Sayfa 1-41 - Isuzu EPC

1-41 — FUEL PIPING; CHASSIS (#17494) — 849 parça

634 47 67 67 174

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date
47	PIPE; FUEL,RETURN 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) (A) L=539	8-98117-709-0	01	1	1206-1212
47	PIPE; FUEL,RETURN 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) EXC. BIO DIESEL FUEL B10<8NV> (A) L=539	8-98117-709-0	01	1	1301-
47	PIPE; FUEL,RETURN (A) L=688	8-98129-921-0	01	1	1109-1205
47	PIPE; FUEL,RETURN 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) (A) L=688	8-98129-921-0	01	1	1206-1212
47	PIPE; FUEL,RETURN EXC. COLOMBIA EQUIPMENT(CB7) (A) L=688	8-98129-921-0	01	1	1206-1212
47	PIPE; FUEL,RETURN 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) (A) L=688	8-98129-921-0	01	1	1301-
47	PIPE; FUEL,RETURN 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) BIO DIESEL FUEL B10<8NV> (A) L=688	8-98129-921-0	01	1	1301-
47	PIPE; FUEL,RETURN EXC. COLOMBIA EQUIPMENT(CB7) (A) L=688	8-98129-921-0	01	1	1301-
47	PIPE; FUEL,RETURN 6HK1-TCS ENG(80L) (B) L=787	8-98127-647-0	01	1	1109-
67	HOSE; FUEL,DELIVERY FUEL TANK 200L FRAME SIDE<N20> (C) L=710	8-98186-527-0	01	1	1109-1205
67	HOSE; FUEL,DELIVERY 6HK1-TCS ENG(80L) WHEEL BASE 3900MM(39W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> (C) L=710	8-98186-527-0	01	1	1206-1212
67	HOSE; FUEL,DELIVERY FUEL TANK 200L FRAME SIDE<N20> EXC. COLOMBIA EQUIPMENT(CB7) (C) L=710	8-98186-527-0	01	1	1206-1212
67	HOSE; FUEL,DELIVERY 6HK1-TCS ENG(80L) WHEEL BASE 3900MM(39W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> EXC. BIO DIESEL FUEL B10<8NV> (C) L=710	8-98186-527-0	01	1	1301-
67	HOSE; FUEL,DELIVERY FUEL TANK 200L FRAME SIDE<N20> EXC. COLOMBIA EQUIPMENT(CB7) (C) L=710	8-98186-527-0	01	1	1301-
67	HOSE; FUEL,DELIVERY FUEL TANK 200L FRAME SIDE<N20> (D) L=1380	8-98186-528-0	01	1	1109-1205
67	HOSE; FUEL,DELIVERY 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> (D) L=1380	8-98186-528-0	01	1	1206-1212
67	HOSE; FUEL,DELIVERY FUEL TANK 200L FRAME SIDE<N20> EXC. COLOMBIA EQUIPMENT(CB7) (D) L=1380	8-98186-528-0	01	1	1206-1212
67	HOSE; FUEL,DELIVERY 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> EXC. BIO DIESEL FUEL B10<8NV> (D) L=1380	8-98186-528-0	01	1	1301-
67	HOSE; FUEL,DELIVERY FUEL TANK 200L FRAME SIDE<N20> EXC. COLOMBIA EQUIPMENT(CB7) (D) L=1380	8-98186-528-0	01	1	1301-
67	HOSE; FUEL,DELIVERY FUEL TANK 400L<SDH> (C) L=980 SERVICED BY L=3000	0-01260-300-0	01	1	1109-1205
67	HOSE; FUEL,DELIVERY COLOMBIA EQUIPMENT(CB7) FUEL TANK 400L<SDH> (C) L=920 SERVICED BY L=3000	0-01260-300-0	01	1	1206-1212
67	HOSE; FUEL,DELIVERY COLOMBIA EQUIPMENT(CB7) FUEL TANK 400L<SDH> EXC. BIO DIESEL FUEL B10<8NV> (C) L=920 SERVICED BY L=3000	0-01260-300-0	01	1	1301-
67	HOSE; FUEL,DELIVERY FUEL TANK 400L<SDH> (C) L=1600 SERVICED BY L=3000	0-01260-300-0	01	1	1109-1212
67	HOSE; FUEL,DELIVERY FUEL TANK 400L<SDH> EXC. BIO DIESEL FUEL B10<8NV> (C) L=1600 SERVICED BY L=3000	0-01260-300-0	01	1	1301-
67	HOSE; FUEL,DELIVERY (C) L=110 SERVICED BY L=3000	0-01260-300-0	01	1	1109-1212
67	HOSE; FUEL,DELIVERY EXC. BIO DIESEL FUEL B10<8NV> (C) L=110 SERVICED BY L=3000	0-01260-300-0	01	1	1301-
67	HOSE; FUEL,DELIVERY (B) L=210 SERVICED BY L=3000	0-01558-300-0	01	1	1109-
67	HOSE; FUEL,DELIVERY FUEL TANK 400L<SDH> EXC. COLOMBIA EQUIPMENT(CB7) (C) L=980 SERVICED BY L=3000	0-01260-300-0	01	1	1206-
67	HOSE; FUEL,DELIVERY 6HK1-TCS ENG(80L) WHEEL BASE 5500MM(55W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> (C) L=730	8-98205-834-0	01	1	1206-1212
67	HOSE; FUEL,DELIVERY 6HK1-TCS ENG(80L) WHEEL BASE 5000MM(50W),WHEEL BASE 5500MM(55W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> EXC. BIO DIESEL FUEL B10<8NV> (C) L=730	8-98205-834-0	01	1	1301-
67	HOSE; FUEL,DELIVERY 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) (E) L=300	8-98157-878-0	01	1	1206-1212
67	HOSE; FUEL,DELIVERY 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) EXC. BIO DIESEL FUEL B10<8NV> (E) L=300	8-98157-878-0	01	1	1301-
67	HOSE; FUEL,DELIVERY 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> (F) L=900	8-98157-879-0	01	1	1206-1212
67	HOSE; FUEL,DELIVERY 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> EXC. BIO DIESEL FUEL B10<8NV> (F) L=900	8-98157-879-0	01	1	1301-
67	HOSE; FUEL,DELIVERY COLOMBIA EQUIPMENT(CB7) FUEL TANK 400L<SDH> BIO DIESEL FUEL B10<8NV> (D) L=1620	8-98232-241-0	01	1	1301-
67	HOSE; FUEL,DELIVERY COLOMBIA EQUIPMENT(CB7) FUEL TANK 400L<SDH> BIO DIESEL FUEL B10<8NV> (C) L=920	8-98232-244-0	01	1	1301-
67	HOSE; FUEL,DELIVERY WHEEL BASE 5000MM(50W),WHEEL BASE 5500MM(55W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> (C) L=730	8-98232-243-0	01	1	1301-
67	HOSE; FUEL,DELIVERY BIO DIESEL FUEL B10<8NV> (A) L=110 SERVICED BY L=3000	0-01859-300-0	01	1	1301-
67	HOSE; FUEL,DELIVERY COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> (D) L=1380	8-98232-240-0	01	1	1301-1304
67	HOSE; FUEL,DELIVERY WHEEL BASE 5000MM(50W),WHEEL BASE 5500MM(55W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> (D) L=1380	8-98232-240-0	01	1	1305-
67	HOSE; FUEL,DELIVERY 6HK1-TCS ENG(80L) WHEEL BASE 3900MM(39W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> (C)	8-98232-911-0	01	1	1301-1304
67	HOSE; FUEL,DELIVERY WHEEL BASE 3900MM(39W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> (C)	8-98238-196-0	01	1	1305-
67	HOSE; FUEL,DELIVERY WHEEL BASE 3900MM(39W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> (D)	8-98238-197-0	01	1	1305-
174	PIPE; FUEL,FEED,FRT 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) L=548	8-98117-708-0	01	1	1206-1212
174	PIPE; FUEL,FEED,FRT 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) EXC. BIO DIESEL FUEL B10<8NV> L=548	8-98117-708-0	01	1	1301-
174	PIPE; FUEL,FEED,FRT L=685	8-98129-920-0	01	1	1109-1205
174	PIPE; FUEL,FEED,FRT 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) L=685	8-98129-920-0	01	1	1206-1212
174	PIPE; FUEL,FEED,FRT EXC. COLOMBIA EQUIPMENT(CB7) L=685	8-98129-920-0	01	1	1206-1212
174	PIPE; FUEL,FEED,FRT 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) L=685	8-98129-920-0	01	1	1301-
174	PIPE; FUEL,FEED,FRT 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) BIO DIESEL FUEL B10<8NV> L=685	8-98129-920-0	01	1	1301-
174	PIPE; FUEL,FEED,FRT EXC. COLOMBIA EQUIPMENT(CB7) L=685	8-98129-920-0	01	1	1301-
634	HOSE; RUBBER RETURN 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) L=1050	8-98128-212-0	01	1	1206-1212
634	HOSE; RUBBER RETURN 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) EXC. BIO DIESEL FUEL B10<8NV> L=1050	8-98128-212-0	01	1	1301-
634	HOSE; RUBBER RETURN 6HK1-TCN ENG(82L) FUEL TANK 200L FRAME SIDE<N20> L=810	8-98186-973-0	01	1	1109-1205
634	HOSE; RUBBER RETURN 6HK1-TCN ENG(82L) FUEL TANK 200L FRAME SIDE<N20> EXC. COLOMBIA EQUIPMENT(CB7) L=810	8-98186-973-0	01	1	1206-1212
634	HOSE; RUBBER RETURN 6HK1-TCN ENG(82L) FUEL TANK 200L FRAME SIDE<N20> EXC. COLOMBIA EQUIPMENT(CB7) L=810	8-98186-973-0	01	1	1301-
634	HOSE; RUBBER RETURN 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> L=810	8-98186-973-0	01	1	1301-
634	HOSE; RUBBER RETURN 6HK1-TCS ENG(80L) FUEL TANK 200L FRAME SIDE<N20>	8-98186-971-0	01	1	1109-
634	HOSE; RUBBER RETURN 6HK1-TCS ENG(80L) FUEL TANK 400L<SDH> L=900 SERVICED BY L=3000	0-01558-300-0	01	1	1109-

47 634 174 67 67

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date
47	PIPE; FUEL,RETURN 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) (A) L=539	8-98117-709-0	01	1	1206-1212
47	PIPE; FUEL,RETURN 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) EXC. BIO DIESEL FUEL B10<8NV> (A) L=539	8-98117-709-0	01	1	1301-
47	PIPE; FUEL,RETURN (A) L=688	8-98129-921-0	01	1	1109-1205
47	PIPE; FUEL,RETURN 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) (A) L=688	8-98129-921-0	01	1	1206-1212
47	PIPE; FUEL,RETURN EXC. COLOMBIA EQUIPMENT(CB7) (A) L=688	8-98129-921-0	01	1	1206-1212
47	PIPE; FUEL,RETURN 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) (A) L=688	8-98129-921-0	01	1	1301-
47	PIPE; FUEL,RETURN 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) BIO DIESEL FUEL B10<8NV> (A) L=688	8-98129-921-0	01	1	1301-
47	PIPE; FUEL,RETURN EXC. COLOMBIA EQUIPMENT(CB7) (A) L=688	8-98129-921-0	01	1	1301-
47	PIPE; FUEL,RETURN 6HK1-TCS ENG(80L) (B) L=787	8-98127-647-0	01	1	1109-
67	HOSE; FUEL,DELIVERY FUEL TANK 200L FRAME SIDE<N20> (C) L=710	8-98186-527-0	01	1	1109-1205
67	HOSE; FUEL,DELIVERY 6HK1-TCS ENG(80L) WHEEL BASE 3900MM(39W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> (C) L=710	8-98186-527-0	01	1	1206-1212
67	HOSE; FUEL,DELIVERY FUEL TANK 200L FRAME SIDE<N20> EXC. COLOMBIA EQUIPMENT(CB7) (C) L=710	8-98186-527-0	01	1	1206-1212
67	HOSE; FUEL,DELIVERY 6HK1-TCS ENG(80L) WHEEL BASE 3900MM(39W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> EXC. BIO DIESEL FUEL B10<8NV> (C) L=710	8-98186-527-0	01	1	1301-
67	HOSE; FUEL,DELIVERY FUEL TANK 200L FRAME SIDE<N20> EXC. COLOMBIA EQUIPMENT(CB7) (C) L=710	8-98186-527-0	01	1	1301-
67	HOSE; FUEL,DELIVERY FUEL TANK 200L FRAME SIDE<N20> (D) L=1380	8-98186-528-0	01	1	1109-1205
67	HOSE; FUEL,DELIVERY 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> (D) L=1380	8-98186-528-0	01	1	1206-1212
67	HOSE; FUEL,DELIVERY FUEL TANK 200L FRAME SIDE<N20> EXC. COLOMBIA EQUIPMENT(CB7) (D) L=1380	8-98186-528-0	01	1	1206-1212
67	HOSE; FUEL,DELIVERY 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> EXC. BIO DIESEL FUEL B10<8NV> (D) L=1380	8-98186-528-0	01	1	1301-
67	HOSE; FUEL,DELIVERY FUEL TANK 200L FRAME SIDE<N20> EXC. COLOMBIA EQUIPMENT(CB7) (D) L=1380	8-98186-528-0	01	1	1301-
67	HOSE; FUEL,DELIVERY FUEL TANK 400L<SDH> (C) L=980 SERVICED BY L=3000	0-01260-300-0	01	1	1109-1205
67	HOSE; FUEL,DELIVERY COLOMBIA EQUIPMENT(CB7) FUEL TANK 400L<SDH> (C) L=920 SERVICED BY L=3000	0-01260-300-0	01	1	1206-1212
67	HOSE; FUEL,DELIVERY COLOMBIA EQUIPMENT(CB7) FUEL TANK 400L<SDH> EXC. BIO DIESEL FUEL B10<8NV> (C) L=920 SERVICED BY L=3000	0-01260-300-0	01	1	1301-
67	HOSE; FUEL,DELIVERY FUEL TANK 400L<SDH> (C) L=1600 SERVICED BY L=3000	0-01260-300-0	01	1	1109-1212
67	HOSE; FUEL,DELIVERY FUEL TANK 400L<SDH> EXC. BIO DIESEL FUEL B10<8NV> (C) L=1600 SERVICED BY L=3000	0-01260-300-0	01	1	1301-
67	HOSE; FUEL,DELIVERY (C) L=110 SERVICED BY L=3000	0-01260-300-0	01	1	1109-1212
67	HOSE; FUEL,DELIVERY EXC. BIO DIESEL FUEL B10<8NV> (C) L=110 SERVICED BY L=3000	0-01260-300-0	01	1	1301-
67	HOSE; FUEL,DELIVERY (B) L=210 SERVICED BY L=3000	0-01558-300-0	01	1	1109-
67	HOSE; FUEL,DELIVERY FUEL TANK 400L<SDH> EXC. COLOMBIA EQUIPMENT(CB7) (C) L=980 SERVICED BY L=3000	0-01260-300-0	01	1	1206-
67	HOSE; FUEL,DELIVERY 6HK1-TCS ENG(80L) WHEEL BASE 5500MM(55W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> (C) L=730	8-98205-834-0	01	1	1206-1212
67	HOSE; FUEL,DELIVERY 6HK1-TCS ENG(80L) WHEEL BASE 5000MM(50W),WHEEL BASE 5500MM(55W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> EXC. BIO DIESEL FUEL B10<8NV> (C) L=730	8-98205-834-0	01	1	1301-
67	HOSE; FUEL,DELIVERY 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) (E) L=300	8-98157-878-0	01	1	1206-1212
67	HOSE; FUEL,DELIVERY 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) EXC. BIO DIESEL FUEL B10<8NV> (E) L=300	8-98157-878-0	01	1	1301-
67	HOSE; FUEL,DELIVERY 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> (F) L=900	8-98157-879-0	01	1	1206-1212
67	HOSE; FUEL,DELIVERY 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> EXC. BIO DIESEL FUEL B10<8NV> (F) L=900	8-98157-879-0	01	1	1301-
67	HOSE; FUEL,DELIVERY COLOMBIA EQUIPMENT(CB7) FUEL TANK 400L<SDH> BIO DIESEL FUEL B10<8NV> (D) L=1620	8-98232-241-0	01	1	1301-
67	HOSE; FUEL,DELIVERY COLOMBIA EQUIPMENT(CB7) FUEL TANK 400L<SDH> BIO DIESEL FUEL B10<8NV> (C) L=920	8-98232-244-0	01	1	1301-
67	HOSE; FUEL,DELIVERY WHEEL BASE 5000MM(50W),WHEEL BASE 5500MM(55W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> (C) L=730	8-98232-243-0	01	1	1301-
67	HOSE; FUEL,DELIVERY BIO DIESEL FUEL B10<8NV> (A) L=110 SERVICED BY L=3000	0-01859-300-0	01	1	1301-
67	HOSE; FUEL,DELIVERY COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> (D) L=1380	8-98232-240-0	01	1	1301-1304
67	HOSE; FUEL,DELIVERY WHEEL BASE 5000MM(50W),WHEEL BASE 5500MM(55W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> (D) L=1380	8-98232-240-0	01	1	1305-
67	HOSE; FUEL,DELIVERY 6HK1-TCS ENG(80L) WHEEL BASE 3900MM(39W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> (C)	8-98232-911-0	01	1	1301-1304
67	HOSE; FUEL,DELIVERY WHEEL BASE 3900MM(39W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> (C)	8-98238-196-0	01	1	1305-
67	HOSE; FUEL,DELIVERY WHEEL BASE 3900MM(39W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> (D)	8-98238-197-0	01	1	1305-
174	PIPE; FUEL,FEED,FRT 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) L=548	8-98117-708-0	01	1	1206-1212
174	PIPE; FUEL,FEED,FRT 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) EXC. BIO DIESEL FUEL B10<8NV> L=548	8-98117-708-0	01	1	1301-
174	PIPE; FUEL,FEED,FRT L=685	8-98129-920-0	01	1	1109-1205
174	PIPE; FUEL,FEED,FRT 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) L=685	8-98129-920-0	01	1	1206-1212
174	PIPE; FUEL,FEED,FRT EXC. COLOMBIA EQUIPMENT(CB7) L=685	8-98129-920-0	01	1	1206-1212
174	PIPE; FUEL,FEED,FRT 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) L=685	8-98129-920-0	01	1	1301-
174	PIPE; FUEL,FEED,FRT 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) BIO DIESEL FUEL B10<8NV> L=685	8-98129-920-0	01	1	1301-
174	PIPE; FUEL,FEED,FRT EXC. COLOMBIA EQUIPMENT(CB7) L=685	8-98129-920-0	01	1	1301-
634	HOSE; RUBBER RETURN 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) L=1050	8-98128-212-0	01	1	1206-1212
634	HOSE; RUBBER RETURN 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) EXC. BIO DIESEL FUEL B10<8NV> L=1050	8-98128-212-0	01	1	1301-
634	HOSE; RUBBER RETURN 6HK1-TCN ENG(82L) FUEL TANK 200L FRAME SIDE<N20> L=810	8-98186-973-0	01	1	1109-1205
634	HOSE; RUBBER RETURN 6HK1-TCN ENG(82L) FUEL TANK 200L FRAME SIDE<N20> EXC. COLOMBIA EQUIPMENT(CB7) L=810	8-98186-973-0	01	1	1206-1212
634	HOSE; RUBBER RETURN 6HK1-TCN ENG(82L) FUEL TANK 200L FRAME SIDE<N20> EXC. COLOMBIA EQUIPMENT(CB7) L=810	8-98186-973-0	01	1	1301-
634	HOSE; RUBBER RETURN 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> L=810	8-98186-973-0	01	1	1301-
634	HOSE; RUBBER RETURN 6HK1-TCS ENG(80L) FUEL TANK 200L FRAME SIDE<N20>	8-98186-971-0	01	1	1109-
634	HOSE; RUBBER RETURN 6HK1-TCS ENG(80L) FUEL TANK 400L<SDH> L=900 SERVICED BY L=3000	0-01558-300-0	01	1	1109-

