211-0408	●	●	●			●
128	02.662 NUT; CROSS PLATE EXC. RR BODY FLAT BED(RS6) 02.559 M8	9-09110-408-0	02	1	0211-0408				●	●
128	02.662 NUT; CROSS PLATE EXC. IDENTIFICATION LABEL FOR KD<6UT> 02.559 M8	9-09110-408-0	02	1	0409-0409	●	●	●			●
128	02.662 NUT; CROSS PLATE EXC. RR BODY FLAT BED(RS6), IDENTIFICATION LABEL FOR KD<6UT> 02.559 M8	9-09110-408-0	02	1	0409-0409				●	●
128	02.662 NUT; CROSS PLATE 02.559 M8	9-09110-408-0	02	1	0409-0501	●	●	●			●
128	02.662 NUT; CROSS PLATE EXC. RR BODY FLAT BED(RS6) 02.559 M8	9-09110-408-0	02	1	0409-0501				●	●
128	02.662 NUT; CROSS PLATE 02.559 M8	9-09110-408-0	02	1	0502-0506	●	●				●
128	02.662 NUT; CROSS PLATE EXC. RR BODY FLAT BED(RS6) 02.559 M8	9-09110-408-0	02	1	0502-0506				●	●
128	02.662 NUT; CROSS PLATE 02.559 M8	9-09110-408-0	02	1	0507-0512	●	●	●			●
128	02.662 NUT; CROSS PLATE EXC. RR BODY FLAT BED(RS6) 02.559 M8	9-09110-408-0	02	1	0507-0512				●	●
128	02.662 NUT; CROSS PLATE 02.334 M8	0-91110-508-0	02	1	0601-0709	●	●	●			●
128	02.662 NUT; CROSS PLATE EXC. RR BODY FLAT BED(RS6) 02.334 M8	0-91110-508-0	02	1	0601-0709				●	●
128	02.662 NUT; CROSS PLATE 01.062 M8 FLANGE	0-91180-108-0	02	1	0710-	●	●	●			●
128	02.662 NUT; CROSS PLATE EXC. RR BODY FLAT BED(RS6) 01.062 M8 FLANGE	0-91180-108-0	02	1	0710-				●	●
129	03.162 WASHER; PL,CROSS PLATE 02.334 ID=8.4 OD=26	9-09164-808-0	02	1	0211-0408	●	●	●
129	03.162 WASHER; PL,CROSS PLATE EXC. RR BODY FLAT BED(RS6) 02.334 ID=8.4 OD=26	9-09164-808-0	02	1	0211-0408				●	●
129	03.162 WASHER; PL,CROSS PLATE EXC. IDENTIFICATION LABEL FOR KD<6UT> 02.334 ID=8.4 OD=26	9-09164-808-0	02	1	0409-0409	●	●	●
129	03.162 WASHER; PL,CROSS PLATE EXC. RR BODY FLAT BED(RS6), IDENTIFICATION LABEL FOR KD<6UT> 02.334 ID=8.4 OD=26	9-09164-808-0	02	1	0409-0409				●	●
129	03.162 WASHER; PL,CROSS PLATE 02.334 ID=8.4 OD=26	9-09164-808-0	02	1	0409-0501	●	●	●
129	03.162 WASHER; PL,CROSS PLATE EXC. RR BODY FLAT BED(RS6) 02.334 ID=8.4 OD=26	9-09164-808-0	02	1	0409-0501				●	●
129	03.162 WASHER; PL,CROSS PLATE 02.334 ID=8.4 OD=26	9-09164-808-0	02	1	0502-0506	●	●
129	03.162 WASHER; PL,CROSS PLATE EXC. RR BODY FLAT BED(RS6) 02.334 ID=8.4 OD=26	9-09164-808-0	02	1	0502-0506				●	●
129	03.162 WASHER; PL,CROSS PLATE 02.334 ID=8.4 OD=26	9-09164-808-0	02	1	0507-0605	●	●	●
129	03.162 WASHER; PL,CROSS PLATE EXC. RR BODY FLAT BED(RS6) 02.334 ID=8.4 OD=26	9-09164-808-0	02	1	0507-0605				●	●
129	03.162 WASHER; PL,CROSS PLATE 03.706 ID=8.4 OD=26	0-91614-808-0	02	1	0606-0709	●	●	●
129	03.162 WASHER; PL,CROSS PLATE EXC. RR BODY FLAT BED(RS6) 03.706 ID=8.4 OD=26	0-91614-808-0	02	1	0606-0709				●	●
133	07.112 HOOK DUMP CHASSIS(V4D) 07.068	8-94249-270-2	01	1	0211-0501	●
133	07.112 HOOK EXC. DUMP CHASSIS(V4D),FRAME STRAIGHTTYPE<7KJ> 07.068	8-94249-270-2	01	1	0211-0501	●
133	07.112 HOOK SINGAPORE EQUIPMENT(S9Y) BUMPER REAR<7HZ> EXC. FRAME STRAIGHT TYPE<7KJ> 07.068	8-94249-270-2	01	1	0211-0501			●	●	●
133	07.112 HOOK RR BODY FLAT BED(RS6) 07.068	8-94249-270-2	01	1	0211-0501				●	●
133	07.112 HOOK EXC. RR BODY FLAT BED(RS6),BUMPER REAR<7HZ>,FRAME STRAIGHT TYPE<7KJ> 07.068	8-94249-270-2	01	1	0211-0501				●	●
133	07.112 HOOK EXC. FRAME STRAIGHT TYPE<7KJ> 07.068	8-94249-270-2	01	1	0211-0501		●
133	07.112 HOOK EXC. BUMPER REAR<7HZ>,FRAME STRAIGHT TYPE<7KJ> 07.068	8-94249-270-2	01	1	0211-0501			●
133	07.112 HOOK 07.068	8-94249-270-2	01	1	0502-0506	●
133	07.112 HOOK SINGAPORE EQUIPMENT(S9Y) BUMPER REAR<7HZ> EXC. RR BODY FLAT BED(RS6),FRAME STRAIGHT TYPE<7KJ> 07.068	8-94249-270-2	01	1	0502-0506				●
133	07.112 HOOK RR BODY FLAT BED(RS6) EXC. FRAME STRAIGHT TYPE<7KJ> 07.068	8-94249-270-2	01	1	0502-0506				●
133	07.112 HOOK EXC. RR BODY FLAT BED(RS6),BUMPER REAR<7HZ>,FRAME STRAIGHT TYPE<7KJ> 07.068	8-94249-270-2	01	1	0502-0506				●
133	07.112 HOOK EXC. FRAME STRAIGHT TYPE<7KJ> 07.068	8-94249-270-2	01	1	0502-0506		●			●
133	07.112 HOOK DUMP CHASSIS(V4D) 07.068	8-94249-270-2	01	1	0507-	●
133	07.112 HOOK EXC. DUMP CHASSIS(V4D),FRAME STRAIGHTTYPE<7KJ> 07.068	8-94249-270-2	01	1	0507-	●
133	07.112 HOOK SINGAPORE EQUIPMENT(S9Y) BUMPER REAR<7HZ> EXC. RR BODY FLAT BED(RS6),FRAME STRAIGHT TYPE<7KJ> 07.068	8-94249-270-2	01	1	0507-				●
