1 |
DRIVE ASM; FINAL,FRT
A/T AISIN<RMD>
FRT&RR P225/75R15 6JJX15 AL<9LH>
41/9
THA
|
8-94376-220-1 |
01 |
1 |
0009- |
| |
1 |
DRIVE ASM; FINAL,FRT
M/T MUA 5 SPEED<RMN>
FRT&RR 265/70R15 7JJX15 ALUMI WHEEL<BVH>
41/9
THA
|
8-94376-220-1 |
01 |
1 |
0009- |
| |
1 |
DRIVE ASM; FINAL,FRT
A/T AISIN<RMD>
FRT&RR 265/70R15 7JJX15 ALUMI WHEEL<BVH>
43/9
|
8-97039-254-0 |
01 |
1 |
0009- |
| |
1 |
DRIVE ASM; FINAL,FRT
M/T MUA 5 SPEED<RMN>
FRT&RR P225/75R15 6JJX15 AL<9LH>
43/10
|
8-97039-250-0 |
01 |
1 |
0009- |
| |
2 |
NUT; FINAL DRIVE PINION
M18 LOCK NUT
|
8-94376-262-0 |
01 |
1 |
0009- |
| |
4 |
COUPLING; FINAL DRIVE PINION
|
8-94318-527-6 |
01 |
1 |
0009- |
| |
5 |
COVER; DUST,PINION,FINAL DRIVE
|
8-94318-409-1 |
01 |
1 |
0009- |
| |
6 |
SEAL; OIL,FINAL PINION
|
8-94318-520-2 |
01 |
1 |
0009- |
| |
7 |
BEARING; PINION,OUTER
JTEKT
|
8-94472-100-1 |
01 |
1 |
0009- |
| |
7 |
BEARING; PINION,OUTER
NSK
THA
|
8-94472-099-0 |
01 |
1 |
0009- |
| |
8 |
SHIM; PINION,FINAL DRIVE
T=2.18
|
9-41519-153-1 |
AR |
1 |
0009- |
| |
8 |
SHIM; PINION,FINAL DRIVE
T=2.20
|
9-41519-154-1 |
AR |
1 |
0009- |
| |
8 |
SHIM; PINION,FINAL DRIVE
T=2.22
|
9-41519-155-1 |
AR |
1 |
0009- |
| |
8 |
SHIM; PINION,FINAL DRIVE
T=2.24
|
9-41519-156-1 |
AR |
1 |
0009- |
| |
8 |
SHIM; PINION,FINAL DRIVE
T=2.26
|
9-41519-157-1 |
AR |
1 |
0009- |
| |
8 |
SHIM; PINION,FINAL DRIVE
T=2.28
|
9-41519-158-1 |
AR |
1 |
0009- |
| |
8 |
SHIM; PINION,FINAL DRIVE
T=2.30
|
9-41519-159-1 |
AR |
1 |
0009- |
| |
8 |
SHIM; PINION,FINAL DRIVE
T=2.32
|
9-41519-160-1 |
AR |
1 |
0009- |
| |
8 |
SHIM; PINION,FINAL DRIVE
T=2.34
|
9-41519-161-1 |
AR |
1 |
0009- |
| |
8 |
SHIM; PINION,FINAL DRIVE
T=2.36
|
9-41519-162-1 |
AR |
1 |
0009- |
| |
8 |
SHIM; PINION,FINAL DRIVE
T=2.38
|
9-41519-163-1 |
AR |
1 |
0009- |
| |
8 |
SHIM; PINION,FINAL DRIVE
T=2.40
|
9-41519-164-1 |
AR |
1 |
0009- |
| |
8 |
SHIM; PINION,FINAL DRIVE
T=2.42
|
9-41519-165-1 |
AR |
1 |
0009- |
| |
8 |
SHIM; PINION,FINAL DRIVE
T=2.44
|
9-41519-166-1 |
AR |
1 |
0009- |
| |
8 |
SHIM; PINION,FINAL DRIVE
T=2.46
|
9-41519-167-1 |
AR |
1 |
0009- |
| |
8 |
SHIM; PINION,FINAL DRIVE
T=2.48
|
9-41519-168-1 |
AR |