47 174 634 67 67

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date
47	PIPE; FUEL,RETURN 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) (A) L=539	8-98117-709-0	01	1	1206-1212
47	PIPE; FUEL,RETURN 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) EXC. BIO DIESEL FUEL B10<8NV> (A) L=539	8-98117-709-0	01	1	1301-
47	PIPE; FUEL,RETURN (A) L=688	8-98129-921-0	01	1	1109-1205
47	PIPE; FUEL,RETURN 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) (A) L=688	8-98129-921-0	01	1	1206-1212
47	PIPE; FUEL,RETURN EXC. COLOMBIA EQUIPMENT(CB7) (A) L=688	8-98129-921-0	01	1	1206-1212
47	PIPE; FUEL,RETURN 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) (A) L=688	8-98129-921-0	01	1	1301-
47	PIPE; FUEL,RETURN 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) BIO DIESEL FUEL B10<8NV> (A) L=688	8-98129-921-0	01	1	1301-
47	PIPE; FUEL,RETURN EXC. COLOMBIA EQUIPMENT(CB7) (A) L=688	8-98129-921-0	01	1	1301-
47	PIPE; FUEL,RETURN 6HK1-TCS ENG(80L) (B) L=787	8-98127-647-0	01	1	1109-
67	HOSE; FUEL,DELIVERY FUEL TANK 200L FRAME SIDE<N20> (C) L=710	8-98186-527-0	01	1	1109-1205
67	HOSE; FUEL,DELIVERY 6HK1-TCS ENG(80L) WHEEL BASE 3900MM(39W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> (C) L=710	8-98186-527-0	01	1	1206-1212
67	HOSE; FUEL,DELIVERY FUEL TANK 200L FRAME SIDE<N20> EXC. COLOMBIA EQUIPMENT(CB7) (C) L=710	8-98186-527-0	01	1	1206-1212
67	HOSE; FUEL,DELIVERY 6HK1-TCS ENG(80L) WHEEL BASE 3900MM(39W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> EXC. BIO DIESEL FUEL B10<8NV> (C) L=710	8-98186-527-0	01	1	1301-
67	HOSE; FUEL,DELIVERY FUEL TANK 200L FRAME SIDE<N20> EXC. COLOMBIA EQUIPMENT(CB7) (C) L=710	8-98186-527-0	01	1	1301-
67	HOSE; FUEL,DELIVERY FUEL TANK 200L FRAME SIDE<N20> (D) L=1380	8-98186-528-0	01	1	1109-1205
67	HOSE; FUEL,DELIVERY 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> (D) L=1380	8-98186-528-0	01	1	1206-1212
67	HOSE; FUEL,DELIVERY FUEL TANK 200L FRAME SIDE<N20> EXC. COLOMBIA EQUIPMENT(CB7) (D) L=1380	8-98186-528-0	01	1	1206-1212
67	HOSE; FUEL,DELIVERY 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> EXC. BIO DIESEL FUEL B10<8NV> (D) L=1380	8-98186-528-0	01	1	1301-
67	HOSE; FUEL,DELIVERY FUEL TANK 200L FRAME SIDE<N20> EXC. COLOMBIA EQUIPMENT(CB7) (D) L=1380	8-98186-528-0	01	1	1301-
67	HOSE; FUEL,DELIVERY FUEL TANK 400L<SDH> (C) L=980 SERVICED BY L=3000	0-01260-300-0	01	1	1109-1205
67	HOSE; FUEL,DELIVERY COLOMBIA EQUIPMENT(CB7) FUEL TANK 400L<SDH> (C) L=920 SERVICED BY L=3000	0-01260-300-0	01	1	1206-1212
67	HOSE; FUEL,DELIVERY COLOMBIA EQUIPMENT(CB7) FUEL TANK 400L<SDH> EXC. BIO DIESEL FUEL B10<8NV> (C) L=920 SERVICED BY L=3000	0-01260-300-0	01	1	1301-
67	HOSE; FUEL,DELIVERY FUEL TANK 400L<SDH> (C) L=1600 SERVICED BY L=3000	0-01260-300-0	01	1	1109-1212
67	HOSE; FUEL,DELIVERY FUEL TANK 400L<SDH> EXC. BIO DIESEL FUEL B10<8NV> (C) L=1600 SERVICED BY L=3000	0-01260-300-0	01	1	1301-
67	HOSE; FUEL,DELIVERY (C) L=110 SERVICED BY L=3000	0-01260-300-0	01	1	1109-1212
67	HOSE; FUEL,DELIVERY EXC. BIO DIESEL FUEL B10<8NV> (C) L=110 SERVICED BY L=3000	0-01260-300-0	01	1	1301-
67	HOSE; FUEL,DELIVERY (B) L=210 SERVICED BY L=3000	0-01558-300-0	01	1	1109-
67	HOSE; FUEL,DELIVERY FUEL TANK 400L<SDH> EXC. COLOMBIA EQUIPMENT(CB7) (C) L=980 SERVICED BY L=3000	0-01260-300-0	01	1	1206-
67	HOSE; FUEL,DELIVERY 6HK1-TCS ENG(80L) WHEEL BASE 5500MM(55W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> (C) L=730	8-98205-834-0	01	1	1206-1212
67	HOSE; FUEL,DELIVERY 6HK1-TCS ENG(80L) WHEEL BASE 5000MM(50W),WHEEL BASE 5500MM(55W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> EXC. BIO DIESEL FUEL B10<8NV> (C) L=730	8-98205-834-0	01	1	1301-
67	HOSE; FUEL,DELIVERY 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) (E) L=300	8-98157-878-0	01	1	1206-1212
67	HOSE; FUEL,DELIVERY 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) EXC. BIO DIESEL FUEL B10<8NV> (E) L=300	8-98157-878-0	01	1	1301-
67	HOSE; FUEL,DELIVERY 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> (F) L=900	8-98157-879-0	01	1	1206-1212
67	HOSE; FUEL,DELIVERY 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> EXC. BIO DIESEL FUEL B10<8NV> (F) L=900	8-98157-879-0	01	1	1301-
67	HOSE; FUEL,DELIVERY COLOMBIA EQUIPMENT(CB7) FUEL TANK 400L<SDH> BIO DIESEL FUEL B10<8NV> (D) L=1620	8-98232-241-0	01	1	1301-
67	HOSE; FUEL,DELIVERY COLOMBIA EQUIPMENT(CB7) FUEL TANK 400L<SDH> BIO DIESEL FUEL B10<8NV> (C) L=920	8-98232-244-0	01	1	1301-
67	HOSE; FUEL,DELIVERY WHEEL BASE 5000MM(50W),WHEEL BASE 5500MM(55W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> (C) L=730	8-98232-243-0	01	1	1301-
67	HOSE; FUEL,DELIVERY BIO DIESEL FUEL B10<8NV> (A) L=110 SERVICED BY L=3000	0-01859-300-0	01	1	1301-
67	HOSE; FUEL,DELIVERY COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> (D) L=1380	8-98232-240-0	01	1	1301-1304
67	HOSE; FUEL,DELIVERY WHEEL BASE 5000MM(50W),WHEEL BASE 5500MM(55W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> (D) L=1380	8-98232-240-0	01	1	1305-
67	HOSE; FUEL,DELIVERY 6HK1-TCS ENG(80L) WHEEL BASE 3900MM(39W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> (C)	8-98232-911-0	01	1	1301-1304
67	HOSE; FUEL,DELIVERY WHEEL BASE 3900MM(39W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> (C)	8-98238-196-0	01	1	1305-
67	HOSE; FUEL,DELIVERY WHEEL BASE 3900MM(39W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> (D)	8-98238-197-0	01	1	1305-
174	PIPE; FUEL,FEED,FRT 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) L=548	8-98117-708-0	01	1	1206-1212
174	PIPE; FUEL,FEED,FRT 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) EXC. BIO DIESEL FUEL B10<8NV> L=548	8-98117-708-0	01	1	1301-
174	PIPE; FUEL,FEED,FRT L=685	8-98129-920-0	01	1	1109-1205
174	PIPE; FUEL,FEED,FRT 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) L=685	8-98129-920-0	01	1	1206-1212
174	PIPE; FUEL,FEED,FRT EXC. COLOMBIA EQUIPMENT(CB7) L=685	8-98129-920-0	01	1	1206-1212
174	PIPE; FUEL,FEED,FRT 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) L=685	8-98129-920-0	01	1	1301-
174	PIPE; FUEL,FEED,FRT 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) BIO DIESEL FUEL B10<8NV> L=685	8-98129-920-0	01	1	1301-
174	PIPE; FUEL,FEED,FRT EXC. COLOMBIA EQUIPMENT(CB7) L=685	8-98129-920-0	01	1	1301-
634	HOSE; RUBBER RETURN 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) L=1050	8-98128-212-0	01	1	1206-1212
634	HOSE; RUBBER RETURN 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) EXC. BIO DIESEL FUEL B10<8NV> L=1050	8-98128-212-0	01	1	1301-
634	HOSE; RUBBER RETURN 6HK1-TCN ENG(82L) FUEL TANK 200L FRAME SIDE<N20> L=810	8-98186-973-0	01	1	1109-1205
634	HOSE; RUBBER RETURN 6HK1-TCN ENG(82L) FUEL TANK 200L FRAME SIDE<N20> EXC. COLOMBIA EQUIPMENT(CB7) L=810	8-98186-973-0	01	1	1206-1212
634	HOSE; RUBBER RETURN 6HK1-TCN ENG(82L) FUEL TANK 200L FRAME SIDE<N20> EXC. COLOMBIA EQUIPMENT(CB7) L=810	8-98186-973-0	01	1	1301-
634	HOSE; RUBBER RETURN 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> L=810	8-98186-973-0	01	1	1301-
634	HOSE; RUBBER RETURN 6HK1-TCS ENG(80L) FUEL TANK 200L FRAME SIDE<N20>	8-98186-971-0	01	1	1109-
634	HOSE; RUBBER RETURN 6HK1-TCS ENG(80L) FUEL TANK 400L<SDH> L=900 SERVICED BY L=3000	0-01558-300-0	01	1	1109-

41 29 41 29 373 41 41 373 41 67 97 304 83 174 47 41 80 41 41 67 41 228 228 227 228

