Isuzu WW
▶
TRUCKS
▶
CYH
▶
11198 - CYH NZ EURO4/JAPAN NEW LONG TERM 2005
▶
8 - Chassis Electrical, Heating / Air Conditioning, Wipers, Radio
▶
8-20 - METER CABLE
▶
8-20 — METER CABLE
(#16110) — 16 parça
◀
[820A] PROTECTOR;SENSOR (2 parça)
[820A] SPEED SENSOR (14 parça)
▶
228
237
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
228
PROTECTOR; SENSOR
EMISSION REGULATION NEW LONG TERM<JBG>
8-97621-446-0
01
1
1006-
237
BOLT; PROTECTOR
EMISSION REGULATION NEW LONG TERM<JBG> M8X20 FLANGE
0-28050-820-0
02
1
1006-
150
129
6
62
6
150
151
151
Balon
Parca Adi
Parca No
Adet
Tip
Applied Date
6
HOLDER; SPD SENSOR
1-83129-260-1
02
1
0904-
6
HOLDER; SPD SENSOR
1-83129-260-1
02
1
0904-
62
BOLT; SENSOR
M8X16
9-05820-816-0
02
1
0904-1506
62
BOLT; SENSOR
M8X16 HEX SOCKET
0-58330-816-0
02
1
1507-
129
COLLAR
1-83129-471-0
02
1
0904-
129
COLLAR
1-83129-471-0
02
1
0904-
150
SENSOR; SPEED,ABS
(A)
1-83127-853-3
02
1
0904-
150
SENSOR; SPEED,ABS
(A)
1-83127-853-3
02
1
0904-
150
SENSOR; SPEED,ABS
(B)
8-98130-586-0
01
1
0904-
150
SENSOR; SPEED,ABS
(B)
8-98130-587-0
01
1
0904-
151
BRACKET; SPD SENSOR
(A)
1-83129-405-0
01
1
0904-1504
151
BRACKET; SPD SENSOR
(B)
8-98299-398-0
01
1
1505-
151
BRACKET; SPD SENSOR
(A)
1-83129-406-0
01
1
0904-1504
151
BRACKET; SPD SENSOR
(B)
8-98299-399-0
01
1
1505-
