1 |
LAMP ASM; RR COMB
|
1-82230-208-0 |
01 |
1 |
1512- |
| |
1 |
LAMP ASM; RR COMB
|
1-82230-209-0 |
01 |
1 |
1512- |
| |
3 |
GASKET; RR COMB LAMP
|
8-94257-505-0 |
02 |
1 |
1512- |
| |
5 |
BULB; RR COMB LAMP
(A)
24V 21W
|
1-82194-036-0 |
04 |
1 |
1512- |
| |
5 |
BULB; RR COMB LAMP
(B)
24V 21/5W
|
1-82194-038-0 |
02 |
1 |
1512- |
| |
9 |
NUT; LAMP,RR COMB
M6
|
0-91110-506-0 |
04 |
1 |
1512- |
| |
11 |
WASHER; PL,LAMP,RR COMB
ID=6.4 OD=18
|
0-91610-706-0 |
04 |
1 |
1512- |
| |
13 |
LENS; TURN SIGNAL
|
8-94174-639-0 |
01 |
1 |
1512- |
| |
13 |
LENS; TURN SIGNAL
|
8-94174-638-0 |
01 |
1 |
1512- |
| |
14 |
LENS; TAIL & STOP,RR COMB LAMP
|
8-94178-625-0 |
01 |
1 |
1512- |
| |
14 |
LENS; TAIL & STOP,RR COMB LAMP
|
8-94178-624-0 |
01 |
1 |
1512- |
| |
15 |
SCREW; RR COMB LAMP
M4X20 TAPPING STAINLESS
|
0-71190-420-0 |
16 |
1 |
1512- |
| |
22 |
LENS; BACKUP,RR COMB LAMP
CLEAR
|
8-94257-512-1 |
02 |
1 |
1512- |
| |
24 |
GASKET; BACK,LAMP
|
8-94257-506-0 |
02 |
1 |
1512- |
| |
25 |
HORN ASM; BACK
|
8-94257-518-0 |
01 |
1 |
1512- |
| |
26 |
SCREW; BACK HORN
M4X14 TAPPING
|
9-07076-414-0 |
01 |
1 |
1512- |
| |
26 |
SCREW; BACK HORN
M4X12 TAPPING
|
9-07076-412-0 |
02 |
1 |
1512- |
| |
28 |
GASKET; TURN,LAMP
|
8-94257-507-0 |
02 |
1 |
1512- |
| |
29 |
BRACKET; LAMP,RR COMB
LIGHTING SYSTEM ECE<SLC>
(A)
|
8-98153-159-0 |
01 |
1 |
1512- |
| |
29 |
BRACKET; LAMP,RR COMB
LIGHTING SYSTEM ECE<SLC>
(C)
|
8-98162-777-0 |
02 |
1 |
1512- |
| |
29 |
BRACKET; LAMP,RR COMB
EXC. LIGHTING SYSTEM ECE<SLC>
(B)
|
1-53487-021-1 |
01 |
1 |
1512- |
| |
30 |
NUT; BRKT,RR COMB
(A)
M10 FLANGE
|
0-91180-210-0 |
02 |
1 |
1512- |
| |
30 |
NUT; BRKT,RR COMB
LIGHTING SYSTEM ECE<SLC>
(B)
M6
|
0-91110-506-0 |
04 |
1 |
1512- |
| |
36 |
BOLT; BRKT,RR COMB
LIGHTING SYSTEM ECE<SLC>
(B)
M6X70 FLANGE
|
0-28050-670-0 |
04 |
1 |
1512- |
| |
36 |
BOLT; BRKT,RR COMB
LIGHTING SYSTEM ECE<SLC>
(A)
M10X70 FLANGE
|
0-28051-070-0 |
02 |
1 |
1512- |
| |
36 |
BOLT; BRKT,RR COMB
EXC. RUSSIA EQUIPMENT(B12)
(C)
M10X40 FLANGE
|
0-28651-040-0 |