133	07.112 HOOK RR BODY FLAT BED(RS6) EXC. FRAME STRAIGHT TYPE<7KJ> 07.068	8-94249-270-2	01	1	0507-				●
133	07.112 HOOK EXC. RR BODY FLAT BED(RS6),BUMPER REAR<7HZ>,FRAME STRAIGHT TYPE<7KJ> 07.068	8-94249-270-2	01	1	0507-				●
133	07.112 HOOK EXC. FRAME STRAIGHT TYPE<7KJ> 07.068	8-94249-270-2	01	1	0507-		●			●
133	07.112 HOOK FRAME STRAIGHT TYPE<7KJ>	8-97122-535-0	01	1	0211-0501	●	●	●	●	●
133	07.112 HOOK FRAME STRAIGHT TYPE<7KJ>	8-97122-535-0	01	1	0502-0506		●		●	●
133	07.112 HOOK FRAME STRAIGHT TYPE<7KJ>	8-97122-535-0	01	1	0507-	●	●		●	●
133	07.112 HOOK	8-97122-535-0	01	1	0507-			●
133	07.112 HOOK 07.330	8-94183-262-0	01	1	0211-						●
134	07.068 BOLT; HOOK EXC. RR BODY FLAT BED(RS6),BUMPER REAR<7HZ> 07.039 M14X50	0-10806-450-0	02	1	0211-0501	●	●	●	●	●
134	07.068 BOLT; HOOK SINGAPORE EQUIPMENT(S9Y) BUMPER REAR<7HZ> EXC. RR BODY FLAT BED(RS6) 07.039 M14X50	0-10806-450-0	02	1	0211-0501			●	●	●
134	07.068 BOLT; HOOK RR BODY FLAT BED(RS6) 07.039 M14X50	0-10806-450-0	02	1	0211-0501				●	●
134	07.068 BOLT; HOOK 07.039 M14X50	0-10806-450-0	02	1	0502-0506	●	●			●
134	07.068 BOLT; HOOK SINGAPORE EQUIPMENT(S9Y) BUMPER REAR<7HZ> EXC. RR BODY FLAT BED(RS6) 07.039 M14X50	0-10806-450-0	02	1	0502-0506				●
134	07.068 BOLT; HOOK RR BODY FLAT BED(RS6) 07.039 M14X50	0-10806-450-0	02	1	0502-0506				●
134	07.068 BOLT; HOOK EXC. RR BODY FLAT BED(RS6),BUMPER REAR<7HZ> 07.039 M14X50	0-10806-450-0	02	1	0502-0506				●
134	07.068 BOLT; HOOK 07.039 M14X50	0-10806-450-0	02	1	0507-0512	●	●	●		●
134	07.068 BOLT; HOOK SINGAPORE EQUIPMENT(S9Y) BUMPER REAR<7HZ> EXC. RR BODY FLAT BED(RS6) 07.039 M14X50	0-10806-450-0	02	1	0507-0512				●
134	07.068 BOLT; HOOK RR BODY FLAT BED(RS6) 07.039 M14X50	0-10806-450-0	02	1	0507-0512				●
134	07.068 BOLT; HOOK EXC. RR BODY FLAT BED(RS6),BUMPER REAR<7HZ> 07.039 M14X50	0-10806-450-0	02	1	0507-0512				●
134	07.068 BOLT; HOOK 07.039 M14X50	0-10856-450-0	02	1	0601-	●	●	●		●
134	07.068 BOLT; HOOK SINGAPORE EQUIPMENT(S9Y) BUMPER REAR<7HZ> EXC. RR BODY FLAT BED(RS6) 07.039 M14X50	0-10856-450-0	02	1	0601-				●
134	07.068 BOLT; HOOK RR BODY FLAT BED(RS6) 07.039 M14X50	0-10856-450-0	02	1	0601-				●
134	07.068 BOLT; HOOK EXC. RR BODY FLAT BED(RS6),BUMPER REAR<7HZ> 07.039 M14X50	0-10856-450-0	02	1	0601-				●
134	07.068 BOLT; HOOK 00.004 M10X45 W/LK WASHER	0-50041-045-0	02	1	0211-0909						●
134	07.068 BOLT; HOOK M10X45 W/LK WASHER	0-50541-045-0	02	1	0910-						●
135	07.068 WASHER; LK,HOOK EXC. RR BODY FLAT BED(RS6),BUMPER REAR<7HZ> 05.422 ID=14.2	9-09150-814-0	02	1	0211-0501	●	●	●	●	●
135	07.068 WASHER; LK,HOOK SINGAPORE EQUIPMENT(S9Y) BUMPER REAR<7HZ> EXC. RR BODY FLAT BED(RS6) 05.422 ID=14.2	9-09150-814-0	02	1	0211-0501			●	●	●
135	07.068 WASHER; LK,HOOK RR BODY FLAT BED(RS6) 05.422 ID=14.2	9-09150-814-0	02	1	0211-0501				●	●
135	07.068 WASHER; LK,HOOK 05.422 ID=14.2	9-09150-814-0	02	1	0502-0506	●	●			●
135	07.068 WASHER; LK,HOOK SINGAPORE EQUIPMENT(S9Y) BUMPER REAR<7HZ> EXC. RR BODY FLAT BED(RS6) 05.422 ID=14.2	9-09150-814-0	02	1	0502-0506				●
135	07.068 WASHER; LK,HOOK RR BODY FLAT BED(RS6) 05.422 ID=14.2	9-09150-814-0	02	1	0502-0506				●
135	07.068 WASHER; LK,HOOK EXC. RR BODY FLAT BED(RS6),BUMPER REAR<7HZ> 05.422 ID=14.2	9-09150-814-0	02	1	0502-0506				●
135	07.068 WASHER; LK,HOOK 05.422 ID=14.2	9-09150-814-0	02	1	0507-0603	●	●	●		●
135	07.068 WASHER; LK,HOOK SINGAPORE EQUIPMENT(S9Y) BUMPER REAR<7HZ> EXC. RR BODY FLAT BED(RS6) 05.422 ID=14.2	9-09150-814-0	02	1	0507-0603				●
135	07.068 WASHER; LK,HOOK RR BODY FLAT BED(RS6) 05.422 ID=14.2	9-09150-814-0	02	1	0507-0603				●
135	07.068 WASHER; LK,HOOK EXC. RR BODY FLAT BED(RS6),BUMPER REAR<7HZ> 05.422 ID=14.2	9-09150-814-0	02	1	0507-0603				●
135	07.068 WASHER; LK,HOOK 06.174 ID=14.2	0-91510-814-0	02	1	0604-0610	●	●	●		●
135	07.068 WASHER; LK,HOOK SINGAPORE EQUIPMENT(S9Y) BUMPER REAR<7HZ> EXC. RR BODY FLAT BED(RS6) 06.174 ID=14.2	0-91510-814-0	02	1	0604-0610				●
135	07.068 WASHER; LK,HOOK RR BODY FLAT BED(RS6) 06.174 ID=14.2	0-91510-814-0	02	1	0604-0610				●
135	07.068 WASHER; LK,HOOK EXC. RR BODY FLAT BED(RS6),BUMPER REAR<7HZ> 06.174 ID=14.2	0-91510-814-0	02	1	0604-0610				●
136	07.068 NUT; HOOK EXC. RR BODY FLAT BED(RS6),BUMPER REAR<7HZ> 07.529 M14	9-99110-514-0	02	1	0211-0501	●	●	●	●	●
