1 |
06.008 AXLE; FRT
G.V.W. 4.0-4.5TON(RPR)
|
8-97262-000-4 |
01 |
1 |
1512- |
● |
|
| |
1 |
06.008 AXLE; FRT
|
8-97262-000-4 |
01 |
1 |
1512- |
|
● |
| |
1 |
06.008 AXLE; FRT
G.V.W. 3.0-3.5TON(RPP)
|
8-94113-402-9 |
01 |
1 |
1512- |
● |
|
| |
2 |
06.020 KNUCKLE; FRT AXLE
G.V.W. 4.0-4.5TON(RPR)
|
8-97261-545-2 |
01 |
1 |
1512- |
● |
|
| |
2 |
06.020 KNUCKLE; FRT AXLE
G.V.W. 4.0-4.5TON(RPR)
|
8-97261-546-2 |
01 |
1 |
1512- |
● |
|
| |
2 |
06.020 KNUCKLE; FRT AXLE
G.V.W. 3.0-3.5TON(RPP)
|
8-97261-537-0 |
01 |
1 |
1512- |
● |
|
| |
2 |
06.020 KNUCKLE; FRT AXLE
G.V.W. 3.0-3.5TON(RPP)
|
8-97261-538-0 |
01 |
1 |
1512- |
● |
|
| |
2 |
06.020 KNUCKLE; FRT AXLE
|
8-97261-549-2 |
01 |
1 |
1512- |
|
● |
| |
2 |
06.020 KNUCKLE; FRT AXLE
|
8-97261-550-2 |
01 |
1 |
1512- |
|
● |
| |
4 |
06.203 KING PIN KIT
G.V.W. 3.0-3.5TON(RPP)
|
5-87832-208-3 |
01 |
1 |
1512- |
● |
|
| |
4 |
06.203 KING PIN KIT
G.V.W. 4.0-4.5TON(RPR)
|
5-87832-220-4 |
01 |
1 |
1512- |
● |
|
| |
4 |
06.203 KING PIN KIT
|
5-87832-220-4 |
01 |
1 |
1512- |
|
● |
| |
10 |
06.009 PLUG; PLATE,KNUCKLE
|
8-97360-117-0 |
01 |
1 |
1512- |
● |
|
| |
12 |
06.021 GASKET; KNUCKLE
G.V.W. 4.0-4.5TON(RPR)
|
8-98084-500-0 |
02 |
1 |
1512- |
● |
|
| |
12 |
06.021 GASKET; KNUCKLE
|
8-98084-500-0 |
02 |
1 |
1512- |
|
● |
| |
12 |
06.021 GASKET; KNUCKLE
G.V.W. 3.0-3.5TON(RPP)
|
9-09561-225-0 |
02 |
1 |
1512- |
● |
|
| |
14 |
06.021 BUSHING; KING PIN
G.V.W. 4.0-4.5TON(RPR)
DAIDO WO/NOTCH
|
8-94107-672-3 |
04 |
1 |
1512- |
● |
|
| |
14 |
06.021 BUSHING; KING PIN
DAIDO WO/NOTCH
|
8-94107-672-3 |
04 |
1 |
1512- |
|
● |
| |
14 |
06.021 BUSHING; KING PIN
G.V.W. 3.0-3.5TON(RPP)
|
8-94102-046-3 |
04 |
1 |
1512- |
● |
|
| |
17 |
06.009 BOLT; STOPPER KNUCKLE
M12X27.5
|
8-98016-968-0 |
03 |
1 |
1512- |
● |
● |
| |
18 |
06.216 NUT; STOPPER BOLT,KNUCKLE
04.439
M12
|
0-91111-512-0 |
03 |
1 |
1512- |
● |
● |
| |
21 |
06.166 NIPPLE; GREASE,KING PIN
05.601
M6 STRAIGHT
|
0-90301-406-0 |
04 |
1 |
1512- |
● |
● |
| |
25 |
06.210 BEARING; THRUST,KING PIN