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date
29	HOSE; FUEL BIO DIESEL FUEL B10<8NV> (A)	8-98156-579-0	01	1	1301-
29	HOSE; FUEL (A)	8-98078-196-2	01	1	1109-1212
29	HOSE; FUEL EXC. BIO DIESEL FUEL B10<8NV> (A)	8-98078-196-2	01	1	1301-
29	HOSE; FUEL (B)	8-98078-197-1	01	1	1109-
29	HOSE; FUEL FUEL TANK 400L<SDH> (C) L=60 SERVICED BY L=3000	0-01259-300-0	01	1	1109-
41	CLIP; FUEL PIPE,FUEL TANK WHEEL BASE 3900MM(39W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> (E) L=250	5-09707-030-1	06	1	1305-
41	CLIP; FUEL PIPE,FUEL TANK COLOMBIA EQUIPMENT(CB7) BIO DIESEL FUEL B10<8NV> (F) ID=24 & 24 L=49	1-09701-018-0	01	1	1301-1304
41	CLIP; FUEL PIPE,FUEL TANK WHEEL BASE 5000MM(50W),WHEEL BASE 5500MM(55W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> (F) ID=24 & 24 L=49	1-09701-018-0	01	1	1305-
41	CLIP; FUEL PIPE,FUEL TANK COLOMBIA EQUIPMENT(CB7) FUEL TANK 400L<SDH> BIO DIESEL FUEL B10<8NV> (F) ID=24 & 24 L=49	1-09701-018-0	01	1	1305-
41	CLIP; FUEL PIPE,FUEL TANK BIO DIESEL FUEL B10<8NV> (D) ID=16	8-94238-568-0	06	1	1301-
41	CLIP; FUEL PIPE,FUEL TANK 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) (B) ID=11 & 9 L=17.5 & 17.5	1-09700-747-0	02	1	1206-1212
41	CLIP; FUEL PIPE,FUEL TANK 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) EXC. BIO DIESEL FUEL B10<8NV> (B) ID=11 & 9 L=17.5 & 17.5	1-09700-747-0	02	1	1301-
41	CLIP; FUEL PIPE,FUEL TANK 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> (E) L=250	5-09707-030-1	02	1	1206-1212
41	CLIP; FUEL PIPE,FUEL TANK 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> EXC. BIO DIESEL FUEL B10<8NV> (E) L=250	5-09707-030-1	02	1	1301-
41	CLIP; FUEL PIPE,FUEL TANK (B) ID=11 & 9 L=17.5 & 17.5	1-09700-747-0	03	1	1109-1205
41	CLIP; FUEL PIPE,FUEL TANK 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) (B) ID=11 & 9 L=17.5 & 17.5	1-09700-747-0	03	1	1206-1212
41	CLIP; FUEL PIPE,FUEL TANK EXC. COLOMBIA EQUIPMENT(CB7) (B) ID=11 & 9 L=17.5 & 17.5	1-09700-747-0	03	1	1206-1212
41	CLIP; FUEL PIPE,FUEL TANK 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) (B) ID=11 & 9 L=17.5 & 17.5	1-09700-747-0	03	1	1301-
41	CLIP; FUEL PIPE,FUEL TANK 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) BIO DIESEL FUEL B10<8NV> (B) ID=11 & 9 L=17.5 & 17.5	1-09700-747-0	03	1	1301-
41	CLIP; FUEL PIPE,FUEL TANK EXC. COLOMBIA EQUIPMENT(CB7) (B) ID=11 & 9 L=17.5 & 17.5	1-09700-747-0	03	1	1301-
41	CLIP; FUEL PIPE,FUEL TANK (F) ID=14X29 H=30 L=25	1-09701-101-0	01	1	1109-1205
41	CLIP; FUEL PIPE,FUEL TANK 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) (F) ID=14X29 H=30 L=25	1-09701-101-0	01	1	1206-1212
41	CLIP; FUEL PIPE,FUEL TANK EXC. COLOMBIA EQUIPMENT(CB7) (F) ID=14X29 H=30 L=25	1-09701-101-0	01	1	1206-1212
41	CLIP; FUEL PIPE,FUEL TANK 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) EXC. BIO DIESEL FUEL B10<8NV> (F) ID=14X29 H=30 L=25	1-09701-101-0	01	1	1301-
41	CLIP; FUEL PIPE,FUEL TANK EXC. COLOMBIA EQUIPMENT(CB7) (F) ID=14X29 H=30 L=25	1-09701-101-0	01	1	1301-
41	CLIP; FUEL PIPE,FUEL TANK (C) ID=14	1-09704-102-0	06	1	1109-1212
41	CLIP; FUEL PIPE,FUEL TANK EXC. BIO DIESEL FUEL B10<8NV> (C) ID=14	1-09704-102-0	06	1	1301-
41	CLIP; FUEL PIPE,FUEL TANK (D) ID=16	8-94238-568-0	02	1	1109-
41	CLIP; FUEL PIPE,FUEL TANK FUEL TANK 200L FRAME SIDE<N20> (E) L=250	5-09707-030-1	05	1	1109-1205
41	CLIP; FUEL PIPE,FUEL TANK 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> (E) L=250	5-09707-030-1	05	1	1206-1212
41	CLIP; FUEL PIPE,FUEL TANK FUEL TANK 200L FRAME SIDE<N20> EXC. COLOMBIA EQUIPMENT(CB7) (E) L=250	5-09707-030-1	05	1	1206-1212
41	CLIP; FUEL PIPE,FUEL TANK 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> (E) L=250	5-09707-030-1	05	1	1301-1304
41	CLIP; FUEL PIPE,FUEL TANK 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> (E) L=250	5-09707-030-1	05	1	1301-1304
41	CLIP; FUEL PIPE,FUEL TANK FUEL TANK 200L FRAME SIDE<N20> EXC. COLOMBIA EQUIPMENT(CB7) (E) L=250	5-09707-030-1	05	1	1301-1304
41	CLIP; FUEL PIPE,FUEL TANK WHEEL BASE 5000MM(50W),WHEEL BASE 5500MM(55W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> (E) L=250	5-09707-030-1	05	1	1305-
41	CLIP; FUEL PIPE,FUEL TANK 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> EXC. BIO DIESEL FUEL B10<8NV> (E) L=250	5-09707-030-1	05	1	1305-
41	CLIP; FUEL PIPE,FUEL TANK FUEL TANK 200L FRAME SIDE<N20> EXC. COLOMBIA EQUIPMENT(CB7) (E) L=250	5-09707-030-1	05	1	1305-
41	CLIP; FUEL PIPE,FUEL TANK FUEL TANK 400L<SDH> (E) L=250	5-09707-030-1	03	1	1109-
41	CLIP; FUEL PIPE,FUEL TANK 6HK1-TCN ENG(82L) (A) ID=13	8-94238-571-0	06	1	1109-
41	CLIP; FUEL PIPE,FUEL TANK 6HK1-TCS ENG(80L) (G) ID=9 & 9 L=17 & 17	1-09700-651-0	02	1	1109-
41	CLIP; FUEL PIPE,FUEL TANK 6HK1-TCS ENG(80L) (A) ID=13	8-94238-571-0	08	1	1109-
47	PIPE; FUEL,RETURN 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) (A) L=539	8-98117-709-0	01	1	1206-1212
47	PIPE; FUEL,RETURN 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) EXC. BIO DIESEL FUEL B10<8NV> (A) L=539	8-98117-709-0	01	1	1301-
47	PIPE; FUEL,RETURN (A) L=688	8-98129-921-0	01	1	1109-1205
47	PIPE; FUEL,RETURN 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) (A) L=688	8-98129-921-0	01	1	1206-1212
47	PIPE; FUEL,RETURN EXC. COLOMBIA EQUIPMENT(CB7) (A) L=688	8-98129-921-0	01	1	1206-1212
47	PIPE; FUEL,RETURN 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) (A) L=688	8-98129-921-0	01	1	1301-
47	PIPE; FUEL,RETURN 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) BIO DIESEL FUEL B10<8NV> (A) L=688	8-98129-921-0	01	1	1301-
47	PIPE; FUEL,RETURN EXC. COLOMBIA EQUIPMENT(CB7) (A) L=688	8-98129-921-0	01	1	1301-
47	PIPE; FUEL,RETURN 6HK1-TCS ENG(80L) (B) L=787	8-98127-647-0	01	1	1109-
67	HOSE; FUEL,DELIVERY FUEL TANK 200L FRAME SIDE<N20> (C) L=710	8-98186-527-0	01	1	1109-1205
67	HOSE; FUEL,DELIVERY 6HK1-TCS ENG(80L) WHEEL BASE 3900MM(39W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> (C) L=710	8-98186-527-0	01	1	1206-1212
67	HOSE; FUEL,DELIVERY FUEL TANK 200L FRAME SIDE<N20> EXC. COLOMBIA EQUIPMENT(CB7) (C) L=710	8-98186-527-0	01	1	1206-1212
67	HOSE; FUEL,DELIVERY 6HK1-TCS ENG(80L) WHEEL BASE 3900MM(39W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> EXC. BIO DIESEL FUEL B10<8NV> (C) L=710	8-98186-527-0	01	1	1301-
67	HOSE; FUEL,DELIVERY FUEL TANK 200L FRAME SIDE<N20> EXC. COLOMBIA EQUIPMENT(CB7) (C) L=710	8-98186-527-0	01	1	1301-
67	HOSE; FUEL,DELIVERY FUEL TANK 200L FRAME SIDE<N20> (D) L=1380	8-98186-528-0	01	1	1109-1205
67	HOSE; FUEL,DELIVERY 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> (D) L=1380	8-98186-528-0	01	1	1206-1212
67	HOSE; FUEL,DELIVERY FUEL TANK 200L FRAME SIDE<N20> EXC. COLOMBIA EQUIPMENT(CB7) (D) L=1380	8-98186-528-0	01	1	1206-1212
67	HOSE; FUEL,DELIVERY 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> EXC. BIO DIESEL FUEL B10<8NV> (D) L=1380	8-98186-528-0	01	1	1301-
67	HOSE; FUEL,DELIVERY FUEL TANK 200L FRAME SIDE<N20> EXC. COLOMBIA EQUIPMENT(CB7) (D) L=1380	8-98186-528-0	01	1	1301-
67	HOSE; FUEL,DELIVERY FUEL TANK 400L<SDH> (C) L=980 SERVICED BY L=3000	0-01260-300-0	01	1	1109-1205
67	HOSE; FUEL,DELIVERY COLOMBIA EQUIPMENT(CB7) FUEL TANK 400L<SDH> (C) L=920 SERVICED BY L=3000	0-01260-300-0	01	1	1206-1212
67	HOSE; FUEL,DELIVERY COLOMBIA EQUIPMENT(CB7) FUEL TANK 400L<SDH> EXC. BIO DIESEL FUEL B10<8NV> (C) L=920 SERVICED BY L=3000	0-01260-300-0	01	1	1301-
67	HOSE; FUEL,DELIVERY FUEL TANK 400L<SDH> (C) L=1600 SERVICED BY L=3000	0-01260-300-0	01	1	1109-1212
67	HOSE; FUEL,DELIVERY FUEL TANK 400L<SDH> EXC. BIO DIESEL FUEL B10<8NV> (C) L=1600 SERVICED BY L=3000	0-01260-300-0	01	1	1301-
67	HOSE; FUEL,DELIVERY (C) L=110 SERVICED BY L=3000	0-01260-300-0	01	1	1109-1212
67	HOSE; FUEL,DELIVERY EXC. BIO DIESEL FUEL B10<8NV> (C) L=110 SERVICED BY L=3000	0-01260-300-0	01	1	1301-
67	HOSE; FUEL,DELIVERY (B) L=210 SERVICED BY L=3000	0-01558-300-0	01	1	1109-
67	HOSE; FUEL,DELIVERY FUEL TANK 400L<SDH> EXC. COLOMBIA EQUIPMENT(CB7) (C) L=980 SERVICED BY L=3000	0-01260-300-0	01	1	1206-
67	HOSE; FUEL,DELIVERY 6HK1-TCS ENG(80L) WHEEL BASE 5500MM(55W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> (C) L=730	8-98205-834-0	01	1	1206-1212
67	HOSE; FUEL,DELIVERY 6HK1-TCS ENG(80L) WHEEL BASE 5000MM(50W),WHEEL BASE 5500MM(55W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> EXC. BIO DIESEL FUEL B10<8NV> (C) L=730	8-98205-834-0	01	1	1301-
67	HOSE; FUEL,DELIVERY 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) (E) L=300	8-98157-878-0	01	1	1206-1212
67	HOSE; FUEL,DELIVERY 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) EXC. BIO DIESEL FUEL B10<8NV> (E) L=300	8-98157-878-0	01	1	1301-
67	HOSE; FUEL,DELIVERY 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> (F) L=900	8-98157-879-0	01	1	1206-1212
67	HOSE; FUEL,DELIVERY 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> EXC. BIO DIESEL FUEL B10<8NV> (F) L=900	8-98157-879-0	01	1	1301-
67	HOSE; FUEL,DELIVERY COLOMBIA EQUIPMENT(CB7) FUEL TANK 400L<SDH> BIO DIESEL FUEL B10<8NV> (D) L=1620	8-98232-241-0	01	1	1301-
67	HOSE; FUEL,DELIVERY COLOMBIA EQUIPMENT(CB7) FUEL TANK 400L<SDH> BIO DIESEL FUEL B10<8NV> (C) L=920	8-98232-244-0	01	1	1301-
67	HOSE; FUEL,DELIVERY WHEEL BASE 5000MM(50W),WHEEL BASE 5500MM(55W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> (C) L=730	8-98232-243-0	01	1	1301-
67	HOSE; FUEL,DELIVERY BIO DIESEL FUEL B10<8NV> (A) L=110 SERVICED BY L=3000	0-01859-300-0	01	1	1301-
67	HOSE; FUEL,DELIVERY COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> (D) L=1380	8-98232-240-0	01	1	1301-1304
67	HOSE; FUEL,DELIVERY WHEEL BASE 5000MM(50W),WHEEL BASE 5500MM(55W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> (D) L=1380	8-98232-240-0	01	1	1305-
67	HOSE; FUEL,DELIVERY 6HK1-TCS ENG(80L) WHEEL BASE 3900MM(39W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> (C)	8-98232-911-0	01	1	1301-1304
67	HOSE; FUEL,DELIVERY WHEEL BASE 3900MM(39W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> (C)	8-98238-196-0	01	1	1305-
67	HOSE; FUEL,DELIVERY WHEEL BASE 3900MM(39W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> (D)	8-98238-197-0	01	1	1305-
80	BOLT; CLIP,FUEL TANK M8X20 FLANGE	0-28650-820-0	02	1	1109-
80	BOLT; CLIP,FUEL TANK 6HK1-TCS ENG(80L) M8X20 FLANGE	0-28650-820-0	02	1	1109-
80	BOLT; CLIP,FUEL TANK M8X30 FLANGE	0-28650-830-0	01	1	1109-1205
80	BOLT; CLIP,FUEL TANK 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) M8X30 FLANGE	0-28650-830-0	01	1	1206-1212
80	BOLT; CLIP,FUEL TANK EXC. COLOMBIA EQUIPMENT(CB7) M8X30 FLANGE	0-28650-830-0	01	1	1206-1212
80	BOLT; CLIP,FUEL TANK 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) M8X30 FLANGE	0-28650-830-0	01	1	1301-1304
80	BOLT; CLIP,FUEL TANK 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) BIO DIESEL FUEL B10<8NV> M8X30 FLANGE	0-28650-830-0	01	1	1301-1304
80	BOLT; CLIP,FUEL TANK EXC. COLOMBIA EQUIPMENT(CB7) M8X30 FLANGE	0-28650-830-0	01	1	1301-1304
80	BOLT; CLIP,FUEL TANK WHEEL BASE 5000MM(50W),WHEEL BASE 5500MM(55W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> M8X30 FLANGE	0-28650-830-0	01	1	1305-
80	BOLT; CLIP,FUEL TANK 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) FUEL TANK 400L<SDH> BIO DIESEL FUEL B10<8NV> M8X30 FLANGE	0-28650-830-0	01	1	1305-
80	BOLT; CLIP,FUEL TANK 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) EXC. BIO DIESEL FUEL B10<8NV> M8X30 FLANGE	0-28650-830-0	01	1	1305-
80	BOLT; CLIP,FUEL TANK EXC. COLOMBIA EQUIPMENT(CB7) M8X30 FLANGE	0-28650-830-0	01	1	1305-
83	NUT; CLIP,FUEL TANK M8 FLANGE	0-91180-108-0	03	1	1109-1205
83	NUT; CLIP,FUEL TANK 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) M8 FLANGE	0-91180-108-0	03	1	1206-1212
83	NUT; CLIP,FUEL TANK EXC. COLOMBIA EQUIPMENT(CB7) M8 FLANGE	0-91180-108-0	03	1	1206-1212
83	NUT; CLIP,FUEL TANK 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) M8 FLANGE	0-91180-108-0	03	1	1301-
83	NUT; CLIP,FUEL TANK 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) BIO DIESEL FUEL B10<8NV> M8 FLANGE	0-91180-108-0	03	1	1301-
83	NUT; CLIP,FUEL TANK EXC. COLOMBIA EQUIPMENT(CB7) M8 FLANGE	0-91180-108-0	03	1	1301-
83	NUT; CLIP,FUEL TANK FUEL TANK 400L<SDH> M8 FLANGE	0-91180-108-0	01	1	1109-
83	NUT; CLIP,FUEL TANK 6HK1-TCS ENG(80L) M8 FLANGE	0-91180-108-0	02	1	1109-1205
83	NUT; CLIP,FUEL TANK 6HK1-TCS ENG(80L) M8 FLANGE	0-91180-108-0	02	1	1206-1212
83	NUT; CLIP,FUEL TANK 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) M8 FLANGE	0-91180-108-0	02	1	1206-1212
83	NUT; CLIP,FUEL TANK 6HK1-TCS ENG(80L) M8 FLANGE	0-91180-108-0	02	1	1301-
83	NUT; CLIP,FUEL TANK 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) EXC. BIO DIESEL FUEL B10<8NV> M8 FLANGE	0-91180-108-0	02	1	1301-
97	BRACKET; CLIP WHEEL BASE 3900MM(39W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> (E)	8-98238-178-0	01	1	1305-
97	BRACKET; CLIP 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) (D)	8-98126-612-0	01	1	1206-1212
97	BRACKET; CLIP 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) EXC. BIO DIESEL FUEL B10<8NV> (D)	8-98126-612-0	01	1	1301-
97	BRACKET; CLIP (C) L=50	1-47475-299-2	01	1	1109-1205
97	BRACKET; CLIP 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) (C) L=50	1-47475-299-2	01	1	1206-1212
97	BRACKET; CLIP EXC. COLOMBIA EQUIPMENT(CB7) (C) L=50	1-47475-299-2	01	1	1206-1212
97	BRACKET; CLIP 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) (C) L=50	1-47475-299-2	01	1	1301-
97	BRACKET; CLIP 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) BIO DIESEL FUEL B10<8NV> (C) L=50	1-47475-299-2	01	1	1301-
97	BRACKET; CLIP EXC. COLOMBIA EQUIPMENT(CB7) (C) L=50	1-47475-299-2	01	1	1301-
97	BRACKET; CLIP (A)	8-98053-654-0	01	1	1109-
97	BRACKET; CLIP (B)	8-98129-922-0	01	1	1109-1205
97	BRACKET; CLIP 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) (B)	8-98129-922-0	01	1	1206-1212
97	BRACKET; CLIP EXC. COLOMBIA EQUIPMENT(CB7) (B)	8-98129-922-0	01	1	1206-1212
97	BRACKET; CLIP 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) (B)	8-98129-922-0	01	1	1301-
97	BRACKET; CLIP 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) BIO DIESEL FUEL B10<8NV> (B)	8-98129-922-0	01	1	1301-
97	BRACKET; CLIP EXC. COLOMBIA EQUIPMENT(CB7) (B)	8-98129-922-0	01	1	1301-
174	PIPE; FUEL,FEED,FRT 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) L=548	8-98117-708-0	01	1	1206-1212
174	PIPE; FUEL,FEED,FRT 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) EXC. BIO DIESEL FUEL B10<8NV> L=548	8-98117-708-0	01	1	1301-
174	PIPE; FUEL,FEED,FRT L=685	8-98129-920-0	01	1	1109-1205
174	PIPE; FUEL,FEED,FRT 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) L=685	8-98129-920-0	01	1	1206-1212
174	PIPE; FUEL,FEED,FRT EXC. COLOMBIA EQUIPMENT(CB7) L=685	8-98129-920-0	01	1	1206-1212
174	PIPE; FUEL,FEED,FRT 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) L=685	8-98129-920-0	01	1	1301-
174	PIPE; FUEL,FEED,FRT 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) BIO DIESEL FUEL B10<8NV> L=685	8-98129-920-0	01	1	1301-
174	PIPE; FUEL,FEED,FRT EXC. COLOMBIA EQUIPMENT(CB7) L=685	8-98129-920-0	01	1	1301-
227	BRACKET; FUEL SEDIMENTER	8-98044-366-3	01	1	1109-
228	BOLT; BRKT,SEDIMENTER 6HK1-TCS ENG(80L) WHEEL BASE 3900MM(39W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 400L<SDH> (B) M10X60 FLANGE	0-28051-060-0	02	1	1207-
228	BOLT; BRKT,SEDIMENTER 6HK1-TCS ENG(80L) WHEEL BASE 5000MM(50W),WHEEL BASE 5500MM(55W) COLOMBIA EQUIPMENT(CB7) (B) M10X60 FLANGE	0-28051-060-0	02	1	1207-
228	BOLT; BRKT,SEDIMENTER 6HK1-TCS ENG(80L) WHEEL BASE 5500MM(55W) CHILE EQUIPMENT(KE1) FUEL TANK 400L<SDH> (B) M10X60 FLANGE	0-28051-060-0	02	1	1207-
228	BOLT; BRKT,SEDIMENTER (A) M8X25 FLANGE	0-28050-825-0	02	1	1109-
228	BOLT; BRKT,SEDIMENTER (B) M10X50 FLANGE	0-28051-050-0	02	1	1109-1206
228	BOLT; BRKT,SEDIMENTER 6HK1-TCS ENG(80L) WHEEL BASE 3900MM(39W) COLOMBIA EQUIPMENT(CB7) EXC. FUEL TANK 400L<SDH> (B) M10X50 FLANGE	0-28051-050-0	02	1	1207-
228	BOLT; BRKT,SEDIMENTER 6HK1-TCN ENG(82L) WHEEL BASE 5000MM(50W) COLOMBIA EQUIPMENT(CB7) (B) M10X50 FLANGE	0-28051-050-0	02	1	1207-
228	BOLT; BRKT,SEDIMENTER EXC. COLOMBIA EQUIPMENT(CB7),FUEL TANK 400L<SDH> (B) M10X50 FLANGE	0-28051-050-0	02	1	1207-
228	BOLT; BRKT,SEDIMENTER (C) M8X20 FLANGE	0-28650-820-0	02	1	1109-
304	NUT; BRKT 6HK1-TCN ENG(82L) WHEEL BASE 5000MM(50W) COLOMBIA EQUIPMENT(CB7) EXC. FUEL TANK 400L<SDH> (B) M10 FLANGE	0-91180-210-0	01	1	1206-1212
304	NUT; BRKT (A) M8 FLANGE	0-91180-108-0	03	1	1109-
304	NUT; BRKT (B) M10 FLANGE	0-91180-210-0	02	1	1109-1205
304	NUT; BRKT EXC. FUEL TANK 400L<SDH> (B) M10 FLANGE	0-91180-210-0	02	1	1109-1205
304	NUT; BRKT (B) M10 FLANGE	0-91180-210-0	02	1	1206-
304	NUT; BRKT 6HK1-TCS ENG(80L) WHEEL BASE 3900MM(39W) COLOMBIA EQUIPMENT(CB7) EXC. FUEL TANK 400L<SDH> (B) M10 FLANGE	0-91180-210-0	02	1	1206-
304	NUT; BRKT EXC. COLOMBIA EQUIPMENT(CB7),FUEL TANK 400L<SDH> (B) M10 FLANGE	0-91180-210-0	02	1	1206-
373	CLAMP; HOSE,FUEL FUEL TANK 400L<SDH> ID=16	8-94238-568-0	02	1	1109-

