Isuzu WW
▶
SUV
▶
UCS
▶
50892 - UCS(THAILAND)
▶
6 - Exterior Body, Glass Mounting, Door Trim, Molding
▶
6-01 - FRONT BUMPER
▶
6-01 — FRONT BUMPER
(#17703) — 16 parça
136
84
301
46
42
42
30
42
160
296
42
39
202
1
64
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
1
BUMPER ASM; FRT
PRIMER THA
8-97920-251-1
01
1
0009-
30
BRACKET; FRT BUMPER
THA
8-97940-785-1
01
1
0009-
30
BRACKET; FRT BUMPER
THA
8-97940-784-1
01
1
0009-
39
BOLT; BUMPER TO BODY
M12X30 FLANGE
0-28691-230-0
04
1
0009-
42
BOLT; BUMPER
(A) M8X14 FLANGE THA
0-28080-814-0
12
1
0009-
42
BOLT; BUMPER
(B) M8X20 W/LK&PL WASHER
0-50140-820-0
04
1
0009-
42
BOLT; BUMPER
(C) M6X16 FLANGE
8-97804-671-1
11
1
0009-
46
REINFORCEMENT; BUMPER
THA
8-97940-777-3
01
1
0009-
64
NUT; CLIP
8-94342-576-1
02
1
0009-
84
HOOK
8-97041-464-2
01
1
0009-
136
WASHER; PL,HOOK
ID=12.5
1-09503-021-0
01
1
0009-
160
SCREW
M5X16
8-94380-268-0
04
1
0009-
202
BRACKET; BUMPER SIDE
THA
8-97940-772-2
01
1
0009-
202
BRACKET; BUMPER SIDE
THA
8-97940-771-2
01
1
0009-
296
BOLT; LICENSE PLATE,FRT
M6X16 FLANGE
0-28080-616-0
02
1
0009-
301
BOLT; HOOK TO FRAME
M10X60
0-28091-060-0
02
1
0009-
Seçili parçaları sepete ekle
İpucu: çizimdeki balona veya tablodaki
Balon
sütununa tıkla; ilgili parçalar vurgulanır. Birden çok çizim varsa üstteki seçim kutusu/oklarla gezin.