136	07.068 NUT; HOOK SINGAPORE EQUIPMENT(S9Y) BUMPER REAR<7HZ> EXC. RR BODY FLAT BED(RS6) 07.529 M14	9-99110-514-0	02	1	0211-0501			●	●	●
136	07.068 NUT; HOOK RR BODY FLAT BED(RS6) 07.529 M14	9-99110-514-0	02	1	0211-0501				●	●
136	07.068 NUT; HOOK 07.529 M14	9-99110-514-0	02	1	0502-0506	●	●			●
136	07.068 NUT; HOOK SINGAPORE EQUIPMENT(S9Y) BUMPER REAR<7HZ> EXC. RR BODY FLAT BED(RS6) 07.529 M14	9-99110-514-0	02	1	0502-0506				●
136	07.068 NUT; HOOK RR BODY FLAT BED(RS6) 07.529 M14	9-99110-514-0	02	1	0502-0506				●
136	07.068 NUT; HOOK EXC. RR BODY FLAT BED(RS6),BUMPER REAR<7HZ> 07.529 M14	9-99110-514-0	02	1	0502-0506				●
136	07.068 NUT; HOOK 07.529 M14	9-99110-514-0	02	1	0507-0512	●	●	●		●
136	07.068 NUT; HOOK SINGAPORE EQUIPMENT(S9Y) BUMPER REAR<7HZ> EXC. RR BODY FLAT BED(RS6) 07.529 M14	9-99110-514-0	02	1	0507-0512				●
136	07.068 NUT; HOOK RR BODY FLAT BED(RS6) 07.529 M14	9-99110-514-0	02	1	0507-0512				●
136	07.068 NUT; HOOK EXC. RR BODY FLAT BED(RS6),BUMPER REAR<7HZ> 07.529 M14	9-99110-514-0	02	1	0507-0512				●
136	07.068 NUT; HOOK 07.833 M14	0-91110-514-0	02	1	0601-0610	●	●	●		●
136	07.068 NUT; HOOK SINGAPORE EQUIPMENT(S9Y) BUMPER REAR<7HZ> EXC. RR BODY FLAT BED(RS6) 07.833 M14	0-91110-514-0	02	1	0601-0610				●
136	07.068 NUT; HOOK RR BODY FLAT BED(RS6) 07.833 M14	0-91110-514-0	02	1	0601-0610				●
136	07.068 NUT; HOOK EXC. RR BODY FLAT BED(RS6),BUMPER REAR<7HZ> 07.833 M14	0-91110-514-0	02	1	0601-0610				●
136	07.068 NUT; HOOK 00.429 M14 FLANGE	0-91180-214-0	02	1	0611-	●	●	●		●
136	07.068 NUT; HOOK SINGAPORE EQUIPMENT(S9Y) BUMPER REAR<7HZ> EXC. RR BODY FLAT BED(RS6) 00.429 M14 FLANGE	0-91180-214-0	02	1	0611-				●
136	07.068 NUT; HOOK RR BODY FLAT BED(RS6) 00.429 M14 FLANGE	0-91180-214-0	02	1	0611-				●
136	07.068 NUT; HOOK EXC. RR BODY FLAT BED(RS6),BUMPER REAR<7HZ> 00.429 M14 FLANGE	0-91180-214-0	02	1	0611-				●
136	07.068 NUT; HOOK 00.002 M10	9-09110-510-0	02	1	0211-0512						●
136	07.068 NUT; HOOK 00.833 M10	0-91110-510-0	02	1	0601-						●
158	07.629 WASHER; PL,HOOK SPACER DUMP CHASSIS(V4D) 06.164 ID=15 OD=30	9-09164-614-0	02	1	0211-	●

134 306 2 158 133 135 136 13 12 9 315 2 1 2 11 2 306 1 2 133 135 136 336 317 13 12 315 9 21 11 317

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date	A	B	C	D	E	F
1	07.070 BUMPER; RR G.V.W. 4.0-4.5TON(RPR),G.V.W. 6.0-6.5TON(RPV) BUMPER REAR<7HZ> EXC. FRAME STRAIGHT TYPE<7KJ> (A)	8-97174-006-1	01	1	0211-0501				●
1	07.070 BUMPER; RR G.V.W. 6.0-6.5TON(RPV) BUMPER REAR<7HZ> EXC. FRAME STRAIGHT TYPE<7KJ> (A)	8-97174-006-1	01	1	0211-0501			●		●
1	07.070 BUMPER; RR BUMPER REAR<7HZ> (A)	8-97174-006-1	01	1	0211-0501						●
1	07.070 BUMPER; RR G.V.W. 6.0-6.5TON(RPV) BUMPER REAR<7HZ> EXC. FRAME STRAIGHT TYPE<7KJ> (A)	8-97174-006-2	01	1	0502-0503				●
1	07.070 BUMPER; RR BUMPER REAR<7HZ> (A)	8-97174-006-2	01	1	0502-0503						●
1	07.070 BUMPER; RR G.V.W. 6.0-6.5TON(RPV) BUMPER REAR<7HZ> EXC. FRAME STRAIGHT TYPE<7KJ> (A) STAMP IJ2K	8-98000-147-1	01	1	0504-0506				●
1	07.070 BUMPER; RR BUMPER REAR<7HZ> (A) STAMP IJ2K	8-98000-147-1	01	1	0504-0506						●
1	07.070 BUMPER; RR G.V.W. 4.0-4.5TON(RPR),G.V.W. 6.0-6.5TON(RPV) BUMPER REAR<7HZ> EXC. FRAME STRAIGHT TYPE<7KJ> (A) STAMP IJ2K	8-98000-147-1	01	1	0507-				●
1	07.070 BUMPER; RR BUMPER REAR<7HZ> (A) STAMP IJ2K	8-98000-147-1	01	1	0507-						●
1	07.070 BUMPER; RR G.V.W. 4.0-4.5TON(RPR),G.V.W. 6.0-6.5TON(RPV) BUMPER REAR<7HZ> FRAME STRAIGHT TYPE<7KJ> (A)	8-97205-670-0	01	1	0211-0501				●
1	07.070 BUMPER; RR G.V.W. 6.0-6.5TON(RPV) BUMPER REAR<7HZ> FRAME STRAIGHT TYPE<7KJ> (A)	8-97205-670-0	01	1	0211-0501			●		●
1	07.070 BUMPER; RR G.V.W. 6.0-6.5TON(RPV) BUMPER REAR<7HZ> FRAME STRAIGHT TYPE<7KJ> (A)	8-97205-670-1	01	1	0502-0503				●
1	07.070 BUMPER; RR G.V.W. 6.0-6.5TON(RPV) BUMPER REAR<7HZ> FRAME STRAIGHT TYPE<7KJ> (A) STAMP IJ2Q	8-98000-148-1	01	1	0504-0506				●
1	07.070 BUMPER; RR G.V.W. 4.0-4.5TON(RPR),G.V.W. 6.0-6.5TON(RPV) BUMPER REAR<7HZ> FRAME STRAIGHT TYPE<7KJ> (A) STAMP IJ2Q	8-98000-148-1	01	1	0507-				●
1	07.070 BUMPER; RR G.V.W. 7.0-7.5TON(RPX),G.V.W. 7.5-8.0TON(RPY),G.V.W. 8.0-8.5TON(RPZ) BUMPER REAR<7HZ> FRAME STRAIGHT TYPE<7KJ> (B)	8-97247-191-1	01	1	0211-0501				●	●