67 67 634 174 47 47 174 634 67 67

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date
47	PIPE; FUEL,RETURN 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) (A) L=539	8-98117-709-0	01	1	1206-1212
47	PIPE; FUEL,RETURN 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) EXC. BIO DIESEL FUEL B10<8NV> (A) L=539	8-98117-709-0	01	1	1301-
47	PIPE; FUEL,RETURN (A) L=688	8-98129-921-0	01	1	1109-1205
47	PIPE; FUEL,RETURN 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) (A) L=688	8-98129-921-0	01	1	1206-1212
47	PIPE; FUEL,RETURN EXC. COLOMBIA EQUIPMENT(CB7) (A) L=688	8-98129-921-0	01	1	1206-1212
47	PIPE; FUEL,RETURN 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) (A) L=688	8-98129-921-0	01	1	1301-
47	PIPE; FUEL,RETURN 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) BIO DIESEL FUEL B10<8NV> (A) L=688	8-98129-921-0	01	1	1301-
47	PIPE; FUEL,RETURN EXC. COLOMBIA EQUIPMENT(CB7) (A) L=688	8-98129-921-0	01	1	1301-
47	PIPE; FUEL,RETURN 6HK1-TCS ENG(80L) (B) L=787	8-98127-647-0	01	1	1109-
67	HOSE; FUEL,DELIVERY FUEL TANK 200L FRAME SIDE<N20> (C) L=710	8-98186-527-0	01	1	1109-1205
67	HOSE; FUEL,DELIVERY 6HK1-TCS ENG(80L) WHEEL BASE 3900MM(39W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> (C) L=710	8-98186-527-0	01	1	1206-1212
67	HOSE; FUEL,DELIVERY FUEL TANK 200L FRAME SIDE<N20> EXC. COLOMBIA EQUIPMENT(CB7) (C) L=710	8-98186-527-0	01	1	1206-1212
67	HOSE; FUEL,DELIVERY 6HK1-TCS ENG(80L) WHEEL BASE 3900MM(39W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> EXC. BIO DIESEL FUEL B10<8NV> (C) L=710	8-98186-527-0	01	1	1301-
67	HOSE; FUEL,DELIVERY FUEL TANK 200L FRAME SIDE<N20> EXC. COLOMBIA EQUIPMENT(CB7) (C) L=710	8-98186-527-0	01	1	1301-
67	HOSE; FUEL,DELIVERY FUEL TANK 200L FRAME SIDE<N20> (D) L=1380	8-98186-528-0	01	1	1109-1205
67	HOSE; FUEL,DELIVERY 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> (D) L=1380	8-98186-528-0	01	1	1206-1212
67	HOSE; FUEL,DELIVERY FUEL TANK 200L FRAME SIDE<N20> EXC. COLOMBIA EQUIPMENT(CB7) (D) L=1380	8-98186-528-0	01	1	1206-1212
67	HOSE; FUEL,DELIVERY 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> EXC. BIO DIESEL FUEL B10<8NV> (D) L=1380	8-98186-528-0	01	1	1301-
67	HOSE; FUEL,DELIVERY FUEL TANK 200L FRAME SIDE<N20> EXC. COLOMBIA EQUIPMENT(CB7) (D) L=1380	8-98186-528-0	01	1	1301-
67	HOSE; FUEL,DELIVERY FUEL TANK 400L<SDH> (C) L=980 SERVICED BY L=3000	0-01260-300-0	01	1	1109-1205
67	HOSE; FUEL,DELIVERY COLOMBIA EQUIPMENT(CB7) FUEL TANK 400L<SDH> (C) L=920 SERVICED BY L=3000	0-01260-300-0	01	1	1206-1212
67	HOSE; FUEL,DELIVERY COLOMBIA EQUIPMENT(CB7) FUEL TANK 400L<SDH> EXC. BIO DIESEL FUEL B10<8NV> (C) L=920 SERVICED BY L=3000	0-01260-300-0	01	1	1301-
67	HOSE; FUEL,DELIVERY FUEL TANK 400L<SDH> (C) L=1600 SERVICED BY L=3000	0-01260-300-0	01	1	1109-1212
67	HOSE; FUEL,DELIVERY FUEL TANK 400L<SDH> EXC. BIO DIESEL FUEL B10<8NV> (C) L=1600 SERVICED BY L=3000	0-01260-300-0	01	1	1301-
67	HOSE; FUEL,DELIVERY (C) L=110 SERVICED BY L=3000	0-01260-300-0	01	1	1109-1212
67	HOSE; FUEL,DELIVERY EXC. BIO DIESEL FUEL B10<8NV> (C) L=110 SERVICED BY L=3000	0-01260-300-0	01	1	1301-
67	HOSE; FUEL,DELIVERY (B) L=210 SERVICED BY L=3000	0-01558-300-0	01	1	1109-
67	HOSE; FUEL,DELIVERY FUEL TANK 400L<SDH> EXC. COLOMBIA EQUIPMENT(CB7) (C) L=980 SERVICED BY L=3000	0-01260-300-0	01	1	1206-
67	HOSE; FUEL,DELIVERY 6HK1-TCS ENG(80L) WHEEL BASE 5500MM(55W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> (C) L=730	8-98205-834-0	01	1	1206-1212
67	HOSE; FUEL,DELIVERY 6HK1-TCS ENG(80L) WHEEL BASE 5000MM(50W),WHEEL BASE 5500MM(55W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> EXC. BIO DIESEL FUEL B10<8NV> (C) L=730	8-98205-834-0	01	1	1301-
67	HOSE; FUEL,DELIVERY 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) (E) L=300	8-98157-878-0	01	1	1206-1212
67	HOSE; FUEL,DELIVERY 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) EXC. BIO DIESEL FUEL B10<8NV> (E) L=300	8-98157-878-0	01	1	1301-
67	HOSE; FUEL,DELIVERY 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> (F) L=900	8-98157-879-0	01	1	1206-1212
67	HOSE; FUEL,DELIVERY 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> EXC. BIO DIESEL FUEL B10<8NV> (F) L=900	8-98157-879-0	01	1	1301-
67	HOSE; FUEL,DELIVERY COLOMBIA EQUIPMENT(CB7) FUEL TANK 400L<SDH> BIO DIESEL FUEL B10<8NV> (D) L=1620	8-98232-241-0	01	1	1301-
67	HOSE; FUEL,DELIVERY COLOMBIA EQUIPMENT(CB7) FUEL TANK 400L<SDH> BIO DIESEL FUEL B10<8NV> (C) L=920	8-98232-244-0	01	1	1301-
67	HOSE; FUEL,DELIVERY WHEEL BASE 5000MM(50W),WHEEL BASE 5500MM(55W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> (C) L=730	8-98232-243-0	01	1	1301-
67	HOSE; FUEL,DELIVERY BIO DIESEL FUEL B10<8NV> (A) L=110 SERVICED BY L=3000	0-01859-300-0	01	1	1301-
67	HOSE; FUEL,DELIVERY COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> (D) L=1380	8-98232-240-0	01	1	1301-1304
67	HOSE; FUEL,DELIVERY WHEEL BASE 5000MM(50W),WHEEL BASE 5500MM(55W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> (D) L=1380	8-98232-240-0	01	1	1305-
67	HOSE; FUEL,DELIVERY 6HK1-TCS ENG(80L) WHEEL BASE 3900MM(39W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> (C)	8-98232-911-0	01	1	1301-1304
67	HOSE; FUEL,DELIVERY WHEEL BASE 3900MM(39W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> (C)	8-98238-196-0	01	1	1305-
67	HOSE; FUEL,DELIVERY WHEEL BASE 3900MM(39W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> (D)	8-98238-197-0	01	1	1305-
174	PIPE; FUEL,FEED,FRT 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) L=548	8-98117-708-0	01	1	1206-1212
174	PIPE; FUEL,FEED,FRT 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) EXC. BIO DIESEL FUEL B10<8NV> L=548	8-98117-708-0	01	1	1301-
174	PIPE; FUEL,FEED,FRT L=685	8-98129-920-0	01	1	1109-1205
174	PIPE; FUEL,FEED,FRT 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) L=685	8-98129-920-0	01	1	1206-1212
174	PIPE; FUEL,FEED,FRT EXC. COLOMBIA EQUIPMENT(CB7) L=685	8-98129-920-0	01	1	1206-1212
174	PIPE; FUEL,FEED,FRT 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) L=685	8-98129-920-0	01	1	1301-
174	PIPE; FUEL,FEED,FRT 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) BIO DIESEL FUEL B10<8NV> L=685	8-98129-920-0	01	1	1301-
174	PIPE; FUEL,FEED,FRT EXC. COLOMBIA EQUIPMENT(CB7) L=685	8-98129-920-0	01	1	1301-
634	HOSE; RUBBER RETURN 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) L=1050	8-98128-212-0	01	1	1206-1212
634	HOSE; RUBBER RETURN 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) EXC. BIO DIESEL FUEL B10<8NV> L=1050	8-98128-212-0	01	1	1301-
634	HOSE; RUBBER RETURN 6HK1-TCN ENG(82L) FUEL TANK 200L FRAME SIDE<N20> L=810	8-98186-973-0	01	1	1109-1205
634	HOSE; RUBBER RETURN 6HK1-TCN ENG(82L) FUEL TANK 200L FRAME SIDE<N20> EXC. COLOMBIA EQUIPMENT(CB7) L=810	8-98186-973-0	01	1	1206-1212
634	HOSE; RUBBER RETURN 6HK1-TCN ENG(82L) FUEL TANK 200L FRAME SIDE<N20> EXC. COLOMBIA EQUIPMENT(CB7) L=810	8-98186-973-0	01	1	1301-
634	HOSE; RUBBER RETURN 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> L=810	8-98186-973-0	01	1	1301-
634	HOSE; RUBBER RETURN 6HK1-TCS ENG(80L) FUEL TANK 200L FRAME SIDE<N20>	8-98186-971-0	01	1	1109-
634	HOSE; RUBBER RETURN 6HK1-TCS ENG(80L) FUEL TANK 400L<SDH> L=900 SERVICED BY L=3000	0-01558-300-0	01	1	1109-

67 41 41 634 41 55 97 41 80 83 24 41 80 97 634 95 41 41 66 95 47 80 83 41 98 308 103 97 174 47 41 83 66 41 634 67 41 303 304 41 29 41 40 634 39 67 41

