1 |
MANIFOLD; EXHAUST
|
8-97028-475-1 |
01 |
1 |
9304-9502 |
● |
● |
|
|
|
|
| |
1 |
MANIFOLD; EXHAUST
|
8-97065-960-1 |
01 |
1 |
9304-9503 |
|
|
● |
|
|
|
| |
1 |
MANIFOLD; EXHAUST
|
8-97124-873-0 |
01 |
1 |
9504-9703 |
|
|
● |
|
|
|
| |
1 |
MANIFOLD; EXHAUST
|
8-97065-960-1 |
01 |
1 |
9704- |
|
|
● |
|
|
|
| |
1 |
MANIFOLD; EXHAUST
|
8-97075-395-0 |
01 |
1 |
9304-9310 |
|
|
|
● |
|
|
| |
1 |
MANIFOLD; EXHAUST
|
8-97104-378-2 |
01 |
1 |
9311-9502 |
|
|
|
● |
|
|
| |
1 |
MANIFOLD; EXHAUST
|
8-97136-316-0 |
01 |
1 |
9503-9611 |
|
|
|
● |
● |
|
| |
1 |
MANIFOLD; EXHAUST
|
8-97074-870-1 |
01 |
1 |
9612-9703 |
|
|
|
● |
● |
|
| |
1 |
MANIFOLD; EXHAUST
|
8-97163-080-0 |
01 |
1 |
9704- |
|
|
|
● |
● |
● |
| |
2 |
GASKET; EXH MANIF TO HD
ALSO INCLUDED IN GASKET SET(ENG. & HEAD)
|
8-94404-610-0 |
02 |
1 |
9304-9502 |
● |
● |
|
|
|
|
| |
2 |
GASKET; EXH MANIF TO HD
ALSO INCLUDED IN GASKET SET(ENG. & HEAD)
|
8-97020-591-0 |
01 |
1 |
9304-9408 |
|
|
● |
|
|
|
| |
2 |
GASKET; EXH MANIF TO HD
ALSO INCLUDED IN GASKET SET(ENG. & HEAD)
|
8-97109-216-2 |
01 |
1 |
9409- |
|
|
● |
|
|
|
| |
2 |
GASKET; EXH MANIF TO HD
ALSO INCLUDED IN GASKET SET(ENG. & HEAD)
(A)
|
8-97061-542-0 |
02 |
1 |
9304-9405 |
|
|
|
● |
|
|
| |
2 |
GASKET; EXH MANIF TO HD
ALSO INCLUDED IN GASKET SET(ENG. & HEAD)
(B)
|
8-97105-866-1 |
01 |
1 |
9406-9502 |
|
|
|
● |
|
|
| |
2 |
GASKET; EXH MANIF TO HD
ALSO INCLUDED IN GASKET SET(ENG. & HEAD)
|
8-97105-866-1 |
01 |
1 |
9503-9609 |
|
|
|
● |
● |
|
| |
2 |
GASKET; EXH MANIF TO HD
ALSO INCLUDED IN GASKET SET(ENG. & HEAD)
|
8-97146-499-0 |
01 |
1 |
9610-9703 |
|
|
|
● |
● |
|
| |
2 |
GASKET; EXH MANIF TO HD
ALSO INCLUDED IN GASKET SET(ENG. & HEAD)
|
8-97146-499-0 |
01 |
1 |
9704- |
|
|
|
● |
● |
● |
| |
3 |
PROTECTOR; HEAT,EXH MANIF
|
8-97095-360-1 |
01 |
1 |
9304-9502 |
● |
● |
|
|
|
|
| |
3 |
PROTECTOR; HEAT,EXH MANIF
AIR CONDITIONER MANUAL CONT(C60),AIR
CONDITIONER AUTOMATIC CONT(C61)
|
8-97083-321-0 |
01 |
1 |
9304-9703 |
|
|
● |
|
|
|
| |
3 |
PROTECTOR; HEAT,EXH MANIF
AIR CONDITIONER MANUAL CONT(C60)
|
8-97083-321-0 |
01 |
1 |
9704- |
|
|
● |