1	07.070 BUMPER; RR G.V.W. 7.5-8.0TON(RPY) BUMPER REAR<7HZ> FRAME STRAIGHT TYPE<7KJ> (B)	8-97247-191-1	01	1	0211-0501			●
1	07.070 BUMPER; RR G.V.W. 7.0-7.5TON(RPX),G.V.W. 8.0-8.5TON(RPZ) BUMPER REAR<7HZ> FRAME STRAIGHT TYPE<7KJ> (B)	8-97247-191-1	01	1	0502-0506				●
1	07.070 BUMPER; RR G.V.W. 7.0-7.5TON(RPX),G.V.W. 7.5-8.0TON(RPY),G.V.W. 8.0-8.5TON(RPZ) BUMPER REAR<7HZ> FRAME STRAIGHT TYPE<7KJ> (B)	8-97247-191-1	01	1	0507-				●
2	07.874 BOLT; BACK BAR G.V.W. 4.0-4.5TON(RPR),G.V.W. 6.0-6.5TON(RPV) BUMPER REAR<7HZ> 01.271 (A) M10X30	8-94324-205-0	04	1	0211-0501				●
2	07.874 BOLT; BACK BAR G.V.W. 6.0-6.5TON(RPV) BUMPER REAR<7HZ> 01.271 (A) M10X30	8-94324-205-0	04	1	0211-0501			●		●
2	07.874 BOLT; BACK BAR BUMPER REAR<7HZ> 01.271 (A) M10X30	8-94324-205-0	04	1	0211-0501						●
2	07.874 BOLT; BACK BAR G.V.W. 6.0-6.5TON(RPV) BUMPER REAR<7HZ> 01.271 (A) M10X30	8-94324-205-0	04	1	0502-0506				●
2	07.874 BOLT; BACK BAR BUMPER REAR<7HZ> 01.271 (A) M10X30	8-94324-205-0	04	1	0502-0506						●
2	07.874 BOLT; BACK BAR G.V.W. 4.0-4.5TON(RPR),G.V.W. 6.0-6.5TON(RPV) BUMPER REAR<7HZ> 01.271 (A) M10X30	8-94324-205-0	04	1	0507-				●
2	07.874 BOLT; BACK BAR BUMPER REAR<7HZ> 01.271 (A) M10X30	8-94324-205-0	04	1	0507-						●
2	07.874 BOLT; BACK BAR BUMPER REAR<7HZ> EXC. FRAME STRAIGHT TYPE<7KJ> 07.347 (B) M14X30	0-20801-430-0	06	1	0211-0501			●	●	●
2	07.874 BOLT; BACK BAR BUMPER REAR<7HZ> EXC. FRAME STRAIGHT TYPE<7KJ> 07.347 (B) M14X30	0-20801-430-0	06	1	0502-0512				●
2	07.874 BOLT; BACK BAR BUMPER REAR<7HZ> 07.347 (B) M14X30	0-20801-430-0	06	1	0502-0512						●
2	07.874 BOLT; BACK BAR BUMPER REAR<7HZ> EXC. FRAME STRAIGHT TYPE<7KJ> (B) M14X30	0-20851-430-0	06	1	0601-				●
2	07.874 BOLT; BACK BAR BUMPER REAR<7HZ> (B) M14X30	0-20851-430-0	06	1	0601-						●
2	07.874 BOLT; BACK BAR BUMPER REAR<7HZ> 07.347 (B) M14X30	0-20801-430-0	08	1	0211-0501						●
9	07.070 NUT; BUMPER G.V.W. 4.0-4.5TON(RPR),G.V.W. 6.0-6.5TON(RPV) BUMPER REAR<7HZ> 08.917 M10 FLANGE	0-91150-210-0	02	1	0211-0501				●
9	07.070 NUT; BUMPER G.V.W. 6.0-6.5TON(RPV) BUMPER REAR<7HZ> 08.917 M10 FLANGE	0-91150-210-0	02	1	0211-0501			●		●
9	07.070 NUT; BUMPER BUMPER REAR<7HZ> 08.917 M10 FLANGE	0-91150-210-0	02	1	0211-0501						●
9	07.070 NUT; BUMPER G.V.W. 6.0-6.5TON(RPV) BUMPER REAR<7HZ> 08.917 M10 FLANGE	0-91150-210-0	02	1	0502-0506				●
9	07.070 NUT; BUMPER BUMPER REAR<7HZ> 08.917 M10 FLANGE	0-91150-210-0	02	1	0502-0506						●
9	07.070 NUT; BUMPER G.V.W. 4.0-4.5TON(RPR),G.V.W. 6.0-6.5TON(RPV) BUMPER REAR<7HZ> 08.917 M10 FLANGE	0-91150-210-0	02	1	0507-0602				●
9	07.070 NUT; BUMPER BUMPER REAR<7HZ> 08.917 M10 FLANGE	0-91150-210-0	02	1	0507-0602						●
9	07.070 NUT; BUMPER G.V.W. 4.0-4.5TON(RPR),G.V.W. 6.0-6.5TON(RPV) BUMPER REAR<7HZ> 04.085 M10 FLANGE	0-91180-210-0	02	1	0603-				●
9	07.070 NUT; BUMPER BUMPER REAR<7HZ> 04.085 M10 FLANGE	0-91180-210-0	02	1	0603-						●
9	07.070 NUT; BUMPER G.V.W. 7.0-7.5TON(RPX),G.V.W. 7.5-8.0TON(RPY),G.V.W. 8.0-8.5TON(RPZ) BUMPER REAR<7HZ> FRAME STRAIGHT TYPE<7KJ> 04.634 M12	9-99110-512-0	08	1	0211-0501				●	●
9	07.070 NUT; BUMPER G.V.W. 7.5-8.0TON(RPY) BUMPER REAR<7HZ> FRAME STRAIGHT TYPE<7KJ> 04.634 M12	9-99110-512-0	08	1	0211-0501			●
9	07.070 NUT; BUMPER G.V.W. 7.0-7.5TON(RPX),G.V.W. 8.0-8.5TON(RPZ) BUMPER REAR<7HZ> FRAME STRAIGHT TYPE<7KJ> 04.634 M12	9-99110-512-0	08	1	0502-0506				●
9	07.070 NUT; BUMPER G.V.W. 7.0-7.5TON(RPX),G.V.W. 7.5-8.0TON(RPY),G.V.W. 8.0-8.5TON(RPZ) BUMPER REAR<7HZ> FRAME STRAIGHT TYPE<7KJ> 04.634 M12	9-99110-512-0	08	1	0507-0512				●
9	07.070 NUT; BUMPER G.V.W. 7.0-7.5TON(RPX),G.V.W. 7.5-8.0TON(RPY),G.V.W. 8.0-8.5TON(RPZ) BUMPER REAR<7HZ> FRAME STRAIGHT TYPE<7KJ> 05.002 M12	0-91110-512-0	08	1	0601-				●
11	07.829 CAP; RR BUMPER G.V.W. 6.0-6.5TON(RPV) BUMPER REAR<7HZ>	8-97174-008-0	02	1	0504-0506				●
11	07.829 CAP; RR BUMPER BUMPER REAR<7HZ>	8-97174-008-0	02	1	0504-0506						●
11	07.829 CAP; RR BUMPER G.V.W. 4.0-4.5TON(RPR),G.V.W. 6.0-6.5TON(RPV) BUMPER REAR<7HZ>	8-97174-008-0	02	1	0507-				●
11	07.829 CAP; RR BUMPER BUMPER REAR<7HZ>	8-97174-008-0	02	1	0507-						●