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date
24	CLIP; FUEL HOSE 6HK1-TCN ENG(82L) FUEL TANK 400L<SDH> BIO DIESEL FUEL B10<8NV> ID=15 & 19 H=33 L=25	1-09701-317-0	01	1	1301-
29	HOSE; FUEL BIO DIESEL FUEL B10<8NV> (A)	8-98156-579-0	01	1	1301-
29	HOSE; FUEL (A)	8-98078-196-2	01	1	1109-1212
29	HOSE; FUEL EXC. BIO DIESEL FUEL B10<8NV> (A)	8-98078-196-2	01	1	1301-
29	HOSE; FUEL (B)	8-98078-197-1	01	1	1109-
29	HOSE; FUEL FUEL TANK 400L<SDH> (C) L=60 SERVICED BY L=3000	0-01259-300-0	01	1	1109-
39	PIPE; FUEL (A) NPTF3/8-18 OD=10	8-98122-953-0	02	1	1109-
39	PIPE; FUEL FUEL TANK 400L<SDH> (B)	8-98009-438-1	01	1	1109-
41	CLIP; FUEL PIPE,FUEL TANK WHEEL BASE 3900MM(39W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> (E) L=250	5-09707-030-1	06	1	1305-
41	CLIP; FUEL PIPE,FUEL TANK COLOMBIA EQUIPMENT(CB7) BIO DIESEL FUEL B10<8NV> (F) ID=24 & 24 L=49	1-09701-018-0	01	1	1301-1304
41	CLIP; FUEL PIPE,FUEL TANK WHEEL BASE 5000MM(50W),WHEEL BASE 5500MM(55W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> (F) ID=24 & 24 L=49	1-09701-018-0	01	1	1305-
41	CLIP; FUEL PIPE,FUEL TANK COLOMBIA EQUIPMENT(CB7) FUEL TANK 400L<SDH> BIO DIESEL FUEL B10<8NV> (F) ID=24 & 24 L=49	1-09701-018-0	01	1	1305-
41	CLIP; FUEL PIPE,FUEL TANK BIO DIESEL FUEL B10<8NV> (D) ID=16	8-94238-568-0	06	1	1301-
41	CLIP; FUEL PIPE,FUEL TANK 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) (B) ID=11 & 9 L=17.5 & 17.5	1-09700-747-0	02	1	1206-1212
41	CLIP; FUEL PIPE,FUEL TANK 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) EXC. BIO DIESEL FUEL B10<8NV> (B) ID=11 & 9 L=17.5 & 17.5	1-09700-747-0	02	1	1301-
41	CLIP; FUEL PIPE,FUEL TANK 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> (E) L=250	5-09707-030-1	02	1	1206-1212
41	CLIP; FUEL PIPE,FUEL TANK 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> EXC. BIO DIESEL FUEL B10<8NV> (E) L=250	5-09707-030-1	02	1	1301-
41	CLIP; FUEL PIPE,FUEL TANK (B) ID=11 & 9 L=17.5 & 17.5	1-09700-747-0	03	1	1109-1205
41	CLIP; FUEL PIPE,FUEL TANK 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) (B) ID=11 & 9 L=17.5 & 17.5	1-09700-747-0	03	1	1206-1212
41	CLIP; FUEL PIPE,FUEL TANK EXC. COLOMBIA EQUIPMENT(CB7) (B) ID=11 & 9 L=17.5 & 17.5	1-09700-747-0	03	1	1206-1212
41	CLIP; FUEL PIPE,FUEL TANK 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) (B) ID=11 & 9 L=17.5 & 17.5	1-09700-747-0	03	1	1301-
41	CLIP; FUEL PIPE,FUEL TANK 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) BIO DIESEL FUEL B10<8NV> (B) ID=11 & 9 L=17.5 & 17.5	1-09700-747-0	03	1	1301-
41	CLIP; FUEL PIPE,FUEL TANK EXC. COLOMBIA EQUIPMENT(CB7) (B) ID=11 & 9 L=17.5 & 17.5	1-09700-747-0	03	1	1301-
41	CLIP; FUEL PIPE,FUEL TANK (F) ID=14X29 H=30 L=25	1-09701-101-0	01	1	1109-1205
41	CLIP; FUEL PIPE,FUEL TANK 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) (F) ID=14X29 H=30 L=25	1-09701-101-0	01	1	1206-1212
41	CLIP; FUEL PIPE,FUEL TANK EXC. COLOMBIA EQUIPMENT(CB7) (F) ID=14X29 H=30 L=25	1-09701-101-0	01	1	1206-1212
41	CLIP; FUEL PIPE,FUEL TANK 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) EXC. BIO DIESEL FUEL B10<8NV> (F) ID=14X29 H=30 L=25	1-09701-101-0	01	1	1301-
41	CLIP; FUEL PIPE,FUEL TANK EXC. COLOMBIA EQUIPMENT(CB7) (F) ID=14X29 H=30 L=25	1-09701-101-0	01	1	1301-
41	CLIP; FUEL PIPE,FUEL TANK (C) ID=14	1-09704-102-0	06	1	1109-1212
41	CLIP; FUEL PIPE,FUEL TANK EXC. BIO DIESEL FUEL B10<8NV> (C) ID=14	1-09704-102-0	06	1	1301-
41	CLIP; FUEL PIPE,FUEL TANK (D) ID=16	8-94238-568-0	02	1	1109-
41	CLIP; FUEL PIPE,FUEL TANK FUEL TANK 200L FRAME SIDE<N20> (E) L=250	5-09707-030-1	05	1	1109-1205
41	CLIP; FUEL PIPE,FUEL TANK 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> (E) L=250	5-09707-030-1	05	1	1206-1212
41	CLIP; FUEL PIPE,FUEL TANK FUEL TANK 200L FRAME SIDE<N20> EXC. COLOMBIA EQUIPMENT(CB7) (E) L=250	5-09707-030-1	05	1	1206-1212
41	CLIP; FUEL PIPE,FUEL TANK 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> (E) L=250	5-09707-030-1	05	1	1301-1304
41	CLIP; FUEL PIPE,FUEL TANK 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> (E) L=250	5-09707-030-1	05	1	1301-1304
41	CLIP; FUEL PIPE,FUEL TANK FUEL TANK 200L FRAME SIDE<N20> EXC. COLOMBIA EQUIPMENT(CB7) (E) L=250	5-09707-030-1	05	1	1301-1304
41	CLIP; FUEL PIPE,FUEL TANK WHEEL BASE 5000MM(50W),WHEEL BASE 5500MM(55W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> (E) L=250	5-09707-030-1	05	1	1305-
41	CLIP; FUEL PIPE,FUEL TANK 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> EXC. BIO DIESEL FUEL B10<8NV> (E) L=250	5-09707-030-1	05	1	1305-
41	CLIP; FUEL PIPE,FUEL TANK FUEL TANK 200L FRAME SIDE<N20> EXC. COLOMBIA EQUIPMENT(CB7) (E) L=250	5-09707-030-1	05	1	1305-
41	CLIP; FUEL PIPE,FUEL TANK FUEL TANK 400L<SDH> (E) L=250	5-09707-030-1	03	1	1109-
41	CLIP; FUEL PIPE,FUEL TANK 6HK1-TCN ENG(82L) (A) ID=13	8-94238-571-0	06	1	1109-
41	CLIP; FUEL PIPE,FUEL TANK 6HK1-TCS ENG(80L) (G) ID=9 & 9 L=17 & 17	1-09700-651-0	02	1	1109-
41	CLIP; FUEL PIPE,FUEL TANK 6HK1-TCS ENG(80L) (A) ID=13	8-94238-571-0	08	1	1109-
47	PIPE; FUEL,RETURN 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) (A) L=539	8-98117-709-0	01	1	1206-1212
47	PIPE; FUEL,RETURN 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) EXC. BIO DIESEL FUEL B10<8NV> (A) L=539	8-98117-709-0	01	1	1301-
47	PIPE; FUEL,RETURN (A) L=688	8-98129-921-0	01	1	1109-1205
47	PIPE; FUEL,RETURN 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) (A) L=688	8-98129-921-0	01	1	1206-1212
47	PIPE; FUEL,RETURN EXC. COLOMBIA EQUIPMENT(CB7) (A) L=688	8-98129-921-0	01	1	1206-1212
47	PIPE; FUEL,RETURN 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) (A) L=688	8-98129-921-0	01	1	1301-
47	PIPE; FUEL,RETURN 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) BIO DIESEL FUEL B10<8NV> (A) L=688	8-98129-921-0	01	1	1301-
47	PIPE; FUEL,RETURN EXC. COLOMBIA EQUIPMENT(CB7) (A) L=688	8-98129-921-0	01	1	1301-
47	PIPE; FUEL,RETURN 6HK1-TCS ENG(80L) (B) L=787	8-98127-647-0	01	1	1109-
55	COVER; PIPE,FUEL TANK FUEL TANK 200L FRAME SIDE<N20> L=150 SERVICED BY L=1300	1-09360-677-1	02	1	1109-1212
55	COVER; PIPE,FUEL TANK FUEL TANK 200L FRAME SIDE<N20> L=150 SERVICED BY L=1300	1-09360-677-1	02	1	1301-
55	COVER; PIPE,FUEL TANK FUEL TANK 400L<SDH> BIO DIESEL FUEL B10<8NV> L=150 SERVICED BY L=1300	1-09360-677-1	02	1	1301-
55	COVER; PIPE,FUEL TANK FUEL TANK 400L<SDH> L=150 SERVICED BY L=1300	1-09360-677-1	03	1	1109-1212
55	COVER; PIPE,FUEL TANK FUEL TANK 400L<SDH> EXC. BIO DIESEL FUEL B10<8NV> L=150 SERVICED BY L=1300	1-09360-677-1	03	1	1301-
66	HOSE; FUEL,RETURN PIPE 6HK1-TCS ENG(80L) L=180 SERVICED BY L=3000	0-01558-300-0	01	1	1109-
67	HOSE; FUEL,DELIVERY FUEL TANK 200L FRAME SIDE<N20> (C) L=710	8-98186-527-0	01	1	1109-1205
67	HOSE; FUEL,DELIVERY 6HK1-TCS ENG(80L) WHEEL BASE 3900MM(39W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> (C) L=710	8-98186-527-0	01	1	1206-1212
67	HOSE; FUEL,DELIVERY FUEL TANK 200L FRAME SIDE<N20> EXC. COLOMBIA EQUIPMENT(CB7) (C) L=710	8-98186-527-0	01	1	1206-1212
67	HOSE; FUEL,DELIVERY 6HK1-TCS ENG(80L) WHEEL BASE 3900MM(39W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> EXC. BIO DIESEL FUEL B10<8NV> (C) L=710	8-98186-527-0	01	1	1301-
67	HOSE; FUEL,DELIVERY FUEL TANK 200L FRAME SIDE<N20> EXC. COLOMBIA EQUIPMENT(CB7) (C) L=710	8-98186-527-0	01	1	1301-
67	HOSE; FUEL,DELIVERY FUEL TANK 200L FRAME SIDE<N20> (D) L=1380	8-98186-528-0	01	1	1109-1205
67	HOSE; FUEL,DELIVERY 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> (D) L=1380	8-98186-528-0	01	1	1206-1212
67	HOSE; FUEL,DELIVERY FUEL TANK 200L FRAME SIDE<N20> EXC. COLOMBIA EQUIPMENT(CB7) (D) L=1380	8-98186-528-0	01	1	1206-1212
67	HOSE; FUEL,DELIVERY 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> EXC. BIO DIESEL FUEL B10<8NV> (D) L=1380	8-98186-528-0	01	1	1301-
67	HOSE; FUEL,DELIVERY FUEL TANK 200L FRAME SIDE<N20> EXC. COLOMBIA EQUIPMENT(CB7) (D) L=1380	8-98186-528-0	01	1	1301-
67	HOSE; FUEL,DELIVERY FUEL TANK 400L<SDH> (C) L=980 SERVICED BY L=3000	0-01260-300-0	01	1	1109-1205
67	HOSE; FUEL,DELIVERY COLOMBIA EQUIPMENT(CB7) FUEL TANK 400L<SDH> (C) L=920 SERVICED BY L=3000	0-01260-300-0	01	1	1206-1212
67	HOSE; FUEL,DELIVERY COLOMBIA EQUIPMENT(CB7) FUEL TANK 400L<SDH> EXC. BIO DIESEL FUEL B10<8NV> (C) L=920 SERVICED BY L=3000	0-01260-300-0	01	1	1301-
67	HOSE; FUEL,DELIVERY FUEL TANK 400L<SDH> (C) L=1600 SERVICED BY L=3000	0-01260-300-0	01	1	1109-1212
67	HOSE; FUEL,DELIVERY FUEL TANK 400L<SDH> EXC. BIO DIESEL FUEL B10<8NV> (C) L=1600 SERVICED BY L=3000	0-01260-300-0	01	1	1301-
67	HOSE; FUEL,DELIVERY (C) L=110 SERVICED BY L=3000	0-01260-300-0	01	1	1109-1212
67	HOSE; FUEL,DELIVERY EXC. BIO DIESEL FUEL B10<8NV> (C) L=110 SERVICED BY L=3000	0-01260-300-0	01	1	1301-
67	HOSE; FUEL,DELIVERY (B) L=210 SERVICED BY L=3000	0-01558-300-0	01	1	1109-
67	HOSE; FUEL,DELIVERY FUEL TANK 400L<SDH> EXC. COLOMBIA EQUIPMENT(CB7) (C) L=980 SERVICED BY L=3000	0-01260-300-0	01	1	1206-
67	HOSE; FUEL,DELIVERY 6HK1-TCS ENG(80L) WHEEL BASE 5500MM(55W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> (C) L=730	8-98205-834-0	01	1	1206-1212
67	HOSE; FUEL,DELIVERY 6HK1-TCS ENG(80L) WHEEL BASE 5000MM(50W),WHEEL BASE 5500MM(55W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> EXC. BIO DIESEL FUEL B10<8NV> (C) L=730	8-98205-834-0	01	1	1301-
67	HOSE; FUEL,DELIVERY 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) (E) L=300	8-98157-878-0	01	1	1206-1212
67	HOSE; FUEL,DELIVERY 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) EXC. BIO DIESEL FUEL B10<8NV> (E) L=300	8-98157-878-0	01	1	1301-
67	HOSE; FUEL,DELIVERY 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> (F) L=900	8-98157-879-0	01	1	1206-1212
67	HOSE; FUEL,DELIVERY 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> EXC. BIO DIESEL FUEL B10<8NV> (F) L=900	8-98157-879-0	01	1	1301-
67	HOSE; FUEL,DELIVERY COLOMBIA EQUIPMENT(CB7) FUEL TANK 400L<SDH> BIO DIESEL FUEL B10<8NV> (D) L=1620	8-98232-241-0	01	1	1301-
67	HOSE; FUEL,DELIVERY COLOMBIA EQUIPMENT(CB7) FUEL TANK 400L<SDH> BIO DIESEL FUEL B10<8NV> (C) L=920	8-98232-244-0	01	1	1301-
67	HOSE; FUEL,DELIVERY WHEEL BASE 5000MM(50W),WHEEL BASE 5500MM(55W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> (C) L=730	8-98232-243-0	01	1	1301-
67	HOSE; FUEL,DELIVERY BIO DIESEL FUEL B10<8NV> (A) L=110 SERVICED BY L=3000	0-01859-300-0	01	1	1301-
67	HOSE; FUEL,DELIVERY COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> (D) L=1380	8-98232-240-0	01	1	1301-1304
67	HOSE; FUEL,DELIVERY WHEEL BASE 5000MM(50W),WHEEL BASE 5500MM(55W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> (D) L=1380	8-98232-240-0	01	1	1305-
67	HOSE; FUEL,DELIVERY 6HK1-TCS ENG(80L) WHEEL BASE 3900MM(39W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> (C)	8-98232-911-0	01	1	1301-1304
67	HOSE; FUEL,DELIVERY WHEEL BASE 3900MM(39W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> (C)	8-98238-196-0	01	1	1305-
67	HOSE; FUEL,DELIVERY WHEEL BASE 3900MM(39W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> (D)	8-98238-197-0	01	1	1305-
80	BOLT; CLIP,FUEL TANK M8X20 FLANGE	0-28650-820-0	02	1	1109-
80	BOLT; CLIP,FUEL TANK 6HK1-TCS ENG(80L) M8X20 FLANGE	0-28650-820-0	02	1	1109-
80	BOLT; CLIP,FUEL TANK M8X30 FLANGE	0-28650-830-0	01	1	1109-1205
80	BOLT; CLIP,FUEL TANK 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) M8X30 FLANGE	0-28650-830-0	01	1	1206-1212
80	BOLT; CLIP,FUEL TANK EXC. COLOMBIA EQUIPMENT(CB7) M8X30 FLANGE	0-28650-830-0	01	1	1206-1212
80	BOLT; CLIP,FUEL TANK 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) M8X30 FLANGE	0-28650-830-0	01	1	1301-1304
80	BOLT; CLIP,FUEL TANK 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) BIO DIESEL FUEL B10<8NV> M8X30 FLANGE	0-28650-830-0	01	1	1301-1304
80	BOLT; CLIP,FUEL TANK EXC. COLOMBIA EQUIPMENT(CB7) M8X30 FLANGE	0-28650-830-0	01	1	1301-1304
80	BOLT; CLIP,FUEL TANK WHEEL BASE 5000MM(50W),WHEEL BASE 5500MM(55W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> M8X30 FLANGE	0-28650-830-0	01	1	1305-
80	BOLT; CLIP,FUEL TANK 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) FUEL TANK 400L<SDH> BIO DIESEL FUEL B10<8NV> M8X30 FLANGE	0-28650-830-0	01	1	1305-
80	BOLT; CLIP,FUEL TANK 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) EXC. BIO DIESEL FUEL B10<8NV> M8X30 FLANGE	0-28650-830-0	01	1	1305-
80	BOLT; CLIP,FUEL TANK EXC. COLOMBIA EQUIPMENT(CB7) M8X30 FLANGE	0-28650-830-0	01	1	1305-
83	NUT; CLIP,FUEL TANK M8 FLANGE	0-91180-108-0	03	1	1109-1205
83	NUT; CLIP,FUEL TANK 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) M8 FLANGE	0-91180-108-0	03	1	1206-1212
83	NUT; CLIP,FUEL TANK EXC. COLOMBIA EQUIPMENT(CB7) M8 FLANGE	0-91180-108-0	03	1	1206-1212
83	NUT; CLIP,FUEL TANK 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) M8 FLANGE	0-91180-108-0	03	1	1301-
83	NUT; CLIP,FUEL TANK 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) BIO DIESEL FUEL B10<8NV> M8 FLANGE	0-91180-108-0	03	1	1301-
83	NUT; CLIP,FUEL TANK EXC. COLOMBIA EQUIPMENT(CB7) M8 FLANGE	0-91180-108-0	03	1	1301-
83	NUT; CLIP,FUEL TANK FUEL TANK 400L<SDH> M8 FLANGE	0-91180-108-0	01	1	1109-
83	NUT; CLIP,FUEL TANK 6HK1-TCS ENG(80L) M8 FLANGE	0-91180-108-0	02	1	1109-1205
83	NUT; CLIP,FUEL TANK 6HK1-TCS ENG(80L) M8 FLANGE	0-91180-108-0	02	1	1206-1212
83	NUT; CLIP,FUEL TANK 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) M8 FLANGE	0-91180-108-0	02	1	1206-1212
83	NUT; CLIP,FUEL TANK 6HK1-TCS ENG(80L) M8 FLANGE	0-91180-108-0	02	1	1301-
83	NUT; CLIP,FUEL TANK 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) EXC. BIO DIESEL FUEL B10<8NV> M8 FLANGE	0-91180-108-0	02	1	1301-
95	BUSHING; PIPE,FUEL TANK 6HK1-TCS ENG(80L) EXC. HEAVY DUTY PACKAGE TRUCK VAR3<Y48> ID=28 OD=35 T=17	9-09956-256-2	02	1	1206-
95	BUSHING; PIPE,FUEL TANK 6HK1-TCS ENG(80L) ID=28 OD=35 T=25	1-09332-011-1	02	1	1109-1205
95	BUSHING; PIPE,FUEL TANK 6HK1-TCS ENG(80L) HEAVY DUTY PACKAGE TRUCK VAR3<Y48> ID=28 OD=35 T=25	1-09332-011-1	02	1	1206-
97	BRACKET; CLIP WHEEL BASE 3900MM(39W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> (E)	8-98238-178-0	01	1	1305-
97	BRACKET; CLIP 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) (D)	8-98126-612-0	01	1	1206-1212
97	BRACKET; CLIP 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) EXC. BIO DIESEL FUEL B10<8NV> (D)	8-98126-612-0	01	1	1301-
97	BRACKET; CLIP (C) L=50	1-47475-299-2	01	1	1109-1205
97	BRACKET; CLIP 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) (C) L=50	1-47475-299-2	01	1	1206-1212
97	BRACKET; CLIP EXC. COLOMBIA EQUIPMENT(CB7) (C) L=50	1-47475-299-2	01	1	1206-1212
97	BRACKET; CLIP 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) (C) L=50	1-47475-299-2	01	1	1301-
97	BRACKET; CLIP 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) BIO DIESEL FUEL B10<8NV> (C) L=50	1-47475-299-2	01	1	1301-
97	BRACKET; CLIP EXC. COLOMBIA EQUIPMENT(CB7) (C) L=50	1-47475-299-2	01	1	1301-
97	BRACKET; CLIP (A)	8-98053-654-0	01	1	1109-
97	BRACKET; CLIP (B)	8-98129-922-0	01	1	1109-1205
97	BRACKET; CLIP 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) (B)	8-98129-922-0	01	1	1206-1212
97	BRACKET; CLIP EXC. COLOMBIA EQUIPMENT(CB7) (B)	8-98129-922-0	01	1	1206-1212
97	BRACKET; CLIP 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) (B)	8-98129-922-0	01	1	1301-
97	BRACKET; CLIP 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) BIO DIESEL FUEL B10<8NV> (B)	8-98129-922-0	01	1	1301-
97	BRACKET; CLIP EXC. COLOMBIA EQUIPMENT(CB7) (B)	8-98129-922-0	01	1	1301-
98	BOLT; BRKT,FUEL PIPE 6HK1-TCS ENG(80L) M8X30 FLANGE	0-28650-830-0	02	1	1109-
103	NUT; BRKT 6HK1-TCS ENG(80L) M8 FLANGE	0-91180-108-0	02	1	1109-
174	PIPE; FUEL,FEED,FRT 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) L=548	8-98117-708-0	01	1	1206-1212
174	PIPE; FUEL,FEED,FRT 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) EXC. BIO DIESEL FUEL B10<8NV> L=548	8-98117-708-0	01	1	1301-
174	PIPE; FUEL,FEED,FRT L=685	8-98129-920-0	01	1	1109-1205
174	PIPE; FUEL,FEED,FRT 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) L=685	8-98129-920-0	01	1	1206-1212
174	PIPE; FUEL,FEED,FRT EXC. COLOMBIA EQUIPMENT(CB7) L=685	8-98129-920-0	01	1	1206-1212
174	PIPE; FUEL,FEED,FRT 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) L=685	8-98129-920-0	01	1	1301-
174	PIPE; FUEL,FEED,FRT 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) BIO DIESEL FUEL B10<8NV> L=685	8-98129-920-0	01	1	1301-
174	PIPE; FUEL,FEED,FRT EXC. COLOMBIA EQUIPMENT(CB7) L=685	8-98129-920-0	01	1	1301-
303	BOLT; BRKT WHEEL BASE 3900MM(39W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> (A) M8X35 FLANGE	0-28650-835-0	01	1	1305-
303	BOLT; BRKT (A) M8X35 FLANGE	0-28650-835-0	02	1	1109-1205
303	BOLT; BRKT 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) (A) M8X35 FLANGE	0-28650-835-0	02	1	1206-1212
303	BOLT; BRKT EXC. COLOMBIA EQUIPMENT(CB7) (A) M8X35 FLANGE	0-28650-835-0	02	1	1206-1212
303	BOLT; BRKT 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) (A) M8X35 FLANGE	0-28650-835-0	02	1	1301-
303	BOLT; BRKT 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) BIO DIESEL FUEL B10<8NV> (A) M8X35 FLANGE	0-28650-835-0	02	1	1301-
303	BOLT; BRKT EXC. COLOMBIA EQUIPMENT(CB7) (A) M8X35 FLANGE	0-28650-835-0	02	1	1301-
303	BOLT; BRKT EXC. FUEL TANK 400L<SDH> (B) M10X35 FLANGE	0-28651-035-0	02	1	1109-1205
303	BOLT; BRKT 6HK1-TCS ENG(80L) WHEEL BASE 3900MM(39W) COLOMBIA EQUIPMENT(CB7) EXC. FUEL TANK 400L<SDH> (B) M10X35 FLANGE	0-28651-035-0	02	1	1206-1212
303	BOLT; BRKT 6HK1-TCN ENG(82L) WHEEL BASE 5000MM(50W) COLOMBIA EQUIPMENT(CB7) EXC. FUEL TANK 400L<SDH> (B) M10X35 FLANGE	0-28651-035-0	02	1	1206-1212
303	BOLT; BRKT EXC. COLOMBIA EQUIPMENT(CB7),FUEL TANK 400L<SDH> (B) M10X35 FLANGE	0-28651-035-0	02	1	1206-1212
303	BOLT; BRKT 6HK1-TCS ENG(80L) WHEEL BASE 3900MM(39W) COLOMBIA EQUIPMENT(CB7) EXC. FUEL TANK 400L<SDH> (B) M10X35 FLANGE	0-28651-035-0	02	1	1301-
303	BOLT; BRKT EXC. COLOMBIA EQUIPMENT(CB7),FUEL TANK 400L<SDH> (B) M10X35 FLANGE	0-28651-035-0	02	1	1301-
304	NUT; BRKT 6HK1-TCN ENG(82L) WHEEL BASE 5000MM(50W) COLOMBIA EQUIPMENT(CB7) EXC. FUEL TANK 400L<SDH> (B) M10 FLANGE	0-91180-210-0	01	1	1206-1212
304	NUT; BRKT (A) M8 FLANGE	0-91180-108-0	03	1	1109-
304	NUT; BRKT (B) M10 FLANGE	0-91180-210-0	02	1	1109-1205
304	NUT; BRKT EXC. FUEL TANK 400L<SDH> (B) M10 FLANGE	0-91180-210-0	02	1	1109-1205
304	NUT; BRKT (B) M10 FLANGE	0-91180-210-0	02	1	1206-
304	NUT; BRKT 6HK1-TCS ENG(80L) WHEEL BASE 3900MM(39W) COLOMBIA EQUIPMENT(CB7) EXC. FUEL TANK 400L<SDH> (B) M10 FLANGE	0-91180-210-0	02	1	1206-
304	NUT; BRKT EXC. COLOMBIA EQUIPMENT(CB7),FUEL TANK 400L<SDH> (B) M10 FLANGE	0-91180-210-0	02	1	1206-
308	BRACKET; FUEL PIPE 6HK1-TCS ENG(80L) L=75	1-47478-323-0	02	1	1109-
634	HOSE; RUBBER RETURN 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) L=1050	8-98128-212-0	01	1	1206-1212
634	HOSE; RUBBER RETURN 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) EXC. BIO DIESEL FUEL B10<8NV> L=1050	8-98128-212-0	01	1	1301-
634	HOSE; RUBBER RETURN 6HK1-TCN ENG(82L) FUEL TANK 200L FRAME SIDE<N20> L=810	8-98186-973-0	01	1	1109-1205
634	HOSE; RUBBER RETURN 6HK1-TCN ENG(82L) FUEL TANK 200L FRAME SIDE<N20> EXC. COLOMBIA EQUIPMENT(CB7) L=810	8-98186-973-0	01	1	1206-1212
634	HOSE; RUBBER RETURN 6HK1-TCN ENG(82L) FUEL TANK 200L FRAME SIDE<N20> EXC. COLOMBIA EQUIPMENT(CB7) L=810	8-98186-973-0	01	1	1301-
634	HOSE; RUBBER RETURN 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> L=810	8-98186-973-0	01	1	1301-
634	HOSE; RUBBER RETURN 6HK1-TCS ENG(80L) FUEL TANK 200L FRAME SIDE<N20>	8-98186-971-0	01	1	1109-
634	HOSE; RUBBER RETURN 6HK1-TCS ENG(80L) FUEL TANK 400L<SDH> L=900 SERVICED BY L=3000	0-01558-300-0	01	1	1109-

