Sayfa 7-10 - Isuzu EPC

7-10 — CAUTION PLATE AND LABEL (#169108) — 7 parça

181 49 49

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date
49	PLATE; CAUTION,FUSE BOX CAUTIONS SPANISH<YN1>	8-98133-856-0	01	1	1511-
49	PLATE; CAUTION,FUSE BOX EXC. CAUTIONS SPANISH<YN1>	8-98133-855-0	01	1	1511-
181	PLATE; CAUTION,AIR CLEANER	1-85886-796-1	01	1	1511-

6 6 150 182

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date
6	PLATE; CAUTION,SPARE TIRE CAUTIONS ENGLISH<RR8> SPARE WHEEL CARRIER(SFB) (B) IDN	8-98082-437-0	01	1	1511-
6	PLATE; CAUTION,SPARE TIRE SPARE WHEEL CARRIER(SFB) CAUTIONS SPANISH<YN1> (A)	8-98082-439-0	01	1	1511-
150	PLATE; CAUTION,INSTRUCTION ELECTRIC SWITCH BOX ENGINE ROOM<TEK>	1-85888-543-0	01	1	1511-
182	PLATE; CAUTION,EMERGENCY AUTO ENG SHUT DOWN(Q3G)	8-98151-591-0	01	1	1511-