|
|
|
| |
3 |
PROTECTOR; HEAT,EXH MANIF
|
8-97095-067-0 |
01 |
1 |
9304-9502 |
|
|
|
● |
|
|
| |
3 |
PROTECTOR; HEAT,EXH MANIF
|
8-97116-079-4 |
01 |
1 |
9503-9703 |
|
|
|
● |
● |
|
| |
3 |
PROTECTOR; HEAT,EXH MANIF
|
8-97116-079-6 |
01 |
1 |
9704- |
|
|
|
● |
● |
● |
| |
13 |
WASHER; LK,EXH MANIF
ID=8.2
|
9-09150-508-0 |
02 |
1 |
9304-9606 |
|
|
● |
|
|
|
| |
13 |
WASHER; LK,EXH MANIF
T=2.2
|
1-09556-015-0 |
04 |
1 |
9304-9404 |
|
|
|
● |
|
|
| |
13 |
WASHER; LK,EXH MANIF
T=2.2
|
1-09556-015-0 |
02 |
1 |
9405-9502 |
|
|
|
● |
|
|
| |
13 |
WASHER; LK,EXH MANIF
T=2.2
|
1-09556-015-0 |
02 |
1 |
9503-9703 |
|
|
|
● |
● |
|
| |
13 |
WASHER; LK,EXH MANIF
T=2.2
|
1-09556-015-0 |
02 |
1 |
9704- |
|
|
|
● |
● |
● |
| |
14 |
WASHER; PL,EXH MANIF
ID=8.4 OD=18
|
9-09164-608-0 |
04 |
1 |
9304-9502 |
● |
● |
|
|
|
|
| |
14 |
WASHER; PL,EXH MANIF
ID=8.5 OD=15 T=4
|
1-09503-219-0 |
02 |
1 |
9607- |
|
|
● |
|
|
|
| |
14 |
WASHER; PL,EXH MANIF
T=5.5
|
1-14149-042-0 |
08 |
1 |
9304-9406 |
|
|
|
● |
|
|
| |
15 |
BOLT; EXH MANIF
M8X75 W/PL WASHER
|
8-94318-555-0 |
03 |
1 |
9304-9502 |
● |
● |
|
|
|
|
| |
15 |
BOLT; EXH MANIF
M8X53 W/PL WASHER
|
8-97020-490-0 |
01 |
1 |
9304-9502 |
● |
● |
|
|
|
|
| |
15 |
BOLT; EXH MANIF
M8X35
|
8-97045-441-0 |
06 |
1 |
9304-9606 |
|
|
● |
|
|
|
| |
15 |
BOLT; EXH MANIF
M8X35 W/PL WASHER & FLANGE
|
8-97131-597-1 |
06 |
1 |
9607- |
|
|
● |
|
|
|
| |
15 |
BOLT; EXH MANIF
M10X60
|
8-97061-543-0 |
04 |
1 |
9304-9405 |
|
|
|
● |
|
|
| |
15 |
BOLT; EXH MANIF
M10X60
|
8-97061-543-0 |
06 |
1 |
9406-9502 |
|
|
|
● |
|
|
| |
15 |
BOLT; EXH MANIF
M10X60
|
8-97061-543-0 |
06 |
1 |
9503-9703 |
|
|
|
● |
● |
|
| |
15 |
BOLT; EXH MANIF
M10X60
|
8-97061-543-0 |
06 |
1 |
9704- |
|
|
|
● |
● |
● |
| |
16 |
STUD; EXH PIPE TO MANIF
M10X45 L=60 STAINLESS
|
8-97032-977-0 |
03 |
1 |
9304-9502 |
● |
● |
|
|
|
|
| |
16 |
STUD; EXH PIPE TO MANIF
M10X45 L=60 PLATING
|
5-09302-008-1 |
04 |
1 |
9304- |
|
|
● |
|
|
|
| |
16 |
STUD; EXH PIPE TO MANIF
M10X38 L=53
|
8-97077-549-0 |
03 |
1 |
9304-9502 |
|
|
|
● |
|
|
| |
16 |
STUD; EXH PIPE TO MANIF
M10X38 L=53
|