G.V.W. 4.0-4.5TON(RPR)
06.021
OD=54 ID=30.2 T=13.8
|
8-94248-883-3 |
01 |
1 |
1512- |
● |
|
| |
25 |
06.210 BEARING; THRUST,KING PIN
06.021
OD=54 ID=30.2 T=13.8
|
8-94248-883-3 |
01 |
1 |
1512- |
|
● |
| |
25 |
06.210 BEARING; THRUST,KING PIN
G.V.W. 4.0-4.5TON(RPR)
OD=51.6 ID=30.5 T=15.6
|
8-97141-943-1 |
01 |
1 |
1512- |
● |
|
| |
25 |
06.210 BEARING; THRUST,KING PIN
OD=51.6 ID=30.5 T=15.6
|
8-97141-943-1 |
01 |
1 |
1512- |
|
● |
| |
25 |
06.210 BEARING; THRUST,KING PIN
G.V.W. 3.0-3.5TON(RPP)
|
8-94162-578-1 |
02 |
1 |
1512- |
● |
|
| |
26 |
06.022 SHIM; KING PIN,BRG
G.V.W. 4.0-4.5TON(RPR)
(A)
T=0.50
|
8-94162-574-0 |
AR |
1 |
1512- |
● |
|
| |
26 |
06.022 SHIM; KING PIN,BRG
(A)
T=0.50
|
8-94162-574-0 |
AR |
1 |
1512- |
|
● |
| |
26 |
06.022 SHIM; KING PIN,BRG
G.V.W. 4.0-4.5TON(RPR)
(A)
T=0.55
|
8-94162-575-0 |
AR |
1 |
1512- |
● |
|
| |
26 |
06.022 SHIM; KING PIN,BRG
(A)
T=0.55
|
8-94162-575-0 |
AR |
1 |
1512- |
|
● |
| |
26 |
06.022 SHIM; KING PIN,BRG
G.V.W. 4.0-4.5TON(RPR)
(A)
T=0.60
|
8-94162-576-0 |
AR |
1 |
1512- |
● |
|
| |
26 |
06.022 SHIM; KING PIN,BRG
(A)
T=0.60
|
8-94162-576-0 |
AR |
1 |
1512- |
|
● |
| |
26 |
06.022 SHIM; KING PIN,BRG
G.V.W. 4.0-4.5TON(RPR)
(A)
T=0.65
|
8-94162-577-0 |
AR |
1 |
1512- |
● |
|
| |
26 |
06.022 SHIM; KING PIN,BRG
(A)
T=0.65
|
8-94162-577-0 |
AR |
1 |
1512- |
|
● |
| |
26 |
06.022 SHIM; KING PIN,BRG
G.V.W. 4.0-4.5TON(RPR)
05.460
(B)
T=1.95
|
8-94168-490-0 |
01 |
1 |
1512- |
● |
|
| |
26 |
06.022 SHIM; KING PIN,BRG
05.460
(B)
T=1.95
|
8-94168-490-0 |
01 |
1 |
1512- |
|
● |
| |
26 |
06.022 SHIM; KING PIN,BRG
G.V.W. 4.0-4.5TON(RPR)
(A)
T=0.70
|
8-94174-352-0 |
AR |
1 |
1512- |
● |
|
| |
26 |
06.022 SHIM; KING PIN,BRG
(A)
T=0.70
|
8-94174-352-0 |
AR |
1 |
1512- |
|
● |
| |
26 |
06.022 SHIM; KING PIN,BRG
G.V.W. 4.0-4.5TON(RPR)
(A)
T=0.80
|
8-94174-354-0 |
AR |
1 |
1512- |
● |
|
| |
26 |
06.022 SHIM; KING PIN,BRG
(A)
T=0.80
|
8-94174-354-0 |
AR |
1 |
1512- |
|
● |
| |
26 |
06.022 SHIM; KING PIN,BRG
G.V.W. 4.0-4.5TON(RPR)