11	07.829 CAP; RR BUMPER G.V.W. 7.0-7.5TON(RPX),G.V.W. 7.5-8.0TON(RPY),G.V.W. 8.0-8.5TON(RPZ) BUMPER REAR<7HZ> FRAME STRAIGHT TYPE<7KJ>	1-71290-055-0	02	1	0211-0501				●	●
11	07.829 CAP; RR BUMPER G.V.W. 7.5-8.0TON(RPY) BUMPER REAR<7HZ> FRAME STRAIGHT TYPE<7KJ>	1-71290-055-0	02	1	0211-0501			●
11	07.829 CAP; RR BUMPER G.V.W. 7.0-7.5TON(RPX),G.V.W. 8.0-8.5TON(RPZ) BUMPER REAR<7HZ> FRAME STRAIGHT TYPE<7KJ>	1-71290-055-0	02	1	0502-0506				●
11	07.829 CAP; RR BUMPER G.V.W. 7.0-7.5TON(RPX),G.V.W. 7.5-8.0TON(RPY),G.V.W. 8.0-8.5TON(RPZ) BUMPER REAR<7HZ> FRAME STRAIGHT TYPE<7KJ>	1-71290-055-0	02	1	0507-				●
12	07.833 NUT; BRKT BUMPER REAR<7HZ> EXC. FRAME STRAIGHT TYPE<7KJ> 07.529 M14	9-99110-514-0	06	1	0211-0501			●	●	●
12	07.833 NUT; BRKT BUMPER REAR<7HZ> EXC. FRAME STRAIGHT TYPE<7KJ> 07.529 M14	9-99110-514-0	06	1	0502-0512				●
12	07.833 NUT; BRKT BUMPER REAR<7HZ> 07.529 M14	9-99110-514-0	06	1	0502-0512						●
12	07.833 NUT; BRKT BUMPER REAR<7HZ> EXC. FRAME STRAIGHT TYPE<7KJ> M14	0-91110-514-0	06	1	0601-0610				●
12	07.833 NUT; BRKT BUMPER REAR<7HZ> M14	0-91110-514-0	06	1	0601-0610						●
12	07.833 NUT; BRKT BUMPER REAR<7HZ> EXC. FRAME STRAIGHT TYPE<7KJ> 00.429 M14 FLANGE	0-91180-214-0	06	1	0611-				●
12	07.833 NUT; BRKT BUMPER REAR<7HZ> 00.429 M14 FLANGE	0-91180-214-0	06	1	0611-						●
12	07.833 NUT; BRKT BUMPER REAR<7HZ> 07.529 M14	9-99110-514-0	08	1	0211-0501						●
13	07.833 WASHER; LK,BACK BAR TO FRAME BUMPER REAR<7HZ> EXC. FRAME STRAIGHT TYPE<7KJ> 05.422 ID=14.2	9-09150-814-0	06	1	0211-0501			●	●	●
13	07.833 WASHER; LK,BACK BAR TO FRAME BUMPER REAR<7HZ> EXC. FRAME STRAIGHT TYPE<7KJ> 05.422 ID=14.2	9-09150-814-0	06	1	0502-0603				●
13	07.833 WASHER; LK,BACK BAR TO FRAME BUMPER REAR<7HZ> 05.422 ID=14.2	9-09150-814-0	06	1	0502-0603						●
13	07.833 WASHER; LK,BACK BAR TO FRAME BUMPER REAR<7HZ> EXC. FRAME STRAIGHT TYPE<7KJ> 06.174 ID=14.2	0-91510-814-0	06	1	0604-0610				●
13	07.833 WASHER; LK,BACK BAR TO FRAME BUMPER REAR<7HZ> 06.174 ID=14.2	0-91510-814-0	06	1	0604-0610						●
13	07.833 WASHER; LK,BACK BAR TO FRAME BUMPER REAR<7HZ> 05.422 ID=14.2	9-09150-814-0	08	1	0211-0501						●
21	07.070 WASHER; LK,BUMPER G.V.W. 7.0-7.5TON(RPX),G.V.W. 7.5-8.0TON(RPY),G.V.W. 8.0-8.5TON(RPZ) BUMPER REAR<7HZ> FRAME STRAIGHT TYPE<7KJ> 04.634 ID=12.2	9-09150-512-0	08	1	0211-0501				●	●
21	07.070 WASHER; LK,BUMPER G.V.W. 7.5-8.0TON(RPY) BUMPER REAR<7HZ> FRAME STRAIGHT TYPE<7KJ> 04.634 ID=12.2	9-09150-512-0	08	1	0211-0501			●
21	07.070 WASHER; LK,BUMPER G.V.W. 7.0-7.5TON(RPX),G.V.W. 8.0-8.5TON(RPZ) BUMPER REAR<7HZ> FRAME STRAIGHT TYPE<7KJ> 04.634 ID=12.2	9-09150-512-0	08	1	0502-0506				●
21	07.070 WASHER; LK,BUMPER G.V.W. 7.0-7.5TON(RPX),G.V.W. 7.5-8.0TON(RPY),G.V.W. 8.0-8.5TON(RPZ) BUMPER REAR<7HZ> FRAME STRAIGHT TYPE<7KJ> 04.634 ID=12.2	9-09150-512-0	08	1	0507-0603				●
21	07.070 WASHER; LK,BUMPER G.V.W. 7.0-7.5TON(RPX),G.V.W. 7.5-8.0TON(RPY),G.V.W. 8.0-8.5TON(RPZ) BUMPER REAR<7HZ> FRAME STRAIGHT TYPE<7KJ> 03.634 ID=12.2	0-91510-512-0	08	1	0604-				●
133	07.112 HOOK DUMP CHASSIS(V4D) 07.068	8-94249-270-2	01	1	0211-0501	●
133	07.112 HOOK EXC. DUMP CHASSIS(V4D),FRAME STRAIGHTTYPE<7KJ> 07.068	8-94249-270-2	01	1	0211-0501	●
133	07.112 HOOK SINGAPORE EQUIPMENT(S9Y) BUMPER REAR<7HZ> EXC. FRAME STRAIGHT TYPE<7KJ> 07.068	8-94249-270-2	01	1	0211-0501			●	●	●
133	07.112 HOOK RR BODY FLAT BED(RS6) 07.068	8-94249-270-2	01	1	0211-0501				●	●
133	07.112 HOOK EXC. RR BODY FLAT BED(RS6),BUMPER REAR<7HZ>,FRAME STRAIGHT TYPE<7KJ> 07.068	8-94249-270-2	01	1	0211-0501				●	●
133	07.112 HOOK EXC. FRAME STRAIGHT TYPE<7KJ> 07.068	8-94249-270-2	01	1	0211-0501		●
133	07.112 HOOK EXC. BUMPER REAR<7HZ>,FRAME STRAIGHT TYPE<7KJ> 07.068	8-94249-270-2	01	1	0211-0501			●
133	07.112 HOOK 07.068	8-94249-270-2	01	1	0502-0506	●
133	07.112 HOOK SINGAPORE EQUIPMENT(S9Y) BUMPER REAR<7HZ> EXC. RR BODY FLAT BED(RS6),FRAME STRAIGHT TYPE<7KJ> 07.068	8-94249-270-2	01	1	0502-0506				●
133	07.112 HOOK RR BODY FLAT BED(RS6) EXC. FRAME STRAIGHT TYPE<7KJ> 07.068	8-94249-270-2	01	1	0502-0506				●
133	07.112 HOOK EXC. RR BODY FLAT BED(RS6),BUMPER REAR<7HZ>,FRAME STRAIGHT TYPE<7KJ> 07.068	8-94249-270-2	01	1	0502-0506				●
133	07.112 HOOK EXC. FRAME STRAIGHT TYPE<7KJ> 07.068	8-94249-270-2	01	1	0502-0506		●			●