1 |
0009- |
| |
8 |
SHIM; PINION,FINAL DRIVE
T=2.50
|
9-41519-169-1 |
AR |
1 |
0009- |
| |
8 |
SHIM; PINION,FINAL DRIVE
T=2.52
|
9-41519-170-1 |
AR |
1 |
0009- |
| |
8 |
SHIM; PINION,FINAL DRIVE
T=2.54
|
9-41519-171-1 |
AR |
1 |
0009- |
| |
8 |
SHIM; PINION,FINAL DRIVE
T=2.56
|
9-41519-172-1 |
AR |
1 |
0009- |
| |
9 |
COLLAR; DIST,PINION
|
8-94472-118-0 |
01 |
1 |
0009- |
| |
11 |
CAGE; FINAL PINION
|
8-97038-515-1 |
01 |
1 |
0009- |
| |
12 |
SHIM; FINAL PINION CAGE
T=0.10
|
8-97130-386-0 |
AR |
1 |
0009- |
| |
12 |
SHIM; FINAL PINION CAGE
T=0.50
|
8-97130-387-0 |
AR |
1 |
0009- |
| |
12 |
SHIM; FINAL PINION CAGE
T=0.24
|
9-41519-109-0 |
AR |
1 |
0009- |
| |
12 |
SHIM; FINAL PINION CAGE
T=0.15
|
9-41519-111-0 |
AR |
1 |
0009- |
| |
13 |
BOLT; FINAL PINION CAGE
M10X17
|
8-97038-065-0 |
10 |
1 |
0009- |
| |
14 |
CARRIER ASM; FINAL DRIVE,FRT AXLE
|
8-94376-231-3 |
01 |
1 |
0009- |
| |
19 |
BEARING; PINION,INNER
NSK
|
9-00093-621-0 |
01 |
1 |
0009- |
| |
21 |
GEAR SET; FINAL DRIVE,FRT
A/T AISIN<RMD>
FRT&RR P225/75R15 6JJX15 AL<9LH>
41/9
|
8-94376-223-1 |
01 |
1 |
0009- |
| |
21 |
GEAR SET; FINAL DRIVE,FRT
M/T MUA 5 SPEED<RMN>
FRT&RR 265/70R15 7JJX15 ALUMI WHEEL<BVH>
41/9
|
8-94376-223-1 |
01 |
1 |
0009- |
| |
21 |
GEAR SET; FINAL DRIVE,FRT
A/T AISIN<RMD>
FRT&RR 265/70R15 7JJX15 ALUMI WHEEL<BVH>
43/9
|
8-97039-255-1 |
01 |
1 |
0009- |
| |
21 |
GEAR SET; FINAL DRIVE,FRT
M/T MUA 5 SPEED<RMN>
FRT&RR P225/75R15 6JJX15 AL<9LH>
43/10
|
8-97039-251-1 |
01 |
1 |
0009- |
| |
30 |
BOLT; DIFF CAGE SETTING
M12X62
|
8-94376-322-0 |
04 |
1 |
0009- |
| |
34 |
PIN; CROSS,DIFF PINION
|
9-41521-044-1 |
01 |
1 |
0009- |
| |
35 |
WASHER; THRUST,SIDE GEAR
T=1.00
|
5-41562-005-1 |
02 |
1 |
0009- |
| |
35 |
WASHER; THRUST,SIDE GEAR
T=1.05
|
5-41562-006-1 |
02 |
1 |
0009- |
| |
35 |
WASHER; THRUST,SIDE GEAR
T=1.10
|
5-41562-007-1 |
02 |
1 |
0009- |
| |
36 |
GEAR; SIDE,DIFF
Z=17
|
8-97079-519-1 |
02 |
1 |
0009- |
| |
37 |
GEAR; PINION DIFF
Z=10
|
8-97079-518-0 |
02 |
1 |
0009- |
| |
39 |
PIN; LK,CROSS PIN
OD=5 L=35
|
9-09878-096-0 |
01 |
1 |
0009- |
| |
69 |
BEARING; DIFF SIDE
NSK
THA
|
9-00093-074-0 |
02 |
1 |
0009- |