304 67 67 41 39 279 228 345 345 303 41 39 418 304 80 97 304 47 41 83 41 67 634 41 174 623 634 41 67 41 41 124 55

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date
39	PIPE; FUEL (A) NPTF3/8-18 OD=10	8-98122-953-0	02	1	1109-
39	PIPE; FUEL FUEL TANK 400L<SDH> (B)	8-98009-438-1	01	1	1109-
41	CLIP; FUEL PIPE,FUEL TANK WHEEL BASE 3900MM(39W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> (E) L=250	5-09707-030-1	06	1	1305-
41	CLIP; FUEL PIPE,FUEL TANK COLOMBIA EQUIPMENT(CB7) BIO DIESEL FUEL B10<8NV> (F) ID=24 & 24 L=49	1-09701-018-0	01	1	1301-1304
41	CLIP; FUEL PIPE,FUEL TANK WHEEL BASE 5000MM(50W),WHEEL BASE 5500MM(55W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> (F) ID=24 & 24 L=49	1-09701-018-0	01	1	1305-
41	CLIP; FUEL PIPE,FUEL TANK COLOMBIA EQUIPMENT(CB7) FUEL TANK 400L<SDH> BIO DIESEL FUEL B10<8NV> (F) ID=24 & 24 L=49	1-09701-018-0	01	1	1305-
41	CLIP; FUEL PIPE,FUEL TANK BIO DIESEL FUEL B10<8NV> (D) ID=16	8-94238-568-0	06	1	1301-
41	CLIP; FUEL PIPE,FUEL TANK 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) (B) ID=11 & 9 L=17.5 & 17.5	1-09700-747-0	02	1	1206-1212
41	CLIP; FUEL PIPE,FUEL TANK 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) EXC. BIO DIESEL FUEL B10<8NV> (B) ID=11 & 9 L=17.5 & 17.5	1-09700-747-0	02	1	1301-
41	CLIP; FUEL PIPE,FUEL TANK 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> (E) L=250	5-09707-030-1	02	1	1206-1212
41	CLIP; FUEL PIPE,FUEL TANK 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> EXC. BIO DIESEL FUEL B10<8NV> (E) L=250	5-09707-030-1	02	1	1301-
41	CLIP; FUEL PIPE,FUEL TANK (B) ID=11 & 9 L=17.5 & 17.5	1-09700-747-0	03	1	1109-1205
41	CLIP; FUEL PIPE,FUEL TANK 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) (B) ID=11 & 9 L=17.5 & 17.5	1-09700-747-0	03	1	1206-1212
41	CLIP; FUEL PIPE,FUEL TANK EXC. COLOMBIA EQUIPMENT(CB7) (B) ID=11 & 9 L=17.5 & 17.5	1-09700-747-0	03	1	1206-1212
41	CLIP; FUEL PIPE,FUEL TANK 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) (B) ID=11 & 9 L=17.5 & 17.5	1-09700-747-0	03	1	1301-
41	CLIP; FUEL PIPE,FUEL TANK 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) BIO DIESEL FUEL B10<8NV> (B) ID=11 & 9 L=17.5 & 17.5	1-09700-747-0	03	1	1301-
41	CLIP; FUEL PIPE,FUEL TANK EXC. COLOMBIA EQUIPMENT(CB7) (B) ID=11 & 9 L=17.5 & 17.5	1-09700-747-0	03	1	1301-
41	CLIP; FUEL PIPE,FUEL TANK (F) ID=14X29 H=30 L=25	1-09701-101-0	01	1	1109-1205
41	CLIP; FUEL PIPE,FUEL TANK 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) (F) ID=14X29 H=30 L=25	1-09701-101-0	01	1	1206-1212
41	CLIP; FUEL PIPE,FUEL TANK EXC. COLOMBIA EQUIPMENT(CB7) (F) ID=14X29 H=30 L=25	1-09701-101-0	01	1	1206-1212
41	CLIP; FUEL PIPE,FUEL TANK 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) EXC. BIO DIESEL FUEL B10<8NV> (F) ID=14X29 H=30 L=25	1-09701-101-0	01	1	1301-
41	CLIP; FUEL PIPE,FUEL TANK EXC. COLOMBIA EQUIPMENT(CB7) (F) ID=14X29 H=30 L=25	1-09701-101-0	01	1	1301-
41	CLIP; FUEL PIPE,FUEL TANK (C) ID=14	1-09704-102-0	06	1	1109-1212
41	CLIP; FUEL PIPE,FUEL TANK EXC. BIO DIESEL FUEL B10<8NV> (C) ID=14	1-09704-102-0	06	1	1301-
41	CLIP; FUEL PIPE,FUEL TANK (D) ID=16	8-94238-568-0	02	1	1109-
41	CLIP; FUEL PIPE,FUEL TANK FUEL TANK 200L FRAME SIDE<N20> (E) L=250	5-09707-030-1	05	1	1109-1205
41	CLIP; FUEL PIPE,FUEL TANK 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> (E) L=250	5-09707-030-1	05	1	1206-1212
41	CLIP; FUEL PIPE,FUEL TANK FUEL TANK 200L FRAME SIDE<N20> EXC. COLOMBIA EQUIPMENT(CB7) (E) L=250	5-09707-030-1	05	1	1206-1212
41	CLIP; FUEL PIPE,FUEL TANK 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> (E) L=250	5-09707-030-1	05	1	1301-1304
41	CLIP; FUEL PIPE,FUEL TANK 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> (E) L=250	5-09707-030-1	05	1	1301-1304
41	CLIP; FUEL PIPE,FUEL TANK FUEL TANK 200L FRAME SIDE<N20> EXC. COLOMBIA EQUIPMENT(CB7) (E) L=250	5-09707-030-1	05	1	1301-1304
41	CLIP; FUEL PIPE,FUEL TANK WHEEL BASE 5000MM(50W),WHEEL BASE 5500MM(55W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> (E) L=250	5-09707-030-1	05	1	1305-
41	CLIP; FUEL PIPE,FUEL TANK 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> EXC. BIO DIESEL FUEL B10<8NV> (E) L=250	5-09707-030-1	05	1	1305-
41	CLIP; FUEL PIPE,FUEL TANK FUEL TANK 200L FRAME SIDE<N20> EXC. COLOMBIA EQUIPMENT(CB7) (E) L=250	5-09707-030-1	05	1	1305-
41	CLIP; FUEL PIPE,FUEL TANK FUEL TANK 400L<SDH> (E) L=250	5-09707-030-1	03	1	1109-
41	CLIP; FUEL PIPE,FUEL TANK 6HK1-TCN ENG(82L) (A) ID=13	8-94238-571-0	06	1	1109-
41	CLIP; FUEL PIPE,FUEL TANK 6HK1-TCS ENG(80L) (G) ID=9 & 9 L=17 & 17	1-09700-651-0	02	1	1109-
41	CLIP; FUEL PIPE,FUEL TANK 6HK1-TCS ENG(80L) (A) ID=13	8-94238-571-0	08	1	1109-
47	PIPE; FUEL,RETURN 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) (A) L=539	8-98117-709-0	01	1	1206-1212
47	PIPE; FUEL,RETURN 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) EXC. BIO DIESEL FUEL B10<8NV> (A) L=539	8-98117-709-0	01	1	1301-
47	PIPE; FUEL,RETURN (A) L=688	8-98129-921-0	01	1	1109-1205
47	PIPE; FUEL,RETURN 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) (A) L=688	8-98129-921-0	01	1	1206-1212
47	PIPE; FUEL,RETURN EXC. COLOMBIA EQUIPMENT(CB7) (A) L=688	8-98129-921-0	01	1	1206-1212
47	PIPE; FUEL,RETURN 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) (A) L=688	8-98129-921-0	01	1	1301-
47	PIPE; FUEL,RETURN 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) BIO DIESEL FUEL B10<8NV> (A) L=688	8-98129-921-0	01	1	1301-
47	PIPE; FUEL,RETURN EXC. COLOMBIA EQUIPMENT(CB7) (A) L=688	8-98129-921-0	01	1	1301-
47	PIPE; FUEL,RETURN 6HK1-TCS ENG(80L) (B) L=787	8-98127-647-0	01	1	1109-
55	COVER; PIPE,FUEL TANK FUEL TANK 200L FRAME SIDE<N20> L=150 SERVICED BY L=1300	1-09360-677-1	02	1	1109-1212
55	COVER; PIPE,FUEL TANK FUEL TANK 200L FRAME SIDE<N20> L=150 SERVICED BY L=1300	1-09360-677-1	02	1	1301-
55	COVER; PIPE,FUEL TANK FUEL TANK 400L<SDH> BIO DIESEL FUEL B10<8NV> L=150 SERVICED BY L=1300	1-09360-677-1	02	1	1301-
55	COVER; PIPE,FUEL TANK FUEL TANK 400L<SDH> L=150 SERVICED BY L=1300	1-09360-677-1	03	1	1109-1212
55	COVER; PIPE,FUEL TANK FUEL TANK 400L<SDH> EXC. BIO DIESEL FUEL B10<8NV> L=150 SERVICED BY L=1300	1-09360-677-1	03	1	1301-
67	HOSE; FUEL,DELIVERY FUEL TANK 200L FRAME SIDE<N20> (C) L=710	8-98186-527-0	01	1	1109-1205
67	HOSE; FUEL,DELIVERY 6HK1-TCS ENG(80L) WHEEL BASE 3900MM(39W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> (C) L=710	8-98186-527-0	01	1	1206-1212
67	HOSE; FUEL,DELIVERY FUEL TANK 200L FRAME SIDE<N20> EXC. COLOMBIA EQUIPMENT(CB7) (C) L=710	8-98186-527-0	01	1	1206-1212
67	HOSE; FUEL,DELIVERY 6HK1-TCS ENG(80L) WHEEL BASE 3900MM(39W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> EXC. BIO DIESEL FUEL B10<8NV> (C) L=710	8-98186-527-0	01	1	1301-
67	HOSE; FUEL,DELIVERY FUEL TANK 200L FRAME SIDE<N20> EXC. COLOMBIA EQUIPMENT(CB7) (C) L=710	8-98186-527-0	01	1	1301-
67	HOSE; FUEL,DELIVERY FUEL TANK 200L FRAME SIDE<N20> (D) L=1380	8-98186-528-0	01	1	1109-1205
67	HOSE; FUEL,DELIVERY 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> (D) L=1380	8-98186-528-0	01	1	1206-1212
67	HOSE; FUEL,DELIVERY FUEL TANK 200L FRAME SIDE<N20> EXC. COLOMBIA EQUIPMENT(CB7) (D) L=1380	8-98186-528-0	01	1	1206-1212
67	HOSE; FUEL,DELIVERY 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> EXC. BIO DIESEL FUEL B10<8NV> (D) L=1380	8-98186-528-0	01	1	1301-
67	HOSE; FUEL,DELIVERY FUEL TANK 200L FRAME SIDE<N20> EXC. COLOMBIA EQUIPMENT(CB7) (D) L=1380	8-98186-528-0	01	1	1301-
67	HOSE; FUEL,DELIVERY FUEL TANK 400L<SDH> (C) L=980 SERVICED BY L=3000	0-01260-300-0	01	1	1109-1205
67	HOSE; FUEL,DELIVERY COLOMBIA EQUIPMENT(CB7) FUEL TANK 400L<SDH> (C) L=920 SERVICED BY L=3000	0-01260-300-0	01	1	1206-1212
67	HOSE; FUEL,DELIVERY COLOMBIA EQUIPMENT(CB7) FUEL TANK 400L<SDH> EXC. BIO DIESEL FUEL B10<8NV> (C) L=920 SERVICED BY L=3000	0-01260-300-0	01	1	1301-
67	HOSE; FUEL,DELIVERY FUEL TANK 400L<SDH> (C) L=1600 SERVICED BY L=3000	0-01260-300-0	01	1	1109-1212
67	HOSE; FUEL,DELIVERY FUEL TANK 400L<SDH> EXC. BIO DIESEL FUEL B10<8NV> (C) L=1600 SERVICED BY L=3000	0-01260-300-0	01	1	1301-
67	HOSE; FUEL,DELIVERY (C) L=110 SERVICED BY L=3000	0-01260-300-0	01	1	1109-1212
67	HOSE; FUEL,DELIVERY EXC. BIO DIESEL FUEL B10<8NV> (C) L=110 SERVICED BY L=3000	0-01260-300-0	01	1	1301-
67	HOSE; FUEL,DELIVERY (B) L=210 SERVICED BY L=3000	0-01558-300-0	01	1	1109-
67	HOSE; FUEL,DELIVERY FUEL TANK 400L<SDH> EXC. COLOMBIA EQUIPMENT(CB7) (C) L=980 SERVICED BY L=3000	0-01260-300-0	01	1	1206-
67	HOSE; FUEL,DELIVERY 6HK1-TCS ENG(80L) WHEEL BASE 5500MM(55W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> (C) L=730	8-98205-834-0	01	1	1206-1212
67	HOSE; FUEL,DELIVERY 6HK1-TCS ENG(80L) WHEEL BASE 5000MM(50W),WHEEL BASE 5500MM(55W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> EXC. BIO DIESEL FUEL B10<8NV> (C) L=730	8-98205-834-0	01	1	1301-
67	HOSE; FUEL,DELIVERY 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) (E) L=300	8-98157-878-0	01	1	1206-1212
67	HOSE; FUEL,DELIVERY 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) EXC. BIO DIESEL FUEL B10<8NV> (E) L=300	8-98157-878-0	01	1	1301-
67	HOSE; FUEL,DELIVERY 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> (F) L=900	8-98157-879-0	01	1	1206-1212
67	HOSE; FUEL,DELIVERY 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> EXC. BIO DIESEL FUEL B10<8NV> (F) L=900	8-98157-879-0	01	1	1301-
67	HOSE; FUEL,DELIVERY COLOMBIA EQUIPMENT(CB7) FUEL TANK 400L<SDH> BIO DIESEL FUEL B10<8NV> (D) L=1620	8-98232-241-0	01	1	1301-
67	HOSE; FUEL,DELIVERY COLOMBIA EQUIPMENT(CB7) FUEL TANK 400L<SDH> BIO DIESEL FUEL B10<8NV> (C) L=920	8-98232-244-0	01	1	1301-
67	HOSE; FUEL,DELIVERY WHEEL BASE 5000MM(50W),WHEEL BASE 5500MM(55W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> (C) L=730	8-98232-243-0	01	1	1301-
67	HOSE; FUEL,DELIVERY BIO DIESEL FUEL B10<8NV> (A) L=110 SERVICED BY L=3000	0-01859-300-0	01	1	1301-
67	HOSE; FUEL,DELIVERY COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> (D) L=1380	8-98232-240-0	01	1	1301-1304
67	HOSE; FUEL,DELIVERY WHEEL BASE 5000MM(50W),WHEEL BASE 5500MM(55W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> (D) L=1380	8-98232-240-0	01	1	1305-
67	HOSE; FUEL,DELIVERY 6HK1-TCS ENG(80L) WHEEL BASE 3900MM(39W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> (C)	8-98232-911-0	01	1	1301-1304
67	HOSE; FUEL,DELIVERY WHEEL BASE 3900MM(39W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> (C)	8-98238-196-0	01	1	1305-