133	07.112 HOOK DUMP CHASSIS(V4D) 07.068	8-94249-270-2	01	1	0507-	●
133	07.112 HOOK EXC. DUMP CHASSIS(V4D),FRAME STRAIGHTTYPE<7KJ> 07.068	8-94249-270-2	01	1	0507-	●
133	07.112 HOOK SINGAPORE EQUIPMENT(S9Y) BUMPER REAR<7HZ> EXC. RR BODY FLAT BED(RS6),FRAME STRAIGHT TYPE<7KJ> 07.068	8-94249-270-2	01	1	0507-				●
133	07.112 HOOK RR BODY FLAT BED(RS6) EXC. FRAME STRAIGHT TYPE<7KJ> 07.068	8-94249-270-2	01	1	0507-				●
133	07.112 HOOK EXC. RR BODY FLAT BED(RS6),BUMPER REAR<7HZ>,FRAME STRAIGHT TYPE<7KJ> 07.068	8-94249-270-2	01	1	0507-				●
133	07.112 HOOK EXC. FRAME STRAIGHT TYPE<7KJ> 07.068	8-94249-270-2	01	1	0507-		●			●
133	07.112 HOOK FRAME STRAIGHT TYPE<7KJ>	8-97122-535-0	01	1	0211-0501	●	●	●	●	●
133	07.112 HOOK FRAME STRAIGHT TYPE<7KJ>	8-97122-535-0	01	1	0502-0506		●		●	●
133	07.112 HOOK FRAME STRAIGHT TYPE<7KJ>	8-97122-535-0	01	1	0507-	●	●		●	●
133	07.112 HOOK	8-97122-535-0	01	1	0507-			●
133	07.112 HOOK 07.330	8-94183-262-0	01	1	0211-						●
134	07.068 BOLT; HOOK EXC. RR BODY FLAT BED(RS6),BUMPER REAR<7HZ> 07.039 M14X50	0-10806-450-0	02	1	0211-0501	●	●	●	●	●
134	07.068 BOLT; HOOK SINGAPORE EQUIPMENT(S9Y) BUMPER REAR<7HZ> EXC. RR BODY FLAT BED(RS6) 07.039 M14X50	0-10806-450-0	02	1	0211-0501			●	●	●
134	07.068 BOLT; HOOK RR BODY FLAT BED(RS6) 07.039 M14X50	0-10806-450-0	02	1	0211-0501				●	●
134	07.068 BOLT; HOOK 07.039 M14X50	0-10806-450-0	02	1	0502-0506	●	●			●
134	07.068 BOLT; HOOK SINGAPORE EQUIPMENT(S9Y) BUMPER REAR<7HZ> EXC. RR BODY FLAT BED(RS6) 07.039 M14X50	0-10806-450-0	02	1	0502-0506				●
134	07.068 BOLT; HOOK RR BODY FLAT BED(RS6) 07.039 M14X50	0-10806-450-0	02	1	0502-0506				●
134	07.068 BOLT; HOOK EXC. RR BODY FLAT BED(RS6),BUMPER REAR<7HZ> 07.039 M14X50	0-10806-450-0	02	1	0502-0506				●
134	07.068 BOLT; HOOK 07.039 M14X50	0-10806-450-0	02	1	0507-0512	●	●	●		●
134	07.068 BOLT; HOOK SINGAPORE EQUIPMENT(S9Y) BUMPER REAR<7HZ> EXC. RR BODY FLAT BED(RS6) 07.039 M14X50	0-10806-450-0	02	1	0507-0512				●
134	07.068 BOLT; HOOK RR BODY FLAT BED(RS6) 07.039 M14X50	0-10806-450-0	02	1	0507-0512				●
134	07.068 BOLT; HOOK EXC. RR BODY FLAT BED(RS6),BUMPER REAR<7HZ> 07.039 M14X50	0-10806-450-0	02	1	0507-0512				●
134	07.068 BOLT; HOOK 07.039 M14X50	0-10856-450-0	02	1	0601-	●	●	●		●
134	07.068 BOLT; HOOK SINGAPORE EQUIPMENT(S9Y) BUMPER REAR<7HZ> EXC. RR BODY FLAT BED(RS6) 07.039 M14X50	0-10856-450-0	02	1	0601-				●
134	07.068 BOLT; HOOK RR BODY FLAT BED(RS6) 07.039 M14X50	0-10856-450-0	02	1	0601-				●
134	07.068 BOLT; HOOK EXC. RR BODY FLAT BED(RS6),BUMPER REAR<7HZ> 07.039 M14X50	0-10856-450-0	02	1	0601-				●
134	07.068 BOLT; HOOK 00.004 M10X45 W/LK WASHER	0-50041-045-0	02	1	0211-0909						●
134	07.068 BOLT; HOOK M10X45 W/LK WASHER	0-50541-045-0	02	1	0910-						●
135	07.068 WASHER; LK,HOOK EXC. RR BODY FLAT BED(RS6),BUMPER REAR<7HZ> 05.422 ID=14.2	9-09150-814-0	02	1	0211-0501	●	●	●	●	●
135	07.068 WASHER; LK,HOOK SINGAPORE EQUIPMENT(S9Y) BUMPER REAR<7HZ> EXC. RR BODY FLAT BED(RS6) 05.422 ID=14.2	9-09150-814-0	02	1	0211-0501			●	●	●
135	07.068 WASHER; LK,HOOK RR BODY FLAT BED(RS6) 05.422 ID=14.2	9-09150-814-0	02	1	0211-0501				●	●
135	07.068 WASHER; LK,HOOK 05.422 ID=14.2	9-09150-814-0	02	1	0502-0506	●	●			●
135	07.068 WASHER; LK,HOOK SINGAPORE EQUIPMENT(S9Y) BUMPER REAR<7HZ> EXC. RR BODY FLAT BED(RS6) 05.422 ID=14.2	9-09150-814-0	02	1	0502-0506				●
135	07.068 WASHER; LK,HOOK RR BODY FLAT BED(RS6) 05.422 ID=14.2	9-09150-814-0	02	1	0502-0506				●
135	07.068 WASHER; LK,HOOK EXC. RR BODY FLAT BED(RS6),BUMPER REAR<7HZ> 05.422 ID=14.2	9-09150-814-0	02	1	0502-0506				●
135	07.068 WASHER; LK,HOOK 05.422 ID=14.2	9-09150-814-0	02	1	0507-0603	●	●	●		●
135	07.068 WASHER; LK,HOOK SINGAPORE EQUIPMENT(S9Y) BUMPER REAR<7HZ> EXC. RR BODY FLAT BED(RS6) 05.422 ID=14.2	9-09150-814-0	02	1	0507-0603				●
135	07.068 WASHER; LK,HOOK RR BODY FLAT BED(RS6) 05.422 ID=14.2	9-09150-814-0	02	1	0507-0603				●
135	07.068 WASHER; LK,HOOK EXC. RR BODY FLAT BED(RS6),BUMPER REAR<7HZ> 05.422 ID=14.2	9-09150-814-0	02	1	0507-0603				●
135	07.068 WASHER; LK,HOOK 06.174 ID=14.2	0-91510-814-0	02	1	0604-0610	●	●	●		●
135	07.068 WASHER; LK,HOOK SINGAPORE EQUIPMENT(S9Y) BUMPER REAR<7HZ> EXC. RR BODY FLAT BED(RS6) 06.174 ID=14.2	0-91510-814-0	02	1	0604-0610				●