8-97077-549-0 |
03 |
1 |
9503-9703 |
|
|
|
● |
● |
|
| |
16 |
STUD; EXH PIPE TO MANIF
M10X38 L=53
|
8-97077-549-0 |
03 |
1 |
9704- |
|
|
|
● |
● |
● |
| |
18 |
NUT; EXH MANIF
M8
|
9-09110-508-0 |
04 |
1 |
9304-9502 |
● |
● |
|
|
|
|
| |
18 |
NUT; EXH MANIF
M8
|
9-09110-508-0 |
02 |
1 |
9304-9606 |
|
|
● |
|
|
|
| |
18 |
NUT; EXH MANIF
M8 FLANGE
|
0-91150-208-0 |
02 |
1 |
9607- |
|
|
● |
|
|
|
| |
18 |
NUT; EXH MANIF
M10 FLANGE
|
0-91150-210-0 |
04 |
1 |
9304-9405 |
|
|
|
● |
|
|
| |
18 |
NUT; EXH MANIF
M10 FLANGE
|
0-91150-210-0 |
02 |
1 |
9406-9407 |
|
|
|
● |
|
|
| |
18 |
NUT; EXH MANIF
M10
|
9-09110-510-0 |
02 |
1 |
9408-9502 |
|
|
|
● |
|
|
| |
18 |
NUT; EXH MANIF
M10
|
9-09110-510-0 |
02 |
1 |
9503-9703 |
|
|
|
● |
● |
|
| |
18 |
NUT; EXH MANIF
M10
|
9-09110-510-0 |
02 |
1 |
9704- |
|
|
|
● |
● |
● |
| |
21 |
BOLT; HEAT PROTECTOR
M6X12 W/LK&PL WASHER
|
0-50140-612-0 |
04 |
1 |
9304-9502 |
● |
● |
|
|
|
|
| |
21 |
BOLT; HEAT PROTECTOR
S TIRE&SHORT CHASSIS(NKB1SC)
FLAT LOW&SHORT CHASSIS(NKN1SC)
M/T MSB5S(R45)
AIR CONDITIONER MANUAL CONT(C60),AIR
CONDITIONER AUTOMATIC CONT(C61)
TACHOMETER<U16>
FRIGID ZONE(YL3)
FRT INDEPENDENT SUSPENSION(6PP)
GENERATOR 60A(86M)
EXC. REFRIGERATOR CHASSIS(V4R)
M6X12 W/LK&PL WASHER
|
0-50140-612-0 |
03 |
1 |
9304-9409 |
|
|
● |
|
|
|
| |
21 |
BOLT; HEAT PROTECTOR
S TIRE&SHORT CHASSIS(NKB1SC)
FLAT LOW&SHORT CHASSIS(NKN1SC)
M/T MSB5S(R45)
AIR CONDITIONER MANUAL CONT(C60),AIR
CONDITIONER AUTOMATIC CONT(C61)
FRT INDEPENDENT SUSPENSION(6PP)
EXC. REFRIGERATOR CHASSIS(V4R)
M6X12 W/LK&PL WASHER
|
0-50140-612-0 |
03 |
1 |
9304-9409 |
|
|
● |
|
|
|
| |
21 |
BOLT; HEAT PROTECTOR
S TIRE&SHORT CHASSIS(NKB1SC)
FLAT LOW&SHORT CHASSIS(NKN1SC)
M/T MSB5S(R45)
AIR CONDITIONER MANUAL CONT(C60),AIR
CONDITIONER AUTOMATIC CONT(C61)
FRT INDEPENDENT SUSPENSION(6PP)
EXC. REFRIGERATOR CHASSIS(V4R)
M6X12 W/LK&PL WASHER
|
0-50140-612-0 |
03 |
1 |
9410-9502 |
|
|
● |
|
|
|
| |
21 |
BOLT; HEAT PROTECTOR
S TIRE&SHORT CHASSIS(NKB1SC)
W TIRE/FULL FLAT LOW & SHORT CHASSIS(NKC1SC)
W TIRE & MIDDLE CHASSIS(NKC1SF)
FLAT LOW&SHORT CHASSIS(NKN1SC)