67	HOSE; FUEL,DELIVERY WHEEL BASE 3900MM(39W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> (D)	8-98238-197-0	01	1	1305-
80	BOLT; CLIP,FUEL TANK M8X20 FLANGE	0-28650-820-0	02	1	1109-
80	BOLT; CLIP,FUEL TANK 6HK1-TCS ENG(80L) M8X20 FLANGE	0-28650-820-0	02	1	1109-
80	BOLT; CLIP,FUEL TANK M8X30 FLANGE	0-28650-830-0	01	1	1109-1205
80	BOLT; CLIP,FUEL TANK 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) M8X30 FLANGE	0-28650-830-0	01	1	1206-1212
80	BOLT; CLIP,FUEL TANK EXC. COLOMBIA EQUIPMENT(CB7) M8X30 FLANGE	0-28650-830-0	01	1	1206-1212
80	BOLT; CLIP,FUEL TANK 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) M8X30 FLANGE	0-28650-830-0	01	1	1301-1304
80	BOLT; CLIP,FUEL TANK 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) BIO DIESEL FUEL B10<8NV> M8X30 FLANGE	0-28650-830-0	01	1	1301-1304
80	BOLT; CLIP,FUEL TANK EXC. COLOMBIA EQUIPMENT(CB7) M8X30 FLANGE	0-28650-830-0	01	1	1301-1304
80	BOLT; CLIP,FUEL TANK WHEEL BASE 5000MM(50W),WHEEL BASE 5500MM(55W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> M8X30 FLANGE	0-28650-830-0	01	1	1305-
80	BOLT; CLIP,FUEL TANK 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) FUEL TANK 400L<SDH> BIO DIESEL FUEL B10<8NV> M8X30 FLANGE	0-28650-830-0	01	1	1305-
80	BOLT; CLIP,FUEL TANK 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) EXC. BIO DIESEL FUEL B10<8NV> M8X30 FLANGE	0-28650-830-0	01	1	1305-
80	BOLT; CLIP,FUEL TANK EXC. COLOMBIA EQUIPMENT(CB7) M8X30 FLANGE	0-28650-830-0	01	1	1305-
83	NUT; CLIP,FUEL TANK M8 FLANGE	0-91180-108-0	03	1	1109-1205
83	NUT; CLIP,FUEL TANK 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) M8 FLANGE	0-91180-108-0	03	1	1206-1212
83	NUT; CLIP,FUEL TANK EXC. COLOMBIA EQUIPMENT(CB7) M8 FLANGE	0-91180-108-0	03	1	1206-1212
83	NUT; CLIP,FUEL TANK 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) M8 FLANGE	0-91180-108-0	03	1	1301-
83	NUT; CLIP,FUEL TANK 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) BIO DIESEL FUEL B10<8NV> M8 FLANGE	0-91180-108-0	03	1	1301-
83	NUT; CLIP,FUEL TANK EXC. COLOMBIA EQUIPMENT(CB7) M8 FLANGE	0-91180-108-0	03	1	1301-
83	NUT; CLIP,FUEL TANK FUEL TANK 400L<SDH> M8 FLANGE	0-91180-108-0	01	1	1109-
83	NUT; CLIP,FUEL TANK 6HK1-TCS ENG(80L) M8 FLANGE	0-91180-108-0	02	1	1109-1205
83	NUT; CLIP,FUEL TANK 6HK1-TCS ENG(80L) M8 FLANGE	0-91180-108-0	02	1	1206-1212
83	NUT; CLIP,FUEL TANK 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) M8 FLANGE	0-91180-108-0	02	1	1206-1212
83	NUT; CLIP,FUEL TANK 6HK1-TCS ENG(80L) M8 FLANGE	0-91180-108-0	02	1	1301-
83	NUT; CLIP,FUEL TANK 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) EXC. BIO DIESEL FUEL B10<8NV> M8 FLANGE	0-91180-108-0	02	1	1301-
97	BRACKET; CLIP WHEEL BASE 3900MM(39W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> (E)	8-98238-178-0	01	1	1305-
97	BRACKET; CLIP 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) (D)	8-98126-612-0	01	1	1206-1212
97	BRACKET; CLIP 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) EXC. BIO DIESEL FUEL B10<8NV> (D)	8-98126-612-0	01	1	1301-
97	BRACKET; CLIP (C) L=50	1-47475-299-2	01	1	1109-1205
97	BRACKET; CLIP 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) (C) L=50	1-47475-299-2	01	1	1206-1212
97	BRACKET; CLIP EXC. COLOMBIA EQUIPMENT(CB7) (C) L=50	1-47475-299-2	01	1	1206-1212
97	BRACKET; CLIP 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) (C) L=50	1-47475-299-2	01	1	1301-
97	BRACKET; CLIP 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) BIO DIESEL FUEL B10<8NV> (C) L=50	1-47475-299-2	01	1	1301-
97	BRACKET; CLIP EXC. COLOMBIA EQUIPMENT(CB7) (C) L=50	1-47475-299-2	01	1	1301-
97	BRACKET; CLIP (A)	8-98053-654-0	01	1	1109-
97	BRACKET; CLIP (B)	8-98129-922-0	01	1	1109-1205
97	BRACKET; CLIP 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) (B)	8-98129-922-0	01	1	1206-1212
97	BRACKET; CLIP EXC. COLOMBIA EQUIPMENT(CB7) (B)	8-98129-922-0	01	1	1206-1212
97	BRACKET; CLIP 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) (B)	8-98129-922-0	01	1	1301-
97	BRACKET; CLIP 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) BIO DIESEL FUEL B10<8NV> (B)	8-98129-922-0	01	1	1301-
97	BRACKET; CLIP EXC. COLOMBIA EQUIPMENT(CB7) (B)	8-98129-922-0	01	1	1301-
124	CLIP; HOSE 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) L=250	5-09707-030-1	01	1	1206-1212
124	CLIP; HOSE 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) EXC. BIO DIESEL FUEL B10<8NV> L=250	5-09707-030-1	01	1	1301-
174	PIPE; FUEL,FEED,FRT 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) L=548	8-98117-708-0	01	1	1206-1212
174	PIPE; FUEL,FEED,FRT 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) EXC. BIO DIESEL FUEL B10<8NV> L=548	8-98117-708-0	01	1	1301-
174	PIPE; FUEL,FEED,FRT L=685	8-98129-920-0	01	1	1109-1205
174	PIPE; FUEL,FEED,FRT 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) L=685	8-98129-920-0	01	1	1206-1212
174	PIPE; FUEL,FEED,FRT EXC. COLOMBIA EQUIPMENT(CB7) L=685	8-98129-920-0	01	1	1206-1212
174	PIPE; FUEL,FEED,FRT 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) L=685	8-98129-920-0	01	1	1301-
174	PIPE; FUEL,FEED,FRT 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) BIO DIESEL FUEL B10<8NV> L=685	8-98129-920-0	01	1	1301-
174	PIPE; FUEL,FEED,FRT EXC. COLOMBIA EQUIPMENT(CB7) L=685	8-98129-920-0	01	1	1301-
228	BOLT; BRKT,SEDIMENTER 6HK1-TCS ENG(80L) WHEEL BASE 3900MM(39W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 400L<SDH> (B) M10X60 FLANGE	0-28051-060-0	02	1	1207-
228	BOLT; BRKT,SEDIMENTER 6HK1-TCS ENG(80L) WHEEL BASE 5000MM(50W),WHEEL BASE 5500MM(55W) COLOMBIA EQUIPMENT(CB7) (B) M10X60 FLANGE	0-28051-060-0	02	1	1207-
228	BOLT; BRKT,SEDIMENTER 6HK1-TCS ENG(80L) WHEEL BASE 5500MM(55W) CHILE EQUIPMENT(KE1) FUEL TANK 400L<SDH> (B) M10X60 FLANGE	0-28051-060-0	02	1	1207-
228	BOLT; BRKT,SEDIMENTER (A) M8X25 FLANGE	0-28050-825-0	02	1	1109-
228	BOLT; BRKT,SEDIMENTER (B) M10X50 FLANGE	0-28051-050-0	02	1	1109-1206
228	BOLT; BRKT,SEDIMENTER 6HK1-TCS ENG(80L) WHEEL BASE 3900MM(39W) COLOMBIA EQUIPMENT(CB7) EXC. FUEL TANK 400L<SDH> (B) M10X50 FLANGE	0-28051-050-0	02	1	1207-
228	BOLT; BRKT,SEDIMENTER 6HK1-TCN ENG(82L) WHEEL BASE 5000MM(50W) COLOMBIA EQUIPMENT(CB7) (B) M10X50 FLANGE	0-28051-050-0	02	1	1207-
228	BOLT; BRKT,SEDIMENTER EXC. COLOMBIA EQUIPMENT(CB7),FUEL TANK 400L<SDH> (B) M10X50 FLANGE	0-28051-050-0	02	1	1207-
228	BOLT; BRKT,SEDIMENTER (C) M8X20 FLANGE	0-28650-820-0	02	1	1109-
279	WASHER ID=10.5 OD=26	0-91614-710-0	02	1	1109-
303	BOLT; BRKT WHEEL BASE 3900MM(39W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> (A) M8X35 FLANGE	0-28650-835-0	01	1	1305-
303	BOLT; BRKT (A) M8X35 FLANGE	0-28650-835-0	02	1	1109-1205
303	BOLT; BRKT 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) (A) M8X35 FLANGE	0-28650-835-0	02	1	1206-1212
303	BOLT; BRKT EXC. COLOMBIA EQUIPMENT(CB7) (A) M8X35 FLANGE	0-28650-835-0	02	1	1206-1212
303	BOLT; BRKT 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) (A) M8X35 FLANGE	0-28650-835-0	02	1	1301-
303	BOLT; BRKT 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) BIO DIESEL FUEL B10<8NV> (A) M8X35 FLANGE	0-28650-835-0	02	1	1301-
303	BOLT; BRKT EXC. COLOMBIA EQUIPMENT(CB7) (A) M8X35 FLANGE	0-28650-835-0	02	1	1301-
303	BOLT; BRKT EXC. FUEL TANK 400L<SDH> (B) M10X35 FLANGE	0-28651-035-0	02	1	1109-1205
303	BOLT; BRKT 6HK1-TCS ENG(80L) WHEEL BASE 3900MM(39W) COLOMBIA EQUIPMENT(CB7) EXC. FUEL TANK 400L<SDH> (B) M10X35 FLANGE	0-28651-035-0	02	1	1206-1212
303	BOLT; BRKT 6HK1-TCN ENG(82L) WHEEL BASE 5000MM(50W) COLOMBIA EQUIPMENT(CB7) EXC. FUEL TANK 400L<SDH> (B) M10X35 FLANGE	0-28651-035-0	02	1	1206-1212
303	BOLT; BRKT EXC. COLOMBIA EQUIPMENT(CB7),FUEL TANK 400L<SDH> (B) M10X35 FLANGE	0-28651-035-0	02	1	1206-1212
303	BOLT; BRKT 6HK1-TCS ENG(80L) WHEEL BASE 3900MM(39W) COLOMBIA EQUIPMENT(CB7) EXC. FUEL TANK 400L<SDH> (B) M10X35 FLANGE	0-28651-035-0	02	1	1301-
303	BOLT; BRKT EXC. COLOMBIA EQUIPMENT(CB7),FUEL TANK 400L<SDH> (B) M10X35 FLANGE	0-28651-035-0	02	1	1301-
304	NUT; BRKT 6HK1-TCN ENG(82L) WHEEL BASE 5000MM(50W) COLOMBIA EQUIPMENT(CB7) EXC. FUEL TANK 400L<SDH> (B) M10 FLANGE	0-91180-210-0	01	1	1206-1212
304	NUT; BRKT (A) M8 FLANGE	0-91180-108-0	03	1	1109-
304	NUT; BRKT (B) M10 FLANGE	0-91180-210-0	02	1	1109-1205
304	NUT; BRKT EXC. FUEL TANK 400L<SDH> (B) M10 FLANGE	0-91180-210-0	02	1	1109-1205
304	NUT; BRKT (B) M10 FLANGE	0-91180-210-0	02	1	1206-
304	NUT; BRKT 6HK1-TCS ENG(80L) WHEEL BASE 3900MM(39W) COLOMBIA EQUIPMENT(CB7) EXC. FUEL TANK 400L<SDH> (B) M10 FLANGE	0-91180-210-0	02	1	1206-
304	NUT; BRKT EXC. COLOMBIA EQUIPMENT(CB7),FUEL TANK 400L<SDH> (B) M10 FLANGE	0-91180-210-0	02	1	1206-
345	PLUG NPTF3/8-18	8-97329-623-0	02	1	1109-
418	BRACKET; PRE FUEL FILTER 6HK1-TCN ENG(82L) WHEEL BASE 5000MM(50W) COLOMBIA EQUIPMENT(CB7) EXC. FUEL TANK 400L<SDH> (B)	8-98128-254-0	01	1	1206-1212
418	BRACKET; PRE FUEL FILTER EXC. FUEL TANK 400L<SDH> (A)	8-98136-381-0	01	1	1109-1205
418	BRACKET; PRE FUEL FILTER 6HK1-TCS ENG(80L) WHEEL BASE 3900MM(39W) COLOMBIA EQUIPMENT(CB7) EXC. FUEL TANK 400L<SDH> (A)	8-98136-381-0	01	1	1206-
418	BRACKET; PRE FUEL FILTER EXC. COLOMBIA EQUIPMENT(CB7),FUEL TANK 400L<SDH> (A)	8-98136-381-0	01	1	1206-
623	PLATE; STUD BOLT 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7)	8-98126-633-0	01	1	1206-1212
623	PLATE; STUD BOLT 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) EXC. BIO DIESEL FUEL B10<8NV>	8-98126-633-0	01	1	1301-
634	HOSE; RUBBER RETURN 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) L=1050	8-98128-212-0	01	1	1206-1212
634	HOSE; RUBBER RETURN 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) EXC. BIO DIESEL FUEL B10<8NV> L=1050	8-98128-212-0	01	1	1301-
634	HOSE; RUBBER RETURN 6HK1-TCN ENG(82L) FUEL TANK 200L FRAME SIDE<N20> L=810	8-98186-973-0	01	1	1109-1205
634	HOSE; RUBBER RETURN 6HK1-TCN ENG(82L) FUEL TANK 200L FRAME SIDE<N20> EXC. COLOMBIA EQUIPMENT(CB7) L=810	8-98186-973-0	01	1	1206-1212
634	HOSE; RUBBER RETURN 6HK1-TCN ENG(82L) FUEL TANK 200L FRAME SIDE<N20> EXC. COLOMBIA EQUIPMENT(CB7) L=810	8-98186-973-0	01	1	1301-
634	HOSE; RUBBER RETURN 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> L=810	8-98186-973-0	01	1	1301-
634	HOSE; RUBBER RETURN 6HK1-TCS ENG(80L) FUEL TANK 200L FRAME SIDE<N20>	8-98186-971-0	01	1	1109-
634	HOSE; RUBBER RETURN 6HK1-TCS ENG(80L) FUEL TANK 400L<SDH> L=900 SERVICED BY L=3000	0-01558-300-0	01	1	1109-

