Sayfa 7-70 - Isuzu EPC

7-70 — SEPARATER AND BED (#168072) — 80 parça

64 51 51 92 46 92

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date
46	CURTAIN ASM; DOOR WINDOW CURTAIN ROUND<BW4>	1-73907-494-0	01	1	1508-
51	CURTAIN; BACK WINDOW CURTAIN ROUND<BW4>	1-73907-482-1	01	1	1508-
51	CURTAIN; BACK WINDOW CURTAIN ROUND<BW4>	1-73907-483-1	01	1	1508-
64	CURTAIN KIT WINDOW CURTAIN ROUND<BW4>	1-73907-630-0	01	1	1508-
92	CURTAIN ASM; ROUND WINDOW CURTAIN ROUND<BW4>	1-73907-484-1	01	1	1508-
92	CURTAIN ASM; ROUND WINDOW CURTAIN ROUND<BW4>	1-73907-485-1	01	1	1508-

86 85 84 42 85 50 47 91 40 42 42 47 50 47 47 50 42 47 40 91 42 50 85 84 86 50 48 84 86 45 58 59

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date
40	RAIL; CURTAIN,SIDE WINDOW CURTAIN ROUND<BW4>	1-73907-635-1	01	1	1508-
40	RAIL; CURTAIN,SIDE WINDOW CURTAIN ROUND<BW4>	1-73907-634-1	01	1	1508-
40	RAIL; CURTAIN,SIDE EXC. WINDOW CURTAIN ROUND<BW4>	1-73907-729-1	01	1	1508-
40	RAIL; CURTAIN,SIDE EXC. WINDOW CURTAIN ROUND<BW4>	1-73907-728-0	01	1	1508-
42	STOPPER; CURTAIN RAIL (A)	1-73996-402-0	02	1	1508-
42	STOPPER; CURTAIN RAIL WINDOW CURTAIN ROUND<BW4> (C)	1-73996-393-0	04	1	1508-
42	STOPPER; CURTAIN RAIL WINDOW CURTAIN ROUND<BW4> (B)	1-73996-399-0	02	1	1508-
42	STOPPER; CURTAIN RAIL EXC. WINDOW CURTAIN ROUND<BW4> (C)	1-73996-393-0	02	1	1508-
42	STOPPER; CURTAIN RAIL EXC. WINDOW CURTAIN ROUND<BW4> (B)	1-73996-399-0	01	1	1508-
45	RAIL; CURTAIN,FRT WINDOW CURTAIN ROUND<BW4>	1-73907-546-3	01	1	1508-
45	RAIL; CURTAIN,FRT EXC. WINDOW CURTAIN ROUND<BW4>	1-73907-545-2	01	1	1508-
47	SCREW; CURTAIN RAIL (A) M5X20	5-09981-059-0	02	1	1508-
47	SCREW; CURTAIN RAIL (A) M5X20	5-09981-059-0	11	1	1508-
47	SCREW; CURTAIN RAIL (B) M5X25	5-09981-093-0	07	1	1508-
47	SCREW; CURTAIN RAIL WINDOW CURTAIN ROUND<BW4> (A) M5X20	5-09981-059-0	16	1	1508-