(A)
T=0.90
|
8-94174-356-0 |
AR |
1 |
1512- |
● |
|
| |
26 |
06.022 SHIM; KING PIN,BRG
(A)
T=0.90
|
8-94174-356-0 |
AR |
1 |
1512- |
|
● |
| |
26 |
06.022 SHIM; KING PIN,BRG
G.V.W. 3.0-3.5TON(RPP)
06.225
(A)
T=0.50
|
8-94162-570-0 |
AR |
1 |
1512- |
● |
|
| |
26 |
06.022 SHIM; KING PIN,BRG
G.V.W. 3.0-3.5TON(RPP)
06.225
(A)
T=0.55
|
8-94162-571-0 |
AR |
1 |
1512- |
● |
|
| |
26 |
06.022 SHIM; KING PIN,BRG
G.V.W. 3.0-3.5TON(RPP)
06.225
(A)
T=0.60
|
8-94162-572-0 |
AR |
1 |
1512- |
● |
|
| |
26 |
06.022 SHIM; KING PIN,BRG
G.V.W. 3.0-3.5TON(RPP)
06.225
(A)
T=0.65
|
8-94162-573-0 |
AR |
1 |
1512- |
● |
|
| |
26 |
06.022 SHIM; KING PIN,BRG
G.V.W. 3.0-3.5TON(RPP)
06.225
(A)
T=0.70
|
8-94174-347-0 |
AR |
1 |
1512- |
● |
|
| |
26 |
06.022 SHIM; KING PIN,BRG
G.V.W. 3.0-3.5TON(RPP)
06.225
(A)
T=0.80
|
8-94174-349-0 |
AR |
1 |
1512- |
● |
|
| |
26 |
06.022 SHIM; KING PIN,BRG
G.V.W. 3.0-3.5TON(RPP)
06.225
(A)
T=0.90
|
8-94174-351-0 |
AR |
1 |
1512- |
● |
|
| |
31 |
07.347 PIN; S/ABS,LWR
G.V.W. 4.0-4.5TON(RPR)
|
8-97141-944-0 |
02 |
1 |
1512- |
● |
|
| |
31 |
07.347 PIN; S/ABS,LWR
|
8-97141-944-0 |
02 |
1 |
1512- |
|
● |
| |
31 |
07.347 PIN; S/ABS,LWR
G.V.W. 3.0-3.5TON(RPP)
|
8-94249-010-1 |
02 |
1 |
1512- |
● |
|
| |
32 |
06.216 BOLT; KEY,KING PIN
G.V.W. 3.0-3.5TON(RPP)
|
8-97141-945-2 |
01 |
1 |
1512- |
● |
|
| |
32 |
06.216 BOLT; KEY,KING PIN
|
8-97141-945-2 |
01 |
1 |
1512- |
|
● |
| |
32 |
06.216 BOLT; KEY,KING PIN
G.V.W. 4.0-4.5TON(RPR)
|
8-97141-945-2 |
02 |
1 |
1512- |
● |
|
| |
33 |
06.216 NUT; KEY BOLT
G.V.W. 4.0-4.5TON(RPR)
00.833
M10
|
0-91110-510-0 |
02 |
1 |
1512- |
● |
|
| |
33 |
06.216 NUT; KEY BOLT
00.833
M10
|
0-91110-510-0 |
02 |
1 |
1512- |
|
● |
| |
34 |
06.216 WASHER; LK,KEY BOLT
G.V.W. 4.0-4.5TON(RPR)
06.606
ID=10.2
|
0-91510-510-0 |
02 |
1 |
1512- |
● |
|
| |
34 |
06.216 WASHER; LK,KEY BOLT
06.606
ID=10.2
|
0-91510-510-0 |
02 |
1 |
1512- |
|
● |
| |
36 |
06.103 ARM; KNUCKLE
G.V.W. 3.0-3.5TON(RPP)
02.525
|
8-97070-138-4 |
01 |
1 |
1512- |
● |
|