135	07.068 WASHER; LK,HOOK RR BODY FLAT BED(RS6) 06.174 ID=14.2	0-91510-814-0	02	1	0604-0610				●
135	07.068 WASHER; LK,HOOK EXC. RR BODY FLAT BED(RS6),BUMPER REAR<7HZ> 06.174 ID=14.2	0-91510-814-0	02	1	0604-0610				●
136	07.068 NUT; HOOK EXC. RR BODY FLAT BED(RS6),BUMPER REAR<7HZ> 07.529 M14	9-99110-514-0	02	1	0211-0501	●	●	●	●	●
136	07.068 NUT; HOOK SINGAPORE EQUIPMENT(S9Y) BUMPER REAR<7HZ> EXC. RR BODY FLAT BED(RS6) 07.529 M14	9-99110-514-0	02	1	0211-0501			●	●	●
136	07.068 NUT; HOOK RR BODY FLAT BED(RS6) 07.529 M14	9-99110-514-0	02	1	0211-0501				●	●
136	07.068 NUT; HOOK 07.529 M14	9-99110-514-0	02	1	0502-0506	●	●			●
136	07.068 NUT; HOOK SINGAPORE EQUIPMENT(S9Y) BUMPER REAR<7HZ> EXC. RR BODY FLAT BED(RS6) 07.529 M14	9-99110-514-0	02	1	0502-0506				●
136	07.068 NUT; HOOK RR BODY FLAT BED(RS6) 07.529 M14	9-99110-514-0	02	1	0502-0506				●
136	07.068 NUT; HOOK EXC. RR BODY FLAT BED(RS6),BUMPER REAR<7HZ> 07.529 M14	9-99110-514-0	02	1	0502-0506				●
136	07.068 NUT; HOOK 07.529 M14	9-99110-514-0	02	1	0507-0512	●	●	●		●
136	07.068 NUT; HOOK SINGAPORE EQUIPMENT(S9Y) BUMPER REAR<7HZ> EXC. RR BODY FLAT BED(RS6) 07.529 M14	9-99110-514-0	02	1	0507-0512				●
136	07.068 NUT; HOOK RR BODY FLAT BED(RS6) 07.529 M14	9-99110-514-0	02	1	0507-0512				●
136	07.068 NUT; HOOK EXC. RR BODY FLAT BED(RS6),BUMPER REAR<7HZ> 07.529 M14	9-99110-514-0	02	1	0507-0512				●
136	07.068 NUT; HOOK 07.833 M14	0-91110-514-0	02	1	0601-0610	●	●	●		●
136	07.068 NUT; HOOK SINGAPORE EQUIPMENT(S9Y) BUMPER REAR<7HZ> EXC. RR BODY FLAT BED(RS6) 07.833 M14	0-91110-514-0	02	1	0601-0610				●
136	07.068 NUT; HOOK RR BODY FLAT BED(RS6) 07.833 M14	0-91110-514-0	02	1	0601-0610				●
136	07.068 NUT; HOOK EXC. RR BODY FLAT BED(RS6),BUMPER REAR<7HZ> 07.833 M14	0-91110-514-0	02	1	0601-0610				●
136	07.068 NUT; HOOK 00.429 M14 FLANGE	0-91180-214-0	02	1	0611-	●	●	●		●
136	07.068 NUT; HOOK SINGAPORE EQUIPMENT(S9Y) BUMPER REAR<7HZ> EXC. RR BODY FLAT BED(RS6) 00.429 M14 FLANGE	0-91180-214-0	02	1	0611-				●
136	07.068 NUT; HOOK RR BODY FLAT BED(RS6) 00.429 M14 FLANGE	0-91180-214-0	02	1	0611-				●
136	07.068 NUT; HOOK EXC. RR BODY FLAT BED(RS6),BUMPER REAR<7HZ> 00.429 M14 FLANGE	0-91180-214-0	02	1	0611-				●
136	07.068 NUT; HOOK 00.002 M10	9-09110-510-0	02	1	0211-0512						●
136	07.068 NUT; HOOK 00.833 M10	0-91110-510-0	02	1	0601-						●
158	07.629 WASHER; PL,HOOK SPACER DUMP CHASSIS(V4D) 06.164 ID=15 OD=30	9-09164-614-0	02	1	0211-	●
306	07.836 BAR; BACK,RR G.V.W. 4.0-4.5TON(RPR),G.V.W. 6.0-6.5TON(RPV) BUMPER REAR<7HZ> (A) STAMP BL	8-97128-333-0	01	1	0211-0501				●
306	07.836 BAR; BACK,RR G.V.W. 6.0-6.5TON(RPV) BUMPER REAR<7HZ> (A) STAMP BL	8-97128-333-0	01	1	0211-0501			●		●
306	07.836 BAR; BACK,RR G.V.W. 6.0-6.5TON(RPV) BUMPER REAR<7HZ> (A) STAMP BL	8-97128-333-0	01	1	0502-0503				●
306	07.836 BAR; BACK,RR G.V.W. 6.0-6.5TON(RPV) BUMPER REAR<7HZ> (A) STAMP IA2	8-98000-171-0	01	1	0504-0506				●
306	07.836 BAR; BACK,RR G.V.W. 4.0-4.5TON(RPR),G.V.W. 6.0-6.5TON(RPV) BUMPER REAR<7HZ> (A) STAMP IA2	8-98000-171-0	01	1	0507-				●
306	07.836 BAR; BACK,RR G.V.W. 4.0-4.5TON(RPR),G.V.W. 6.0-6.5TON(RPV) BUMPER REAR<7HZ> (A) STAMP BR	8-97128-334-0	01	1	0211-0501				●
306	07.836 BAR; BACK,RR G.V.W. 6.0-6.5TON(RPV) BUMPER REAR<7HZ> (A) STAMP BR	8-97128-334-0	01	1	0211-0501			●		●
306	07.836 BAR; BACK,RR G.V.W. 6.0-6.5TON(RPV) BUMPER REAR<7HZ> (A) STAMP BR	8-97128-334-0	01	1	0502-0503				●
306	07.836 BAR; BACK,RR G.V.W. 6.0-6.5TON(RPV) BUMPER REAR<7HZ> (A) STAMP IA2	8-98000-172-0	01	1	0504-0506				●
306	07.836 BAR; BACK,RR G.V.W. 4.0-4.5TON(RPR),G.V.W. 6.0-6.5TON(RPV) BUMPER REAR<7HZ> (A) STAMP IA2	8-98000-172-0	01	1	0507-				●
306	07.836 BAR; BACK,RR G.V.W. 7.0-7.5TON(RPX),G.V.W. 7.5-8.0TON(RPY),G.V.W. 8.0-8.5TON(RPZ) BUMPER REAR<7HZ> FRAME STRAIGHT TYPE<7KJ> (B) STAMP IA	8-97138-361-1	01	1	0211-0501				●	●
306	07.836 BAR; BACK,RR G.V.W. 7.5-8.0TON(RPY) BUMPER REAR<7HZ> FRAME STRAIGHT TYPE<7KJ> (B) STAMP IA	8-97138-361-1	01	1	0211-0501			●
306	07.836 BAR; BACK,RR G.V.W. 7.0-7.5TON(RPX),G.V.W. 8.0-8.5TON(RPZ) BUMPER REAR<7HZ> FRAME STRAIGHT TYPE<7KJ> (B) STAMP IA	8-97138-361-1	01	1	0502-0503				●