47	SCREW; CURTAIN RAIL EXC. WINDOW CURTAIN ROUND<BW4> (A) M5X20	5-09981-059-0	08	1	1508-
48	RAIL; CURTAIN,BACK WINDOW CURTAIN ROUND<BW4>	1-73996-386-1	01	1	1508-
48	RAIL; CURTAIN,BACK EXC. WINDOW CURTAIN ROUND<BW4>	1-73996-385-1	01	1	1508-
50	GROMMET; SCREW,CURTAIN RAIL (B) D=8X8 L=13 M5	1-09983-159-0	07	1	1508-
50	GROMMET; SCREW,CURTAIN RAIL (A) D=8.6X7.7 L=7.5	8-94279-078-0	02	1	1508-
50	GROMMET; SCREW,CURTAIN RAIL (A) D=8.6X7.7 L=7.5	8-94279-078-0	11	1	1508-
50	GROMMET; SCREW,CURTAIN RAIL WINDOW CURTAIN ROUND<BW4> (A) D=8.6X7.7 L=7.5	8-94279-078-0	16	1	1508-
50	GROMMET; SCREW,CURTAIN RAIL EXC. WINDOW CURTAIN ROUND<BW4> (A) D=8.6X7.7 L=7.5	8-94279-078-0	08	1	1508-
58	BED; MAT SEAT ASM - WITH CENTER SEAT(7BC) SEAT CLOTH(7FL)	8-98202-396-0	01	1	1508-
58	BED; MAT VINYL SEAT(A83) SEAT ASM - WITH CENTER SEAT(7BC)	8-98202-395-0	01	1	1508-
58	BED; MAT 1 CREWS SEAT ASM PASSENGER DELETE(AP5),CENTER SEAT DELETE(SP9) SEAT CLOTH(7FL)	8-98133-259-1	01	1	1508-
58	BED; MAT 1 CREWS SEAT ASM PASSENGER DELETE(AP5),CENTER SEAT DELETE(SP9) VINYL SEAT(A83)	1-75117-967-3	01	1	1508-
59	COVER ASM; TRIM,BED MAT SEAT ASM - WITH CENTER SEAT(7BC) SEAT CLOTH(7FL)	8-98209-458-0	01	1	1508-
59	COVER ASM; TRIM,BED MAT VINYL SEAT(A83) SEAT ASM - WITH CENTER SEAT(7BC)	8-98209-459-0	01	1	1508-
59	COVER ASM; TRIM,BED MAT 1 CREWS SEAT ASM PASSENGER DELETE(AP5),CENTER SEAT DELETE(SP9) SEAT CLOTH(7FL)	8-98061-723-1	01	1	1508-
59	COVER ASM; TRIM,BED MAT 1 CREWS SEAT ASM PASSENGER DELETE(AP5),CENTER SEAT DELETE(SP9) VINYL SEAT(A83)	1-75117-970-1	01	1	1508-
84	BRACKET; CURTAIN RAIL (A)	1-73998-986-2	02	1	1508-
84	BRACKET; CURTAIN RAIL (B)	1-73998-987-4	07	1	1508-
85	SCREW; BRKT M5X20	5-09981-059-0	09	1	1508-
86	GROMMET; SCREW,BRKT D=8.6X7.7 L=7.5	8-94279-078-0	09	1	1508-
91	CLIP; CURTAIN HOOK D6X23 LIGHT GRAY	1-73318-629-0	02	1	1508-