345 345 39 41 67 67 228 279 304 418 304 303 39 41

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date
39	PIPE; FUEL (A) NPTF3/8-18 OD=10	8-98122-953-0	02	1	1109-
39	PIPE; FUEL FUEL TANK 400L<SDH> (B)	8-98009-438-1	01	1	1109-
41	CLIP; FUEL PIPE,FUEL TANK WHEEL BASE 3900MM(39W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> (E) L=250	5-09707-030-1	06	1	1305-
41	CLIP; FUEL PIPE,FUEL TANK COLOMBIA EQUIPMENT(CB7) BIO DIESEL FUEL B10<8NV> (F) ID=24 & 24 L=49	1-09701-018-0	01	1	1301-1304
41	CLIP; FUEL PIPE,FUEL TANK WHEEL BASE 5000MM(50W),WHEEL BASE 5500MM(55W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> (F) ID=24 & 24 L=49	1-09701-018-0	01	1	1305-
41	CLIP; FUEL PIPE,FUEL TANK COLOMBIA EQUIPMENT(CB7) FUEL TANK 400L<SDH> BIO DIESEL FUEL B10<8NV> (F) ID=24 & 24 L=49	1-09701-018-0	01	1	1305-
41	CLIP; FUEL PIPE,FUEL TANK BIO DIESEL FUEL B10<8NV> (D) ID=16	8-94238-568-0	06	1	1301-
41	CLIP; FUEL PIPE,FUEL TANK 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) (B) ID=11 & 9 L=17.5 & 17.5	1-09700-747-0	02	1	1206-1212
41	CLIP; FUEL PIPE,FUEL TANK 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) EXC. BIO DIESEL FUEL B10<8NV> (B) ID=11 & 9 L=17.5 & 17.5	1-09700-747-0	02	1	1301-
41	CLIP; FUEL PIPE,FUEL TANK 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> (E) L=250	5-09707-030-1	02	1	1206-1212
41	CLIP; FUEL PIPE,FUEL TANK 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> EXC. BIO DIESEL FUEL B10<8NV> (E) L=250	5-09707-030-1	02	1	1301-
41	CLIP; FUEL PIPE,FUEL TANK (B) ID=11 & 9 L=17.5 & 17.5	1-09700-747-0	03	1	1109-1205
41	CLIP; FUEL PIPE,FUEL TANK 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) (B) ID=11 & 9 L=17.5 & 17.5	1-09700-747-0	03	1	1206-1212
41	CLIP; FUEL PIPE,FUEL TANK EXC. COLOMBIA EQUIPMENT(CB7) (B) ID=11 & 9 L=17.5 & 17.5	1-09700-747-0	03	1	1206-1212
41	CLIP; FUEL PIPE,FUEL TANK 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) (B) ID=11 & 9 L=17.5 & 17.5	1-09700-747-0	03	1	1301-
41	CLIP; FUEL PIPE,FUEL TANK 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) BIO DIESEL FUEL B10<8NV> (B) ID=11 & 9 L=17.5 & 17.5	1-09700-747-0	03	1	1301-
41	CLIP; FUEL PIPE,FUEL TANK EXC. COLOMBIA EQUIPMENT(CB7) (B) ID=11 & 9 L=17.5 & 17.5	1-09700-747-0	03	1	1301-
41	CLIP; FUEL PIPE,FUEL TANK (F) ID=14X29 H=30 L=25	1-09701-101-0	01	1	1109-1205
41	CLIP; FUEL PIPE,FUEL TANK 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) (F) ID=14X29 H=30 L=25	1-09701-101-0	01	1	1206-1212
41	CLIP; FUEL PIPE,FUEL TANK EXC. COLOMBIA EQUIPMENT(CB7) (F) ID=14X29 H=30 L=25	1-09701-101-0	01	1	1206-1212
41	CLIP; FUEL PIPE,FUEL TANK 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) EXC. BIO DIESEL FUEL B10<8NV> (F) ID=14X29 H=30 L=25	1-09701-101-0	01	1	1301-
41	CLIP; FUEL PIPE,FUEL TANK EXC. COLOMBIA EQUIPMENT(CB7) (F) ID=14X29 H=30 L=25	1-09701-101-0	01	1	1301-
41	CLIP; FUEL PIPE,FUEL TANK (C) ID=14	1-09704-102-0	06	1	1109-1212
41	CLIP; FUEL PIPE,FUEL TANK EXC. BIO DIESEL FUEL B10<8NV> (C) ID=14	1-09704-102-0	06	1	1301-
41	CLIP; FUEL PIPE,FUEL TANK (D) ID=16	8-94238-568-0	02	1	1109-
41	CLIP; FUEL PIPE,FUEL TANK FUEL TANK 200L FRAME SIDE<N20> (E) L=250	5-09707-030-1	05	1	1109-1205
41	CLIP; FUEL PIPE,FUEL TANK 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> (E) L=250	5-09707-030-1	05	1	1206-1212
41	CLIP; FUEL PIPE,FUEL TANK FUEL TANK 200L FRAME SIDE<N20> EXC. COLOMBIA EQUIPMENT(CB7) (E) L=250	5-09707-030-1	05	1	1206-1212
41	CLIP; FUEL PIPE,FUEL TANK 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> (E) L=250	5-09707-030-1	05	1	1301-1304
41	CLIP; FUEL PIPE,FUEL TANK 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> (E) L=250	5-09707-030-1	05	1	1301-1304
41	CLIP; FUEL PIPE,FUEL TANK FUEL TANK 200L FRAME SIDE<N20> EXC. COLOMBIA EQUIPMENT(CB7) (E) L=250	5-09707-030-1	05	1	1301-1304
41	CLIP; FUEL PIPE,FUEL TANK WHEEL BASE 5000MM(50W),WHEEL BASE 5500MM(55W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> (E) L=250	5-09707-030-1	05	1	1305-
41	CLIP; FUEL PIPE,FUEL TANK 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> EXC. BIO DIESEL FUEL B10<8NV> (E) L=250	5-09707-030-1	05	1	1305-
41	CLIP; FUEL PIPE,FUEL TANK FUEL TANK 200L FRAME SIDE<N20> EXC. COLOMBIA EQUIPMENT(CB7) (E) L=250	5-09707-030-1	05	1	1305-
41	CLIP; FUEL PIPE,FUEL TANK FUEL TANK 400L<SDH> (E) L=250	5-09707-030-1	03	1	1109-
41	CLIP; FUEL PIPE,FUEL TANK 6HK1-TCN ENG(82L) (A) ID=13	8-94238-571-0	06	1	1109-
41	CLIP; FUEL PIPE,FUEL TANK 6HK1-TCS ENG(80L) (G) ID=9 & 9 L=17 & 17	1-09700-651-0	02	1	1109-
41	CLIP; FUEL PIPE,FUEL TANK 6HK1-TCS ENG(80L) (A) ID=13	8-94238-571-0	08	1	1109-
67	HOSE; FUEL,DELIVERY FUEL TANK 200L FRAME SIDE<N20> (C) L=710	8-98186-527-0	01	1	1109-1205
67	HOSE; FUEL,DELIVERY 6HK1-TCS ENG(80L) WHEEL BASE 3900MM(39W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> (C) L=710	8-98186-527-0	01	1	1206-1212
67	HOSE; FUEL,DELIVERY FUEL TANK 200L FRAME SIDE<N20> EXC. COLOMBIA EQUIPMENT(CB7) (C) L=710	8-98186-527-0	01	1	1206-1212
67	HOSE; FUEL,DELIVERY 6HK1-TCS ENG(80L) WHEEL BASE 3900MM(39W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> EXC. BIO DIESEL FUEL B10<8NV> (C) L=710	8-98186-527-0	01	1	1301-
67	HOSE; FUEL,DELIVERY FUEL TANK 200L FRAME SIDE<N20> EXC. COLOMBIA EQUIPMENT(CB7) (C) L=710	8-98186-527-0	01	1	1301-
67	HOSE; FUEL,DELIVERY FUEL TANK 200L FRAME SIDE<N20> (D) L=1380	8-98186-528-0	01	1	1109-1205
67	HOSE; FUEL,DELIVERY 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> (D) L=1380	8-98186-528-0	01	1	1206-1212
67	HOSE; FUEL,DELIVERY FUEL TANK 200L FRAME SIDE<N20> EXC. COLOMBIA EQUIPMENT(CB7) (D) L=1380	8-98186-528-0	01	1	1206-1212
67	HOSE; FUEL,DELIVERY 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> EXC. BIO DIESEL FUEL B10<8NV> (D) L=1380	8-98186-528-0	01	1	1301-
67	HOSE; FUEL,DELIVERY FUEL TANK 200L FRAME SIDE<N20> EXC. COLOMBIA EQUIPMENT(CB7) (D) L=1380	8-98186-528-0	01	1	1301-
67	HOSE; FUEL,DELIVERY FUEL TANK 400L<SDH> (C) L=980 SERVICED BY L=3000	0-01260-300-0	01	1	1109-1205
67	HOSE; FUEL,DELIVERY COLOMBIA EQUIPMENT(CB7) FUEL TANK 400L<SDH> (C) L=920 SERVICED BY L=3000	0-01260-300-0	01	1	1206-1212
67	HOSE; FUEL,DELIVERY COLOMBIA EQUIPMENT(CB7) FUEL TANK 400L<SDH> EXC. BIO DIESEL FUEL B10<8NV> (C) L=920 SERVICED BY L=3000	0-01260-300-0	01	1	1301-
67	HOSE; FUEL,DELIVERY FUEL TANK 400L<SDH> (C) L=1600 SERVICED BY L=3000	0-01260-300-0	01	1	1109-1212
67	HOSE; FUEL,DELIVERY FUEL TANK 400L<SDH> EXC. BIO DIESEL FUEL B10<8NV> (C) L=1600 SERVICED BY L=3000	0-01260-300-0	01	1	1301-
67	HOSE; FUEL,DELIVERY (C) L=110 SERVICED BY L=3000	0-01260-300-0	01	1	1109-1212
67	HOSE; FUEL,DELIVERY EXC. BIO DIESEL FUEL B10<8NV> (C) L=110 SERVICED BY L=3000	0-01260-300-0	01	1	1301-
67	HOSE; FUEL,DELIVERY (B) L=210 SERVICED BY L=3000	0-01558-300-0	01	1	1109-
67	HOSE; FUEL,DELIVERY FUEL TANK 400L<SDH> EXC. COLOMBIA EQUIPMENT(CB7) (C) L=980 SERVICED BY L=3000	0-01260-300-0	01	1	1206-
67	HOSE; FUEL,DELIVERY 6HK1-TCS ENG(80L) WHEEL BASE 5500MM(55W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> (C) L=730	8-98205-834-0	01	1	1206-1212
67	HOSE; FUEL,DELIVERY 6HK1-TCS ENG(80L) WHEEL BASE 5000MM(50W),WHEEL BASE 5500MM(55W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> EXC. BIO DIESEL FUEL B10<8NV> (C) L=730	8-98205-834-0	01	1	1301-
67	HOSE; FUEL,DELIVERY 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) (E) L=300	8-98157-878-0	01	1	1206-1212
67	HOSE; FUEL,DELIVERY 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) EXC. BIO DIESEL FUEL B10<8NV> (E) L=300	8-98157-878-0	01	1	1301-
67	HOSE; FUEL,DELIVERY 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> (F) L=900	8-98157-879-0	01	1	1206-1212
67	HOSE; FUEL,DELIVERY 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> EXC. BIO DIESEL FUEL B10<8NV> (F) L=900	8-98157-879-0	01	1	1301-
67	HOSE; FUEL,DELIVERY COLOMBIA EQUIPMENT(CB7) FUEL TANK 400L<SDH> BIO DIESEL FUEL B10<8NV> (D) L=1620	8-98232-241-0	01	1	1301-
67	HOSE; FUEL,DELIVERY COLOMBIA EQUIPMENT(CB7) FUEL TANK 400L<SDH> BIO DIESEL FUEL B10<8NV> (C) L=920	8-98232-244-0	01	1	1301-
67	HOSE; FUEL,DELIVERY WHEEL BASE 5000MM(50W),WHEEL BASE 5500MM(55W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> (C) L=730	8-98232-243-0	01	1	1301-
67	HOSE; FUEL,DELIVERY BIO DIESEL FUEL B10<8NV> (A) L=110 SERVICED BY L=3000	0-01859-300-0	01	1	1301-
67	HOSE; FUEL,DELIVERY COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> (D) L=1380	8-98232-240-0	01	1	1301-1304
67	HOSE; FUEL,DELIVERY WHEEL BASE 5000MM(50W),WHEEL BASE 5500MM(55W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> (D) L=1380	8-98232-240-0	01	1	1305-
67	HOSE; FUEL,DELIVERY 6HK1-TCS ENG(80L) WHEEL BASE 3900MM(39W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> (C)	8-98232-911-0	01	1	1301-1304
67	HOSE; FUEL,DELIVERY WHEEL BASE 3900MM(39W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> (C)	8-98238-196-0	01	1	1305-
67	HOSE; FUEL,DELIVERY WHEEL BASE 3900MM(39W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> (D)	8-98238-197-0	01	1	1305-
228	BOLT; BRKT,SEDIMENTER 6HK1-TCS ENG(80L) WHEEL BASE 3900MM(39W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 400L<SDH> (B) M10X60 FLANGE	0-28051-060-0	02	1	1207-
228	BOLT; BRKT,SEDIMENTER 6HK1-TCS ENG(80L) WHEEL BASE 5000MM(50W),WHEEL BASE 5500MM(55W) COLOMBIA EQUIPMENT(CB7) (B) M10X60 FLANGE	0-28051-060-0	02	1	1207-
228	BOLT; BRKT,SEDIMENTER 6HK1-TCS ENG(80L) WHEEL BASE 5500MM(55W) CHILE EQUIPMENT(KE1) FUEL TANK 400L<SDH> (B) M10X60 FLANGE	0-28051-060-0	02	1	1207-
228	BOLT; BRKT,SEDIMENTER (A) M8X25 FLANGE	0-28050-825-0	02	1	1109-
228	BOLT; BRKT,SEDIMENTER (B) M10X50 FLANGE	0-28051-050-0	02	1	1109-1206
228	BOLT; BRKT,SEDIMENTER 6HK1-TCS ENG(80L) WHEEL BASE 3900MM(39W) COLOMBIA EQUIPMENT(CB7) EXC. FUEL TANK 400L<SDH> (B) M10X50 FLANGE	0-28051-050-0	02	1	1207-
228	BOLT; BRKT,SEDIMENTER 6HK1-TCN ENG(82L) WHEEL BASE 5000MM(50W) COLOMBIA EQUIPMENT(CB7) (B) M10X50 FLANGE	0-28051-050-0	02	1	1207-
228	BOLT; BRKT,SEDIMENTER EXC. COLOMBIA EQUIPMENT(CB7),FUEL TANK 400L<SDH> (B) M10X50 FLANGE	0-28051-050-0	02	1	1207-
228	BOLT; BRKT,SEDIMENTER (C) M8X20 FLANGE	0-28650-820-0	02	1	1109-
279	WASHER ID=10.5 OD=26	0-91614-710-0	02	1	1109-
303	BOLT; BRKT WHEEL BASE 3900MM(39W) COLOMBIA EQUIPMENT(CB7) FUEL TANK 200L FRAME SIDE<N20> BIO DIESEL FUEL B10<8NV> (A) M8X35 FLANGE	0-28650-835-0	01	1	1305-
303	BOLT; BRKT (A) M8X35 FLANGE	0-28650-835-0	02	1	1109-1205
303	BOLT; BRKT 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) (A) M8X35 FLANGE	0-28650-835-0	02	1	1206-1212
303	BOLT; BRKT EXC. COLOMBIA EQUIPMENT(CB7) (A) M8X35 FLANGE	0-28650-835-0	02	1	1206-1212
303	BOLT; BRKT 6HK1-TCS ENG(80L) COLOMBIA EQUIPMENT(CB7) (A) M8X35 FLANGE	0-28650-835-0	02	1	1301-
303	BOLT; BRKT 6HK1-TCN ENG(82L) COLOMBIA EQUIPMENT(CB7) BIO DIESEL FUEL B10<8NV> (A) M8X35 FLANGE	0-28650-835-0	02	1	1301-
303	BOLT; BRKT EXC. COLOMBIA EQUIPMENT(CB7) (A) M8X35 FLANGE	0-28650-835-0	02	1	1301-
303	BOLT; BRKT EXC. FUEL TANK 400L<SDH> (B) M10X35 FLANGE	0-28651-035-0	02	1	1109-1205
303	BOLT; BRKT 6HK1-TCS ENG(80L) WHEEL BASE 3900MM(39W) COLOMBIA EQUIPMENT(CB7) EXC. FUEL TANK 400L<SDH> (B) M10X35 FLANGE	0-28651-035-0	02	1	1206-1212
303	BOLT; BRKT 6HK1-TCN ENG(82L) WHEEL BASE 5000MM(50W) COLOMBIA EQUIPMENT(CB7) EXC. FUEL TANK 400L<SDH> (B) M10X35 FLANGE	0-28651-035-0	02	1	1206-1212
303	BOLT; BRKT EXC. COLOMBIA EQUIPMENT(CB7),FUEL TANK 400L<SDH> (B) M10X35 FLANGE	0-28651-035-0	02	1	1206-1212
303	BOLT; BRKT 6HK1-TCS ENG(80L) WHEEL BASE 3900MM(39W) COLOMBIA EQUIPMENT(CB7) EXC. FUEL TANK 400L<SDH> (B) M10X35 FLANGE	0-28651-035-0	02	1	1301-
303	BOLT; BRKT EXC. COLOMBIA EQUIPMENT(CB7),FUEL TANK 400L<SDH> (B) M10X35 FLANGE	0-28651-035-0	02	1	1301-
304	NUT; BRKT 6HK1-TCN ENG(82L) WHEEL BASE 5000MM(50W) COLOMBIA EQUIPMENT(CB7) EXC. FUEL TANK 400L<SDH> (B) M10 FLANGE	0-91180-210-0	01	1	1206-1212
304	NUT; BRKT (A) M8 FLANGE	0-91180-108-0	03	1	1109-
304	NUT; BRKT (B) M10 FLANGE	0-91180-210-0	02	1	1109-1205
304	NUT; BRKT EXC. FUEL TANK 400L<SDH> (B) M10 FLANGE	0-91180-210-0	02	1	1109-1205
304	NUT; BRKT (B) M10 FLANGE	0-91180-210-0	02	1	1206-
304	NUT; BRKT 6HK1-TCS ENG(80L) WHEEL BASE 3900MM(39W) COLOMBIA EQUIPMENT(CB7) EXC. FUEL TANK 400L<SDH> (B) M10 FLANGE	0-91180-210-0	02	1	1206-
304	NUT; BRKT EXC. COLOMBIA EQUIPMENT(CB7),FUEL TANK 400L<SDH> (B) M10 FLANGE	0-91180-210-0	02	1	1206-
345	PLUG NPTF3/8-18	8-97329-623-0	02	1	1109-
418	BRACKET; PRE FUEL FILTER 6HK1-TCN ENG(82L) WHEEL BASE 5000MM(50W) COLOMBIA EQUIPMENT(CB7) EXC. FUEL TANK 400L<SDH> (B)	8-98128-254-0	01	1	1206-1212
418	BRACKET; PRE FUEL FILTER EXC. FUEL TANK 400L<SDH> (A)	8-98136-381-0	01	1	1109-1205
418	BRACKET; PRE FUEL FILTER 6HK1-TCS ENG(80L) WHEEL BASE 3900MM(39W) COLOMBIA EQUIPMENT(CB7) EXC. FUEL TANK 400L<SDH> (A)	8-98136-381-0	01	1	1206-
418	BRACKET; PRE FUEL FILTER EXC. COLOMBIA EQUIPMENT(CB7),FUEL TANK 400L<SDH> (A)	8-98136-381-0	01	1	1206-

İpucu: çizimdeki balona veya tablodaki Balon sütununa tıkla; ilgili parçalar vurgulanır. Birden çok çizim varsa üstteki seçim kutusu/oklarla gezin.