FLAT LOW/FULL FLAT LOW &MIDDLE CHASSIS(NKN1SF)
AIR CONDITIONER MANUAL CONT(C60),AIR
CONDITIONER AUTOMATIC CONT(C61)
FLOOR REMOTE SHIFT<M11>
FRT INDEPENDENT SUSPENSION(6PP)
EXC. REFRIGERATOR CHASSIS(V4R)
M6X12 W/LK&PL WASHER
|
0-50140-612-0 |
03 |
1 |
9503-9509 |
|
|
● |
|
|
|
| |
21 |
BOLT; HEAT PROTECTOR
SHORT CHASSIS(NK***C)
FLOOR REMOTE SHIFT<M11>
REFRIGERATOR CHASSIS(V4R)
FRT INDEPENDENT SUSPENSION(6PP)
EXC. AIR CONDITIONER MANUAL CONT(C60),AIR
CONDITIONER AUTOMATIC CONT(C61)
M6X12 W/LK&PL WASHER
|
0-50140-612-0 |
03 |
1 |
9510-9703 |
|
|
● |
|
|
|
| |
21 |
BOLT; HEAT PROTECTOR
MIDDLE CHASSIS(NK***F)
AIR CONDITIONER MANUAL CONT(C60),AIR
CONDITIONER AUTOMATIC CONT(C61)
FLOOR REMOTE SHIFT<M11>
FRT INDEPENDENT SUSPENSION(6PP)
EXC. REFRIGERATOR CHASSIS(V4R)
M6X12 W/LK&PL WASHER
|
0-50140-612-0 |
03 |
1 |
9510-9703 |
|
|
● |
|
|
|
| |
21 |
BOLT; HEAT PROTECTOR
SHORT CHASSIS(NK***C)
AIR CONDITIONER MANUAL CONT(C60),AIR
CONDITIONER AUTOMATIC CONT(C61)
FLOOR REMOTE SHIFT<M11>
FRT INDEPENDENT SUSPENSION(6PP)
M6X12 W/LK&PL WASHER
|
0-50140-612-0 |
03 |
1 |
9510-9703 |
|
|
● |
|
|
|
| |
21 |
BOLT; HEAT PROTECTOR
AIR CONDITIONER MANUAL CONT(C60)
M6X12 W/LK&PL WASHER
|
0-50140-612-0 |
03 |
1 |
9704- |
|
|
● |
|
|
|
| |
21 |
BOLT; HEAT PROTECTOR
M6X10 FLANGE
|
0-28080-610-0 |
08 |
1 |
9304-9402 |
|
|
|
● |
|
|
| |
21 |
BOLT; HEAT PROTECTOR
M6X12 FLANGE
|
8-97108-669-0 |
08 |
1 |
9403-9410 |
|
|
|
● |
|
|
| |
21 |
BOLT; HEAT PROTECTOR
M6X12 FLANGE
|
8-97108-669-0 |
06 |
1 |
9411-9502 |
|
|
|
● |
|
|
| |
21 |
BOLT; HEAT PROTECTOR
M6X28 W/LK&PL WASHER
|
8-97028-387-1 |
08 |
1 |
9503-9703 |
|
|
|
● |
● |
|
| |
21 |
BOLT; HEAT PROTECTOR
M6X28 W/LK&PL WASHER
|
8-97028-387-1 |
08 |
1 |
9704- |
|
|
|
● |
● |
● |
| |
34 |
COLLAR; DIST,EXH MANIF
L=24.0
|
8-94396-410-0 |
08 |
1 |
9304-9406 |
|
|
|
● |
|
|
| |
34 |
COLLAR; DIST,EXH MANIF
L=28
|
8-97108-653-0 |
08 |
1 |
9407-9502 |
|
|
|
● |
|
|
| |
34 |
COLLAR; DIST,EXH MANIF
L=28
|
8-97108-653-0 |
08 |
1 |
9503-9703 |
|
|
|
● |
● |
|
| |
34 |
COLLAR; DIST,EXH MANIF
L=28
|
8-97108-653-0 |
08 |
1 |
9704- |
|
|
|
● |
● |
● |