86 85 84 85 42 50 41 40 42 47 91 42 47 50 47 42 84 86 48 50 41 42 45 85 84 41 50 86 91 42 50 47 42 41 42 40 47 58 59

Balon	Parca Adi	Parca No	Adet	Tip	Applied Date
40	RAIL; CURTAIN,SIDE WINDOW CURTAIN ROUND<BW4>	1-73907-635-1	01	1	1508-
40	RAIL; CURTAIN,SIDE WINDOW CURTAIN ROUND<BW4>	1-73907-634-1	01	1	1508-
40	RAIL; CURTAIN,SIDE EXC. WINDOW CURTAIN ROUND<BW4>	1-73907-729-1	01	1	1508-
40	RAIL; CURTAIN,SIDE EXC. WINDOW CURTAIN ROUND<BW4>	1-73907-728-0	01	1	1508-
41	HOOK; CURTAIN RAIL WINDOW CURTAIN ROUND<BW4> H=14.5 WHITE	1-73996-398-0	14	1	1508-
41	HOOK; CURTAIN RAIL WINDOW CURTAIN ROUND<BW4> H=14.5 WHITE	1-73996-398-0	42	1	1508-
42	STOPPER; CURTAIN RAIL (A)	1-73996-402-0	02	1	1508-
42	STOPPER; CURTAIN RAIL WINDOW CURTAIN ROUND<BW4> (C)	1-73996-393-0	04	1	1508-
42	STOPPER; CURTAIN RAIL WINDOW CURTAIN ROUND<BW4> (B)	1-73996-399-0	02	1	1508-
42	STOPPER; CURTAIN RAIL EXC. WINDOW CURTAIN ROUND<BW4> (C)	1-73996-393-0	02	1	1508-
42	STOPPER; CURTAIN RAIL EXC. WINDOW CURTAIN ROUND<BW4> (B)	1-73996-399-0	01	1	1508-
45	RAIL; CURTAIN,FRT WINDOW CURTAIN ROUND<BW4>	1-73907-546-3	01	1	1508-
45	RAIL; CURTAIN,FRT EXC. WINDOW CURTAIN ROUND<BW4>	1-73907-545-2	01	1	1508-
47	SCREW; CURTAIN RAIL (A) M5X20	5-09981-059-0	02	1	1508-
47	SCREW; CURTAIN RAIL (A) M5X20	5-09981-059-0	11	1	1508-
47	SCREW; CURTAIN RAIL (B) M5X25	5-09981-093-0	07	1	1508-
47	SCREW; CURTAIN RAIL WINDOW CURTAIN ROUND<BW4> (A) M5X20	5-09981-059-0	16	1	1508-
47	SCREW; CURTAIN RAIL EXC. WINDOW CURTAIN ROUND<BW4> (A) M5X20	5-09981-059-0	08	1	1508-
48	RAIL; CURTAIN,BACK WINDOW CURTAIN ROUND<BW4>	1-73996-386-1	01	1	1508-
48	RAIL; CURTAIN,BACK EXC. WINDOW CURTAIN ROUND<BW4>	1-73996-385-1	01	1	1508-
50	GROMMET; SCREW,CURTAIN RAIL (B) D=8X8 L=13 M5	1-09983-159-0	07	1	1508-
50	GROMMET; SCREW,CURTAIN RAIL (A) D=8.6X7.7 L=7.5	8-94279-078-0	02	1	1508-
50	GROMMET; SCREW,CURTAIN RAIL (A) D=8.6X7.7 L=7.5	8-94279-078-0	11	1	1508-
50	GROMMET; SCREW,CURTAIN RAIL WINDOW CURTAIN ROUND<BW4> (A) D=8.6X7.7 L=7.5	8-94279-078-0	16	1	1508-
50	GROMMET; SCREW,CURTAIN RAIL EXC. WINDOW CURTAIN ROUND<BW4> (A) D=8.6X7.7 L=7.5	8-94279-078-0	08	1	1508-
58	BED; MAT SEAT ASM - WITH CENTER SEAT(7BC) SEAT CLOTH(7FL)	8-98202-396-0	01	1	1508-
58	BED; MAT VINYL SEAT(A83) SEAT ASM - WITH CENTER SEAT(7BC)	8-98202-395-0	01	1	1508-
58	BED; MAT 1 CREWS SEAT ASM PASSENGER DELETE(AP5),CENTER SEAT DELETE(SP9) SEAT CLOTH(7FL)	8-98133-259-1	01	1	1508-
58	BED; MAT 1 CREWS SEAT ASM PASSENGER DELETE(AP5),CENTER SEAT DELETE(SP9) VINYL SEAT(A83)	1-75117-967-3	01	1	1508-
59	COVER ASM; TRIM,BED MAT SEAT ASM - WITH CENTER SEAT(7BC) SEAT CLOTH(7FL)	8-98209-458-0	01	1	1508-
59	COVER ASM; TRIM,BED MAT VINYL SEAT(A83) SEAT ASM - WITH CENTER SEAT(7BC)	8-98209-459-0	01	1	1508-
59	COVER ASM; TRIM,BED MAT 1 CREWS SEAT ASM PASSENGER DELETE(AP5),CENTER SEAT DELETE(SP9) SEAT CLOTH(7FL)	8-98061-723-1	01	1	1508-
59	COVER ASM; TRIM,BED MAT 1 CREWS SEAT ASM PASSENGER DELETE(AP5),CENTER SEAT DELETE(SP9) VINYL SEAT(A83)	1-75117-970-1	01	1	1508-
84	BRACKET; CURTAIN RAIL (A)	1-73998-986-2	02	1	1508-
84	BRACKET; CURTAIN RAIL (B)	1-73998-987-4	07	1	1508-
85	SCREW; BRKT M5X20	5-09981-059-0	09	1	1508-
86	GROMMET; SCREW,BRKT D=8.6X7.7 L=7.5	8-94279-078-0	09	1	1508-
91	CLIP; CURTAIN HOOK D6X23 LIGHT GRAY	1-73318-629-0	02	1	1508-

İpucu: çizimdeki balona veya tablodaki Balon sütununa tıkla; ilgili parçalar vurgulanır. Birden çok çizim varsa üstteki seçim kutusu/oklarla gezin.