306	07.836 BAR; BACK,RR G.V.W. 7.0-7.5TON(RPX),G.V.W. 8.0-8.5TON(RPZ) BUMPER REAR<7HZ> FRAME STRAIGHT TYPE<7KJ> (B) STAMP IA3	8-98000-173-0	01	1	0504-0506				●
306	07.836 BAR; BACK,RR G.V.W. 7.0-7.5TON(RPX),G.V.W. 7.5-8.0TON(RPY),G.V.W. 8.0-8.5TON(RPZ) BUMPER REAR<7HZ> FRAME STRAIGHT TYPE<7KJ> (B) STAMP IA3	8-98000-173-0	01	1	0507-				●
306	07.836 BAR; BACK,RR G.V.W. 7.0-7.5TON(RPX),G.V.W. 7.5-8.0TON(RPY),G.V.W. 8.0-8.5TON(RPZ) BUMPER REAR<7HZ> FRAME STRAIGHT TYPE<7KJ> (B) STAMP IA	8-97138-362-1	01	1	0211-0501				●	●
306	07.836 BAR; BACK,RR G.V.W. 7.5-8.0TON(RPY) BUMPER REAR<7HZ> FRAME STRAIGHT TYPE<7KJ> (B) STAMP IA	8-97138-362-1	01	1	0211-0501			●
306	07.836 BAR; BACK,RR G.V.W. 7.0-7.5TON(RPX),G.V.W. 8.0-8.5TON(RPZ) BUMPER REAR<7HZ> FRAME STRAIGHT TYPE<7KJ> (B) STAMP IA	8-97138-362-1	01	1	0502-0503				●
306	07.836 BAR; BACK,RR G.V.W. 7.0-7.5TON(RPX),G.V.W. 8.0-8.5TON(RPZ) BUMPER REAR<7HZ> FRAME STRAIGHT TYPE<7KJ> (B) STAMP IA3	8-98000-174-0	01	1	0504-0506				●
306	07.836 BAR; BACK,RR G.V.W. 7.0-7.5TON(RPX),G.V.W. 7.5-8.0TON(RPY),G.V.W. 8.0-8.5TON(RPZ) BUMPER REAR<7HZ> FRAME STRAIGHT TYPE<7KJ> (B) STAMP IA3	8-98000-174-0	01	1	0507-				●
306	07.836 BAR; BACK,RR BUMPER REAR<7HZ> (A) STAMP AL	8-97128-331-0	01	1	0211-0503						●
306	07.836 BAR; BACK,RR BUMPER REAR<7HZ> (A) STAMP IA1	8-98000-169-0	01	1	0504-0603						●
306	07.836 BAR; BACK,RR BUMPER REAR<7HZ> (A) STAMP IA1	8-98039-406-0	01	1	0604-						●
306	07.836 BAR; BACK,RR BUMPER REAR<7HZ> (A) STAMP AR	8-97128-332-0	01	1	0211-0503						●
306	07.836 BAR; BACK,RR BUMPER REAR<7HZ> (A) STAMP IA1	8-98000-170-0	01	1	0504-0603						●
306	07.836 BAR; BACK,RR BUMPER REAR<7HZ> (A) STAMP IA1	8-98039-407-0	01	1	0604-						●
315	07.829 RIVET; CAP G.V.W. 6.0-6.5TON(RPV) BUMPER REAR<7HZ> 08.155 D8X13.5	1-09987-248-1	04	1	0504-0506				●
315	07.829 RIVET; CAP BUMPER REAR<7HZ> 08.155 D8X13.5	1-09987-248-1	04	1	0504-0506						●
315	07.829 RIVET; CAP G.V.W. 4.0-4.5TON(RPR),G.V.W. 6.0-6.5TON(RPV) BUMPER REAR<7HZ> 08.155 D8X13.5	1-09987-248-1	04	1	0507-				●
315	07.829 RIVET; CAP BUMPER REAR<7HZ> 08.155 D8X13.5	1-09987-248-1	04	1	0507-						●
315	07.829 RIVET; CAP G.V.W. 7.0-7.5TON(RPX),G.V.W. 7.5-8.0TON(RPY),G.V.W. 8.0-8.5TON(RPZ) BUMPER REAR<7HZ> FRAME STRAIGHT TYPE<7KJ> PUSH RIVET BLACK	1-71290-041-0	04	1	0211-0501				●	●
315	07.829 RIVET; CAP G.V.W. 7.5-8.0TON(RPY) BUMPER REAR<7HZ> FRAME STRAIGHT TYPE<7KJ> PUSH RIVET BLACK	1-71290-041-0	04	1	0211-0501			●
315	07.829 RIVET; CAP G.V.W. 7.0-7.5TON(RPX),G.V.W. 8.0-8.5TON(RPZ) BUMPER REAR<7HZ> FRAME STRAIGHT TYPE<7KJ> PUSH RIVET BLACK	1-71290-041-0	04	1	0502-0506				●
315	07.829 RIVET; CAP G.V.W. 7.0-7.5TON(RPX),G.V.W. 7.5-8.0TON(RPY),G.V.W. 8.0-8.5TON(RPZ) BUMPER REAR<7HZ> FRAME STRAIGHT TYPE<7KJ> PUSH RIVET BLACK	1-71290-041-0	04	1	0507-				●
317	07.800 PLATE; BUMPER SIDE G.V.W. 7.0-7.5TON(RPX),G.V.W. 7.5-8.0TON(RPY),G.V.W. 8.0-8.5TON(RPZ) BUMPER REAR<7HZ> FRAME STRAIGHT TYPE<7KJ>	1-71290-053-0	04	1	0211-0501				●	●
317	07.800 PLATE; BUMPER SIDE G.V.W. 7.5-8.0TON(RPY) BUMPER REAR<7HZ> FRAME STRAIGHT TYPE<7KJ>	1-71290-053-0	04	1	0211-0501			●
317	07.800 PLATE; BUMPER SIDE G.V.W. 7.0-7.5TON(RPX),G.V.W. 8.0-8.5TON(RPZ) BUMPER REAR<7HZ> FRAME STRAIGHT TYPE<7KJ>	1-71290-053-0	04	1	0502-0506				●
317	07.800 PLATE; BUMPER SIDE G.V.W. 7.0-7.5TON(RPX),G.V.W. 7.5-8.0TON(RPY),G.V.W. 8.0-8.5TON(RPZ) BUMPER REAR<7HZ> FRAME STRAIGHT TYPE<7KJ>	1-71290-053-0	04	1	0507-				●
336	07.070 PIN; SPRING G.V.W. 7.0-7.5TON(RPX),G.V.W. 7.5-8.0TON(RPY),G.V.W. 8.0-8.5TON(RPZ) BUMPER REAR<7HZ> FRAME STRAIGHT TYPE<7KJ>	1-71290-054-0	04	1	0211-0501				●	●
336	07.070 PIN; SPRING G.V.W. 7.5-8.0TON(RPY) BUMPER REAR<7HZ> FRAME STRAIGHT TYPE<7KJ>	1-71290-054-0	04	1	0211-0501			●
336	07.070 PIN; SPRING G.V.W. 7.0-7.5TON(RPX),G.V.W. 8.0-8.5TON(RPZ) BUMPER REAR<7HZ> FRAME STRAIGHT TYPE<7KJ>	1-71290-054-0	04	1	0502-0506				●
336	07.070 PIN; SPRING G.V.W. 7.0-7.5TON(RPX),G.V.W. 7.5-8.0TON(RPY),G.V.W. 8.0-8.5TON(RPZ) BUMPER REAR<7HZ> FRAME STRAIGHT TYPE<7KJ>	1-71290-054-0	04	1	0507-				●

İpucu: çizimdeki balona veya tablodaki Balon sütununa tıkla; ilgili parçalar vurgulanır. Birden çok çizim varsa üstteki seçim kutusu/oklarla gezin.