| |
36 |
06.103 ARM; KNUCKLE
G.V.W. 4.0-4.5TON(RPR)
|
8-97253-712-4 |
01 |
1 |
1512- |
● |
|
| |
36 |
06.103 ARM; KNUCKLE
|
8-97253-712-4 |
01 |
1 |
1512- |
|
● |
| |
44 |
06.225 COVER; KING PIN
G.V.W. 3.0-3.5TON(RPP)
OD=36
|
8-97360-023-0 |
01 |
1 |
1512- |
● |
|
| |
44 |
06.225 COVER; KING PIN
OD=36
|
8-97360-023-0 |
01 |
1 |
1512- |
|
● |
| |
44 |
06.225 COVER; KING PIN
G.V.W. 4.0-4.5TON(RPR)
OD=36
|
8-97360-023-0 |
02 |
1 |
1512- |
● |
|
| |
48 |
06.225 BOLT; COVER
G.V.W. 4.0-4.5TON(RPR)
M10X12 FLANGE
|
0-28051-012-0 |
02 |
1 |
1512- |
● |
|
| |
48 |
06.225 BOLT; COVER
M10X12 FLANGE
|
0-28051-012-0 |
02 |
1 |
1512- |
|
● |
| |
49 |
06.225 CAP; KNUCKLE
|
8-97360-024-0 |
02 |
1 |
1512- |
● |
● |
| |
58 |
06.103 ARM; TIE ROD
G.V.W. 3.0-3.5TON(RPP)
|
8-97032-912-0 |
01 |
1 |
1512- |
● |
|
| |
58 |
06.103 ARM; TIE ROD
G.V.W. 4.0-4.5TON(RPR)
|
8-97138-303-1 |
01 |
1 |
1512- |
● |
|
| |
58 |
06.103 ARM; TIE ROD
|
8-97138-303-1 |
01 |
1 |
1512- |
|
● |
| |
59 |
06.104 NUT; TIE ROD ARM
|
8-97360-123-0 |
02 |
1 |
1512- |
● |
● |
| |
61 |
06.233 ROD END; TIE ROD
|
8-97107-349-2 |
01 |
1 |
1512- |
● |
● |
| |
61 |
06.233 ROD END; TIE ROD
G.V.W. 4.0-4.5TON(RPR)
|
8-98251-954-0 |
01 |
1 |
1512- |
● |
|
| |
61 |
06.233 ROD END; TIE ROD
|
8-98251-954-0 |
01 |
1 |
1512- |
|
● |
| |
61 |
06.233 ROD END; TIE ROD
G.V.W. 3.0-3.5TON(RPP)
|
8-97107-348-2 |
01 |
1 |
1512- |
● |
|
| |
66 |
06.234 NUT; TIE ROD END
06.216
M16 SLOTTED
|
8-98049-689-0 |
02 |
1 |
1512- |
● |
● |
| |
69 |
06.255 PIN; SPLIT,TIE ROD END
OD=3.7 L=20
|
0-81124-020-0 |
02 |
1 |
1512- |
● |
● |
| |
70 |
06.234 NUT; TIE ROD END
M20 LH THREAD
|
8-94254-726-0 |
01 |
1 |
1512- |
● |
● |
| |
70 |
06.234 NUT; TIE ROD END
M20 RH THREAD
|
8-98043-530-0 |
01 |
1 |
1512- |
● |
● |
| |
81 |
06.230 ROD; TIE
G.V.W. 4.0-4.5TON(RPR)
|
8-97142-024-0 |
01 |
1 |
1512- |
● |
|
| |
81 |
06.230 ROD; TIE
|
8-97142-024-0 |
01 |
1 |
1512- |
|
● |
| |
81 |
06.230 ROD; TIE
G.V.W. 3.0-3.5TON(RPP)
|
8-97061-866-0 |
01 |
1 |
1512- |
● |
|
