Isuzu WW
▶
TRUCKS
▶
FXZ
▶
11662 - FXZ/GXZ LHD CHINA
▶
6 - Exterior Body, Glass Mounting, Door Trim, Molding
▶
6-90 - REAR BUMPER
▶
6-90 — REAR BUMPER
(#175091) — 23 parça
Tümü
A - FGZ6MX
B - GGZ6MX
21
10
2
117
136
135
117
3
12
12
134
134
133
113
114
291
290
2
291
290
1
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
A
B
1
BUMPER; RR
STAMP B2L
1-71220-076-1
01
1
1509-
●
2
BOLT; BACK BAR
(A) M12X30 FLANGE
0-28081-230-0
08
1
1509-
●
2
BOLT; BACK BAR
(B) M16X40
0-20801-640-0
12
1
1509-
●
3
BRACKET; BUMPER
STAMP BU
1-71230-254-1
01
1
1509-
●
3
BRACKET; BUMPER
STAMP BU
1-71230-255-1
01
1
1509-
●
4
BOLT; BUMPER
M6X20
1-87223-636-0
08
1
1509-
●
9
NUT; BUMPER
M6
0-91110-506-0
08
1
1509-
●
10
WASHER; PL,BRKT
ID=12.5 OD=26
9-09160-612-0
08
1
1509-
●
12
NUT; BRKT
(A) M12
9-99110-512-0
08
1
1509-
●
12
NUT; BRKT
(B) M16
9-99110-516-0
12
1
1509-
●
21
WASHER; LK,BUMPER
ID=12.2
9-09150-512-0
08
1
1509-
●
21
WASHER; LK,BUMPER
ID=16.2
9-09150-816-0
12
1
1509-
●
113
BRACKET; LICENSE PLATE
8-98090-218-1
01
1
1509-
●
●
114
BOLT; BRKT,LICENSE PLATE
M8X25 FLANGE
0-28650-825-0
02
1
1509-
●
●
117
NUT; BRKT
(B) M10
0-91110-510-0
04
1
1509-
●
117
NUT; BRKT
(A) M8 FLANGE
0-91180-108-0
02
1
1509-
●
●
133
HOOK
1-57181-027-1
01
1
1509-
●
134
BOLT; HOOK
M16X70
0-10861-670-0
01
1
1509-
●
134
BOLT; HOOK
M16X50
0-20851-650-0
01
1
1509-
●
135
WASHER; LK,HOOK
ID=16.2
0-91510-516-0
02
1
1509-
●
136
NUT; HOOK
M16
0-91110-516-0
02
1
1509-
●
290
COVER; RR
1-71290-040-0
02
1
1509-
●
291
RIVET; REFLECTOR
PUSH RIVET BLACK
1-71290-041-0
06
1
1509-
●
Seçili parçaları sepete ekle
İpucu: çizimdeki balona veya tablodaki
Balon
sütununa tıkla; ilgili parçalar vurgulanır. Birden çok çizim varsa üstteki seçim kutusu/oklarla gezin.