02 |
1 |
1512- |
| |
37 |
COVER; RR COMB LAMP
|
1-82239-008-0 |
01 |
1 |
1512- |
| |
37 |
COVER; RR COMB LAMP
|
1-82239-007-0 |
01 |
1 |
1512- |
| |
38 |
BOLT; LAMP,RR COMB
M6X30 W/LK&PL WASHER
|
0-50640-630-0 |
04 |
1 |
1512- |
| |
49 |
LAMP; LICENSE PLATE
24V 5W
|
8-98329-430-0 |
02 |
1 |
1512- |
| |
50 |
LENS; LICENSE PLATE LAMP
|
8-97108-212-0 |
02 |
1 |
1512- |
| |
51 |
BULB; LICENSE PLATE LAMP
24V 5W
|
1-82194-039-0 |
02 |
1 |
1512- |
| |
54 |
SCREW; LICENSE PLATE LAMP
M4X8
|
8-94419-312-0 |
02 |
1 |
1512- |
| |
58 |
COVER; LICENSE PLATE LAMP
|
8-97076-590-1 |
02 |
1 |
1512- |
| |
113 |
WASHER; PL,BRKT,RR COMB
LIGHTING SYSTEM ECE<SLC>
ID=6.4 OD=18
|
0-91610-706-0 |
04 |
1 |
1512- |
| |
114 |
BRACKET; RR FOG LAMP
RUSSIA EQUIPMENT(B12)
|
8-97108-583-0 |
01 |
1 |
1512- |
| |
148 |
LAMP ASM; RR FOG
RUSSIA EQUIPMENT(B12)
|
1-82110-477-0 |
01 |
1 |
1512- |
| |
149 |
SCREW; BRKT TO LAMP BODY
RUSSIA EQUIPMENT(B12)
|
8-94336-372-0 |
02 |
1 |
1512- |
| |
150 |
NUT; RR FOG LAMP
RUSSIA EQUIPMENT(B12)
M6
|
0-91110-506-0 |
01 |
1 |
1512- |
| |
153 |
BOLT; LICENSE PLATE LAMP
M5X20
|
9-93490-520-0 |
04 |
1 |
1512- |
| |
195 |
LAMP UNIT; RR FOG
RUSSIA EQUIPMENT(B12)
|
8-94336-322-0 |
01 |
1 |
1512- |
| |
196 |
LENS; RR FOG LAMP
RUSSIA EQUIPMENT(B12)
|
8-94336-325-0 |
01 |
1 |
1512- |
| |
197 |
GASKET; RR FOG LAMP
RUSSIA EQUIPMENT(B12)
|
8-94336-324-0 |
01 |
1 |
1512- |
| |
198 |
SCREW; LENS TO BODY
RUSSIA EQUIPMENT(B12)
|
0-71190-416-0 |
02 |
1 |
1512- |
| |
199 |
WASHER; LENS,RR FOG LAMP
RUSSIA EQUIPMENT(B12)
|
8-94336-326-0 |
02 |
1 |
1512- |
| |
200 |
PLATE; SET,RR FOG LAMP
RUSSIA EQUIPMENT(B12)
|
8-94336-323-0 |
01 |
1 |
1512- |
| |
201 |
BULB; RR FOG LAMP
RUSSIA EQUIPMENT(B12)
24V 21W
|
1-82194-036-0 |
01 |
1 |
1512- |
| |
211 |
HARNESS; EXT
|
8-98131-066-0 |
01 |
1 |
1512- |
| |
213 |
WASHER; PL,RR FOG LAMP
RUSSIA EQUIPMENT(B12)
ID=6.4 OD=18
|
0-91610-706-0 |
01 |
1 |
1512- |
| |
214 |
BOLT; RR FOG LAMP
RUSSIA EQUIPMENT(B12)
M6X70 FLANGE
|
0-28050-670-0 |
01 |
1 |
1512- |
